HTC Windows Mobile SmartPhone User manual

Smartphone
User Manual

2
Congratulations on the purchase of your new Windows Mobile®
Smartphone!
Please Read Before Proceeding.
THE BATTERY IS NOT FULLY CHARGED WHEN YOU TAKE IT OUT OF THE BOX.
DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.
YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER WITH THE
DEVICE’S OUTER CASING.
PRIVACY RESTRICTIONS
Some countries require full disclosure of recorded telephone conversations, and
stipulate that you must inform the person with whom you are speaking that the
conversation is being recorded. Always obey the relevant laws and regulations of
your country when using the recording feature of your phone.
TRADEMARK AND COPYRIGHT INFORMATION
Copyright © 2006 High Tech Computer Corp. All rights reserved.
, , , ExtUSB and JOGGR are trademarks and/or
service marks of High Tech Computer Corp.
Microsoft, MS-DOS, Windows, Windows NT, Windows Server, Windows Mobile,
ActiveSync, Excel, Internet Explorer, MSN, Hotmail, Outlook, PowerPoint, Word,
and Windows Media are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc.
Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.
microSD is a trademark of SD Card Association.
Java, J2ME and all other Java-based marks are trademarks or registered
trademarks of Sun Microsystems, Inc. in the United States and other countries.
Copyright © 2006, Adobe Systems Incorporated.
Copyright © 2006, Macromedia Netherlands, B.V.
Macromedia, Flash, Macromedia Flash, Macromedia Flash Lite and Reader are
trademarks and/or registered trademarks of Macromedia Netherlands, B.V. or

3
Adobe Systems Incorporated.
Copyright © 2006, JATAAYU SOFTWARE (P) LTD. All Rights Reserved.
Copyright © 2006, Dilithium Networks, Inc. All Rights Reserved.
ArcSoft MMS Composer™ Copyright © 2003-2006, ArcSoft, Inc. and its licensors.
All Rights Reserved. ArcSoft & the ArcSoft logo are registered trademarks of
ArcSoft, Inc. in the United States and/or other countries.
ClearVue is a trademark of WESTTEK, LLC.
Sprite Backup is a trademark or service mark of Sprite Software.
Licensed by QUALCOMM Incorporated under one or more of the following
patents:
4,901,307 ; 5,490,165 ; 5,056,109 ; 5,504,773 ; 5,101,501 ; 5,778,338 ; 5,506,865
5,109,390 ; 5,511,073 ; 5,228,054 ; 5,535,239 ; 5,710,784 ; 5,267,261 ; 5,544,196
5,267,262 ; 5,568,483 ; 5,337,338 ; 5,659,569 5,600,754 ; 5,414,796 ; 5,657,420
5,416,797
All other company, product and service names mentioned herein are trademarks,
registered trademarks or service marks of their respective owners.
HTC shall not be liable for technical or editorial errors or omissions contained
herein, nor for incidental or consequential damages resulting from furnishing
this material. The information is provided “as is” without warranty of any kind
and is subject to change without notice. HTC also reserves the right to revise the
content of this document at any time without prior notice.
No part of this document may be reproduced or transmitted in any form or by
any means, electronic or mechanical, including photocopying, recording or
storing in a retrieval system, or translated into any language in any form without
prior written permission of HTC.

