IBM Slicestor 2584 User manual

IBM Cloud Object Storage System™
Version 3.13.1
Slicestor®2584 Installation Guide
IBM

Note
Before using this information and the product it supports, read the following information:
vThe general information in Notices
vThe information in Safety and environmental notices
vThe information in the IBM Environmental Notices and User Guide (provided on a DVD)
This edition applies to IBM Cloud Object Storage System™Slicestor®2584 and is valid until replaced by new
editions.
© Copyright IBM Corporation 2016, 2018.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Contents
Figures ............... v
Tables ............... vii
Safety and environmental notices ... ix
Safety notices .............. ix
Environmental notices........... xii
Declared noise emissions ........ xiii
Support information ........... xiii
Chapter 1. Appliance safety precautions 1
Safe handling .............. 1
Safety................. 1
Rack system precautions .......... 2
Electrostatic discharge (ESD) precautions ..... 3
Product rating .............. 3
Chapter 2. Preparation ........ 5
Before you begin ............. 5
Unpacking the storage system ........ 5
Chapter 3. Installing the appliance into a
rack ................ 7
Mounting the system into a rack........ 7
Enclosure layout ............. 8
Installing and removing disk drives in carriers
(DDICs) ............... 10
Installing and removing cooling modules, power
supply units, and compute modules ...... 11
Battery removal ............. 14
Chapter 4. LED states ........ 17
Compute module LEDs .......... 17
Ops panel LEDs ............. 18
Drawer indicators ............ 19
Power supply unit (PSU) LEDs ........ 20
Cooling module LEDs ........... 21
Notices .............. 23
Trademarks .............. 25
Homologation statement .......... 25
© Copyright IBM Corp. 2016, 2018 iii

iv Slicestor®2584 Installation Guide

Figures
1. Unpacking the storage system....... 6
2. Mounting the system into a rack (left rail only) 8
3. Drive numbering for drawer 1 (top)..... 9
4. Drive numbering for drawer 2 (bottom) ... 9
5. LED locations ............ 10
6. Installing a DDIC .......... 10
7. Removing a DDIC .......... 11
8. Removing a cooling module (1) ...... 11
9. Removing a cooling module (2) ...... 12
10. Removing a PSU (1).......... 12
11. Removing a PSU (2).......... 13
12. Removing a module (1). (6Gb/s SAS EBOD
module shown) ........... 13
13. Removing a module (2). (6Gb/s SAS EBOD
module shown) ........... 14
14. Remove the battery .......... 15
15. SBB compute module LEDs ....... 17
16. Ops panel LEDs ........... 18
17. Drawer status indicators ........ 19
18. PSU LEDs ............. 20
19. Cooling module LEDs ......... 21
© Copyright IBM Corp. 2016, 2018 v

vi Slicestor®2584 Installation Guide

Tables
1. Declared noise emissions in accordance with
ISO 9296(1,2,3) ............ xiii
2. SBB compute module LED descriptions 17
3. Ops module LED states ........ 18
4. Drawer LED states .......... 19
5. PSU LED states ........... 20
6. Cooling module LED states ....... 21
© Copyright IBM Corp. 2016, 2018 vii

viii Slicestor®2584 Installation Guide

Safety and environmental notices
Review the safety notices, environmental notices, and electronic emission notices for IBM®Cloud Object
Storage System before you install and use the product.
Suitability for telecommunication environment - This product is not intended to connect directly or
indirectly by any means whatsoever to interfaces of public telecommunications networks.
Examples of a caution and a danger notice. Numbers in parentheses refer to message numbers in the IBM
Safety Notices publication G229-9054, which is included with your product.
CAUTION:
A caution notice indicates the presence of a hazard that has the potential of causing moderate or
minor personal injury. (C001)
DANGER
A danger notice indicates the presence of a hazard that has the potential of causing death or serious
personal injury. (D002)
Safety notices
Safety notices for this product.
Familiarize yourself with the IBM Safety Notices publication G229-9054, which is included with your
product.
© Copyright IBM Corp. 2016, 2018 ix

