Thank you for purchasing this multimedia

system.

This user's manual explains how to use

the HYUNDAI Motor multimedia system.

Before using the product, read the con-

tents of this user's manual carefully and

use this product safely.

•

The screens shown in this manual may

differ with the actual screens of the

product.

•

The design and specification of this

product may change without prior notifi-

cation for product improvement.

•

When transferring the vehicle to another

individual, include this user's manual so

that the next driver can continue its use.

Precaution for safe usage

•

Driving while distracted can result in a

loss of vehicle control, that may lead to

an accident, severe personal injury, and

death. The driver’s primary responsibil-

ity is in the safe and legal operation of a

vehicle, and use of any handheld devices,

other equipment, or vehicle systems which

take the driver’s eyes, attention and focus

away from the safe operation of a vehicle

or which are not permissible by law should

never be used during operation of the

vehicle.

•

Do not operate the

multimedia system

while driving.

•

Do not disassemble, assemble, or modify

the

multimedia system

•

Do not watch the screen for prolonged

periods of time while driving.

•

Set the volume to a level which allows the

driver to be aware of external conditions.

•

Do not operate the

multimedia system

for

prolonged periods of time with the vehicle

ignition in ACC. Such operations may lead

to battery discharge.

•

Be cautious not to spill water or introduce

foreign objects into the device.

•

Do not cause severe shock to the device.

Direct pressure onto the front side of the

monitor may cause damage to the LCD or

touch panel.

•

In case of product malfunction, please

contact your place of purchase or service

center.

•

When cleaning the touch screen, make

sure to turn off the device and use a dry

and smooth cloth. Never use tough materi-

als, chemical cloths, or solvents (alcohol,

ammonia, benzene, thinners, etc.) as such

materials may damage the device panel or

cause color and quality deterioration.

•

SiriusXM service requires a subscrip-

tion, sold separately, after 3-month trial

included with vehicle purchase. If you

decide to continue your SiriusXM ser-

vice at the end of your trial subscription,

the plan you choose will automatically

renew and bill at then-current rates until

you call Sirius XM at 1-866-635-2349 to

cancel. See our Customer Agreement

for complete terms at www.siriusxm.

com. Programming subject to change.

Sirius satellite service is available only

to those at least 18 and older in the 48

contiguous USA, D.C., and PR (with

coverage limitations). Traffic informa-

tion not available in all markets. See

siriusxm.com/traffic for details. Sirius,

XM and all related marks and logos are

trademarks of Sirius XM Radio Inc.

WARNING

• Driving while distracted can result in a

loss of vehicle control that may lead to

an accident, severe personal injury, and

death. The driver’s primary responsibil-

ity is in the safe and legal operation

of a vehicle, and use of any handheld

devices, other equipment, or vehicle

systems which take the driver’s eyes,

attention and focus away from the safe

operation of a vehicle or which are not

permissible by law should never be used

during operation of the vehicle.

All Map Database cannot be copied without permission.

Important Notice : This is protected by U.S. copyright laws. All rights not expressly granted are reserved.

You may not otherwise reproduce, modify and distribute the content without HYUNDAI MnSoft, Inc’s prior written consent.

H_LFE 17MY_G4.0[USA_EU]AVN_COVER.indd 4-5H_LFE 17MY_G4.0[USA_EU]AVN_COVER.indd 4-5 2016-06-28 오전 9:56:552016-06-28 오전 9:56:5

Read the following safety precautions for your

safety

Before using the product, read the contents of this user's manual

carefully and use this product safely.

※The design and speciﬁcations of this product may change without prior

notiﬁcation for product and service improvement.

The actual features in the vehicle may differ from the illustrations.

For more accurate information about the vehicle, please refer to the

catalogue.

※For more information on open licenses and legal notices, refer to the

website below.

http://www.mobiszone.co.kr/front/mall/jsp/manual/avn_download_

center_manual.jsp

Notations used within this User's Manual

WARNING

• Failure to observe the instructions within this category could result in death

or serious injury or damage to the vehicle.

