IBM 2196 User manual

Personal Computer
Types 2196, 2197, and 6344
User Guide

First Edition (March 2000)
The following paragraph does not apply to any state or country where such provisions are
inconsistent with local law: INTERNATIONAL BUSINESS MACHINES CORPORATION
PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. References to IBM
products, programs, or services do not imply that IBM intends to make them available outside
the United States.
This publication could contain technical inaccuracies or typographical errors. Changes are
periodically made to the information herein; these changes will be made in later editions. IBM
may make improvements and/or changes in the product(s) and/or program(s) at any time.
Request for copies of this publication and for technical information about IBM products should
be made to your IBM Authorized Dealer, your IBM Marketing Representative or your IBM
Retailer. Address comments about this publication to the IBM HelpCenter.
© Copyright International Business Machines Corporation 2000. All rights reserved.
Note to U.S. Government Users – Documentation related to restricted rights – Use, duplication
or disclosure is subject to restrictions set forth in GSA ADP Schedule Contract with IBM Corp.
Note: Before using this information and the product it supports, be sure to read
the general information under Appendix D, “Warranty” on page D-1.

iii
Contents
Notices .........................................................................................................ix
Conventions used in this book .......................................................................x
Safety information ..........................................................................................xii
Installation .............................................................................................xii
Safety while working with hardware ......................................................xii
Lithium battery notice ............................................................................xiv
Regulatory safety notice for the CD-ROM and DVD-ROM drive ..........xiv
Laser compliance statement .................................................................xv
Consignes de sécurité ..........................................................................xvii
Consignes de sécurité lors de la manipulation du matériel ..................xvii
Regulatory notices .........................................................................................xxi
North American Federal Communications Commission (FCC)
Statement ......................................................................................................xxiv
European Community Directive Conformance Statement ....................xxv
Trademarks ...........................................................................................xxv
Year 2000 Notice Information ........................................................................xxvii
Ergonomics.....................................................................................................xxix
Part 1. Learning about this book
Using this book ...........................................................................................1-1
How this book is organized ............................................................................1-1
Where to find more information .....................................................................1-4
Part 2. Support information
HelpWare support and services ................................................................2-1
What do I do first? .........................................................................................2-1
What is IBM HelpWare? .......................................................................2-1
Need quick help? ..................................................................................2-1
What can I do on my own? ...................................................................2-2
How do I get help electronically? ...................................................................2-4
Electronic support .................................................................................2-4
How and when do I contact the IBM PC HelpCenter? ...................................2-5

iv IBM Personal Computer User Guide
What help can I get by telephone? .......................................................2-5
Before you call... ...................................................................................2-7
How and when do I purchase additional support? ........................................2-9
Purchasing additional HelpWare services ............................................2-9
Express Maintenance ................................................................................. 3-1
Part 3. Controlling system settings
Getting started ............................................................................................ 4-1
Controlling monitor settings ...........................................................................4-2
Getting the best performance from your monitor ..................................4-2
Power saver feature .............................................................................4-3
Changing display settings .....................................................................4-3
Controlling volume .........................................................................................4-6
Adjusting the speaker volume .............................................................4-6
Getting ready to print .....................................................................................4-7
Setting up communications ...........................................................................4-8
Connecting your modem to the telephone network ..............................4-8
Configuring your communications software ..........................................4-9
Configuring your computer for a connection to the Internet ..........................4-10
The IBM Internet Connection Services .................................................4-10
The Microsoft Network ..........................................................................4-11
The Internet Connection Wizard ...........................................................4-11
Using the Rapid Access II keyboard .....................................................4-11
Power management features .................................................................... 5-1
Software shutdown ........................................................................................5-2
Using the software shutdown feature ...................................................5-2
System Standby ............................................................................................5-3
Using the Windows 98 Start menu .......................................................5-3
Using the power button .........................................................................5-3
Using the Power Management feature in Windows 98 .................................5-5
Monitor standby .............................................................................................5-6
BIOS Setup configuration .......................................................................... 6-1
Configuration/Setup Utility overview ..............................................................6-2

