IBM ThinkPad Dock II User manual

Dock II (3546)
General Checkout . . . . . . . . . . . . . . . . 390
Checking the Installed Devices ........ 397
Power Supply . . . . . . . . . . . . . . . . 398
Printer . . . . . . . . . . . . . . . . . . . 401
External Display . . . . . . . . . . . . . . . 402
External Keyboard . . . . . . . . . . . . . . 404
How To Run the Diagnostics ......... 405
Running Diagnostics . . . . . . . . . . . . . 410
Symptom-to-FRU Index . . . . . . . . . . . . . 416
Miscellaneous Symptoms . . . . . . . . . . 417
Numeric Error Codes ............. 418
FRU Codes . . . . . . . . . . . . . . . . . 419
Undetermined Problems . . . . . . . . . . . 421
Product Overview . . . . . . . . . . . . . . . . 422
Security . . . . . . . . . . . . . . . . . . . 422
Main Card . . . . . . . . . . . . . . . . . . 423
Riser Card . . . . . . . . . . . . . . . . . 425
Power Supply . . . . . . . . . . . . . . . . 426
Specifications . . . . . . . . . . . . . . . . . . 427
FRU Removals and Replacements ........ 428
1010 Main Cabinet Group .......... 429
1020 Audio Card . . . . . . . . . . . . . . 431
1030 Power Supply Unit ........... 432
1040 Riser Card . . . . . . . . . . . . . . 436
1050 Main Card . . . . . . . . . . . . . . . 437
1060 Keylock Assembly . . . . . . . . . . . 439
1070 Micro Switch Group .......... 440
1080 Solenoid Group . . . . . . . . . . . . 441
1090 Tray Unit Group ............ 442
1100 Blank Cover Group .......... 444
1110 Speaker and Speaker Cover Group . . . 446
1120 Cable Group . . . . . . . . . . . . . 448
Locations . . . . . . . . . . . . . . . . . . . . 450
Parts Listing . . . . . . . . . . . . . . . . . . 458
Special Tools . . . . . . . . . . . . . . . . 461
 Copyright IBM Corp. 1995 389

General Checkout
The IBM* ThinkPad* Dock II (hereinafter referred to as the
Dock II ) expands the capability of the IBM ThinkPad 360,
750, and 755 notebooks (hereinafter referred to as the
computer ), using the IBM AT* Bus architecture.
The diagnostic tests are intended to test
only IBM
products. Non-IBM products, prototype cards, or modified
options can give false errors and invalid system responses.
Warning
Drives in the computer that you are servicing
might have been rearranged or the drive startup
sequence might have been altered. Be
extremely careful during write operations such as
copying, saving, or formatting. Data or programs
can be written over if you select an incorrect
drive.
Only certified and trained personnel should
service the computer.
The parts exchange form or parts return form
attached to the FRU to be returned must
describe the following:
– Name and phone number of servicer (in
print).
– Date serviced.
– Date failed.
– Date purchased.
– Failure symptoms, error codes, and beep
symptoms.
– Procedure index and page number on which
the symptom or error code is described.
– The failing FRU name and part number.
– Machine type, model number, and serial
number.
– Customer name and address
Checkout Guide: During the warranty period, the
customer may be responsible for repair costs if the
computer damage was caused by misuse, accident,
modification, unsuitable physical or operating environment,
or improper maintenance by the customer.
The following list provides some common items that are
not covered under warranty and some symptoms that may
indicate the system was subjected to stresses beyond
normal use.
390 IBM Mobile Systems HMM - Volume 1

The following are not covered under warranty:
LCD panel cracked by applying excessive force or
being dropped
Scratched (cosmetic) parts
Cracked or broken plastic parts, latches, or
connectors caused by excessive force
Damage caused by liquid spilled into the system
Damage caused by improperly inserting a PCMCIA
card or installation of a incompatible card
Damage due to foreign material in the FDD or FDD
bay
If the following symptoms are present, they may
indicate damage caused by non-warranted activity:
Missing parts may be a symptom of unauthorized
service or modification.
HDD spindles become noisy if subjected to high
levels of force or being dropped
I9990303 errors may be caused by exposure to
extreme magnetic fields
Overall Procedure
1. Check that the computer is correctly docked
to Dock II.
2. If possible, make sure that there are no hardware
setting conflicts, such as in interrupt levels, memory
addresses, DMA channels, and I/O addresses.
3. Check that the SCSI ID is set correctly.
4. Test and correct any computer problem before you
test it with Dock II. Use the computer documentation
to resolve any computer problems.
5. Test the computer with the external keyboard,
external display, mouse, and parallel and serial
device connectors. (Use the keyboard/mouse
connector to test the external keyboard and mouse.)
If no problems are found, connect the external
keyboard, mouse, parallel and serial devices to Dock
II, then connect Dock II to the computer and test it.
6. If external devices are attached to Dock II, such as an
audio amplifier, check the device by referring to the
manual shipped with the device.
7. If the user did not bring the computer with
Dock II when service is needed, use a computer that
works correctly with Dock II.
How to Diagnose Combined FRUs: If an
adapter or device consists of more than one FRU, an error
code can be caused by any of the FRUs. Before replacing
the adapter or device, remove the FRUs, one by one, to
see if the symptom changes.
Dock II (3546) 391

