Hunter Institutional Series User manual

ARC ADJUSTMENTS
(NON-OPPOSING NOZZLE MODEL)
All I-40 group adjustable heads are preset to approximately 180°.
Sprinklers may be adjusted with water on or off. It is recommended
that initial adjustment be made before installation.
1. Using the palm of your hand, rotate the nozzle turret counter-
clockwise to left stop to complete any interrupted rotation cycle
(Fig. 1).
2. Rotate the nozzle turret clockwise to right stop. This is the fixed
side of the arc. The nozzle turret must be held in this position
for all arc adjustments.
To Increase Arc
1. Insert the key end of the Hunter wrench into the adjustment
socket (Figs. 2 & 3).
2. While holding the nozzle turret at the right stop, turn the
wrench clockwise. Each 360° turn of the wrench increases the
arc 45°.
3. Adjust to any arc between 50° and 360°.
4. Wrench will stop turning, or there will be a ratcheting noise,
when the maximum arc (360°) is reached.
5. When set to 360°, the sprinkler will rotate continually
counterclockwise.
To Decrease Arc
1. Insert the key end of the Hunter wrench into the adjustment
socket (Figs. 2 & 3).
2. While holding the nozzle turret at the right stop, turn the
wrench counterclockwise. Each 360° turn of the wrench
decreases the arc 45°.
3. Adjust to any arc between 50° and 360°.
4. Wrench will stop turning, or there will be a ratcheting noise,
when the minimum arc (50°) is reached.
Radius Adjustment
Insert the hex end of the Hunter wrench into the nozzle-retainer/
range-adjustment screw (Figs. 2 & 3). Turn the screw clockwise
into the stream of water to decrease the radius, or counterclockwise
to increase the radius.
Precipitation Rate Adjustment
Where excessively wet or dry areas are a problem, the
precipitation rate may be adjusted. Simply replace the existing
nozzle with a larger one to increase or a smaller one to decrease
the rate of precipitation.
Nozzle Installation
1. Insert the key end of the Hunter wrench into the lifting socket
of a pop-up sprinkler. Pull the riser up to gain access to the
nozzle socket.
2. Using the Hunter wrench, loosen the nozzle-retainer/range-
adjustment screw. If a nozzle is already installed in the
sprinkler, it may now be removed by briefly turning on
the water.
3. Discard nozzle if removed with pliers. Slip the desired nozzle
into the nozzle socket. Note that the socket is angled up 25°
(see Fig. 4). Tighten the nozzle-retainer/range-adjustment screw.
Institutional Series™
I-40
Gear-Driven Sprinklers
®
Fig. 1
Fig. 2
®
Fig. 1
Fig. 2
Nozzle
Retainer/
Range
Adjustment
Screw
Arc Adjustment
Socket
Fig. 3
Lift Up
Socket
SS
I40
®
I-40
ADS
Fig. 4
Water
flow
Arc Adjustment
Direction
Nozzle
Retainer/
Range
Adjustment
Screw
Arc Adjustment
Socket
Fig. 3
Lift Up
Socket
SS
I40
®
I-40
ADS
Fig. 4
Water
flow
Arc Adjustment
Direction
NON-STRIPPABLE BACKDRIVE
This sprinkler is designed with an internal device that prevents
damage to the internal gear drive if it should be turned by
vandals. This important feature works when the nozzle turret
is turning in either direction. This makes the sprinkler very
durable in all applications.
AUTO ARC RETURN
This sprinkler is designed with an internal device that re-aligns
the arc if it is turned by vandals. This important feature works
when the nozzle turret is turning in either direction. When
forced outside of the originally set arc, the sprinkler takes the
shortest path back to the pattern without going completely
around. This saves the non-irrigated areas from getting wet!
Always a good thing!
Hunter Industries Incorporated • The Irrigation Innovators © 2011 Hunter Industries Incorporated
www.hunterindustries.com P/N 700593 LIT-470 G 12/11

CORRECT INSTALLATION
Each nozzle can be identified by
the number of raised ridges on the
inside surface of the nozzle.
Example: 2 ridges = # 42 nozzle
I-40 = 3 minutes (approx.)
I-40 High Speed = 1 minute (approx.)
I-40 NOZZLE INSTALLATION
Each nozzle can be identified by
the number of raised ridges on the
inside surface of the nozzle.
Example: 2 ridges = # 42 nozzle
I-40 = 3 minutes (approx.)
I-40 High Speed = 1 minute (approx.)