CAUTION

• Information on matters that could potentially lead to injury or vehicle

damage/malfunction Information that could lead to higher user safety

Information

• Information and tips that provide additional user convenience in using the

product

NOTICE

• Information on specific features that facilitate proper product use and

functional understanding

• Information on terminology used within this manual

H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 1H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 1 2016-06-28 오전 9:58:212016-06-28 오전 9:58:2

HYUNDAI VEHICLE OWNER PRIVACY POLICY

Your Hyundai vehicle may be equipped with technologies and services that use information collected,

generated, recorded or stored by the vehicle. Hyundai has created a Vehicle Owner Privacy Policy to explain

how these technologies and services collect use and share this information.

You may read our Vehicle Owner Privacy Policy on the Hyundaiusa.com website at:

https://www.hyundaiusa.com/owner-privacy-policy.aspx

If you would like to receive a hard copy of our Vehicle Owner Privacy Policy, please contact our Customer

Connect Center at:

Hyundai Motor America/Phoenix

P.O. Box 83835

Phoenix, AZ 85071-3835

800-633-5151

consumeraff[email protected]

Hyundai's Customer Connect Center representatives are available Monday through Friday,

between the hours of 5:00 AM and 7:00 PM PST and Saturday and Sunday between 6:30 AM and 3:00 PM PST

(English).

For Customer Connect Center assistance in Spanish or Korean, representatives are available Monday

through Friday between 6:30 AM and 3:00 PM PST.

H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 2H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 2 2016-06-28 오전 9:58:242016-06-28 오전 9:58:2

Table of Contents I 3

1. Basic

Warnings and Cautions .........................1-2

Key Product Features ...........................1-4

Component Names and Functions ......1-5

Head Unit……………………………… 1-5

Steering Wheel Controls ……………… 1-7

Starting the System for the

First Time .................................................1-9

Turning the System On/Off …………… 1-9

System Reset ………………………… 1-9

Battery Warning Message ……………1-10

Restrictions on Features for

Safety Measures ……………………… 1-10

Home Screen …………………………1-11

On-Screen Touch Controls …………… 1-12

2. Hybrid

Hybrid information .................................2-2

Starting Hybrid Mode ………………… 2-2

Driving Status of Hybrid Vehicle ……… 2-3

3. AV

FM/AM .....................................................3-2

FM/AM Mode Display Controls ……… 3-2

HD Radio™ Technology ........................3-4

HD Radio™ Mode Display Controls … 3-5

SiriusXM™ ...............................................3-6

SiriusXM™ Mode Display Controls … 3-6

Selecting through Channel/

Category List ………………………… 3-8

Direct Tune …………………………… 3-8

Viewing Menu ………………………… 3-8

About Disc .............................................3-11

Precautions upon Handling Discs …… 3-11

Supported Disc Formats……………… 3-12

Disc/Content Format Compatibility…… 3-12

Before Playing an MP3 Disc ………… 3-14

Disc CD ....................................................3-16

CD Mode Display Controls ……………3-16

Disc MP3 ................................................3-19

Disc MP3 Mode Display Controls ……3-19

USB ..........................................................3-22

Before Playing a USB MP3……………3-22

Supported USB MP3 music

specifications …………………………3-24

Supported Image Specifications……… 3-24

USB Mode Display Controls ………… 3-25

USB Image …………………………… 3-28

iPod .........................................................3-30

Using iPod Devices ……………………3-30

iPod Mode Display Controls ………… 3-34

AUX .........................................................3-37

Connecting an External Device ……… 3-37

Bluetooth® Audio ..................................3-38

Bluetooth Audio Mode Display

Controls ………………………………3-38

Bluetooth Connections Settings ………3-39

My Music ...............................................3-40

My Music Mode Display Controls …… 3-40

Table of Contents

H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 3H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 3 2016-06-28 오전 9:58:242016-06-28 오전 9:58:2