(CONTINUED)
How to Use Error Messages: The error
messages caused by Dock II, the attached computer, and
the attached devices are displayed on the LCD of the
attached computer or on the external display. Use the
error codes displayed on the screen to diagnose failures.
If more than one error code is displayed, begin the
diagnosis with the first error code. The cause of the first
error code can result in false error codes being displayed.
If the error code is displayed, see the “Symptom-to-FRU
Index” on page 416.
Important: When the Problem Determination Procedure
in the operation manual that is supplied with the adapter or
device says “Have the system unit serviced”, this means
the computer and Dock II.
001
– Turn off the computer and all external devices.
– Remove the computer from Dock II.
– Connect the external keyboard, mouse, parallel and
serial devices to the computer, if used. (Use the
keyboard/mouse connector for testing the external
keyboard and mouse.)
– Diagnose all computer problems first (see the computer
Hardware Maintenance Service manual).
DID THE TEST COMPLETE WITHOUT ANY ERROR?
Yes No
002
Have the computer serviced.
003
– Install the computer on Dock II. Make sure that the
computer is firmly connected.
– Check all cables and power cords.
– Check the fan in the power supply in Dock II and make
sure it is working correctly.
Notes:
1. The mouse or some other pointing device do not
work if they are connected to the keyboard/numeric
keypad connector.
2. The mouse or some other pointing device do not
work if they are connected to the mouse connector
on the numeric keypad that is connected
to Dock II.
3. The computer keyboard does not work when an
external keyboard is connected to Dock II.
– Reinstall all external devices.
– Turn on all external devices.
(Step 003 continues)
392 IBM Mobile Systems HMM - Volume 1

003 (continued)
– Press and hold F1, then turn on the computer. (Hold F1
until the Easy-Setup screen or an error message
appears.) See “How To Run the Diagnostics” on
page 405.
Note: If a warning beep sounds for the correct
operation, go to the “Symptom-to-FRU Index” on
page 416.
– Write down all post error codes that are displayed.
(Press the Pause key when an error code appears to
keep the screen from scrolling. Press F1 to continue.)
If the POST stops and you cannot continue, go to
“Symptom-to-FRU Index” on page 416.
ARE THERE ANY EXTERNAL DEVICES ATTACHED TO
THE DOCK II?
Yes No
004
Go to Step 007.
005
DID THE POWER-GOOD LIGHT FOR ALL OF THE
EXTERNAL DEVICES TURN ON?
Yes No
006
See the manual for the failing device.
007
DID YOU RECEIVE A POST ERROR CODE?
Yes No
008
If you cannot check the error code:
– Press and hold F1, then turn on the computer.
(Hold F1 until the Easy-Setup screen or an error
message appears.)
– Write down all post error codes that are displayed.
(Press the Pause key when an error code
appears to keep the screen from scrolling. Press
F1 to continue.)
To run system checkout, or if you suspect another
problem, go to Step 010.
009
Go to “Symptom-to-FRU Index” on page 416.
010
(Step 010 continues)
Dock II (3546) 393

(CONTINUED)
010 (continued)
DID THE EASY-SETUP SCREEN APPEAR?
CONFIG Date/Time Password Start Up Test
Exit
123
Yes No
011
The system may have hung during the running of
the POST. Note the symptoms and go to
“Symptom-to-FRU Index” on page 416.
012
– Select Test and press Enter.
DID THE DIAGNOSTIC SCREEN APPEAR?
111
222
Yes No
013
– If the keyboard does not work, go to “External
Keyboard” on page 404.
– Otherwise, go to “Symptom-to-FRU Index” on
page 416.
014
(Step 014 continues)
394 IBM Mobile Systems HMM - Volume 1

