Huawei APAA00001 User manual

APAA00001
User Manual
Issue Draft A
Date 2015-06-12
HUAWEI TECHNOLOGIES CO., LTD.

Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
i
Copyright © Huawei Technologies Co., Ltd. 2015. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address:
Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website:
http://www.huawei.com
Email:
[email protected]

APAA00001
User Manual
About This Document
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii
About This Document
Overview
This document describesAPAA00001, typical usage, software installation and operation, and
method for using, operating, and maintaining APAA00001.
Intended Audience
This document is intended for:
Technical support engineers
Maintenance engineers
Documentation Obtaining
The electronic version of this document can be obtained from http://support.huawei.com.
Change History
Changes between document issues are cumulative. The latest document issue contains all the
changes in earlier issues.
Document Issue
Draft A (2015-06-12)
This is draft A.

APAA00001
User Manual
Contents
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iii
Contents
About This Document.................................................................................................................... ii
1 Introduction to PAA .....................................................................................................................1
1.1 Overview ......................................................................................................................................................................1
1.2 Product Specifications ..................................................................................................................................................1
1.3 Appearance Description................................................................................................................................................2
1.3.1 Appearance ................................................................................................................................................................2
1.3.2 Accessory List............................................................................................................................................................5
2 App Installation Guidelines .......................................................................................................8
2.1 App Download by Scanning the QR Code....................................................................................................................8
2.2 App Download from the Website..................................................................................................................................9
3 Networking Guideline...............................................................................................................10
3.1 Before Network Deployment......................................................................................................................................10
3.2 Typical Scenarios........................................................................................................................................................10
3.2.1 ALD Control over the AISG Port.............................................................................................................................10
3.2.2 ALD Control over the OOK Port............................................................................................................................. 11
3.3 Procedure....................................................................................................................................................................12
4 System Maintenance...................................................................................................................15
4.1 Routine Maintenance..................................................................................................................................................15
4.1.1 Battery .....................................................................................................................................................................15
4.1.2 PAAShell.................................................................................................................................................................16
4.1.3 Silicone Shell...........................................................................................................................................................16
4.2 Alarm Handling ..........................................................................................................................................................16
4.2.1 Hardware Fault Alarm Handling..............................................................................................................................16
4.2.2 AISG/OOK Overcurrent Alarm Handling................................................................................................................17
4.2.3 Battery Not in Position Alarm Handling..................................................................................................................19
4.3 Troubleshooting..........................................................................................................................................................19
4.3.1 Battery Fault ............................................................................................................................................................19
4.3.2 PAAPower-On/Off Failure......................................................................................................................................19
5 FCC Statements ...........................................................................................................................21
5.1 Warning Statement FCC §15.21 ................................................................................................................................21
5.2 Statement FCC §15.19...............................................................................................................................................21

APAA00001
User Manual
Contents
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iv
5.3 FCC Radiation Exposure Statement: ..........................................................................................................................21
5.4 IC RSS warning..........................................................................................................................................................21
A Appendix .....................................................................................................................................23
A.1 Acronyms and Abbreviations.....................................................................................................................................23
A.2 Alarm Codes ..............................................................................................................................................................25

APAA00001
User Manual
1 Introduction to PAA
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1
1 Introduction to PAA
1.1 Overview
The portable AISG adapter (PAA) is an adapter that enables users to control antenna line
devices (ALDs) using the PAA app. With a rechargeable battery inside, the PAA has a small
size and can be carried easily, facilitating onsite ALD installation, commissioning, and
maintenance.
APAA00001, the current PAA model, can provide working current toALDs and implement
conversions between bluetooth signals and RS485/OOK signals so thatALDs can be
controlled by using an app.
APAA00001 can be used to control all types of Huawei ALDs. If the PAA is to be used with
the ALDs supplied by peer vendors, you are advised to perform joint commissioning to
confirm their compatibility with each other.
1.2 Product Specifications
Table 1-1 provides the product specifications ofAPAA00001.
Table 1-1 Product specifications ofAPAA00001
Electrical Specifications
Operating
Power Supply
Input: 12 V DC 2.0 A (AC/DC adapter)
Output: 12 V DC 1.0 A (AC/DC adapter) or 15 V DC 1.0 A
(rechargeable battery)
Rechargeable
Battery
Lithium battery: 14.8 V (≥ 2000 mAh)
Maximum number of battery charging/discharging times: > 300
AISG
Connector
Female AISG
connector equipped
with eight pins
compliant with the
IEC 60130-9 and
AISG standards
Pin 1 and pin 6
DC (+12 V) (AC/DC
adapter)
DC (+15 V) (rechargeable
battery)
Pin 3
RS485 B

