IBM IC25N040ATCS04 - Travelstar 40 GB Hard Drive User manual

IBM
Hard disk drive specifications
Travelstar 60GH & 40GN
2.5 inch ATA/IDE hard disk drive
IC25N010ATCS04
IC25N020ATCS04
IC25N030ATCS04
IC25N040ATCS04
IC25T060ATCS05Models:
Revision 3.0 22 January 2002
S07N-7681-09 Publication # 1540
IBM storage products - official published specifications

IBM
Hard disk drive specifications
Travelstar 60GH & 40GN
2.5 inch ATA/IDE hard disk drive
IC25N010ATCS04
IC25N020ATCS04
IC25N030ATCS04
IC25N040ATCS04
IC25T060ATCS05Models:
Revision 3.0 22 January 2002
S07N-7681-09 Publication # 1540

1st Edition (Revision 0.1) S07N-7681-00 (19 September 2001) Preliminary
2nd Edition (Revision 0.2) S07N-7681-01 (23 October 2001) Preliminary
3rd Edition (Revision 0.3) S07N-7681-02 (25 October 2001) Preliminary
4th Edition (Revision 0.4) S07N-7681-03 (29 October 2001) Preliminary
5th Edition (Revision 0.5) S07N-7681-04 (1 November 2001) Preliminary
6th Edition (Revision 0.6) S07N-7681-05 (2 November 2001) Preliminary
7th Edition (Revision 0.7) S07N-7681-06 (5 November 2001) Preliminary
8th Edition (Revision 1.0) S07N-7681-07 (16 November 2001)
9th Edition (Revision 2.0) S07N-7681-08 (4 December 2001)
10th Edition (Revision 3.0) S07N-7681-09 (22 January 2002)
The following paragraph does not apply to the United Kingdom or any country where such provisions are
inconsistent with local law: INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS
PUBLICATION "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, IN-
CLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer or express or implied warranties in certain
transactions, therefore, this statement may not apply to you.
This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the
information herein; these changes will be incorporated in new editions of the publication. IBM may make improve-
ments and changes in any product or program described in this publication at any time.
It is possible that this publication may contain reference to, or information about, IBM products (machines and
programs), programming, or services that are not announced in your country. Such references or information must
not be construed to mean that IBM intends to announce such IBM products, programming, or services in your
country.
Technical information about this product is available by contacting the local IBM representative or by using the
following:
Internet: http://www.ibm.com/harddrive
IBM may have patents or pending patent applications covering subject matter in this document. The furnishing of
this document does not give you any license to these patents. You can send license inquiries, in writing, to the IBM
Director of Commercial Relations, IBM Corporation, Armonk, NY 10577.
©Copyright International Business Machines Corporation 2002. All rights reserved.
Note to US Government Users—Documentation related to restricted rights—Use, duplication or disclosure is subject
to restrictions set forth in GSA ADP Schedule Contract with IBM Corp.

Table of contents
286.4.4 Service life and usage condition ...................................... 286.4.3 Cable noise interference ........................................... 286.4.2 Failure prediction (S.M.A.R.T.) ....................................... 286.4.1 Data reliability ................................................... 286.4 Reliability ........................................................... 266.3 Start up Current ...................................................... 266.2.1 Power consumption efficiency ....................................... 256.2 DC power requirements ................................................ 246.1.4 Magnetic fields ................................................... 246.1.3 Conductive noise ................................................. 246.1.2 Radiation noise .................................................. 236.1.1 Temperature and humidity .......................................... 236.1 Environment ......................................................... 236.0 Specification ........................................................ 215.8 ECC ............................................................... 205.7.3 Recovered read errors ............................................. 205.7.2 Nonrecoverable read error .......................................... 205.7.1 Nonrecovered write errors .......................................... 205.7 Automatic reallocation .................................................. 205.6 Error recovery ........................................................ 205.5 Data buffer test ....................................................... 205.4 WRITE safety ........................................................ 195.3 Equipment status ..................................................... 195.2 Write Cache ......................................................... 195.1 Data loss on power off ................................................. 195.0 Data integrity ........................................................ 174.4.3 Operating modes ................................................. 154.4.2 Mechanical positioning ............................................. 144.4.1 Command overhead .............................................. 144.4 Performance characteristics ............................................. 124.3 Cylinder allocation by model number ....................................... 124.2 Data sheet .......................................................... 114.1 Formatted capacity by model number ...................................... 114.0 Fixed disk characteristics ............................................. 93.2 Head disk assembly data ................................................ 93.1 Control Electronics ..................................................... 93.0 Fixed disk subsystem description ........................................
7
Part 1. Functional specification ........................................
52.0 General features ...................................................... 31.4 Drive handling precautions ............................................... 31.3 General caution ....................................................... 31.2 References ........................................................... 11.1 Abbreviations ......................................................... 11.0 General .............................................................
viiFigures ................................................................
Travelstar 60GH & 40GN hard disk drive specifications
iii

