AP6050DN&AP6150DN
Product Description
About This Document
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii
About This Document
Intended Audience
This document describes the positioning, characteristics, hardware structure, product features,
and technical specifications of the AP.
This document helps you understand the characteristics and features of theAP.
This document is intended for:
Network planning engineers
Hardware installation engineers
Commissioning engineer
Data configuration engineers
On-site maintenance engineers
Network monitoring engineers
System maintenance engineers
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Indicates an imminently hazardous situation
which, if not avoided, will result in death or
serious injury.
Indicates a potentially hazardous situation
which, if not avoided, could result in death
or serious injury.
Indicates a potentially hazardous situation
which, if not avoided, may result in minor
or moderate injury.
Indicates a potentially hazardous situation
which, if not avoided, could result in
equipment damage, data loss, performance
deterioration, or unanticipated results.
NOTICE is used to address practices not

AP6050DN&AP6150DN
Product Description
About This Document
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iii
Symbol
Description
related to personal injury.
Calls attention to important information,
best practices and tips.
NOTE is used to address information not
related to personal injury, equipment
damage, and environment deterioration.
Change History
Changes between document issues are cumulative. The latest document issue contains all the
changes made in previous issues.
Changes in Issue 02 (2016-07-22)
This version has the following updates:
The following information is modified:
5.1 Basic Specifications
5.2 Radio Specifications
Changes in Issue 01 (2016-05-31)
This is the initial commercial release.

AP6050DN&AP6150DN
Product Description
Contents
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iv
Contents
About This Document.................................................................................................................... ii
1 Product Positioning and Characteristics...................................................................................1
1.1 Product Positioning.......................................................................................................................................................1
1.2 Product Characteristics .................................................................................................................................................6
2 Hardware Structure.......................................................................................................................9
2.1 AP6050DN....................................................................................................................................................................9
2.2 AP6150DN..................................................................................................................................................................12
3 Product Features (in Fat AP and Fit AP Modes)....................................................................16
3.1 WLAN Features..........................................................................................................................................................16
3.2 Network Features........................................................................................................................................................17
3.3 QoS Features...............................................................................................................................................................17
3.4 Security Features ........................................................................................................................................................17
3.5 Maintenance Features .................................................................................................................................................18
3.6 BYOD.........................................................................................................................................................................18
3.7 Locating Service.........................................................................................................................................................19
3.8 Spectrum Analysis ......................................................................................................................................................19
4 Product Features (in Cloud-based Management Mode)......................................................20
5 Technical Specifications ............................................................................................................23
5.1 Basic Specifications....................................................................................................................................................23
5.2 Radio Specifications ...................................................................................................................................................24
5.3 Standards Compliance ................................................................................................................................................30

AP6050DN&AP6150DN
Product Description
1 Product Positioning and Characteristics
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1
1 Product Positioning and Characteristics
1.1 Product Positioning
Table 1-1 Product positioning
Product
Model
Frequency
Band
IEEE
Standards
Compliance
Positioning
Usage
Scenario
AP6050DN
AP6150DN
Dual band:
2.4 GHz
5 GHz
The AP6050DN
and AP6150DN
can provide
services
simultaneously
on the 2.4 GHz
and 5 GHz
frequency
bands to
support more
access users.
IEEE
802.11a/b/g/n/a
c/ac wave2
The AP6050DN
and AP6150DN
are the
next-generation
technology-lead
ing APs. They
support
4SU-3MU
MU-MIMO and
feature high
reliability, high
security, simple
network
deployment,
automatic AC
discovery and
configuration,
and real-time
management
and
maintenance. In
compliance
with IEEE
802.11ac, the
AP6050DN and
AP6150DN
support a
theoretical rate
of up to 2.33
Gbit/s, greatly
The AP6050DN
and AP6150DN
provide
highest-quality
wireless
services for
mobile office,
high-density
scenarios,
elementary
education, and
higher
education. They
provide flexible
distribution
options in
different
environments.

