OPERATOR MANUAL
FIN AND INTERCEPTOR
HCS-5
HCS-5
For software versions 5.7.x

FOREWORDS
Congratulations on your new Humphree system!
Humphree systems provide effective solutions to enhance your vessels performance in both calm and rough
water. Depending on the conguration, the system can provide the following benets and features:
●Reduced vessel resistance
●Reduced wake wash
●Increased speed and vessel range
●Easy adaptation to your specic hull shape
●Protected inboard electric servo actuators
●No environmental pollution from hydraulic oil
●Selected composite materials eliminating corrosion
●Operator control of running trim and list
●Automatic trim control
●Automatic list control
●Heel control when turning with coordinated turn
●Stabilization
●Zero speed stabilization
●No anchor walking
●Auxiliary steering using vertical interceptors
●Remote control or monitoring from external system
For more information, visit www.humphree.com

SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . 4
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Interceptor Safety Information . . . . . . . . . . . . . . . . . . . . 4
Fin Safety Information . . . . . . . . . . . . . . . . . . . . . . . 5
IMPORTANT NOTICES . . . . . . . . . . . . . . . . . . . . . . . 6
GENERAL OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . 7
Interceptors . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Fins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Example of Placement . . . . . . . . . . . . . . . . . . . . . . . 7
MAIN SCREEN OVERVIEW . . . . . . . . . . . . . . . . . . . . . . 8
HUMPHREE FUNCTIONS OVERVIEW . . . . . . . . . . . . . . . . . 9
CONTROL PANEL KEYS . . . . . . . . . . . . . . . . . . . . . . . 10
DEPARTURE PROCEDURE . . . . . . . . . . . . . . . . . . . . . . 13
SHUT DOWN PROCEDURE . . . . . . . . . . . . . . . . . . . . . 14
Short-term Shut Down. . . . . . . . . . . . . . . . . . . . . . . 14
Long-term Shut Down . . . . . . . . . . . . . . . . . . . . . . . 15
START UP THE SYSTEM - FIRST TIME . . . . . . . . . . . . . . . . . . 17
HUMPHREE FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . 18
Automatic Trim Control . . . . . . . . . . . . . . . . . . . . . . 18
Automatic List Control . . . . . . . . . . . . . . . . . . . . . . 19
Coordinated Turn . . . . . . . . . . . . . . . . . . . . . . . . . 20
Stabilization . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Interceptor Steering . . . . . . . . . . . . . . . . . . . . . . . 22
Zero Speed Stabilization . . . . . . . . . . . . . . . . . . . . . . 23
Fish Hunting Mode . . . . . . . . . . . . . . . . . . . . . . . . 25
Vessel Motion Monitoring . . . . . . . . . . . . . . . . . . . . . 26
SYSTEM INFORMATION. . . . . . . . . . . . . . . . . . . . . . . 27
Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
System Units . . . . . . . . . . . . . . . . . . . . . . . . . . 27
License Key . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Advanced Setup . . . . . . . . . . . . . . . . . . . . . . . . . 28
TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . 29
Pop-Ups . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Other Errors . . . . . . . . . . . . . . . . . . . . . . . . . . 34
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Regular Maintenance . . . . . . . . . . . . . . . . . . . . . . . 36
Annual Maintenance . . . . . . . . . . . . . . . . . . . . . . . . 36
WARRANTY FORM . . . . . . . . . . . . . . . . . . . . . . . . 38
SERVICE SCHEDULES . . . . . . . . . . . . . . . . . . . . . . . . 42
Interceptors . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Fins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Contents

4
OPERATOR MANUAL HCS-5 020310 5.7.x 03
SAFETY INFORMATION
General
Please read the manual carefully before operating the Humphree system and pay extra attention to the following
safety notices:
WARNING!
●Make sure to read all Warnings thoroughly as they contain important safety information.The Humphree
system can cause serious injuries or death if not used properly.
IMPORTANT!
●The Important notices contain important instructions to avoid damage or malfunctions on the Humphree
system or other property.
NOTE!
●A note contains information that facilitates the work when operating the Humphree system.
Interceptor Safety Information
WARNING!
When installing the interceptors, make sure that there is no electrical current connected to them.
Isolate shore electrical current to the engine block, battery charger, or accessories mounted on the
engine.
WARNING!
Sharp edges, watch your fingers.

