Hydromatic S4NVX Manual

HAZARDOUS LOCATION
SUBMERSIBLE PUMP
Model S4NVX (Class I, Division 1, Group C & D): FM
12/10
Item # E-03-333
Part # 5625-333-1
© 2010 Pe tair Pump Group, I c.
Installation and Service Manual
NOTE! To the i staller: Please make sure
you provide this ma ual to the ow er of
the equip me t or to the respo sible party
who mai tai s the system.
For use wit product
built wit Regal Beloit/
Marat on motor.

2
Thank you for purchasing your
Hydromatic®pump. To help
ensure years of trouble-free
op er a tion, please read the
fol low ing manual carefully.
 !), * ,.$)(
Read the following in struc tions
care ful ly. Reasonable care and
safe meth ods should be practiced.
Check local codes and
requirements before installation.
.. (.$)(
This manual contains important
information for the safe use of
this product. Read this manual
completely before using this
product and refer to it often for
con tin ued safe product use.
DO OT THROW AWAY OR
LOSE THIS MA U AL. Keep it
in a safe place so that you may
refer to it often.
(*%$("/'*
Remove pump from carton. When
un pack ing unit, check for
con cealed damage. Claims for
damage must be made at the
receiving end through the delivery
carrier. Dam age cannot be
processed from the factory.
Remove plywood base from
bottom of pump, saving shipping
bolts. Re in stall shipping bolts
(without washers) in legs of pump.
This must be done to ensure
proper alignment of pump and
discharge piping.
  !),  #(&$("
.# -  */'*- ( )(.,)&-
&13- $-)(( . .#  *)1 ,
!$,-. ) (). -')%  ), /-
-*,%&  & .,$&  0$ - ),
!&' - $(  - *.$ "- )/- ),
*)--$& - *.$-/'*
   &&
$, .$)(-  !),  , *&$("
(3*,.-
/'*
The hazardous location
submersible pump family was
designed in ac cor dance with
requirements for haz ard ous
locations. These pumps,
connected prop er ly, will provide
years of trouble-free service. If
ser vic ing is required, the repair
should be done by a Hydromatic
approved ser vice center.
/'*-$(.)," 
),).* ,.$("
Pumps with carbon ceramic seals
must have impellers manually
rotated (6 revolutions) after
setting non-operational for 3
months or longer and prior to
electrical start-up.
Pumps with tungsten carbide seals
must have impellers manually
rotated (6 revolutions) after
setting non-operational for 3
weeks or longer and prior to
electrical start-up.
 &$&/, ,) -
All hazardous location
submersible pumps have two
factory installed mois ture
detectors (seal failure probes).
They are in a normally open series
cir cuit, in the seal chamber. Un der
normal operating conditions, the
circuit remains open. If the lower
seal leaks and moisture enters this
cham ber, the moisture would
settle to the bottom of the
chamber and will com plete the
circuit between the mois ture
detectors.
General
Information
This circuit must be connected to
a sensing unit and signaling
device. This is supplied in a
Hydromatic built control panel.
$&/, .)$(-.&&-/#
 0$ ( ". -&&1,,(.$ -3
3,)'.$ */'*-
 . (-),-
All motors in this family have
heat sensors on or embedded in
the motor winding to detect
ex ces sive heat. This prevents
damage to the motor. If sen sor
trips due to excessive winding
tem per a ture, starter in panel
breaks power to the pump.
Once sensor re sets, the starter is
automatically reset for FM for
continued operation of the pump.
This circuitry is supplied in a
Hydromatic control panel.
The sensors are set to trip at
120°C (248°F).
 $&/,  .) $(-.&& -/#
$,/$.,3 1)/& ( ".  
**,)0&-(&&1,,(.$ -3
3,)'.$ */'*-
)1 ,),-
The power cord and heat sensor
seal failure cord are potted into
the con nec tion box cap. The cords
must not be spliced.
# &  #-  ", (
&  #$- $- .#  ",)/( 1$,
('/-. ",)/( *,)* ,&3
* ,  (), &)& ) -
),- -#)/&   $(-* . 
!), (),'& 1 , (
, *& ),$("&3