4
Important Health Information and Safety
Precautions
When using this product, the safety precautions below must be
taken to avoid possible legal liabilities and damages.
Retain and follow all product safety and operating instructions.
Observe all warnings in the operating instructions on the
product.
To reduce the risk of bodily injury, electric shock, fire and
damage to the equipment, observe the following precautions.
ELECTRICAL SAFETY
This product is intended for use when supplied with power
from the designated battery or power supply unit. Other usage
may be dangerous and will invalidate any approval given to this
product.
SAFETY PRECAUTIONS FOR PROPER GROUNDING
INSTALLATION
CAUTION – Connecting to an improperly grounded equipment
can result in an electric shock to your device.
This product is equipped with a USB cable for connecting the
product to a desktop or notebook computer. Be sure your
computer is properly grounded (earthed) before connecting the
product to the computer. The power supply cord of a desktop
or notebook computer has an equipment-grounding conductor
and a grounding plug. The plug must be plugged into an
appropriate outlet which is properly installed and grounded in
accordance with all local codes and ordinances.
SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT
• Use the correct external power source
A product should be operated only from the type of power
source indicated on the electrical ratings label. If you are
not sure of the type of power source required, consult your
authorized service provider or local power company. For a
product that operates from battery power or other sources,

5
refer to the operating instructions that are included with the
product.
• Handle battery packs carefully
This product contains a Li-Ion/Li-Ion Polymer battery. There
is a risk of fire and burns if the battery pack is handled
improperly. Do not attempt to open or service the battery
pack. Do not disassemble, crush, puncture, short external
contacts or circuits, dispose of in fire or water, or expose a
battery pack to temperatures higher than 60˚C (140˚F).
WARNING! Danger of explosion if battery is incorrectly
replaced. To reduce risk of fire or burns, do not
disassemble, crush, puncture, short external
contacts, expose to temperature above 60oC
(140oF), or dispose of in fire or water. Replace only
with specified batteries. Recycle or dispose of used
batteries according to the local regulations or
reference guide supplied with your product.
SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT
Keep this product away from excessive moisture and extreme
temperatures. Do not leave the product or its battery inside a
vehicle or in places where the temperature may exceed 60°C
(140°F), such as on a car dashboard, window sill, or behind a
glass that is exposed to direct sunlight or strong ultraviolet light
for extended periods of time. This may damage the product,
overheat the battery, or pose a risk to the vehicle.

6
PREVENTION OF HEARING LOSS
CAUTION –Permanent hearing loss may occur if earphones or
headphones are used at high volume for prolonged periods of
time.
Note: For France, Headphones, Earphones, and Wired
Remote Controller (listed below) for this device have
been tested to comply with the Sound Pressure
Level requirement laid down in the applicable NF
EN 50332-1:2000 and NF EN 50332-2:2000 standards
as required by French Article L. 5232-1.
1. Earphone, manufactured by HTC or Cotron,
Models CHM-60STV07002
SAFETY IN AIR CRAFTS
Due to the possible interference caused by this product to an
aircraft’s navigation system and its communications network,
using this device’s phone function on board an airplane is
against the law in most countries. If you want to use this device
when on board an aircraft, remember to turn off your phone by
switching to Flight Mode.
ENVIRONMENT RESTRICTIONS
Do not use this product in gas stations, fuel depots, chemical
plants or where blasting operations are in progress, or in
potentially explosive atmospheres such as fuelling areas, fuel
storehouses, below deck on boats, chemical plants, fuel or
chemical transfer or storage facilities, and areas where the air
contains chemicals or particles, such as grain, dust, or metal
powders. Please be aware that sparks in such areas could cause
an explosion or fire resulting in bodily injury or even death.

7
EXPLOSIVE ATMOSPHERES
When in any area with a potentially explosive atmosphere or
where flammable materials exist, the product should be turned
off and the user should obey all signs and instructions. Sparks
in such areas could cause an explosion or fire resulting in bodily
injury or even death. Users are advised not to use the equipment
at refueling points such as service or gas stations, and are
reminded of the need to observe restrictions on the use of radio
equipment in fuel depots, chemical plants, or where blasting
operations are in progress. Areas with a potentially explosive
atmosphere are often, but not always, clearly marked. These
include fueling areas, below deck on boats, fuel or chemical
transfer or storage facilities, and areas where the air contains
chemicals or particles, such as grain, dust, or metal powders.
ROAD SAFETY
Vehicle drivers in motion are not permitted to use telephony
services with handheld devices, except in the case of emergency.
In some countries, using hands-free devices as an alternative is
allowed.
SAFETY PRECAUTIONS FOR RF EXPOSURE
• Avoid using your device near metal structures (for
example, the steel frame of a building).
• Avoid using your device near strong electromagnetic
sources, such as microwave ovens, sound speakers, TV and
radio.
• Use only original manufacturer-approved accessories, or
accessories that do not contain any metal.
• Use of non-original manufacturer-approved accessories
may violate your local RF exposure guidelines and should
be avoided.

