2 Introduction
ibaClock is a compact device for the time synchronization of several connected ibaPDA
systems.
The time base of every ibaPDA system is the time of the respective ibaPDA computer.
In case of requirements such as real time measurements or correlation of decentralized
data, distributed systems may require a synchronization of all computers.
ibaClock indicates the time base for all connected ibaPDA systems as central master
clock and ensures an exact and timely synchronized acquisition of the data. Thereby, a
precision of better than 150 ns can be reached.
For a high-precision synchronization, ibaClock receives the time signal of the GPS sat-
ellites. The functions of ibaClock are adjusted to the “Trimble®Acutime™ GG” and “Trim-
ble®Acutime™ 360” smart antennas, therefore the use of the device is exclusively pro-
vided for one of these antennas. The antennas, the suitable antenna cables and mount-
ing accessories can also be obtained at iba, see chapter 12. The length of the antenna
cable has to be indicated when placing the order.
Alternatively, ibaClock can use the time code IRIG-B as external time source. The fol-
lowing telegrams are supported, e.g. IEEE C37.118, AFNOR NF S87-500, IEEE 1344 or
B004 + B124, B005 + B125, B006 + B126, B007 + B127, see chapter 7.3.5.
The distribution of the time signal to the ibaPDA systems is made via fiber-optic cables.
For this purpose, the ibaPDA computers need a card of the ibaFOB-D-family with FO
input and output for the connection of an ibaClock device.
Beginning with firmware version v01.02.001, time synchronization with ibaClock is pos-
sible via network. The following protocols are supported: TIME protocol, DAYTIME pro-
tocol and NTP.
ibaClock has an internal clock that will carry on to set the time in case of a failure of the
GPS signal. Here, ibaClock provides a stability of < 0.150 ppm for temporary signal fail-
ures.
ibaClock can be configured comfortably via ibaPDA or the web interface.

Manual
ibaClock
8
Issue 1.4
3 Scope of delivery
After unpacking, please check the completeness and integrity of the delivery.
The scope of delivery comprises:
ibaClock device
2-pin connector for power supply
4-pin connector for digital outputs
Manual
Required accessories:
GPS:
“Trimble®Acutime™ GG” or “Trimble®Acutime™ 360” smart antenna
Pre-assembled cable
The cable length has to be indicated when placing the order.
Antenna base, optional
Mounting bar, optional
IRIG-B:
IRIG-B time source
Coaxial cable, e.g. RG58 with BNC connector

ibaClock
Manual
Issue 1.4
9
4 Safety instructions
The device is only to be used as shown in the chapter “Technical Data”.
Strictly observe the operating voltage range
The device is supplied with a voltage of 24 VDC ±10%. When connecting to the voltage,
please ensure compliance with the correct power level and polarity.
Important note
A possibly necessary lightning protection for the GPS antenna, that might be needed,
must be foreseen and built by an electrician.
Important note
Do not open the device! Opening the device results in a loss of warranty!
Note
Clean the device only on the outside with a dry or slightly damp and statically dis-
charged cloth.

Manual
ibaClock
10
Issue 1.4
5 System requirements
5.1 Hardware
External time source:
“Trimble®Acutime™ GG” or “Trimble®Acutime™ 360” GPS smart antenna
Time code IRIG-B
PTP (IEEE 1588), E2E and P2P
Pre-assembled antenna cable for a point-to-point-connection from the antenna to
the device
Connection to an ibaPDAsystem: 2 fiber optic patch cable for a bidirectional fiber
optic connection to one of the following ibaFOB cards in the ibaPDA computer:
ibaFOB-io-D
ibaFOB-2io-D
ibaFOB-2i-D, optionally with extension module ibaFOB-4o-D
ibaFOB-4i-D, optionally with extension module ibaFOB-4o-D
ibaFOB-io-ExpressCard
The firmware of the ibaFOB-D-card must eventually be upgraded to a state D3 or
higher for the use of ibaClock. Please contact the iba support in case of a required
firmware update.
Connection to a standard computer: standard Ethernet cable
5.2 Software
ibaPDA, version 6.34.0 and higher
Web browser for configuration and diagnosis via the web interface of the device