con sult ing engineer de pend ing on
the con di tions of the application.
For installation of Hydromatic
supplied level con trols, refer
to your sys tem’s installation and
service manual.
(-.&&$("/'*$(/'*
Before installing pump in sump,
lay it on side and rotate impeller.
Impeller may be slightly stuck
due to factory test water so it must
be broken loose with small bar or
screwdriver in edge of vanes. The
impeller should turn freely. Do
not connect the power until after
this test.
Clean all trash and sticks from
sump and connect pump to piping.
A check valve must be installed
on each pump. A gate or plug
valve in each pump discharge is
highly rec om mend ed. This valve
should be installed on the
discharge side of the check valve
so if necessary to service the
check valve, the line pressure can
be cut off. Sin gle pump systems
are sometimes installed without a
check valve where it is de sir able
to self-drain the dis charge line to
prevent freezing. This can be done
only with short discharge lines;
oth er wise water will return to the
sump and cause short cycling of
the pump.
%$("& .,$&)(( .$)(-
All electrical wiring must be in
ac cor dance with local code, and
only qual i fied electricians should
make the in stal la tions. Complete
wiring di a grams are included
for use in making the installation.
All wires should be checked
for shorts to ground with an
ohmmeter or Megger after the
con nec tions are made. This is
important, as one grounded wire
can cause con sid er able trouble.
 ! +/$*' (.
$- (). *,)* ,&3 1$,  (
*,). .  - , )'' ( 
3,)'.$ 1,,(.3 $- 0)$
 " 
 . (-),( &
$&/, )(( .$)(-
If a Hydromatic control panel
is used, terminal blocks are
provided for heat sensor, seal
failure connections (See Panel
Schematic). If a control panel
is supplied by others, it must
allow heat sensor and seal failure
ter mi na tions.
.,.$("3-. '
1. Double check all wire
con nec tions.
2. Turn pumps to Off position
on H-O-A switch es.
3. Turn on breakers.
4A. When using single phase
pumps, make sure red
pump lead is con nect ed to
capacitor circuit, con nect
amprobe to pump power cord
and turn pump on. Pump
will show high amp draw
mo men tari ly, then as pump
comes off start wirings,
amps will drop to normal
nameplate amps.
4B. When using three phase
pumps (230/460/575), turn
H-O-A switch to Hand po si tion
on one pump and notice
op er a tion. If pump is noisy
and vi brates, rotation is
wrong. To change rotation,
interchange any two line
Pump
Operations
0 ,&) . ,-
If the Hydromatic electrical panel
is not used, start ers with 3 leg
overload relay must be
supplied on 3 phase pumps. Each
leg is to have an iden ti cal heater
sized in accordance with the
nameplate amps on the motor
hous ing. The amp draw on these
sub mers ible motors is slightly
higher than a cor re spond ing
horsepower sur face motor so
heat ers must be sized by the
nameplate rating.
Single phase pumps with
capacitor start have a run and a
start winding each drawing a
different current. To adequately
protect these windings with the
appropriate heaters, consult
the factory.
   &  $- &13-
-.,. 1$($(" )! */'* /-$("
-$("& *#- 
(-.&&$(" /'*  0 & )(.,)&
&).)(.,)&-
In either simplex, duplex or
triplex systems the lower or
turn-off control is to be set to
maintain a minimum level in the
sump. This level shall be no more
than 31⁄4" from the top of the
motor housing down to the
surface of the sewage.
The second or turn-on control
is set above the lower turn-off
control. The exact distance
between the two floats must be a
compromise between a fre quent
pumping cycle (10 starts per hour
max.) to control septicity, solids
and a slower cycle for energy
econ o my. This distance should be
de ter mined by the engineer or
Installation
Instructions
3

