Hypontech HPT Series User manual

HPT Series
3-Phase Grid-tied Solar Inverters
USER MANUAL

CATALOGUE
1. SYMBOLS ON THE LABEL .................................................................................. 4
2. SAFETY AND WARNINGS .................................................................................. 4
3. UNPACKING ......................................................................................................... 5
3.1 Scope of Delivery .............................................................................................................. 5
3.2 Product Overview ............................................................................................................. 6
4. INSTALLING ......................................................................................................... 7
4.1 Installation Requirement .................................................................................................. 7
4.2 Mounting Location ........................................................................................................... 8
4.3 Mounting ........................................................................................................................... 9
4.4 Installing the PE cable ...................................................................................................... 9
5. COMMISSIONING ............................................................................................. 10
5.1 Safety Instructions .......................................................................................................... 10
5.2 AC Wire Assembly and Connection .............................................................................. 11
5.3 DC Wire Assembly and Connection .............................................................................. 12
5.4 Residual Current Protection ........................................................................................... 12
6. COMMUNICATION ........................................................................................... 13
6.1 System monitoring via Datalogger - RS485/Wi-Fi /GPRS (Optional) ........................ 13
6.2 Output Efficiency Control via Smart Meter ................................................................... 14
6.3 Demand Responsive Modes（DRMs） ........................................................................ 15
7. START UP AND OPERATION ........................................................................... 17
7.1 Safety Check Before Start Up ......................................................................................... 17
7.2 Inverter LED Indicators ................................................................................................... 18
7.3 Display and Control Logics ............................................................................................ 19
8. DISCONNECTING FROM VOLTAGE RESOURCES ......................................... 20
9. TECHNICAL PARAMETERS ............................................................................... 21
10. TROUBLE SHOOTING ................................................................................... 26
11. SYSTEM MAINTENANCE .............................................................................. 31
12. CERTIFICATES ................................................................................................ 32

HPT USER MANUAL 4
1. SYMBOLS ON THE LABEL
DANGER, WARNING AND
CAUTION
RECYCLABLE AND REUSABLE
HIGH VOLTAGE
AVOID CONTACT
AVOID DAMP AND MOISTURE
HIGH TEMPERATURE
AVOID CONTACT
SHIPMENT STACK LIMIT: 8
CE MARKS
DO NOT DISPOSE WITH
HOUSEHOLD WASTE
PROCEED OPERATIONS
AFTER 5 MINUTES
DISCHARGE
BREAKABLE ITEM
PLACE UPWARDS USER MANUAL IN PACK
2. SAFETY AND WARNINGS
1. All persons who are responsible for mounting, installation, commissioning,
maintenance, tests, and service of HYPONTECH inverter products must be suitably
trained and qualified for corresponding operations. They MUST be experienced and
have knowledge of operation safety and professional methods. All installation
personnel must have knowledge of all applicable safety information, standards,
directives, and regulations.
2. The product must ONLY be connected and operated with PV arrays of protection
class II, in accordance with IEC 61730, application class A. The PV modules must also

5 HPT USER MANUAL
be compatible with this product. Power resources other than compatible PV arrays
MUST not be connected and operate with the product.
3. When designing or constructing a PV system, all components MUST remain in their
permitted operating ranges, and their installation requirements MUST always be
fulfilled.
4. Under exposure to sunlight, the PV array may generate dangerous output in DC
voltage. Contacts with the DC wires, conductors and live components in the inverter
may result in lethal shocks.
5. High voltages in inverter could cause lethal electrical shocks. Before proceeding any
work, including maintenance and/or service, on the inverter, fully disconnect it from
all DC input, AC grid and other voltage sources. There MUST be a 5-minute waiting
time after the full disconnection.
6. The DC input voltage of the PV array MUST never exceed the maximum input
voltage of the inverter.
7. DO NOT touch parts of the inverter during operation as heat will be induced and
these parts will exceed 60℃.
3. UNPACKING
3.1 Scope of Delivery
Please inspect and check for completeness in the scope of delivery. Confirm with
purchase order.
INVERTER MOUNTING
BRACKET
MOUNTING
ACCESSORIES
DC PLUGS
(SEALED)
AC
CONNECTOR
COMMUNICATIO
N DATALOGGER
(OPTIONAL)
DOCUMENTS
1 1 1 2 1 1 1

HPT USER MANUAL 6
3.2 Product Overview
1 LED&LCD or LED
2 DC Switch
3 PV Terminal (s)
4 COM1: Wi-Fi/GPRS (Optional)
5 COM2: RS485/METER/DRED
6 Secondary PE Terminal
7 AC Terminal

7 HPT USER MANUAL
4. INSTALLING
4.1 Installation Requirement
1. Please install the inverter(s) in places that can avoid inadvertent contact.
2. Installation method, location and surface must be fitting for the inverter’s weight and
dimensions.
3. Please install the inverter in an accessible location for operation, future maintenance
and service.
4. The inverter performance peaks at ambient temperature lower than 45℃.
5. When installing in residential or domestic environment, it is recommended to install
and mount the inverter on a solid, concrete wall surface. Mounting the inverter on
composite or plaster boards or walls with similar materials would induce noise during
its operation and is therefore not recommended.
6. DO NOT cover the inverter NOR place any objects on top of the inverter.
7. To ensure sufficient room for heat dissipation and maintenance, the clearing space
between inverter(s) and other surroundings is indicated below for reference:
8. Avoid direct exposure to sunlight and rain and snow layup.