014 (continued)
IS THE CONFIGURATION THE SAME AS THE
INSTALLED DEVICES?
Yes No
015
– Go to “Checking the Installed Devices” on
page 397.
016
– Select Start and press Enter.
Diagnostic tests will run on all available devices.
If the test finds a device error, the error is displayed with
an X beside the device name.
For example:
DID THE TESTS FIND A DEVICE ERROR?
Yes No
017
The error was not detected by the basic test. Go to
Step 019.
018
– Note the error codes and go to “FRU Codes” on
page 419 and replace the appropriate FRUs.
019
– Go to the advanced diagnostic screen by pressing
Ctrl+A, and run the following tests.
Diskette drive test (use a blank diskette).
Serial port test (with the wrap plug).
Note: Install the wrap plug on the serial port of
Dock II.
Parallel port test (with the wrap plug).
Note: Install the wrap plug on the parallel port of
Dock II.
PCMCIA-2 test (with the PC test card).
Note: Install the PC Test Cards into the PCMCIA
slot of Dock II.
(Step 019 continues)
SystemBoard
02
FRU 0010
DEV 001
ERR
DEV: Device ID
ERR: Error Description Code
FRU: FRU Code
Note: If the test stops or hangs during
the test, replace the last device
that was tested.
Dock II (3546) 395

(CONTINUED)
019 (continued)
Keyboard test (see “How to Run the Keyboard
Test” on page 407).
DID THE ADVANCED DIAGNOSTICS FIND AN ERROR?
Yes No
020
The problem was not detected by the diagnostics.
Check that the cables and connectors are not
damaged.
If a SCSI device is not installed, start at Step 3.
If a SCSI device is installed, do the following:
1. Check that the total number of the attached
SCSI devices is less than eight.
2. Check that the SCSI terminator is correctly
installed.
If the problems still remain, run the SCSI test.
(See “Running Diagnostics” on page 410.)
3. Reconnect all adapters, drives, and devices,
then test the system several times. A Loop
Test option is available for running all the tests.
(See “How to Run the Loop Test” on
page 407.)
After stopping the loop test, check that the error
log appears in the error list. (See “Error Log”
on page 409.)
If no errors were detected, go to “Undetermined
Problems” on page 421 and use the user
reported symptom.
If any errors are detected, go to “Numeric Error
Codes” on page 418.
021
Note the error code and go to “FRU Codes” on page 419
and replace the appropriate FRUs. If the problem remains
after all repair actions are taken, go to “Undetermined
Problems” on page 421.
396 IBM Mobile Systems HMM - Volume 1

Checking the Installed Devices
The HDD-1 or FDD-1 represents the first drive in the
system configuration, respectively. Similarly, the HDD-2 or
FDD-2 represents the second drive, usually attached
through a Dock II.
Notes:
1. Neither the Dock II nor the adapters and SCSI
devices installed in the Dock II appear as icons on
the screen.
2. HDD-1 and HDD-2 icons are for the 2.5-inch
ThinkPad hard disk drive.
If the devices are installed, but the icon appears in a gray
shade rather than a dark shade on the basic diagnostic
screen, it means that the devices are defective. Turn off
the computer and make sure that the devices are correctly
connected. If the symptom still remains after the computer
is turned on, replace the devices or the main card of Dock
II.
Dock II (3546) 397

Power Supply
If the power-on indicator is not on and the power supply
fan is not turning, check the power cord for continuity and
correct installation.
If the power cord is not the problem, either the power
supply is defective, or another component is defective
causing the power supply to cut off. To verify that the
power supply is operating correctly, do the following:
1. Turn off the computer and disconnect the Dock II
power cord.
2. Remove all internal and external devices, and the
computer from the Dock II.
3. Remove the power supply connector CN26 from the
main card (refer to “Main Card” on page 453) and
CN56 from the riser card (refer to “Riser Card” on
page 455).
4. Remove the SCSI power supply connector from the
SCSI device.
5. Install jumpers between pins 1 and 2, and pins 3 and
4 of JP2 on the main card.
6. Connect the Dock II power cord.
7. Check the power supply voltages on the CN26,
CN56, and SCSI connectors by referring to the
respective voltage tables. Then, check that the fan is
turning. If the voltage is not correct or the fan is not
turning, replace the power supply.
8. Connect the Dock II power cord.
If any of the voltages are not correct, replace the power
supply. If replacing the power supply does not correct the
problem, then replace the main card.
398 IBM Mobile Systems HMM - Volume 1

