Hussmann RGD Original operating instructions

RGD
UPRIGHT DELI CASE
INSTALLATION & OPERATION GUIDE
/CHINO
RGD
UPRIGHT DELI CASE REV. 0223
Installation
&Operation
Manual

1. General Instructions
/CHINO
A publication of HUSSMANN®Chino
13770 Ramona Avenue • Chino, California 91710
[phone] FAX
[phone]
[phone]
www.hussmann.com
This Booklet Contains Information on:
RGD: A narrow depth multi deck air curtain case designed to display pre-packaged
Deli products. It can be placed at the end of gondolas or inline with gondola.
Shipping Damage
All equipment should be thoroughly examined for shipping damage before and during
unloading.
This equipment has been carefully inspected at our factory and the carrier has assumed
responsibility for safe arrival. If damaged, either apparent or concealed, claim must
be made to the carrier.
Apparent Loss or Damage
If there is an obvious loss or damage, it must be noted on the freight bill or express
receipt and signed by the carrier’s agent; otherwise, carrier may refuse claim. The
carrier will supply necessary claim forms.
Concealed Loss or Damage
When loss or damage is not apparent until after equipment is uncrated, a claim for
concealed damage is made. Make request in writing to carrier for inspection within 15
days, and retain all packaging. The carrier will supply inspection report and required
claim forms.
Shortages
Check your shipment for any possible shortages of material. If a shortage should exist
and is found to be the responsibility of Hussmann Chino, notify Hussmann Chino. If such
a shortage involves the carrier, notify the carrier immediately, and request an inspection.
Hussmann Chino will acknowledge shortages within ten days from receipt of equipment.
Hussmann Chino Product Control
The serial number and shipping date of all equipment has been recorded in Hussmann’s
files for warranty and replacement part purposes. All correspondence pertaining to
warranty or parts ordering must include the serial number of each piece of equipment
involved, in order to provide the customer with the correct parts.
Keep this booklet with the case at all times for future reference.
2

2. Table of Contents
1. General Instructions...............................................................2
2. Table of Contents ...................................................................3
3. Cut and Plan Views ................................................................4
4. Installation............................................................................. 11
5. Plumbing ...............................................................................14
6. Refrigeration .........................................................................15
7. Electrical................................................................................22
8. Finishing Touches ................................................................23
9. User Information...................................................................23
10. Maintenance........................................................................26
11. Controller Data....................................................................28
12. RGD Check List ..................................................................29
13. Electrical Wiring Diagrams ................................................30
14. Wiring Diagrams .................................................................31
15. Troubleshooting Guide ......................................................67
16. Appendices .........................................................................69
17. Program Parameters ..........................................................72
18. Controller Instructions.......................................................74
3

3. Cut and Plan Views
4

Cut and Plan Views (Cont'd)
5

Cut and Plan Views (Cont'd)
6

Cut and Plan Views (Cont'd)
7

Cut and Plan Views (Cont'd)
8

Cut and Plan Views (Cont'd)
9

Cut and Plan Views (Cont'd)
10