5
OPERATOR MANUAL HCS-5 020310 5.7.x 03
Fin Safety Information
WARNING!
Before docking, make sure the Humphree system is turned off by the main switch.
WARNING!
Before installation or service, the electrical power to the servo units with dedicated power supply must
be switched off.
WARNING!
Fins must be in neutral position before the boat is lifted out of the water.The lifting device and/or
struts must be placed in such a way that the fins are not damaged.To create a safe workplace in the
area around the ns, it is recommended to have an enclosed area of at least 1.5 x n length 360°
around the n.
WARNING!
There is a risk of being squeezed between the fin and the hull when working in the area of the fin.
Work with caution in the area around the fins.
WARNING!
The fins are rotating when enabled in ZERO SPEED STABILIZATION mode. Swimmers must stay away
from the fins due to the risk of injury. For safety around the vessel, make sure the installer has applied
appropriate warning signs prominently on the hull above the waterline above each fin.
NO SLINGS NO SWIMMING

6
OPERATOR MANUAL HCS-5 020310 5.7.x 03
IMPORTANT NOTICES
●The following manual is provided for Humphree service workshops, ship-builders, machine manufacturers,
and other authorized workshops that have personnel with qualied professional training. The installation
instructions are only for professionals. If the installation instructions are not followed or if the work is carried
out by non-professional personnel, Humphree will not assume any liability for damage that may incur to
materials or personal injury.
●The information in this document is the property of Humphree and may not be copied or communicated to
a third party, or used for any purpose other than that for which it is supplied, without the express written
consent of Humphree.This information is given in good faith based upon the latest information available to
Humphree, no warranty or representation is given concerning such information, which must not be taken
as establishing any contractual or other commitment binding upon Humphree or any of it subsidiary or
associated companies.
●If the manual is lost or worn, see www.humphree.com or contact your local Humphree dealer.
●The contents of the manual and equipment specications are subject to change without notice.
●All illustrations in the manual are schematically correct but may not be exact copies of the corresponding
equipment on your vessel.
●The screens shown in the manual may not match in detail the screens you see on the display.The screens you
see depends on software versions, system conguration and system settings.
●Humphree will assume no responsibility for damage caused by improper use or modication of the
interceptor system parts, or claims of loss of prot by a third party.
●The interceptor system is protected by patent.
●Inspect the parts at arrival for damage occurred during transportation.

7
OPERATOR MANUAL HCS-5 020310 5.7.x 03
GENERAL OVERVIEW
Interceptors
The interceptor creates pressure on the hull bottom plate directly
ahead of the transom using a blade. With only a few millimeters,
the transom edge raises and results in a high hydrodynamic lift.The
interceptor provides forces to optimize running trim and actively
dampen vessel motions.
Fins
As the vessel speeds through the water, the water moves along the n body. If the n is given an angle of attack, the
n creates a lifting force acting on the vessel to reduce vessel motions.
To reduce roll motion when the vessel is stationary or moving at speeds below 4 knots, the ns do a strong paddle
to counteract each wave induced roll motion which result in reduced roll motions onboard the vessel.
Example of Placement
Fins Interceptors
RCU
Control Panel

8
OPERATOR MANUAL HCS-5 020310 5.7.x 03
MAIN SCREEN OVERVIEW
FUNCTION Color
Function is turned off.
Function is turned on but not activated because of the speed.
Function is turned on.
The operator does not have a license for the function.
G
F
J
A
B
E
H
I
K
L
M
C
D
A. Speed Indicator
B. Port Fin
C . Port Interceptor
D. Interceptor Trim Demand
E. Page Indicator
F. Humphree Functions ON/OFF
G. Status Bar
H. Trim Angle
I. List Angle
J. Rudder Indicator
K. Starboard Fin
L. Starboard Interceptor
M. Interceptor Trim Demand