v
Entering Setup ...............................................................................................6-4
When the computer is on ......................................................................6-4
When the computer is off ......................................................................6-4
Working with the Setup menus ......................................................................6-5
Configuration/Setup Utility menu .........................................................6-5
Viewing system information and product data ......................................6-6
Changing parameter settings ................................................................6-7
Loading the default settings ..................................................................6-7
Canceling changes ...............................................................................6-8
Exiting Setup .........................................................................................6-8
Setup parameters ..........................................................................................6-9
Devices and I/O Ports ...........................................................................6-9
Start Options .........................................................................................6-12
Halt On ..................................................................................................6-15
Date and Time ......................................................................................6-15
Advanced Setup ...................................................................................6-16
Power Management Setup ...................................................................6-16
Clock Generator Configuration .............................................................6-19
Set Password ........................................................................................6-19
Using other configuration utilities ...................................................................6-20
Part 4. Upgrading and replacing hardware
Preparing to upgrade .................................................................................7-1
Evaluating your new hardware ......................................................................7-2
For conflicts with system resources used by adapter cards .................7-2
For conflicts with other system resources .............................................7-2
Planning your hardware changes ..................................................................7-3
Recording your changes .......................................................................7-3
Resolving resource conflicts ..........................................................................7-4
Using Setup ..........................................................................................7-4
Using the Windows 98 Device Manager ...............................................7-4
Opening the system unit ................................................................................7-5
Taking safety precautions .....................................................................7-5
Removing the top cover ........................................................................7-6
Looking inside the system unit ......................................................................7-7

vi IBM Personal Computer User Guide
Adding and removing adapter cards and drives ..................................... 8-1
Resolving conflicts with installed adapter cards ............................................8-2
Setting modem card configurations ......................................................8-2
Working with the hardware in the system unit ...............................................8-3
Adding and removing adapter cards .............................................................8-4
Installing adapter cards ........................................................................8-4
Removing adapter cards ......................................................................8-5
Removing and adding drives .........................................................................8-6
Identifying signal cable connectors .......................................................8-6
Removing the CD-ROM drive ...............................................................8-11
Removing the hard disk drive ...............................................................8-12
Updating the CMOS settings in Setup ...........................................................8-13
For adapter cards .................................................................................8-13
For Drives .............................................................................................8-13
Adding and replacing system board components .................................. 9-1
Identifying system board parts (machine type 2196) .....................................9-2
Locating system board jumpers and connectors (machine type 2196) .........9-4
Identifying system board parts (machine type 2197 and 6344) .....................9-5
Locating system board jumpers and connectors (machine type 2197
and 6344) ......................................................................................................9-7
Card connector and jumper information ........................................................9-8
Identifying adapter card connectors .....................................................9-8
Setting a jumper ...................................................................................9-8
Upgrading the system memory .....................................................................9-9
Installing memory modules ...................................................................9-9
Removing memory modules .................................................................9-10
Verifying the system memory ...............................................................9-10
Replacing the system battery ........................................................................9-11
Updating the CMOS settings in Setup ...........................................................9-13
Part 5. Troubleshooting
Diagnosing and recovering from problems ............................................. 10-1
Before you panic: some simple fixes .............................................................10-2

vii
Quick problem solving chart ..........................................................................10-6
Solving hardware and software problems .....................................................10-7
Solving hardware problems ..................................................................10-7
Solving software problems ....................................................................10-13
Solving modem problems .....................................................................10-15
Error codes and messages ............................................................................10-17
IBM Diagnostic Programs ..............................................................................10-20
Recovering factory-installed programs and files ............................................10-22
Part 6. Technical reference
Appendix A. Specification tables ...............................................................A-1
Memory module placement ...........................................................................A-1
Memory map ..................................................................................................A-3
System input/output addresses .....................................................................A-4
System interrupts ...........................................................................................A-6
DMA channel assignments ............................................................................A-7
Serial port addresses .....................................................................................A-8
Connector functions .......................................................................................A-9
Appendix B. Modem information ...............................................................B-1
Modem features .............................................................................................B-1
Operating your modem ..................................................................................B-3
Using the Auto Answer feature .............................................................B-3
Disabling Call Waiting ...........................................................................B-4
Modem commands ........................................................................................B-5
Executing commands ...........................................................................B-5
Command format ..................................................................................B-5
AT commands .......................................................................................B-6
Detail for +MS Controls ........................................................................B-9
Extended AT commands ......................................................................B-10
V.42bis commands ...............................................................................B-11
Modem response codes ................................................................................B-12
S registers .....................................................................................................B-13
Appendix C. Monitor terminology ..............................................................C-1

viii IBM Personal Computer User Guide
Appendix D. Warranty ................................................................................. D-1