DANGER: When working on or around the system, observe the following precautions:
Electrical voltage and current from power, telephone, and communication cables are hazardous. To
avoid a shock hazard:
• , connect power to this unit only with the IBM provided powerIf IBM supplied a power cord(s)
cord. Do not use the IBM provided power cord for any other product.
• Do not open or service any power supply assembly.
• Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration
of this product during an electrical storm.
• The product might be equipped with multiple power cords. To remove all hazardous voltages,
disconnect all power cords.
• Connect all power cords to a properly wired and grounded electrical outlet. Ensure that the outlet
supplies proper voltage and phase rotation according to the system rating plate.
• Connect any equipment that will be attached to this product to properly wired outlets.
• When possible, use one hand only to connect or disconnect signal cables.
• Never turn on any equipment when there is evidence of fire, water, or structural damage.
• Do not attempt to switch on power to the machine until all possible unsafe conditions are corrected.
• Assume that an electrical safety hazard is present. Perform all continuity, grounding, and power
checks specified during the subsystem installation procedures to ensure that the machine meets
safety requirements.
• Do not continue with the inspection if any unsafe conditions are present.
• Disconnect the attached power cords, telecommunications systems, networks, and modems before
you open the device covers, unless instructed otherwise in the installation and configuration
procedures.
• Connect and disconnect cables as described in the following procedures when installing, moving,
or opening covers on this product or attached devices.
To disconnect:
1. Turn off everything (unless instructed otherwise).
2. Remove the power cords from the outlets.
3. Remove the signal cables from the connectors.
4. Remove all cables from the devices.
To connect:
1. Turn off everything (unless instructed otherwise).
2. Attach all cables to the devices.
3. Attach the signal cables to the connectors.
4. Attach the power cords to the outlets.
5. Turn on the devices.
• Sharp edges, corners and joints may be present in and around the system. Use care when handling
equipment to avoid cuts, scrapes and pinching. (D005)
DANGER: Heavy equipment — personal injury or equipment damage might result if mishandled.
(D006)
xSlicestor®2584 Installation Guide

DANGER: Professional movers are to be used for all relocation activities. Serious injury or death
may occur if systems are handled and moved incorrectly. (D008)
DANGER: Serious injury or death can occur if loaded lift tool falls over or if a heavy load falls off
the lift tool. Always completely lower the lift tool load plate and properly secure the load on the lift
tool before moving or using the lift tool to lift or move an object. (D010)
CAUTION:
T
The battery contains lithium. To avoid possible explosion, do not burn or charge the
battery.
Do not: hrow or immerse into water, heat to more than 100ºC (212ºF), repair or disassemble. (C003)
DANGER: Observe the following precautions when working on or around your IT rack system:
• Heavy equipment—personal injury or equipment damage might result if mishandled.
• Always lower the leveling pads on the rack cabinet.
• Always install stabilizer brackets on the rack cabinet.
• To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest
devices in the bottom of the rack cabinet. Always install servers and optional devices starting
from the bottom of the rack cabinet.
• Rack-mounted devices are not to be used as shelves or work spaces. Do not place objects on top
of rack-mounted devices.
• Each rack cabinet might have more than one power cord. Be sure to disconnect all power cords in
the rack cabinet when directed to disconnect power during servicing.
• Connect all devices installed in a rack cabinet to power devices installed in the same rack cabinet.
Do not plug a power cord from a device installed in one rack cabinet into a power device
installed in a different rack cabinet.
• An electrical outlet that is not correctly wired could place hazardous voltage on the metal parts of
the system or the devices that attach to the system. It is the responsibility of the customer to
ensure that the outlet is correctly wired and grounded to prevent an electrical shock.
(R001 part 1 of 2)
Use the following general safety information for all rack mounted devices:
Safety and environmental notices xi