HPT USER MANUAL 8
4.2 Mounting Location
1. DO NOT mount the inverter near any inflammable materials.
2. DO NOT mount the inverter near any explosive materials.
3. DO NOT mount the inverter on tilting surface over 15° backwards. Please mount the
inverter on a vertical wall surface.
4. DO NOT mount the inverter on any surfaces tilting forward or to either sides.
5. DO NOT mount the inverter on a horizontal surface.
6. For easy installation and operation, please mount the inverter on a height that the
display could match eye level.
7. The bottom side where all commissioning terminals are equipped MUST always point
downwards.

9 HPT USER MANUAL
4.3 Mounting
1. Use the mounting paper guide as a template and drill holes of 10mm diameter and
70mm depth.
2. Fix the mounting bracket with the screws and expansion bolts packed in mounting
accessories.
3. Hold up the inverter and tilt it slightly forward. Hang up the inverter and attach it to
the mounting bracket. Check both sides of the heat sink to ensure its stably attached.
4. Use M5 screws (T25 screwdriver, torque 2.5 Nm) to attach the heat sink fins to the
mounting bracket.
5. It is recommended to attach the anti-theft lock to the inverter. Lock diameter φ4-
5.5mm recommended.
4.4 Installing the PE cable
1. Insert the grounding conductor into the suitable terminal lug and crimp the contact.
2. Align the terminal lug with the grounding conductor and the ground washer on the
screw. The teeth of the ground washer must be facing the housing.
3. Tighten it firmly into the housing (screwdriver type: T25, torque: 2.5Nm).

HPT USER MANUAL 10
Information on grounding components:
Object Description
1 Housing
2 M5 terminal lug with protective conductor
3 M5×12 pan head screw
5. COMMISSIONING
5.1 Safety Instructions
1. Measure the frequency and voltage of grid connection and make sure they follow the
inverter’s grid connection specifications.
2. An external circuit-breaker on the AC side (or a fuse) at 1.25*AC rated current is
strongly recommended.
3. Reliability of all earth connections must be tested and valid.
4. Before commissioning, disconnect the inverter and the circuit-breaker or fuse, and
prevent accidental reconnection.

11 HPT USER MANUAL
5.2 AC Wire Assembly and Connection
5.2.1 AC Commissioning
5.2.2 AC Switch Types
Please install an individual 2-stage miniature circuit breaker according to the following
specifications.
Model Maximum output current（A） AC Breaker Rated current（A）
HPT-3000 5 16
HPT-4000 6.5 16
HPT-5000 8.5 16
HPT-6000 9 16
HPT-8000 13 25
HPT-10000 15.2 25
HPT-11000 16 25

HPT USER MANUAL 12
5.3 DC Wire Assembly and Connection
1. PV modules of the connected strings must be of: the same time, identical alignment
and tilting angle.
2. Before commissioning and connecting the PV arrays, the DC switch MUST be open.
3. Parallel strings must have the same number of modules.
4. It is mandatory to use the DC connectors within package for the connection of PV
arrays.
5. The polarity of the PV arrays MUST be compatible to the DC connectors of the
inverter.
6. The DC input voltage AND DC input current of the PV array MUST never exceed the
maximum input allowance of the inverter.
DC Commissioning：
5.4 Residual Current Protection
This product is equipped with residual current protection device internally, in accordance
with IEC 60364-7-714. An external residual current protection device is not needed.
If the local regulation demands otherwise, it is recommended to install a 30mA Type B
residual current protection device.

13 HPT USER MANUAL
6. COMMUNICATION
6.1 System monitoring via Datalogger - RS485/Wi-Fi /GPRS (Optional)
6.1.1 Wi-Fi /GPRS Datalogger Installation
1. Unpack the Datalogger from package.
2. Unscrew the cap in COM1 port and plug
the Datalogger in and tighten.
3. For user guidance and configuration of
Datalogger, please refer to the
corresponding HYPONTECH Wi-Fi Stick Guide manual, which is available in
printed form inside Documents pack, or an online manual on HYPONTECH
website at .
6.1.2 RS485 Installation
If the communication module is connected via RS485:
Step 1: Unscrew with T25 screwdriver and remove the COM sealing plate. The terminals of
DRED/Meter/RS485 is exposed as indicated.

