iBACheck i1 AA1698 User manual

Operation Manual
i1
AA1698 / AA198
Breath Alcohol Tester
Made
in
China
After Sales Services
Please feel free to contact us for any question via
Contact us: [e-mail] (Europe)
us_suppo[email protected]m (USA)
Specification subjects to change without notice
English
1
Thanks for purchasing our iBACheck
i1
Alcohol Tester, a hand-held
Digital Alcohol Breath Analyzer. Model gives you a digital reading of your
breath alcohol content and your possible concentration of alcohol
intoxication.
Important
To begin, rinse your mouth with fresh water before using the device.
Abstain from smoking or drinking for at least 15 minutes. If you perform
a test just after drinking, the reading will fluctuate from very high to low
reading, i.e. it will drop gradually. It is due to the alcohol residues inside
your mouth that effects the test values. This will also happen with
aromatic drinks, alcoholic mouthwashes or mouth sprays, medicines or
drug, as well as by burping and vomiting.
Also, when alcohol enters the blood through the alimentary canal
(mouth, stomach, and intestines), it is distributed through every part of
the body, including the lungs. This period will last for about 15~30min-
utes before stable. Our device detects human breath and gives a digital
reading out of a person’s approximate Blood Alcohol Concentration
(known from here on as BAC). If user direct blow very high concentra-
tion into the sensor, its surface will be surrounded by lots of ethanol
particles, which need to wait for 10 min for evaporation.
Battery Power
Install the provided 3.7V Li ion battery (10440) into the battery
compartment and fully charge the tester before use. Attention: The
reading is invalid if the battery power is low. When there is not enough
battery power, the battery icon【 】 will flash and the tester will
return to the【RTC】mode.
The reading is not reliable when low power and you should charge the
machine immediately. Please connect the provided USB cable and
charge the machine. The LOGO will turn to red and the battery bar will
move forward and backward. The red logo will turn off when the battery
is fully charged.
English
2
Insert the provided Mouthpiece into the gas inlet located aside of
the LCD screen.
(1) Pressing the START【 】Key 1 second to turn on the power and
enter into the Digit Alcohol Computer mode 【DAC 】,sensor pre-
heating will be activated for an approximate 20 seconds.
If the machine has already turned on, just press START【 】Key once
to activate sensor pre-heating, 【PH 】will flashes for 6 times and then
start to counts down.
(2) When count down to zero,【BLOW】flashes with beep tone. It is
ready to start testing & there will has a 5s count down period for auto
detect function. User can preform either or 4)
(3)
Press the START【 】 Key, 【BLOW】light shown. Please start to
blow through the mouthpiece steadily and continuously for
approximately 6 seconds.
While blowing, a long beep will be heard and please keep blowing. When
the beep tone stops, sampling finishes and the test result reading will be
shown on the display immediately.

English
3
(4)
Please blow in within the 5s auto detect period. If alcohol is detected, a
long beep will be heard and please keep blowing. When the beep tone
stops, sampling finishes and the test result reading will be shown on the
display immediately.
If there is no alcohol detected within 5s auto detect period, it will also
take about 5 seconds sampling and show the reading.
(5) Unit set mode：
User can press SET【 】& START【 】keys at the same time for 2
seconds and enter unit set mode 【Unit 】will be shown on the 4-8
segment, the selected unit will flash. Press START【 】Key will scroll
four different units.
mg/l %BAC mg/100mL ‰BAC
（0.10mg/l ≈0.020%BAC = 20mg/mL = 0.20‰BAC）
When exit this unit set mode, the selected unit will be preset as default
unit. If power reset, the unit setting will also be reset.
(6) Press & hold SET 【 】 key 2 seconds can go to memory recall
mode, “MEMORY” display together with record number. The last record
will display on the screen.
(7) Press SET【 】key to scroll backward the memories, if the last
record is 9, then the sequence is as following.
