Huawei AOLYNK WDR814G User manual

HUAWEI
Aolynk
WDR814g/ WDR814Ig
ADSL2+WirelessRouter
User sManual

Aolynk
WDR814g /WDR814Ig
ADSL2+WirelessRouter
User sManual
Volume
ManualVersion
Product Version
BOM
HuaweiTechnologiesCo., Ltd. providescustomerswithcomprehensivetechnicalsupport and service.
Pleasefeelfree tocontactourlocal officeorcompanyheadquarters.
HuaweiTechnologiesCo.,Ltd.
Address: Administration Building, HuaweiTechnologiesCo., Ltd.,
Bantian,Longgang District, Shenzhen, P.R.China
PostalCode: 518129
Website: http://www.huawei-3com.com
Email: [e-mail]

Copyright ©2004 HuaweiTechnologiesCo., Ltd.
All RightsReserved
No partofthisdocumentmaybereproduced ortransmitted inanyformorbyanymeans
without priorwritten consent ofHuaweiTechnologiesCo., Ltd.
Trademarks
,HUAWEI, C&C08, EAST8000, HONET, , ViewPoint,INtess,ETS, DMC, TELLIN,
InfoLink, Netkey,Quidway, SYNLOCK,Radium, M900/M1800, TELESIGHT,
Quidview, Musa, Airbridge,Tellwin,Inmedia,VRP,DOPRA,iTELLIN,HUAWEIOptiX,
C&C08 iNET, NETENGINE,OptiX,iSite,U-SYS,iMUSE,OpenEye, Lansway,
SmartAX,infoX,TopEng aretrademarksof HuaweiTechnologiesCo., Ltd.
Allothertrademarksmentioned inthismanual arethe propertyoftheirrespective
holders.
Notice
The information inthisdocumentissubject tochange without notice. Everyefforthas
been made inthe preparation of thisdocumenttoensureaccuracy of the contents, but
allstatements,information,and recommendationsinthisdocument don'tconstitutethe
warrantyofanykind, express orimplied.

AolynkWDR814(I)gADSL2+Wireless RouterUserManual Contents
i
Contents
1Introduction...........................................................................................................................7
1.1Aboutthe ADSLWireless Router.............................................................................................7
1.2Contentsofthe ADSLWireless RouterPackage......................................................................8
1.3Featuresofthe ADSLWireless Router.....................................................................................9
2HardwareInstallation &Setup..........................................................................................10
2.1RearPanel &Connections....................................................................................................10
2.2FrontPanel LEDs...................................................................................................................11
2.3POTSSplitter........................................................................................................................12
2.4SystemRequirementsand Setup..........................................................................................12
2.4.1Installing the TCP/IPProtocol.......................................................................................13
2.4.2Fixed IPAddressesConfiguration.................................................................................16
2.4.3Installing the USBdriver...............................................................................................18
3InternetAccess.....................................................................................................................22
3.1Prepareyournetwork............................................................................................................22
3.2Web-based UserInterface.....................................................................................................23
3.3Quick StartthisADSLWireless Router...................................................................................24
3.4WANSetup...........................................................................................................................25
3.4.1InternetConnectionSetup............................................................................................25
3.4.2DDNSSetup.................................................................................................................29
3.4.3NTPSetup....................................................................................................................30
3.5LANSetup............................................................................................................................31
3.5.1LANIPsetting &DHCPsetting.....................................................................................31
3.5.2Routing Setting.............................................................................................................32
3.6Wireless Setup......................................................................................................................34
3.7Advanced Wireless Setting....................................................................................................35
3.8Advanced Applications...........................................................................................................38
3.9Security.................................................................................................................................38

AolynkWDR814(I)gADSL2+Wireless RouterUserManual Contents
ii
3.9.1Access Policy...............................................................................................................38
3.9.2Firewall.........................................................................................................................39
3.10 Services..............................................................................................................................40
3.10.1Virtual Server..............................................................................................................40
3.10.2Forwarding.................................................................................................................42
3.10.3Trigger........................................................................................................................43
3.10.4DMZHost...................................................................................................................44
4Management.........................................................................................................................45
4.1ManagementSettings...........................................................................................................45
4.2Log.......................................................................................................................................46
4.3Diagnostic-Ping.....................................................................................................................47
4.4Upgrade Firmware.................................................................................................................48
5Troubleshooting..................................................................................................................50
AFAQ......................................................................................................................................52
BTechnicalSpecifications....................................................................................................54
CGlossary...............................................................................................................................56