4
WHITE
BLACK
PINK
L1
L3
A B
120 VAC
FUSE
M
TYPICAL THREE PHASE
MOTOR CONNECTIONS
O/L
O/L
L2
O/L
FUSES
GREEN
RED
WHITE
BLACK PUMP MOTOR
FE
RED
330K
DC
GREEN
HEAT SENSORS
120 VAC, 5A
SEAL PROBES
300 VAC, 20 MA
POWER
CORD CONTROL
CORD
SEE TYPICAL CONTROL
CIRCUITRY BELOW
WHITE
BLACK
PINK
L1
A B
120 VAC
M
TYPICAL FM ONLY SCHEMATICS
TYPICAL SINGLE PHASE
MOTOR CONNECTIONS
O/L
O/L
L2
FUSES
GREEN
RED
BLACK
WHITE PUMP MOTOR
FE
RED
330K
DC
GREEN
HEAT SENSORS
120 VAC, 5A
SEAL PROBES
300 VAC, 20 MA
POWER
CORD CONTROL
CORD
SEE TYPICAL CONTROL
CIRCUITRY BELOW
CRS
RUN
CAPACITOR
CRS
START
CAPACITOR
CAPACITOR
PACK PANEL
M
RUN
LIGHT
SEAL
FAILURE
INDICATOR
DC
TO SEAL PROBES
IN PUMP MOTOR
SEAL
FAILURE
RELAY
LEVEL
CONTROL
CIRCUITRY
H
O
A
H
A
R
OVERLOADS
CAPACITORS AND/OR CONTROLS SHOULD BE LOCATED OUTSIDE
HAZARDOUS AREA AND ENCLOSED IN AN APPROPRIATE ENCLOSURE.
NOTE:
TYPICAL
CONTROL
CIRCUITRY
SEE TYPICAL
CONTROL CIRCUITRY
BELOW

5
leads to pump. Do not
in ter change main incoming
lines. Check rotation of all
pumps in this same manner.
5. ow set both H-O-A switches
to Auto po si tion and allow
water to rise in sump until one
pump starts. Allow pump to
operate until level drops to
turn-off point.
6. Allow sump level to rise to
start other pump(s). otice
run lights to panel. Pumps
should alternate on each
successive cycle of op er a tion.
7. Turn both H-O-A switches to
Off position and allow sump
to fill to the override control
level(s).
8. Turn switches to Auto
position, and pumps should
start and op er ate together
until level drops to turn-off
point.
9. Repeat this operation cycle
sev er al times before leaving
the job.
10. Check voltage when pumps
are operating, and check the
amp draw of each pump.
Check amps on each wire
as sometimes a high leg
will exist. One leg can be
some what higher by 5 to
10 per cent without causing
trouble. For excessive amp
draw on one leg, the electric
utility company should be
consulted.
As the motors are oil filled, no
lubrication or other main te nance
is re quired.
If the heat sensor and seal failure
are hooked up properly, no
attention is necessary as long as
the seal failure indicator light
doesn’t come on. To ensure
continuity of the seal sensor leads,
a test light is provided on
in trin si cal ly safe Hydromatic
panels as standard equipment.
Pump should be checked every
quar ter for cor ro sion and wear.
 ,0$$("(-.,/.$)(-
   &&
$, .$)(-  !),  , *&$("
(3*,.-
Pump
Maintenance
  !),  #(&$("
.# -  */'*- ( )(.,)&-
&13- $-)(( . .#  *)1 ,
!$,-.
)(). -')%  ),/- -*,%&
& .,$& 0$ -),!&' -$(
- *.$ "- )/- ), *)--$& 
- *.$-/'*
$ & ,0$ )(3,)'.$
4,)/-).$)(/'*-
If a Hydromatic hazardous
location pump is used in a
hazardous location, or if the pump
is still in war ran ty, the pump must
be returned to the factory for
service or repaired in an
authorized Hydromatic service
center. Charges will not be
allowed if (in war ran ty) pump is
taken to a motor repair shop that is
not an authorized Hydromatic
service cen ter. This will ensure
the integrity of the hazardous
location rating of the pump and
Pump
Operations