638.1 Introduction .......................................................... 638.0 General ............................................................
61
Part 2. Interface specification ........................................
597.11 Addressing of HDD registers ............................................ 587.10.1 Drive default address setting ....................................... 587.10 Drive address setting ................................................. 577.9.8 Host Terminating Write DMA ........................................ 567.9.7 Device Terminating Write DMA ...................................... 557.9.6 Device Pausing Write DMA ......................................... 547.9.5 Initiating Write DMA ............................................... 537.9.4 Device Terminating Read DMA ...................................... 527.9.3 Host Terminating Read DMA ........................................ 517.9.2 Host Pausing Read DMA ........................................... 507.9.1 Initiating Read DMA ............................................... 507.9 Ultra DMA timings ..................................................... 497.8 Multiword DMA timings ................................................. 487.7 PIO timings .......................................................... 477.6 Reset timings ........................................................ 477.5 Interface logic signal levels .............................................. 447.4 Signal descriptions .................................................... 427.3 Signal definitions ...................................................... 417.2 Interface connector .................................................... 417.1 Cabling ............................................................. 417.0 Electrical interface specifications ....................................... 406.11 Packaging .......................................................... 406.10.5 Secondary circuit protection ........................................ 406.10.4 Flammability ................................................... 406.10.3 German Safety Mark ............................................. 406.10.2 IEC compliance ................................................. 406.10.1 UL and CSA approval ............................................ 406.10 Safety ............................................................. 396.9.2 C-Tick Mark ..................................................... 396.9.1 CE Mark ....................................................... 396.9 Electromagnetic compatibility ............................................ 396.8 Identification labels .................................................... 386.7.2 Discrete tone penalty .............................................. 376.7.1 Sound power level ................................................ 376.7 Acoustics ........................................................... 366.6.4 Nonoperating shock ............................................... 356.6.3 Operating shock ................................................. 356.6.2 Nonoperating vibration ............................................. 346.6.1 Operating vibration ............................................... 346.6 Vibration and shock ................................................... 336.5.5 Load/unload mechanism ........................................... 326.5.4 Mounting orientation .............................................. 326.5.3 Connector and jumper description .................................... 316.5.2 Mounting hole locations ............................................ 316.5.1 Physical dimensions and weight ...................................... 316.5 Mechanical specifications ............................................... 296.4.6 Load/unload ..................................................... 296.4.5 Preventive maintenance ............................................
Travelstar 60GH & 40GN hard disk drive specifications
iv