9
OPERATOR MANUAL HCS-5 020310 5.7.x 03
HUMPHREE FUNCTIONS OVERVIEW
AUTOMATIC TRIM
Automatic Trim Control (AUTO TRIM) adds automatic adjustment of the
vessel trim to provide optimum running trim for the highest speed and lowest
fuel consumption.The trim and list can be manually adjusted by deploying or
retracting the interceptors and/or the ns.
AUTOMATIC LIST
When running in a straight course, Automatic List Control (AUTO LIST)
corrects the boat list to a set list angle, usually zero degrees. When the vessel
enters a turn, the system allows the vessel to heel naturally during the turn and
then continue to correct the vessel to the set list angle.
COORDINATED TURN
Coordinated Turn automatically adjusts the heeling angle of the vessel during turns to reduce the side forces for
everyone on board.The system continuously monitors the rudder position during the turn and the interceptor
blade movement is coordinated with the rudder movement. With a controlled heel angle, higher turning speeds
and better comfort can be achieved.
STABILIZATION
Boats are constantly exposed to waves that cause roll and pitch motions
resulting in reduced comfort on board. With Stabilization, the interceptors and/or
stabilizing ns are instantly actuated to provide lift which counteracts the vessel
motions and at the same time optimizes the running trim and list angle.
ZERO SPEED STABILIZATION
Zero Speed Stabilization reduces roll motion when the vessel is not moving.The
function can be used when the boat is at anchor or unanchored. Zero Speed can
be activated when the vessel speed is below 4 knots.
FISH HUNTING MODE
Fish Hunting Mode suits sport shing boats and makes the vessel easy to steer
with a sh on the hook. When the Fish Hunting Mode is activated, the ns
gradually deactivate and rotate freely.
VESSEL MOTION MONITORING
Vessel Motion Monitoring (VMM) is used to monitor impacts and motion
sickness when the vessel is moving.The sensors in the RCU measures
3D-accelerations and presents live data on the display. On the VMM screen,
there is a yellow and a red warning level for the acceleration impacts.
INTERCEPTOR STEERING
Interceptor steering enhances the water jet steering by deploying the
interceptors and keeping the water jet thrust undeected for small steering
commands. For larger steering commands, a combination of interceptors and
water jet deection results in an increased steering force and reduced turning
radius.The steering interceptor position bar is seen in the main screen when
installed.

10
OPERATOR MANUAL HCS-5 020310 5.7.x 03
CONTROL PANEL KEYS
The following chapter covers the different keys of the control panel.
TRIM Forward (bow down)
Both port and starboard interceptors deploy
simultaneously and the bow of the vessel will trim down.
The key also navigates up in menus.
TRIM Aft (bow up)
Both port and starboard interceptors retract
simultaneously and the bow of the vessel will trim up.
The key also navigates down in menus.
LIST Port (list to port)
Port side interceptors retract, starboard interceptors
deploy, and ns rotate counter clockwise to make the
vessel list to port.
The key also navigates back to the previous menu.
LIST Stb (list to starboard)
Starboard side interceptors retract, port side interceptors
deploy, and the ns rotate clockwise to make the vessel list
to starboard.
The key also navigates into menus.
Force Retract
Only available on the main screen.
Press both LIST Port and LIST Stb for one second to turn all automatic functions off, rapidly
retract the interceptors and rotate the ns to neutral.
The function can be used when approaching a large wave from another vessel.

11
OPERATOR MANUAL HCS-5 020310 5.7.x 03
Function Keys
The function keys changes depending on which menu is active.
In the main screen, the function keys can turn on or off specic
functions.
ENTER (Menu)
The enter key opens the menu screen, enters sub menu screens and turns on and off specic functions.
EXIT (Power On/Off/Dimmer)
●When in menus, a short press exits to the main screen.
●Press and hold for two seconds to turn off the system.
Dimmer
On the main screen, shortly press EXIT and the DIMMER pop-up screen will be visible.
Center Key
There can be more than one view available on the main screen.The Center key is used to change the
main screen view.
If more than one view is available, a page indicator is displayed above the function soft keys.
INVERT / RED or
GREEN: Changes the
background between white
and black in day mode or
between red and green in
night mode.
- : Lowers the
dimmer light.
+ : Increases the
dimmer light.
NIGHT / DAY: Switches
between night and day
screens.