FULL CIRCLE ROTATION SPEED
I-40
Nozzle Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
8
Lt. Brown
(40)
40
50
60
44'
45'
46'
7.6
8.4
9.2
0.76
0.80
0.84
.87
.92
.97
10
Lt. Green
(41)
50
60
70
80
49'
50'
51'
51'
10.3
11.3
12.2
13.0
0.83
0.87
0.90
0.96
0.95
1.00
1.04
1.11
13
Lt. Blue
(42)
50
60
70
80
50'
51'
52'
53'
11.1
12.3
13.3
14.2
0.85
0.91
0.95
0.97
.99
1.05
1.08
1.12
15
Gray
(43)
50
60
70
80
54'
55'
57'
59'
13.8
15.7
16.6
18.3
0.91
1.00
0.98
1.01
1.05
1.15
1.14
1.17
23
Dk. Green
(44)
60
70
80
90
62'
64'
65'
66'
21.3
23.0
24.5
25.9
1.07
1.08
1.12
1.14
1.23
1.25
1.29
1.32
25
Dk. Blue
(45)
60
70
80
90
66'
67'
68'
69'
23.9
25.8
27.7
29.5
1.06
1.11
1.15
1.19
1.22
1.28
1.33
1.38
I-40 High Speed
Nozzle Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
8
Lt. Brown
(40)
40
50
60
41'
41'
42'
7.6
8.4
9.2
0.87
0.96
1.00
1.00
1.11
1.16
10
Lt. Green
(41)
50
60
70
80
45'
46'
47'
47'
10.3
11.3
12.2
13.0
0.98
1.03
1.06
1.13
1.13
1.19
1.23
1.31
13
Lt. Blue
(42)
50
60
70
80
46'
47'
48'
49'
11.1
12.3
13.3
14.2
1.01
1.07
1.11
1.14
1.17
1.24
1.28
1.31
15
Gray
(43)
50
60
70
80
51'
52'
53'
54'
13.8
15.7
16.6
18.3
1.02
1.12
1.14
1.21
1.18
1.29
1.31
1.40
23
Dk. Green
(44)
60
70
80
90
58'
59'
60'
61'
21.3
23.0
24.5
25.9
1.22
1.27
1.31
1.34
1.41
1.47
1.51
1.55
25
Dk. Blue
(45)
60
70
80
90
59'
61'
62'
63'
23.9
25.8
27.7
29.5
1.32
1.33
1.39
1.43
1.53
1.54
1.60
1.65
I-40 Dual Opposing
Nozzle Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
15
Gray
50
60
70
80
52'
54'
56'
57'
13.0
13.2
14.4
15.5
0.46
0.44
0.44
0.46
0.53
0.50
0.51
0.53
18
Red
50
60
70
80
58'
59'
60'
62'
13.7
15.2
16.6
17.8
0.39
0.42
0.44
0.45
0.45
0.49
0.51
0.51
20
Dk. Brown
60
70
80
90
63'
64'
66'
66'
19.1
20.9
22.3
23.9
0.46
0.49
0.49
0.53
0.53
0.57
0.57
0.61
23
Dk. Green
60
70
80
90
65'
66'
67'
68'
20.4
22.3
24.0
25.6
0.46
0.49
0.51
0.53
0.54
0.57
0.59
0.62
25
Dk. Blue*
60
70
80
90
66'
68'
69'
70'
22.0
24.0
25.9
27.2
0.49
0.50
0.52
0.53
0.56
0.58
0.60
0.62
28
Black
70
80
90
100
70'
72'
74'
76'
28.9
30.9
32.9
33.7
0.57
0.57
0.58
0.56
0.66
0.66
0.67
0.65
* Factory-installed nozzle
Note: All precipitation rates are calculated for 180 degree
operation. For the precipitation rate for a 360 degree sprinkler,
divide by 2. Precipitation rates for the ON model are calculated
at 360 degrees.
I-40
Nozzle Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
8
Lt. Brown
(40)
40
50
60
44'
45'
46'
7.6
8.4
9.2
0.76
0.80
0.84
.87
.92
.97
10
Lt. Green
(41)
50
60
70
80
49'
50'
51'
51'
10.3
11.3
12.2
13.0
0.83
0.87
0.90
0.96
0.95
1.00
1.04
1.11
13
Lt. Blue
(42)
50
60
70
80
50'
51'
52'
53'
11.1
12.3
13.3
14.2
0.85
0.91
0.95
0.97
.99
1.05
1.08
1.12
15
Gray
(43)
50
60
70
80
54'
55'
57'
59'
13.8
15.7
16.6
18.3
0.91
1.00
0.98
1.01
1.05
1.15
1.14
1.17
23
Dk. Green
(44)
60
70
80
90
62'
64'
65'
66'
21.3
23.0
24.5
25.9
1.07
1.08
1.12
1.14
1.23
1.25
1.29
1.32
25
Dk. Blue
(45)
60
70
80
90
66'
67'
68'
69'
23.9
25.8
27.7
29.5
1.06
1.11
1.15
1.19
1.22
1.28
1.33
1.38
I-40 High Speed
Nozzle Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
8
Lt. Brown
(40)
40
50
60
41'
41'
42'
7.6
8.4
9.2
0.87
0.96
1.00
1.00
1.11
1.16
10
Lt. Green
(41)
50
60
70
80
45'
46'
47'
47'
10.3
11.3
12.2
13.0
0.98
1.03
1.06
1.13
1.13
1.19
1.23
1.31
13
Lt. Blue
(42)
50
60
70
80
46'
47'
48'
49'
11.1
12.3
13.3
14.2
1.01
1.07
1.11
1.14
1.17
1.24
1.28
1.31
15
Gray
(43)
50
60
70
80
51'
52'
53'
54'
13.8
15.7
16.6
18.3
1.02
1.12
1.14
1.21
1.18
1.29