6
Pump
Maintenance
com ply with our warranty
re quire ments. Pumps out of
warranty and not used in a
hazardous location can be field
serviced by any reputable
serviceman. When any field
servicing is per formed on a pump,
the fol low ing in struc tions should
be followed care ful ly.
$-)(( .$("/'*),-
If a Hydromatic hazardous
location pump is to be removed
from its lo ca tion, one of two ways
may be used to disconnect the
pump cords from the rest of the
system.
Pump cords may be disconnected
at control panel (on sump
mounted con trol panels) and cord
as sem bly taken with pump.
 ! ), )* ($("-
!,)'-/'*.))(.,)&*( &,
)* ( "- - !,)' -/'* )/&
(. , *( & ( ( 2*&)-$0
)($.$)()/& 2$-.
The pump cords may be
disconnected at the pump by
removing the cord and cap
assembly, unplugging sensor
wires, and re mov ing wire nuts.
After removal from pump,
reinstall wire nuts in cord and
cap assembly and install the
protective cover. (Hydromatic Kit
11159-000-1)
 ) (). , )(( .
*)1 , .)  ), ( *
-- '&3 1#$&  , ')0$("
!,)'*/'*
 *&$("),-
The power cord and heat
sensor - seal failure cord is
potted into the con nec tion box
cap, forming the cord and
cap assembly.
If cords require replacement due
to damage or cords being too
short, cord and cap assembly
must be replaced as a complete
assembly avail able from factory.
1. Remove cord and cap assembly
from con nec tion box.
2. Disconnect wires taking note
of color/num ber coding.
3. Connect wires of new cord and
cap as sem bly in the same
manner as the old one was
removed.
4. Check for moisture and
dryout.
5. Reinstall cord and cap
assembly on con nec tion box,
taking care not to pinch wires.
6. Check pump for proper
rotation before re turn ing to
normal service.
 *&$("..),
If motor winding is burned or
shorted, it can be rewound or
replaced with new factory wound
sta tor. Refer to sectional drawing
of pump and motor, and use the
following steps to remove and
replace stator.
1. If only the stator is damaged,
it may not be necessary to
com plete ly dismantle pump
as stator and housing can be
lifted from pump without
dis turb ing seals or bearings.
2. Drain all oil from upper
housing. Remove drain plug
in bottom of bearing housing,
and re move con nec tion box
to allow air to enter.

7
3. When connection box is
lifted off, con nec tion wires to
motor will be exposed. These
wires are tagged with a metal
marker giving wire num ber.
Disconnect wires and remove
connection box.
4. After chamber is drained,
remove hold-down bolts on
motor housing and lift off.
Use care in lifting as the seal
failure connecting wire must be
disconnected before hous ing
is completely re moved. See
sectional drawing.
5. The stator is held in the
housing with a bolted-in
retaining ring and pre vent ed
from rotating by a roll pin.
6. Remove the retaining ring
and socket head cap screw.
7. After ring is removed, turn
hous ing upright and bump on
hard wood block. This should
jar the stator loose and allow
it to drop out.
8. Thoroughly clean housing
before replacing new stator.
Replace sta tor and make
all wire con nec tions to
the con nec tion box before
re plac ing housing on pump.
See motor lead connection
drawing. This is important as
leads must be tucked behind
the windings by using hands
up through rotor core.
 -  )(&3 /..
)(( .$)(-)(.# 1$, -
) (). .*  & - - )$& 1$&&
 . ,$),.  .#  .*  ( /-
'" .)-..),( ,$("-
9. Check top bearing. If the
bearing is clean and does not
turn rough, bearings can be
reused. If bear ings are
damaged with dirt or heat,
they must be replaced. See
ad di tion al instructions on
re plac ing seals and bearings.
10. Replace stator housing onto
seal chamber and bolt
in place. Be sure seal failure
wires are con nect ed before
the housing is assembled.
See Fig. 1.
Be sure O-ring seal has been
re placed. If O-ring is nicked
or cut, replace with new ring.
This ap plies to all O-rings
used in as sem bly.
11. After all leads are reconnected
in the con nec tion box, make a
high voltage ground test on
each wire. The only wire that
should show ground is the
green power lead and the
ground head in the aux il ia ry
control cable.
12. For safety, complete pump
should be air checked under
water for leaks.
If seals were okay, refill seal
cham ber with oil. Lay pump
on side for this oil filling
with oil fill hole upright. Do
not completely fill; leave
oil about 1" below plug
hole. Use only Hydromatic
submers ible oil or high grade
trans form er oil in this
chamber. Re place plug; use
Permatex on threads. Install
air valve in plug opening of
motor housing and charge
housing with about 10 psi of
air. Be sure air is dry. Do not
use air line where water may
be trapped in the line.
Submerge com plete unit
under water and check
for leaks.
Pump
Maintenance

