HUAWEI SE2900 Session Border Controller
V300R002C10
Hardware Description
Issue
01
Date
2016-01-15
HUAWEI TECHNOLOGIES CO., LTD.

Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
i
Copyright © Huawei Technologies Co., Ltd. 2016. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address:
Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website:
http://www.huawei.com
Email:
[email protected]

HUAWEI SE2900 Session Border Controller
Hardware Description
Contents
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii
Contents
1 Service Processing Device ...........................................................................................................1
1.1 Subrack Datasheet ........................................................................................................................................................2
1.2 Subrack Classification and Numbering Rules ..............................................................................................................5
1.3 F8002 DC Subrack .......................................................................................................................................................6
1.3.1 PEM.........................................................................................................................................................................12
1.3.2 Fan Tray...................................................................................................................................................................15
1.4 F8002 AC Subrack......................................................................................................................................................17
1.4.1 AC PSU....................................................................................................................................................................24
1.4.2 Fan Tray...................................................................................................................................................................28
1.5 F8002 Subrack System Topology Structure................................................................................................................30
1.5.1 CAN Bus..................................................................................................................................................................30
1.5.2 Base Topology Structure..........................................................................................................................................31
1.5.3 eFabric Topology Structure......................................................................................................................................32
1.6 F8002 Subrack System Monitoring ............................................................................................................................33
1.6.1 Power Module Monitoring.......................................................................................................................................33
1.6.2 Fan Tray Monitoring................................................................................................................................................33
1.7 MXU...........................................................................................................................................................................34
1.7.1 MXUA0...................................................................................................................................................................34
1.8 SPU.............................................................................................................................................................................45
1.8.1 SPUA0.....................................................................................................................................................................45
1.8.2 SPUA1.....................................................................................................................................................................53
1.8.3 SPUZ0 .....................................................................................................................................................................61
1.9 VPU ............................................................................................................................................................................69
1.9.1 VPUA0 ....................................................................................................................................................................69
1.9.2 VPUA1 ....................................................................................................................................................................77
1.10 Filler Panel................................................................................................................................................................85
2 Other Accessories........................................................................................................................87
2.1 Alarm Box...................................................................................................................................................................87
2.2 Optical Module...........................................................................................................................................................91
2.3 Electrical Module........................................................................................................................................................98
3 Cables ..........................................................................................................................................101
3.1 Power Cables and PGND Cables..............................................................................................................................101

HUAWEI SE2900 Session Border Controller
Hardware Description
Contents
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iii
3.1.1 Power and PGND Cables to a Subrack..................................................................................................................101
3.1.2 Power Cables of the Alarm Box.............................................................................................................................104
3.2 Signaling Cables.......................................................................................................................................................105
3.2.1 Ethernet Cable .......................................................................................................................................................105
3.2.2 LC/PC-LC/PC-Multi-Mode Optical Cable............................................................................................................108
3.2.3 DLC/PC-DLC/PC-Multi-Mode Optical Cable ......................................................................................................109
3.2.4 LC/PC-LC/PC-Single-Mode Optical Cable........................................................................................................... 110
3.2.5 MPO/PC-MPO/PC-Multi-Mode Optical Cable..................................................................................................... 112
3.2.6 High-Density Cable ............................................................................................................................................... 113
3.2.7 DB9-RJ45 Serial Cable.......................................................................................................................................... 115

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1
1 Service Processing Device
About This Chapter
1.1 Subrack Datasheet
1.2 Subrack Classification and Numbering Rules
1.3 F8002 DC Subrack
1.4 F8002 AC Subrack
1.5 F8002 Subrack System Topology Structure
1.6 F8002 Subrack System Monitoring
1.7 MXU
1.8 SPU
1.9 VPU
1.10 Filler Panel

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2
1.1 Subrack Datasheet

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
1.2 Subrack Classification and Numbering Rules
Subrack Numbering Rules
Each subrack has a unique number.
The subracks in a cabinet are numbered in ascending order from bottom to top. The basic
subrack is the first subrack from the bottom and is numbered 0.
If there are multiple cabinets, the subracks are numbered in ascending order based on the
cabinet numbers.
Figure 1-1 illustrates how subracks are numbered.
Figure 1-1 Subrack numbering rules
Figure 1-1 uses a cabinet configured with more than two subracks as an example. Number subracks
based to the subrack numbering rule depending on the actual situation.
Subrack Slot Numbering Rules
The slots in an subrack are numbered from 1 in ascending order from bottom to top and then
from left to right.
Figure 1-2 illustrates how the slots are numbered in an F8002 subrack.