AolynkWDR814(I)gADSL2+Wireless RouterUserManual AboutThisManual
iii
AboutthisManual
RelatedManuals
None
Organization
The manualhasthe following organization.
Chapter Description
Chapter1
Introduction Thischapterdescribesthe package contentsand providesalist of featuresand application illustrationsof the ADSLWirelessRouter.
Chapter2
Hardware
Installation &
Setup
Thischapterprovidesinformation aboutyourADSLWireless
Router sphysicalfeaturesand givesstep-by-step installation
instructionsforhardwareinstallation and softwareconfiguration.
Chapter3
Internet Access Thischapterdescribesthe proceduresnecessary toconfigurethe basicfunctionsand beginusing yourADSLWireless Router. If you
followtheseprocedurescorrectly,thereshouldbe no problemin
accessing the Internet via yourADSLWireless Router.
Chapter4
Advanced
Applications
Thischapterprovidesinformation onhowtoset up and usethe
advanced functionsofyourADSLWireless Router.
Chapter5
Management Thischapterprovidesinformation onusing Macintoshcomputersin yournetwork. The instructionsgivenhereareforsystemsoftware
version 8.0orabove, whichcomeswiththe TCP/IPProtocol
preloaded and supportsDHCPAddressing.
Chapter6
Troubleshooting Thischapterprovidessolutionstoproblemsyou mayencounter during installation and operation of yourADSLWirelessRouter.
AppendixAFAQ
……
AppendixB
Technical
Specifications
……
AppendixC
Glossary ……

AolynkWDR814(I)gADSL2+Wireless RouterUserManual AboutThisManual
iv
IntendedAudience
The manualisfor:
nWDR814gADSL2+Wireless Router
nWDR814IgADSL2+Wireless Router
Conventions
nThe manualusesthe following conventions.
SymbolConventions
Symbol Description
&Important
Note: Animportant notenoticewiththissymbolhelpsyou avoidan undesirablesituation orindicatesimportant supplementary
information.
&Note: Anotenoticewiththissymbol indicatesadditional, helpful,
non-criticalinformation.
GUIConventions
Convention Description
Boldface Button namesand menu itemsareinBoldface.Forexample,Click
OK.
/ Multi-level menusareinboldand separated byforwardslashes. For
example,Select theFile/Create/Foldermenu.
Convention Description
<> Button nameareinside anglebrackets.Forexample,clickthe<OK>
button
[ ] Windownames,menu items,datatableand fieldnamesareinside
squarebrackets. Forexample,pop up the [NewUser] window.
/ Multi-level menusareseparated byforwardslashes. Forexample,
[File/Create/Folder].
KeyboardOperation
Format Description
<Key> Press the keywiththekeynameinside anglebrackets.Forexample,
<Enter>,<Tab>,<Backspace>, or<A>.
<Key1+Key2> Press the keysconcurrently.Forexample,<Ctrl+Alt+A>meansthe
three keysshouldbe pressed concurrently.
<Key1,Key2> Press the keysinturn.Forexample,<Alt,A>meansthe twokeys
shouldbe pressed inturn.

AolynkWDR814(I)gADSL2+Wireless RouterUserManual AboutThisManual
v
Mouse Operation
Action Description
Select Press andholdthe primarymousebutton (left mousebutton bydefault).
Click Selectand releasethe primary mousebutton withoutmoving the pointer.
Double-click
Press the primarymousebutton twicecontinuouslyandquicklywithout
moving the pointer.
Drag Press and holdthe primarymousebuttonand movethe pointertoacertain
position.
SyntaxConventions
Convention
Description
Italics meansnewwords, terms, orspecial emphasis. E.g. Getting toknow your
ADSLWireless Router.
Boldface meansyou canselectbuttons,checkboxes,oritemsfromscreens,menus,
ordialog boxes.E.g.Click “OK”torestart
BoldItalics aresamplesonlyand you shouldenterothernames,numbers, orwordsto
substitute.
EnvironmentalProtection
Thisproduct hasbeen designed tocomplywiththe requirementsonenvironmental
protection.Forthe properstorage,useanddisposalof thisproduct, nationallawsand
regulationsmustbe observed