1.31
1.40
23
Dk. Green
(44)
60
70
80
90
58'
59'
60'
61'
21.3
23.0
24.5
25.9
1.22
1.27
1.31
1.34
1.41
1.47
1.51
1.55
25
Dk. Blue
(45)
60
70
80
90
59'
61'
62'
63'
23.9
25.8
27.7
29.5
1.32
1.33
1.39
1.43
1.53
1.54
1.60
1.65
I-40 Dual Opposing
Nozzle Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
15
Gray
50
60
70
80
52'
54'
56'
57'
13.0
13.2
14.4
15.5
0.46
0.44
0.44
0.46
0.53
0.50
0.51
0.53
18
Red
50
60
70
80
58'
59'
60'
62'
13.7
15.2
16.6
17.8
0.39
0.42
0.44
0.45
0.45
0.49
0.51
0.51
20
Dk. Brown
60
70
80
90
63'
64'
66'
66'
19.1
20.9
22.3
23.9
0.46
0.49
0.49
0.53
0.53
0.57
0.57
0.61
23
Dk. Green
60
70
80
90
65'
66'
67'
68'
20.4
22.3
24.0
25.6
0.46
0.49
0.51
0.53
0.54
0.57
0.59
0.62
25
Dk. Blue*
60
70
80
90
66'
68'
69'
70'
22.0
24.0
25.9
27.2
0.49
0.50
0.52
0.53
0.56
0.58
0.60
0.62
28
Black
70
80
90
100
70'
72'
74'
76'
28.9
30.9
32.9
33.7
0.57
0.57
0.58
0.56
0.66
0.66
0.67
0.65
* Factory-installed nozzle
Note: All precipitation rates are calculated for 180 degree
operation. For the precipitation rate for a 360 degree sprinkler,
divide by 2. Precipitation rates for the ON model are calculated
at 360 degrees.
I-40
Nozzle Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
8
Lt. Brown
(40)
40
50
60
45'
46'
46'
7.0
8.0
8.5
0.67
0.73
0.77
0.77
0.84
0.89
10
Lt. Green
(41)
50
60
70
80
50'
51'
52'
53'
10.2
11.1
12.1
13.0
0.79
0.82
0.86
0.89
0.91
0.95
0.99
1.03
13
Lt. Blue
(42)
50
60
70
80
51'
53'
55'
56'
11.0
12.3
13.1
13.9
0.81
0.84
0.83
0.85
0.94
0.97
0.96
0.99
15
Gray
(43)
50
60
70
80
56'
57'
59'
61'
13.5
15.1
16.1
17.5
0.83
0.89
0.89
0.91
0.96
1.03
1.03
1.05
23
Dk. Green
(44)
60
70
80
90
63'
65'
66'
67'
20.0
21.8
23.4
24.9
0.97
0.99
1.03
1.07
1.12
1.15
1.19
1.23
25
Dk. Blue
(45)
60
70
80
90
66'
68'
69'
70'
22.7
24.7
26.4
28.2
1.00
1.03
1.07
1.11
1.16
1.19
1.23
1.28
I-40 High Speed
Nozzle Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
8
Lt. Brown
(40)
40
50
60
41'
42'
42'
7.0
8.0
8.5
0.80
0.87
0.93
0.93
1.01
1.07
10
Lt. Green
(41)
50
60
70
80
44'
44'
45'
46'
10.2
11.1
12.1
13.0
1.01
1.10
1.15
1.18
1.17
1.27
1.33
1.37
13
Lt. Blue
(42)
50
60
70
80
46'
47'
49'
50'
11.0
12.3
13.1
13.9
1.00
1.07
1.05
1.07
1.16
1.24
1.21
1.24
15
Gray
(43)
50
60
70
80
51'
52'
52'
53'
13.5
15.1
16.1
17.5
1.00
1.07
1.15
1.20
1.15
1.24
1.32
1.38
23
Dk. Green
(44)
60
70
80
90
58'
58'
60'
60'
20.0
21.8
23.4
24.9
1.14
1.25
1.25
1.33
1.32
1.44
1.44
1.54
25
Dk. Blue
(45)
60
70
80
90
60'
62'
64'
65'
22.7
24.7
26.4
28.2
1.21
1.24
1.24
1.28
1.40
1.43
1.43
1.48
I-40 Dual Opposing
Nozzle Performance Data
Pressure Radius Flow Precip in/hr
Nozzle PSI ft. GPM
15
Gray
50
60
70
80
52'
54'
56'
57'
13.0
13.2
14.4
15.5
0.46
0.44
0.44
0.46
0.53
0.50
0.51
0.53
18
Red
50
60
70
80
58'
59'
60'
62'
13.7
15.2
16.6
17.8
0.39
0.42
0.44
0.45
0.45
0.49
0.51
0.51
20
Dk. Brown
60
70
80
90
63'
64'
66'
66'
19.1
20.9
22.3
23.9
0.46
0.49
0.49
0.53
0.53
0.57
0.57
0.61
23
Dk. Green
60
70
80
90
65'
66'
67'
68'
20.4
22.3
24.0
25.6
0.46
0.49
0.51
0.53
0.54
0.57
0.59
0.62
25
Dk. Blue*
60
70
80
90
66'
68'
69'
70'
22.0
24.0
25.9
27.2
0.49
0.50
0.52
0.53
0.56
0.58
0.60
0.62
28
Black
70
80
90
100
70'
72'
74'
76'
28.9
30.9
32.9
33.7
0.57
0.57
0.58
0.56
0.66
0.66
0.67
0.65
* Factory-installed nozzle
Note: All precipitation rates are calculated for 180 degree
operation. For the precipitation rate for a 360 degree sprinkler,
divide by 2. Precipitation rates for the ON model are calculated
at 360 degrees.