Power Supply Connector CN25
Power Supply Connector CN26
Power Supply Connector-Reserved
Pin Signal V dc Min. V dc Max.
1+5 volts +4.75 +5.25
2 Ground – –
3+12 volts +11.4 +12.6
4 Ground – –
5 Sub+5 volts +4.75 +5.25
6 System On – –
7 Power On – –
8 Mode
Control – –
9 Security – –
10 Ground – –
11 Sub+12 volts +11.4 +12.6
12 NC – –
Pin Signal V dc Min. V dc Max.
1 CVCC +19 +21
2 Ground – –
Pin Signal V dc Min. V dc Max.
1 CVCC +19 +21
2 Ground – –
Dock II (3546) 399

Power Supply Connector CN56
SCSI Power Supply Connector
Pin Signal V dc Min. V dc Max.
1, 2, 3 +5 volts +4.75 +5.25
4, 5 Ground – –
6+12 volts +11.4 +12.6
7 Ground – –
8−12 volts −11.4 −13.2
9−5 volts −4.53 −5.5
10 Ground – –
Pin Signal V dc Min. V dc Max.
1+12 volts +11.46 +12.6
2, 3 Ground – –
4+5 volts +4.758 +5.25
400 IBM Mobile Systems HMM - Volume 1

Printer
Test the printer by connecting it to the computer before
testing it on Dock II.
1. Make sure the printer is correctly connected and the
power is turned on.
2. Run the printer self-test.
If the printer self-test does not run correctly, the problem is
in the printer. Refer to the printer service manual.
If the printer self-test runs correctly, connect a wrap plug
on the parallel connector on the rear of Dock II and run the
advanced diagnostic tests to determine the failing FRU.
If the advanced diagnostic tests (with the wrap plug
connected) did not detect a failure, replace the printer
cable.
If the problem is not corrected, do one of the following:
If the printer is attached to the parallel connector of
Dock II, replace the main card of Dock II.
If the printer is attached to the parallel connector on
the adapter, replace the FRUs in the following order
one at a time until the problem is corrected:
Note: If the replaced parts did not resolve the
problem, put the original parts back in the
Dock II. Do not replace non-defective parts.
1. Adapter
2. Main card of Dock II
Dock II (3546) 401

External Display
If the screen is rolling, replace the external display.
If the problem is not corrected, replace FRUs in the
following order one at a time until the problem is corrected:
Note: If the replaced parts did not resolve the problem,
put the original parts back in the Dock II. Do not
replace non-defective parts.
If the external display is attached to Dock II:
– Main card of Dock II
If the external display is attached to the display
adapter:
1. Display adapter
2. Main card of Dock II
3. Riser card
If the screen is not rolling, do the following to run the
display self-test:
1. Turn off Dock II and the external display.
2. Disconnect the external display signal cable from
Dock II.
3. Turn on the external display.
4. Turn the contrast control to its maximum position.
5. Turn the brightness control to its center detent
position.
Check for the following conditions:
The screen should be white or light gray, with a black
margin as described below:
– 2–20 mm (0.08–0.79 in.) wide on one or both
sides
– 2–50 mm (0.08–1.97 in.) wide on the top,
bottom, or both sides
– For other test patterns, see the appropriate
display manual.
The screen contrast and brightness controls should
vary the intensity of the screen.
402 IBM Mobile Systems HMM - Volume 1

If the external display does not meet these specifications,
replace the external display.
If the external display meets these specifications, replace
FRUs in the following order one at a time until the problem
is corrected.
Note: If the replaced parts did not resolve the problem,
put the original parts back in the Dock II. Do not
replace non-defective parts.
If the external display is attached to Dock II:
1. Main card of Dock II
2. External display
If the external display is attached to the display adapter:
1. Display adapter
2. Main card of Dock II
3. Riser card
4. External display
Dock II (3546) 403

External Keyboard
Notes
If a mouse or other pointing device is attached,
remove it and see if the error symptom goes away. If
the symptom goes away, the mouse or other pointing
device is defective.
The computer keyboard does not work when an
external keyboard is connected.
001
– Turn off the computer.
– Disconnect the keyboard cable from the external
keyboard.
– Turn on the computer and check the keyboard cable
connector for the following voltages. All voltages have a
±5% voltage tolerance.
4531
26
Pin
1
2
3
4
5
6
+5.0
G round
+5.0
+5.0
Voltage (V dc)
Not Used
Not Used
ARE ALL VOLTAGES CORRECT?
Yes No
002
Replacing the following FRUs one at a time until the
problem is corrected.
Note: If the replaced parts did not resolve the
problem, put the original parts back in the
Dock II. Do not replace non-defective parts.
1. Keyboard cable
2. Main card of Dock II
003
Replace the external keyboard.
404 IBM Mobile Systems HMM - Volume 1