4 I Table of Contents

4. Bluetooth

Before Using the Bluetooth®

Handsfree ................................................4-2

What is

Bluetooth

Wireless

Technology?…………………………… 4-2

Precautions for Safe Driving ………… 4-2

CAUTIONS upon Connecting Bluetooth®

Phone ………………………………… 4-3

Bluetooth Connection ............................4-4

Pairing a New Device ………………… 4-4

Connecting Bluetooth Devices ……… 4-4

Disconnecting Bluetooth Devices …… 4-5

Deleting Bluetooth Devices…………… 4-5

Bluetooth Phone ....................................4-6

Phone Status Icons ………………… 4-6

Dial …………………………………… 4-7

Accept/Reject Call …………………… 4-7

Using the Menu During a Phone Call… 4-8

Call History …………………………… 4-9

Contacts ………………………………4-10

Favorites ………………………………4-11

5. Blue Link® Control

Name and Function of Each Part ........5-2

Rear View Mirror Switch ……………… 5-2

Before Use ...............................................5-3

What Is Blue Link? …………………… 5-3

What Is Telematics? ………………… 5-3

About Transmission and Reception of

Radio Waves ………………………… 5-3

Getting Started with Blue Link ............5-4

Connecting with the Blue Link Center … 5-4

Blue Link®Safety and Security Service…5-5

Stolen Vehicle Recovery ……………… 5-5

Driving Info ..............................................5-6

Send to Car with Google .......................5-6

Vehicle Diagnostics ................................5-7

Blue Link Settings ..................................5-7

Blue Link Voice Local Search ..............5-8

What is Blue Link Voice Local Search?… 5-8

Starting Blue Link Voice Local Search… 5-8

6. Navigation

Basic Features ........................................6-2

Operating Navigation Screen ………… 6-2

Places ………………………………… 6-3

Changing Map View ………………… 6-3

Navigation Volume …………………… 6-3

Zoom In/Zoom Out …………………… 6-4

Map Scale …………………………… 6-4

Menu .........................................................6-5

Route ………………………………… 6-5

Map Display ………………………… 6-6

Navigation Volume …………………… 6-6

Nearby POIs ………………………… 6-7

Traffic ………………………………… 6-10

Save ……………………………………6-14

Search .....................................................6-15

Places …………………………………6-15

Address ………………………………6-16

Previous Destinations ………………… 6-17

Local Search …………………………6-18

POI Categories ………………………6-19

Gas Stations …………………………6-20

H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 4H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 4 2016-06-28 오전 9:58:242016-06-28 오전 9:58:2

Table of Contents I 5

Restaurants ……………………………6-20

Emergency ……………………………6-20

Address Book …………………………6-21

Phone Number ……………………… 6-22

Freeway Exit/Entrance ……………… 6-23

Intersection ……………………………6-23

Coordinates ……………………………6-24

Favorite places………………………… 6-25

Route Setting ………………………… 6-26

Route Guidance ……………………… 6-29

Route .......................................................6-31

Canceling Route ……………………… 6-31

Display Route Information …………… 6-31

Route Overview ……………………… 6-32

Route Preview ………………………… 6-32

Editing Route ………………………… 6-33

Route Options ………………………… 6-34

Avoid Street ……………………………6-34

Navigation Settings ..............................6-35

General ………………………………6-35

Display ………………………………… 6-35

Guidance ………………………………6-36

Route …………………………………6-36

Traffic ………………………………… 6-36

Troubleshooting ....................................6-37

7. Voice Recognition

What is Voice Recognition? .................7-2

Precautions Required for Successful

Voice Recognition ..................................7-2

Starting/Ending and Setting Voice

Recognition ..............................................7-3

Starting Voice Recognition …………… 7-3

Ending Voice Recognition …………… 7-3

Combining Voice Recognition

with On-Screen Commands ………… 7-3

Extending the Listening Time ………… 7-4

Skipping Prompt Messages ………… 7-5

Adjusting Voice Recognition Volume … 7-5

Voice Recognition Screen Overview ..7-6

Start Screen…………………………… 7-6

Help Display…………………………… 7-6

Instructions for Using Voice Recognition…7-7

Voice Commands ....................................7-8

Types of Commands ………………… 7-8

Call Commands ……………………… 7-8

Navigation Commands ……………… 7-9

Radio Commands …………………… 7-11

Media Commands …………………… 7-12

Other Commands List

(Commands used in List / Help) ……… 7-14

“Find <Category>” List…………………7-15

Siri Eyes Free ........................................7-21

How to start Siri ………………………7-21

How to use Siri…………………………7-21

8. Info

Pandora Radio .......................................8-2

Pandora Radio Mode Screen Controls…8-2

SoundHound ............................................8-5

Accessing SoundHound……………… 8-5

SoundHound Screen Controls ……… 8-5

Recognizing Music …………………… 8-6

Searching Music ……………………… 8-6

Song Main Screen …………………… 8-7

H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 5H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 5 2016-06-28 오전 9:58:242016-06-28 오전 9:58:2