ix
Notices
References in this publication to IBM products, programs, or services do not imply
that IBM intends to make these available in all countries in which IBM operates. Any
reference to an IBM product, program, or service is not intended to state or imply
that only IBM's product, program, or service may be used. Any functionally
equivalent product, program, or service that does not infringe any of IBM's
intellectual property rights may be used instead of the IBM product, program, or
service. Evaluation and verification of operation in conjunction with other products,
except those expressly designated by IBM, are the user's responsibility.
IBM may have patents or pending patent applications covering subject matter in this
document. The furnishing of this document does not give you any license to these
patents. You can send license inquiries, in writing, to the IBM Director of Licensing,
IBM Corporation, North Castle Drive, Armonk, NY 10504-1785, U.S.A.
IBM makes no representations whatsoever about any non-IBM Web site. When you
access a non-IBM Web site, please understand that it is independent from IBM, and
IBM has no control over the content on that Web site. In additional, a reference to a
non-IBM Web site does not mean that IBM endorses or accepts any responsibility
for the content, or the use, of such Web site. It is up to you to take precautions to
ensure that whatever you select for your use is free of such items as viruses, worms,
trojan horses and other items of a destructive nature. IN NO EVENT WILL IBM BE
LIABLE TO ANY PERTY FOR ANY DIRECT, INDIRECT, SPECIAL OR OTHER
CONSEQUENTIAL DAMAGES FOR ANY OTHER WEBSITE, INCLUDING,
WITHOUT LIMITATION, ANY LOST PROFITS, BUSINESS INTERRUPTION, LOSS
OF PROGRAMS OR OTHER DATA ON YOUR INFORMATION HANDLING
SYSTEM OR OTHERWISE, EVEN IF WE ARE EXPRESSLY ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.

xIBM Personal Computer User Guide
Conventions used in this book
Symbols
The following list contains an explanation of the symbols used in this document.
Highlighting
There are several ways that text is highlighted in this book. Each highlighting
convention has a specific purpose.
Note:
This symbol is used when there is information you
might find especially useful. The information may
also warn you about possible problems you could
encounter.
Attention!
This symbol is used when there is important
information that can help you avoid damage to the
hardware or software that came with your
computer.
Caution! This symbol is used when there is important
information that can help you avoid potential injury.
Danger! This symbol is used when there is important information that can help you avoid the risk of
serious personal injury or death.
Highlight Purpose
Bold
Bold font is used to identify items on the screen
you are instructed to click or double-click. Bold
font is also used in headings, table titles, and
numbered lists.
([DPSOH
Example font is used to show text that you need to
type from your keyboard.
Italic
Italic font is used to show proper names of
programs or books. Italic font is also used in table
footnotes and sidenotes.
"Quotes" Quotation marks are used to identify window,
screen, and heading names.
Underline Underline font is used to call special emphasis to
a particular word or instruction.

xi
Safety information
Installation
The construction of the IBM Personal Computer provides extra protection against
the risk of electrical shock. The IBM computer has a power cord with a three-prong
plug that is required to ground metal parts. It is the responsibility of the person
installing the computer to connect it to a properly grounded electrical outlet. Seek
professional assistance before using an adapter or extension cord; these devices
could interrupt the grounding circuit.
If the computer is connected to an electrical outlet that is incorrectly connected to
the building wiring, serious electrical shock could result.
CONTINUED PROTECTION AGAINST THE RISK OF ELECTRICAL SHOCK:
For continued protection against the risk of electrical shock, follow these steps:
• Connect your computer only to an electrical outlet of the correct voltage. If you
are unsure about the voltage of the electrical outlet you are using, contact your
local power company.
• If your computer has cables other than the power cords, you must connect
them before plugging the power cords into an electrical outlet. Before removing
these cables, you must first unplug the power cords from the outlet.
• If your computer has a telephone connection, do not touch the telephone cords
when there is lightning in the area.
• Do not use or store the computer in an area where it can become wet.
• Make sure all replacement parts have characteristics identical or equivalent to
the original parts. Other parts may not have the same safety features.
• Personal injury or electrical shock may result if you undertake actions other
than those specifically described in this book. This is particularly true if you try
to service or repair the power supply, monitor, or built-in modem. Always refer
service or repairs to qualified service personnel.