Environmental notices
This information contains all of the environmental notices for IBM Systems products in English and other
languages.
CAUTION:
• Do not install a unit in a rack where the internal rack ambient temperatures will exceed the
manufacturer’s recommended ambient temperature for all your rack-mounted devices.
• Do not install a unit in a rack where the air flow is compromised. Ensure that air flow is not
blocked or reduced on any side, front or back of a unit used for air flow through the unit.
• Consideration should be given to the connection of the equipment to the supply circuit so that
overloading of the circuits does not compromise the supply wiring or overcurrent protection. To
provide the correct power connection to a rack, refer to the rating labels located on the equipment
in the rack to determine the total power requirement of the supply circuit.
• (For sliding drawers): Do not pull out or install any drawer or feature if the rack stabilizer
brackets are not attached to the rack. Do not pull out more than one drawer at a time. The rack
might become unstable if you pull out more than one drawer at a time.
• (For fixed drawers): This drawer is a fixed drawer and must not be moved for servicing unless
specified by the manufacturer. Attempting to move the drawer partially or completely out of the
rack might cause the rack to become unstable or cause the drawer to fall out of the rack.
(R001 part 2 of 2)
DANGER: Multiple power cords. The product might be equipped with multiple power cords. To
remove all hazardous voltages, disconnect all power cords. (L003)
xii Slicestor®2584 Installation Guide

The IBM Systems Environmental Notices (http://ibm.co/1fBgWFI) information includes statements on
limitations, product information, product recycling and disposal, battery information, flat panel display,
refrigeration and water-cooling systems, external power supplies, and safety data sheets.
Declared noise emissions
Declared noise emissions in accordance with ISO 9296(1, 2, 3)
Table 1. Declared noise emissions in accordance with ISO 9296(1,2,3)
Product description
Declared A-Weighted
Sound Power Level,
LWAd (B)
Declared A-Weighted
Sound Pressure Level,
LpAm (dB)
Operating Idling Operating Idling
Model S03
@ 25 deg. C room ambient
8.0 8.0 61 61
Model S03
@ 35 deg. C room ambient
9.3 9.3 75 75
Model S03
@ 25 deg. C room ambient w/Acoustical doors
Feature codes FC EC07 = back FC EC08 = front
7.4 7.4 55 55
Model S03
@ 35 deg. C room ambient w/Acoustical doors
Feature codes FC EC07 = back FC EC08 = front
8.7 8.7 69 69
Notes:
1. Declared level LWAd is the upper-limit A-weighted sound power level; Declared level LpAm is the mean
A-weighted sound pressure level measured at the 1-meter bystander positions.
2. All measurements made in conformance with ISO 7779 and declared in conformance with ISO 9296.
3. B, dB, abbreviations for bels and decibels, respectively. 1 B = 10 dB.
Support information
For more information on the product or help with troubleshooting, contact IBM Support at
[email protected] or visit the Directory of worldwide contacts.
Safety and environmental notices xiii

xiv Slicestor®2584 Installation Guide

Chapter 1. Appliance safety precautions
Observe physical, electrical, and electronic component safety precautions.
Important: The enclosure must be mounted in a rack.
Safe handling
Handle the enclosure with care.
vAn unpopulated enclosure can weigh up to 45kg (100lb). Use appropriate lifting methods.
vA fully populated enclosure weighs 135kg (298lb). Only lift the enclosure when the drawers are empty
and latched closed. Do not attempt to lift the enclosure when populated with drives.
vDo not lift the enclosure by the handles on the rear modules. They are not designed to take the weight.
Only lift from underneath the main chassis.
vWhen closing the drawers, do so firmly, ensuring the latches are engaged.
Safety
vThis equipment is for installation in a restricted access location only.
CAUTION:
If this equipment is used in a manner not specified by the manufacturer, the protection provided by
the equipment might be impaired.
vAll rear modules are part of the fire enclosure and must only be removed when a replacement can be
immediately added. The system must not be run without all modules in place.
vUnplug the unit before you move it or if you think it has become damaged in any way.
vA safe electrical ground connection must be provided to the power supply cords.
Important: The enclosure must be grounded before applying power.
vThe plug on the power supply cord is used as the main disconnect device. Ensure that the socket
outlets are located near the equipment and are easily accessible.
DANGER: An electrical outlet that is not correctly wired could place hazardous voltage on the
metal parts of the system or the devices that attach to the system. It is the responsibility of the
customer to ensure that the outlet is correctly wired and grounded to prevent an electrical shock.
(D004)
DANGER: Hazardous voltage present. Voltages present constitute a shock hazard, which can cause
severe injury or death. (L004)
© Copyright IBM Corp. 2016, 2018 1