Institutional Series™
I-40
Gear-Driven Sprinklers
I-40
Nozzle Performance Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m3/hr l/min
8
Lt.
Brown
(40)
2.5
3.0
3.5
4.0
4.5
5.0
250
300
350
400
450
500
13.1
13.4
13.7
14.0
14.0
14.3
1.63
1.80
1.94
2.06
2.18
2.29
27.2
30.0
32.3
34.4
36.3
38.2
19
20
21
21
22
22
22
23
24
24
26
26
10
Lt.
Green
(41)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
14.6
14.9
15.2
15.5
15.5
15.8
2.20
2.37
2.52
2.67
2.81
2.96
36.6
39.4
42.0
44.5
46.8
49.3
21
21
22
22
23
24
24
24
25
25
27
27
13
Lt. Blue
(42)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
14.9
15.2
15.5
15.5
15.8
16.2
2.36
2.55
2.73
2.90
3.06
3.23
39.4
42.6
45.5
48.3
51.0
53.9
21
22
23
24
24
25
24
25
26
28
28
29
15
Gray
(43)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
16.2
16.5
16.8
17.1
17.4
18.0
2.93
3.19
3.44
3.67
3.89
4.14
48.8
53.2
57.3
61.2
64.9
68.9
22
24
24
25
26
26
26
27
28
29
30
30
23
Dk.
Green
(44)
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
18.9
19.2
19.5
19.8
20.1
20.1
4.76
5.03
5.29
5.56
5.79
6.01
79.4
83.9
88.1
92.7
96.5
100.2
27
27
28
28
29
30
31
32
32
33
33
34
25
Dk.
Blue
(45)
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
20.1
20.4
20.7
21.0
21.0
21.3
5.33
5.65
5.96
6.29
6.57
6.84
88.7
94.2
99.3
104.9
109.6
114.1
26
27
28
28
30
30
30
31
32
33
34
35
I-40 High Speed
Nozzle Performance Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m3/hr l/min
8
Lt.
Brown
(40)
2.5
3.0
3.5
4.0
4.5
5.0
250
300
350
400
450
500
12.2
12.5
12.8
12.8
13.1
13.4
1.63
1.80
1.94
2.06
2.18
2.29
27.2
30.0
32.3
34.4
36.3
38.2
22
23
24
25
25
25
25
27
27
29
29
29
10
Lt.
Green
(41)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
13.4
13.7
14.0
14.0
14.3
14.6
2.20
2.37
2.52
2.67
2.81
2.96
36.6
39.4
42.0
44.5
46.8
49.3
24
25
26
27
27
28
28
29
30
31
32
32
13
Lt. Blue
(42)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
13.7
14.0
14.3
14.3
14.6
14.9
2.36
2.55
2.73
2.90
3.06
3.23
39.4
42.6
45.5
48.3
51.0
53.9
25
26
27
28
29
29
29
30
31
33
33
33
15
Gray
(43)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
15.2
15.5
15.8
15.8
16.2
16.5
2.93
3.19
3.44
3.67
3.89
4.14
48.8
53.2
57.3
61.2
64.9
68.9
25
26
27
29
30
31
29
30
32
34
34
35
23
Dk.
Green
(44)
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
17.4
17.7
17.7
18.0
18.3
18.6
4.76
5.03
5.29
5.56
5.79
6.01
79.4
83.9
88.1
92.7
96.5
100.2
32
32
34
34
35
35
36
37
39
40
40
40
25
Dk.