MEMORY
......
MEMORY
8
MEMORY MEMORY
...... ......
(8) Power off:
①. Auto off, the machine will turn off automatically if no key being press
for 25 seconds.
②. Press ESC【ESC 】key to enter Time Clock Mode. Press & hold
START Key for 2 second to turn off the machine.
Alert Signals
i1 alcohol tester is designed to alert user as following:
English
4
ESC
LOW For measurements between 0~0.08‰BAC
(0~0.008%BAC or 0~0.04mgl). It will show 0and avoid
false alarm due to environment and mouth smell
Safety
Level
For measurements between Low Level and Alert
Level, the alcohol concentration level shows on the
display with white backlight.
Alert
Level
For measurements equal to or above the alert
concentration level, the analyzer beeps together
red backlight flashes for 10 times
Time Setting
(1) Press ESC【ESC 】key would change the【DAC】mode into Real
Time Clock mode for time reading, at the same time, the【DAC】
indicator will would disappear.
(2) In【RTC 】mode, press and hold SET【 】& ESC 【ESC 】key for
2 seconds and the device would enter time setting mode. The selected
digits for adjusting will flash. (SET【 】is + up; ESC【 】 is
down, START【 】is to confirm).
(3) Press SET 【 】 & ESC【ESC 】to alter the selected digits. Press
SET【 】to add number and press ESC【ESC 】to minus number.
(4) Press START【 】once to shift the selected digit and press START
【 】for the second time and press SET【 】key to select 12/24
hour format.
(5) Press START【 】for two seconds to exit the time setting mode
Caution
(1) To achieve an accurate reading, user should ensure there is no
alcohol residue inside the chamber before starting a new alcoholtest.
(2) After any 4 consecutive tests, please allow the device to rest for 2
minutes.
(3) When the product is unused, please store it in a dry environment.
(4) When low battery indicator flashes, the reading is invalid, please
recharge the battery immediately.
English
5
(5) If the difference between two successive reading is >0.1‰, user
should test again.
(6) If there is very high concentration tested, user should wait for at least
3min to perform another test)
(7) When battery indicator flashes, please charge the battery immediate-
ly. Connect the provided charge cable to USB port and the white LOGO
on the upper screen will change to RED. The RED indicator will switch
off automatically if battery is fully charged.
Specification
Range 0 / 0,08 ~ 2,00 ‰BAC or 0,008 ~0,200%BAC
or
0/
0,04
~1,00
mg/l
or
0
/
8
~
200
mg/100mL
Power Input 1 x 3.7V AAA Li ion battery
Display 15 seconds
Auto Power Off Digital LCD display with bi-color Backlighting
Breath
Sampling ≥5 seconds continuous breath sample
Recycle Time ≈25 seconds
Dimension
about 12cm (L) x 6.5cm (W) x2.4cm(T) /4.7x2.5x0.96inch
Weight about 40g ( Device only )
Alert Level
Calibrated □0.2‰ □0.3‰
√
□0.5‰ □0.8‰ BAC
Agency
Approval CE
Accessory 6 pcs Blowing tubes (3*2 different type)
Rescue hammer
(1) User can change the machine into a rescue hammer. However, the
high impact force may damage the machine and sensor itself; i.e. ONLY
use this device to break the window as a rescue hammer for emergency
use. After high impact, you need to check whether the sensor is still in
good condition.
English
6
(2) Open the battery door and take the metal object under the battery.
(3) Insert the metal object into the holder on the left hand side of the
machine.
Battery
cover
metal
object
Specification is subject to changes without notice
The Digital Alcohol Analyzer should be used as a general guide to the
level of alcohol in your body.
Many factors (e.g. environment gas residue, smoke & various smell
in human mouth, etc…) may affect the BAC level, so the readings
are For Reference Only.
Neither the reseller nor manufacturer accept any liability arising
from the use of the unit
Don’t drink before you drive!
