Night Curtain
with Internal Brake
for Excel B3X, C3X and C2NX
Multi-deck Cases with Narrow Canopy
1
P/N 0500176_A
January 2008
©2008 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
PARTS LIST (per curtain)
Item Quantity Description
1. Night Curtain
Brackets
(Factory Installed)
1 Left-hand
1 Right-hand
2. 1Night Curtain
3. 1Wrench
4. 1Spindle Lock
5. 1Handle Hook
6. 2Screw (#6 x 3/8)
LH
RH

Notes: Night curtains are intended
to reduce energy use outside normal
business hours.
Carefully unpack and inspect the
night curtain and components to
ensure there is no breakage or
damage, and there are no missing
parts.
Be sure cases have been positioned
and leveled according to installation
instructions. Install night curtains
after all cases are joined, and
splashguards and bumpers are
installed.
1Remove the night curtain close off.
P/N 0500176_A
2
Remove Screws
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM

Note: Night Curtain
Brackets (parts list Item 1)
are factory-installed.
2Verify spring tension in the Night Curtain (parts list
Item 2).
The night curtain spring is
properly tensioned at the time
of shipment but may unwind
due to vibration or rough
handling.
To tension the spring, use the
supplied Wrench (parts list
Item 3) on the rectangular pin
on the RH end of the curtain
(as shown in Detail 2A), then
make 10 to 12 full clockwise
revolutions.
After passing the detent, gently
tap on the end. Slowly release
pressure against the spring until
the wrench stops, then remove
the wrench. Handle tensioned
curtain carefully.
Excel Multi-Deck Night Curtain
Installation Instruction
P/N 0500176_A
3
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
Make sure the curtain is
the internal brake style.
- - - - - - - - - - - - - - - - - -
Old style has no brake.
Uncontrolled release can
lead to personal injury or
equipment damage.
WARNING
!

3Place the rectangular pin of the night curtain into the cross
shaped opening of the right-
hand bracket.
4Put the Spindle Lock (parts list Item 4) on the spindle of the
night curtain. The spindle is
on the left end of the night
curtain. Put the spindle lock
in place by sliding it into the
keyhole slot of the left bracket
and turning the spindle lock
90 degrees as shown in the
illustration and Detail 4A.
Test tension of spring and
adjust if needed before moving
to next step. (Remove spindle
lock and remove night curtain
from case. Return to Step 2.)
Note: Spindle Lock will be very
stiff in cold temperatures or
when new.
Spring tension cannot be
adjusted without removing the
curtain from the case.
P/N 0500176_A
4HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
Spindle
Lock
Night Curtain
Bracket
Locked
Position
Rectangular
Pin
Night Curtain
Bracket
Detail 4A

5Reinstall the night curtain close off removed in Step 1.
6Mount the Handle Hook (parts list Item 5) below the
front bumper. Pull the night
curtain down and put the
hook on the handle to position
the hook. Mark the mounting
hole locations and drill pilot
holes for the Mounting Screws
(parts list Item 6). Mount the
Handle Hook with the
Mounting Screws.
Once the Night Curtain installation
is complete, spring tension cannot
be adjusted without removing the
curtain from the case.
Excel Multi-Deck Night Curtain
Installation Instruction
P/N 0500176_A
5
Night
Curtain
Handle
Handle
Hook
Mounting
Screw
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
Reinstall Screws
Locate handle through opening
between brackets for Night Curtain
Close off

P/N 0500176_A
6HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
Installed Night Curtain with Spindle Lock Inside LH Mounting Bracket