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6
Figure 1-2 Slot numbering rules in the F8002 subrack
The slot identifiers are labeled inside the subrack.
1.3 F8002 DC Subrack
Functions
Table 1-1 describes the functions of the F8002 subrack.
Table 1-1 F8002 subrack functions
Function
Description
Power supply
Two power entry modules (PEMs) are configured in 1+1
redundancy mode. Each PEM supplies DC power to the entire
subrack through the backplane.
Data transmission
The F8002 subrack provides data transmission channels.
Heat dissipation
Two fan trays are configured to dissipate heat for the subrack.
Subrack identification
Each F8002 subrack has a unique number.
If the subrack number is not set, the subrack number indicators are blinking in sequence. For details
about how to set the subrack number, see Hardware-Specific Modifications.
Appearance
Figure 1-3 shows an F8002 subrack.

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7
Figure 1-3 F8002 subrack (unit: mm)
Each F8002 subrack provides six slots for installing the multi-function switch units (MXUs)
and service boards. Figure 1-4 shows the slot positions of the F8002 subrack.
Figure 1-4 F8002 subrack slot positions
The F8002 subrack provides:
Slots 2 and 5 for MXUs.
Slots 1, 3, 4, and 6 for service boards.

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8
PEM 1 and PEM 2 for PEMs.
Fan 1 and Fan 2 for fan trays.
Figure 1-5 shows the front view of an F8002 subrack in full configuration.
Figure 1-5 Front view of an F8002 subrack in full configuration
Figure 1-6 shows the rear view of an F8002 subrack.
Figure 1-6 Rear view of an F8002 subrack
Table 1-2 describes the components of the F8002 subrack.
Table 1-2 F8002 subrack components
Componen
t
Quantit
y
Description
MXU
2
The MXUs implement operation, maintenance, and
management of the system.
Two MXUs are installed in slots 2 and 5 to work in
active/standby mode.
Service
boards
4
The service boards can be installed in slots 1, 3, 4, and 6. The
service boards in any two slots can be configured in
active/standby mode.
PEM
2
Two PEMs are configured in 1+1 redundancy mode. If one

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9
Componen
t
Quantit
y
Description
PEM is faulty, the power supply to the subrack is not affected.
Fan tray
2
Two fan trays are configured to draw in cool air from the front
of the subrack and exhaust warm air from the rear of the
subrack. Figure 1-7 shows the air flows.
Ground
point
2
The F8002 subrack provides two ground points.
If the subrack is used in North America, connect both ground
points. If the subrack is used in other regions, only connect one
of the ground points.
Electrostatic
discharge
(ESD) jack
1
The F8002 subrack provides one ESD jack.
Figure 1-7 Heat dissipation in the subrack
Figure 1-8 shows the power supply mode of the F8002 subrack. Each PEM supplies power to
all slots and fan trays in the subrack.

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10
Figure 1-8 F8002 subrack power supply mode
Logical Structure
Figure 1-9 shows the logical structure of the F8002 subrack.
Figure 1-9 F8002 subrack logicalstructure
The MXUs implement subrack management and data exchange in the subrack.
The MXUs work in active/standby mode. Only the active MXU executes management
tasks. The MXUs also manage the two fan trays through the RS485 bus and the two
PEMs through the Inter-integrated circuit (I2C) bus.
The service data and signaling data from a service board is forwarded in eFabric
channels to the MXUs through the backplane. The MXUs then forward the data to
another service board.
The management data from a service board is forwarded in Base channels to the MXUs
through the backplane. The MXUs then forward the data to another service board.
The power distribution box (PDB) in the subrack provides two DC power supplies to the
subrack.

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11
Hardware and Software Compatibility
Table 1-3 lists the boards that can be used in F8002 subracks.
Table 1-3 Types of boards in the F8002 subrack
MXU Type
Compatible Service
Board Type
Compatibility Rule
MXU
SPU
VPU
-
Technical Specifications
Table 1-4 lists the technical specifications of the F8002 subrack.
Table 1-4 F8002 subrack technical specifications
Item
Specifications
Mechanical
specificatio
ns
Dimensions (H x W x D)
130.5 mm x 442.0 mm x 675.0 mm (5.14 in. x
17.40 in. x 26.57 in.)
Weight of an empty
subrack
20.8 kg (45.86 lb)
NOTE
An empty subrack is equipped with two fan trays
and two PEMs.
Weight of a fully loaded
subrack
47.8 kg (105.38 lb)
NOTE
A fully loaded subrack is equipped with two fan
trays, two PEMs, two MXUA0s, and four SPUA0s.
Power
supply
Rated input voltage
-48 V DC to -60 V DC
Operating voltage
-40 V DC to -72 V DC
Total power inputs
Two
Rated input current
60 A/power input
Power rating
2400 W (The rated power of each PEM is
2400 W)
NOTE
The subrack is configured with two PEMs in 1+1
redundancy mode.
Environme
ntal
specificatio
ns
Temperature
Long-term operating temperature: 0°C to
45°C (32°F to 113°F)
Short-term operating temperature: -5°C to
+55°C (23°F to 131°F)
Storage temperature: -40°C to +70°C
(-40°F to +158°F)

