HydroLogic EvolutionRo User manual

USER MANUAL

1
Description, Table of Contents................................................................................p 1
Precautions..........................................................................................................p 2
Filter Replacement Schedule ..................................................................................p 3
Includes ..............................................................................................................p 4
Installation........................................................................................................p 5-6
Performance and Dimensions.................................................................................p 7
Component Specs ................................................................................................p 8
Quick Connect Fittings..........................................................................................p 9
Warranty and Support........................................................................................p 10
Troubleshooting .................................................................................................p 11
Options ............................................................................................................p 12
Filter Replacement Notes.....................................................................................p 13
User Notes........................................................................................................p 14
DESCRIPTION
TABLE OF CONTENTS
The EvolutionROTM is a customized Reverse Osmosis water lter that is made in the USA. This
system is capable of reducing up to 95% of most contaminants. This system is designed and built
for use with hydroponic or horticultural applications. This system is built to give the maximum
amount of ow from the membrane while sending less waste water to the drain, compared to
similar RO lters. Please read the following setup and maintenance guide to get the maximum
results from your lter.
1

2
• Do not use this product to make safe drinking water from non-potable water sources. Do not use the system
on microbiologically unsafe water, or water of unknown quality without adequate disinfection before or
after the system.
• Temperature of the water supply to the EvolutionROTM must be between 40°F - 100°F (4°C - 38°C). Do
not install on hot water lines.
• High levels of certain contaminants in the incoming water may prematurely foul the membranes and/or
the pre-lter. Softened water is recommended for optimal system performance and RO membrane life.
• The black drain line must be unrestricted at all times.
• Keep out of direct sunlight or high intensity lights, which degrade the housing and ttings over time. Protect
unit against freezing to prevent cracking of the lter housing and water leakage. Replace housings every
three years. (HL 23115 See page 4).
• When replacing lter cartridges use the lter wrench to remove housing. Do not use the wrench to tighten
the housings. Hand tighten the housings only. Take care not to over-tighten.
• Do not install where leakage or failure may cause damage to property.
• If you are going to store or not use your EvolutionROTM for an extended period of time (2 weeks+), it is
recommended that you remove your membranes, seal them in plastic and put in refrigerator.
• Keep the lengths of tubing short. Longer lengths of tubing will decrease inlet pressure and ultimately system
performance.
• Do not use grease containing petroleum products.
• When the system is initially turned on, water may temporarily sputter until all the air is purged. Allow up to
4 hours for any trapped air noise in the system to subside.
• EvolutionROTM lter housings must be replaced every 3 years.
PRECAUTIONS
PRECAUTIONS:
The flow rate of product water can drastically decrease due to low psi and low temperature,
especially in the winter. In some cases with cold temperature and/or low pressure predicted
flow rate can drop by as much as 50% or more. A combination of cold water and low
pressure can drop flow rates even further. This is the case with all RO technology and is not
unique to the EvolutionROTM. The ratio of waste water to product water can also get drastically
worse due to low pressure and low temperature. You can overcome some of these issue by
increasing pressure with our optional booster pump (HL 29014 See pg. 12)) or by increasing
inlet temperature.
We do not recommend hooking the RO system up to your hot water tank lines because hot water tanks contain lots
of minerals and the water can be too hot. A safe way to increase temperature is with an on demand or flash style
water heater set at below 100°F (37.7°C). For people with adequate pressure but decreased water temperature a
flash water heater is a great way to increase flow rates.
2

