HydroLogic StealthRO 300 User manual

USER MANUAL

DESCRIPTION
The is a customized Reverse Osmosis water lter that is capable of reducing
up to 99% of most contaminants. This system is designed and built for use with hydroponic
or horticultural applications. This system is built to give the maximum amount of ow from the
membrane while sending less waste water to the drain, compared to similar RO lters. Please
read the following setup and maintenance guide to get the maximum results from your lter.
TABLE OF CONTENTS
Description, Table of Contents, Precautions...........................................................p 2-3
Filter Replacement Schedule/KDF85 Upgrade Replacement Schedule......................p 4-5
Stealth-RO 300 Includes........................................................................................p 6
Setup, QC Fittings, Filter Changes/Maintenance, Changing the RO Membrane, TFC
Membrane Rejection Chart...............................................................................p 7-14
Options .......................................................................................................p 15-16
Component Specs .........................................................................................p 17-18
Performance ......................................................................................................p 19
Warranty and Support........................................................................................p 20
Troubleshooting ............................................................................................p 21-22
2

• Do not install the unit where the source/inlet pressure may be more than 80 psi or there are
excessive water hammer/spike problems. If your inlet pressure is more than 80 psi, install
a 3/8” pressure regulator (HL 10071 see pg. 15), available at your dealer or through
HydroLogic.
• Keep out of direct sunlight or high intensity lights, which degrade the housing and ttings over
time. For added protection use the Algae Block Sleeve (HL 26009 see pg. 15) to protect
from sun or lights.
• When replacing lter cartridges, use the lter wrench to remove housings. Do not use the
wrench to tighten the housings. Hand-tighten the housings only. Take care not to over-tighten.
• Do not install where leakage or failure may cause damage to property.
• If you are going to store or not use your stealth-RO for an extended period of time (2
weeks+), remove your membranes, seal them in plastic and put in refrigerator.
• Protect unit against freezing to prevent cracking of the lter housings and water leakage.
•Replace both clear pre-lter housings every three years: HL 23165 from your local dealer
or from HydroLogic.
• Do not drop or place heavy objects on top of unit.
Description HydroLogic
Part #
Product Water
Flow Rate
Inlet Tubing
Size
Product Tubing
Size
Waste
Tubing
Size
STEALTH-R0300 HL 31040 300 GPD (Gallons Per Day)*
12.5 GPH (Gallons Per Hour) 3/8” 1/4” 1/4”
*see pg. 18 for operating limits
PRECAUTIONS
REVERSE OSMOSIS MEMBRANE DIAGRAM
3

Note: Check with your municipality to see if your city uses chlorine, chloramines or a combination
of both. This will determine if the standard Green Coconut Carbon lter is adequate or if you
should upgrade to the optional KDF85/Catalytic Carbon upgraded lter. The Green Coconut
Carbon lter or optional KDF85/Catalytic Carbon upgraded lter is responsible for removing
chlorine and/or chloramines. If you don’t change these according to the schedule below, chlorine
and/or chloramines will break through to the membrane and deteriorate them quickly.
BE SURE TO CHANGE YOUR PRE-FILTERS BASED ON THE FILTER
REPLACEMENT SCHEDULE!
The Flowmaster lter capacity monitor is a great way to keep track of your ller changes.
(HL 19014 See pg. 15)
HL 22121 HL 22110 HL 22125 HL 22060
Filter HydroLogic Part # Replacement
Schedule
Membrane Element - 150 GPD HL 22121 6 months - 2 years
Green Coconut Carbon lter HL 22110 1,250 gallons of
puried water
Sediment lter - Pleated HL 22125
clean regularly,
change every 6 -12 months
KDF85/Catalytic Carbon
upgraded lter HL 22060
2,000 gallons of
puried water
FILTER REPLACEMENT SCHEDULE
4