APAA00001
User Manual
1 Introduction to PAA
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2
Electrical Specifications
Pin 5
RS485 A
Pin 7
DC return
Environmental Specifications
Operating
Temperature
–20°C to +55°C
Storage
temperature
0°C to +45°C
Recharge
temperature
0°C to 40°C
Humidity
5% to 95%
Service Life
Three years
Mechanical Specifications
Weight
0.52 kg (including the weight of a rechargeable battery)
Dimensions (H
x W x D)
204 mm x 88 mm x 30 mm
Material
PC+ABS (30%)
1.3 Appearance Description
1.3.1 Appearance
Figure 1-1 shows the appearance and dimensions of APAA00001.

APAA00001
User Manual
1 Introduction to PAA
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3
Figure 1-1 Appearance and dimensions ofAPAA00001
Figure 1-2 APAA00001 appearance
(1) AISG connection port
(2) Strap hole
(3) OOK connection port

APAA00001
User Manual
1 Introduction to PAA
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4
(4) Power supply indicator
(5) Communication indicator
(6) Alarm indicator
(7) Power button
(8) Mini USB port
(9) 12 V DC adapter port
Table 1-2 Ports onAPAA00001
No.
Port
Description
1
AISG connection
port
Connects the PAA to an ALD using an AISG cable.
2
Strap hole
Used to fasten straps so that the PAA can be carried easily.
3
OOK connection
port
Connects the PAA to an ALD using an RF cable.
4, 5,
and 6
Indicators
Indicate the power supply, communication, and alarm
status of the PAA. For details, see Table 1-3
7
Power button
Used to power on or off the PAA. The PAA can be
powered on or off by holding down this button.
8
Mini USB port
Reserved for further development and is not used
temporarily.
9
12 V DC adapter
port
Connects to the AC/DC adapter. When an AC/DC adapter
is connected, the PAA automatically uses the input power
supply as the operating power supply to charge the
integrated battery.
Table 1-3 Indicators
No.
Indicator and
Silkscreen
Description
4
Power indicator (PWR)
Indicates the power supply state. The indicator has
four working status:
Steady green: The PAA has sufficient battery
power.
Steady yellow: The PAA has moderate battery
power.
Steady red: The PAA has low battery power.
Blinking at the frequency of 1 Hz: The battery
inside the PAA is being recharged.
5
Communication
indicator (COM)
The indicator blinks when the mobile app has been
successfully connected to the PAA and
communication is proper.
6
Alarm indicator (ALM)
The indicator is steady red when the PAA generates an
alarm.

APAA00001
User Manual
1 Introduction to PAA
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
1.3.2 Accessory List
Table 1-4 lists the accessories of APAA00001.
Table 1-4 Accessories ofAPAA00001
No.
Accessory
Quantity
1
12 V DC adapter
1 PCS
2
AC power cable
1 PCS
3
AISG 1-to-2 cable
1 PCS
4
N(M)-DIN(M) adapter
1 PCS
5
N(M)-DIN(F) adapter
1 PCS
6
RF cable
1 PCS
7
Strap
1 PCS
8
User manual
1 PCS
12 V DC Adapter
The adapter parameters are as follows:
Input: 100 VAC to 240 VAC, 0.8A, 50 Hz to 60 Hz
Output: 12 V DC, 2.0 AAC/DC
Figure 1-3 shows the 12 V DC adapter.
Figure 1-3 12 V DC adapter
AISG 1-to-2 Cable
The cable specifications are as follows:
Connectors: Each AISG 1-to-2 cable has three 8-core connectors that comply with the
IEC 60130-9 standard: one female connector and two male connectors.

