Huntleigh Hydroven 12 Instruction sheet

Hydroven 12

Contents
1. Safety .....................................................................3
1.1 Warnings.........................................................................................3
2. Electromagnetic Compatibility..............................5
3. Introduction............................................................8
3.1 About this Manual..........................................................................8
3.2 Intended Use ..................................................................................8
3.3 About the Hydroven 12 system....................................................8
3.4 Use Environment ...........................................................................9
4. Clinical Applications .............................................10
4.1 Indications.....................................................................................10
4.2 Contraindications .........................................................................11
5. Preliminary Checks...............................................12
6. Garment and Insert Information...........................13
6.1 Garment Dimensions....................................................................14
7. Hydroven 12 System..............................................16
7.1 Garment Connections ..................................................................16
7.2 Operating Modes...........................................................................17
7.2.1 Standby..............................................................................................................17
7.2.2 Sleep Mode........................................................................................................17
7.2.3 Run Mode..........................................................................................................17
7.3 Inflation Modes..............................................................................18
7.3.1 Sequential Inflation............................................................................................18
7.3.2 Wave Inflation....................................................................................................18
7.3.3 LymphAssist Inflation.........................................................................................19
7.3.4 Linking LymphAssist with other Therapy cycles ................................................20
8. Controls, Indicators and Alarms...........................21
8.1 Typical Control Panel in Run mode ............................................21
8.2 Pump Controls and Indicators.....................................................21
8.2.1 Run/Standby Button, and Run and Sleep Mode Indicators...............................22
8.2.2 Inflation Mode Select Button and Indicators......................................................22
8.2.3 Pressure Display and Pressure Setting Buttons................................................23
8.2.4 Therapy Setting Select Button and Therapy Setting Indicators.........................23
8.2.5 Therapy Setting Display and Therapy Setting Buttons......................................24
8.2.6 Storing New Therapy Settings...........................................................................25
8.3 Pump Alarm...................................................................................25
8.3.1 System Fault......................................................................................................25

2
Table of Contents
9. Operation...............................................................26
9.1 Preparing the System...................................................................26
9.2 Checking the Therapy Settings...................................................28
9.3 Changing the Therapy Settings...................................................29
9.3.1 Setting the Pressure..........................................................................................29
9.3.2 Setting the Inflate/Deflate Times........................................................................29
9.3.3 Setting the Treatment Duration..........................................................................30
9.4 Starting Therapy ...........................................................................30
9.5 Stopping Therapy .........................................................................31
9.6 Storing New Therapy Settings.....................................................31
9.7 Control Panel Lockout..................................................................31
9.7.1 Pressure Setting................................................................................................31
9.7.2 Inflation Mode and Therapy Time Settings ........................................................32
10.Decontamination...................................................33
10.1 Cleaning.........................................................................................33
10.2 Chemical Disinfection ..................................................................33
10.3 Cleaning and Sterilising Garments.............................................33
11.Routine Maintenance ............................................34
11.1 Hydroven 12 System.....................................................................34
11.1.1 Maintenance.....................................................................................................34
11.1.2 Servicing ..........................................................................................................34
11.1.3 Service Period..................................................................................................34
11.2 General Care, Maintenance and Inspection ...............................34
11.2.1 Pump................................................................................................................34
11.2.2 Garments .........................................................................................................34
11.3 Serial Number Labels...................................................................34
11.3.1 Pump................................................................................................................34
11.3.2 Garments .........................................................................................................34
12.Trouble Shooting...................................................35
13.Accessories...........................................................36
14.Specifications........................................................37
14.1 Equipment Classification ............................................................37
14.2 General ..........................................................................................37
14.3 Environmental...............................................................................38
14.4 Standards Compliance.................................................................38
15.Product Labelling..................................................39
16.End of Life Disposal ..............................................40
17.Warranty & Service...............................................41
17.1 Service Returns.............................................................................41