3
ChloraShieldTM (HL 22019): The carbon filter reduces sediment and certain chemicals, such as
chlorine and chloramines from the water. Depending on water use and the amount of impurities,
this lter should be replaced a minimum of 2,500 gallons of puried water produced.
EvolutionROTM membrane (HL 22045): The functional life of the EvolutionROTM membranes will vary
based on feed water quality. Product water should be tested periodically to verify the membranes are
performing properly. For most applications, the EvolutionROTM membranes should be replaced every
6 months to two years.
BE SURE TO CHANGE YOUR FILTERS BASED ON THE FILTER
REPLACEMENT SCHEDULE!
FILTER REPLACEMENT SCHEDULE
HL 22043 HL 22045
Filter HydroLogic Part # Replacement
Schedule
ChloraShieldTM
HL 22043 2,500 gallons of
puried water
Membrane Element - 600 GPD
HL 22045 6 months - 2 years
3

4
EVOLUTION-ROTM INCLUDES
1. 2. 3.
4.
6.
8.
10.
11.
14. 15.
12. 13.
9.
7.
5.
1. Filter Housings (X3)
2. ChloraShieldTM Carbon Filter (X1)
3. 600+ Gallon Per Day Membranes (X2)
4. White Feed Fitting (X1)
5. Dark Blue Product Water Fitting (X1)
6. Orange 1:1 Ratio Drain Fitting (X1)
7. Green 2:1 Ratio Drain Fitting (X1)
8. Lock Bar (X1)
9. Pressure Gauge w/Tee Fitting (X1)
10. Support Leg/Housing Wrench (X1)
11. White Tubing (6 ft)
12. Black Tubing (10 ft)
13. Blue Tubing (10 ft)
14. Garden Hose Connector (X1)
15. Inline Shut-Off Valve (X1)
4

5
EVOLUTION-ROTM INSTALLATION
STEP 1:
Put a thin layer of lube on the o-rings of the 3
housings, and both o-rings on the 2 membranes.
Be sure to completely cover the o-rings.
Apply lube here
Apply lube here
STEP 2:
Install carbon lter. The lter can
only be installed in the manifold
in the position shown. The other
two openings in the manifold
are for the membranes.
STEP 5:
Lube the o-rings on
each of the 3 elbow
connector ttings
and push them into
the corresponding
STEP 6:
Install the manifold lock bar clip by matching
symbols on the clip to symbols on the manifold
(square to square, arrow to arrow).
STEP 3:
Once the housing
is hand-tight, crank
down one quarter
turn with the wrench.
There’s no need
for the ange on
the bottom of the
housing to come
in contact with
the ange on the
manifold.
STEP 4:
Install RO membranes.
Carefully push the rst
membrane into the
position shown. Push it
straight down into the
hole of the manifold
until both o-rings are
seated in the hole.
Install housing over
membrane. Do not
rock membrane back
and forth to install.
Repeat this step for
second membrane.
Tighten
ports on the manifold as shown. The back
of each elbow connector tting has a
symbol that corresponds to the symbol
next to the manifold ports.
5

6
STEP 8:
Install the Support Leg/Housing Wrench,
as shown.
Never install the shut-off valve on the
black waste water line! This has to be able
to drain waste water freely and without
obstruction.
STEP 10:
Install blue puried water tubing and black
waste water tubing into corresponding elbow
connector ttings as shown. The inline shut-off
valve should only be installed on blue puried
water line to shut system off/on.
STEP 9:
Install the white inlet tubing by pushing the tubing
into pressure gauge tting. Push the garden
hose inlet tting onto other end of
tubing. This tting is compatible
with garden hoses and hose
bibs.
EVOLUTION-ROTM INSTALLATION, CONT.
STEP 7:
Install the pressure gauge assembly. Push the
short length of tubing into the left side of the
gauge. Push the other end of the
tubing in to the elbow
connector tting
as shown.
6

7
PERFORMANCE
TFC Membrane
Rejection Chart
The TFC membrane rejection chart can
be very helpful as a general guideline,
but is not a guarantee. Every water
source has a different chemistry,
temperature and TDS, and it is best to
test your water thoroughly to determine
your unique water prole.
A good place to start is EWG.org,
just type in your zip-code to determine
what contaminants (if any) you may
be dealing with.
(243.9)
9.6
(242.5)
9.55
(89.8)
3.53
(383.5)
15.10
(508.9)
20.03
(268.2)
10.56
(261)
10.27
(140)
5.51
(84.3)
3.32
(130.4)
5.13
(59.4)
2.34
(114.3)
4.50
(50.8)
2.0
(25.4)
1.0
DIMENSIONS
7