8
INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS
This product may cause medical equipment to malfunction. The
use of this device is forbidden in most hospitals and medical
clinics.
If you use any other personal medical device, consult the
manufacturer of your device to determine if it is adequately
shielded from external RF energy. Your physician may be able to
assist you in obtaining this information.
Turn the phone OFF in health care facilities when any
regulations posted in these areas instruct you to do so. Hospitals
or health care facilities may be using equipment that could be
sensitive to external RF energy.
HEARING AIDS
Some digital wireless phones may interfere with some hearing
aids. In the event of such interference, you may want to consult
your service provider, or call the customer service line to discuss
alternatives.
NONIONIZING RADIATION
This product should be operated in the suggested normal
condition only to ensure the radiative performance and safety
of the interference. As with other mobile radio transmitting
equipment, users are advised that for satisfactory operation
of the equipment and for the safety of personnel, it is
recommended that no part of the human body be allowed
to come too close to the antenna during operation of the
equipment.
General Precautions
• Heed service markings
Except as explained elsewhere in the Operating or Service
documentation, do not service any product yourself. Service
needed on components inside the device should be done
by an authorized service technician or provider.

9
• Damage requiring service
Unplug the product from the electrical outlet and refer
servicing to an authorized service technician or provider
under the following conditions:
• Liquid has been spilled or an object has fallen into the
product.
• The product has been exposed to rain or water.
• The product has been dropped or damaged.
• There are noticeable signs of overheating.
• The product does not operate normally when you follow
the operating instructions.
• Avoid hot areas
The product should be placed away from heat sources
such as radiators, heat registers, stoves, or other products
(including, but limited to, amplifiers) that produce heat.
• Avoid wet areas
Never use the product in a wet location.
• Avoid using your device after a dramatic change in
temperature
When you move your device between environments
with very different temperature and/or humidity ranges,
condensation may form on or within the device. To avoid
damaging the device, allow sufficient time for the moisture
to evaporate before using the device.
Note: When taking the device from low-temperature conditions
into a warmer environment or from high-temperature
conditions into a cooler environment, allow the device
to acclimate to room temperature before turning on the
power.

10
• Avoid pushing objects into product
Never push objects of any kind into cabinet slots or other
openings in the product. Slots and openings are provided
for ventilation. These openings must not be blocked or
covered.
• Mounting Accessories
Do not use the product on an unstable table, cart, stand,
tripod, or bracket. Any mounting of the product should
follow the manufacturer’s instructions, and should use a
mounting accessory recommended by the manufacturer.
• Avoid unstable mounting
Do not place the product with an unstable base.
• Use product with approved equipment
This product should be used only with personal computers
and options identified as suitable for use with your
equipment.
• Adjust the volume
Turn down the volume before using headphones or other
audio devices.
• Cleaning
Unplug the product from the wall outlet before cleaning. Do
not use liquid cleaners or aerosol cleaners. Use a damp cloth
for cleaning, but NEVER use water to clean the LCD screen.