6 I Table of Contents

Download Center ...................................8-8

App List ……………………………… 8-8

My Apps ……………………………… 8-9

SiriusXM™ Data ...................................8-10

Accessing SiriusXM™ Data …………8-10

SiriusXM™ Weather Announcement…8-10

SiriusXM™ Traffic Information…………8-11

SiriusXM™ Fuel Price Information…… 8-12

SiriusXM™ Stock Information………… 8-13

SiriusXM™ Sports Information ………8-14

SiriusXM™ Movie Information ……… 8-16

9. Other Features

Camera ......................................................9-2

Steering-linked camera ……………… 9-2

10. Setup

Setup .......................................................10-2

Navigation Settings ..............................10-3

Sound Settings ......................................10-3

Display Settings ....................................10-4

Bluetooth Settings ...............................10-4

Bluetooth Settings …………………… 10-4

Bluetooth Connection Settings ……… 10-5

Auto Connection Priority ……………… 10-6

Phone Ringtone ……………………… 10-6

Bluetooth System Information…………10-7

Blue Link Settings ................................10-7

Service Activation ……………………10-8

Modem Information …………………… 10-8

Voice Recognition Settings ................10-8

Clock Settings .......................................10-9

Wi-Fi Settings .......................................10-9

Wi-Fi Settings Screen ………………… 10-9

How to Connect to a Network………… 10-9

Language Settings .............................10-10

Keyboard Settings ..............................10-10

Blue Link Apps Settings ....................10-10

Screen Saver Settings .......................10-11

System Info ..........................................10-11

System Update …………………… 10-11

11. Appendix

Product Specification ..........................11-2

Troubleshooting ....................................11-4

FAQ .........................................................11-7

About Pairing Mobile Phones …………11-7

About Making/Answering Phone Calls … 11-8

About

Bluetooth

Wireless Technology

/Head Unit Use Environment …………11-8

H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 6H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 6 2016-06-28 오전 9:58:242016-06-28 오전 9:58:2

CAUTIONS upon Using SD Cards

•Ejecting and Inserting SD Cards

• Ejecting and inserting SD cards while the multimedia system is operating may result in SD

Card or System errors. To eject or insert the SD card, ﬁrst turn off the multimedia system and

the vehicle ignition.

• Eject/insert SD cards only to update the multimedia system with a new version.

•Usage of SD Cards

• The SD Card is formatted to include only Map and new system update ﬁles.

• The SD Card cannot be used to save and play Music.

• Do not add, delete, or format ﬁles within the SD Card.

H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 7H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 7 2016-06-28 오전 9:58:252016-06-28 오전 9:58:2

iPod®

iPod®is a registered trademark of Apple Inc.

Bluetooth®

Wireless Technology

The Bluetooth®word mark and logos are registered trademarks owned

by Bluetooth SIG, Inc. and any use of such marks by HYUNDAI is under

license. Other trademarks and trade names are those of their respective

owners.

Bluetooth

Wireless Technology enabled cell phone is required to use

Bluetooth

Wireless Technology.

Bluetooth

Wireless Technology phone

compatibility can be checked by visiting https://www.hyundaiusa.com/

bluetooth.

HD Radio™ Technology

HD Radio™ Technology manufactured under license from iBiquity Digital

Corporation. U.S. and Foreign Patents.

HD Radio™ and the HD, HD Radio, and "Arc" logos are proprietary

trademarks of iBiquity Digital Corp.

Wi-Fi®

The Wi-Fi CERTIFIED™ Logo is a certiﬁcation mark of Wi-Fi Alliance.