8
ChloraShieldTM HL 22043:
• Operating pressure 20 -125 psi (1.38 - 8.62 bar)
• Operating temperature 40°F -125°F (4°C - 52°C)
• 1 micron nominal ltration
• No release of carbon nes
• Exceptionally low pressure drop
RO Membrane: HL 22045
EvolutionROTM HydroLogic Membranes are recognized as one of the industry’s most reliable
and highest performing membranes that deliver consistent performance and quality. Advanced
membrane technology and manufacturing processes allow these membranes to deliver
consistent results.
• Dry rolled element - extended life • Superior quality and cost savings
• 95%+ PPM Rejection • Individually tested and sanitized
• DOW at sheet material
• Improved system performance
Minimum and Maximum Operating Conditions
Condition Minimum Maximum
• Inlet Pressure 40 psi (2.76 bar) 80 psi (5.52 bar)
• Inlet Temperature 40°F (4.44°C) 100°F (37.78°C)
• Inlet TDS 50 mg/L 2,000 mg/L
• Inlet Hardness 0 mg/L (0 grain) 171 mg/L (10 grain)
• Inlet Chlorine 0 mg/L 1.0 mg/L
• Inlet Iron 0 mg/L 0.1 mg/L
• Inlet Manganese 0 mg/L 0.05 mg/L
• Inlet pH 4 10
• Inlet Turbidity 0 1 NTU
• Proposition 65 compliant
• Meets NSF61 standards
• Industry leading performance
• Wishing Well member
COMPONENT SPECIFICATIONS
This combination of high performance carbon, unique binders, and proprietary manufacturing
processes delivers exceptionally low pressure drop, high dirt holding capacity, and excellent
contaminant reduction.
8

9
Connecting QC Fittings:
Push tubing rmly into the tting, all the way until the tube stops. The collet (gripper) has stainless
steel teeth which hold the tube rmly in position while the O-ring provides a leak proof seal. Pull
tubing to check for security. If some tube pulls out, then push it all the way in again until it stops. It
is good practice to test the system prior to leaving site and/or before use.
Disconnecting QC Fittings:
Ensure system is depressurized before removing ttings then push in the collet evenly against the
face of the tting. With the collet held in this position the tube can be removed by simply pulling.
You can use a collet release tool (HL 24010, available from your dealer). The tting can then be
re-used. If the tubing has been removed several times you may see score marks on the ends, and
this can lead to leaks. It is best to cut the end off of the tubing with a sharp blade, being careful to
cut straight across. Any angle to the cut can cause a leak.
Link To Instruction Video
https://bit.ly/2RJ0qLq
QUICK CONNECT FITTINGS (QC)
Please visit hydrologicsystems.com for tutorial videos on the Evolution-RO.
9

10
Do not bring unit back to the dealer, contact
HydroLogic directly for questions and warranty
issues.
A one year warranty against manufacturer’s defects comes with each unit.
This does not include clogged or damaged pre-lters or RO membranes due to
lack of regular maintenance or excessive sediment, chlorine, chloramines, iron,
silica, manganese, sulfur or PPM in the source water. This warranty also excludes
damage caused by using the unit outside of the specied operating parameters listed on page 8.
Do not operate unit if incoming pressure exceeds 80 psi or there is problem with water hammer or
pressure spikes.
Change both clear pre-lter housings every three years, available through your
local dealer or HydroLogic.
The manufacturer believes the information and data contained herein to be accurate and useful. The
information and data are offered in good faith, but without guarantee, as conditions and methods
of use of products are beyond the manufacturer’s control. The manufacturer assumes no liability
for results obtained or damages incurred through the application of the presented information and
data. It is the user's responsibility to determine the suitability of the products for the user's specic
end uses.
Tech Support Contact:
[email protected]
1-888-426-5644
Visit us on the web at: www.hydrologicsystems.com There are a variety of
videos under the resources tab
WARNING: USING NON-ORIGINAL REPLACEMENT
FILTERS OR MEMBRANES WILL VOID THE WARRANTY
WARRANTY AND SUPPORT
10