AolynkWDR814(I)gADSL2+Wireless RouterUserManual 1Introduction
6
Preface
Congratulationson yourpurchaseof thisADSLWireless Router. ThisADSLWireless
Routerisan idealsolution forSOHO userswho requirefastInternet access over
existing copperwires.ThisADSL-based routercanprovide up to20MbpsInternet
downstreamspeed and 1Mbpsupstreamspeed.All usersinthe LANside allow
sharing thishigh-speedbroadband connectionwithembedded NATandDHCP
server.
Integrated 802.11b/gwirelessAP,4-port10/100MbpsEthernetswitchand1USB port;
it isquick and easy todeploywireless andwireLANwithout spendingextracostofa
wireless access point, huborswitch. Especially, the extraUSB portoffersafastand
convenientconnection totheInternet.All LANusersareabletoshareinternalnetwork
data, likefiles, printers, andothernetworking resourcesinablazingspeed.
The built-in802.11b/gwirelessAPenablesyou tomoveyourcomputerfreelyaround
yourliving orworking environment. The802.11g technologyisanextension of
802.11b,thebasisofthe majoritywireless LANsandbeing widespread today.802.11g
notonlyprovidesdataratesuptomaximum54 Mbps,butalsoisbackwardcompatible
with802.11b.
TheADSLWireless Routeralsoprovidesacompletesecuritysolution thatprotects
yournetworkfromhackerattacks andInternet intruders, aswell asfilters
objectionableWebsitesorcontents.
Withaweb-basedUI(UserInterface), thisADSLWireless Router iseasytoconfigure
and maintain.All functionscanbe configuredwiththisexclusive, easy and friendly
UserInterfaceviawebbrowserssuchasInternet Explorerand Netscape
Communicator.
Thisguide containsinformation about installing andconfiguring yourADSLWireless
Router. It isdesigned toguideusersthrough the correct setupproceduresfor
appropriatehardwareinstallation andbasicconfiguration. Later, it showshowto
completeadvancedconfigurationstoget thebestoperating performancefromthis
ADSLWireless Router.
Thereare2modelsof thisrouter, the different of theyareshownbelow, and
the rest issameaseachother.
Model DSL Different
WDR814g ADSL2+overPOTS
WDR814Ig ADSL2+overISDN

AolynkWDR814(I)gADSL2+Wireless RouterUserManual 1Introduction
7
1 Introduction
Thischapterdescribesthe packagecontentsand providesalist offeaturesand
application illustrationsof theADSLWireless Router.
1.1AbouttheADSL WirelessRouter
DSL(DigitalSubscriberLine)referstoatechnologyused toincreasethe datacapacity
of standardtwisted-pairwiresthat aregenerallyusedtoconnect mosthouseholdsto
the phonenetwork. Inaddition, thistechnologyallowssimultaneousvoiceand
high-speeddatatransmission overasinglepairoftelephonewires.
ThereareseveralkindsofDSLservices, eachwithitsowncompromisesbetween
speed,distance, cost, and reliability.Theseservicesareeithersymmetrical(data
flowsatthe samespeed inbothdirections), orasymmetrical(the downstream
capacityishigherthan theupstreamcapacity).
ADSL
AsymmetricDigitalSubscriberLine (ADSL),asitsnameindicates,isan asymmetrical
datatransmission technologywhichprovideshigh-speeddatatransferoverexisting
telephone orISDN linesbymaking gooduseofthe previouslyunused high-frequency
band-width.ADSLprovidesmuchhigherdownstreamspeed than upstreamspeed. It
ismuchpopularasordinaryusersdownloadmuchmoredatathan what theyupload.
ADSLprovidesadedicatedsecurecommunication between you and the ISP(Internet
ServiceProvider) and theconnectionishigh-speed and always-on.
Ethernet/ FastEthernet/ USB
Ethernet isthe most widely-usednetworkaccess method, especiallyinaLocalArea
Network(LAN)and isdefinedbythe IEEE 802.3standard. Normally, Ethernet isa
shared mediaLAN.All stationsonthesegmentsharethetotalbandwidth, whichcould
be 10Mbps(Ethernet), 100Mbps(Fast Ethernet), or1000Mbps(Gigabit Ethernet).
WithaswitchedEthernet, eachsenderandreceiverhasthefull bandwidth.
Fast Ethernet isdefined asIEEE 802.3u standard, ahigh-speedversion of Ethernet
with100Mbpstransmission rate.
USB (UniversalSerialBus)isadatacommunicationstandardwhichallowsthe
PC/desktoptodetectnewdevicessuchasprinters, joysticks, keyboards, mice,
adapters, storagedevices,audiodevices,digitalcamerasand thingswiththis
technology.Theadvantage of USB istoreplacedifferent typesofserialandparallel
port connectorswithonestandardized plug and portcombination withthe data
transferrateupto12Mbps.Alsolow-powerdevicescan drawpowerfromUSB and
dont requirean extraadapter. Beforeyou usethisconnector, you mayneed toinstall
the USB driverfirst.
Wireless LAN
Wireless LocalArea Networksystems(WLANs)transmitand receivedataoverthe air
byusing radiofrequency (RF).Thisofferssomeadvantageslikemobility, easeof
installation, andscalabilityovertraditionalwired systems.