11
Contents
Chapter 1 Getting Started 15
1.1 Getting to Know Your Phone and
Its Accessories .......................................................16
1.2 Inserting the USIM/SIM Card ...............................22
1.3 Installing a microSD Card .....................................23
1.4 The Home Screen ..................................................24
1.5 Status Indicators and Program Icons ..................25
1.6 Using the Start Menu ............................................30
1.7 Using the Quick List ..............................................30
1.8 Entering Information ............................................31
1.9 Battery Information ..............................................33
Chapter 2 Using Phone Features 35
2.1 Using the Phone ....................................................36
2.2 Making a Voice Call ...............................................37
2.3 Receiving a Voice Call ...........................................40
2.4 In-Call Options ......................................................40
2.5 Additional Dialing Information ...........................42
2.6 SIM Tool Kit (STK) ..................................................43
2.7 Setting Up Bluetooth SIM Access
for Car Kit Phones ................................................44

12
Chapter 3 Synchronizing Information
and Setting Up E-mail Security 45
3.1 About ActiveSync ..................................................46
3.2 Setting Up ActiveSync ..........................................46
3.3 Synchronizing Information ..................................49
3.4 Synchronizing via Bluetooth ...............................55
3.5 Synchronizing Music, Video, and Pictures ..........55
3.6 Setting Up E-mail Security ...................................57
Chapter 4 Managing Your Phone 59
4.1 Personalizing Your Phone ....................................60
4.2 Adding and Removing Programs ........................66
4.3 Using Task Manager and Managing Memory .....67
4.4 Managing Files ......................................................68
4.5 Backing Up Data ...................................................71
4.6 Protecting Your Phone .........................................74
4.7 Restarting Your Phone ..........................................76
4.8 Resetting Your Phone ...........................................76
Chapter 5 Getting Connected 77
5.1 Connecting to the Internet ..................................78
5.2 Using Internet Explorer Mobile ...........................82
5.3 Using Internet Sharing .........................................84

13
5.4 Using Comm Manager ..........................................85
5.5 Using Bluetooth ....................................................87
5.6 Using Wi-Fi Connection ........................................98
Chapter 6 Exchanging Messages and
Using Outlook 101
6.1 Using E-mail and Text Messages ........................102
6.2 Using MMS Messages .........................................110
6.3 Using Pocket MSN ...............................................118
6.4 Using Calendar ....................................................120
6.5 Using Contacts ...................................................121
6.6 Using Tasks ..........................................................127
6.7 Using Voice Notes ...............................................128
6.8 Using Voice Recorder ..........................................129
Chapter 7 Experiencing Multimedia 131
7.1 Using Camera and Video Recorder ....................132
7.2 Using Pictures & Videos ......................................142
7.3 Using Windows Media Player .............................147
7.4 Using MIDlet Manager ........................................155
7.5 Using Streaming Media ......................................161
7.6 Using Audio Manager .........................................163

14
Chapter 8 Using Other Applications 171
8.1 Using ClearVue Office .........................................172
8.2 Using Adobe Reader LE ......................................175
8.3 Using Speed Dial .................................................176
8.4 Using Voice Speed Dial .......................................178
Appendix 181
A.1 Regulatory Notices ..............................................182
A.2 PC Requirement to Run ActiveSync 4.x .............188
A.3 Specifications ......................................................189
Index 193

Chapter 1
Getting Started
1.1 Getting to Know Your Phone and Its
Accessories
1.2 Inserting the USIM/SIM Card
1.3 Installing a microSD Card
1.4 The Home Screen
1.5 Status Indicators and Program Icons
1.6 Using the Start Menu
1.7 Using the Quick List
1.8 Entering Information
1.9 Battery Information

16 Getting Started
1.1 Getting to Know Your Phone and Its
Accessories
1
3
4
5
6
7
8
9
11
14
13
15
2
12
16
17
10
18
19
20
21

