Huawei AR500 Technical specifications

Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
V200R008
Product Description
Issue 02
Date 2016-11-25
HUAWEI TECHNOLOGIES CO., LTD.

Copyright © Huawei Technologies Co., Ltd. 2016. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior written
consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and the
customer. All or part of the products, services and features described in this document may not be within the
purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,
and recommendations in this document are provided "AS IS" without warranties, guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://e.huawei.com
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
i

About This Document
Intended Audience
This document helps you understand the characteristics and features of the AR.
This document is intended for:
lNetwork planning engineers
lHardware installation engineers
lCommissioning engineer
lData configuration engineers
lOn-site maintenance engineers
lNetwork monitoring engineers
lSystem maintenance engineers
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Description
Indicates an imminently hazardous situation
which, if not avoided, will result in death or
serious injury.
Indicates a potentially hazardous situation
which, if not avoided, could result in death
or serious injury.
Indicates a potentially hazardous situation
which, if not avoided, may result in minor
or moderate injury.
Indicates a potentially hazardous situation
which, if not avoided, could result in
equipment damage, data loss, performance
deterioration, or unanticipated results.
NOTICE is used to address practices not
related to personal injury.
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description About This Document
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii

Symbol Description
NOTE
Calls attention to important information,
best practices and tips.
NOTE is used to address information not
related to personal injury, equipment
damage, and environment deterioration.
Security Conventions
lPassword setting
–When configuring a password, the cipher text is recommended. To ensure device
security, change the password periodically.
–When you configure a password in plain text that starts and ends with %@%@, @
%@%, %#%#, or %^%# (the password can be decrypted by the device), the
password is displayed in the same manner as the configured one in the
configuration file. Do not use this setting.
–When you configure a password in cipher text, different features cannot use the
same cipher-text password. For example, the cipher-text password set for the AAA
feature cannot be used for other features.
lEncryption algorithm
Currently, the device uses the following encryption algorithms: 3DES, AES, RSA,
SHA1, SHA2, and MD5. 3DES, RSA and AES are reversible, while SHA1, SHA2, and
MD5 are irreversible. The encryption algorithms DES/3DES/RSA (RSA-1024 or
lower)/MD5 (in digital signature scenarios and password encryption)/SHA1 (in digital
signature scenarios) have a low security, which may bring security risks. If protocols
allowed, using more secure encryption algorithms, such as AES/RSA (RSA-2048 or
higher)/SHA2/HMAC-SHA2, is recommended. The encryption algorithm depends on
actual networking. The irreversible encryption algorithm must be used for the
administrator password, SHA2 is recommended.
lPersonal data
Some personal data may be obtained or used during operation or fault location of your
purchased products, services, features, so you have an obligation to make privacy
policies and take measures according to the applicable law of the country to protect
personal data.
lThe terms mirrored port, port mirroring, traffic mirroring, and mirroring in this manual
are mentioned only to describe the product's function of communication error or failure
detection, and do not involve collection or processing of any personal information or
communication data of users.
Mappings Between Product Software Versions and NMS
Versions
The mappings between product software versions and NMS versions are as follows.
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description About This Document
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iii

AR500&AR510&AR530&AR550
&AR2500 Product Software
Version
eSight
V200R008(C00&C20&C30) V300R006C00
Change History
Changes between document issues are cumulative. Therefore, the latest document version
contains all updates made to previous versions.
Changes in Issue 02 (2016-11-25)
This version has the following updates:
The following information is modified:
l8.1 Router Purchase List
Changes in Issue 01 (2016-07-30)
Initial commercial release.
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description About This Document
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iv

