Huawei HG655a User manual

HUAWEI HG655a
Home Gateway Quick Start
1
1 Introduction
1.1 Contents in the package
HG655a Splitter Power Adapter
Telephone Cables Ethernet Cable User CD-ROM
General Public
License
Warranty Card

1.2 The Front Panel of the HG655a
The front panel of the HG655a provides the following indicators:
zOne power indicator: POWER
zOne ADSL indicator: DSL
zOne Internet indicator: INTERNET
zFour LAN indicators: LAN1,LAN2,LAN3,LAN4
zOne VoIP indicator: VOIP
1.3 The Rear Panel of the HG655a
The rear panel of the HG655a provides the following interfaces and buttons:
zOne ADSL interface: DSL
zTwo RJ-11 phone interfaces: PHONE1, PHONE2
zFour LAN interfaces: LAN1,LAN2,LAN3,LAN4
zOne RESET and ON/OFF buttons: RESET, ON/OFF
2
zOne POWER interface: POWER

3
2 Installation Guide
To connect the cables for installing the HG655a, do as follows:
1 Telephone jack on the wall 2 Splitter 3 Telephone
4 PC 5 Set-top box 6 Power adapter

2.1 Connecting the HG655a to the Fixed Network
Step 1 Connect the telephone jack on the wall to the LINE interface on the splitter
with a telephone cable. Connect the telephone to the PHONE interface on the
splitter with a telephone cable.
####
#### ####
LINE PHONE
Step 2 Connect the DSL interface on the HG655a to the MODEM interface on the
splitter with a telephone cable.
4

2.2 Connecting telephones to the HG655a
Connect a telephone to the PHONE1 or PHONE2 interface of the HG655a. The
connection methods are as follows:
zIf you have two VoIP numbers, you can connect two telephones to the PHONE1
and PHONE2 interfaces respectively.
zIf you have no VoIP number and use only the PSTN function, then connect the
telephone to the PHONE interface through splitter, refer to 2.1 Connecting the
HG655a to the Fixed Network.
2.3 Connecting the PC to the HG655a
Connect Ethernet interface on the computer to any of the four LAN interfaces on the
rear panel of HG655a with an Ethernet cable.
5

2.4 Supplying Power to the HG655a
Connect the power adapter to the power interface on the back of the HG655a and plug
the power adapter into a wall outlet.
After you power on the HG655a, the DSL indicator blinks (for less than three
minutes), which indicates that the HG655a is being activated. After the DSL
indicator stops blinking, the POWER and DSL indicators turn solid on, which
indicates that the HG655a is working properly.
6

7
3 Configuring the HG655a
You can access the Internet by use the following two methods:
zUsing the Embedded PPP Dial-Up Software of the HG655a to Get Online
zUsing the PPP Dial-Up Software of the Computer to Get Online
Please use the parameters provided by your internet service provider (ISP) for
configuration. If the configuration is wrong, you will not be able to access the
Internet.
Using the Embedded PPP Dial-Up Software of the
HG655a to Get Online
Step 1
Step 2
Step 3
Configure the HG655a to enable the embedded dial-up function
1. Connect the HG655a with your computer by using the Ethernet cable.
2. Start Internet Explorer on your computer and enter the http://192.168.1.1
in the address bar, and then press Enter.
3. The Login dialog box is displayed.
4. Enter the administrator name (admin by default) and password (admin
by default) in the Login dialog box, and then click OK.
Configure the ATM PVC.
1. In the navigation tree, choose Basic > ATM.
2. Click New.
3. Enter VPI and VCI in the VPI/VCI text box provided by the Internet
Service Provider.
4. Select EoA from the DSL link type option button, and keep the default
settings of other parameters.
5. Click Submit.
Just keep the default settings for PTM.
Enable the embedded dial-up function
1. In the navigation tree on the left of the Web-based configuration utility,
choose Basic > WAN.
2. Click New.
3. Select a PVC from the Layer2 interface drop-down combo box.
The HG655a supports ADSL/VDSL compliance uplink. When choose the ADSL
uplink mode, the name of PVC should be composed by the value of VPI and VCI.
When choose the VDSL uplink mode, the name of PVC should begin with ptm.

8
4. Select VOICE_TR069_INTERNET from the Service list drop-down
combo box.
5. Select Route from the Connection mode drop-down combo box.
6. Select PPPoE option button for Connection type.
7. Enter the user name and password that are provided by the network
operator in the User name and Password text boxes, and keep the default
settings of other parameters.
8. Click Submit to save the settings.
After you complete the preceding settings, you can surf the Internet. You need to
perform the preceding operations on a computer once only.
Using the PPP Dial-Up Software of the Computer to Get
Online
Step 1
Step 2
Configure the HG655a to work in the bridge mode
For details, refer to the Step 3 in section "Using the Embedded PPP Dial-Up Software
of the HG655a to Get Online." Note that Bridge is selected from the Connection mode
drop-down combo box.
Configure your computer
The PPP dial-up software is pre-installed on certain computer operating systems. To
create a dial-up connection, do as follows (taking the Windows XP operating system as
an example):
1. Choose Start > All Programs > Accessories > Communications >
Network Connections.
2. Click Create a new connection in Network Tasks to display the New
Connection Wizard window, and then click Next.
3. Select Connect to the Internet, and then click Next.
4. Select Set up my connection manually, and then click Next.
5. Select Connect using a broadband connection that requires a user
name and password, and then click Next.
6. Enter the name (as desired) of the dial-up connection in ISP Name, and
then click Next.
7. Select Anyone's use or My use only, and then click Next.
8. Enter the user name and password provided by the Internet Service
Provider and used for the dial-up connection, and then click Next.
9. Select Add a shortcut to this connection to my desktop, and then click
Finish.
To access the network, double-click the icon for the dial-up connection on the desktop
of your computer, enter the password and username provided by the Internet Service
Provider, and then click Connect. You need to perform the preceding operations only
once for creating a network connection.