KDF85 is the most advanced media available to lter and pre-treat your water when using Reverse
Osmosis, and can extend the life of your membrane when changed regularly. This special lter
is made using a blend of KDF85 and medical grade Catalytic Granular Activated Carbon. This
premium grade of carbon reduces chloramines and chlorine to the lowest industry standard levels
available. The media of the KDF85 lter is superior to ordinary grades of activated carbon for
chloramine removal and is acid washed, pH buffered, and rinsed with sanitized water. This unique
process helps to ensure a neutral pH and minimize the possibility of metal contaminants appearing
after ltration.
This specialized lter is designed to double the life of your standard carbon lter (see diagram
below). KDF85 is great for people on city water with its ability to remove the majority of all chlorine
and chloramines. KDF85 is also ideal for people on well or spring water sources and can reduce
many more contaminants such as: iron, sulfur, and heavy metals than the standard Green Coconut
Carbon lter and help your garden thrive. Water containing contaminants such as iron and sulfur
can foul Reverse Osmosis membranes quickly and lead to poor water quality, leading to decreased
yields and nutrient lock-out.
Filter HydroLogic Part # Replacement
Schedule
KDF85/Catalytic Carbon
upgraded lter HL 22060 2,000 gallons of puried water
KDF85/UPGRADED FILTER REPLACEMENT SCHEDULE
KDF85/Catalytic Carbon Reduces:
• Chlorine
• Chloramines
• Iron
• Hydrogen sulde
• Heavy metals
5

1. Stage 1 - Pleated, Cleanable Sediment pre-lter
Reduces dirt, sediment, silt, rust, etc.
2. Stage 2 - Green Coconut Carbon or KDF85/Catalytic Carbon upgraded
pre-lter
Reduces chlorine and other toxins
3. Stage 3 - 150 GPD Reverse Osmosis Membranes (2)
Reduces PPMs of Total Dissolved Solids
4.
Inlet Pressure Gauge with safe zones
Shows dynamic line pressure and optimal operating zones
5.
5 ft white 3/8” inlet tubing, 8 ft black 1/4” waste water tubing,
8ft blue 1/4” puried water tubing
Food grade LLDPE (linear low density polyethylene) tubing
6.
Inline Shut-Off Valve with 1/4” Quick Connect
Turns system on/off
7.
Double-Ended Filter Housing Wrench
Large end for pre-lter housing, small end for membrane housing cap
8. Flow Restrictor/Flush Kit Assembly with 1:1 and Flow Restrictors
Determines waste to puried water ratio
9. 3/8” QC X Garden Hose Connector
3
8
9
65
7
21
4
STEALTH-RO300 INCLUDES
6

A: The system comes with and 1:1 purple Flow Restrictors which determine the
waste water to puried water ratios. The Flow Restrictor will give you the
best trade-off between membrane life and waste water. If you have relatively low Parts Per Million
(PPM) source water or desire less waste water you can choose to use the included 1:1 (purple
tubing) Flow Restrictor.
Warning: The 1:1 purple Flow Restrictor reduces waste water and can lead to reduction in
the membrane life. The higher the source water’s PPM, the shorter your membrane life will be.
USE AT YOUR OWN RISK if the source water is above 300 PPM.
B. Once you have chosen the Flow Restrictor install it into the Flow Restrictor/Flush Kit Assembly
(push both ends of the Flow Restrictor all the way into the open quick connect ttings). Note: The
Flow Restrictor tubing can be installed in either direction.
A
B
STEALTH-RO300 SETUP: FLOW RESTRICTOR/FLUSH KIT ASSEMBLY
7

C: Next take the Flow Restrictor/Flush Kit Assembly and install it on the system by pushing the short
piece of pre-installed black tubing on the Flow Restrictor/Flush Kit Assembly into the open black
quick connect tting on the ASOV.
Note: When starting up the system for the rst time, make sure that the blue valve an the Flow
Restrictor/Flush Kit Assembly is in the open position (parallel with tubing). In order to ush the carbon
pre-lter properly, run for 2 - 3 minutes and discard all water. It is recommended to power ush the
system once a week for 5 minutes. This will help remove scale build up on the membrane.
D:Once the initial ush is complete turn the blue valve on the Flow Restrictor/Flush Kit Assembly
to the closed position (perpendicular to the tubing). The blue valve should be in the closed
position for normal operation.
D
STEALTH-RO300 SETUP: FLOW RESTRICTOR/FLUSH KIT ASSEMBLY, CONT.
ASOV
C
8