Contents
About This Document.....................................................................................................................ii
1 Product Positioning and Characteristics................................................................................... 1
1.1 Product Positioning.........................................................................................................................................................2
1.2 Product Characteristics................................................................................................................................................... 2
1.2.1 Industrial Environment Adaptability........................................................................................................................... 2
1.2.2 Industry-Class Reliability............................................................................................................................................ 2
1.2.3 Service Integration Capability..................................................................................................................................... 3
1.2.4 Hardware Extensibility................................................................................................................................................ 3
1.2.5 Remote Maintenance Capability................................................................................................................................. 3
1.2.6 Strong Access Capability.............................................................................................................................................3
2 Applications....................................................................................................................................4
2.1 AR530 as a Industrial Router......................................................................................................................................... 5
2.2 AR500 or AR530 as the Industrial Switch..................................................................................................................... 5
2.3 AR2500 Used as the Industrial Switch...........................................................................................................................6
2.4 AR500&AR530 Used as Industrial Gateways............................................................................................................... 8
3 Product Characteristics............................................................................................................... 10
3.1 Feature List................................................................................................................................................................... 11
3.2 Key Features................................................................................................................................................................. 34
3.2.1 SEP............................................................................................................................................................................ 34
3.2.2 VPN........................................................................................................................................................................... 34
3.2.3 Security......................................................................................................................................................................35
3.2.4 QoS............................................................................................................................................................................ 37
3.2.5 IPv6............................................................................................................................................................................38
3.2.6 WLAN....................................................................................................................................................................... 39
4 Appearance................................................................................................................................... 41
4.1 AR500 Series................................................................................................................................................................42
4.1.1 AR502EG-L...............................................................................................................................................................42
4.1.2 AR502EGW-L........................................................................................................................................................... 43
4.1.3 AR502CG-L.............................................................................................................................................................. 45
4.1.4 AR503GW-LM7........................................................................................................................................................47
4.1.5 AR503GW-LcM7...................................................................................................................................................... 48
4.1.6 AR503EDGW-Lc...................................................................................................................................................... 49
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description Contents
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
v

4.1.7 AR509G-L-D-H.........................................................................................................................................................51
4.1.8 AR509G-Lc............................................................................................................................................................... 52
4.1.9 AR509CG-Lc.............................................................................................................................................................54
4.1.10 AR509CG-Lt........................................................................................................................................................... 56
4.1.11 AR503EQGW-L...................................................................................................................................................... 58
4.1.12 AR503EW............................................................................................................................................................... 59
4.2 AR510 Series................................................................................................................................................................60
4.2.1 AR511GW-LAV2M3.................................................................................................................................................60
4.2.2 AR511CGW-LAV2M3.............................................................................................................................................. 62
4.2.3 AR511GW-LM7........................................................................................................................................................ 63
4.2.4 AR511GW-L-B3........................................................................................................................................................65
4.2.5 AR513W-V3M8........................................................................................................................................................ 66
4.2.6 AR515GW-LM9-D....................................................................................................................................................68
4.3 AR530 Series................................................................................................................................................................69
4.3.1 AR531-2C-H............................................................................................................................................................. 69
4.3.2 AR531-F2C-H........................................................................................................................................................... 70
4.3.3 AR531GPe-U-H........................................................................................................................................................ 72
4.3.4 AR531G-U-D-H........................................................................................................................................................ 73
4.4 AR550 Series................................................................................................................................................................75
4.4.1 AR550C-4GE............................................................................................................................................................ 75
4.4.2 AR550C-2C6GE........................................................................................................................................................76
4.5 AR2500 Series..............................................................................................................................................................78
4.5.1 AR2504-H................................................................................................................................................................. 78
4.5.2 AR2504E-H............................................................................................................................................................... 79
4.5.3 AR2504-D-H............................................................................................................................................................. 79
5 Maintenance and Management................................................................................................ 81
5.1 Various Maintenance Methods..................................................................................................................................... 82
5.1.1 Remote Deployment and Maintenance Using USB.................................................................................................. 82
5.1.2 SNMP-based Maintenance........................................................................................................................................ 82
5.1.3 CLI-based Maintenance.............................................................................................................................................82
5.2 Fault Location...............................................................................................................................................................82
5.2.1 Device Fault Location............................................................................................................................................... 82
5.2.2 Routing Service Fault Location.................................................................................................................................83
6 Industry Standards......................................................................................................................84
7 Technical Specifications.............................................................................................................85
7.1 AR500 Series................................................................................................................................................................86
7.1.1 AR502EG-L...............................................................................................................................................................86
7.1.2 AR502EGW-L........................................................................................................................................................... 87
7.1.3 AR502CG-L.............................................................................................................................................................. 88
7.1.4 AR503GW-LM7........................................................................................................................................................89
7.1.5 AR503GW-LcM7...................................................................................................................................................... 91
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description Contents
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
vi