xii IBM Personal Computer User Guide
Safety while working with hardware
Each time you open your computer, you must follow specific safety procedures to
ensure that you do not damage your computer. For your safety, and the safety of
your equipment, follow the steps for "Disconnecting your computer" on page xiii
before you remove the cover of the system unit (if included with the model you
purchased).
Connecting your computer
To connect your computer:
1. Turn off the computer and any external devices (such as a monitor or printer)
that have their own power switches.
2. Attach a signal cable to each external device (such as a monitor or printer), and
then connect the other end of the signal cable to the computer.
3. Attachcommunicationcables (suchasmodem cablesornetworkcables)tothe
computer. Then, attach the other ends of the cables to properly wired commu-
nication outlets.
4. Attach the power cords to the computer and any external devices (such as a
monitor or printer), and then connect the other ends of the power cords to prop-
erly grounded electrical outlets.
5. Turn on the computer and any attached devices that have their own power
switches.
To avoid shock hazard:
Danger!
•Do not connect or disconnect any cables or
perform installation, maintenance, or
reconfiguration of this product during an
electrical storm.
•The power cord must be connected to a
properly wired and grounded receptacle.
•Any equipment to which this product will be
attached must also be connected to properly
wired electrical outlets.
•Electrical current from power, telephone, and
communications cables is hazardous. To
avoid shock hazard, use the steps described
in this section to connect and disconnect
cables when installing, moving, or opening
the cover of this product.
•Never install telephone wiring during a
lightning storm

xiii
Disconnecting your computer
To disconnect your computer:
1. Turn off the computer and any attached devices that have their own power
switches.
2. Unplug all power cables from electrical outlets.
3. Disconnect all communication cables (such as modem or network cables) from
communication outlets.
4. Disconnect all cables and cords from the computer; this includes power cords,
signal cables from external devices, communication cables, and any other
cables attached to the computer.
Modem safety information
To reduce the risk of fire, electrical shock, or injury when using telephone
equipment, always follow basic safety precautions, such as:
•Never install telephone wiring during a lightning storm.
•Never install telephone jacks in wet locations unless the jack is specifically
designed for wet locations.
•Never touch uninsulated telephone wires or terminals unless the telephone line
has been disconnected at the network interface.
•Use caution when installing or modifying telephone lines.
•Avoid using a telephone (other than a cordless type) during an electrical storm.
There may be a remote risk of electric shock from lightning.
•Do not use the telephone to report a gas leak in the vicinity of the leak.
Danger! Do not detach the power-supply bracket from the power supply or remove any of the power-supply
screws.
Caution! Be sure to turn off the computer and monitor power switches before cleaning the computer and
monitor screen.

xiv IBM Personal Computer User Guide
Lithium battery notice
To ensure safety:
•Do not recharge, disassemble, heat, or incinerate a lithium battery.
•Replace the battery with an identical or equivalent type lithium battery.
•Do not throw or immerse the battery in water.
•Discard used lithium batteries according to local country dispositions.
Regulatory safety notice for the CD-ROM and DVD-ROM
drive
This notice contains required safety information about the CD-ROM/DVD-ROM
drive in your computer (if included with the model you purchased). The CD-ROM/
DVD-ROM drive is a Class 1 laser product, and Class 1 laser products are not
considered to be hazardous. The design of the laser system and CD/ROM-DVD-
ROM drive ensures that during normal operation, there is no exposure to laser
radiation above Class 1 level.
Please note that the CD-ROM/DVD-ROM drive does not contain any user
adjustable or serviceable parts. Service on this drive should only be performed by a
trained service provider.
Caution! Your computer uses lithium batteries. There may be a risk of fire, explosion, or burns if the batteries are
handled incorrectly.

xv
Laser compliance statement
Some IBM Personal Computer models are equipped from the factory with a CD-
ROM or DVD-ROM drive. CD-ROM/DVD-ROM drives are also sold separately as
options. The CD-ROM/DVD-ROM drive is a laser product. The CD-ROM/DVD-ROM
drive is certified in the U.S. to conform to the requirements of the Department of
Health and Human Services 21 Code of Federal Regulations (DHHS 21 CFR)
Subchapter J for Class 1 laser products. Elsewhere, the drive is certified to conform
to the requirements of the International Electrotechnical Commission (IEC) 825 and
CENELEC EN 60 825 for Class 1 laser products.
When a CD-ROM/DVD-ROM drive is installed, note the following:
Removing the covers of the CD-ROM/DVD-ROM drive could result in exposure to
hazardous laser radiation. There are no serviceable parts inside the CD-ROM/DVD-
ROM drive covers. Do not remove the CD-ROM/DVD-ROM drive covers.
Some CD-ROM/DVD-ROM drives contain an embedded Class 3A or Class 3B laser
diode. Note the following:
Caution! Use of controls or adjustments or performance of procedures other than those specified herein might
result in hazardous radiation exposure.
Danger! Laser radiation when open. Do not stare into the beam, do not view directly with optical instruments,
and avoid direct exposure to the beam.