1.
1. Source/lnlet Line (White)
2. 2. Puried Water Line (Blue)
3. 3. Waste Water Line (Black)
4. 4. ASOV (Automatic Shut off Valve)
5. 5. Blue Valve
Main Unit Setup:
There are 3 long lengths of tubing included with the system. Push the 3/8” white inlet tubing into
the 3/8” QC pressure gauge tting. Connect the 1/4” blue puried water tubing to the blue outlet
of the ASOV. Connect the 1/4” black waste water tubing to the outlet of the Flow Restrictor/Flush
Kit Assembly. You are now ready to connect the included garden hose adapter to your source
water and the other end of the 3/8’ white inlet tubing. There are a variety of feed valve options
available to connect to any existing plumbing. Inquire at your dealer, or through HydroLogic.
5
4
2
3
1
STEALTH-RO300 SETUP
9

Be sure the Flow Restrictor/Flush Kit Assembly’s blue valve is open (handle is parallel with tubing,
see gure E). Next, slowly turn the source water on until both the Carbon and Sediment lters have
water in the housings. Once both pre-lter housings are full, open source water up all the way (do
not exceed 80 psi). Power ush the system for 2-3 minutes when the system is new and/or when you
replace your carbon lter. Next, close the blue valve and continue to ush the membranes for 30-45
minutes. This will ush out the food grade preservative in the membranes.
After the initial 30-45 minute ush, turn the inline shut-off valve (pre-installed on the blue puried
water line) to the off position (perpendicular to the tubing). This will shut the water off on both the blue
and black lines, and pressurize the system. This is a good way to make sure that all the ttings and
connections are secured properly and that there are no leaks. It is also a good way to make sure that
the ASOV is working properly, meaning the black drain line is also shutting off shortly after the blue
line shuts off. If there are problems of any kind please contact HydroLogic directly at 888-426-5644
Note: It may take up to 24 hours of running the system for the PPM & pH of the
puried water to stabilize.
WARNING: USING NON-ORIGINAL
REPLACEMENT FILTERS OR MEMBRANES
WILL VOID THE WARRANTY
STEALTH-RO300 SETUP, CONT.
EASOV
10

Connecting QC Fittings:
Push tubing rmly into the tting, all the way until the tube stops. The collet (gripper) has stainless steel teeth
which hold the tube rmly in position while the O-ring provides a leak proof seal. Pull tubing to check for
security. If some tube pulls out, then push it all the way in again until it stops. It is good practice to test the
system prior to leaving site and/or before use.
Disconnecting QC Fittings:
Ensure system is depressurized before removing ttings then push in the collet evenly against the face of
the tting. With the collet held in this position the tube can be removed by simply pulling. You can use a
collet release tool (HL 24010, available from your dealer). The tting can then be re-used. If the tubing
has been removed several times you may see score marks on the ends, and this can lead to leaks. It is
best to cut the end off of the tubing with a sharp blade, being careful to cut straight across. Any angle to
the cut can cause a leak.
Link To Instruction Video
https://goo.gl/L8b5Rii
QUICK CONNECT FITTINGS (QC)
goo.gl/sq8GaA
Please visit www.hydrologicsystems.com for tutorial videos on the stealth-RO.
11

