Huawei EC152 User manual


HUAWEIEC152
UserGuide


TableofContents
1.Introduction................................................................................................................ 1
2.SystemRequirements ................................................................................................. 1
3.EC152Appearance...................................................................................................... 2
4.TechnicalSpecifications .............................................................................................. 3
5.InsertingamicroSDCard ............................................................................................ 4
6.Usingthedevice.......................................................................................................... 5
InstallationProcedureforWindowsXP ..................................................................... 5
InstallationProcedureforMacOS ........................................................................... 15
7.Troubleshooting........................................................................................................ 25
8.CareandMaintenance.............................................................................................. 26
9.WarningsandPrecautions ........................................................................................ 27
i

1
1. Introduction
CongratulationsonyourpurchaseofHuaweiEC152TATAPhotonPlusUSBDataModem
Device.

TheUserGuidecontainsimportantinformationontheproperuseandcorrect
operationofHuaweiEC152TATAPhotonPlusUSBDataModemDevice.We
recommendthatyoureadthismanualcarefullytoensureoptimalperformance.

2. SystemRequirements
•PCwithUSBPort
•Windows2000SP4,WindowsXPSP2/SP3,WindowsVistaSP1/SP2,Windows7
MacOSX10.4,10.5and10.6withlatestupgrades
•Hardwareconfigurationshouldsatisfythedemandoftheoperatingsystem.
•DisplayResolution：Above800x600
Note:
IfyourPChaslowerconfiguration，theperformanceofEC152maybelower.

2
3. EC152Appearance
1
2
3

Pleasefindbelowthedescriptionthatyouneedtoknowtostartusingyourdevice.
NameDescription
1.USBPlugItconnectsEC152toaPC.
2.Indicatorlight•Solid:EC152ispoweredon.
•Blinkingonceevery2seconds:EC152issearchingfor
anetworkornonetworkisfound.
•Blinkingtwiceevery2seconds:EC152findsa
network.
•Blinkingonceevery0.2second:EC152is
transmittingdata.
3.microSDcardSlotInstallingmicroSDcard

3
4. TechnicalSpecifications
ModemTypeUSBDongleNON‐RIUM
Mode EVDOREVA
Frequency(Band)800MHz
AntennaTypeInternal
Dimension 83.0mm×26.6mm×11.5mm
MemoryCardSlotSupportmicroSDcard
ExternalMemorySupport Upto4GB


4
5. InsertingamicroSDCard
1. SlidethebackcovertoremoveitfromEC152.
2. InsertthemicroSDcardintothecorrespondingcardslot,asshowninthefollowing
figure.
3. Replacethebackcoverandslideitintoplace.


5
6. Usingthedevice
Fordifferentoperatingsystem,theinstallationprocessisdifferent.Pleasenotethe
processforthefollowingOperatingSystems
InstallationProcedureforWindowsXP
1．ConnectEC152withPC
ConnectEC152withPCviaUSBport.




6
2．InstallEC152Dialer&Driver
IfPCopenstheautorunfunction,itwillpopupaninstallationinterface.Ifnot,please
gotoCDasshowninthefigurebelowandopenitanddoubleclickthe“AutoRun.exe”
fileorrightclickandclickonAutoplay.

Pleaserefertothefollowingscreenshotsforthefurtherstepsofinstallation


7

Click“Next“andthentoagreewiththelicenseagreementclick“IAgree”.


Click“Next“andthenchoosealocationpathforinstallationandclickinstall.Incase
youdonothaveanyspecificlocationpreferenceyoumaychoosetocontinuewiththe
defaultlocationandclick“Install”.


8








9

Pleaseclickon“Finish”button.


Afterinstallation,pleasegobacktodesktop,clickontheicon”Tata
Photon+” .Themaininterfaceappears
Whentheinstallationiscomplete,thefollowingdialerappears




10

1. Assoonastheinstallationiscompletethedefaultdialerwillappearasfollows


2. Pleaseclickonthe“Continue”button.Onclickingthebutton,thedialerappearsas
follows.Clickonthe“Activate”buttonasshowninthebelowfigure







11
3. Onclickingthe“Activate”button,thefollowingscreenappears.Pleaseselectthe
Prepaid/Postpaidoptiondependingontheservicesthatyouwishtooptfor.

Gentlyscratchthesilverstriponthe“Activationcard”youhavereceivedwiththekit,
torevealyour14‐digitPIN.Enteryour14digitPINnumberintextboxbelow“Enter
PIN”.

Pleaseclickonthe”Activate”button



12

4. Onclickingthe“Activate”button,thefollowingscreenappears.Themovingbars
indicatethattheactivationisinprogress.

5. Youmayhavetowaitforacoupleofminutes.Onceactivationissuccessful,youwill
seethefollowingscreen

13
6. Clickonthe“Connect”buttonandstartsurfing.

Incasetheactivationfails,thefollowingsequenceofstepsneedstobefollowed
1. Incaseactivationisunsuccessful,youwillseethefollowingprompt



14
2. Pleaseclickonthe“OK”button.Thefollowingscreenwillappear.Pleaseclickonthe
“Activate”buttonasshowninthebelowfigure.Pleaserepeatthesamesequenceas
statedabovetocontinue.





15
Un‐installationofApplicationSoftware
1. ExitManagementprocedures.
2. RemovetheEC152devicefromthesystemthenpullitout.
3. Open“Add/Removeprogram”inthecontrolpanel.
4. Accordtheprompt,finishun‐installation.
InstallationProcedureforMacOS
1．ConnectEC152withPC
ConnectEC152withPCviaUSB.





16
2．InstallEC152Dialer&Driver
InserttheEC152deviceintocomputer

Doubleclickiconof“MobilePartner”,
Click“Continue”tostarttheinstallation.


17

ReadtheSoftwareLicenseAgreementthenclick“Continue”.

Click“Agree”toacceptthelicenseagreement.