3
Safety
1. Safety
Before using this equipment, please study this manual
carefully and familiarise yourself with the controls, display
features and operation. Ensure that each user fully
understands the safety and operation of the unit, as misuse
may cause harm to the user or patient, or damage to the
product.
Please keep these Instructions for Use to hand for future reference.
Symbols
General Warning / Cautions
Follow Instructions for Use
1.1 Warnings
Do NOT use unapproved accessories or attempt to modify, disassemble or
otherwise misuse the Hydroven 12 system. Failure to observe this caution could
result in injury, or in extreme cases, death.
WARNING: A possible explosion hazard exists if used in the
presence of flammable anaesthetics.
WARNING: Do not mount the unit directly above the patient.
Locate the unit so that it will not cause harm should it fall.
WARNING: Do not operate the unit from the mains supply if the
mains cable is damaged.
WARNING: Do not immerse any portion of the unit in water or
other liquids.
WARNING: Use only recommended accessories listed in this
manual.
WARNING: If this product is connected to another item of
electrical equipment, it is important that the system is fully
compliant with EN60601-1.
WARNING: It is the responsibility of the care giver to ensure that
the user can use this product safely.

4
Safety
WARNING: Make sure that the mains power cable and tubeset or
air hoses are positioned to avoid causing a trip or other hazard,
and are clear of moving bed mechanisms or other possible
entrapment areas.
WARNING: Electrical equipment may be hazardous if misused.
There are no user-serviceable parts inside the pump. The pump’s
case must only be removed by authorised technical personnel.
No modification of this equipment is allowed.
WARNING: The mains power socket/plug must be accessible at
all times. To disconnect the pump completely from the electricity
supply, remove the plug from the mains power socket.
WARNING: Disconnect the pump from the mains power socket
before cleaning and inspecting.
WARNING: Only the pump and garment/insert combination as
indicated by Huntleigh should be used. The correct function of
the product cannot be guaranteed if incorrect pump and garment
combinations are used.
WARNING: Bags supplied with this equipment may present a
suffocation risk; to avoid the risk of suffocation, keep the bags
away from babies and small children.
CAUTION: Do not expose the system to naked flames, such as
cigarettes, etc.
CAUTION: Do not store the system in direct sunlight.
CAUTION: Do not use phenol-based solutions to clean the
system.
CAUTION: Make sure the system is clean and dry prior to use or
storage.
CAUTION: Pets and children must be supervised in the vicinity
of the system.
Expected Service Life
The Hydroven 12 has an expected service life of 7 years. To maintain the
condition of the pump have it serviced regularly according to the schedule
recommended by your Huntleigh distributor.

5
Electromagnetic Compatibility
2. Electromagnetic Compatibility
Make sure the environment in which Hydroven 12 is installed is not subject to
strong sources of electromagnetic interference (e.g. radio transmitters, mobile
phones).
This equipment generates and uses radio frequency energy. If not installed
and used properly, in strict accordance with the manufacturer’s instructions,
it may cause or be subject to interference. Type-tested in a fully configured
system, complies with EN60601-1-2, the standard intended to provide
reasonable protection against such interference. Whether the equipment causes
interference may be determined by turning the equipment off and on. If it does
cause or is affected by interference, one or more of the following measures may
correct the interference:
• Reorienting the equipment
• Relocating the equipment with respect to the source of interference
• Moving the equipment away from the device with which it is
interfering
• Plugging the equipment into a different outlet so that the devices are
on different branch circuits
WARNING: The Hydroven 12 should not be used adjacent to
or stacked with other equipment and that if adjacent or stacked
use is necessary, the Hydroven 12 should be observed to verify
normal operation in the configuration in which it will be used
Guidance and Manufacturer’s declaration - electromagnetic emissions
The Hydroven 12 is intended for use in the electromagnetic environment specified below. The
customer or the user of the Hydroven 12 should assure that it is used in such an environment.
Emissions Test Compliance Electromagnetic Environment - guidance
RF emissions
CISPR 11 Group 1
The Hydroven 12 uses RF energy only for its internal
function. Therefore, its RF emissions are very low and are
not likely to cause any interference in nearby electronic
equipment.
RF emissions
CISPR 11 Class B
The Hydroven 12 is suitable for use in all establishments,
including domestic establishments and those directly
connected to the public low-voltage power supply network
that supplies buildings used for domestic purposes.
Harmonic emissions
IEC 61000-3-2 Class A
Voltage fluctuations /
flicker emissions
IEC 61000-3-3 Complies