9011.9.6 Command table ................................................. 8711.9.5 Operation example ............................................... 8711.9.4 Master Password Revision Code .................................... 8611.9.3 Password ..................................................... 8611.9.2 Security level ................................................... 8611.9.1 Security Mode .................................................. 8611.9 Security Mode Feature Set ............................................. 8511.8.6 S.M.A.R.T. operation with power management modes .................... 8411.8.5 S.M.A.R.T. commands ............................................ 8411.8.4 Threshold exceeded condition ...................................... 8411.8.3 Attribute thresholds .............................................. 8411.8.2 Attribute values ................................................. 8411.8.1 Attributes ...................................................... 8411.8 S.M.A.R.T. Function .................................................. 8211.7.4 Transition Time ................................................. 8211.7.3 Low Power Idle Mode ............................................. 8211.7.2 Active Idle Mode ................................................ 8211.7.1 Performance Idle Mode ........................................... 8211.7 Advanced Power Management (ABLE-3) feature ............................. 8111.6.7 Initial Power Mode at Power On ..................................... 8111.6.6 Interface Capability for Power Modes ................................. 8111.6.5 Status ........................................................ 8111.6.4 Standby timer .................................................. 8011.6.3 Standby/Sleep command completion timing ............................ 8011.6.2 Power management commands ..................................... 8011.6.1 Power Mode ................................................... 8011.6 Power management features ........................................... 7911.5.2 LBA addressing mode ............................................ 7811.5.1 Logical CHS addressing mode ...................................... 7811.5 Sector Addressing Mode ............................................... 7811.4.3 Required power-off sequence ...................................... 7711.4.2 Emergency unload ............................................... 7711.4.1 Load/Unload ................................................... 7711.4 Power-off considerations ............................................... 7611.3 Diagnostic and Reset considerations ...................................... 7511.2 Register initialization .................................................. 7311.1 Reset response ...................................................... 7311.0 General operation descriptions ........................................ 7210.13 Status Register ..................................................... 7210.12 Sector Number Register .............................................. 7110.11 Sector Count Register ................................................ 7110.10 Features Register ................................................... 7110.9 Error Register ....................................................... 7010.8 Device/Head Register ................................................. 7010.7 Drive Address Register ................................................ 6910.6 Device Control Register ............................................... 6910.5 Data Register ....................................................... 6810.4 Cylinder Low Register ................................................. 6810.3 Cylinder High Register ................................................ 6810.2 Command Register ................................................... 6810.1 Alternate Status Register .............................................. 6710.0 Registers .......................................................... 659.0 Deviations from standard .............................................. 638.2 Terminology .........................................................
Travelstar 60GH & 40GN hard disk drive specifications
v

16413.31 Sleep (E6h/99h) ................................................... 16313.30 Set Multiple (C6h) .................................................. 16113.29 Set Max ADDRESS (F9h) ............................................ 15913.28 Set Features (EFh) ................................................. 15813.27 Sense Condition (F0h: vendor specific) .................................. 15713.26 Seek (7xh) ....................................................... 15513.25 Security Unlock (F2h) ............................................... 15313.24 Security Set Password (F1h) .......................................... 15213.23 Security Freeze Lock (F5h) ........................................... 15013.22 Security Erase Unit (F4h) ............................................ 14913.21 Security Erase Prepare (F3h) ......................................... 14813.20 Security Disable Password (F6h) ....................................... 14713.19 Recalibrate (1xh) ................................................... 14513.18 Read Verify Sectors (40h/41h) ........................................ 14313.17 Read Sectors (20h/21h) ............................................. 14113.16 Read Native Max ADDRESS (F8h) ..................................... 13913.15 Read Multiple (C4h) ................................................ 13713.14 Read Long (22h/23h) ............................................... 13513.13 Read DMA (C8h/C9h) ............................................... 13413.12 Read Buffer (E4h) .................................................. 13313.11 Initialize Device Parameters (91h) ...................................... 13213.10 Idle Immediate (E1h/95h) ............................................ 13113.9 Idle (E3h/97h) ...................................................... 12213.8 Identify Device (ECh) ................................................ 12013.7 Format Unit (F7h: vendor specific) ....................................... 11913.6 Format Track (50h: vendor specific) ..................................... 11813.5 Flush Cache (E7h) .................................................. 11713.4 Execute Device Diagnostic (90h) ........................................ 11613.3 Enable/Disable Delayed Write (FAh: vendor specific) ........................ 11313.2.4 DEVICE CONFIGURATION SET (subcommand C3h) ................... 11313.2.3 DEVICE CONFIGURATION IDENTIFY (subcommand C2h) ............... 11313.2.2 DEVICE CONFIGURATION FREEZE LOCK (subcommand C1h) ........... 11213.2.1 DEVICE CONFIGURATION RESTORE (subcommand C0h) .............. 11213.2 Device Configuration Overlay (B1h) ..................................... 11113.1 Check Power Mode (E5h/98h) .......................................... 10713.0 Command descriptions ............................................. 10612.4 DMA Data Transfer commands ......................................... 10512.3 Nondata commands ................................................. 10312.2 Data Out commands ................................................. 10112.1 Data In commands .................................................. 10112.0 Command protocol ................................................. 9911.15.1 Auto Reassign Function .......................................... 9911.15 Reassign Function .................................................. 9811.14.1 Enable/Disable Delayed Write command ............................. 9811.14 Delayed Write function (vendor specific) .................................. 9811.13 Write Cache function ................................................. 9711.12 Seek Overlap ...................................................... 9611.11.3 Exceptions in Address Offset Mode ................................. 9611.11.2 Identify Device Data ............................................. 9511.11.1 Enable/Disable Address Offset Mode ................................ 9511.11 Address Offset Feature (vendor specific) .................................. 9311.10.2 Set Max security extension commands ............................... 9211.10.1 Example for operation (In LBA Mode) ................................ 9211.10 Protected Area Function ..............................................
Travelstar 60GH & 40GN hard disk drive specifications
vi