H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 8H_LFE 17MY_G4.0[USA_EU]AVN_PART0.indd 8 2016-06-28 오전 9:58:252016-06-28 오전 9:58:2

Warnings and Cautions

Key Product Features

Component Names and Functions

Starting the System for the First Time

part.1 Basic

H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-1H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-1 2016-06-28 오전 9:59:382016-06-28 오전 9:59:3

1-2 I Basic

Safety Warnings

•Even when receiving route guidance

from the Navigation system, please

abide by actual traffic and road regu-

lations. Following only the Navigation

route guidance may lead to violations of

actual traffic and road regulations and

lead to traffic accidents.

•Do not stare at the screen while driv-

ing. Staring at the screen for prolonged

periods of time could lead to traffic acci-

dents.

•Do not operate the Navigation system

while driving, such as entering POIs or

conducting route searches. Doing so

may lead to an accident. Park the vehi-

cle before operating the device.

•Do not disassemble, assemble, or mod-

ify the Multimedia system. Doing so may

result in damage of the electronic equip-

ment.

•Heed caution not to spill water or intro-

duce foreign objects into the device.

Doing so may result in damage of the

electronic equipment or product mal-

function.

•If you use phone related functions while

driving, you will find it difficult to concen-

trate on operating the vehicle and the

current traffic conditions, so the possibil-

ity of an accident may increase. Please

use phone related functions only when

parked.

•Please refrain from use if the screen

is blank or no sound can be heard as

these signs may indicate product mal-

function.

•Do not stop or park in parking-restricted

areas to operate the product.

•For some Audio and multimedia modes,

the display will not operate when the

vehicle is in motion. For your safety, first

park the vehicle to watch or view the

screen.(The screen will only operate

when the parking brake is ON for man-

ual transmission vehicles and when the

parking brake is ON or the gearshift is in

the P (PARK) position for automatic.)

Basic

H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-2H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-2 2016-06-28 오전 9:59:392016-06-28 오전 9:59:3

Warnings and Cautions I 1-3

Safety Cautions

Pay attention to traffic conditions while

driving.

•In some instances, the navigation may

provide guidance through restricted

areas.

•Operating the device while driving could

lead to accidents due to a lack of atten-

tion to external surroundings. First park

the vehicle before operating the device.

In addition, the touch screen may not

work for some functions when the vehi-

cle is in motion. The touch screen fea-

ture will be supported once the vehicle

has stopped.

•Adjust the volume to levels that allow

the driver to hear sounds from outside

of the vehicle. Driving in a state where

external sounds cannot be heard may

lead to accidents.

•Pay attention to the volume setting when

turning the device on. A sudden output

of extreme volume upon turning the

device on could lead to hearing impair-

ment. (Adjust the volume to a suitable

levels before turning off the device.)

•If you want to change the position of

device installation, please inquire with

your place of purchase or service main-

tenance center. Technical expertise is

required to install or disassemble the

device.

•Turn on the car ignition before using this

device. Do not operate the Multimedia

system for long periods of time with the

ignition turned off as such operations

may lead to battery discharge.

•Upon using the Multimedia system

for more than 10 minutes with the car

engine turned off, the following warning

will be displayed. After 10 minutes, the

warning will be displayed for 5 seconds

every 1 minute.

•Do not subject the device to severe

shock or impact. Direct pressure onto

the front side of the monitor may cause

damage to the LCD or touch screen.

•When cleaning the device, make sure

to turn off the device and always use a

clean, soft cloth. Never use tough mate-

rials, chemical cloths, or solvents(alco-

hol, benzene, thinners, etc.) as such

materials may damage the device panel

or cause color/quality deterioration.

When experiencing product concerns,

inquire with your place of purchase or

service maintenance center.

•Prevent caustic solutions such as per-

fume and cosmetic oil from contacting

the dashboard because they may cause

damage or discoloration.

H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-3H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-3 2016-06-28 오전 9:59:402016-06-28 오전 9:59:4

1-4 I Basic

Display

Wide TFT-LCD Display

•Provides high quality video through a Wide TFT-

LCD Display using an LED Back Light.

•Touch screen for maximum user convenience.

Radio

Digital Tuner Feature

•Digital Tuner using PLL method that supports

memory of 12 broadcast stations for each AM

and FM modes.

Radio broadcast station name

•Displays broadcast station names.