8
13. Refill motor chamber with
oil through con nec tion box
opening. Use high grade,
non-syn thet ic trans form er
oil or Hydromatic spe cial
sub mers ible oil. Fill hous ing
until oil covers top of
wind ings. Leave air space in
top for expansion.
 $& '/-. )0 , .)*
)!-..),
 *&$(" &-( ,$("-
1. Drain all oil from motor
chamber and seal chamber as
described.
2. Remove motor housing as
de scribed in re plac ing stator.
3. Remove bolts that hold
bearing housing to volute.
Lift bearing housing and
rotating unit off and set
assembly on its side. Remove
socket head screw and
washer at the impeller end of
the shaft. Hold ing the shaft
stationary, un screw the
impeller from the shaft by
tapping the end of the
impeller blades.
4. To remove seal plate take out
sock et head screws and using
screws in back-off holes,
pry plate loose. This will
also force seal off if not
already removed.
5. Remove snap ring. Pull seal
if it is free. If not free, it
can be forced off when shaft
is re moved.
6. Set seal housing in upright
po si tion and bump end of
shaft on hard wood block.
This will push the bearing
from the housing and will
force upper seal from shaft.
7. Use bearing puller to remove
bear ings. Replace with new
bear ings. Press only on
inner face of bearing when
replacing. Pressing on outer
face can damage the bear ing.
Bearings are stan dard size
that can be obtained from
any bearing sup ply house
or can be obtained from
Hydromatic factory.
8.  Do not use
any of the old seal parts.
Replace with all new seals.
 (3 .$'  - & $-
$-./, , *& - &
9. Thoroughly clean all castings
be fore re plac ing seals. One
grain of dirt between the seal
faces can cause failure.
10. Examine all O-rings for nicks
be fore re us ing.
11. Use Locktite (red) on socket
head locking screw in end
of shaft.
12. Before refilling chamber with
oil, air test as described in
replacing stator.
13. Refill both chambers with
oil as described in replacing
stator.
14. Always check all leads with
high voltage or with Megger
for grounds before operating
the pump.
15. Check pump for proper
rotation before re turn ing to
normal ser vice.
Pump
Maintenance

9
Wiring
Diagrams
PROBE TEST RESISTOR
ON HAZARDOUS LOCATION ONLY
–
PROBE TEST RESISTOR
ON HAZARDOUS LOCATION ONLY
–
––
PROBE TEST RESISTOR
ON HAZARDOUS LOCATION ONLY
PROBE TEST RESISTOR
ON HAZARDOUS LOCATION ONLY