201Index ................................................................ 20015.3 Changes from Travelstar 48GH, 30GN & 15GN ............................. 19915.2 SET FEATURES Command Support Coverage ............................. 19715.1 Commands Support Coverage ......................................... 19715.0 Appendix ......................................................... 19514.0 Time-out values ................................................... 19313.40 Write Verify (3Ch: vendor specific) ..................................... 19113.39 Write Sectors (30h/31h) ............................................. 18913.38 Write Multiple (C5h) ................................................ 18713.37 Write Long (32h/33h) ............................................... 18513.36 Write DMA (CAh/CBh) ............................................... 18413.35 Write Buffer (E8h) .................................................. 18313.34 Standby Immediate (E0h/94h) ......................................... 18213.33 Standby (E2h/96h) ................................................. 18113.32.6 Error reporting ................................................ 18013.32.5 Self-test log data structure ....................................... 17713.32.4 S.M.A.R.T. error log sector ....................................... 17513.32.3 Device Attribute Thresholds data structure ........................... 17013.32.2 Device Attributes Data Structure .................................. 16613.32.1 S.M.A.R.T. Function Subcommands ................................ 16513.32 S.M.A.R.T. Function Set (B0h) ........................................
Travelstar 60GH & 40GN hard disk drive specifications
vii

This page intentionally left blank.

Figures
59Figure 49. I/O address map ................................................ 58Figure 48. Drive address setting ............................................. 57Figure 47. Ultra DMA cycle timings (Host Terminating Write) ........................ 56Figure 46. Ultra DMA cycle timings (Device Terminating Write) ...................... 55Figure 45. Ultra DMA cycle timings (Device Pausing Write) ......................... 54Figure 44. Ultra DMA cycle timings (Initiating Write) .............................. 53Figure 43. Ultra DMA cycle timings (Device Terminating Read) ...................... 52Figure 42. Ultra DMA cycle timings (Host Terminating Read) ........................ 51Figure 41. Ultra DMA cycle timings (Host Pausing Read) .......................... 50Figure 40. Ultra DMA cycle timings (Initiating Read) .............................. 49Figure 39. Multiword DMA cycle timings ....................................... 48Figure 38. PIO cycle timings ................................................ 47Figure 37. System reset timings ............................................. 43Figure 36. Special signal definitions for Ultra DMA ............................... 42Figure 35. Signal definition ................................................. 41Figure 34. Interface connector pin assignments ................................. 37Figure 33. Weighted sound power ............................................ 36Figure 32. Nonoperating shock .............................................. 35Figure 31. Operating shock ................................................. 35Figure 30. Random Vibration PSD Profile Breakpoints (nonoperating) ................. 34Figure 29. Swept sine vibration .............................................. 34Figure 28. Random vibration PSD profile breakpoints (operating) .................... 32Figure 27. Mounting hole locations of all models except 60 GB model. ............... 31Figure 26. Mounting hole locations of the 60 GB model. .......................... 31Figure 25. Physical dimensions and weight ..................................... 27Figure 24. Typical current wave form at start up of 20 GB model) .................... 27Figure 23. Typical current wave form at start up of 40 GB model .................... 26Figure 22. Typical current wave form at start up of 60 GB model ..................... 26Figure 21. Power consumption efficiency ...................................... 25Figure 20. DC Power requirements ........................................... 24Figure 19. Magnetic flux density limits ......................................... 23Figure 18. Limits of temperature and humidity ................................... 23Figure 17. Environmental condition ........................................... 21Figure 16. Examples of error cases. .......................................... 17Figure 15. Drive ready time ................................................. 17Figure 14. Operating mode ................................................. 16Figure 13. Drive ready time ................................................. 16Figure 12. Latency time ................................................... 16Figure 11. Single track seek time ............................................ 15Figure 10. Full stroke seek time ............................................. 15Figure 9. Mechanical positioning performance ................................... 14Figure 8. Performance characteristics ......................................... 13Figure 7. Cylinder allocation — all models except 60 GB (low TPI format) .............. 13Figure 6. Cylinder allocation — all models except 60 GB (high TPI format) ............. 12Figure 5. Cylinder allocation of 60 GB model .................................... 12Figure 4. Data sheet ...................................................... 11Figure 3. Formatted capacity by model number. ................................. 3Figure 2. Handling Precaution 2 .............................................. 3Figure 1. Handling Precaution 1 ..............................................
Travelstar 60GH & 40GN hard disk drive specifications
ix