xvi IBM Personal Computer User Guide
Consignes de sécurité
Installation
La conception de fabrication de l'ordinateur personnel IBM assure une protection
accrue contre les risques d'électrocution. Le PC IBM possède un cordon
d'alimentation équipéd'une fiche àtrois broches qui permet une mise àla terre des
principaux éléments métalliques de la machine. Il incombe au responsable de
l'installation de vérifier le branchement. Si vous devez installer un adaptateur ou une
rallonge, faites appel àun professionnel pour ne pas risquer de créer une rupture
dans le circuit de mise àla terre. Un socle de prise de courant incorrectement relié
àl'alimentation électrique du bâtiment peut être àl'origine d'une électrocution.
Protection contre les risques d'électrocution. Pour vous prémunir contre les
risques d'électrocution, respectez les consignes ci-après:
•Ne branchez l'ordinateur que sur un socle de prise de courant présentant la
tension adéquate.
•Ne branchez le cordon d'alimentation sur le socle de prise de courant qu'après
avoir connectétout autre cordon àla machine. Inversement, débranchez le
cordon d'alimentation du socle de la prise de courant avant de déconnecter tout
autre cordon.
Danger!
Pour éviter tout risque de choc électrique:
Ne manipulez aucun cordon et n’effectuez aucune
opération d’installation, de maintenance ou
reconfiguration de ce produit au cours d’un orage.
Les cordon d’alimentation du présent produit et de
tous les appareils qui lui sont connectés doivent être
branchés sur des socles de prise de courant
correctement câblés et mis àla terre.
Le courant électrique circulant dans les câblés de
communication et les cordons téléphoniques et
d’alimentation est dangereux. pour éviter tout risque
de choc électrique, respectez les consignes de la
présente section pour connecter et déconnecter des
câblés lors de l’installation, du retrait ou de
l’ouverture du panneu de ce produit.

xvii
•Si votre ordinateur est dotéd'un cordon téléphonique, ne manipulez jamais ce
cordon pendant un orage.
•Évitez d'utiliser et de placer votre ordinateur dans un endroit humide.
•Ne remplacez un élément que par un élément identique ou possédant des
caractéristiques équivalentes et équipédes mêmes dispositifs de sécurité.
•Le non-respect de ces consignes peut être àl'origine de blessures ou d'une
électrocution, en particulier si vous intervenez sur le bloc d'alimentation, l'écran
ou le modem intégré. Confiez la maintenance et la réparation de l'ordinateur à
une personne qualifiée.
Consignes de sécuritélors de la manipulation du matériel
Lorsque vous ouvrez l'unitécentrale, il convient de suivre un certain nombre de
consignes de sécuritéafin de ne pas endommager l'ordinateur. Pour votre sécurité
et celle de votre matériel, suivez les instructions de la section “Disconnecting your
computer”on page xiii, avant d'ouvrir l'unitécentrale (le cas échéant).
Branchement de l'ordinateur. Pour brancher l'ordinateur, procédez comme suit:
1. Mettez l'ordinateur hors tension ainsi que tout périphérique (écran ou
imprimante) que vous allez connecter, qui dispose d'un interrupteur
d'alimentation.
2. Connectez tous les câbles (de l'écran, par exemple) àl'ordinateur.
3. Branchez tous les câbles d'interface (par exemple, un câble téléphonique) sur
des socles de prise de courant correctement mis àla terre.
4. Branchez les cordons d'alimentation sur des socles de prise de courant
correctement mis àla terre.
5. Mettez l’ordinateur sous tension ainsi que tout périphérique connecté
disposant d’un interrupteur d’alimentation.
Débranchement de l'ordinateur. Pour débrancher l'ordinateur, procédez comme
suit:
1. Mettez l'ordinateur hors tension ainsi que tout périphérique connecté
disposant d'un interrupteur d'alimentation.