10
1 10894 029 5 Cord Cap Assy. 35' dual 10/4 1
10894 005 5 Cord Cap Assy. 35' dual 10/4 1
10894 030 5 Cord Cap Assy. 35' dual 8/4 1
10894 010 5 Cord Cap Assy. 50' dual 8/4 1
2 00557 000 1 Connector 200/230/1/60, 1
200/575/3/60
02494 000 1 Connector 200/230/460/575/3/60 3
(7 1/2 HP)
3 00834 008 1 O Ring SC 1
4 10898 000 1 Connector 4
5 10899 000 1 Connector 230/460/3/60 9
10899 000 1 Connector 200/230/1/60, 3
200/575/3/60
6 05454 001 1 Roll Pin 1
7 00299 002 1 Stator Holding Ring 1
8 00065 020 1 Lower Bearing 1
9 00150 020 1 O Ring SC 1
10 10900 001 5 Seal Sensor Assy. 1
11 10901 000 1 Seal Failure Probe 2
12 00119 016 1 Pipe Plug 2
13 10902 000 1 Safety 1
14 05876A106 O Ring SC 1
15 19103A043 Capscrew 4
16 00834 024 1 O Ring SC 1
17 10752 000 2 Seal Plate 1
18 07144 005 2 Impeller 7.95" 1
07144 006 2 Impeller 7.85" 1
07144 008 2 Impeller 7.30" 1
07144 009 2 Impeller 7.20" 1
07144 011 2 Impeller 6.40" 1
07144 013 2 Impeller 5.90" 1
07144 014 2 Impeller 5.50" 1
19 19101A017 Capscrew S/S 3
20 00519 001 1 Washer 1
21 00556 003 1 Capscrew S/S 1
23 00300 000 1 Lower Seal Ceramic (Std.) S 1
00696 000 1 Lower Seal Carbide (Opt.) C 1
24 07143 001 2 Volute 1
25 105 014034 263 Capscrew S/S 3
26 00975 012 1 Retaining Ring 1
27 10743 001 2 Bearing Housing 1
28 04916 000 1 Upper Seal SC 1
29 00568 007 1 Capscrew 4
31 00517 008 1 Capscrew 4
32 24407C223 Stator 3/4–1 HP 230/1/60 1150 RPM 1
14715 203 1 Stator 3/4–1 HP 200/1/60 1150 RPM 1
24407C225 Stator 3/4–1 HP 230/460/3/60 1
1150 RPM
24407C224 Stator 3/4–1 HP 200/3/60 1
1150 RPM
24407C226 Stator 3/4–1 HP 575/3/60 1
1150 RPM
24407C231 Stator 1 1/2–2 HP 230/1/60 1
1150 RPM
14717 203 1 Stator 1 1/2–2 HP 200/1/60 1
1150 RPM
24407C233
Stator 1 1/2 –2 HP 230/460/3/60 1
1150 RPM
24407C232 Stator 1 1/2–2 HP 200/3/60 1
1150 RPM
24407C234 Stator 1 1/2–2 HP 575/3/60 1
1150 RPM
24407C200 Stator 3 HP 230/1/60 1750 RPM 1
14698 203 1 Stator 3 HP 200/1/60 1750 RPM 1
24407C202 Stator 3 HP 230/460/3/60 1
1750 RPM
24407C201 Stator 3 HP 200/3/60 1750 RPM 1
24407C203 Stator 3 HP 575/3/60 1750 RPM 1
24407C206 Stator 5 HP 230/460/3/60 1
1750 RPM
24407C205 Stator 5 HP 200/3/60 1750 RPM 1
24407C207 Stator 5 HP 575/3/60 1750 RPM 1
24407C209 Stator 7 1/2 HP 230/460/3/60 1
1750 RPM
24407C208 Stator 7 1/2 HP 200/3/60 1
1750 RPM
24407C210 Stator 7 1/2 HP 575/3/60 1
1750 RPM
33 07774 015 5 Rotor w/Shaft 3/4–1 HP 1
1 phase 1150 RPM
Ref. Part Part
No. No. Description Qty.
07773 015 5 Rotor w/Shaft 3/4–1 HP 1
3 phase 1150 RPM
01329 018 5 Rotor w/Shaft 1 1/2–2 HP 1
1 phase 1150 RPM
00740 016 5 Rotor w/Shaft 1 1/2–2 HP 1
3 phase 1150 RPM
01329 018 5 Rotor w/Shaft 3 HP 1
1 phase 1750 RPM
01329 018 5 Rotor w/Shaft 3–5 HP 1
3 phase 1750 RPM
01329 018 5 Rotor w/Shaft 7 1/2 HP 1
3 phase 1750 RPM
34 10765 003 2 Motor Housing 3/4–1 HP 1
3 phase 1150 RPM
10765 002 2 Motor Housing (all others) 1
36 00736 001 1 Spacer 3/4–1 1/2–2 1
3 phase 1150 RPM
00736 002 1 Spacer 3/4–1 HP 1 phase 1150 RPM 1
37 00065 021 1 Upper Bearing 1
38 00064 003 1 Load Spring 1
39 01032 002 1 Nut 1
40 00589 002 1 Eyebolt 1
41 10895 000 5 Conn. Box 230/460/3/60 1
10895 001 5 Conn. Box 200/230/1/60, 1
200/575/3/60
42 00834 013 1 O Ring SC 1
43 19100A029 Capscrew 2
44 19101A017 Capscrew 2
45 04580 001 1 Drive Screw 3
46 13425 034 1 Nameplate 1
47 13425 030 1 Nameplate (UL) 1
13425 033 1 Nameplate (FM) 1
48 00995 008 1 Lock Washer 4
51700 056 7 Seal Kit
51700 356 7 Carbide Seal Kit
49 24709110000 Paraffinic Oil
otes: S — Parts in Seal Kit C — Parts in Carbide Seal Kit
— Fill Oil to above the Top of the Motor Windings
ORDERI G REPLACEME T PARTS: Product improvements are made from time to time. The latest part design will be fur nished
as long as it is in ter change able with the old part.When ordering re place ment parts, always furnish the fol low ing information: (1)
pump serial num ber, (2) pump model and size, (3) part description, (4) part number, (5) im pel ler diameter (if ordering impeller),
(6) quan ti ty required, and (7) shipping instructions.
Ref. Part Part
No. No. Description Qty.
Ref. Part Part
No. No. Description Qty.
S4NVX
Parts List
For use wit product built wit Regal Beloit/Marat on motor.