HPT USER MANUAL 14
Step 2: Unscrew the nut of cable gland and take out the rubber cylinders. Please seal the
cable gland properly if there is an unused hole to prevent moisture and dust.
Step 3: Connect the crimped cables to RS485 / Meter terminals and secure by (blade
0.4x2.5) screwdriver.
Step 4: Tighten the nut to prevent the cable from wobbling.
Step 5: Put on the COM sealing plate and firmly tighten the screws to prevent moisture and
dust. (Screwdriver type: T25; Torque: 2.5 Nm)
When installing RS485, the COM sealing plate needs to be removed. All operation MUST
NOT proceed until AC and DC power is securely disconnected and discharged to
prevent electric shocks.
6.2 Output Efficiency Control via Smart Meter
The inverter’s active power output and efficiency could be monitored via the application
of a smart meter.

15 HPT USER MANUAL
Please refer to EASTRON SDM630-Modbus V2 User manual for its connection and
baud rate settings.
6.3 Demand Responsive Modes（DRMs）
The inverter shall detect and initiate a response to all supported demand response
commands.
MODE DEMAND
DRM 0 Disconnect
DRM 1 No power consumption
DRM 2 Power consumption <50% rated power
DRM 3 Power consumption <75% rated power AND respond to reactive power when
capable
DRM 4 Increase power consumption (prior subject to constraints from other active DRMs)
DRM 5 No power generation
DRM 6 Power generation <50% rated power
DRM 7 Power generation <75% rated power AND sink reactive power if possible
DRM 8 Increase power generation (prior subject to constraints from other active DRMs)
DRMs Application Description
• Only applicable to AS/NZS4777.2:2015.
• DRM0, DRM5, DRM6, DRM7, DRM8 are available.

HPT USER MANUAL 16
Moistures and Dust will damage the inverter
• Secure and tighten the screws on COM sealing plate.
• Warranty will be void if the inverter is damaged due to moisture and dust caused by poor
installation of COM sealing plate.

17 HPT USER MANUAL
7. START UP AND OPERATION
7.1 Safety Check Before Start Up
Please check before switching on any voltage resources connected to the inverter and
closing inverter’s DC switch:
1. Grid Voltage: Check the grid voltage at point of connection at the inverter complies
with permitted range of the inverter.
2. Mounting Bracket: Check if the mounting bracket is properly and securely installed.
3. Mounting of the inverter: Check if the inverter is properly mounted and attached to
the mounting bracket.
4. DC Connectors: Check if the DC connectors are installed correctly on terminals.
5. AC Connectors and Wire Assembly: Check if wires are assembled correctly on the AC
side and if the AC connector is properly and securely installed. Check if the AC
connector is firmly plugged into AC terminal.
6. Cables: Check if all cables are reliably connected. Check if the connections are
effective, while the insulations are undamaged.
7. Groundings: Check all groundings using multimeter and if all exposed metal parts of
the inverter are properly grounded.
8. DC Voltage: Check if the largest open-circuit voltage of PV arrays complies with the
permitted range.
9. DC Polarity: Check if the wires from DC voltage resource are connected to terminals
with correct polarity.
10. Grounding Resistance: Check if the grounding resistance of PV strings >1MOhm using
a multimeter.
After all installation and checks, close the AC circuit-breaker, then the DC switch. The
inverter will start to operate when DC input voltage and grid conditions meet the
requirements of inverter startup.

HPT USER MANUAL 18
7.2 Inverter LED Indicators
When the inverter operates, LED symbols on display have the following meanings:

19 HPT USER MANUAL
7.3 Display and Control Logics
When inverter starts up and operates, there is a control button beside LCD Display of the
inverter. Please follow the logics listed below.

HPT USER MANUAL 20
8. DISCONNECTING FROM VOLTAGE RESOURCES
Before proceeding any operations on inverter, please disconnect the inverter from all
voltage resources as described in this manual.
Following these steps in described sequence are mandatory.
1. Disconnect miniature circuit-breaker and prevent from unintentional reconnections.
2. Open the DC switch and prevent the switch from closing unintentionally.
3. Use clamps to ensure there is no electrical current in DC wires.
4. Disconnect all DC connections and resources. Unplug the DC connectors, and DO
NOT pull the cables.
5. Use multimeter to ensure the voltage on DC terminals of inverter is 0.
6. Unscrew and remove the AC connector.
Danger to life due to high voltages.
Inverter capacitors need 10 minutes to be completely de-energized. Please
wait for 10 minutes to remove the cover.
When an error occurs, DO NOT remove the cover of the inverter onsite. Improper
operations and attempts may induce electric shock.