6
Electromagnetic Compatibility
Guidance and Manufacturer’s declaration - electromagnetic immunity
The Hydroven 12 is intended for use in the electromagnetic environment specified below. The
customer or the user of the Hydroven 12 should assure that it is used in such an environment.
Immunity Test IEC 60601 test
level Compliance level Electromagnetic Environment - guidance
Portable and mobile RF communications
equipment should be used no closer to any
part of the Hydroven 12, including cables,
than the recommended separation distance
calculated from the equation applicable to
the frequency of the transmitter.
Conducted RF
IEC 61000-4-6 3 Vrms 150kHz to 80MHz 3V d= 1.2 √P
Radiated RF
IEC 61000-4-3 3 Vrms 80MHz to 2.5MHz 3V/m d= 1.2 √P80MHz to 800MHz
d= 2.3 √P800MHz to 2.5GHz
where Pis the maximum output power
rating of the transmitter in watts (W)
according to the transmitter manufacturer
and dis the recommended separation
distance in metres (m).
Field strengths from fixed RF transmitters,
as determined by an electromagnetic
site survey, ashould be less than the
compliance level in each frequency range b.
Interference may occur in the vicinity of
the equipment marked with the following
symbol:
NOTE 1 At 80MHz and 800MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected
by absorption and reflection from structures, objects and people.
aField strengths from fixed transmitters, such as base stations for radio (cellular/cordless)
telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast
cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to
fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field
strength in the location in which the Hydroven 12 is used exceeds the applicable RF compliance
level above, the Hydroven 12 should be observed to verify normal operation. If abnormal
performance is observed, additional measures may be necessary, such as re-orienting or relocating
the Hydroven 12.
bOver the frequency range 150kHz to 80kHz, field strengths should be less than 3V/m.

7
Electromagnetic Compatibility
Recommended separation distances between portable and mobile RF communications
equipment and the Hydroven 12
The Hydroven 12 is intended for use in an electromagnetic environment in which radiated
RF disturbances are controlled. The customer or user of the Hydroven 12 can help prevent
electromagnetic interference by maintaining a minimum distance between portable and mobile RF
communications equipment (transmitters) and the Hydroven 12 as recommended below, according
to the maximum output power of the communications equipment.
Rated maximum
output power of
transmitter
W
Separation distance according to frequency of transmitter
m
150kHz to 80MHz
d= 1.2 √P
80MHz to 800MHz
d= 1.2 √P
800MHz to 2.5GHz
d= 2.3 √P
0.01 0.12 0.12 0.23
0.1 0.38 0.38 0.73
1 1.2 1.2 2.3
10 3.8 3.8 7.3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the recommended separation
distance din metres (m) can be estimated using the equation applicable to the frequency of the
transmitter, where Pis the maximum output power rating of the transmitter in watts (W) according to
the transmitter manufacturer.
NOTE 1 At 80MHz and 800MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected
by absorption and reflection from structures, objects and people.

8
Introduction
3. Introduction
3.1 About this Manual
This manual is your introduction to the Hydroven®12 system.
You must read and fully understand this manual before using the system.
Use this manual to initially set up the system, and keep it as a reference for day-
to-day routines and as a guide to maintenance.
If you have any difficulties in setting-up or using the Hydroven 12 system,
contact your local Huntleigh sales representative, listed at the end of this
manual.
3.2 Intended Use
The intended use of this product is to manage the list of clinical conditions
detailed in the “Indications” section.
The Hydroven 12 system should be used as part of a prescribed plan of care
detailed in the “Indications” section.
3.3 About the Hydroven 12 system
The system comprises a pump and multi-chamber arm or leg garments. Optional
multi-chamber garment inserts can be used to increase the circumference of the
arm and leg garments.
The pump supplies air to inflate the chambers in the garments via connecting
tubes, allowing the application of controlled pressure to gently compress and/or
massage the limb.
The pump has three inflation modes:
• Sequential.
• Wave.
• LymphAssist®.
Sequential and Wave inflation are used for the treatment of wounds, chronic
venous insufficiency, and venous or dependency oedema. The gentle
compression of the limb increases the return of blood and excess fluids,
improves venous stasis and encourages the reabsorption of waste products.

9
Introduction
LymphAssist inflation is used where there is a requirement to move lymph
away from malfunctioning lymphatics. The gentle, rhythmic massage of the limb
throughout the LymphAssist cycle moves the skin in the direction of the lymph
flow and stimulates the lymphatic vessels, which carry proteins and waste
products.
The pump can also be set to “link” LymphAssist cycles with Sequential or Wave
cycles to treat patients with lympho-venous oedema.
A full technical description of the Hydroven 12 system can be found in the
Service Manual, part number SER0010, available from your local Huntleigh
sales representative.
3.4 Use Environment
Hydroven 12 is suitable for use in hospital, primary care and community
settings. It must not be used outdoors, or in any environment where it may
come into contact with water.