Blue
(45)
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
18.0
18.3
18.6
18.9
19.2
19.5
5.33
5.65
5.96
6.29
6.57
6.84
88.7
94.2
99.3
104.9
109.6
114.1
33
34
34
35
36
36
38
39
40
41
41
42
I-40 Dual Opposing
Nozzle Performance Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m3/hr l/min
15
Gray
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
15.2
15.8
16.2
16.8
17.1
17.4
2.75
2.91
3.06
3.20
3.32
3.46
45.8
48.5
51.0
53.3
55.4
57.7
12
12
12
11
11
11
14
13
14
13
13
13
18
Red
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
17.4
17.7
18.0
18.0
18.3
18.9
2.90
3.15
3.38
3.61
3.82
4.05
48.3
52.5
56.4
60.1
63.7
67.5
10
10
10
11
11
11
11
12
12
13
13
13
20
Dk. Brown
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
18.9
19.2
19.5
20.1
19.8
20.1
4.26
4.54
4.80
5.08
5.32
5.55
71.1
75.6
80.0
84.7
88.7
92.5
12
12
13
13
14
14
14
14
15
15
16
16
23
Dk. Green
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
19.5
19.8
20.1
20.4
20.7
20.7
4.55
4.85
5.14
5.45
5.71
5.96
75.8
80.8
85.6
90.8
95.1
99.4
12
12
13
13
13
14
14
14
15
15
15
16
25
Dk. Blue*
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
20.1
20.4
20.7
21.0
21.3
21.3
4.92
5.23
5.52
5.84
6.10
6.36
82.1
87.2
92.0
97.3
101.7
106.0
12
13
13
13
13
14
14
14
15
15
15
16
28
Black
4.5
5.0
5.5
6.0
6.5
7.0
448
496
552
600
648
696
21.0
21.3
21.9
22.3
22.6
23.2
6.38
6.68
7.00
7.27
7.52
7.76
106.4
111.3
116.7
121.1
125.3
129.4
14
15
15
15
15
14
17
17
17
17
17
17
* Factory-installed nozzle
Note: All precipitation rates are calculated for 180 degree
operation. For the precipitation rate for a 360 degree sprinkler, divide by 2.
Precipitation rates for the ON model are calculated at 360 degrees.
* Factory-installed nozzle
Note: All precipitation rates are calculated for 180 degree operation. For the precipitation rate for a 360 degree sprinkler, divide by 2.
Precipitation rates for the ON model are calculated at 360 degrees.
I-40
Nozzle Performance Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m3/hr l/min
8
Lt.
Brown
(40)
2.5
3.0
3.5
4.0
4.5
5.0
250
300
350
400
450
500
13.1
13.4
13.7
14.0
14.0
14.3
1.63
1.80
1.94
2.06
2.18
2.29
27.2
30.0
32.3
34.4
36.3
38.2
19
20
21
21
22
22
22
23
24
24
26
26
10
Lt.
Green
(41)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
14.6
14.9
15.2
15.5
15.5
15.8
2.20
2.37
2.52
2.67
2.81
2.96
36.6
39.4
42.0
44.5
46.8
49.3
21
21
22
22
23
24
24
24
25
25
27
27
13
Lt. Blue
(42)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
14.9
15.2
15.5
15.5
15.8
16.2
2.36
2.55
2.73
2.90
3.06
3.23
39.4
42.6
45.5
48.3
51.0
53.9
21
22
23
24
24
25
24
25
26
28
28
29
15
Gray
(43)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
16.2
16.5
16.8
17.1
17.4
18.0
2.93
3.19
3.44
3.67
3.89
4.14
48.8
53.2
57.3
61.2
64.9
68.9
22
24
24
25
26
26
26
27
28
29
30
30
23
Dk.
Green
(44)
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
18.9
19.2
19.5
19.8
20.1
20.1
4.76
5.03
5.29
5.56
5.79
6.01
79.4
83.9
88.1
92.7
96.5
100.2
27
27
28
28
29
30
31
32
32
33
33
34
25
Dk.
Blue
(45)
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
20.1
20.4
20.7
21.0
21.0
21.3
5.33
5.65
5.96
6.29
6.57
6.84
88.7
94.2
99.3
104.9
109.6
114.1
26
27
28
28
30
30
30
31
32
33
34
35
I-40 High Speed
Nozzle Performance Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m3/hr l/min
8
Lt.
Brown
(40)
2.5
3.0
3.5
4.0
4.5
5.0
250
300
350
400
450
500
12.2
12.5
12.8
12.8
13.1
13.4
1.63
1.80
1.94
2.06
2.18
2.29
27.2
30.0
32.3
34.4
36.3
38.2
22
23
24
25
25
25
25
27
27
29
29
29
10
Lt.
Green
(41)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
13.4
13.7
14.0
14.0
14.3
14.6
2.20
2.37
2.52
2.67
2.81
2.96
36.6
39.4
42.0
44.5
46.8
49.3
24
25
26
27
27
28
28
29
30
31
32
32
13
Lt. Blue
(42)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
13.7
14.0
14.3
14.3
14.6
14.9
2.36
2.55
2.73
2.90
3.06
3.23
39.4
42.6
45.5
48.3
51.0
53.9
25
26
27
28
29
29
29
30
31
33
33
33
15
Gray
(43)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
15.2
15.5
15.8
15.8
16.2
16.5
2.93
3.19
3.44
3.67
3.89
4.14
48.8
53.2
57.3
61.2
64.9
68.9
25
26
27
29
30
31
29
30
32
34
34
35
23
Dk.