It is essential that you change your pre-lters regularly. The Green Coconut Carbon lter has
a rated life of approximately 1,250 gallons*of puried water produced. The Sediment lter
can be cleaned at your faucet or with a garden hose as often as you like. You should change
the Sediment lter at least once a year or sooner if you have extremely dirty water.
*2000 gallon lter life with KDF85/Catalytic Carbon upgraded lter
Dirt can become embedded in your pre-lters and cause slower ow rates. To rinse the pre-
lters, use the included lter wrench to loosen the clear pre-lter housings. Be careful not to
over-tighten when reinstalling. It is preferable to hand-tighten lter housings.
The Reverse Osmosis membranes have a useful lifespan of 6 months to 2 years depending
on how high your source water PPM is, if there are high levels of certain contaminants (such
as iron & silica), how much water you produce and regular pre-lter maintenance. If your
water is highly contaminated, then you may need to change the membranes more often. If
your water is relatively clean and you keep up with your pre-lter changes, they may last 2
years+.
There are two indications as to when to change your membranes:
1. PPM rejection %: Test the RO product and source/inlet water to see what % of the inlet
water’s PPM the stealth-RO is ltering out (rejection %). You should see approximately
98% of the inlet PPM being removed when the membrane is new. If the rejection % falls
under an acceptable level (typically 90%), it's time to change the membranes.
2. The ow rate of the product water slows down signicantly. This can also happen if your
pre-lters are clogged. If you change your pre-lters and the product water still ows
slowly, this is an indication you need a new membranes. When in doubt, contact
HydroLogic.
STEP 1:
1. Remove the white 1/4” tubing
from the membrane housing.
2. Next, pull that same end of the
membrane housing straight up
to release it from the clip.
2
FILTER CHANGES / MAINTENANCE
CHANGING THE RO MEMBRANES
1
12

STEP 3:
You can now remove the membranes with either a strong set of needle nose pliers or
something similar. Hold onto the membrane housing body and pull straight out until it
releases the membrane. It may seem tight, but with even pressure it will come out.
STEP 2:
Firmly grip the membrane housing
and twist the membrane cap counter
clockwise using the provided lter
wrench.
CHANGING THE RO MEMBRANES, CONT.
13

STEP 5:
Repeat steps 1-4 for second
membrane.
STEP 6:
Run the system for 30-45 minutes,
discarding all puried and waste
water before using.
STEP 4:
Push the new membrane back into the housing with the end that has the two black O-rings going
in rst. Push rmly until it bottoms out and can’t go in further. Then thread the cap back on tightly
and reconnect the white 1/4” tubing. Be sure the O-ring in the cap is in place.
CHANGING THE RO MEMBRANES, CONT.
TFC Membrane
Rejection Chart
The TFC membrane rejection chart
can be very helpful as a general
guideline, but is not a guarantee.
Every water source has a different
chemistry, temperature and TDS, and
it is best to test your water thoroughly
to determine your unique water
prole.
A good place to start is EWG.org,
just type in your zip-code to determine
what contaminants (if any) you may
be dealing with.
14

Booster Pump with High
Pressure Switch
HL 29020
Boosts pressure to 65+ psi for
increased ow rate of puried
water. For low pressure situations
(below 40 psi) or those wanting
higher ow rates.
Float Valve
HL 27015
Fill any tank or reservoir
unattended. Can be Installed in
lid or sidewall of tank. Never
ood your garden again!
KDF85/Catalytic Carbon
Upgraded Filter
HL 22060
Reduces chloramines, chlorine,
iron, sulfur and heavy metals,
Great for well or city water
sources.
Algae Block Sleeve
HL 26009
Neoprene sleeve that covers all
standard clear housings. Blocks
light so no algae can grow. Easily
removed to check status of lters.
Pressure Regulator
HL 10071
For high inlet pressure. Limits
pressure to below 85 psi. Simply
connects onto the source/inlet line.
Flowmaster for
HL 19015
Gallonage & lter capacity monitor.
Alerts you when It’s time to change
your lters and measures total
number of gallons of puried water
produced.
TDS Monitor
HL 19006
Measures source/inlet water’s PPM
going into the RO system and puried
water’s PPM coming out. Monitors
the performance of your RO system.
Instantly displays values and allows
you to switch back and forth between
dirty and clean water TDS readings.
OPTIONS
15

