I-GO AUTO AIR 85 User manual

auto/air85
www.iGo.com
Specifications
DC input: 11.5-28 VDC; 8A max
DC output to notebook: Up to 70W continuous; 84W peak*
Unit dimensions: 3.91 x 2.01 x 1.23"
(99.0 x 50.9 x 32.0mm)
Unit weight: 6.9oz (195.61g)
Cord lengths: DC output-6.0 (1.83m);
DC input-3.0’ (0.91m)
* Peak ou pu power is defined as he maximum achievable wa age,
sus ained for en seconds or less, under he following specific condi ions:
• DC Input: 13.8 VDC minimum
• DC Output: 18 VDC
Safety Features
Over-voltage protection
Over-current limit
Over-temperature protection
Short circuit protection
Before installing, please read this important
safety information. Proper care of your
adapter will ensure its optimal performance.
1. Never pull on the adapter cords.Always hold the plug when
inserting or removing it.
2. Select the correct tip for your notebook by reviewing the
attached tip compatibility hang tag or going to
www.iGo.com –using the wrong tip may damage your
computer or cause it to malfunction.
3. Unplug iGo auto/air85 from the power outlet each time
you attach a new tip to the cable.
4. eep the adapter away from heat sources, such as
electric heaters, and avoid direct sunlight exposure.
5. For indoor use only. eep the adapter free of dust and
moisture, and avoid exposure to corrosive chemicals (such
as cleaning fluids).
6. Do not drop the adapter or subject it to undue shock.
7. Do not place anything on top of the adapter while in use.
8. Turn off the computer and unplug the adapter if you smell
something burning or if the adapter becomes
overly hot.
9. Do not attempt to disassemble the adapter. It has no
serviceable or replaceable parts inside.Voltage in the adapter
can cause injury. If the adapter malfunctions, immediately
discontinue use, and contact iGo Product Support.
10. Always use the appropriate cables and connectors supplied
with your adapter as shown in this User Guide. Use of
cables, connectors or other accessories not supplied with
your product may result in injury or damage to your device.
Issue Pro a le Cause(s) Possi le Solution(s)
Notebook is not charging No input or output power Check plug connector
Check cable connections
Check outlet circuit breaker
or fuse
LED does not light up No electricity to unit See solutions to “Notebook is
not charging”
LED does not light but unit Light burned out Contact iGo customer service
appears to power devices (see contact information on
the back of this guide)
Notebook model not listed on Compatibility is always See www.iGo.com for current
enclosed compatibility chart being updated compatibility information
Device is not charging when Tip not installed on Install tip on Notebook on
iGo dualpower is configured Notebook Input Cord Input Cord
User Guide
iGo Tip Technology
iGo power products deliver the precise amount of power to
each device through the use of interchangeable tips. Using iGo
power products with patented tip technology eliminates
concern about the correct amount of power for your device or
trying to select it yourself as you do with other products—we
do it for you! The attached compatibility hang tag will help you
determine which tip you need for your notebook. Simply attach
the correct tip and get powered up and connectedTM.If your
notebook tip is not included in this package, visit www.iGo.com
to locate additional tips for purchase.WARNING – Using the
wrong tip may damage your device or cause it to malfunction.
Power Your Mo ile Phones,
Smartphones/PDAs, MP3 Players, Digital
Cameras and more...
So, you would like to power/charge an additional mobile
electronic (ME) device? Great, iGo auto/air85 does that too.All
you need is the included iGo dualpower accessory and the
appropriate tip to power/charge your notebook and a ME
device at the same time (additional tips sold separately).
Canada Compliance
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numériqué de la classe B est conformé à la norme
NMB-003 du Canada
Environmental Requirements
Ambient operating temperature is -5ºC to 40ºC
Storage temperature is -20ºC to 85ºC
Certifications
Product Support
We are committed to providing our customers with first-class
customer service and product support.You can receive help in
avariety of ways:
Sales/Customer Service: 1-888-205-0093
T
echnical Support: 1-800-474-7593
Web: www.iGo.com
Product Registration
Thank you for purchasing an iGo mobile solution. Help us serve
you better by taking a moment to register your product at
www.iGo.com/registration. By registering, you are eligible for
benefits including 90 days of free tech support, automatic
notification of product updates and other special promotions.
Warranty
2-year limited warranty
Package Contents
iGo notebook power adapter
iGo dualpower accessory
Auto charging plug
Auto/air outlet cord (DC)
Notebook input cord
Notebook tips (See attached hang tag for corresponding models and tips)
Carrying case
User Guide
Compatibility hang tag
Trou leshooting
©2002-2006 Mobility Electronics, Inc. Mobility Electronics, iGo and iGo dualpower are
registered trademarks and powered up and connected is a trademark of Mobility
Electronics, Inc. All other brand names and logos are trademarks or registered
trademarks of their respective owners. Specifications are subject to change without
notice. Protected by one or more of the following patents: 5,347,211, 6,064,177,
6,700,808, 6,643,158, 6,650,560, 6,751,109, 6,775,163 6,791,853, 6,920,056, 6,937,490
and 6,976,885. Other United States and foreign patents pending. Made in China.