vWhen powered by multiple AC sources, disconnect all supply power for complete isolation.
vIn order to comply with applicable safety, emission, and thermal requirements, carry out the following
precautions:
– Do not remove any covers
– Populate all rear bays with plug-in modules
vThe power connection should always be disconnected prior to insertion or removal of a power supply
unit (PSU) from the enclosure.
vDo not attempt to disassemble the rear sub-chassis from the enclosure.
vProvide a suitable power source with electrical overload protection to meet the requirements laid down
in the technical specification.
CAUTION:
Operating temperatures inside the enclosure drawers can reach up to 60°C. Take care when opening
drawers and removing drive carriers.
vIf any component of the product fails, consult your storage vendor.
vDo not remove Cooling Modules, PSUs or I/O Modules unless you have a replacement model of the
correct type ready for insertion.
vFor use in North America, each branch circuit must be rated for 20A.
vThis equipment is suitable for connection to an IT power system (Norway).
CAUTION:
Double pole/neutral fusing in PSUs.
Important: The optional RJ45 socket on the I/O module is for Ethernet connection only. Do not
connect it to a telecommunications network.
CAUTION: Due to product acoustics, it is recommended that users wear ear protection for any
prolonged exposure.
CAUTION: To prevent overturning, drawer interlocks stop users from opening both drawers at the
same time. Do not attempt to force open a drawer when the other drawer is already open.
Rack system precautions
The enclosure must be mounted in a rack. Consider the following safety requirements when mounting
the enclosure:
vThe rack construction must be capable of supporting the total weight of the installed enclosure(s) and
the design should incorporate stabilizing features suitable to prevent the rack tipping or being pushed
over during installation or in normal use.
vWhen loading a rack with enclosures, fill from the bottom up; empty from the top down.
vTo avoid danger of the rack toppling over, do not slide more than one enclosure out of the rack at a
time.
vThe system must be operated with low pressure rear exhaust installation. The back pressure created by
rack doors and obstacles is not to exceed 5 Pascals (0.5mm water gauge).
vThe rack design should take into consideration a maximum operating ambient temperature of 35°C.
vThe rack should have a safe electrical distribution system. It must provide over-current protection for
the unit and must not be overloaded by the total number of units installed in the rack. When
addressing these concerns, consider the electrical power consumption rating shown on the nameplate.
vThe electrical distribution system must provide a reliable ground for each unit in the rack.
vThe design of the electrical distribution system must take into consideration the total ground leakage
current from all the PSUs in all the units. The rack might require labeling with “HIGH LEAKAGE
CURRENT. Ground connection essential before connecting supply.”
2Slicestor®2584 Installation Guide

Electrostatic discharge (ESD) precautions
Fit and check a suitable anti-static wrist or ankle strap and observe all conventional ESD precautions
when handling plug-in modules and components. Avoid contact with backplane components, module
connectors, and other potential sources of ESD.
Product rating
Product rating information can also be found on the back of the PSUs.
The product has the following ratings:
vVoltage: 200 to 240 VAC
vCurrent: 16A
vFrequency: 50 to 60 Hz.
Chapter 1. Appliance safety precautions 3

4Slicestor®2584 Installation Guide

Chapter 2. Preparation
Before you install the system, verify the location and installable components.
Before you begin
Before you begin installing the product, you must meet certain requirements.
Make sure that the site where you intend to set up and use your storage system can meet the following
needs:
vStandard power from an independent source or a rack power distribution unit with a UPS.
vHost computer with the correct firmware, BIOS and drivers. Contact your supplier for the correct
software levels.
Before setting up your enclosure, ensure that you have the following accessories:
vPower Cord
vRack kit (if installing within a rack)
Refer to your supplier for a list of qualified accessories for use with the enclosure. The accessory box
contains the power cords and other ordered accessories
Unpacking the storage system
Read these instructions before unpacking the system.
1. Position the shipping case within 2m (6 feet) of the site where you intend to use your storage system.
2. Inspect the packaging for crushes, cuts, water damage or any other evidence of mishandling during
transit. If there is any damage, photograph the packaging for future reference before opening.
3. Unpack the system, as shown in the following figure.
© Copyright IBM Corp. 2016, 2018 5

Figure 1. Unpacking the storage system
6Slicestor®2584 Installation Guide