Tubing
see website
Extra tubing is available to customize your
setup. Visit www.hydrologicsystems.com
Leak Detector & Shut Off Valve 3/8”
HL 19023
Installs on source/inlet line. If there is a leak
anywhere in the system and water reaches
the pad on the bottom of the leak protector
the valve shuts off all incoming water,
preventing further damage from the leak.
Drinking Water Upgrade Kit
HL 26016
The Stealth-RO drinking water add-on kit is for
the horticulture enthusiast who also wants to
use their system for home drinking water.
De-lonization Kit
HL 33005
DI post lters are a necessity for reducing
TDS to absolute zero. The color-changing DI
resin will remove any leftover contaminants
giving you the purest H2O possible.
Fittings
see website
Various ttings are available to customize your
setup. Visit www.hydrologicsystems.com
UV Sterilizer Kit
HL 35015
Kills 100% of all bacteria and viruses.
Ensures the safest water.
OPTIONS, CONT.
16

Sediment Filter - Pleated, Cleanable HL 22125
• 5 micron nominal ltration
•SURFACE AREA: Approximately 4 sq. ft. (0.37 m2)
• TEMPERATURE LIMIT: Up to 140°F (60°C) depending on pressure and time under load
• FILTER MEDIA: Polyester - PlusTM
• END CAPS: Plastisol (pliable PVC)
Green Coconut Carbon Filter - (Earth Friendly) HL 22110
HydroLogic is proud to introduce the rst Carbon Block to use NSF61 listed Greencarbon. This
high performance coconut shell carbon is manufactured using a patented process that signicantly
reduces harmful greenhouse gas emissions.
These carbon blocks are made using coconut shell Greencarbon, which has more micropores than
other types of carbon and a unique binder system, delivering a product with superior absorption
capacity and kinetic dynamics.
This combination of high performance carbon, unique binders, and proprietary manufacturing
processes delivers exceptionally low pressure drop, high dirt holding capacity, and excellent
contaminant reduction.
Features and Benets
• 10 micron nominal ltration
• No release of carbon nes
•Exceptionally low pressure drop
•Meets NSF61 standards
RO Membrane: HL 22121
stealth-RO HydroLogic Membranes are recognized as one of the industry’s most reliable and
highest performing membrane elements that deliver consistent performance and quality. Advanced
membrane technology and manufacturing processes allow these elements to deliver consistent
results.
• DOW at sheet material • Superior quality and cost savings
•96% - 99% PPM Rejection • Individually tested and sanitized
•Improved system performance • Made in the U.S.A.
•Hand rolled
• Performance validated by WQA
• NSF certied for material safety
• Industry leading performance
COMPONENT SPECIFICATIONS
17

Membrane Operating Limits: Very Important
• MEMBRANE TYPE: Thin Film Composite
• MAXIMUM OPERATING TEMPERATURE: 113 °F (45 °C)
• MAXIMUM OPERATING PRESSURE: 100 psi
• MAXIMUM FEED FLOW RATE: 2 GPM
• MAXIMUM TDS: <1000 PPM
•MAXIMUM HARDNESS: <10 Grains Per Gallon (170 PPM)
•PH RANGE, CONTINUOUS
•OPERATION: 2 - 11
• MAXIMUM FEED WATER TURBIDITY: 1 NTU
• MAXIMUM FEED SILT DENSITY INDEX (SDI): 5 SDI
• CHLORINE TOLERANCE: 0 PPM
•CHLORAMINE TOLERANCE: 0 PPM
•MANGANESE TOLERANCE: 0 PPM
•IRON TOLERANCE: <1 PPM
•SILICA TOLERANCE: <10 PPM
NOTE: Operating your membranes outside of the parameters voids the warranty. Use only with
microbiologically safe water. Do not use with water of any unknown origin or water quality.
When in doubt contact HydroLogic to order a water analysis kit.
COMPONENT SPECIFICATIONS, CONT.
KDF FILTER
KDF85/Catalytic Carbon upgraded lter HL 22060
HydroLogic only uses the highest grade materials to make our
KDF85/Catalytic Carbon upgraded lter for reducing chloramines.
• KDF: 0.5 lb copper/zinc media
•5 micron nominal ltration
•Meets NSF61 standards
•Reduces a wide range of contaminants, including heavy metals, chlorine, chloramines, sulfur and iron
•Carbon has enhanced catalytic capability
•KDF neutralizes chlorine
•NSF Certied for material safety
• Bacteriostatic qualities do not allow microbes to breed in lter
18