AP6050DN&AP6150DN
Product Description
1 Product Positioning and Characteristics
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2
Product
Model
Frequency
Band
IEEE
Standards
Compliance
Positioning
Usage
Scenario
improving user
experience.
The AP6050DN andAP6150DN can work as a Fat AP, Fit AP, or cloudAP. TheAP can
switch flexibly among three working modes based on the network plan.
Typical networking modes are as follows:
Figure 1-1 FitAP networking (APmode)

AP6050DN&AP6150DN
Product Description
1 Product Positioning and Characteristics
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3
In this networking, theAP functions as a FitAP. TheAC is responsible for user access,AP
go-online,AP management, authentication, routing, security, and QoS. Huawei products that
provide theAC function include theAC6605, AC6005, ACU2 (with S7700, S9700, or
S12700), S5720HI, S7700 (with X series board), S9700 (with X series board), and S12700
(with X series board).
Figure 1-2 FitAP networking (WDS mode: point-to-point)
Figure 1-3 FitAP networking (WDS mode: point-to-multipoint)
In this networking, theAP connects two or more independently wired or wireless LANs
through wireless links to construct a network on which users can exchange data. In Wireless
Distribution System (WDS) mode, theAP supports point-to-point (P2P) and
point-to-multipoint (P2MP) networking modes. Supporting 5 GHz and 2.4 GHz frequency
bands, theAP can implement wireless bridging and access functions.

AP6050DN&AP6150DN
Product Description
1 Product Positioning and Characteristics
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4
Figure 1-4 FitAP mesh networking
In this networking,APs function as mesh points (MPs) and are fully meshed to establish an
auto-configured and self-healing wireless mesh network (WMN).APs with the gateway
function can work as the mesh portal points (MPPs) through which the WMN can provide
access to the Internet. Terminals connect to APs to access the WMN. The WMN uses
dedicated mesh routing protocols to guarantee high transmission quality and is more
applicable to scenarios that require high bandwidth and highly stable Internet connections.

AP6050DN&AP6150DN
Product Description
1 Product Positioning and Characteristics
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
Figure 1-5 FatAPnetworking
In this networking, the device functions as a Fat AP to implement functions such as user
access, authentication, data security, service forwarding, and QoS.

AP6050DN&AP6150DN
Product Description
1 Product Positioning and Characteristics
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6
Figure 1-6 CloudAPnetworking
In this networking, the device functions as a cloud AP and works with the Agile
Controller-Cloud Manager on the same cloud for user access,AP online, authentication,
routing,AP management, security, and QoS. An enterprise can choose to use the Portal
authentication server integrated in the Agile Controller-Cloud Manager or the authentication
server deployed by itself.
1.2 Product Characteristics
Product
Characteristics
Description
High-speed and
reliable wireless
access
Compatibility with IEEE 802.11a/b/g/n/ac/ac wave 2.
Supports 4SU-3MU MU-MIMO and a rate up to 2.33 Gbit/s.
Supports a rate of up to 600 Mbit/s at 2.4 GHz frequency band.
Supports a rate of up to 1.73 Gbit/s at 5 GHz frequency band.