145Figure 103. Read Verify Sectors command (40h/41h) ............................ 143Figure 102. Read Sectors command (20h/21h) ................................. 141Figure 101. Read Native Max ADDRESS (F8h) ................................. 139Figure 100. Read Multiple command (C4h) .................................... 137Figure 99. Read Long command (22h/23h) .................................... 135Figure 98. Read DMA command (C8h/C9h) ................................... 134Figure 97. Read Buffer command (E4h) ...................................... 133Figure 96. Initialize Device Parameters command (91h) .......................... 132Figure 95. Idle Immediate command (E1h/95h) ................................. 131Figure 94. Idle command (E3h/97h) ......................................... 130Figure 93. Number of cylinders/heads/sectors by model. .......................... 129Figure 92. Identify device information. (Part 7 of 7) .............................. 128Figure 91. Identify device information. (Part 6 of 7) .............................. 127Figure 90. Identify device information. (Part 5 of 7) .............................. 126Figure 89. Identify device information. (Part 4 of 7) .............................. 125Figure 88. Identify device information. (Part 3 of 7) .............................. 124Figure 87. Identify device information. (Part 2 of 7) .............................. 123Figure 86. Identify device information. (Part 1 of 7) .............................. 122Figure 85. Identify Device command (ECh) .................................... 120Figure 84. Format Unit command (F7h) ....................................... 119Figure 83. Format Track command (50h) ..................................... 118Figure 82. Flush Cache command (E7h) ...................................... 117Figure 81. Execute Device Diagnostic command (90h) ........................... 116Figure 80. Enable/Disable Delayed Write command (FAh) ........................ 115Figure 79. DCO error information definition .................................... 114Figure 78. Device Configuration Overlay Data structure .......................... 112Figure 77. Device Configuration Overlay Features register values ................... 112Figure 76. Check Power Mode Command (E5h/98h) ............................. 111Figure 75. Check Power Mode command (E5h/98h) ............................. 109Figure 74. Command Set (Subcommand) ..................................... 108Figure 73. Command set (2 of 2) ............................................ 107Figure 72. Command set (1 of 2) ............................................ 97Figure 71. Seek overlap ................................................... 95Figure 70. Device address map before and after Set Feature ....................... 94Figure 69. Set Max security mode transition .................................... 93Figure 68. Set Max SET PASSWORD data content ............................... 91Figure 67. Command table for device lock operation (2 of 2) ........................ 90Figure 66. Command table for device lock operation (1 of 2) ........................ 89Figure 65. Password lost .................................................. 88Figure 64. Usual operation for POR .......................................... 87Figure 63. Initial setting .................................................... 81Figure 62. Power conditions ................................................ 77Figure 61. Device behavior by ATA commands. ................................. 76Figure 60. Reset error register values ......................................... 75Figure 59. Diagnostic Codes ................................................ 75Figure 58. Default Register Values ........................................... 74Figure 57. Reset response table ............................................. 72Figure 56. Status Register ................................................. 71Figure 55. Error Register .................................................. 70Figure 54. Device/Head Register ............................................ 70Figure 53. Drive Address Register ........................................... 69Figure 52. Device Control Register ........................................... 68Figure 51. Alternate Status Register .......................................... 67Figure 50. Register Set ....................................................
Travelstar 60GH & 40GN hard disk drive specifications
x