Important Information & Performance Parameters
Reverse Osmosis is the most efcient and cost-effective way to remove the majority of all
contaminants from your water. The key component of the system are the RO membranes composed
of tightly wrapped sheets of a semi-permeable material. Under pressure, the membrane allows
pure water to pass through it and rejects, or ushes away, most impurities down the drain.
That is why all RO systems have a certain amount of waste water. The ratio of waste water is
determined by the Flow Restrictor installed in the Flow Restrictor/Flush Kit Assembly. The system
comes with a choice of 1:1 and Flow Restrictors. Refer to pg. 7.
The ow of puried water is determined by the GPD rating of the membrane, inlet pressure
and inlet temperature. The stealth-RO300 has the capacity to produce 300 gallons per day
(approx. 12.5 gallons/hour when your inlet water is at 77°F, 60 psi, 500 PPM). If your inlet
pressure is less than 60 psi, you may experience less than the rated 300 GPD ow rate. A
minimum of 40 psi is required to operate the system. The higher the inlet pressure, the better the
ow. A booster pump is available as an option in case of low pressure and is necessary if your
pressure is below 40 psi (HL 29020 see pg. 15) .
You will notice that in colder areas or in the winter, when water temperatures
are lower, the ow rate will be slower.
Inlet water that is very high in total PPM or very hard with calcium or magnesium, or high
in certain contaminants such as iron or silica, may shorten the life of the membranes and/
or cause slower ow rates. The RO membranes can handle inlet water up to 1,000 PPM and
with a hardness up 10 grains per gallon (170 PPM). Note that this is considered both very
contaminated and very hard water and may result in a shorter membrane lifespan. At these
levels of contamination and hardness, and especially beyond, you may consider pre-treatment
in the form of a water softener or other equipment. Softened water can be run through your
stealth-RO system for optimal performance. The membranes in the stealth-RO is capable of
removing 99% of salts that are introduced by the softener. Contact HydroLogic for more info at
888-426-5644.
All RO systems exhibit “TDS creep”. The rst few ounces of RO water produced
are higher in PPM than after the system has run for a few minutes. Take any
PPM readings a full ve minutes after turning the system on to ensure accuracy.
PERFORMANCE
19

A one year warranty against manufacturer’s defects comes with each unit.
This does not include clogged or damaged pre-lters or RO membranes due to
lack of regular maintenance or excessive sediment, chlorine, chloramines, iron,
silica, manganese, sulfur or PPM in the source water. This warranty also excludes
damage caused by using the unit outside of the specied operating parameters listed on page 18.
Do not operate unit if incoming pressure exceeds 80 psi or there is problem with water hammer
or pressure spikes.
Change both clear pre-lter housings every three years, available through your
local dealer or HydroLogic. HL 23165
Do not bring unit back to the dealer without contacting HydroLogic rst.
Contact HydroLogic directly for questions and warranty issues
The manufacturer believes the information and data contained herein to be accurate and useful.
The information and data are offered in good faith, but without guarantee, as conditions and
methods of use of products are beyond the manufacturer’s control. The manufacturer assumes
no liability for results obtained or damages incurred through the application of the presented
information and data. It is the user's responsibility to determine the suitability of the products for
the user's specic end uses.
Tech Support Contact:
[email protected]
1-888-426-5644
Visit us on the web at: www.hydrologicsystems.com There are a variety of
videos under the resources tab
WARNING: USING NON-ORIGINAL
REPLACEMENT FILTERS OR MEMBRANES
WILL VOID THE WARRANTY
WARRANTY AND SUPPORT
20