7.1.6 AR503EDGW-Lc...................................................................................................................................................... 93
7.1.7 AR509G-L-D-H.........................................................................................................................................................94
7.1.8 AR509G-Lc............................................................................................................................................................... 96
7.1.9 AR509CG-Lc.............................................................................................................................................................98
7.1.10 AR509CG-Lt........................................................................................................................................................... 99
7.1.11 AR503EQGW-L.................................................................................................................................................... 100
7.1.12 AR503EW............................................................................................................................................................. 102
7.2 AR510 series...............................................................................................................................................................104
7.2.1 AR511GW-LAV2M3...............................................................................................................................................104
7.2.2 AR511CGW-LAV2M3............................................................................................................................................ 105
7.2.3 AR511GW-LM7...................................................................................................................................................... 107
7.2.4 AR511GW-L-B3......................................................................................................................................................109
7.2.5 AR513W-V3M8.......................................................................................................................................................111
7.2.6 AR515GW-LM9-D..................................................................................................................................................113
7.3 AR530 Series.............................................................................................................................................................. 114
7.3.1 AR531-2C-H............................................................................................................................................................114
7.3.2 AR531-F2C-H......................................................................................................................................................... 116
7.3.3 AR531GPe-U-H.......................................................................................................................................................117
7.3.4 AR531G-U-D-H...................................................................................................................................................... 118
7.4 AR550 Series..............................................................................................................................................................120
7.4.1 AR550C-4GE.......................................................................................................................................................... 120
7.4.2 AR550C-2C6GE......................................................................................................................................................121
7.5 AR2500 Series............................................................................................................................................................122
7.5.1 AR2504-H............................................................................................................................................................... 122
7.5.2 AR2504E-H............................................................................................................................................................. 124
7.5.3 AR2504-D-H........................................................................................................................................................... 125
8 Component Selection Guide................................................................................................... 128
8.1 Router Purchase List...................................................................................................................................................129
8.2 Card Category.............................................................................................................................................................132
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description Contents
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
vii

1 Product Positioning and Characteristics
About This Chapter
1.1 Product Positioning
1.2 Product Characteristics
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description 1 Product Positioning and Characteristics
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1

1.1 Product Positioning
The AR500&AR510&AR530&AR550&AR2500 Industrial Switch Routers, developed by
Huawei, is applied to the Internet of Things. It is a next-generation industrial routing gateway
that provides routing, switching, wireless, and security functions. In addition to gateway
functions, the AR500&AR510&AR530&AR550&AR2500 provides various extensions. For
example, it can function as the gateway on the Internet of Things to aggregate data. It applies
to various industries.
The AR500&AR510&AR530&AR550&AR2500 can work stably in challenging industry
environments for a long time, meeting local and remote networking requirements.
1.2 Product Characteristics
The AR500&AR510&AR530&AR550&AR2500 uses leading hardware platforms and
software architectures. The AR500&AR510&AR530&AR550&AR2500 provides integrated
network solutions for enterprises with minimum investment costs; therefore, they can meet
many facets of future business expansion and developments of the Internet of Things.
1.2.1 Industrial Environment Adaptability
As the industrial routing and switching device, the
AR500&AR510&AR530&AR550&AR2500 adapts to various industry environments:
lComplies with IEC 61000-6-2.
lProtection level
–AR500 series: IP30
–AR530 series: IP51
–AR550 series: IP40
–AR2500 series: IP40
lUses fanless design and the operating temperatures are as follows:
–AR500 series operating at maximum LTE transmit power: -25°C to +65°C
–AR500 series operating at typical LTE transmit power:-25°C to +70°C
–AR531-2C-H and AR531-F2C-H: -40°C to +70°C
–AR531GPe-U-H, AR531G-U-D-H:-40°C to +60°C
–AR550 series: -40°C to +70°C
–AR2500 series: -40°C to 65°C
lComplies with transformer substation environment standard IEC61850-3/IEEE1613.
1.2.2 Industry-Class Reliability
lThe AR500&AR510&AR530&AR550&AR2500 complies with industry standards and
provides quality service.
lThe AR500&AR510&AR530&AR550&AR2500 defends against network attacks.
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description 1 Product Positioning and Characteristics
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2

