HULALA HOME KCBSD0504 User manual

NOTE:
This brochure contains IMPORTANT safty info. Please read and keep for
future reference.
1/16
ITEM NO. KCBSD0504

MAINTAINANCE
AND WARNING
Keep furniture away from heat.
Do not clean furniture with harsh cleansers
or polish. Do not use detergents, Solvents,
abrasives, spray packs or leather cleaner. Use
non-color mild soap with warm water clean
spills(Mix 1:10 soap to water)
Do not place furniture under direct sunlight,
material will possibly fade over time.
Do not use on site dry Cleaning machine.
Children should not climb or jump on the
furniture.
Do not write on furniture without a padded
barrier to protect the surface.
Not for commercial use, For residential use
only.
Weight Limitation
80LBS
16

PARTS
LIST
16

Explosive View
16

HARDWARE
LIST
Be sure to check all packing material carefully for
small parts, which may have come loose inside the
carton during shipment.
16
SPARE
ST
10
10
T1

6 16
ASSEMBLY
INSTRUCTIONS
Place part #4 vertically on clean padded surface,
insert wood dowel D to edge of part #4.
Insert another end of wood dowel through part
#6, use screw C and allen key H to connect part
#6 with bottom edge of part #4, fasten screws to
secure part #6 with part #4.
With help of adult partner,
turn the assembled unit
upright, insert wood dowel D
to side of part #6.
Use philips head screwdriver
to fasten cam bolt A to side of
part #6.
Insert wood dowel D and cam
bolt A through end hole on
part #9, Insert cam lock B to
part #9 then use philips head
screwdriver to fasten cam
lock to secure. Then use
sticker to cover the cam lock.

16
7
3
Lay down the assembled
unit with adult partner.
Insert wood dowel D to edge
of part #6/#9.
Insert wood dowel D to
dowel holes on part #2, use
screw C and allen key H to
connect part #2 and
part#6/#9, fasten screws to
secure part #2 with part
#6/#9.
Place part #3 on clean padded
surface, Insert wood dowel D and
fasten cam bolt A to part #3 then
insert cam bolt and wood dowel
through end hole of part #11,Insert
and fasten cam lock B to secure part
#11 with part #3. Then use sticker to
cover the cam lock.

16
6
9
18
18
19
7
Place assembled unit side down on
clean padded surface, insert wood
dowel D to edge of part #3.
Use philips head screw driver to fasten
cam bolt A to bottom of part #3.
Insert wood dowel D, fasten cam bolt A
into end holes on part #6/#9, insert cam
lock into part #6/#9 then use philips
head screwdriver to fasten cam lock to
secure part #3 with part #6/#9 and use
sticker O to cover the cam lock.
Insert part #19 to side hole on part #18.
Use screw C and allen key H to attach the whole handrail to
part #7. Fasten screws to secure.

9 16
8
7
8
T*10
O*10
Place part #8 on clean padded surface . Use philips head screwdriver to fasten cam
bolt A to part #8.
Insert cam bolt on part #7/#8 through end hole of part #11/#9, then insert cam lock B
to part #11/#9, use philips head screwdriver to fasten cam lock B to secure part#11/
#9 with part #7/#8 and use sticker O to cover the cam lock.
Use screw T to connect part #7/#8
with part #3/#4/#2, fasten all
screws to secure then use sticker
O to cover the screw holes.
Use philips head screwdriver to
fasten cam bolt A to part #1.
Insert cam bolt on part #1
through end hole of part
#7/#8/#11, then insert cam lock
B to part #7/#8/#11.
Use philips head screwdriver to
fasten cam lock B to secure
part#1 with part #7/#8/#11 and
use sticker O to cover the cam
lock.
H
TT
T

16
9
10
68
7
Use open wrench
M to attach casters
L to bottom of part
#7/#8, fasten to
secure all casters.
Turn the whole unit upright, then insert shelf pin G to
predrilled hole on inside of part #6/#8 as desired level
then place part #5 on top of all shelf pins.

11 16
11
10
RK
R
K
R
E
R
K
Use screw E and philips head screwdriver to attach door hinge F to back side of
part #10.
Use screw R and philips head screwdriver to attach mending plate K to back
side of part #10.
Use screw P and philips head screwdriver to attach knob N to front of part #10.
E*2
E*2

12 16
12
J
With help of adult partner to hold the
door, then use screw E and philips head
screwdriver to attach door hinge F to
part #8.
Use screw R and philips head screw
driver to attach magnetic catch to pilot
hole on part #2/#3.
Gradually adjust the bolt on hinge then
slightly move the door to set it level
while needed.

13 16
13
Place part #12 on clean padded surface. Use
philips head screwdriver to fasten cam bolt A to
part #12.
Insert cam bolt A through end
hole of part #13/#14/#15, then
insert and fasten cam lock B to
secure part #12 with part
#13/#14/#15 and use sticker O
to cover the cam lock.

14 16
14
12
Insert part #17 through lower
groove on part #14/#15
Use philips head screwdriver and
screw I to connect part #16 with
part #13/#14/#15, fasten to secure.
Place the drawer upright, use
philips head screwdriver and
screw E to attach hand pull Q
on part #12.
E*2

15/16
15
Carefully slide the steel ball on female drawer slides to front end. Carefully
align male and female slides then insert the drawer gradually.
Loose the screw on male slide and slightly adjust the position of drawer
then fasten again while needed.
Assembly completed

Are you having
with assembly? Missing
send email with your order
For return, Please check the return policy
the retailer or MarketPlace you bought
Appreciated your purchasing from us.
Pop up your life by our furniture
16/16
