Hydromatic X-30 Manual

X-30
3/10 HP Submersible Sump Pump
1/4" Solids Handling
• Oil-filledmotorforsuperiorheatdissipationand
continuouslubrication
• Mechanicalshaftsealensuresreliableoperation
• Availablewithdiaphragmorverticalswitch
• High-impactthermoplasticcapandbase
Notetotheinstaller:Pleasemakesureyouprovidethis
manualtotheownerofthepumpingequipmentortothe
responsiblepartywhomaintainsthesystem.
Pump Installation And Service Manual

2
General Information
ThankyouforpurchasingyourPentairpump.Tohelp
ensureyearsoftrouble-freeoperation,pleasereadthe
followingmanualcarefully.
Before operation
Readthefollowinginstructionscarefully.Reasonable
careandsafemethodsshouldbepracticed.Checklocal
codesandrequirementsbeforeinstallation.
Attention
Thismanualcontainsimportantinformationforthesafe
useofthisproduct.Readthismanualcompletelybefore
usingthisproductandrefertoitoftenforcontinuedsafe
productuse.
DO NOT THROW AWAY OR LOSE THIS MANUAL.
Risk of shock.Beforehandlingthesepumps
andcontrols,alwaysdisconnectthepowerfirst.Donot
smokeorusesparkableelectricaldevicesorflamesina
septic(gaseous)orpossiblesepticsump.
NOTICEAllinstallationswhereasumppumpis
permanently-wiredtothesourceofelectricalsupply
(controldeviceorjunctionbox)mustbeperformedonly
byqualifiedpersonnelusingtheappropriatetools,skills,
andknowledgeofelectricalsafety.Suchaconnection
wouldnotbeconsideredreadilyremovableiftheplug
werecutoffthepump’spowercord.Questionsrelating
tothistypeofinstallationshouldbedirectedtoyour
localcodeauthority.
Pump Troubleshooting
Pump does not run or hum
1. Linecircuitbreakermaybeoff,orfusemaybe
blownorloose.
2. Waterlevelinsumpmaybetoolow.Ad
morewater.Turn-onlevelisasindicatedin
installationdrawing.
3. Pumpcordmaynotbemakingcontact
inreceptacle.
4. Floatmaybestuck.Itshouldoperatefreely
inbasin.
5. IfallsystemscheckOK,motorwindingmay
beopen.
Pump runs but does not deliver water
1. Checkvalvemaybeinstalledbackward.Arrowon
valveshouldpointindirectionofflow.
2. Dischargeshut-offvalve(ifused)maybeclosed.
3. Pumpmaybeairlocked.Startandstopseveral
timesbypluggingandunpluggingcord.Checkfor
cloggedventholeindischarge.
4. Impellerorvoluteopeningsmaybefullyor
partiallyclogged.Removepumpandclean.
5. Inletholesinpumpbasemaybeclogged.Remove
pumpandcleantheopenings.
6. Pumpheadmaybetoohigh.Pumpcan’tdeliver
waterover22feetvertical.Horizontaldistance
doesnotaffectpumping,exceptlossdue
tofriction.
Pump runs and pumps out sump but
does not stop
Floatisstuckinupposition.Besurefloatoperatesfreely
inbasin.
Pump runs but delivers only a small
amount of water
1. Pumpmaybeairlocked.Startandstopseveral
timesbypluggingandunpluggingcord.Checkfor
cloggedventholeindischarge.
2. Pumpheadmaybetoohigh.Pumpcan’t
deliverwaterover22feetvertical.Horizontal
distancedoesnotaffectpumpingexceptlossdue
tofriction.
3. Inletholesinpumpbasemaybeclogged.Remove
pumpandcleantheopenings.
4. Impellerorvoluteopeningsmaybefullyor
partiallyclogged.Removepumpandclean.
5. Pumpimpellermaybepartiallycloggedwithtar
orpaint,causingmotortorunslowandoverload.
Removepumpandclean.
Fuse blows or circuit breaker trips
when pump starts
1. Inletholesinpumpbasemaybeclogged.Remove
pumpandcleantheopenings.
2. Pumpimpellermaybepartiallycloggedwithtar
orpaint,causingmotortorunslowandoverload.
Removepumpandclean.
3. Motorstatormaybedefective.
4. Fusesizeorcircuitbreakermaybetoosmall.
Mustbe15amps.
5. Impellerorvoluteopeningsmaybewhollyor
partiallyclogged.Removepumpandclean.
Motor runs for a short time, then stops
1. Inletholesinpumpbasemaybeclogged.Remove
pumpandcleantheopenings.
2. Impellerorvoluteopeningsmaybewhollyor
partiallyclogged.Removepumpandclean.
3. Motorstatormaybedefective.
4. Pumpimpellermaybepartiallycloggedwithtar
orpaint,causingmotortorunslowandoverload.
Removepumpandclean.

3
Ground type 115 volt
receptacle min. height
above floor - 4 Ft.
Shut-off
gate valve (Optional)
1-1/2" Discharge piping can be
PVC or ABS plastic with proper
adapters, or can be galv. steel
Sump pump
Float switch
Lifting handle
10-1/2"
Min.
13"
Min.
Bottom of
Inlet Pipe
Diaphragm and Vertical fits in 12" dia. plastic, fiberglass or concrete basins.
Note: Drill 1/8" dia. hole in
discharge pipe below check
valve to prevent air locking.
Angle hole as shown (it can
discharge at any convenient
angle below the horizontal).
Check valve
(13254-001-1)
with rubber sleeve
connectors for 1-1/4"
and 1-1/2" pipe
Switches
On/Off Vertical
7" - 3-1/2"
On/Off Diaphragm
8-1/2" - 3-1/2"
0
00
1
2
3
4
5
6
7
8
9
5
10
15
20
25
30
200406080100 110120 130
51015202530354045
Flow (GPM)
Flow (LPM)
Total Head (Feet)
Total Head (Meters)
5969 0309

W-03-260(Rev.5/12/2011)©2011
–YourAuthorizedLocalDistributor–
USA
293WrightStreet,Delavan,WI53115
Tel:888-957-8677Fax:800-426-9446 www.hydromatic.com
CANADA
269TrilliumDriveKitchener,Ontario,CanadaN2G4W5
Tel:519-896-2163Fax:519-896-6337