lThe AR500&AR510&AR530&AR550&AR2500 supports in-service patching so that the
system software can be upgraded during system operation.
lThe AR500&AR510&AR530&AR550&AR2500 supports fast switching on a data
channel and provides highly reliable networking.
1.2.3 Service Integration Capability
The AR500&AR510&AR530&AR550&AR2500 integrates various services:
lIntegrates routing, switching, and wireless services.
lUses open software architecture to support various industry services.
1.2.4 Hardware Extensibility
The AR500&AR510&AR530&AR550&AR2500 uses the modular design and daughter cards
for communication modules. The daughter cards can be flexibly replaced and extended,
meeting requirements for different services and installation environments.
1.2.5 Remote Maintenance Capability
In addition to one-stop deployment, plug and play capability, and remote commissioning
functions, the AR500&AR510&AR530&AR550&AR2500 manages the customer premises
equipment (CPE) remotely. The remote maintenance function improves efficiency and greatly
reduces maintenance costs.
1.2.6 Strong Access Capability
The AR500&AR530 provide FE, GE, and RS485 interfaces, supports IEC62056 (DLMS/
COSEM), Modbus, DLT645, and PoweRline Intelligent Metering Evolution (PRIME), and
connects to various networks to transmit different industry services, which greatly reduces
investment and maintenance costs.
The AR2500 series supports GE interfaces and the AR2504E-H supports 10GE interfaces.
The AR2500 can connect to downstream terminals and access switches, greatly reducing
investment and maintenance costs.
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description 1 Product Positioning and Characteristics
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3

2 Applications
About This Chapter
2.1 AR530 as a Industrial Router
2.2 AR500 or AR530 as the Industrial Switch
2.3 AR2500 Used as the Industrial Switch
2.4 AR500&AR530 Used as Industrial Gateways
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description 2 Applications
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4

2.1 AR530 as a Industrial Router
As the industrial router, the AR530 can connect a transformer substation to a dispatch center
(monitoring center) through the Internet, and establish a GRE/IPSec VPN or Dynamic Smart
Virtual Private Network (DSVPN) tunnel to secure data transmission. A transformer
substation can also use dedicated lines to connect to a dispatch center on a private network
through an AR530.
As shown in Figure 2-1, the dispatch center connects to the Internet, and transformer
substation A and transformer substation B connect to the Internet through the AR530. A GRE
VPN or IPSec VPN tunnel is established between the dispatch center and transformer
substation A/B so that the dispatch center can communicate with transformer substation A/B
and transformer substations A and B can communicate through the DSVPN tunnel.
You can also use an AR530 to directly connect the transformer substation (for example,
transformer substation C) to the dispatch center through dedicated lines to construct a private
network.
Figure 2-1 AR530 as the industrial router
GRE/IPSEC VPN
AR530
DSVPN
AR530
AR530
GRE/IPSEC VPN
AR530
Dispatch
center
Transformer
substation C
Transformer
substation A
Transformer
substation B
2.2 AR500 or AR530 as the Industrial Switch
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description 2 Applications
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5

An AR500 or AR530 can function as a switch in industry fields to implement fast switching
on a data channel, which improves reliability.
In Figure 2-2, highway device access is used as an example.
Router A, Router B, Router C, and Router D are AR500 or AR530s and connected through
GE optical interfaces, constitute an open-ring network, and connect to the aggregation layer
ring network composed of monitoring subcenters. SEP runs on the open-ring network and
ensures fast switching of data channels between the four AR500 or AR530s.
Figure 2-2 AR500 or AR530s as industrial switches
Monitoring
subcenter
Monitoring
subcenter
Video
surveillance
device
10GE Fiber
FE Fiber
FE Ethernet
FE Failover
GE Fiber
SEP
Segment
6×
AP AP
6×
Router C
Router B
Router A Router D
STA STA
Internet
2.3 AR2500 Used as the Industrial Switch
The AR2500 can function as a switch in industry fields. It provides multiple LAN interfaces
to connect to terminals and switches. In Figure 2-3, Router A, Router B, and Router C are all
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description 2 Applications
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6

AR2500s and play roles of switches. They connect to the MPLS/IP network through a CE,
and connect to terminals (for example, electrical meters and PCs) and switches.
Figure 2-3 AR2500 used as industrial switches to connect to terminals and access switches
Industrial field
Router A
Router B
Router C
PC
Switch
Switch
PC
PC
PC
CE
Switch
MPLS/IP
network
Electrical
meter
Electrical
meter
Electrical
meter
Electrical
meter
Electrical
meter
An AR2500 can function as a switch in an industry field to implement fast switching on a
data channel, which improves network reliability in the industry field. In Figure 2-4, Router
A through Router I are AR2500s and connected through GE interfaces. They constitute two
ring networks and connects to the substations, power distribution station, and power
distribution cabinet. SEP runs on the ring network and ensures fast switching of data channels
between the AR2500s.
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description 2 Applications
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7

