HyperX Cloud Revolver HX-HSCR-BK/AS User manual

User Manual
HyperX Cloud Revolver Headset
Find the language and latest documentation for your HyperX Cloud Revolver Headset here.
HyperX Cloud Revolver Headset Installation Guide
Simplied Chinese .....
Traditional Chinese ....
............For instructions in English
. . . . . . . . . . . . . . . . . . Para instrucciones en español
.........Für Anleitungen in Deutsch
. . . . . . . . . . . . . . . . . . Pour des instructions en français
. . . . . . . . . . . . . . . . . . Per le istruzioni in italiano
............Por as instruções em português
. . . . . . . . . . . . . . . . . . Instrukcje w jezyku polskim
. . . . . . . . . . . . . . . . . . Для инструкции на русском
. . . . . . . . . . . . . . . . . . Turkce talimatlar icin
. . . . . . . . . . . . . . . . . . Japanese
. . . . . . . . . . . . . . . . . . Korean
. . . . . . . . . . . . . . . . . . Thai
. . . . . . . . . . . . . . . . . . Vietnamese

Document No. 480HX-HSCR001.A01
HyperX Cloud Revolver Headset
Page 1 of 10
HyperX Cloud Revolver Headset
Part Numbers:
HX-HSCR-BK/AS
HX-HSCR-BK/EE
HX-HSCR-BK/EM
HX-HSCR-BK/LA
HX-HSCR-BK/NA

Document No. 480HX-HSCR001.A01
HyperX Cloud Revolver Headset
Page 2 of 10
Introduction
HyperX Cloud Revolver™ has a wider audio range that creates depth and width for improved
audio precision. Get the competitive edge by hearing your opponents’ location more
accurately, even when they’re further away. Re-engineered audio profiles create a larger
sound stage that’s ideal for FPS and open-environment gameplay and for a concert-hall-like
experience when listening to music. Next-generation 50mm drivers direct sound into the ear
for precise audio positioning, making HyperX Cloud Revolver the only headset you need for
both PC and console gaming.
What’s included:
HyperX Cloud Revolver Headset
Detachable microphone
Audio control box

Document No. 480HX-HSCR001.A01
HyperX Cloud Revolver Headset
Page 3 of 10
Features:
Studio-grade sound stage
Signature HyperX memory foam with premium leatherette
Durable steel frame
Detachable noise-cancellation microphone
Next-generation directional 50mm drivers
Multi-platform compatibility
Technical specifications:
Headphone
Driver: Dynamic, 50mm with neodymium magnets
Type: Circumaural, closed back
Frequency response: 12Hz–28,000 Hz
Impedance: 30 Ω
Sound pressure level: 104.5dBSPL/mW at 1kHz
THD: < 2%
Input power: Rated 30mW, maximum 500mW
Weight: 360g
Weight w/ mic: 376g
Cable length and type: Headset (1m) + audio control Box (2m)
Connection: Headset - 3.5mm plug (4 pole) + Audio Control Box - 3.5mm stereo and
mic plugs
Microphone
Element: Electret condenser microphone
Polar pattern: Uni-directional, Noise-cancelling
Frequency response: 50Hz-18,000 Hz
Sensitivity: -40dBV (0dB=1V/Pa,1kHz)

Document No. 480HX-HSCR001.A01
HyperX Cloud Revolver Headset
Page 4 of 10
Overview
A. Durable steel Frame
B. Suspension headband
C. Detachable noise cancellation
mic
D. Attached cable w/ 4 pole
3.5mm plug
E. Audio control box with 3.5mm
stereo and mic plugs (2m)

Document No. 480HX-HSCR001.A01
HyperX Cloud Revolver Headset
Page 5 of 10
Audio control box operation
The audio control box contains a volume dial to adjust the headphone output volume and
a microphone mute slider to mute the microphone output.
To increase the volume of the headset, rotate the volume wheel towards the + sign (anti-
clockwise). To reduce the volume, rotate the volume wheel towards the –sign (clockwise).
To mute the microphone output, slide the microphone mute button to the down position. To
activate the microphone output, slide the microphone mute button to the up position.
Microphone
Active
Microphone
Mute
Headphone
Volume

Document No. 480HX-HSCR001.A01
HyperX Cloud Revolver Headset
Page 6 of 10
Usage (PC)
To connect the headset to your computer (or other device) that has both a headphone jack and
a microphone jack, connect the headset’s 3.5mm plug to the female jack on the audio control
box. The audio control box has two 3.5mm jacks. The audio plug, which has green stripes,
plugs into the port signified by a green input or headphone symbol . The extension cable
microphone plug, which has pink stripes, plugs into the port signified by a pink input or
a microphone symbol .
Using with PC extension cable

Document No. 480HX-HSCR001.A01
HyperX Cloud Revolver Headset
Page 7 of 10
Usage (Xbox One)
To use the headset with Xbox One™, connect the 3.5mm plug on the headset directly to the
3.5mm jack on the Xbox One controller
*If your Xbox One controller does not have a 3.5mm jack you will need the Xbox One Stereo Headset
adapter (sold separately) that plugs into the Xbox One controller (pictured below).
Using with Xbox One™
*

Document No. 480HX-HSCR001.A01
HyperX Cloud Revolver Headset
Page 8 of 10
Usage (PlayStation4)
To use the headset with PlayStation®4 (PS4™), connect the 3.5mm plug on the headset
directly to the PS4 game controller and follow these steps:
1. Turn on your PS4 game console.
2. Navigate to the Settings menu and select it.
3. Highlight the ‘Devices’ menu option and select it.
4. Scroll down to ‘Audio Devices’ and select it.
5. Choose ‘Output to Headphones’ and select ‘All Audio’.
Using with PS4™

Document No. 480HX-HSCR001.A01
HyperX Cloud Revolver Headset
Page 9 of 10
Usage (Wii U)
To use the headset with Wii U™, connect the 3.5mm plug on the headset directly to the Wii
U gamepad controller.
Using with Wii U™