11
38
42
37
36
33
32
31
29
49
27
28
26
24
34
48
25
47 39 45
41 40 46
1
2
3
4
5
6
7
8
9
10
12
11
13
14
16
17
18
19 20 21 23
15
43
44
S4NVX
DUAL VOLTAGE
3 PHASE MOTOR WIRING
230V 3ø 460V 3ø
GREEN GREEN
R
(L3)
W
(L2)
BL
(L1)
R
(L3)
W
(L2)
BL
(L1)
12 3
789
456
12 3
789
456
$"/, 

12
Pump
Notes
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________

13
Pump
Notes
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________
______________________________________________

– Your Authorized Local Distributor –
www.hydromatic.com
STANDARD LIMITED WARRANTY
HYDROMATIC®warrants its products against defects in material and workmanship for a period of 12 months
from the date of shipment from Hydromatic or 18 months from the manufacturing date, whichever occurs first -
provided that such products are used compliance with the requirements of the Hydromatic catalog and
technical manuals for use in pumping raw sewage, municipal wastewater or similar, abrasive free
non-corrosive liquids.
During the warranty period and subject to the conditions set forth, Hydromatic, at its discretion, will repair or
replace to the original user, the parts which prove defective in materials and workmanship. Hydromatic
reserves the right to change or improve its products or any portions thereof without being obligated to provide
such a change or improvement for prior sold and/or shipped units.
Start-up reports and electrical schematics may be required to support warranty claims. Warranty is
effective only if Hydromatic authorized control panels are used. All seal fail and heat sensing devices must be
hooked up, functional and monitored or this warranty will be void. Hydromatic will only cover the lower seal
and labor thereof for all dual seal pumps. Under no circumstance will Hydromatic be responsible for the cost
of field labor, travel expenses, rented equipment, removal/reinstallation costs or freight expenses to and from
the factory or an authorized Hydromatic service facility.
This limited warranty will not apply: (a) to defects or malfunctions resulting from failure to properly
install, operate or maintain the unit in accordance with the printed instructions provided; (b) to failures resulting
from abuse, accident or negligence; (c) to normal maintenance services and parts used in connection with such
service; (d) to units which are not installed in accordance with applicable local codes, ordinances and good
trade practices; (e) if the unit is moved from its original installation location; (f) if unit is used for purposes other
than for what it is designed and manufactured; (g) to any unit which has been repaired or altered by anyone
other than Hydromaticor an authorized Hydromatic service provider; (h) to any unit which has been repaired
using non factory specified/OEM parts.
Warranty Exclusions: HYDROMATIC MAKES NO EXPRESS OR IMPLIED WARRANTIES WHICH EXTEND
BEYOND THE DESCRIPTION ON THE FACE HEREOF. HYDROMATIC SPECIFICALLY DISCLAIMS THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR ANY PARTICULAR PURPOSE.
Liability Limitation: IN NO EVENT SHALL HYDROMATIC BE LIABLE OR RESPONSIBLE FOR
CONSEQUENTIAL, INCIDENTAL OR SPECIAL DAMAGES RESULTING FROM OR RELATED IN ANY MANNER
TO ANY HYDROMATIC PRODUCT OR PARTS THEREOF. PERSONAL INJURY AND/OR PROPERTY DAMAGE
MAY RESULT FROM IMPROPER INSTALLATION. HYDROMATIC DISCLAIMS ALL LIABILITY, INCLUDING
LIABILITY UNDER THIS WARRANTY, FOR IMPROPER INSTALLATION. HYDROMATIC RECOMMENDS
INSTALLATION BY PROFESSIONALS.
Some states do not permit some or all of the above warranty limitations or the exclusion or limitation of
incidental or consequential damages and therefore such limitations may not apply to you. No warranties
or representations at any time made by any representatives of Hydromatic shall vary or expand the
provision hereof.
USA
740 East 9th Street, Ashland, Ohio 44805
Tel: [phone] Fax: [phone]
CANADA
269 Trillium Drive, Kitchener, Ontario, Canada N2G 4W5
Tel: [phone] Fax: [phone]
Warranty Rev 02/09