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
12
Item
Specifications
Humidity
Long-term operating humidity: 5% RH to
85% RH (non-condensing)
Short-term operating humidity: 5% RH to
95% RH (non-condensing)
Storage humidity: 10% RH to 95% RH
(non-condensing)
Altitude
-60 m to +4000 m (-196.85 ft to +13123.20 ft)
Short term means that the consecutive working period is not more than 96 hours and that the cumulative
working period over a year is not more than 15 days.
1.3.1 PEM
Functions
Table 1-5 describes the functions of the power entry module (PEM).
Table 1-5 PEM functions
Function
Description
Power supply
Supplies power to devices in the subrack.
Supports wide input voltage range.
Power
distribution
monitoring
Detects the installation status and type of PEMs.
Provides the indicators on the panel to indicate PEM status.
Detects the voltage and power of the subrack.
Detects the status of the circuit breakers and surge protection circuits.
Detects the PEM temperature.
Reports voltage, current, and power information in real time.
Implements the electronic label function.
Protection
Implements surge protection, short circuit protection, and
over-current protection.
Prevents incorrect insertion.
Appearance
Figure 1-10 shows a PEM.

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
13
Figure 1-10 PEM
Figure 1-11 shows the PEM panel.
Figure 1-11 PEM panel
1. STATUS
indicator
2. Power input
terminal RTN(+)
3. Power input terminal
protective cover
4. Handle

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
14
5. Captive
screw
6. Circuit breaker
7. Power input terminal
NEG(-)
8. Circuit breaker
protective cover
The circuit breaker is switched on when it is turned up and is switched off when it is turned down.
Indicators
Table 1-6 describes the STATUS indicator on the PEM panel.
Table 1-6 STATUS indicator on the PEM panel
Silk
Screen
Meaning
State
State Description
STATUS
Status
indicator
Off
There is no power supply.
Green
The PEM is operating properly.
Red
The power supply is abnormal.
The surge protection circuit is faulty.
The circuit breaker is faulty.
Technical Specifications
Table 1-7 lists the technical specifications of the PEM.
Table 1-7 PEM technical specifications
Item
Specifications
Mechanical
specificatio
ns
Dimensions (H x W x
D)
122.5 mm x 65.0 mm x 122.7 mm (4.82 in. x
2.60 in. x 4.83 in.)
Weight
1.0 kg (2.20 lb)
Input terminal
Duplex M6
Voltage
and current
Rated input voltage
-48 V DC to -60 V DC
Maximum input voltage
-40 V DC to -72 V DC
Total power inputs
1
Rated input current
60 A/power input
PEM voltage drop
≤ 0.5 V
Power rating
2400 W
Environme
ntal
specificatio
Temperature
Long-term operating temperature: 0°C to
45°C (32°F to 113°F)
Short-term operating temperature: -5°C to

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
15
Item
Specifications
ns
+55°C (23°F to 131°F)
Storage temperature: -40°C to +70°C (-40°F
to +158°F)
Relative humidity
≤ 95% RH
Altitude
-60 m to +4000 m (-196.85 ft to +13123.20 ft)
Short term means that the consecutive working period is not more than 96 hours and that the cumulative
working period over a year is not more than 15 days.
1.3.2 Fan Tray
Functions
Table 1-8 describes the functions of the fan tray.
Table 1-8 Fan tray functions
Function
Description
Heat dissipation
The fan trays draw in cool air from the front of the subrack and
exhaust warm air from the rear of the subrack.
Monitoring
Fan monitoring boards are configured for fan trays to:
Provide ports for communicating with the switch boards.
Detect and report the fan operating status and speed values.
Control the health indicators on the fan trays.
Support fan blocking status detection and reports fan
alarms.
Support online software upgrades and log uploads.
Monitor and report the fan temperature.
Detect the fan tray installation status.
Speed adjustment
The fan speed can be automatically or manually adjusted based
on the ambient temperature, implementing fan speed
adjustment for low-power operating.
Hot swap
Online replacement is supported.
Appearance
Figure 1-12 shows a fan tray.

HUAWEI SE2900 Session Border Controller
Hardware Description
1 Service Processing Device
Issue 01 (2016-01-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
16
Figure 1-12 Fan tray
Indicators
There is an indicator on the panel of a fan tray, showing the fan tray operating status. Table
1-9 describes the indicator on the panel.
Table 1-9 Health indicator on the fan tray
Silk Screen
Meaning
State
State Description
None
Health indicator
Off
The fan monitoring
module is not powered on.
Blinking green
Blinking at 0.5 Hz: The
fan tray is operating
properly, and the
communication is
normal.
Blinking at 4 Hz: The
fan tray is operating
properly, but the
communication is
abnormal.
Steady orange
The fan monitoring
module is powered on, but
the hardware is abnormal.
Blinking red at 0.5
Hz
An alarm is generated.