10
Clinical Applications
4. Clinical Applications
4.1 Indications
Intermittent Pneumatic Compression (IPC) is effective in the treatment of the
following clinical conditions, when combined with an individualised monitoring
programme:
• Oedema.
• Dependent (including secondary to cerebrovascular
incident, pregnancy or paralysis).
• Traumatic (post-surgical or injury).
• Lymphoedema.
• Primary and secondary (including post
surgery, radio or chemotherapy).
• Chronic venous insufficiency.
• Post phlebotic syndrome.
• Acute and chronic wounds including venous leg ulcers and post-
surgical wounds.
IPC may also be beneficial in the management of:
• Fixed flexion deformity.
• Arthritic conditions.
• Lower limb pain due to trauma or surgery.
• Lipoedema.
Selection should be based upon a holistic assessment of the patients’ individual
care needs.
Note: These systems represent one aspect of a treatment strategy;
if the patient’s condition changes the overall therapy regimen
should be reviewed by the prescribing clinician.
Note: The above are guidelines only and should not replace clinical
judgement.

11
Clinical Applications
4.2 Contraindications
IPC should NOT be used in the following circumstances:
• Known or suspected deep vein thrombosis (DVT), pulmonary
embolism, thrombophlebitis and acute infections of the skin, such as
cellulitis.
• Decompensated/severe congestive cardiac failure, pulmonary
oedema associated with significant limb oedema or any condition
where an increase of fluid to the heart may be detrimental.
• Severe arteriosclerosis or other ischaemic vascular disease.
• Active metastatic disease affecting the limb.
NOTE TO PATIENT: if you are uncertain whether you have any of the above
conditions please consult a physician before use.
CAUTION: IPC should be used with care in patients with the
following symptoms or conditions:
• Peripheral neuropathy, pain or numbness in the limb.
• Undiagnosed, untreated or infected wounds, fragile
skin, grafts or dermatological conditions that may be
aggravated by the garment.
• Extreme limb deformity which may practically impede
the correct application of the garment.
WARNING: Therapy should be interrupted if pain, tingling or
numbness of the limb occurs during or as a result of therapy.
WARNING: In the event of a power failure or fault whereby the
garment remains inflated, disconnect the tubeset(s) in order to
deflate the garment(s) and then remove the garment(s) from the
limb(s).
WARNING: Patients must not walk or stand when wearing leg
garments.

12
Preliminary Checks
5. Preliminary Checks
Contents (supplied with each system)
Item Item
1 x Hydroven 12 1 x Instructions for Use
Delivery Inspection
Huntleigh Healthcare Ltd takes every precaution to ensure that goods reach
you in perfect condition. However, accidental damage can occur in transit and
storage. For this reason we recommend that a thorough visual inspection is
made immediately the unit is received. Should any damage be evident or any
parts missing, ensure that Huntleigh Healthcare Ltd is informed at once.
Storage
If the unit not be required for immediate use, it should be re-sealed into its
original packing after carrying out the initial delivery inspection, and stored
under covered conditions at a temperature between -20°C to +50°C, and
relative humidity of 20% to 95% non-condensing.
After exposure to extreme temperatures during storage, the pump must be
allowed to adjust to normal operating temperatures for a minimum of 12 hours
before use. Failure to do this may result in accelerated wear of mechanical
components.

13
Garment and Insert Information
6. Garment and Insert Information
WARNING: Bags supplied with this equipment can present a
suffocation risk; to avoid the risk of suffocation, keep the bags
away from babies and small children.
The Hydroven 12 pump is designed to be used with Hydroven™ 12 garments,
which are available in two sizes for arms and four sizes for legs. Each length
arm and leg garment has a corresponding Hydroven 12 insert piece which
increases its circumference by 17 cm for arm garments and 19 cm for leg
garments.
The length of the tubeset is 140 cm from the pump connector to the foot/hand
end of the garment.
All garments (arm garments, leg garments and garment inserts) have multiple
chambers. Each chamber overlaps the adjacent chamber to provide smooth
and seamless pressure application, and prevent pressure voids or ridging to
the limbs. All garments have zip closures. When closed, the inflating chamber
section overlaps underneath the zip around the whole circumference of the limb
to prevent pressure voids and ridging of the skin underneath the zip section.
The leg garment (and leg garment insert) has a unique 5-chamber foot section
which provides fine application of pressure to the foot, promoting blood and
lymph movement.
Garment inserts are available for arm and leg garments to fit larger limbs. Once
connected to the garment and pump they are designed to inflate in sequence
with the garment to provide unique inflation capabilities for larger limbs.
Arm Garment Leg Garment
Arm Garment
Insert Piece Leg Garment
Insert Piece