12
OPERATOR MANUAL HCS-5 020310 5.7.x 03
MENU OVERVIEW
Access the menu by pressing ENTER/Menu at the main screen.
Navigate through the menu using TRIM Aft and TRIM Forward.
Press List Stb or ENTER to visit.
Press List Port to get back to the previous page.
Press EXIT to get back to the main screen.
SYSTEM INFORMATION
Here, the Alarms, System Units, and License Key is located.
SETTINGS
Here, Cleaning, Servo Calibration, NMEA2000 Setup, and Fish Hunting
Mode is located.

13
OPERATOR MANUAL HCS-5 020310 5.7.x 03
DEPARTURE PROCEDURE
Perform the steps 1 to 3 before departure:
1. Turn on the system.
a. Use the key switch.
b. If the Humphree system is not connected to a key switch, press and hold EXIT until the
system is turned on.
2. Make sure that there are no alarms.
a. The status bar turns red if there are activated alarms.
b. Go to MENU/SYSTEM INFORMATION/ALARMS.
c. A list of the activated alarms will be present.
d. Select the alarm to read more details and how to clear the alarm.
e. Clear the alarms according to the descriptions.
f. When the alarms are cleared, press RESTART SYSTEM.
3. Make sure that the GPS speed is showing.
a. The speed is shown in the top left corner of the status bar.
b. If the speed isn’t showing, see Setup Manual.

14
OPERATOR MANUAL HCS-5 020310 5.7.x 03
SHUT DOWN PROCEDURE
Shut down the system using STANDBY mode or MAIN SWITCH.
STANDBY MODE
When the system is in STANDBY mode, the interceptors stays in the same position and the ns return to their
neutral positions.A cleaning function is activated every 24 hours to avoid marine growth.
1. Go to the main screen.
2. Press and hold the EXIT key for more than one second
3. When the turn off-screen appears, press OFF.
IMPORTANT!
The system consumes power in STANDBY mode. Remember to charge the batteries continuously or
connect it to a power outlet.
TURN OFF BY MAIN SWITCH
If the system is connected to a remote key switch, the system turns off when the engines are turned off.
NOTE!
If the vessel is moored for longer period of time, it is recommended to turn off the main switch or connect the
battery to a power outlet.Turning off the main switch will however disable the cleaning function so it is important
that the interceptor blades are completely retracted into the interceptor housing.
Short-term Shut Down
Short-term leave is when the operator leaves the boat over night or over a couple of days.There are some settings
that are recommended to activate before leaving the boat short-term.
CLEANING
WARNING!
If the cleaning function is activated, the interceptors makes a
full stroke every 24 hours. Make sure people stay clear of the
interceptors.
Cleaning is used to remove any initial marine growth from the interceptors when
the vessel is not in use. The CLEANING box is by default ticked, and is activated 24
hours after the system has been turned off.The screen indicates when cleaning is
active.
NOTE!
The cleaning function will not be activated if the main switch is turned off.
Make sure that the system is in STANDBY.
SETTINGS FOR CLEANING
4. Go to MENU/SETTINGS/CLEANING.
5. Tick the AUTOMATIC CLEANING box to activate the cleaning function.
6. Tick the INTENSIVE CLEANING box when the water around is full of
marine growth.
7. Use the PLUS or MINUS function keys to adjust the Cleaning Period.
Default is 24 hours.