Figure 2-4 AR2500s used as industrial switches to implement fast switching of data channels
Electrical
meter
Electrical
meter
Electrical
meter
Electrical
meter
Router B
Router E
SEP
Segment
Router A
PC PC
Router G
Router D
Router C
Router F
Router H
Router I
SEP
Segment
MPLS/IP
Main
station
Substation
Substation
Substation
Power
distribution
station
Power
distribution
cabinet
2.4 AR500&AR530 Used as Industrial Gateways
As industrial gateways, AR500&AR530 integrate routing, switching, and data collection
functions, which facilitates installation and commissioning, and saves investments.
As shown in Figure 2-5, RouterA, RouterB, RouterC, and RouterD, are AR500s or AR530s.
They are used as industrial gateways and provide the following functions:
lRouter: functions as the egress gateway and connects to the remote Head-End with data
collection functions through the Ethernet or 3G/GPRS.
lIoT gateway: RouterA, RouterB, RouterC, and RouterD function as concentrators and
connect to meters using RS485, ZigBee, RF, or PLC to implement remote management.
When the AR500 functions as the IoT gateway, electrical meters can connect to the
AR500 through RS485 only.
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description 2 Applications
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8

Figure 2-5 AR500&AR530 used as industrial gateways
Three-
phase
meter
Single-
phase
meter
Three-
phase
meter
Single-
phase
meter
Three-
phase
meter
Single-
phase
meter
Three-
phase
meter
Single-
phase
meter
RS485 cable
PLC cable
Zigbee Communication network
RF Communication network
UMS
…...…... …...
RouterBRouterA
…...…... …...
RouterDRouterC
…...…... …... …...
Ethernet
Ethernet
3G/GPRS
Meter
DCP
Communication
network
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description 2 Applications
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9

3 Product Characteristics
About This Chapter
3.1 Feature List
3.2 Key Features
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description 3 Product Characteristics
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10

3.1 Feature List
Feature list of AR500 series
Table 3-1 Features supported by the AR500
Featu
re
Sub-
Feature
Description Differ
ence
LAN VLAN VLAN services including basic VLAN, super VLAN,
MUX VLAN, and voice VLAN; dynamic VLAN
learning using Generic Attribute Registration Protocol
(GVRP)
AR503
EDGW-
Lc,
AR503
EW,
AR509
CG-Lc,
AR509
CG-Lt
do not
support
GVRP.
AR503
GW-
LM7,
AR503
GW-
LcM7,
AR503
EDGW-
Lc,
AR503
EW,
AR509
CG-Lt,
AR509
CG-Lc
do not
support
Voice
VLAN.
LAN MAC Dynamic MAC address learning and static MAC
address configuration; MAC address learning limit,
blackhole MAC entries, sticky MAC entries, and anti-
MAC flapping
None
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description 3 Product Characteristics
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11

Featu
re
Sub-
Feature
Description Differ
ence
LAN STP Spanning Tree Protocol (STP), Rapid Spanning Tree
Protocol (RSTP), Multiple Spanning Tree Protocol
(MSTP), and STP security
AR502
EG-L,
AR502
EGW-
L,
AR502
CG-L,
AR503
EDGW-
Lc,
AR503
EW,
AR509
CG-Lc,
and
AR509
CG-Lt
do not
support
STP/
RSTP
and
MSTP.
LAN SEP Ring network protocol applied to the link layer of an
Ethernet network that provides open ring, closed ring,
single ring, and multi-ring, and implements link
redundancy in these topologies
None
LAN Link
aggregation
Static link aggregation and Link Aggregation Control
Protocol (LACP)-based aggregation
Only
AR503
EDGW-
Lc,
AR503
EW,
AR509
CG-Lt,
AR509
CG-Lc,
AR502
CG-L,
AR502
EG-L,
and
AR502
EGW-L
support
link
aggrega
tion.
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description 3 Product Characteristics
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
12