14
Garment and Insert Information
6.1 Garment Dimensions
Limbs should be measured and the correct garment(s) chosen using the
following measuring guides and tables of dimensions.
When determining the correct garment size:
• Remove any bandages, stockings and/or any bulky dressings.
• Measure the circumference of the limb where stated.
• When measuring, do not pull the tape measure tight.
• Make sure the garment extends above the level of the swelling/
trauma, whilst maintaining the level of comfort.
Note: Garments should not feel tight-fitting when deflated.
1. Arm Garments:
• The length of the garment is measured from the
fingertips to 5 cm below the armpit, with the arm straight.
• The circumference of the garment is measured at the shoulder
Length
(Shoulder to Fingertips)
Shoulder
Circumference
at Shoulder
Fingers
Arm Garment Dimensions
Garment Part No. 316A68 316A78
Length (shoulder to fingertips) 68 cm 78 cm
Circumference (at shoulder)
Arm Garment
with Garment Insert 62 cm 79 cm 62 cm 79 cm
Corresponding Insert Piece Part No. 316AI68 316AI78
Width of Insert (at shoulder) 17 cm 17 cm
Note: The Hydroven 12 arm garment insert piece adds 17 cm to the
shoulder-end circumference of the garment.

15
Garment and Insert Information
2. Leg Garments:
• There are two ranges of leg garments: standard and large.
• The length of the garment is measured
from the heel to 5 cm below the groin.
• The circumference of the garment is measured at the top of the thigh.
Top of Thigh
Length
(Top of thigh to heel)
Heel
Circumference
Leg Garment Dimensions Standard Large
Garment Part No. 316L76S 316L84S 316L76W 316L84W
Length (top-of-thigh to heel) 76 cm 84 cm 76 cm 84 cm
Circumference
(at top-of-thigh)
Leg Garment
with Garment Insert 71 cm 90 cm 71 cm 90 cm 79 cm 98 cm 79 cm 98 cm
Corresponding Insert Piece
Part No. 316LI76 316LI84 316LI76 316LI84
Width of Insert (at top of thigh) 19 cm 19 cm 19 cm 19 cm
Note: The Hydroven 12 leg garment insert piece adds 19 cm to the
top-of-thigh circumference of the garment.
For further information about garment sizing, please contact Huntleigh.

16
Hydroven 12 System
7. Hydroven 12 System
The Hydroven 12 pump is designed for table-top use, with the controls situated
at the front of the pump. It comprises a moulded case with non-slip feet on the
base and rear cover, and an integral carry handle.
Non-Slip Feet
Lower 12-Way connector
(shown with rubber cover
closed) Control Panel
Upper 12-Way
connector
Carry Handle
7.1 Garment Connections
There are two 12-way connectors on the front of the pump. They are covered
by a 2-part, hinged, rubber cover, which is secured to the pump by a strap. The
cover is fitted over both connectors when the pump is being cleaned to prevent
ingress of fluids.
The garments are connected to these two 12-way connectors, which are push-
fit and polarised to prevent incorrect orientation of the connectors. The following
pump/garment connections are possible:
• If two garments are used (either two arm garments, two leg
garments, or one arm/leg garment and one garment insert), one will
be connected to the upper connector and the other connected to the
lower connector. The two connections are interchangeable - both
garments will inflate at the same time and to the same pressure.
• If only one garment is used, it must be connected to the upper
connector and the rubber cover must be securely fitted to the lower
connector (folded as shown).
All garments (arm garments, leg garments and garment inserts) have multiple
chambers. The chambers are inflated in a pre-determined sequence, according
to the inflation modes detailed below. (Refer to “Inflation Modes”).
The inflation of the chambers follows a preset pressure gradient, but the
deflation of the chambers is effectively instantaneous.