11
Q: Why is the system leaking?
A: This can be due to various reasons, including lack of Teon tape at threaded ttings, tubing
not being pushed in all the way to the quick connect ttings, or improperly seated O-rings in
pre-lter and membrane housings. It is also important to make sure the ends of the tubing have a
clean cut before inserting them into the quick connect ttings (see pg. 10) Please call us if you’re
experiencing any leaks.
Q: Why did the clear lter housing crack?
A: This can be due to freezing conditions, excessive pressure spikes, or long-term exposure to high
intensity lighting. Replacement housings are available and should be replaced every three years.
Q: Why is the pH of the puried water higher/lower than the source water?
A: The pH of the puried water depends entirely on source water chemistry. Customers can
experience either slightly lower or higher pH after ltration. This is completely normal for Reverse
Osmosis technology. Since RO water is almost pure H2O and has no ability to buffer pH, the
actual pH reading will not be accurate until you add minerals back.
Q: Why are both the 1:1 and 2:1 Flow Restrictors included in the box?
A: The Flow Restrictor(s) determines your waste to puried water ratio. HydroLogic has always
provided two options for the waste to puried water ratio, because water conditions vary across
the world; one xed ratio would not work for every water condition.
Q: My product ow rate is low. What could be happening?
A: It could be a few different things. First, check for leaks of line kinks. If feed pressure is still
low, you may need to install a pump. Or, shorter/wider tubing might be enough to decrease ow
restriction. Water temperature may also be too low. Be sure and check the lter; consider a lter
for sediment for non-chlorinated applications. Finally, it may be time to replace your membranes.
Q: Why does concentrate water continue to run to drain after shut off?
A: This could be caused by a clogged lter. Consider a sediment lter for non chlorinated
applications. It could also be a leak. Find and repair leak. Install pressure gauge in product line
to help identify a product pressure leak.
TROUBLESHOOTING
11

12
TDS Monitor
HL 28010
Measures PPM of dirty water going in
and pure water going out. Monitors
performance of your membranes.
Pressure Regulator
HL 26020
Required for water pressure over 80
psi. Fully adjustable from 0 -125 psi.
PreEvolution™
HL 31027
Recommended when using more
than 300 gallons per week on
average. The Pre-EvolutionTM adds 2
extra stages of pre-ltration. Extends
lter life to 7,500 gallon.
Pressure Booster Pump for
Continuous Duty
HL 29014
For higher ow rates or low inlet
pressure. Heavy duty booster pump
for continuous use.
Wall Mount Bracket
HL 10057
Stainless steel, heavy duty bracket to
mount your system on the wall.
Float Valve
HL 27020
Fill any tank or reservoir unattended. Can
be Installed in lid or sidewall of tank.
Never ood your garden again!
De-Ionization Add-On Kit
HL 33006
Delivers 000 PPM water. Removes
nal traces of Total Dissolved
Solids.
Drain Saddle
HL 10055
The optional drain saddle is an
alternative way to run your drain
line.
Leak Detector
HL 28002
Turns off inlet water to system
if leak is detected to prevent
damage.
OPTIONS
UV Sterilizer Kit
HL 35010
Kills 100% of all bacteria and viruses.
Ensures the safest water possible.
Flowmaster
HL 19020
Gallon meter and lter capacity monitor.
Indicates when to change your lters.
12

FILTER REPLACEMENT LOG
MEMBRANE CARBON PREFILTERDATE DATE

NOTES