AP6050DN&AP6150DN
Product Description
1 Product Positioning and Characteristics
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7
Product
Characteristics
Description
Supports link aggregation of dual Ethernet ports.
Supports Wi-Fi Multimedia (WMM) and priority mapping on the
air interface and wired interface.
Supports wired link integrity check.
Supports load balancing.
Supports roaming without service interruption in Fit AP mode.
Supports AC dual-link backup in Fit AP mode.
Supports beamforming.
Provides a latest 802.11ac Wave 2 chip with higher performance
and wider coverage.
Uses a metal shell and heat dissipation design to ensure high
reliability.
Comprehensive
user access control
capability
Supports access control lists (ACLs) and implements user access
control based on the user group policy.
Provides fine-grained bandwidth management for each user.
Supports user isolation policies.
Supports unified authentication on the AC in Fit AP mode.
Identifies the device type according to the organizationally unique
identifier (OUI) in the MAC address, user agent (UA) information
in an HTTP packet, and DHCP options in Fit AP mode.
The RADIUS server delivers packet forwarding, security, and
QoS policies according to the device type carried in the RADIUS
authentication and accounting packets in Fit AP mode.
High network
security
Open system authentication
WEP authentication/encryption
WPA/WPA2-PSK authentication and encryption
WPA/WPA2-802.1x authentication and encryption
Wireless intrusion detection system (WIDS) and wireless
intrusion prevention system (WIPS), including rogue device
detection and countermeasure, attack detection and dynamic
blacklist, and STA/AP blacklist and whitelist
Flexible
networking and
environment
adaptability
Provides flexible networking capabilities and applies to various
application scenarios.
Has strong environment adaptability. The AP can automatically
select the transmission rates, channels, and transmit power to
adapt to various radio environments and avoid interference in real
time.
Adjusts bandwidth allocation based on the user quantity and
environment to improve user experience.
The AP6050DN supports the MIMO antenna system equipped
with built-in dual-band omnidirectional antennas.
The AP6150DN supports the MIMO antenna system equipped
with external dual-band omnidirectional antennas.

AP6050DN&AP6150DN
Product Description
1 Product Positioning and Characteristics
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8
Product
Characteristics
Description
Works in Fit AP mode to identify interference sources such as
baby monitors, Bluetooth devices, digital cordless phones (at 2.4
GHz frequency band only), wireless audio transmitters (at both the
2.4 GHz and 5 GHz frequency bands), wireless game controllers,
and microwaves, and works together with eSight to locate
interference sources and display spectrums.
Easy device
management and
maintenance
Works in Fit AP mode to support automatic going-online,
configuration loading, and plug-and-play (PnP).
Supports batch upgrade.
Works in Fat AP mode to support HTTP or HTTPS login to the
web platform to achieve local management and maintenance.
Allows real-time monitoring on the network management system
(NMS) to facilitate remote configuration and fast fault location.
Supports the Link Layer Discovery Protocol (LLDP) to implement
automatic link discovery and obtain the network topology.

AP6050DN&AP6150DN
Product Description
2 Hardware Structure
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9
2 Hardware Structure
2.1 AP6050DN
Appearance
Figure 2-1 shows the appearance of the AP.
The actual device appearance may be different from the following device appearance, but these
differences will not affect device functions.
Figure 2-1 AP6050DN appearance
Port
The following figure shows ports on theAP6050DN.

AP6050DN&AP6150DN
Product Description
2 Hardware Structure
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10
Figure 2-2 AP6050DN ports
As shown in Figure 2-2, each port can be described as follows:
1. Default button: restores factory settings if you hold down the button more than 3
seconds.
2. USB port: connects to a USB flash drive to extend the storage space of the AP, and
provides a maximum of 2.5 W power.
3. Console port: connects to the maintenance terminal for AP configuration and
management.
4. Ground screw: connects the AP to a ground cable.
5. GE1: 10/100/1000M port used to connect to the wired Ethernet.
6. GE0/PoE: 10/100/1000M port used to connect to the wired Ethernet. The port can
connect to a PoE power supply to provide power for APs.
7. Input port for 12 V DC power supply.
8. Lock port: protects the AP against theft.
LED Indicators
Indicator colors may vary slightly at different temperature.
Type
Color
Status
Description
Default status after
power-on
Green
Steady on
The AP is just
powered on and the
software is not
started yet.
Software startup
status
Green
Steady on after
blinking once
After the system is
reset and starts
uploading the
software, the
indicator blinks