17
Hydroven 12 System
7.2 Operating Modes
Refer to “Pump Controls and Indicators” for a description of the controls and
indicators on the pump.
The pump has the following three operating modes:
7.2.1 Standby
After the mains power supply has been switched on to the pump, the pump will
perform a short self-test and then go into Standby.
In Standby mode:
• The Run and Sleep mode indicators are extinguished.
• The pump shows the previously selected therapy settings.
• The pump is ready to start therapy. Press the Run/Standby button to
start therapy.
7.2.2 Sleep Mode
If the pump has been in Standby for 10 minutes without any of the buttons being
pressed, it then goes into Sleep mode to conserve power.
Note: The pump can be left in Sleep mode for long periods without
disconnecting the mains power.
In Sleep mode:
• Only the Sleep mode indicator on the control panel is illuminated.
• All other displays and indicators are extinguished.
• Press the Run/Standby button to put the pump into Standby.
7.2.3 Run Mode
The pump is in Run mode for the duration of the therapy session, while it is
inflating and deflating the garments.
In Run mode:
• The Run mode indicator will be illuminated.
• The pump automatically stops at the end of the selected therapy time
and the garments are deflated.
• The pump can be stopped during the therapy by pressing the Run/
Standby button.
Note: Loss of mains power will halt therapy.

18
Hydroven 12 System
7.3 Inflation Modes
The pump has the following three inflation modes:
7.3.1 Sequential Inflation
1. The first garment chamber starts to inflate.
2. When the first chamber has been inflated to the correct pressure, the second
chamber starts to inflate.
3. This sequence continues for all 12 chambers.
Note: In Sequential mode, all chambers are kept fully inflated while
subsequent chambers are inflated.
4. After the final chamber has been inflated, all chambers are then deflated
simultaneously.
5. The pressure in each chamber is less than the pressure in the preceding
chamber, and the pressure in the final chamber is set to 60% of the pressure
in the first chamber.
7.3.2 Wave Inflation
1. The first garment chamber starts to inflate.
2. When the first chamber has been inflated to the correct pressure, the second
chamber starts to inflate.
3. When the second chamber has been inflated to the correct pressure, the first
chamber starts to deflate and the third chamber starts to inflate.
Note: The patient may feel that more than one chamber is inflated at
any one time.
4. This sequence continues for all 12 chambers.
5. The pressure in each chamber is less than the pressure in the preceding
chamber, and the pressure in the final chamber is set to 60% of the pressure
in the first chamber.
Note: Wave inflation is also known as “peristaltic” inflation.
Chamber
100%
60%
100%
60%
Chamber
Sequential Inflation Cycle Wave Inflation Cycle
Pressure Pressure

19
Hydroven 12 System
7.3.3 LymphAssist Inflation
Refer to the diagram below for the LymphAssist cycle.
Note: Chamber 1 is at the distal (foot/hand) end and chamber 12 is at
the proximal (thigh/shoulder) end.
1. On initial application, the LymphAssist therapy starts with a single peristaltic
Wave inflation from chamber 1 to chamber 12.
2. A LymphAssist cycle is comprised of the following sequence of inflations/
deflations, starting at chamber 12, then 11, 10, etc., down to chamber 1:
• There are 5 pulses where the chamber is inflated and
deflated. These are referred to as LymphAssist pulses.
• This is followed by a single “partial”-peristaltic Wave inflation of
part of the garment - between the next chamber and chamber 12.
For example, at chamber 5, the 5 LymphAssist pulses are followed by a
partial-peristaltic Wave inflation from chamber 6 to chamber 12.
1
2
3
4
5
6
7
8
9
10
11
12
Proximal
Distal
5 x LymphAssist pulses Start of next
LymphAssist cycle
LymphAssist cycle
Peristaltic
Wave Inflation Deflate Time
Garment Chamber
Start of LymphAssist Cycle “Partial”-Peristaltic wave inflation
Time
3. When the partial-peristaltic Wave inflation gets to chamber 12, there is a
short delay, and then the sequence of 5 LymphAssist pulses followed by a
partial-peristaltic Wave inflation is repeated for the next chamber.
4. The LymphAssist cycle is complete after the 5 LymphAssist pulses at
chamber 1 and the partial-peristaltic Wave inflation from chamber 2 to
chamber 12.
5. The next LymphAssist cycle will start after the Deflate time set on the pump
control panel.
Note: The maximum pump pressure that can be set in LymphAssist
mode is 40 mmHg.