AolynkWDR814(I)gADSL2+Wireless RouterUserManual 1Introduction
8
Mobility: WLANscombine dataconnectivitywithusermobility.Thisprovidesusers
withaccess tonetworkanywhereintheirorganization. Forexample,userscan roam
fromaconferenceroomtotheirofficewithout being disconnected fromtheLAN.This
isimpossiblewithwired networks.
EaseofInstallation: Eliminating theneed todeploynetworkcablesinwallsand
ceilings, Installing WLANsiseasy fornoviceandexpert usersalike.
Scalability:WLANtopologiesareeasy tochangeinvariousways frompeer-to-peer
networks forasmall group ofuserstofull infrastructurenetworks forhundredsof
usersroaming overabroad area.
Wireless LANissuitablefordifficult-to-wireand frequentlychangingenvironments.Its
alsoan idealsolutionformobileworkerstoaccess networkresourceand forsetting a
temporaryLANwhennecessary
Wireless LANscan be setas “Ad-hoc”networkand “Infrastructure”network. Unlike
the “Ad-hocnetwork”, whereuserson theLANsenddatadirectlytoeachother, the
“Infrastructure”networkincludesanaccess pointanduserson the “Infrastructure”
networksenddatatothat dedicatedaccess point.ADSLWireless Routeruses
“Infrastructure”networkasWireless LANs. Eachwireless LANPCwithintherangeof
the access point can communicatewithotherwireless LANPCswithinthe range.
Firewall
DoS isan abbreviation forDenialofService.Thisoccurswhen acomputerornetwork
isoverwhelmed tothepoint that it can no longerfunction normally. Forexample,a
hackermayusefakeIPaddressestoaccumulatenumbersconnectionsinordersto
floodthe serverhe wantstoattack.The wayTCPworks isthataSYNpacketissentto
the serverfromthe client.Afterthe serverreceivesthe SYNpacket, aSYN-ACKis
sent back toclient. Theserverwill then waitforthereplyfromthe SYN-ACK. Ifthe
hackersenthundredsorthousandsofSYNpacketstothe serverwithbogusIP
addresses, the serverallocatescomputerandmemoryresourcestoestablishing a
connectionsincethe serverdoesnot knowalegitimateSYNmessage fromabogus
message. Byfloodingtheserverwithalarge volumeofrequests, the servers
maximumcapacitycan be used bythesebogusanduseless connection attempts
SPI isan acronymforStatefulPacket Inspection.TheSPIengineexaminesnot just
the headersofthepacket,butalsothepacket content. It can thendetermine more
about the packet than just itssourceanddestinationinformation. Moreover, stateful
inspection firewallsalsocloseoffportsuntil aconnection tothespecificport is
requested.
1.2ContentsoftheADSL Wireless Router Package
Aftercarefullyunpacking the shipping carton, check the contentslisted below.
n1AolynkADLS2+ router
n1Poweradaptor
n1Telephone cables
n1Ethernet cable
n1USB cable
n2Screwandanchor
n1Quick Start Manual
n1Driver&ManualCD

