Huyndai Ioniq hybrid User manual

G2EUG11

(영어 | 미국) 표준4세대

www.hyundai.com Car Multimedia System | User’s Manual

User’s Manual

H_AE HEV 16_G4.0[USA_EU]AVN_COVER.indd 2-3H_AE HEV 16_G4.0[USA_EU]AVN_COVER.indd 2-3 2016-11-10 오후 1:48:442016-11-10 오후 1:48:4

Thank you for purchasing this multimedia

system.

This user's manual explains how to use

the HYUNDAI Motor multimedia system.

Before using the product, read the

contents of this user's manual carefully

and use this product safely.

• The screens shown in this manual may

differ with the actual screens of the

product.

• The design and specification of this

product may change without prior

notification for product improvement.

• When transferring the vehicle to

another individual, include this user's

manual so that the next driver can

continue its use.

Precaution for safe usage

• Driving while distracted can result

in a loss of vehicle control, that may

lead to an accident, severe personal

injury, and death. The driver’s primary

responsibility is in the safe and legal

operation of a vehicle, and use of any

handheld devices, other equipment, or

vehicle systems which take the driver’s

eyes, attention and focus away from

the safe operation of a vehicle or which

are not permissible by law should never

be used during operation of the vehicle.

• Do not operate the multimedia system

while driving.

• Do not disassemble, assemble, or

modify the multimedia system.

• Do not watch the screen for prolonged

periods of time while driving.

• Set the volume to a level which allows

the driver to be aware of external

conditions.

• Do not operate the multimedia system

for prolonged periods of time with the

vehicle ignition in ACC. Such operations

may lead to battery discharge.

• Be cautious not to spill water or introduce

foreign objects into the device.

• Do not cause severe shock to the

device. Direct pressure onto the front

side of the monitor may cause damage

to the LCD or touch panel.

• In case of product malfunction, please

contact your place of purchase or

service center.

• When cleaning the touch screen, make

sure to turn off the device and use a

dry and smooth cloth. Never use tough

materi-als, chemical cloths, or solvents

(alcohol, ammonia, benzene, thinners,

etc.) as such materials may damage the

device panel or cause color and quality

deterioration.

• SiriusXM service requires a

subscription, sold separately, after

3-month trial included with vehicle

purchase. If you decide to continue

your SiriusXM service at the end of

your trial subscription, the plan you

choose will automatically renew and

bill at then-current rates until you

call Sirius XM at 1-866-635-2349 to

cancel. See our Customer Agreement

for complete terms at www.siriusxm.

com. Programming subject to change.

Sirius satellite service is available

only to those at least 18 and older

in the 48 contiguous USA, D.C.,

and PR (with coverage limitations).

Trafﬁc information not available in all

markets. See siriusxm.com/trafﬁc for

details. Sirius, XM and all related marks

and logos are trademarks of Sirius XM

Radio Inc.

WARNING

• Driving while distracted can result in a

loss of vehicle control that may lead to

an accident, severe personal injury, and

death. The driver’s primary responsibility

is in the safe and legal operation of a

vehicle, and use of any handheld devices,

other equipment, or vehicle systems

which take the driver’s eyes, attention

and focus away from the safe operation

of a vehicle or which are not permissible

by law should never be used during oper-

ation of the vehicle.

All Map Database cannot be copied without permission.

Important Notice : This is protected by U.S. copyright laws. All rights not expressly granted are reserved.

You may not otherwise reproduce, modify and distribute the content without HYUNDAI MnSoft, Inc’s prior written consent.

H_AE HEV 16_G4.0[USA_EU]AVN_COVER.indd 4-5H_AE HEV 16_G4.0[USA_EU]AVN_COVER.indd 4-5 2016-11-10 오후 1:48:482016-11-10 오후 1:48:4

Read the following safety precautions for your

safety

Before using the product, read the contents of this user's manual

carefully and use this product safely.

※The design and speciﬁcations of this product may change without prior

notiﬁcation for product and service improvement.

The actual features in the vehicle may differ from the illustrations.

For more accurate information about the vehicle, please refer to the

catalogue.

※For more information on open licenses and legal notices, refer to the

website below.

http://www.mobiszone.co.kr/front/mall/jsp/manual/avn_download_

center_manual.jsp

Notations used within this User's Manual

WARNING

• Failure to observe the instructions within this category could result in death

or serious injury or damage to the vehicle.

CAUTION

• Information on matters that could potentially lead to injury or vehicle

damage/malfunction Information that could lead to higher user safety

Information

• Information and tips that provide additional user convenience in using the

product

NOTICE

• Information on specific features that facilitate proper product use and

functional understanding

• Information on terminology used within this manual

H_AE HEV 16_G4.0[USA_EU]AVN_PART0.indd 1H_AE HEV 16_G4.0[USA_EU]AVN_PART0.indd 1 2016-11-10 오후 1:49:572016-11-10 오후 1:49:5

HYUNDAI VEHICLE OWNER PRIVACY POLICY

Your Hyundai vehicle may be equipped with technologies and services that use information collected,

generated, recorded or stored by the vehicle. Hyundai has created a Vehicle Owner Privacy Policy to explain

how these technologies and services collect use and share this information.

You may read our Vehicle Owner Privacy Policy on the Hyundaiusa.com website at:

https://www.hyundaiusa.com/owner-privacy-policy.aspx

If you would like to receive a hard copy of our Vehicle Owner Privacy Policy, please contact our Customer

Connect Center at:

Hyundai Motor America/Phoenix

P.O. Box 83835

Phoenix, AZ 85071-3835

800-633-5151

consumeraff[email protected]

Hyundai's Customer Connect Center representatives are available Monday through Friday,

between the hours of 5:00 AM and 7:00 PM PST and Saturday and Sunday between 6:30 AM and 3:00 PM PST

(English).

For Customer Connect Center assistance in Spanish or Korean, representatives are available Monday

through Friday between 6:30 AM and 3:00 PM PST.

H_AE HEV 16_G4.0[USA_EU]AVN_PART0.indd 2H_AE HEV 16_G4.0[USA_EU]AVN_PART0.indd 2 2016-11-10 오후 1:50:002016-11-10 오후 1:50:0