15
OPERATOR MANUAL HCS-5 020310 5.7.x 03
LOCK FINS
To avoid that the ns might bump into something and get damaged, LOCK FINS
means that the ns will hold their set position when the system is in standby
mode.
NOTE!
When LOCK FINS is activated, it increases the power consumption. It is
recommended to connect the battery to a power outlet.
ACTIVATE LOCK FINS
1. Go to ADVANCED SETUP/FIN SETTINGS.
2. Tick the LOCK FINS box.
3. Go back to the main screen.
Long-term Shut Down
When its time to leave the boat for a longer period of time or if the boat is about to be hauled up from the water,
the following are recommended:
INTERCEPTORS
NOTE!
Make sure to untick the AUTOMATIC CLEANING box when the vessel is taken out of the water.
1. Put the control panel in STANDBY mode by holding the EXIT key and then press CONTINUE. The
interceptors will retract to their neutral position.
2. Turn off the system using the main switch.The interceptors will stay in their neutral position.
FINS
HAUL OUT MODE
If the vessel is about to be hauled up from the water, it is recommended to use Haul Out Fin Park Mode (Haul Out
Mode). Haul Out Mode puts the ns in a more useful position for the travel lift.
The ns are parked perpendicular to the hull while the boat speed is below 4.2 knots and the control system is in
running mode. The ns can be parked pointing towards the keel or pointing outwards from the hull.
IMPORTANT!
The Haul Out Fin Park mode will not hold the selected fin position if the control
system is in STANDBY mode, if the power supply is turned OFF, or if the boat speed
exceeds 2.8 knots.

16
OPERATOR MANUAL HCS-5 020310 5.7.x 03
OPERATE HAUL OUT MODE
1. Use the Center Key to access the ZERO SPEED STABILIZATION page.
NOTE!
The boat speed must be below 4.2 knots for the ZERO SPEED
STABILIZATION page to show.
2. Press HAUL OUT that is located in the bottom right corner.
3. Press HULL SIDE or KEEL to determine which way that the ns will point.
4. Press YES to conrm the position.
The screen shows the selected n position.
RESET THE FINS
NOTE!
The fins automatically reset if the speed exceeds 4.8 knots.
1. Press RESET FINS in the bottom right corner.
2. Press YES to conrm.
WARNING!
Make sure that it is safe for the fins to move before
confirming.
WARNING
Make sure that it is safe for the fins to move before confirming.
The fins will return to the neutral position if the system is
turned off by switch key.

17
OPERATOR MANUAL HCS-5 020310 5.7.x 03
START UP THE SYSTEM - FIRST TIME
Perform the following steps to get the system up and running:
1. Use the main switch and fuses to turn on the power.
NOTE!
The system can not be operated until all servo units have been calibrated. If
CALIBRATION NEEDED is showing on the screen, see Setup Manual.
If the servo units have been calibrated, the system starts normally.
2. Verify that the GPS signal is received properly. Make sure that the speed
is showing in the top left corner of the main screen.
It is recommended to use a Humphree GPS antenna or a NMEA 2000
connection. If no GPS is installed, see Setup Manual.
3. Check Trim and List Angle indication.
Angles should be close to 0.0° when the vessel is floating at even keel,
with no heel, at zero speed. If the trim and list angles show extreme
values, see Setup Manual.
4. Press TRIM Forward to deploy the interceptors.
The black bars indicates how much the interceptors are
deploying.
5. Press LIST Port or LIST Stb to angle out the ns. The n angle will be
displayed on the main screen.
6. Press both LIST Port and LIST Stb for one second.
The interceptors will fully retract and the fins will return to neutral.