HD Radio™/Satellite Radio feature

•Supports HD Radio™ reception and Satellite

Radio (SiriusXM™).

Key Product Features

This device is a Multimedia system equipped with a multifunctional

disc player that supports Radio (FM, AM), HD Radio™ Technology,

SiriusXM™, Audio CD, MP3, USB, iPod, AUX, Bluetooth Audio

and My Music features. The WIDE VGA LCD provides a high qual-

ity resolution while the powerful and rich sound system adds to the

driving enjoyment.

Multimedia

Player

Support for various Media Formats

•Support for various media formats, including

Radio, Audio CD, MP3, USB, iPod, AUX and

Bluetooth

Audio Streaming modes

My Music

•Supports copying of music stored within USB

devices into My Music (internal memory) mode

Navigation

Voice Guidance

•Voice route guidance to safely and conveniently

reach set destinations

•Various map scales that enable drivers to accu-

rately view map and surrounding areas

Automatic Correction for Current Location

•Automatically corrects current position using

map matching and GPS information.

Miscellaneous

Bluetooth

Wireless Technology

•Convenient use of Bluetooth

Handsfree by

using buttons within the steering wheel control

Digital Screen Control Features

•Easy control of features through touch screen

options

Steering Wheel Control

•Control over audio features, voice recognition

and Bluetooth

through the steering wheel con-

trol for maximum convenience

H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-4H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-4 2016-06-28 오전 9:59:402016-06-28 오전 9:59:4

Component Names and Functions I 1-5

Component Names and Functions

Head Unit

Name Description

POWER/

VOL

•When power is off, press to turn power on

•When power is on, press and hold (more than

0.8 seconds) to turn power off

•When power is on, press quickly (less than 0.8

seconds) to turn Audio off

•Turn left/right to control volume

TUNE

•FM/AM mode : changes the frequency

•SiriusXM™ mode : changes the channel

•MEDIA (Disc/USB/iPod/My Music) mode :

changes the track, file or title changes the

track, file or title (except USB Image, Bluetooth

Audio and AUX)

RADIO

Selects to FM/AM/SiriusXM™ mode

•Each time the key is pressed, the mode is

changed in order of FM →AM →SiriusXM™ →

Name Description

MEDIA

Selects to MEDIA mode

•If the media is not connected or the CD player is not

available for this model, MEDIA mode will not be

activated.

PHONE

Displays phone screen

BLUELINK

Displays the Blue Link screen

MAP

VOICE

Displays the map for the current position

NAVI

Displays the menu screen where you can find your

destination and set the route.

※ The actual feature in the vehicle may differ from the illustration.

H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-5H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-5 2016-06-28 오전 9:59:402016-06-28 오전 9:59:4

1-6 I Basic

Name Description

SEEK

TRACK

When pressed quickly. (less than 0.8 seconds)

•FM/AM mode : plays previous/next frequency

•SiriusXM™ mode : plays the previous/next channel

•MEDIA (Disc/USB/iPod/My Music) mode :

changes the track, file or title (except USB Image

and AUX)

When pressed and held down (more than 0.8 seconds),

•FM/AM mode : continuously changes the fre-

quency until the key is released

•SiriusXM™ mode : continuously changes the

channel until the key is released and plays the

current channel

•MEDIA (Disc/USB/iPod/My Music) mode :

rewinds or fastforwards the track or file (except

USB Image, Bluetooth Audio and AUX)

Name Description

SD card insert slot

Press to insert or eject disc

DISP

Turns the screen on/off.

INFO

Displays the information mode

SETUP

Displays the Setup screen

RESET

Resets the system settings. (Preset radio channels

and other data will not be deleted)

H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-6H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-6 2016-06-28 오전 9:59:432016-06-28 오전 9:59:4

Component Names and Functions I 1-7

Name Description

VOL +

VOL -

Controls the volume

MODE

•Each time this is pressed, the mode is changed

in the order FM →AM →SiriusXM™ →Disc →

USB Music or iPod →AUX →Bluetooth Audio →

My Music

•If the media is not connected, the corresponding

modes will be disabled

•Press and hold (more than 0.8 seconds) to turn

the Audio system on/off

•When power is off, press to turn power back on

When pressed quickly. (less than 0.8 seconds)