199Figure 144. SET FEATURES command coverage ............................... 198Figure 143. Command coverage (2 of 2) ...................................... 197Figure 142. Command coverage (1 of 2) ...................................... 195Figure 141. Time-out values ............................................... 191Figure 140. Write Sectors command (30h/31h) ................................. 189Figure 139. Write Multiple command (C5h) .................................... 187Figure 138. Write Long command (32h/33h) ................................... 185Figure 137. Write DMA command (CAh/CBh) .................................. 184Figure 136. Write Buffer command (E8h) ..................................... 183Figure 135. Standby Immediate command (E0h/94h) ............................ 182Figure 134. Standby command (E2h/96h) ..................................... 181Figure 133. S.M.A.R.T. Error Codes ......................................... 180Figure 132. Self-test log data structure ....................................... 179Figure 131. Error data structure ............................................ 178Figure 130. Command data structure ........................................ 177Figure 129. Error log data structure .......................................... 177Figure 128. S.M.A.R.T. error log sector ....................................... 176Figure 127. Individual Threshold Data Structure ................................ 175Figure 126. Device Attribute Thresholds Data Structure .......................... 172Figure 125. Status Flag definitions .......................................... 171Figure 124. Individual Attribute Data Structure ................................. 170Figure 123. Device Attribute Data Structure ................................... 167Figure 122. Log sector addresses ........................................... 165Figure 121. S.M.A.R.T. Function Set command (B0h) ............................ 164Figure 120. Sleep command (E6h/99h) ....................................... 163Figure 119. Set Multiple command (C6h) ..................................... 161Figure 118. Set Max ADDRESS (F9h) ........................................ 159Figure 117. Set Features command (EFh) ..................................... 158Figure 116. Sense Condition Command (F0h) .................................. 157Figure 115. Seek command (7xh) ........................................... 156Figure 114. Security Unlock information ...................................... 155Figure 113. Security Unlock command (F2h) ................................... 154Figure 112. Security Set Password information ................................. 153Figure 111. Security Set Password command (F1h) ............................. 152Figure 110. Security Freeze Lock command (F5h) .............................. 150Figure 109. Erase Unit information .......................................... 150Figure 108. Security Erase Unit command (F4h) ................................ 149Figure 107. Security Erase Prepare command (F3h) ............................. 148Figure 106. Password Information for Security Disable Password command ........... 148Figure 105. Security Disable Password command (F6h) .......................... 147Figure 104. Recalibrate command (1xh) ......................................
Travelstar 60GH & 40GN hard disk drive specifications
xi

This page intentionally left blank.

1.0 General
This document describes the specifications of the IBM Travelstar 60GH & 40GN, a 2.5-inch hard disk
drive with ATA/IDE interface:
4,2009.510IC25N010ATCS04Travelstar 40GN
4,2009.520IC25N020ATCS04Travelstar 40GN
4,2009.530IC25N030ATCS04Travelstar 40GN
4,2009.540IC25N040ATCS04Travelstar 40GN
5,40012.560IC25T060ATCS05Travelstar 60GH
Rotation speed (rpm)Height (mm)Capacity (GB)Model NumberDrive name
Part 1 of this document beginning on page 7 defines the hardware functional specification. Part 2 of this
document beginning on page 61 defines the interface specification
These specifications are subject to change without notice.
1.1 Abbreviations
hard disk driveHDD
hexadecimalh
groundGND
(32 ft/sec)2per HertzG2/Hz
1 000 000 000 bits per square inchGb/sq.in.
1 000 000 000 bytesGB
1 000 000 000 bitsGb
gravity, a unit of forceG
field replacement unitFRU
Federal Communications CommissionFCC
electrostatic dischargeESD
Error Recovery ProcedureERP
electromagnetic compatibilityEMC
European Economic CommunityEEC
error correction codeECC
Direct Memory AccessDMA
Drive Fitness TestDFT
direct currentDC
cylinderCyl
Canadian-Underwriters LaboratoryC-UL
Canadian Standards AssociationCSA
degrees Celsius°C
Basic Input/Output SystemBIOS
unit of sound powerBels
Advanced Technology AttachmentATA
Advanced TechnologyAT
alternating currentAC
ampA
inch"
64 x 1024 bytes64 KB
32 x 1024 bytes32 KB
MeaningAbbreviation
Travelstar 60GH & 40GN hard disk drive specifications
1