START-UP REPORT
cut along dotted line
Distributor:__________________________________________________ Order No.: _________________________
Installing Contractor: _________________________________________ Phone: ____________________________
Sales Contact: ______________________________________________ Phone: ____________________________
Customer: ______________________________________________________________________________________
Location: _______________________________________________________________________________________
1. SYSTEM INFORMATION
Size of Wet Well:_______________________________________Manufacturer: _____________________________
Discharge from Bottom of Basin: ________________________Discharge Location:________________________
Inlet from Bottom of Basin: _____________________________Inlet Location: _____________________________
Type of Check Valves: __________________________________Type of Piping: ____________________________
Does System Have Suction Gauges? TYes TNo Suction Pressure Reading: __________________
Does System Have Discharge Gauges? TYes TNo Discharge Pressure Reading:________________
Liquid Being Pumped:_______________________Temperature (F°): __________ Pct. of Solid (%):___________
Is a Sketch or Photograph of System Available? TYes TNo If So, Please Attach.
Any Additional Comments on System:______________________________________________________________
_______________________________________________________________________________________________
2. ELECTRICAL INFORMATION
Control Panel Part Number: _____________________________Panel Rated Amps: ________________________
Manufacturer: _________________________________________Voltage: _______________ Phase: ____________
Heater Size:___________________________________________Location of Panel to Wet Well: _______________
Incoming Line Voltage: _________________________________Actual? ___________________________________
Voltage to Pumps: _____________________________________Actual?___________________________________
Type of Junction Box: __________________________________Manufacturer of Junction Box: ______________
Are Floats Installed in Wet Well? TYes TNo Are Floats Set to Engineer’s Specs? TYes TNo
Are Floats Wired for Proper Sequencing? TYes TNo Are Heat Sensors Hooked Up? TYes TNo
Is the Seal Leak Detection Hooked Up? TYes TNo
Any Additional Comments on Electrical: ____________________________________________________________
_______________________________________________________________________________________________
3. PUMP INFORMATION
Type of Pump:_________________________________________Serial Number of Pump: ____________________
Voltage of Pump: ________________ Phase: _______________RPM: _________________ Amps: ____________
Impeller Size:____________________ C.O.S. TDH: __________GPM: _________________
Voltage Supplied from Panel:____________________________Actual?___________________________________
Actual Amperage (All Phases): Phase 1 Amps: ________ Phase 2 Amps: ________ Phase 3 Amps: ________
Define the Rotation of the Pump: TClockwise TCounterclockwise
Method Used to Check Rotation: TViewed from the Top TViewed from the Bottom
Any Additional Comments on Pumps: ______________________________________________________________
_______________________________________________________________________________________________
4. ACKNOWLEDGE
Acknowledge that all information is accurate and proper procedures have been followed.
Customer: ___________________________________________________________________ Date: _____________
Start-up Technician:___________________________________________________________ Date: _____________
Send to Warranty Manager, 1101 Myers Parkway, Ashland, OH 44805
or Fax to 419-207-3344
or email to [email protected]
or submit online at http://forms.pentairliterature.com/startupform/startupform.asp?type=h