AolynkWDR814(I)gADSL2+Wireless RouterUserManual 1Introduction
9
n1Qualitycard
1.3Featuresof theADSLWireless Router
YourADSLWireless Routercontainsthe following featureswhichdone theabsolutely
excellent workfornetworkconnections.
nAsymmetricaldataratesofupto8Mbpsdownstreamand 832kbpsupstream.
nSupportsITUG.dmt, ITUG.lite,ANSI T1.413 issue 2,ADSL2 andADSL2+
standards.
nAllowsmultipleuserstoaccess theInternet at thesametimebyproviding
maximumInternet utilization tomultipleuserssharingasinglepublicIPAddress.
nAllowsuserson EthernetLANandWireless LANtotransferdatatoeachother
throughwireless-to-wireBridge.
nProvideswireless access roaming, bestaccess point selection, loading balance,
networktrafficfiltering included inwireless roaming function.
nProvides64bits/128bitskeyWEP(Wired EquivalentPrivacy)wireless data
encryption tosecurewireless communication.
nFullysupports802.11open and shared keyauthentications.
nIntegratesfour10/100BASE-T/TXauto-sensing switchports.
nUsesNATtoallowyourentirenetworksPCstoconnect tothe Internet using only
one (purchased)IPaddress.
nSupportsPPPoEenabling userstoseamlesslyconnect toISPswiththe familiar
“dial-up”connection interface.
nBuilt-inweb-based userinterfaceforeasy configuration and management through
common web browserssuchasNetscape Communication 6.0orlaterandInternet
Explorer5.0orlater.
nBuilt-infirewall toprotect yourPCsfromoutside intruders(NAT).
nSupportsDHCPclienttoreceivebothadynamicIPAddress andafixed IPAddress
fromISP.
nBuilt-inDHCPservertoautomaticallyassign andmanageLANIPaddresses.
nAllowadministratorstoblock specificinternalusersfromaccessing specified
applicationsorservices.
nAllowsexternalInternet userstoaccessinformationfromthe internaltarget host by
setting theVirtualServer.
nProvidesunrestricted two-waycommunicationbetween one PCon yourLANand
certainInternet servicessuchasconferencing, video and gaming applications.
nEnhancesroutingperformancebyusing Dynamicand Staticrouting settings.
nCompatiblewithall popularInternetapplications.

AolynkWDR814(I)gADSL2+Wireless RouterUserManual 2HardwareInstallation &Setup
10
2 Hardware Installation &Setup
Thischapterprovidesinformation about yourADSLWireless Routersphysical
featuresand givesstep-by-stepinstallation instructionsforhardwareinstallation and
softwareconfiguration.
2.1Rear Panel&Connections
The following figuresshowtherearviewoftheADSLWireless Routerand illustrate
howthe cablesconnecttothe interfacesonthe rearpanel.
Step1 Plug oneendoftheADSLline (Standardphone line)intotheADSLport, the otherinto
the wall jack that isconnected totheADSLservice.
Step2 Connect the Ethernet NIC(NetworkInterfaceCard)port ofaPCtoone oftheLAN
Ports.
Step3 Connect the externalpowersupplytotheADSLWireless Router.
Step4 The Resetbuttonisused torebootand re-initializethe device(press oncequickly), or
forclearing configuration settingsback tofactorydefault values(press forlongerthan
3seconds).
&Note:
If you areMacintoshusers, pleasereferto Chapter6MacintoshSetup formore

AolynkWDR814(I)gADSL2+Wireless RouterUserManual 2HardwareInstallation &Setup
11
detailed informationabout configuring TCP/IP,hardwareinstallation andsoon.
2.2FrontPanelLEDs
The following figureshowsthefront viewof theADSLWireless Router.The LEDson
the frontpanelindicatethe statusoftheunit. You caneasilyviewthe operation ofyour
High-PerformanceWireless Routerfromthispanel.
&Note:
Pleaserefertothe modelonyourhandtofindproperdescription.
The LEDsonthefront panelindicatethestatusoftheunit. You caneasilyviewthe
operationofyourADSLWireless Routerfromthispanel.
LED Status Description
ON Powerhasbeenswitchedon andisworking
normally
Power
OFF Powerisswitchedoff orfails.
Diag - Forfactorytestonly
ON ADSLloopisbrought UP.
Blinking Startup.
Link
OFF ADSLloopisdown.
Blinking Dataisbeing transmittedorreceivedthrough
ADSL.
Act
OFF Nodatatransmission activitiespresenton thelink.
ON Wirelessconnectionestablished
Wireless OFF Wirelessfunction disabled
ON USB connectionestablished
USB OFF NoUSBcableconnected