How To Run the Diagnostics
Do the following to run the diagnostic tests.
Either the TrackPoint II or the cursor move keys can be
used to interact with the tests. The Enter key works the
same as selecting the OK icon to reply OK.
1. Press and hold F1, then turn on the computer. Hold
F1 until the Easy-Setup screen appears.
CONFIG Date/Time Password Start Up Test
Exit
123
2. Select Test and press Enter. The basic diagnostic
screen appears.
111
222
3. Select a device and press Enter to run the test.
Dock II (3546) 405

4. The test progress screen appears.
C
SSystem Board
5. OK appears when the test ends without any errors.
Advanced Diagnostic Tests
1. Go to the advanced diagnostic screen by pressing
Ctrl+A on the basic diagnostic screen.
2. Select Tool to install the tools.
3. Select a device, press the Spacebar, and install the
tool. Multiple devices can be selected by repeating
this step.
A √ mark appears for the selected device.
4. Select OK and press Enter if the selection is OK.
5. Select a device and press Enter to start the tests.
406 IBM Mobile Systems HMM - Volume 1

How to Run All Tests: In the advanced diagnostic
screen, select Test All to test all devices.
How to Run the Loop Test
1. Go to the advanced diagnostic screen by pressing
Ctrl+A on the basic diagnostic screen.
2. Select the Looptest icon and press Enter or click the
click button.
3. Select a device and press the Spacebar.A √ mark
appears for the selected device.
4. If the selection is OK, select OK and press Enter to
start the loop test.
5. To exit the loop test, press and hold Ctrl+Pause until
the interrupt is accepted by the test program. A beep
sounds when the interrupt is accepted. The test loop
stops at the end of the current test.
How to Run the Keyboard Test: Use the
following procedure to run the keyboard key test.
1. Turn off the computer.
2. Remove the external keyboard, if one is attached.
3. Press and hold F1 key, then turn on the computer.
Hold F1 until the Easy-Setup screen appears.
4. Select Test and press Enter. The basic diagnostic
screen appears.
5. Press Ctrl+A to go to advanced diagnostic screen.
6. Press Ctrl+K (a keyboard graphic appears on the
screen).
7. By pressing a key, the mark appears or disappears
on the corresponding key position on the screen.
Repeat this step for any keys that need to be tested.
8. To exit the test, press Esc or select the cancel icon.
How to Run the Audio Test: Use the following
procedure to run the audio tests.
1. Turn off the computer.
2. Insert the maintenance diskette into diskette drive A
and turn on power.
3. Select the Audio Diagnostics from the main menu.
4. Select Tests from the menu bar and press Enter.
5. Select All tests from the pull-down menu and press
Enter.
Run options are set to test once and stop on error as
defaults. Other options can be selected by the
pull-down menu of Setting-up.
6. Follow the instructions that appear on the screen to
proceed with the tests.
7. If the tests end without detecting any error, the “All
tests passed OK” message appears.
8. If an error is detected, the FRU code and error
description message appear. Go to “FRU Codes” on
page 419 and replace the FRU.
Dock II (3546) 407

9. To exit the test screen, press Esc.
Notes:
a. If an instruction to plug the external loop cable
appears, connect it between the microphone/line
jack of the computer and the headphone jack of
Dock II.
b. If an instruction to plug the headphone appears,
connect it to the headphone jack of Dock II.
c. Volume Control Test does not work when the
computer is docked to Dock II.
PC Test Card LED: The green LED on the PC test
card lights when the PCMCIA test is running. If the LED
does not go on, check that the card is installed correctly by
reseating the card. If it still does not light after reseating,
try using another slot for the test. If the LED still does not
go on and the test fails, replace the FRU shown in the
diagnostic error code.
Diagnostic Error Indications: If an error is
detected, the following appears:
Large X on the left-side of the device icon.
Device ID (three digits).
Error code (two digits).
FRU code (four digits).
The FRU code represents two FRUs. The leftmost two
digits indicates the higher priority of replacement.
The device ID and error codes are used to indicate the
detail portion of the FRU which caused the error.
Errors during the POST: If the POST detects an
error, a three- to eight-digit error code is displayed.
408 IBM Mobile Systems HMM - Volume 1