transistor-transistor tristate logic3-state
wattW
Verband Deutscher ElectrotechnikerVDE
voltV
Underwriters LaboratoryUL
transistor-transistor logicTTL
trackTrk.
tracks per inchTPI
Self-monitoring, analysis, and reporting technologyS.M.A.R.T
secondary low voltageSELV
sectors per trackSect/Trk
secondsec
read/writeR/W
resetRST
revolutions per minuteRPM
root mean squareRMS
per cent relative humidity% RH
relative humidityRH
radio frequency interferenceRFI
radiated electromagnetic susceptibilityRES
power spectral densityPSD
peak-to-peakp-p
part numberP/N
populationPop.
power on hoursPOH
PIO
Open Drain Programmed Input/OutputOD
OutputO
oscillations per minuteoct/min
numberNo. or #
microsecond
us, µs
millisecondms
millimetermm
Machine Level ControlMLC
megahertzMHz
1,000 ,00 bits per square inchMb/sq.in.
1,000,000 bytes per secondMB/sec
1,000,000 Bit per secondMb/sec
1,000,000 Bit per secondMbps
1,000,000 bytesMB
maximummax. or Max.
meterm
unit of A-weighted sound powerLw
logical block addressingLBA
kilohertzKHz
kilogram (force)-centimeterkgf-cm
1,000 Bit Per InchKbpi
1,000 bytesKB
International Standards OrganizationISO
Input/OutputI/O
impedanceimped
integrated lead suspensionILS
InputI
hertzHz
Travelstar 60GH & 40GN hard disk drive specifications
2

1.2 References
ATA/ATAPI-5 (T13/1321D Revision 3)
1.3 General caution
!Do not apply force to the top cover (See figure below).
!Do not cover the breathing hole on the top cover (See figure below).
!Do not touch the interface connector pins or the surface of the printed circuit board.
!The drive can be damaged by shock or ESD (Electric Static Discharge). Any damages incurred to
the drive after removing it from the shipping package and the ESD protective bag are the responsi-
bility of the user
1.4 Drive handling precautions
Do not press on the drive cover during handling.
Figure 1. Handling Precaution 1
Figure 2. Handling Precaution 2
Travelstar 60GH & 40GN hard disk drive specifications
3

This page intentionally left blank.

2.0 General features
"2.5-inch, 12.5- and 9.5-mm Height MCC Compliance
"Formatted capacities of 60 GB, 40 GB, 30 GB, 20 GB, and 10 GB
"512 bytes/sector
"AT Interface (Enhanced IDE) conforming to ATA/ATAPI-5
"Integrated controller
"No-ID recording format
"Coding : 96/104 MTR
"Multi zone recording
"Enhanced ECC On-The-Fly
#40 bytes 3 way Interleaved Reed Solomon Code
#5 bytes per interleave On-The-Fly correction
"Segmented Buffer with write cache
#2 MB - Upper 280 KB is used for firmware
"Fast data transfer rate (up to 100 MB/s)
"Media data transfer rate (max):
#60-GB model - 261 Mb/s
#all other models - 245 Mb/s
"Average seek time: 12 ms for read
"Closed-loop actuator servo (Embedded Sector Servo)
"Rotary voice coil motor actuator
"Load/Unload mechanism
"Mechanical latch
"Adaptive power save control
#60-GB model - 0.9 Watts at idle state
#all other models - 0.65 Watts at idle state
"Power on to ready
#60-GB model - 5.0 sec
#all other models - 3.0 sec
"Operating shock
#60-GB model - 150 G/2ms
#all other models - 200 G/2ms
"Nonoperating shock
#60-GB model - 700 G/1ms
#all other models - 800 G/1ms
Travelstar 60GH & 40GN hard disk drive specifications
5

This page intentionally left blank.

Part 1. Functional specification
Travelstar 60GH & 40GN hard disk drive specifications
7
