Huvitz HS-5000 User manual

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 1 / 72
SLIT LAMP MICROSCOPE
HS-5000&5500
7000&7500
HIS-5000
5000U
HUVITZ IMAGING SYSTEM

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 2 / 72
1. Information
2. Structure of SLIT LAMP
3. Principle of SLIT LAMP
4. Illumination System
5. Microscope
6. Installation of Slit Lamp
7. Installation of Joystick driver
8. Installation of LED
9. NEW SMPS Installation
10. Trouble Shooting
Contents

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 3 / 72
1. The slit lamp performs stereomicroscopic
examination of the eye under the slit light.
2. The slit lamp performs microscopic examination
of the ocular fundus and posterior vitreous body
(using hruby’s lens).
3. The slit lamp is designed for use
ophthalmologists and optometrists.
Information

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 4 / 72
Illumination
System
Microscope
Module
Mechanical
Body
Structure 1
HS-5000,7000

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 5 / 72
Illumination
System
Microscope
Module
Mechanical
Body
Structure 2
HS-5500,7500

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 6 / 72
⑮
①: Eyepiece
②: Prism (Ver Prism)
③: Prism (Hor Prism)
④: 16x lens
⑤: Magnification lens
⑥: Objective lens
⑦: Mirror
⑧: Lamp lens
⑨: C lens
⑩: Halogen lamp
⑪: C mirror
⑫: OD’S Eyes
⑮: Patient’s Eye
①
⑤
②
③
④
⑦
⑧
⑨
⑩
⑪
⑫
①
③
②
⑥
⑫
⑩→⑪→⑨→⑧→⑦
→⑮→⑥→⑤→④
→③→②→①→⑫
⑮
Principle

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 7 / 72
①Light source Halogen lamp (12V 30W)
or LED
②Slit length 0.3 ~ 12mm
③Slit width 0 ~ 12mm (continuous)
④Slit projection 1x
⑤Aperture diaphragm 0.3 / 1 / 3 / 5 / 9 / 12mm
⑥Filters cobalt blue / ND (gray) /
heat absorption /
red-free (green)
⑦Slit rotation 0 ~ 180˚ (continuous)
•1
•2
3
•5
•6
7
Illumination System
HS-5000,7000
1
2
5
6

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 8 / 72
①Light source Halogen lamp (12V 30W)
or LED
②Slit length 0.3 ~ 12mm
③Slit width 0 ~ 12mm (continuous)
④Filters cobalt blue / ND (gray) /
heat absorption /
red-free (green)
⑤Slit rotation 0 ~ 180˚ (continuous)
⑥Horizontal tilting Slit movement
(left & right)
⑦Vertical tilting Angle change for slit
⑧Diffuser Diffusing the light
1 2
3
5
6
7
Illumination System
HS-5500,7500
4
8

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 9 / 72
•6
Blue filter
Vacancy
Heat absorption filter
(IR)
ND(25%) filter
(Gray)
Green filter
①The cobalt blue filter is used in conjunction with fluorescein dye.
②The green filter (red-free) obscures anything that is red, thus blood
vessels or hemorrhages appear black.
③Neutral Density filter (ND) is to reduces the amount of light.
④Heat absorption (IR) filter is mainly used in lighting systems to absorb
the heat from a light source.
Illumination System –Filter 1
•4

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 10 / 72
Yellow filter
The Yellow filter fits RGP lenses with fluorescein dye
After installation, check whether Yellow filter is removed or not.
Illumination System –Filter 2
Yellow Filter

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 11 / 72
①Type Galilean converging
binocular (8˚)
②Eyepiece 12.5x, 10.0x
③Diopter adjustment ±5D
④PD adjustment 55 ~ 80mm
⑤Filter yellow
⑥Magnification 5 positions rotating drum
⑦Total magnification & real field of view
6x (38.5mm)
10x (22.2mm)
16x (15.2mm)
25x (10.5mm)
40x (6.7mm)
6
2
3
4
5
Microscope

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 12 / 72
Part Name 1
•6
0

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 13 / 72
1. Fixation point
2. Control lever for changing enlargement
3. Removable eye-pieces
4. Knob for clamping the breath screen
5. Breath screen
6. Control handle for the slit rotation 90-0-90
7. Connecting plug of the projector lamp
8. Knurled ring for filters insertion
9. Movements (x y z)
10. Base with orthogonal movements
11. Shaped tabletop
12. Warning light of the SMPS
13. Main switch
14. Luminosity selector
15. SMPS box
16. Drawer
17. Toothed guides
18. Wheel protection Cases
19. Sliding plate
20. Knob to lock the projector
21. Scale for the projector position
22. Knob to lock the arm of the microscope
23. Hole cover
24. Knurled knob to lift the bulb holder
25. Ring for the vertical setting of the chin-rest
26. Locking pins for chin rest paper
27. Chin rest
28. Knobs to change the slit width
29. Pointer for the eye positioning
30. Head rest
31. Microscope
33. Knob to lock the base of the instrument
34. Knob to lock the microscope
35. Control handle for horizontal tilting
36. Control lever for vertical tilting
37. Microscope position stop
38. 90-0-90 determining the inclination of
the slit during rotation
39. Lamp cover
45. Microscope arm
49. An optical group of the slit projector
50. Patient’s handle
51. Chin rest fastening screw
52. Wheel
55. Mirror
56. Capture connector (For the image system)
57. Capture switch
58. Luminosity selector connector (Connecting to the SMPS)
59. Head rest module
60. LED Lamp (Option)
Part Name 2

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 14 / 72
CIT-5000 (Made by HUVITZ)
or your country’s model
TABLE MODULE
(HS-5000)
Installation TABLE

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 15 / 72
1. Table Ass’y
2. Main Body Ass’y
3. Microscope Ass’y
4. Illumination Ass’y
5. Rotation Guide Bolt
6. Wheel protection Cases
7. Head rest module
8. Screw M3
9. Bolt M6
10. Stopper shaft
Rotation Guide Bolt
Stopper shaft
Installation HS-5000,7000

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 16 / 72
1. Table Ass’y
2. Main Body Ass’y
3. Microscope Ass’y
4. Illumination Ass’y
5. Head rest module
6. Screw M3
7. Bolt M6
Installation HS-5500,7500
1
2
3
4
5
6
7

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 17 / 72
Be careful, you have to assemble the Microscope until you reach end
of the stopper.
STOPPER
Installation Microscope Ass’y
Using the test bar, check whether focus is aligned or not.
(Try to move entire Microscope until the figure(sight) become clear)

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 18 / 72
Be careful, you have to connect the connector to the cable.
Installation CABLE

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 19 / 72
(1) Camera Module (2) Camera communication cable
(3) Auxiliary light cable (4) FireWire IEEE 1394 cable or USB
(5) Software CD (6) Light sensor plate
(7) Light sensor PCB (1394 or USB) (8) Scatter (Diffuser)
(9) Auxiliary light cable supporter (10) Auxiliary light Module
Component and Accessories

Customer Service Department HUVITZ Co.,Ltd
2013. 08. 16 20 / 72
Installation HS-5000/7000 (1)
2. Remove the old camera cables.
1. Remove the cover by loosening
the screws.
※Notice : In case of equipped camera, you can skip the slide (1) ~ (10)