Getting Started 17
Item Function
1. Speaker Listen to a phone call.
2. LED Indicator This indicator (green/red/amber) notifies you of
the battery and network status of your phone.
3. Display Screen
4. Left SOFT KEY Press to perform the command shown in the
label above the button.
5. TALK Press to dial a phone number, answer a call,
switch to another call, or put a call on hold. Press
and hold to activate/deactivate speakerphone
mode .
6. HOME Press to go to the Home Screen.
7. QWERTY Keyboard This is similar to a standard keyboard on a PC.
8. Key
Press once to let you type symbols (characters in
green) and enter numbers in text fields. Press two
more times for continuous symbol or number
entries.
9. Microphone Speak into the microphone when receiving or
making a phone call or during voice recording.
10. Key
Press to type a single capital letter. Press the FN
key, then this key to type in all caps.
11. Key Press to open the Symbol table.
12. Key
Press the FN key and this key to open Comm
Manager.
13. Key Press to open Internet Explorer Mobile.
14. BACK Press to go to the previous screen, or backspace
over characters.
15. END Press to end a call, or press and hold to lock the
phone.
16. Right SOFT KEY Press to perform the command shown in the
label above the button.
17. NAVIGATION
CONTROL/CENTER OK
Use to scroll left, right, up, or down. Press the
center to use as the CENTER OK button.

18 Getting Started
Item Function
18. Light Sensor Dark conditions sensed here will activate a
backlight under the keyboard.
19. LED Indicator This indicator (blue/green/amber) notifies you
of Bluetooth and Wi-Fi connectivity status.
20. Sync Connector/
Earphone Jack
Pry open the plastic cover to connect the USB
cable to synchronize data or recharge the
battery. You can also connect the earphone
to listen to audio media or use the phone’s
hands-free kit.
21. Release Lock Press to release the back cover lock.
31
26
23
22
27
24
25
28
29
30
A
B
C

Getting Started 19
Item Function
22. Speakers Listen to audio media or a phone call when using
speakerphone mode.
23. Camera Lens
24. Self-Portrait
Mirror
Turn the back side of your phone to face yourself so
that your image reflects on the mirror when taking
self-portrait shots.
25. POWER Press (more than 1 second) to turn on and off the
phone. Or press and quickly release the POWER
button to display the Quick List, which allows you to
change profiles, open Comm Manager, and enable/
disable key lock and enable/disable device lock.
26. microSD slot Pry open the plastic cover to insert a microSD card.
27. VOICE
RECOGNITION/
VOICE NOTES
Press to open the voice recognition program; Press
and hold to open Voice Notes.
28. Car Antenna
Connector
Lets you attach your phone to the car antenna for
better network reception. Remove the back cover,
then peel off the rubber cap and connect the
antenna jack.
29. Back Cover Remove to insert battery and USIM/SIM card.
30. CAMERA Press to open the Camera program.
31. JOGGR Depending on the selected JOGGR function, slide the
middle part up or down to adjust the volume or to
go through the items on-screen.
A Double-click to go back to the previous screen.
B Slide up or down to scroll up/down or adjust the
volume. Double-click to select an item.
C Double-click to open the Messaging program.
Click Start > Settings > JOGGR to set the
appropriate function the JOGGR will be used for.
Clear the Enable JOGGR box to disable the JOGGR.
You can only open the tutorial with 3 clicks if you set
the Function to either Scroll or Adjust volume.

20 Getting Started
LED indicator lights
Various colors that might display in the two LED Indicators are
summarized here.
Left LED Status
Solid green Battery is fully charged.
Blank Battery case is empty, no USIM/SIM card
inserted or phone is off.
Solid amber Battery is charging or the phone is using
ActiveSync to synchronize with a PC.
Solid red Battery is not installed or battery is over-
discharged.
Blinking green Connected to the network.
Blinking red Battery very low (less than 10%).
Blinking amber Battery temperature is hotter or colder than
the functional limits of 0 to 48 degrees Celsius
(32 to 118 degrees Fahrenheit), and has
stopped charging.
Amber/Green LED off Battery fault. The “Battery Fault” indicator
( ) is displayed. In this case, the blinking
green LED can be recovered by unplugging
the AC adapter.
Right LED Status
Blinking blue Bluetooth mode set to “On” or “Visible” mode.
Blinking green Connected to Wi-Fi network.