•FM/AM mode : searches broadcast frequencies

saved to Presets

•SiriusXM™ mode : searches broadcast channels

saved to Presets

•MEDIA (Disc/USB/iPod/My Music) mode :

changes the track, file or title (except USB Image,

AUX)

When pressed and held. (more than 0.8 seconds)

•FM/AM mode : automatically searches broadcast

frequencies

•SiriusXM™ mode : automatically searches broad-

cast channels

•MEDIA (Disc/USB/iPod/My Music) mode : quickly

looks up songs (excluding USB images, AUX and

Bluetooth audio files)

Steering Wheel Controls

H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-7H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-7 2016-06-28 오전 9:59:462016-06-28 오전 9:59:4

1-8 I Basic

Name Description

When pressed quickly. (less than 0.8 seconds)

•Activates voice recognition

When pressed and held. (more than 0.8 seconds)

•Ends voice recognition

•Activates Siri Eyes Free

When pressed quickly. (less than 1.2 seconds)

•When pressed in the dial screen, makes a call

•When pressed in the incoming call screen,

answers the call

•When pressed during call waiting, switches to

waiting call (Call Waiting)

When pressed and held. (more than 1.2 seconds)

•When pressed in Bluetooth

Hands-free, redials

the last dialed call

•When pressed during a Bluetooth

Hands-free

call, switches call back to mobile phone (Private)

•When pressed while calling on the mobile phone,

switches call back to Bluetooth

Hands-free

(operates only when Bluetooth

Hands-free is

connected)

•When pressed during a call, ends the phone call

•When pressed in the incoming call screen, rejects

the call

※ The actual feature in the vehicle may differ from the illustration.

H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-8H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-8 2016-06-28 오전 9:59:512016-06-28 오전 9:59:5

Starting the System for the First Time I 1-9

Starting the System for the

First Time

Turning the System On/Off

Press the engine start button or set the

ignition key to On or ACC. Each time you

turn on the system, a boot logo and safety

warning will appear.

Pressing the power key on the head unit

will display the user confirm screen. To

change the system language between

English, French, Spanish and Korean

press the Change

Language

button.

NOTICE

• You cannot operate the system while it is

booting up. It may take some time for all of

features of the system, particularly the voice

recognition system, to be ready for use.

Pressing and holding the power key on the

head unit will turn off the system.

You can change Screen Saver Settings in

Setup to display a clock or another chosen

image on the Screen Saver.

Information

• If you turn off the system during a phone call

using the Hands-free feature, then the call will

automatically switch to your mobile phone.

NOTICE

• Check the volume when turning on the

system. Before turning on the system, adjust

the volume to a reasonable level.

System Reset

The System Reset function restores the

system when it is not operating correctly.

Press and hold the RESET key for a sec-

ond or longer. (It is recommended that you

press the RESET key using a tool, such as

a pin or a clip.)

NOTICE

• Resetting the system restores all existing

settings and configurations (e.g. volume,

display, etc.) back to their factory defaults.

H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-9H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-9 2016-06-28 오전 9:59:522016-06-28 오전 9:59:5

1-10 I Basic

Battery Warning Message

Always use the system while the car

engine is running. If you turn on the sys-

tem while the engine is off, a battery warn-

ing message will appear. When the engine

starts, the message will disappear.

NOTICE

• If you use the system for a long time with

the engine off, the battery may become

completely discharged.

Restrictions on Features for

Safety Measures

The restriction screen will disappear when

shifting gears into P.

WARNING

- Blank Screen

• Refrain from use if the screen is blank or

no sound can be heard as these signs may

indicate product malfunction. Continued use in

such conditions could lead to accidents (ﬁres,

electric shock).

WARNING

- Touching the Antenna During A

Thunder Storm

• Do not touch the antenna during thunder or

lightning as such acts may lead to lightning

induced electric shock.

H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-10H_LFE 17MY_G4.0[USA_EU]AVN_PART1.indd 1-10 2016-06-28 오전 9:59:552016-06-28 오전 9:59:5

Table of contents

Huyndai Sonata Hybrid 2017 User manual

Popular Car Video System manuals by other brands
