Huawei e5577s User manual

Quick Start

1
Thank you for purchasing the Mobile WiFi. This Mobile
WiFi brings you a high speed wireless network connection.
This document will help you understand your Mobile WiFi so you can start using it right away.
Please read this document carefully before using your Mobile WiFi.
For detailed information about the functions and configurations of the Mobile WiFi, refer to
the online help on the web management page that comes with the Mobile WiFi.
For detailed instructions for logging in to the web management page, refer to "Logging In to
the Web Management Page".

2
Getting to Know Your Mobile WiFi
Note:
The Mobile WiFi function descriptions and illustrations in this document are for your
reference only. The product you have purchased may vary.
Application Scenarios
Wi-Fi devices (such as smartphones, tablet computers, and game consoles) or computers can
all access the Internet through Mobile WiFi. The specific connection procedure depends on the
operating system of the Wi-Fi device or computer. Establish a connection according to your
device's specific instructions.

3
Scenario 1: Accessing the Internet Using an LTE, 3G, or 2G Network
The Mobile WiFi uses your operator's LTE, 3G, or 2G network to access the Internet.
LTE/3G/2G

4
Scenario 2: Accessing the Internet Using a Wi-Fi Network
When you use the Mobile WiFi in Wi-Fi coverage areas, for example, an airport, cafe, hotel, or
your home, the Mobile WiFi can access the Internet via Wi-Fi networks, helping save your LTE,
3G, or 2G network usage.
WLAN

5
Appearance
MENU
1
3
24
Power button
Screen
Micro USB port
MENU button

6
Screen
Home screen
Roaming
R: Data roaming turned on.
Signal strength
: Signal strength from weak to strong.
Network type
4G/3G/2G: Connected to an LTE/3G/2G network.
: Connected to WLAN.
Data connection status
Battery
SMS
New messages.
Number of new messages.
4G
R
1
0 B/2GB
1
2
3
4
5
7
6
8
100%
1
5G

7
Wi-Fi
Wi-Fi turned on.
Number of connected Wi-Fi devices.
5G: 5GHz turned on.
Traffic statistics
Data usage this month.
Monthly data usage limit.
Note:
To set the start date of the monthly data usage statistics and data usage limit, go to
the web management page.
Data traffic information is for your reference only. For more accurate data traffic
information, please consult your service provider.

8
Menu screen
Press the MENU button to display the menu.
Back
Return to the previous screen.
Options
Operation tips
Press the MENU button to scroll down.
Press the button to confirm your selection.
Back
XXXXXXXXX
XXXXXXXXX
Next OK
XXXXXXXXX
Menu
1
2
3

9
Update screen
When updates are available, you will be prompted to update
the Mobile WiFi.
Update
When Update is selected, press the button to update the
Mobile WiFi.
Ignore
When Ignore is selected, press the button to ignore the
update.
New Software
Update
Ignore
1
2
Next OK
Menu
4G
1
100%
1
5G

10
SSID and Wireless Network Encryption Key
When a Wi-Fi device establishes a connection
to the Mobile WiFi for the first time, you may
need to enter the default Service Set
Identifier (SSID) and wireless network
encryption key.
The default SSID and encryption key are
printed on the Mobile WiFi label.
It is recommended that you log in to the web
management page and change your SSID
and network encryption key.

11
To view the current SSID and wireless network encryption key on the screen:
1. Press the MENU button to display the menu.
2. Press the MENU button to scroll to Device Info.
3. Press the button to enter Device Info.
Back
Device Info
Next OK
Menu
Back
SSID: XXXXXXXXXX
PWD: XXXXXX
Next OK
Menu

12
Getting Started
Installing
Install the SIM card, microSD card, and battery according to the illustration.
4
123
RESET
MENU
MENU
MENU
RESET
RESET
MENU
RESET
1
2
2
1
2
1
Note:
The microSD card is an optional accessory. If no microSD card is included in the package,
please purchase one separately.

