HULALA HOME SCBSD0533 User manual

NOTE:
This brochure contains IMPORTANT safety info. Please read and keep it
for future reference.
1/16
ITEM NO. SCBSD0533

MAINTAINANCE
AND WARNING
Keep furniture away from heat sources.
Do not clean furniture with harsh cleaner or
polishes. Do not use detergents, Solvents,
abrasives, spray packs or leather cleaner. Use
non-color mild soap with warm water to
clean spills(Mix 1:10 soap to water)
Do not place furniture under direct sunlight,
material will possibly fade over time.
Do not use on site dry Cleaning machine.
Children should not climb or jump on the
furniture.
Do not write on furniture that is not protected
by a padded barrier.
Not for commercial use, only for residential
use .
Weight Limitation
70LBS
16

PARTS
LIST
16

Explosive View
16

HARDWARE
LIST
Be sure to inspect all packing material carefully for
small parts, that may have come loose inside the
carton during shipment.
16
SPARE
H
x12
Ax4 Dx8 x2
G
4*35mm
15mm
J
I x4
C x16
O
x18
M6*50mm
Px9
Ex8 x58
M6*35mm
x1
M6*60mm
M4
B
x2
8 *30mm
x8 F
Q
x2
x4
3.5*14mm
M7*50mm
x4 N
x8 MLK
3.5*14mm
x5 x1 x1
M6*60mm
M6*50mm
L
M7*50mm
x1 x1
4*35mm
Q
E Px1A
M6*35mm
C
R

6 16
ASSEMBLY
INSTRUCTIONS
x8x8
M6*35mm
D
8*30mm
A
15mm
x8J B x8
A*8
D*8
1
13
6
J*8
4
5
B*8
Insert the wood dowel D into the holes of panel 1,
then attach the cam bolt A to panel 1 by screwdriver.
Use the screwdriver and cam lock B to connect panel 3,4,5,6
with panel 1,make sure all holes aligned and tighten all bolts
to secure.Then stick the partJ on all bolts holes.
6
5

16
7
3
x8
D
K
M7*50mm
M4
x8
x1 C
1
9
4
10
9
2
4
8*30mm
D
10
1
9
9
Carefully align and slide the back panel 9 & 10 into the groove along rear
edge of pre-assembled unit in step 2 ,insert the wood dowel D into the
holes of panel 3,4,5,6.
Use the allen key K and bolt C to attach the assembled step 3
with panel 2,make sure all holes aligned and tighten all bolts
to secure.

16
K
M6*50mm
M4
x1 x5 P
x4
Q
K P
M4
x1
M6*60mm
x2
M6*50mm
Use the allen key K,bolt P to connect stretcher 15
with panel 2,make sure all holes aligned and do
not tighten all bolts until step 6.
Use the allen key K,bolt Q and bolt P to connect the
stretcher 15 with the left & right leg 14,make sure
all holes aligned and tighten all bolts to secure.

9 16
x18x18
E
3.5*14mm
H
H*18
E*18
Use the screwdriver,screw E,and plastic buckle H to connect the back panel with
all side panel & top panel,vertical partition panel,bottom panel.Then fasten all
screws to secure

16
8
I*12
I
Place shelf holders I into the desired position and then
slide adjustable shelves 7 & 8 into place.

11 16
9
x4
3.5*14mm
E
x2
G
x8
3.5*14mm
E
x4
F
E*4
F*2
E*4
G*2
E*4
10
Use the screwdriver,screw E to connect concealed
hinges F with the panel 11 & 13.
Use the screwdriver,screw E to connect concealed
hinges G with the panel 12.

12 16
11
11
13
3
4
Horizontal
by screw adjustment!
Vertical via slots in
the mounting plate
or via cam adjustment!
Concealed hinges are
three-way adjustable:
Side panels
Door
Side panels
Door
Side panels
Door
In-and-out
by loosening the hinge arm
mounting screw or via cam
adjustment!
Use the screwdriver and screw E to connect concealed hinges on panel 11 & 13
with side panel 3 & panel 4.
5mm

13 16
12
12
6
Horizontal
by screw adjustment!
Vertical via slots in
the mounting plate
or via cam adjustment!
Concealed hinges are
three-way adjustable:
Side panels
Door
In-and-out
by loosening the hinge arm
mounting screw or via cam
adjustment!
Side panels
Door
Side panels
Door
Use the screwdriver and screw E to connect door panel 12 with vertical
partition panel 6.
5mm

14 16
13
x4M Ex2
3.5*14mm
Use the screwdriver and screw E to attach plastic bracket M to top panel 1.
Keep the cabinet-level with adjustable nails in the event of a wobbly cabinet.
Now your cabinet is ready to use.

15/16
14
L
O
O
L
O
4*35mm
x4
O
x2x2L x4 NM
M
MM
M
N
N
N
Install the anti-collapse device.
1. Mark the position on the wall that corresponds to the location of M on
the back of panel 1; Drill and insert the expandable screw O by hammer;
2.Assemble the part M to the wall. Align the hole in the part M with the
expandable screw O, screw in and tighten by screwdriver;
3.Let the plastic belt N pass through the both M and pull tightly.
4.Use the protruding part above the doors as a puller to open and close.

Are you having
with assembly? Missing
send email with your order
For return, Please check the return policy
the retailer or MarketPlace you bought
Appreciated your purchasing from us.
Pop up your life by our furniture
16/16
We strive to offer high-quality products, and we also try our
best to satisfy each and every customer that orders from us
with product or service as needed. We provide 30 days
warranty starting from the time you receive the item. Each
customer must provide a record of their order such as the
order number, or item receipt for any items that are out of
the warranty period you may also still receive replacement
parts by purchasing them with our company if they are
available.