APAA00001
User Manual
1 Introduction to PAA
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6
Cable: complies with the UL2464 standard.
Figure 1-4 AISG 1-to-2 cable
N(M)-DIN(M) Adapter
Figure 1-5 N(M)-DIN(M) adapter
N(M)-DIN(F) Adapter
Figure 1-6 N(M)-DIN(F) adapter
RF Cable
Figure 1-7 RF cable

APAA00001
User Manual
1 Introduction to PAA
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7
AC Power Cable
China standard Power is as shown in figure 1-8,According to the different delivery area, the
cable will be different.
Figure 1-8 AC power cable
Strap
Figure 1-9 Strap

APAA00001
User Manual
2 App Installation Guidelines
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8
2 App Installation Guidelines
Before you use the PAA to control an ALD, the PAA mobile app must be installed on your
smartphone. The app can be downloaded by scanning the QR code or from the website.
Currently, PAA is available only on Android smartphones.
PAA has the following requirements for smartphones:
Android 4.0 or later
1.5 GHz CPU or higher
1 GB flash memory or higher
2.1 App Download by Scanning the QR Code
Procedure
Step 1 Scan the QR code on the back of the PAA using the QR code scanning function of your
smartphone, and then download the PAA app after the scanning is successful.( Some browsers
may have use restrictions can not download, can replace try different browsers).
Figure 2-1 QR code of the PAAapp

APAA00001
User Manual
2 App Installation Guidelines
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9
Figure 2-2 PAAapp installation
Step 2 Click Open. On the displayed Please Connect to Bluetooth dialog box, click OK to enter the
GUI for selecting bluetooth devices, and click the bluetooth device name of the PAA to
connect the PAA. The bluetooth device name of the PAA consists of PAA and the last eight
characters of the bar code labeled on the back of the PAA, and the bluetooth password is 1234.
Communication between the smartphone and the PAA through bluetooth can be checked
based on the connection state between them.
After the connection is successful, the app notifies the user that the PAA has been
connected, and the main PAA GUI is displayed. In this situation, the communication
indicator on the PAA blinks.
If the connection fails, a notification indicating the failure is displayed at the lower part
of the bluetooth GUI, and the bluetooth selection GUI of the app is still displayed.
2.2 App Download from the Website
Visit the following URL using the web browser of your smartphone and download the PAA
app:
http://w3m-beta.huawei.com/m/Service/ClientDownloadServlet?osType=3&appId=258&flag
=0
The installation method is the same as that used when the QR code is scanned.

APAA00001
User Manual
3 Networking Guideline
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10
3 Networking Guideline
3.1 Before Network Deployment
Before using the PAA, ensure that the following preparations have been made:
The AISG cable or RF cable has been connected to theALD.
The PAA app has been installed properly.
The battery inside the PAA is fully charged. If no, recharge the PAA or connect the PAA
to the power adapter.
The mode in which the PAA controls an ALD depends on theALD capability.
If theALD supports only the RS485 control mode, the PAA controls theALD over the
AISG port. For details, see section 3.2.1 "ALD Control over the AISG Port."
If theALD supports only the OOK control mode, the PAA controls the ALD over the
OOK port. For details, see section 3.2.2 "ALD Control over the OOK Port."
If theALD supports both OOK and RS485 control modes, the PAA selects the control
mode based on actual situations.
3.2 Typical Scenarios
3.2.1 ALD Control over the AISG Port
The AISG output port on the PAA is connected to theAISG input port on the ALD using an
AISG cable, as shown in Figure 3-1.