13
Charging the Battery
If the Mobile WiFi has not been used for a long time or if the battery is fully depleted, the
Mobile WiFi may not power on immediately after the charger is plugged in. Please charge the
battery for a while before attempting to power on the Mobile WiFi.
Method 1: Use the charger to charge the device
Note:
Only use chargers compatible with
the Mobile WiFi and provided by a
designated manufacturer. Use of
an incompatible charger or one
from an unknown manufacturer
may cause the Mobile WiFi to
malfunction, fail, or could even
cause a fire. Such use voids all
warranties, whether expressed or implied, on the product.
The charger is an optional accessory. If it is not included in the package, you may
contact an authorized dealer to buy a charger compatible with the Mobile WiFi.

14
The Mobile WiFi's charger model is HW-050100XYW. X and Y represent letters or
numbers that vary by region. For details about the specific charger model, contact an
authorized dealer.
Method 2: Charge the device through a computer connection
Use the data cable provided with your device to connect the Mobile WiFi to the computer.

15
Turning on the Mobile WiFi
Press and hold the button until the screen lights up,
indicating that the Mobile WiFi is turned on.
You can use the menu screen or log in to the web
management page and turn the fast boot function on or
off. This function greatly reduces the Mobile WiFi's
boot-up time.
Note:
Press and hold the button to turn off the Mobile WiFi.
Verifying the PIN
If the Mobile WiFi's network parameters have been correctly configured but you cannot access
the Internet after powering it on, PIN verification may be enabled. Log in to the web
management page and enter the PIN when prompted. To avoid entering the PIN every time
you power on the Mobile WiFi, disable PIN verification from the web management page.
The PIN/PUK is delivered with your SIM card. For more details, contact your service provider.

16
Connecting to the Internet
Using an LTE, 3G, or 2G Network
By default, the Mobile WiFi's management parameters have been preset according to your
operator's requirements. The Mobile WiFi will be connected to the Internet after its startup.
If data is transmitted, the Mobile WiFi will automatically connect to the Internet. If data is not
transmitted for a period of time, the Mobile WiFi will automatically disconnect from the
network connection.
Note:
You can use the menu screen or log in to the web management page to enable or disable
the automatic dialing while roaming function. If this function is turned off, when the
Mobile WiFi enters a roaming network, it will automatically disconnect from the Internet
connection that has already been established. You will need to manually establish this
network connection again.

17
Using a Wi-Fi Network
1. Ensure that the Wi-Fi extender function is enabled.
2. The Mobile WiFi automatically connects to a Wi-Fi hotspot set by your service provider or
yourself. When the Mobile WiFi is connected to a Wi-Fi network, and the Wi-Fi
hotspot SSID are displayed on the screen.
Note:
After connecting to a Wi-Fi network, the Mobile WiFi automatically reconnects to the
network the next time you are under that network's coverage.
For details about adding Wi-Fi hotspots, see "Adding a Wi-Fi Hotspot".

18
Logging In to the Web Management Page
1. Make sure the connection between the Mobile WiFi and the Wi-Fi device or computer is
working normally.
2. Open the browser, and enter http://192.168.8.1 in the address box.
Note:
If the IP address conflicts with other IP addresses on the network, the IP address of the
Mobile WiFi automatically changes. Check the current IP address on the Mobile WiFi
screen.
3. Enter the user name and password to log in to the web management page.
Note:
The default user name is admin.
The default password is admin.

19
Battery Saving Mode
If the Mobile WiFi has been inactive for some time, the Mobile WiFi enters the standby mode,
in which the display screen turns off. Pressing any button causes the display screen to light up.
When the Mobile WiFi is being powered only by the battery, you can choose to enable or
disable the automatic Wi-Fi off function. If this function is enabled and if no Wi-Fi devices
access the Mobile WiFi for a period of time, the Wi-Fi turns off automatically. You can press any
button to turn the Wi-Fi on again.