AolynkWDR814(I)gADSL2+Wireless RouterUserManual 2HardwareInstallation &Setup
12
LED Status Description
ON Ethernet linkisup.
Blinking Ethernet interfaceistransmittingorreceiving
data.
LAN0/1/2/3
OFF Nolinkisup.
2.3POTSSplitter
IfyourISPoffersADSLservicesand POTS(plainoldtelephoneservice) inthe same
telephone line,you can connectanduseADSLand ordinaryphone servicesat the
sametimebyusing a POTSSplitter.The following figureshowshowtoconnect a
POTSSplitterintoyourADSLconnection. (APOTSsplitterislikelytobe provided by
yourISP)
123456
789101112
AB
12x
6x
8x
2x
9x
3x
10x
4x
11x
5x
7x
1x
Ethernet
A
12x
6x
8x
2x
9x
3x
10x
4x
11x
5x
7x
1x
C
2.4System RequirementsandSetup
Toconnect tothe Internet, anexternalADSLorCablemodemandanInternetaccess
accountfroman ISPisrequired. InordertooperatewiththeADSLWireless Router,
eachPCthat istobe connected totheADSLWireless Routershouldhavethe
following thingsinstalled:
nEthernetNIC(NetworkInterfaceCard:a10Base-Tor10/100Base-T/TXEthernet
card), orwireless client cardforwireless connection.
nStandardtwisted-pairEthernet cable(UTPnetworkcable)withRJ-45 connectors.
Orthe USB cable.
nSystemOS:Windows95/98,WindowsNT4.0,Windows2000/XP, orotherOSwith
web browserinstalled.
nTCP/IPnetworkprotocol.
nWebbrowser, suchasMicrosoft Internet Explorer5.0orlater, orNetscape
Navigator6.0orlater.

AolynkWDR814(I)gADSL2+Wireless RouterUserManual 2HardwareInstallation &Setup
13
2.4.1InstallingtheTCP/IP Protocol
Ifyou arenotsurewhetherthe TCP/IPProtocolhasbeen installed,followthesesteps
tocheck,and ifnecessary, install TCP/IPontoyourPCs.
Step1 Click the “Start”button. Choose “Settings”, then “ControlPanel”. Double-click the
“Network”icon.YourNetworkwindowshouldappearasfollows:
Step2 Select the “Configuration”tab.
&ImportantNote:
SettingsforWindows2000/XPandWindows98/ME/NTmight differslightly. See the
following forreference.
Click the “LocalArea Connection”icon on the lowerrighthand side ofyourdesktop
screen.

AolynkWDR814(I)gADSL2+Wireless RouterUserManual 2HardwareInstallation &Setup
14
Inthe “Local Area ConnectionStatus”window, click the “Properties”button then
yourNetworkwindowwill appear.
Step3 Check whetherthe TCP/IPProtocolhasalreadybeeninstalled ontoyourcomputers
Ethernetcard. NotethatTCP/IPProtocolcan beinstalled foracomputersDial-Up
Adapteraswell asfortheEthernet card.
Ifyes, go tostep7.
Ifno, click the “Add”button.

AolynkWDR814(I)gADSL2+Wireless RouterUserManual 2HardwareInstallation &Setup
15
Step4 Double-click “Protocol”inthe Select NetworkComponentType orhighlight
“Protocol”then click “Add”.
Step5 Highlight “Microsoft”underthe list ofmanufacturers. Double-click “TCP/IP”from
the list on the rightorhighlight “TCP/IP”thenclick “OK”toinstall TCP/IP.
Step6 Afterafewseconds,youwill be returned tothe Networkwindow.The TCP/IPProtocol
shouldnowbe on the list ofinstalled networkcomponents(see 3above).

AolynkWDR814(I)gADSL2+Wireless RouterUserManual 2HardwareInstallation &Setup
16
Step7 Click the “Properties”button.The TCP/IPPropertieswindowconsistsofseveraltabs.
Choosethe “IPAddress”tab.
Step8 Select “ObtainanIPaddress automatically”.Click “OK”. Restart yourPCto
completetheTCP/IPinstallation.
2.4.2Fixed IP AddressesConfiguration
Fixed IPaddressesmaybeassignedtonetworkdevicesformanyreasons, suchas
the serverPCsorprinterswhichareconsistentlyaccessed bymultipleusers.Toset
up computerswithfixed IPAddresses, gotothe “IPAddress”tab of the “TCP/IP
Properties”windowasshownabove.
Step1 Select “SpecifyanIPaddress”and enter “192.168.1.xxx”inthe “IPAddress”
location (wherexxx isanumberbetween 2and254 used bythe High-Performance
Wireless Routertoidentifyeachcomputer), and the default “SubnetMask”
255.255.255.0”. Notethatnotwocomputerson thesameLANcanhavethesameIP
address.

AolynkWDR814(I)gADSL2+Wireless RouterUserManual 2HardwareInstallation &Setup
17
Step2 Click on the “DNSConfiguration”tab andselect “Enable DNS”.Enterthe “DNSIP
Address”obtained fromyourISPinthe “ServerSearchOrder”location.Thenclick
the “Add”button.
Step3 Click on the “Gateway”tab andenterthe High-PerformanceWireless Routers
default gatewayvalue 192.168.1.1 inthe “Newgateway”field, then click “Add”
Button.
