HYGEAR GEAR 1 User manual

GEAR 1
User manual

Product
Specification
Function
Band mate
DC input 5V
Bluetooth version BLE 4.2
Connectivity Android, iOS
Dimensions ~45x3.9x1.9 inches
Weight 3.3 lbs
Resistance band material
Max user weight
Capacity
Safeguards
Connected fitness system
1 band 13lbs - 22lbs
2 bands 26lbs - 44lbs
100% pure latex
330 lbs
3.7V 300mAh Li-ion
Over-discahrge protection
Overheat protection
Over-current protection
Overcharge protection
Short circuit protection
*Depending on the type of charger used
Water resistance IP54
Charge Time* (0-100%) 2 hours
Frequency 2.4GHz
Micro USB
Input port
60 hours
Work Time
26 feet
Bluetooth range

GEAR 1 Mission:
GEAR 1 is a versatile and portable smart fitness system that
provides personal training based on your actual workout
perfomance. Developed by childhood friends, Guy Bar, Dan
Strik, and Elad Elkalai, GEAR 1 was born out of a need for
smart, motivational fitness gear that was easy to transport
and use anywhere. It’s the full home gym that hits every
muscle and gives real-time feedback, so you always
know where you stand, and what to do next. And with
personalized workouts to build muscle, burn fat and lose
weight faster, it’s like a personal trainer, just way better.
The HYGEAR app is compatible with iOS 7 and higher,
Android Jelly Bean 4.1 and higher. The app is free to
download from the App Store and Google Play.
What is GEAR 1
To create versatile fitness solutions that adapt to
any health goal or journey
To make fitness accessible with affordable, portable
solutions that anyone can use
To connect with the HYGEAR community, to listen
and understand its needs, and respond with new
and innovative technological fitness solutions that
help people achieve their goals

What’s in the box GEAR 1
A. Band 1
1. Carabiner
2. Pulley
3. Band Holder
4. Resistance Adjuster
5. Resistance Band
6. Smart fitness sensor
7. Carabiner
B. Band 2
C. Cuffs
D. Door anchor
E. Object anchor
F. Handles
G. Double USB cable
F
G
C
A
1 2 6 73 54
B
D
E

How to Set Up Your GEAR 1
1. Open the GEAR 1 Package.
You should find:
A. Band 1
B. Band 2
C. Cuffs
D. Door anchor
E. Object anchor
F. Handles
G. Double USB cable
H. Door hanger «Workout in progress»
2. Read the User Manual & Pairing Guide.
3. Download the HYGEAR app.
4. Make sure Bluetooth and location services are enabled.
5. Open the app and follow the instructions to create your
GEAR 1 account.
6. Take one band and press the button once to wake the
sensor. Red and blue lights will start blinking.
7. The app will connect automatically to the band.
8. Once the band is connected, the blue light will blink
slowly.
9. Press ‘Connect another’ to connect the second band.
10. If you do not manage to connect your bands , shut down
the app, re-open, and try again.
SEE
HYGEAR
IN ACTION

ILED Indications and
Sensor State
▶ Red-blue blinking: Not paired, not
connected (never used)
▶ Blue blinking (slow): Connect
▶ Red blinking (fast): Low battery
▶ Green-red blinking: Charging
▶ Green steady: Fully charged
▶ Active: While the app is connected
▶ Standby: For minutes after the app is closed
▶ Sleep: When the app is not in use for 20 minutes,
after the app has been closed for more than 3 minutes
LED Indications
LED Indications

GEAR 1 adjuster
The adjuster changes the Working Length of the GEAR 1
bands. By moving the adjuster, you can:
1. Increase or decrease the band’s tension (shorter for more
tension, longer for less tension).
2. Change the length of the bands to suit your workout
space and your exercise needs.
** Do not place the adjuster too close to the sensor unit or tip
cover, to prevent snapping and damaging the bands.

GEAR 1 adjuster
Make sure not to stretch the bands more
than 3 times their original length to prevent
them from snapping or breaking.

How to use GEAR 1 with
the Door Anchor
Always close the door securely.
Clip the carabiner on the GEAR 1
to the Door Anchor
For a low anchor, place the Door Anchor
under the door
For a middle anchor, place the Door Anchor
above the door lock
For a high anchor, place the Door Anchor
inside the top of the of the door

Important Safety Information
for Door Anchoring
Only use the GEAR 1 Door Anchor with professionally
constructed doors that can fully support your body
weight.
It is safest and most secure to place the Door Anchor
so that you pull, rather than push, the door closed. That
way, the door is less likely to open into you while you’re
exercising.
When using any hinge-style door, always ensure it’s
completely closed before starting your workout.
Check that the door is fully closed and secured by
pushing or pulling it before starting your workout.
For additional safety, use a door that locks.
Safety tips
To avoid injury, always place the door sign, ‘Workout in
Progress - Do Not Open’ on the opposite side of the door
before starting your workout.
DO NOT use GEAR 1 on glass doors, sliding doors, or any
lightweight doors such as closets or kitchen cabinets.

