HyperX cloud ii User manual

User Manual
HyperX Cloud II Wireless
Find the language and latest documentation for your HyperX Cloud II Wireless here.
HyperX Cloud II Wireless Installation Guide
Simplied Chinese .....简体中文说明书
............For instructions in English
. . . . . . . . . . . . . . . . . . Para instrucciones en Español
.........Für Anleitungen in Deutsch
. . . . . . . . . . . . . . . . . . Pour des instructions en Français
. . . . . . . . . . . . . . . . . . Per le istruzioni in Italiano
............Por as instruções em Português
. . . . . . . . . . . . . . . . . . Instrukcje w jezyku Polskim
. . . . . . . . . . . . . . . . . . Для инструкции на Pусском
. . . . . . . . . . . . . . . . . . Turkce talimatlar icin
. . . . . . . . . . . . . . . . . .日本語マニュアル用
. . . . . . . . . . . . . . . . . .한국어 안내
. . . . . . . . . . . . . . . . . . คำ�แนะนำ�ภ�ษ�ไทย
. . . . . . . . . . . . . . . . . . Để xem hướng dẫn bằng tiếng Việt
Traditional Chinese ....繁體中文說明
ﻰﺑرﻋ. . . . . . . . . . . . .ﺔﯾﺑرﻌﻟا ﺔﻐﻠﻟﺎﺑ تﺎﻣﯾﻠﻌﺗﻟا ﻰﻠﻋ لوﺻﺣﻠﻟ

Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 1 of 13
HyperX Cloud II Wireless
Part Numbers
HHSC2X-BA-RD/G

Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 2 of 13
TABLE OF CONTENTS
Overview .................................................................................................................................... 3!
Specifications............................................................................................................................ 4!
Setting up with PC .................................................................................................................... 5!
Setting up with PlayStation 4 ................................................................................................... 9!
Controls ................................................................................................................................... 10!
Mic mute / mic monitoring button ........................................................................................................................ 10!
Power button / 7.1 Surround Sound button ........................................................................................................ 10!
Volume wheel ........................................................................................................................................................ 11!
Status LED ............................................................................................................................................................. 10!
Charging the Headset ............................................................................................................. 12!
Wired charging ...................................................................................................................................................... 12!
HyperX NGENUITY Software .................................................................................................. 12!
Manually Pairing the Headset and USB Adapter ................................................................. 13!

Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 3 of 13
Overview
A. Mic mute / mic monitoring button
B. USB charge port
C. Microphone port
D. Status LED
E. Power / 7.1 Surround Sound button
F. Volume wheel
G. Detachable microphone
H. Microphone mute LED
I. USB adapter
J. Wireless pairing pin hole
K. Wireless status LED
L. USB charge cable

Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 4 of 13
Specifications
Headphone
Driver: Dynamic, 53mm with neodymium magnets
Type: Circumaural, Closed back
Frequency response: 15Hz–20kHz
Impedance: 60 Ω
Sound pressure level: 104dBSPL/mW at 1kHz
T.H.D.: ≤ 1%
Weight: 300g
Weight with mic: 309g
Cable length and type: USB charge cable (0.5m)
Microphone
Element: Electret condenser microphone
Polar pattern: Bi-directional, Noise-cancelling
Frequency response: 50Hz-6.8kHz
Sensitivity: -20dBV (1V/Pa at 1kHz)
Battery life*
30 hours
Wireless Range**
2.4 GHz
Up to 20 meters
*Tested at 50% headphone volume. Battery life varies depending upon the usage.
**Wireless range may vary due to environmental conditions.

Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 5 of 13
Setting up with PC
1. Connect the wireless USB adapter to the PC.
2. Power on the headset.
3. Right click speaker icon > Select Open Sound settings > Select Sound Control Panel

Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 6 of 13
4. Under the Playback tab, click on “HyperX Cloud II Wireless” and click on the Set Default
button.
5. Right click on “HyperX Cloud II Wireless” and click on Configure Speakers.

Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 7 of 13
6. Select 7.1 Surround as the speaker configuration and click next.
7. Under the Recording tab, click on “HyperX Cloud II Wireless” and click on the Set Default
button.

Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 8 of 13
8. Under the Playback tab, verify that “HyperX Cloud II Wireless” is set as Default Device and
Default Communication Device. Under the Recording tab, verify that “HyperX Cloud II
Wireless” is set as Default Device.

Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 9 of 13
Setting up with PlayStation 4
1. Set Input Device to USB Headset (HyperX Cloud II Wireless)
2. Set Output Device to USB Headset (HyperX Cloud II Wireless)
3. Set Output to Headphones to All Audio
4. Set Volume Control (Headphones) to maximum.

Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 10 of 13
Controls
Status LED
Status
Battery Level
LED
Pairing
-
Flash green and red every 0.2s
Searching
-
Slow breathing green
Connected
90% - 100%
Solid green
15% - 90%
Blinking green
< 15%
Blinking red
Power / 7.1 Surround Sound button
• Hold for 3 seconds to power headset on/off
• Press to toggle 7.1 Surround Sound* on/off
*Virtual 7.1 surround sound outputs as a 2 channel stereo signal to be used with stereo headphones.
Mic mute / mic monitoring button
• Press to toggle mic mute on/off
o LED On – Mic muted
o LED Off – Mic active
• Hold for 3 seconds to toggle mic monitoring on/off
Status LED
Power / 7.1 Surround Sound button
Mic mute / mic monitoring button

Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 11 of 13
Volume wheel
• Scroll up and down to adjust volume level
WARNING: Permanent hearing damage can occur if a headset is used at high volumes for extended
periods of time
Volume wheel

Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 12 of 13
Charging the Headset
It is recommended to fully charge your headset before first use.
When charging the headset, the headset status LED will indicate the current charge status.
Status LED
Charge Status
Solid green
Fully charged
Breathing green
15% - 99% battery level
Breathing red
< 15% battery level
Wired charging
To charge the headset via wired, plug the headset to a USB port with the USB charge cable.
HyperX NGENUITY Software
Download NGENUITY software at: hyperxgaming.com/ngenuity

Document No. 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Page 13 of 13
Manually Pairing the Headset and USB Adapter
The headset and USB adapter are automatically paired together out of the box. But if manual pairing is
needed, follow the steps below to pair the headset and USB adapter.
1. While the headset is powered off, hold down the power button until the headset status LED
starts blinking red/green rapidly. The headset is now in pairing mode.
2. While the USB adapter is plugged in, use a small tool (e.g. paper clip, SIM tray ejector, etc.) to
hold down the button inside the pin hole until the USB adapter LED starts blinking rapidly. The
USB adapter is now in pairing mode.
3. Wait until both the headset LED and the USB adapter LED are solid.
The headset and USB adapter are now paired together.
Questions or Setup Issues?
Contact the HyperX support team at: hyperxgaming.com/support/

Documento n.º 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Página 1 de 13
HyperX Cloud II Wireless
Números de referencia
HHSC2X-BA-RD/G

Documento n.º 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Página 2 de 13
ÍNDICE
Visión general.......................................................................................................................... 3
Especificaciones ..................................................................................................................... 4
Configuración con PC............................................................................................................. 5
Configuración con PlayStation 4 ........................................................................................... 9
Controles................................................................................................................................ 10
LED de estado........................................................................................................................................................ 10
Botón de encendido/sonido envolvente 7.1 ....................................................................................................... 10
Botón para silenciar el micrófono/controlar el micrófono................................................................................ 10
Rueda de volumen................................................................................................................................................. 11
Carga de los auriculares....................................................................................................... 12
Carga con cable..................................................................................................................................................... 12
Software HyperX NGENUITY ................................................................................................ 12
Emparejamiento manual de los auriculares y el adaptador USB...................................... 13

Documento n.º 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Página 3 de 13
Visión general
A. Botón para silenciar el micrófono/controlar
el micrófono
B. Puerto de carga USB
C. Puerto de micrófono
D. LED de estado
E. Botón de encendido/sonido envolvente 7.1
F. Rueda de volumen
G. Micrófono desmontable
H. LED de silencio del micrófono
I. Adaptador USB
J. Orificio de vinculación inalámbrica
K. LED de estado inalámbrico
L. Cable de carga USB

Documento n.º 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Página 4 de 13
Especificaciones
Auriculares
Controlador: Dinámico de 53mm, con imanes de neodimio
Tipo: Circumaural, cerrado por la parte trasera
Respuesta de frecuencia: 15 Hz –20 kHz
Impedancia: 60 Ω
Nivel de presión acústica: 104 dBSPL/mW a 1 kHz
Distorsión armónica total: ≤ 1%
Peso: 300 g
Peso con micrófono: 309 g
Longitud y tipo de cable: Cable de carga USB (0,5 m)
Micrófono
Elemento: Micrófono de condensador electret
Patrón polar: Bidireccional, cancelación de ruido
Respuesta de frecuencia: 50 Hz-6,8 kHz
Sensibilidad: -20 dBV (1 V/Pa a 1 kHz)
Duración de la batería*
30 horas
Alcance inalámbrico**
2,4 GHz
Hasta 20 metros
*Probado al 50 % del volumen de los auriculares. La duración de la batería depende del uso.
**El alcance inalámbrico puede variar en función de las condiciones ambientales.

Documento n.º 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Página 5 de 13
Configuración con PC
1. Conecta el adaptador USB inalámbrico al PC.
2. Enciende los auriculares.
3. Haz clic con el botón derecho en el icono del altavoz > Selecciona Abrir configuración de
sonido > Selecciona Panel de control de sonido

Documento n.º 480HX-HHSC2X.A01
HyperX Cloud II Wireless
Página 6 de 13
4. En la pestaña Reproducción, haz clic en “HyperX Cloud II Wireless” y, a continuación, en el
botón Establecer como predeterminado.
5. Haz clic con el botón derecho en “HyperX Cloud II Wireless” y haz clic en Configurar
altavoces.