Green
(44)
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
17.4
17.7
17.7
18.0
18.3
18.6
4.76
5.03
5.29
5.56
5.79
6.01
79.4
83.9
88.1
92.7
96.5
100.2
32
32
34
34
35
35
36
37
39
40
40
40
25
Dk.
Blue
(45)
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
18.0
18.3
18.6
18.9
19.2
19.5
5.33
5.65
5.96
6.29
6.57
6.84
88.7
94.2
99.3
104.9
109.6
114.1
33
34
34
35
36
36
38
39
40
41
41
42
I-40 Dual Opposing
Nozzle Performance Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m3/hr l/min
15
Gray
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
15.2
15.8
16.2
16.8
17.1
17.4
2.75
2.91
3.06
3.20
3.32
3.46
45.8
48.5
51.0
53.3
55.4
57.7
12
12
12
11
11
11
14
13
14
13
13
13
18
Red
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
17.4
17.7
18.0
18.0
18.3
18.9
2.90
3.15
3.38
3.61
3.82
4.05
48.3
52.5
56.4
60.1
63.7
67.5
10
10
10
11
11
11
11
12
12
13
13
13
20
Dk. Brown
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
18.9
19.2
19.5
20.1
19.8
20.1
4.26
4.54
4.80
5.08
5.32
5.55
71.1
75.6
80.0
84.7
88.7
92.5
12
12
13
13
14
14
14
14
15
15
16
16
23
Dk. Green
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
19.5
19.8
20.1
20.4
20.7
20.7
4.55
4.85
5.14
5.45
5.71
5.96
75.8
80.8
85.6
90.8
95.1
99.4
12
12
13
13
13
14
14
14
15
15
15
16
25
Dk. Blue*
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
20.1
20.4
20.7
21.0
21.3
21.3
4.92
5.23
5.52
5.84
6.10
6.36
82.1
87.2
92.0
97.3
101.7
106.0
12
13
13
13
13
14
14
14
15
15
15
16
28
Black
4.5
5.0
5.5
6.0
6.5
7.0
448
496
552
600
648
696
21.0
21.3
21.9
22.3
22.6
23.2
6.38
6.68
7.00
7.27
7.52
7.76
106.4
111.3
116.7
121.1
125.3
129.4
14
15
15
15
15
14
17
17
17
17
17
17
* Factory-installed nozzle
Note: All precipitation rates are calculated for 180 degree
operation. For the precipitation rate for a 360 degree sprinkler, divide by 2.
Precipitation rates for the ON model are calculated at 360 degrees.
* Factory-installed nozzle
Note: All precipitation rates are calculated for 180 degree operation. For the precipitation rate for a 360 degree sprinkler, divide by 2.
Precipitation rates for the ON model are calculated at 360 degrees.
I-40
Nozzle Performance Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m3/hr l/min
8
Lt.
Brown
(40)
2.5
3.0
3.5
4.0
4.5
5.0
250
300
350
400
450
500
13.1
13.4
13.7
14.0
14.0
14.3
1.63
1.80
1.94
2.06
2.18
2.29
27.2
30.0
32.3
34.4
36.3
38.2
19
20
21
21
22
22
22
23
24
24
26
26
10
Lt.
Green
(41)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
14.6
14.9
15.2
15.5
15.5
15.8
2.20
2.37
2.52
2.67
2.81
2.96
36.6
39.4
42.0
44.5
46.8
49.3
21
21
22
22
23
24
24
24
25
25
27
27
13
Lt. Blue
(42)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
14.9
15.2
15.5
15.5
15.8
16.2
2.36
2.55
2.73
2.90
3.06
3.23
39.4
42.6
45.5
48.3
51.0
53.9
21
22
23
24
24
25
24
25
26
28
28
29
15
Gray
(43)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
16.2
16.5
16.8
17.1
17.4
18.0
2.93
3.19
3.44
3.67
3.89
4.14
48.8
53.2
57.3
61.2
64.9
68.9
22
24
24
25
26
26
26
27
28
29
30
30
23
Dk.
Green
(44)
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
18.9
19.2
19.5
19.8
20.1
20.1
4.76
5.03
5.29
5.56
5.79
6.01
79.4
83.9
88.1
92.7
96.5
100.2
27
27
28
28
29
30
31
32
32
33
33
34
25
Dk.
Blue
(45)
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
20.1
20.4
20.7
21.0
21.0
21.3
5.33
5.65
5.96
6.29
6.57
6.84
88.7
94.2
99.3
104.9
109.6
114.1
26
27
28
28
30
30
30
31
32
33
34
35
I-40 High Speed
Nozzle Performance Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m3/hr l/min
8
Lt.
Brown
(40)
2.5
3.0
3.5
4.0
4.5
5.0
250
300
350
400
450
500
12.2
12.5
12.8
12.8
13.1
13.4
1.63
1.80
1.94
2.06
2.18
2.29
27.2
30.0
32.3
34.4
36.3
38.2
22
23
24
25
25
25
25
27
27
29
29
29
10
Lt.