The handles
Connect the D-rings on the handles to the carabiners on
the Gear 1 bands.
Grip the handle or slip your foot through the loop as
illustrated, according to the exercise instructions.
You may adjust the size of the loop as needed.
Please follow the safety guidelines outlined further in this
User Manual.
The ankle straps
Wrap the cuffs around your ankles or wrists and close the
velcro securely.
Connect the D-rings on the cuffs to the carabiners on the
Gear 1 bands.
How to use

How to use GEAR 1 with
the Object Anchor
Warp the Object Anchor strap around a sturdy object
that can support the weight.
Clip the carabiner on the anchor through the tightest
loop on the strap so that it’s secure. You may need to
warp the anchor strap around the object a number of
times before clipping the carabiner through to ensure
that it’s secure.
Attach the bands to the Object Anchore with the handles
of cuffs end.
Please follow the safety guidelines outlined further in this
User Manual.

Important Safety Information
for Object Anchoring
Only use the GEAR 1 Door Anchor with professionally
constructed doors that can fully support your body
weight.
The Objects Anchor attachments are safest when
properly secured to sturdy, permanent structures. Use
outdoors on swing sets or playground bars. Use indoors
on professionally manufactured fitness facility cable
machines, ceiling mounts, smith machines or caling
beams and posts.
For higher anchor points, wrap the anchor strap around
the anchor point once and clip the carabiner into the
tightest available loop.
For lower anchor points, wrap the anchor strap around the
anchor point as many times as neede to shorten, and then
clip the carabiner into the tightest available loop.
Insure that the carabiner is securely attached to the loop
on the Object Anchor before attaching the Gear 1 bands.
Test that the Object Anchor is safely secured by firmly
pulling the bottom D-ring downward.
IMPORTANT: Always clip the GEAR 1 bands t othe D-ring
of the Object Anchor attachment, and never to the loops
of the strap itself.

Examples of Exercises
Using GEAR 1
Straight body pullover
GEAR 1 butterfly
1 Leg deadfit

GEAR 1 Pull Over
Bicep Curls to Chest
Side Plank L Row
Examples of Exercises
Using GEAR 1

Do start slowly and take it easy before progressing to a
more challenging or intense workout.
Do set your own limits and be responsible for your own
safety.
Do choose the right workout program for your fitness
level and stay in control.
Do check that you have attached the product properly
and the bands are secure.
Do always perform a weight test by pulling hard on the
anchor and handles once the product is anchored in
place.
Do use a strong and secure anchoring point that can
fully support your body weight.
Do pull hard on the handles to ensure the are secure
before using.
Do maintain a secure grip when performing exercises
using the han
Do ensure the carabiners are correctly attached to the
GEAR 1.
Do inspect the resistance bands for holes, tears or
cracks before starting your workout.
Do make sure the floor is not wet or slipppery to avoid
minor or even severe injuries.
Do use GEAR 1 only for its intended use, as described in
this manual.
Do inspect your GEAR 1 and all its components before
each use.
Do replace any damaged or worn components
immediately.
Safety: do’s and dont’s
As with any exercise equipment, it is essential
to be mindful of your personal safety.

Don’t continue exercising you feel pain or discomfort.
Don’t use GEAR 1 if your hands are greasy, wet or overly
sweaty.
Don’t push yourself too far beyond your comfort zone.
Don’t use GEAR 1 if a band or any other element is
damaged.
Don’t allow children under the age of 13 to use GEAR 1.
Don’t expose GEAR 1 to direct sunlight, rain or snow.
Don’t leave GEAR 1 exposed outdoors for an extended
period of time.
Don’t use strong chemical agents or cleaners, which
may discolor or damage your GEAR 1.
Don’t touch GEAR 1 or the power plug with wet hands.
Don’t bend or yank the plug or power cord from the
electrical outlet.
Don’t download and install any firmware from an
unauthorized provider. This may cause GEAR 1 to
malfunction or become incompatible, which would void
the product warranty.
Don’t use GEAR 1 if any of the components are worn or
damaged.
Don’t use an anchoring point that causes excessive
friction or wear to the GEAR 1.
Don’t expose your GEAR 1 to high temperatures.
Failure to adhere to GEAR 1 safety guidelines may result
in minor or severe injury. The user assumes the full risk
of injury and and all liability resulting from the use of
GEAR 1 and all of its components.
Safety: do’s and dont’s

FCC Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or
more of the following measures:
Any Changes or modifications not expressly approved by
the part responsible for compliance could void the user’s
authority to operate the equipment.
FCC RF Radiation Exposure Statement Caution: This
equipment complies with FCC exposure limits set forth
for an uncontrolled environment.
FCC Сaution

FCC Caution
FR
Le présent appareil est conforme aux CNR d’Industrie
Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux conditions
suivantes : (1) l’appareil ne doit pas produire de brouillage,
et (2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible
d’en compromettre le fonctionnement.
Cet équipement est conforme à l’exposition aux
rayonnements Industry Canada limites établies pour
unenvironnement non contrôlé.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
EN
This device complies with Industry Canada licence-exempt
RSS standard(s).
Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must
accept any interference, including interference that may
cause undesired operation of the device.
This equipment complies with Industry Canada radiation
exposure limits set forth for an uncontrolled environment.
IC Statement
PN:DOC-HYD0001.V01