AP6050DN&AP6150DN
Product Description
2 Hardware Structure
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11
Type
Color
Status
Description
green once. Until the
software is uploaded
and started, the
indicator remains
steady green.
Running status
Green
Blinking once every
2s (0.5 Hz)
The system is
running properly,
the Ethernet
connection is
normal, and
STAs are
associated with
the AP.
The system
enters the Uboot
CLI.
Blinking once every
5s (0.2 Hz)
The system is
running properly,
the Ethernet
connection is
normal, and no STA
is associated with
the AP. The system
is in low power
consumption state.
Alarm
Green
Blinking once every
0.25s (4 Hz)
The software is
being upgraded.
After the
software is
loaded and
started, the AP
requests to go
online if it works
in Fit AP or
cloud-based
management
mode. The
indicator remains
in this state
before the AP
successfully goes
online
(CAPWAP link
setup).
The AP works in
Fit AP or
cloud-based
management
mode and fails to
go online

AP6050DN&AP6150DN
Product Description
2 Hardware Structure
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
12
Type
Color
Status
Description
(CAPWAP link
disconnection).
Fault
Red
Steady on
A fault that affects
services has
occurred, such as a
DRAM detection
failure or system
software loading
failure. The fault
cannot be
automatically
rectified and must be
rectified manually.
2.2 AP6150DN
Appearance
Figure 2-3 shows the appearance of the AP.
The actual device appearance may be different from the following device appearance, but these
differences will not affect device functions.

AP6050DN&AP6150DN
Product Description
2 Hardware Structure
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
13
Figure 2-3 AP6150DN appearance
Port
The following figure shows ports on theAP6150DN.
Figure 2-4 AP6150DN ports

AP6050DN&AP6150DN
Product Description
2 Hardware Structure
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
14
As shown in Figure 2-4, each port can be described as follows:
1. Default button: restores factory settings if you hold down the button more than 3
seconds.
2. USB port: connects to a USB flash drive to extend the storage space of the AP, and
provides a maximum of 2.5 W power.
3. Console port: connects to the maintenance terminal for AP configuration and
management.
4. Ground screw: connects the AP to a ground cable.
5. GE1: 10/100/1000M port used to connect to the wired Ethernet.
6. GE0/PoE: 10/100/1000M port used to connect to the wired Ethernet. The port can
connect to a PoE power supply to provide power for APs.
7. Input port for 12 V DC power supply.
8. Lock port: protects the AP against theft.
9. Antenna port: connects to an external antenna for transmitting and receiving service
signals.
LED Indicators
Indicator colors may vary slightly at different temperature.
Type
Color
Status
Description
Default status after
power-on
Green
Steady on
The AP is just
powered on and the
software is not
started yet.
Software startup
status
Green
Steady on after
blinking once
After the system is
reset and starts
uploading the
software, the
indicator blinks
green once. Until the
software is uploaded
and started, the
indicator remains
steady green.
Running status
Green
Blinking once every
2s (0.5 Hz)
The system is
running properly,
the Ethernet
connection is
normal, and
STAs are
associated with
the AP.
The system
enters the Uboot
CLI.

AP6050DN&AP6150DN
Product Description
2 Hardware Structure
Issue 01 (2016-05-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
15
Type
Color
Status
Description
Blinking once every
5s (0.2 Hz)
The system is
running properly,
the Ethernet
connection is
normal, and no STA
is associated with
the AP. The system
is in low power
consumption state.
Alarm
Green
Blinking once every
0.25s (4 Hz)
The software is
being upgraded.
After the
software is
loaded and
started, the AP
requests to go
online if it works
in Fit AP or
cloud-based
management
mode. The
indicator remains
in this state
before the AP
successfully goes
online
(CAPWAP link
setup).
The AP works in
Fit AP or
cloud-based
management
mode and fails to
go online
(CAPWAP link
disconnection).
Fault
Red
Steady on
A fault that affects
services has
occurred, such as a
DRAM detection
failure or system
software loading
failure. The fault
cannot be
automatically
rectified and must be
rectified manually.