Green
(41)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
13.4
13.7
14.0
14.0
14.3
14.6
2.20
2.37
2.52
2.67
2.81
2.96
36.6
39.4
42.0
44.5
46.8
49.3
24
25
26
27
27
28
28
29
30
31
32
32
13
Lt. Blue
(42)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
13.7
14.0
14.3
14.3
14.6
14.9
2.36
2.55
2.73
2.90
3.06
3.23
39.4
42.6
45.5
48.3
51.0
53.9
25
26
27
28
29
29
29
30
31
33
33
33
15
Gray
(43)
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
15.2
15.5
15.8
15.8
16.2
16.5
2.93
3.19
3.44
3.67
3.89
4.14
48.8
53.2
57.3
61.2
64.9
68.9
25
26
27
29
30
31
29
30
32
34
34
35
23
Dk.
Green
(44)
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
17.4
17.7
17.7
18.0
18.3
18.6
4.76
5.03
5.29
5.56
5.79
6.01
79.4
83.9
88.1
92.7
96.5
100.2
32
32
34
34
35
35
36
37
39
40
40
40
25
Dk.
Blue
(45)
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
18.0
18.3
18.6
18.9
19.2
19.5
5.33
5.65
5.96
6.29
6.57
6.84
88.7
94.2
99.3
104.9
109.6
114.1
33
34
34
35
36
36
38
39
40
41
41
42
I-40 Dual Opposing
Nozzle Performance Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m3/hr l/min
15
Gray
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
15.2
15.8
16.2
16.8
17.1
17.4
2.75
2.91
3.06
3.20
3.32
3.46
45.8
48.5
51.0
53.3
55.4
57.7
12
12
12
11
11
11
14
13
14
13
13
13
18
Red
3.0
3.5
4.0
4.5
5.0
5.5
300
350
400
450
500
550
17.4
17.7
18.0
18.0
18.3
18.9
2.90
3.15
3.38
3.61
3.82
4.05
48.3
52.5
56.4
60.1
63.7
67.5
10
10
10
11
11
11
11
12
12
13
13
13
20
Dk. Brown
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
18.9
19.2
19.5
20.1
19.8
20.1
4.26
4.54
4.80
5.08
5.32
5.55
71.1
75.6
80.0
84.7
88.7
92.5
12
12
13
13
14
14
14
14
15
15
16
16
23
Dk. Green
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
19.5
19.8
20.1
20.4
20.7
20.7
4.55
4.85
5.14
5.45
5.71
5.96
75.8
80.8
85.6
90.8
95.1
99.4
12
12
13
13
13
14
14
14
15
15
15
16
25
Dk. Blue*
4.0
4.5
5.0
5.5
6.0
6.5
400
450
500
550
600
650
20.1
20.4
20.7
21.0
21.3
21.3
4.92
5.23
5.52
5.84
6.10
6.36
82.1
87.2
92.0
97.3
101.7
106.0
12
13
13
13
13
14
14
14
15
15
15
16
28
Black
4.5
5.0
5.5
6.0
6.5
7.0
448
496
552
600
648
696
21.0
21.3
21.9
22.3
22.6
23.2
6.38
6.68
7.00
7.27
7.52
7.76
106.4
111.3
116.7
121.1
125.3
129.4
14
15
15
15
15
14
17
17
17
17
17
17
* Factory-installed nozzle
Note: All precipitation rates are calculated for 180 degree
operation. For the precipitation rate for a 360 degree sprinkler, divide by 2.
Precipitation rates for the ON model are calculated at 360 degrees.
* Factory-installed nozzle
Note: All precipitation rates are calculated for 180 degree operation. For the precipitation rate for a 360 degree sprinkler, divide by 2.
Precipitation rates for the ON model are calculated at 360 degrees.
I-40
Nozzle Performance Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m3/hr l/min
8
Lt.
Brown
(40)
2.5
3.0
3.5
4.0
4.5
5.0
248
303
352
400
448
496
13.4
13.7
14.0
14.0
14.0
14.3
1.52
1.68
1.80
1.92
2.03
2.13
25.4
28.0
30.0
32.0
33.8
35.5
17
18
18
20
21
21
20
21
21
23
24
24
10
Lt.
Green
(41)
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
14.9
15.2
15.5
15.5
15.8
16.2
2.16
2.33
2.49
2.64
2.79
2.95
36.0
38.9
41.5
44.1
46.5
49.1
19
20
21
22
22
23
22
23
24
25
26
26
13
Lt. Blue
(42)
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
15.2
15.5
16.2
16.5
16.8
17.1
2.37
2.54
2.71
2.87
3.01
3.17
39.4
42.4
45.2
47.8
50.2
52.9
20
21
21
21
21
22
24
24
24
24
25
25
15
Gray
(43)
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
16.8
17.1
17.4
17.7
18.0
18.6
2.87
3.11
3.33
3.55
3.75
3.97
47.9
51.8
55.6
59.1
62.4
66.1
20
21
22
23
23
23
24
25
26
26
27
26
23
Dk.