18
OPERATOR MANUAL HCS-5 020310 5.7.x 03
HUMPHREE FUNCTIONS
Automatic Trim Control
Automatic Trim Control (AUTO TRIM) automatically adjusts the interceptors
for optimum vessel trim depending on the vessel speed.
TURN ON AUTO TRIM
1. Press the AUTO TRIM function key at the main screen.
The blue trim lines are extended to indicate the interceptor deployment
applied by the auto trim function.The black bars indicate actual
interceptor position.
2. Use the TRIM Forward or TRIM Aft to manually compensate for different
load conditions.
The inner blue line will separate from the outer blue lines, to indicate the
total amount of trim.
3. Use the LIST keys to manually compensate for different loads and/or side
wind conditions.
NOTE!
If GPS signal is lost, AUTO TRIM will switch off. They can be manually
adjusted while the speed signal is absent.
TIPS & TRICKS
●It is recommended to keep AUTO TRIM turned ON.
CALIBRATE AUTO TRIM CURVES
There are four AUTO TRIM curves that can be set to different load conditions.The calibration of the curves is
normally done during initial sea trials.
1. Go to MENU/AUTOMATIC TRIM CONTROL.
1. Navigate to the desired curve and press SELECT to activate that curve.
2. Press EDIT to edit the curve.
3. Use the LIST keys to move the cursor to the desired speed.
4. Use the TRIM keys to change the interceptor deployment at the particular speed.
5. Press SAVE.
6. Press NAME to edit the name of the curve.
MANUAL TRIM
The manual trim lets the operator manually change the trim and list of the
vessel.The TRIM keys adjusts the trim angle of the vessel by deploying or
retracting the interceptors.
The amount of trim is indicated by a blue line and in percent below the
indicator.The black bars indicate the interceptors position on port and
starboard side.
Use the LIST keys to adjust the list angle by deploying the interceptors on one
side, and retracting on the opposite side. The total amount of trim will be kept
unchanged, but the black interceptor bars will separate from the blue trim lines.

19
OPERATOR MANUAL HCS-5 020310 5.7.x 03
Automatic List Control
Automatic List Control (AUTO LIST) automatically adjusts the vessel’s list angle to compensate for cross winds or
asymmetric load conditions.
TURN ON AUTO LIST
1. Press the AUTO LIST function key at the main screen.
AUTO LIST will then be replaced by SET LIST on the main screen. SET LIST
is the desired heel angle of the vessel. SET LIST is normally 0.0° for running
at even keel.
INTERCEPTORS
●AUTO LIST is automatically activated when the speed exceeds 9 knots.
●AUTO LIST is automatically deactivated when the speed drops below 7.5
knots.The interceptors returns to neutral position.
FINS.
●AUTO LIST is automatically activated when the speed exceeds 14 knots.
●AUTO LIST is automatically deactivated when the speed drops below 12.5
knots.
2. Use the LIST keys to manually set the desired SET LIST from port 4° to starboard 4°.
If the speed drops below 4 knots, the SET LIST automatically switches back to 0.0°. After a turn, SET LIST will
also switch back to 0.0° to make sure that the vessel runs even keel.
SENSITIVITY
The SENSITIVITY can be increased for faster list control if the compensation is considered slow when the boat
enters a new load condition or wind angle.The range of Automatic List Sensitivity is from -20 to 10.
1. Navigate to MENU/AUTOMATIC LIST CONTROL.
2. Set the SENSITIVITY using the PLUS/MINUS function keys.
Default value is -5.
NOTE!
If the speed GPS signal is lost, AUTO LIST will automatically be switched off. The LIST offset will slowly adjust to 0.
TIPS & TRICKS
●It is recommended to keep AUTO LIST turned ON.
●To reduce slamming in quartering head sea, use SET LIST to make the bow cut the waves.
●Default setting is -5 and works for most vessels.A bigger vessel (over 80 ft) with a slower rolling period can
generally use a higher sensitivity for faster AUTO LIST operation.
●If the auto-pilot is not working correctly, try decreasing the SENSITIVITY until the auto-pilot seems to work
again. If it doesn’t help to decrease the SENSITIVITY, the auto-pilot must be
re-calibrated with AUTO LIST turned ON.
●Some vessels can start to roll back and forth in calm water if the sensitivity is
set too high. Lower the sensitivity for a slower operation.
The system gives a warning when the sensitivity exceeds 5.

20
OPERATOR MANUAL HCS-5 020310 5.7.x 03
Coordinated Turn
Coordinated Turn automatically adjusts the heeling angle of the vessel during turns to reduce the side forces for
people on board. The vessel’s turning ability is signicantly improved as a result of the interceptor steering force. A
rudder input bar is additionally shown on the main screen.
With Coordinated Turn Without Coordinated Turn
SETTINGS
See Setup Manual.