P/N 8040365-01 Rev.A.
Mo ility Electronics, Inc.
17800 North Perimeter Drive, Ste. 200, Scottsdale, AZ 85255 USA
Tel: [phone]; Fax: [phone]
Congratulations on your iGo®power purchase!
Universally compatible with today’s popular brands, iGo
auto/air85 allows you to power/charge a notebook computer
from any standard DC power source.With the included iGo
dualpower®accessory, you can simultaneously power/charge a
notebook computer and a second mobile electronic device
such as a mobile phone, smartphone/PDA, MP3 player, digital
camera and more (additional iGo power tips sold separately).
Also, use the iGo dualpower accessory and included auto
charging plug as a stand-alone car charger for your gadgets.
No other adapters are as powerful or as versatile as the iGo
line of power products.
How to Use This iGo Auto/Air Power
Adapter
Auto, Boat or RV: Plug the auto/air outlet cord into any
standard in-vehicle outlet.Your vehicle may need to be running
in order to get power.The illuminated LED indicates the
adapter is ready to use. If the LED does not illuminate, check
the connections and you may need to check the in-vehicle
power outlet fuse. Please refer to your vehicle manual for
instructions on how to check the fuse box and replace power
outlet fuse if needed. Note: In some vehicles, power to the
outlet is always on.These vehicles may not require the ignition
to be turned on. CAUTION: It is not recommended to have
this iGo adapter connected to your electronic device when
starting the engine.The power may be interrupted causing your
system to reset.
Air: You will need to find the in-flight power outlet in the
airplane.The power outlet is usually located in the arm of your
seat, typically near the same location used to plug in
headphones. It may also be located under the seat. Please ask a
flight attendant for the exact location of the outlet. Once
located, plug the in-flight connector into the airline power
outlet. Some airline outlets may have vehicle type outlets
where the in-flight connector is not necessary.
Note: We recommend that you only use iGo auto/air85 with
device batteries that meet or exceed the original manufacturer
specifications. CAUTION: Like the power adapter that came
with your electronic device, this iGo adapter may get warm to
the touch during use.This is normal.Avoid placing your iGo
adapter in direct sunlight or next to heat sensitive materials.
FCC Compliance
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
•Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
FCC Compliance for iGo dualpower®Accessory
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
autoairpower85UG.q d:Layout 1 2/14/07 8:53 AM Page 1

No ebook Inpu Cord
Connec ion Por
1. Connect the correct notebook tip to
the iGo unit’s notebook input cord.
2. Insert the notebook input cord into
the iGo auto/air85 body.
3. Insert the auto/air outlet cord into
the iGo auto/air85 body.
5. Plug the notebook input cord
into the notebook.
4. Plug into the appropriate socket.The
LED on the adapter will now
illuminate, indicating that power is available. If the LED is not lit, be sure
to check all connections. Check Troubleshooting for additional
information.
Quick Connect Guide
Attention! Unplug iGo auto/air85 from the
power outlet each time you attached a new tip to the cable.
Warning: Choosing the wrong tip may
damage your device or cause it to
malfunction.
Tip Selection:
Make sure you have selected the right tip for the device you want to
charge by checking the compatibility on the attached
compatibility hang tag or online at www.iGo.com.
iGo dualpower®
accessory
(power ips sold
separa ely)
No ebook ip
AC Power Cord
Auto: Use as shown. Note: Always configure the unit as
shown in the Quick Connect
Guide before connecting to power
source.
Air: Remove the auto connector to uncover the connector
for use with EMPOWER®outlet as shown. Note:Although
most airlines use the EMPOWER connections for in-flight use, some airlines may use the standard in-vehicle power outlet. In this case, it is unnecessary to remove the auto connector.
Au o Cord
Slide Ou
Push
Air Cord
auto/air85
Simultaneously power/charge a note ook
computer and a gadget y using the
included iGo dualpower®accessory and
power tips (iGo power tips sold separately).
When charging both your notebook and your gadget, plug
dualpower into the connection port on the Notebook Input Cord.
When you just need to charge your gadgets, simply plug dualpower
directly into the iGo auto/air85 adapter.
Auto charging plug lets you charge your
gadgets in the car.
Simply plug the iGo dualpower accessory with appropriate
power tip into the auto charging plug and use it in your car’s
power outlet.
A/W P/N: 8330365-01
Rev:A
Material 80g art paper
Au o charging plug
Tech note: When using iGo dualpower with this iGo adapter, the maximum
power output is shared between both devices.
If a device attached to iGo dualpower is not charging properly, it may
need more charging power than can be delivered at that particular
time. When this happens, the adapter will shut down (LED will turn
off), and we recommend charging each device separately.
autoairpower85UG.q d:Layout 1 2/14/07 8:53 AM Page 2