APAA00001
User Manual
3 Networking Guideline
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11
Figure 3-1 ALD control over theAISG port (when an external RCU is used)
The total length of the AISG cable cannot exceed 50 m.
Connectors and cables can be used for transfer during cable connection.
The external power supply switch of the PAAmust be turned on when the ALD is connected. Figure
3-4 shows the external power supply switch of the PAA.
3.2.2 ALD Control over the OOK Port
The OOK port on the PAA is connected to the RF port on theALD, as shown in Figure 3-2.

APAA00001
User Manual
3 Networking Guideline
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
12
Figure 3-2 ALD control over the OOK port
The total length of the RF cable cannot exceed 50 m.
Connectors and cables can be used for transfer during cable connection.
The external power supply switch of the PAAmust be turned on when the ALD is connected. Figure
3-4 shows the external power supply switch of the PAA.
3.3 Procedure
Step 1 Select the networking drawing for cable connection based on the ALD capability.
Step 2 Power on the PAA. When the power indicator is steady on, the PAA is powered on properly.
If the PAA cannot be powered on, recharge the PAA by using the AC/DC adapter of the PAA.
When the PAA is being recharged, the power indicator blinks.
Step 3 Open the PAA app on the smartphone and then perform bluetooth pairing based on the
displayed messages. The bluetooth device name of the PAA consists of PAA and the last
eight characters of the bar code labeled on the back of the PAA. The bluetooth password is

APAA00001
User Manual
3 Networking Guideline
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
13
1234. After bluetooth pairing is successful, the communication indicator on the PAA blinks,
and the PAA app indicates that the PAA has been connected successfully, as shown in Figure
3-3.
Figure 3-3 PAAsuccessfully connected
Step 4 Tap the power switch on the app to turn on the external power supply switch of the PAA, as
shown in Figure 3-4. If the power switch on the app turns white, the external power supply
switch of the PAA has been turned on. If the power switch on the app turns gray, the external
power supply switch of the PAA has been turned off.
Figure 3-4 Turning on the external power supplyswitch of the PAA
In actual application, the PAA app GUI may slightly vary with app versions. For details, see
the online help of the app.
Figure 3-5 Opening the online help of the PAAapp
Power button to turn on
the external power
supply

APAA00001
User Manual
3 Networking Guideline
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
14
Obtain the online help from the menu

APAA00001
User Manual
4 System Maintenance
Draft A (2015-06-12)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
15
4 System Maintenance
4.1 Routine Maintenance
During the use and maintenance of the PAA, its battery and shell must be protected.
4.1.1 Battery
The rechargeable battery inside the PAA is a lithium battery. Inappropriate use of the battery
may compromise its life cycle or even lead to safety risks.
The battery cannot be overly recharged or discharged. Otherwise, its life cycle is
compromised.
The PAA must be recharged and discharged at least once every one or two months if it is
not used for a long time.
The dedicatedAC/DC adapter of the PAA must be saved properly. Do not use other
models ofAC/DC adapters to recharge the PAA.
If the PAA is used without any external power supply, ensure that the PAA is fully
recharged.
The PAA must not be used or placed near high-temperature sources, such as fire or
heaters. Otherwise, the battery may be overheated, disconnected, or even fail, thereby
compromising the battery life.
The PAA cannot be used in places with strong electrostatic and magnetic fields.
Otherwise, the battery safety protection unit may be damaged, causing safety issues.
If the battery becomes smelly, overheated, discolored, or deformed, or any other
exception occurs during its use, storage, and recharging, remove the battery from the
PAA immediately and stop using the battery.
Unused batteries must be properly disposed. The electrical polarity can be wrapped up using insulation
material to prevent fire.
The battery may fail if either of the following conditions are met:
−The battery is fully recharged within 1 hour after the recharging starts.
−An alarm indicating low battery power is displayed within 0.5 hour after the battery is
used.
In this case, contact Huawei technical support to replace the battery.
The rechargeable battery inside the PAA is provided by the battery supplier specified by
Huawei. If the battery needs to be replaced, contact Huawei technical support.