Green
(44)
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
19.2
19.5
19.8
20.1
20.1
20.4
4.47
4.75
5.02
5.31
5.56
5.80
74.4
79.1
83.6
88.5
92.6
96.6
24
25
26
26
27
28
28
29
30
30
32
32
25
Dk.
Blue
(45)
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
20.1
20.4
20.7
21.0
21.3
21.6
5.07
5.38
5.68
6.01
6.28
6.55
84.4
89.7
94.7
100.2
104.7
109.1
25
26
26
27
28
28
29
30
31
31
32
32
I-40 High Speed
Nozzle Performance Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m3/hr l/min
8
Lt.
Brown
(40)
2.5
3.0
3.5
4.0
4.5
5.0
248
303
352
400
448
496
13.4
13.7
14.0
14.0
14.0
14.3
1.52
1.68
1.80
1.92
2.03
2.13
25.4
28.0
30.0
32.0
33.8
35.5
17
18
18
20
21
21
20
21
21
23
24
24
10
Lt.
Green
(41)
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
13.1
13.4
13.4
13.4
13.7
14.0
2.16
2.33
2.49
2.64
2.79
2.95
36.0
38.9
41.5
44.1
46.5
49.1
25
26
28
29
30
30
29
30
32
34
34
35
13
Lt. Blue
(42)
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
13.7
14.0
14.3
14.6
14.9
15.2
2.37
2.54
2.71
2.87
3.01
3.17
39.4
42.4
45.2
47.8
50.2
52.9
25
26
26
27
27
27
29
30
30
31
31
32
15
Gray
(43)
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
14.9
15.5
15.8
15.8
15.8
16.2
2.87
3.11
3.33
3.55
3.75
3.97
47.9
51.8
55.6
59.1
62.4
66.1
26
26
27
28
30
30
30
30
31
33
34
35
23
Dk.
Green
(44)
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
17.7
17.7
17.7
18.3
18.3
18.3
4.47
4.75
5.02
5.31
5.56
5.80
74.4
79.1
83.6
88.5
92.6
96.6
29
30
32
32
33
35
33
35
37
37
38
40
25
Dk.
Blue
(45)
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
18.3
18.6
18.9
19.5
19.8
19.8
5.07
5.38
5.68
6.01
6.28
6.55
84.4
89.7
94.7
100.2
104.7
109.1
30
31
32
32
32
33
35
36
37
36
37
39
I-40 Dual Opposing
Nozzle Performance Data – Metric
Pressure Radius Flow Precip mm/hr
Nozzle Bars kPa m m3/hr l/min
15
Gray
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
15.2
15.8
16.2
16.8
17.1
17.4
2.75
2.91
3.06
3.20
3.32
3.46
45.8
48.5
51.0
53.3
55.4
57.7
12
12
12
11
11
11
14
13
14
13
13
13
18
Red
3.0
3.5
4.0
4.5
5.0
5.5
303
352
400
448
496
552
17.4
17.7
18.0
18.0
18.3
18.9
2.90
3.15
3.38
3.61
3.82
4.05
48.3
52.5
56.4
60.1
63.7
67.5
10
10
10
11
11
11
11
12
12
13
13
13
20
Dk. Brown
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
18.9
19.2
19.5
20.1
19.8
20.1
4.26
4.54
4.80
5.08
5.32
5.55
71.1
75.6
80.0
84.7
88.7
92.5
12
12
13
13
14
14
14
14
15
15
16
16
23
Dk. Green
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
19.5
19.8
20.1
20.4
20.7
20.7
4.55
4.85
5.14
5.45
5.71
5.96
75.8
80.8
85.6
90.8
95.1
99.4
12
12
13
13
13
14
14
14
15
15
15
16
25
Dk. Blue*
4.0
4.5
5.0
5.5
6.0
6.5
400
448
496
552
600
648
20.1
20.4
20.7
21.0
21.3
21.3
4.92
5.23
5.52
5.84
6.10
6.36
82.1
87.2
92.0
97.3
101.7
106.0
12
13
13
13
13
14
14
14
15
15
15
16
28
Black
4.5
5.0
5.5
6.0
6.5
7.0
448
496
552
600
648
696
21.0
21.3
21.9
22.3
22.6
23.2
6.38
6.68
7.00
7.27
7.52
7.76
106.4
111.3
116.7
121.1
125.3
129.4
14
15
15
15
15
14
17
17
17
17
17
17
* Factory-installed nozzle
Note: All precipitation rates are calculated for 180 degree
operation. For the precipitation rate for a 360 degree sprinkler, divide by 2.
Precipitation rates for the ON model are calculated at 360 degrees.
* Factory-installed nozzle
Note: All precipitation rates are calculated for 180 degree operation. For the precipitation rate for a 360 degree sprinkler, divide by 2.
Precipitation rates for the ON model are calculated at 360 degrees.
Nozzle
Retainer/
Range
Adjustment
Screw
Arc Adjustment
Socket
Fig. 3
Lift Up
Socket
SS
I40
®
I-40
ADS
Fig. 4
Water
flow
Arc Adjustment
Direction