xviii IBM Personal Computer User Guide
2. Débranchez tous les cordons d'alimentation des prises de courant.
3. Débranchez tous les câbles (câble de téléphone, par exemple) de leurs
prises.
4. Débranchez tous câbles de l’ordinateur (les cordons d’alimentation, les
câbles d’entrée-sortie et tous les autres câbles qui pourraient y être
connectés).
Consignes de sécuritérelatives au modem
Lors de l’utilisation de votre matériel téléphonique, il est important de respecter les
consignes ci-après afin de réduire les risques d’incendie, d’électrocution et d’autres
blessures:
•N’intallez jamais de cordons téléphoniques durant un orage.
•Les prises téléphoniques ne doivent pas être installées dan des endroits
humides, exceptési le modéle a étéconçu àcet effet.
Attention!
Votre ordinateur est équipéde piles au lithium.
Prenez garde aux risques d’incendie, d’explosion ou
de brûlures liés àune mauvaise utilisation des piles.
Respectez les consignes de sécuritésuivantesy:
Ne rechargez pas la pile, ne la démontez pas, ne
l’exposez pas àla chaleur et ne la faites pas brûler.
Ne la remplacez que par une pile identique ou de
type équivalent.
Ne la jetez pas àl’eau.
Pour le recyclage ou la mise au rebut des piles au
lithium, reportez-vous àla réglementation en
vigueur.
Danger! No détachez pas le bloc d’alimentation de son support et ne retirez aucune vis du bloc
d’alimentation.
Attention! Veillez àmettre l’ordinateur et l’écran hors tension
avant de procéder àleur nettoyage.

xix
•Ne touchez jamais un cordon téléphonique ou un terminal non isoléavant que
la ligne ait étédéconnectée du réseau téléphonique.
•Soyez toujours prudent lorsque vous procédez àl’intallation ou àla
modification de lignes téléphoniques.
•Si vous devez téléphoner pendant un orage, pour éviter tout risque de choc
électrique, utilisez toujours un téléphone sans fil.
•En cas de fulte de gaz, n’utilisez jamais un téléphone situéàproximitéde la
fuite.
Consignes relatives àla pile au lithium
•Ne rechargez pas la pile, ne la démontez pas, ne l’exposez pas àla chaleur et
ne la faite pas brûler.
•Ne la remplacez que par une pille identique ou de type équivalent.
•Ne la jetez pas àl’eau.
•Pour le recyclage ou la mise au rebut des piles au lithium, reportez-vous àla
réglementation en vigueur.
Consignes de sécuritépour l’unitéde CD-ROM et de DVD-ROM
La présente consigne contient les informations de sécuritérelatives àl’unitéde CD-
ROM de votre ordinateur (le cas échéant). L’unitéde CD-ROM est un produit àlaser
de classe 1. Les produits de classe 1 ne sont pas considérés comme dangereux. Le
système àlaser et l’unitéde CD-ROM ont étéconçus de façon telle qu’il n’existe
aucun risque d’exposition àun rayonnement laser de niveau supérieur àla classe 1
dans des conditions normales d’utilisation.
Veuillez noter qu’aucune pièce de l’unitéde CD-ROM n’est réglable ni réparable. Ne
confiez la réparation de cette unitéqu’à une personne qualifiée.
Attention!
Votre ordinateur est équipéde piles au
lithium. Prenez garde aux risques
d’incenjdie, d’explosion ou de brûlures llés à
une mauvaise utilisation des piles.
Respectez les consignes de sécurité
suivantesy:

xx IBM Personal Computer User Guide
Conformitéaux normes relatives aux appareils laser.
Certains modèles d’ordinateurs personnels sont équipés d’origine d’une unitéde
CD-ROM ou de DVD-ROM. Mais ces unités sont également vendues séparément
en tant qu’options. L’unitéde CD-ROM/DVD-ROM est un appareil àlaser. Aux Etat-
Unis, l’unitéde CD-ROM/DVD-ROM est certifiée conforme aux normes indiquées
dans le sous-chapitre J du DHHS 21 CFR relatif aux produits àlaser de classe 1.
Dans les autres pays, elle est certifiée être un produit àlaser de classe 1 conforme
aux normes CDI 825 et CENELEC EN 60 825.
Lorsqu’une unitéde CD-ROM est installée, tenez compte des remarques suivantes:
Attention!
Pour éviter tout risque d’exposition au rayon
laser, respectez les consignes de réglage et
d’utilisation des commandes, ainsi que les
procédures décrites.
L’ouverture del’unitéde CD-ROM/DVD-ROM
peut entraîner un risque d’exposition au
rayon laser. Pour toute intervention, faites
appel àdu personnel qualifié.
Danger!
Rayonnement laser lorsque le carter est
ouvert. Évitez toute exposition directe des
yeux au rayon laser. Évitez de regarder
fixement le faisceau ou de l’observer àl’aide
d’instruments optiques.
