IB980
Intel ®4th Generation Core / Q87 PCH
PICMG 1.3 SHB Express Full-Size CPU Card
USER’S MANUAL
Version 1.0

ii IB980 User’s Manual
Acknowledgments
AMI is a registered trademark of American Megatrends Inc.
PS/2 is a trademark of International Business Machines
Corporation.
Intel and Intel®4th Generation Core DC/QC Processor are
registered trademarks of Intel Corporation.
Microsoft Windows is a registered trademark of Microsoft
Corporation.
Fintek is a registered trademark of Fintek Electronics Corporation.
All other product names or trademarks are properties of their
respective owners.

IB980 User’s Manual iii
Table of Contents
Introduction.......................................................4
Product Description.............................................................4
Checklist..............................................................................5
IB980 Specifications...........................................................6
Board Dimensions...............................................................8
Installations.....................................................10
Installing the CPU.............................................................10
Installing the Memory.......................................................12
Setting the Jumpers...........................................................13
Connectors on IB980.........................................................19
BIOS Setup.......................................................31
Drivers Installation......................................60
Intel Chipset Software Installation Utility........................61
VGA Drivers Installation..................................................63
Realtek HD Audio Driver Installation ..............................66
LAN Drivers Installation...................................................68
Intel® Management Engine Interface...............................71
Intel® USB 3.0 Drivers.....................................................73
Appendix............................................................76
A. I/O Port Address Map ..................................................76
B. Interrupt Request Lines (IRQ)......................................77
C. Watchdog Timer Configuration ...................................78

iv IB980 User’s Manual
Introduction
Product Description
The IB980 PICMG1.3 SHB is based on the latest Intel®Q87 chipset.
The platform supports 4th Generation Intel®Core processor family with
LGA1150 packing and features an integrated dual-channel DDR3
memory controller as well as a graphics core.
The latest Intel®processors provide advanced performance in both
computing and graphics quality. This meets the requirement of customers
in the gaming, POS, digital signage and server market segment.
The Q87 platform is made with 22-nanometer technology that supports
Intel’s first processor architecture to unite the CPU and the graphics core
on the transistor level. The IB980 PICMG1.3 board utilizes the dramatic
increase in performance provided this Intel’s latest cutting-edge
technology. Measuring 338mm x122mm, the IB980 offers fast 6Gbps
SATA support (6 ports), USB3.0 (4 ports) and interfaces for DVI-D,
VGA and LVDS displays.
IB980 FEATURES:
Supports Intel®4th Generation Core i7/i5/i3 QC/DC desktop
processors
Two DDR3 DIMM, 1066/1333/1600MHz, Max. 16GB
memory
Dual Intel® PCI-Express Gigabit LAN
Integrated Graphics for VGA, DVI-D & LVDS displays
6x SATA 3.0, 10x USB 2.0, USB 3.0 (4 ports),
4x COM, Watchdog timer

INSTALLATIONS
IB980 User’s Manual 5
Checklist
Your IB980 package should include the items listed below.
The IB980 PICMG1.3 SHB
This User’s Manual
1 CD containing chipset drivers and flash memory utility
Serial ATA cable

INSTALLATIONS
6 IB980 User’s Manual
IB980 Specifications
Product Name
IB980AF (Support LVDS, w/o LPT)
IB980F (Support LPT, w/o LVDS)
Form Factor
PICMG 1.3 SHB Express Full size CPU card
CPU Type
- 4th Generation Intel®CoreTM i7/i5/i3/Pentium DT processor
- FCLGA1150 package [37.5 mm x 37.5mm]
- TDP: QC=84W/45W ; DC=54W/35W
CPU Speed
Up to 3.8GHz
Cache
Up to 8MB
BIOS
AMI BIOS
CPU Socket
LGA1150
Chipset
Intel®Lynx Point DT Platform Controller Hub, Q87 PCH
Package =23 mm x 22 mm , 0.65 mm ball pitch
Memory
4th Generation Intel®CoreTM i7/i5/i3 DT processor integrated memory controller,
support dual channel DDR3-1333/1600 MHz (Non-ECC)
- DDR3 240-pin DIMM x 2, Max. 16GB [8GB in per DIMM]
VGA
4th Generation Intel®CoreTM i7/i5/i3 DT processor integrated graphics device
- 1 x VGA
- 1x DVI-D : (Thru port C, Reserve ASM1442K level shifter)
- 1 x LVDS (Thru port B, via NXP PTN3460), support 24-bit dual channel
LAN
1. Intel® Clarkville I217LM GbE , 6mm x 6mm, QFN48
2. Intel® Pearsonville I211AT as 2nd GbE
USB
USB 2.0 host controller [Q87 Integrated], support 10 ports
-4 ports via onboard pin header
-1 port via Mini PCIe
4 ports on board, 4 ports to the backplane [Connector C]
USB 3.0 host controller [Q87 integrated] support 4 ports
-2 ports via the rear panel I/O
-2 ports via on board pin header [BLUE color box header]
Serial ATA
Ports
Intel®Lynx Point Desktop PCH built-in SATA controller, support 6 ports
4 x SATAIII (3.0) 6Gbps
2 ports to the backplane [Connector C]
Audio
Intel®Q87 PCH built-inhigh definition audio w/ Realtek ALC662 Codec support 5.1
channel
LPC I/O
Fintek F81846AD-I (128-pin LQFP[14mm x 14 mm])
- COM #1 (RS232/422/485) support ring-in with power @500 mA (selectable for
5V or 12V) [EXAR SP339EER1 232/422/485 transceiver x 1 for jumper-less]
- COM #2~COM #4 (RS232 only)
Hardware Monitor (2 thermal inputs,4 voltage monitor inputs & 2 Fan headers)
- CPU FAN x 1(PWM Fan type, 4-pin connector)
- SYS FAN x 1 (DC Fan type, 3-pin connector)]
- Support Parallel port (IB980F only)
Digital IO
4 in & 4 out
Keyboard/Mouse
Connector
Supports PS/2 Keyboard/Mouse thru onboard pin-header
Expansion
Slots
Mini PCIe socket x1@ component side [Full-sized]
Support USB client & mSATA [share with onboard SATA]
Support PCIe signal
Edge
Connector
DB15 x1 for VGA
RJ45 x 2 for LAN 1 & 2
USB 3.0 x 2
On Board
Header
/Connector
DF11-20 pins pin-header x 2 for DVI-D x 1
DF20-20pins box-header x 2 for dual channel LVDS (IB980AF)
1 x 4 pins box header x 1 for LCD backlight control (IB980AF)
2x13 pins box-header x 1 for Printer port (IB980F)
DF11-20 pins box-header x1 for COM1/2
DF11-20 pins box-header x1 for COM3/4

INSTALLATIONS
IB980 User’s Manual 7
2x5 pins pin-header x 2for USB 2.0 x 4
2x10 pins box-header x 1 for USB3.0 x 2
2x6 pins pin-header x1 for Audio (Line-Out, Line-In & Mic)
2x5 pins pin-header x 1 for Digital I/O
2x4 pins pin-header x 1 for PS/2 KB/MS
4 pins pin-header x1 for CPU fan (PWM mode)
3 pins pin-header x1 for system fan (DC mode)
4 ports x SATAIII (Blue connectors)
2X10 pins pin-header x 1 for front panel indicators
2 x 2 pin ATX power connector x 1
Interface
1x PCIe(16x) [Connector A & B]
4x PCIe(1x) or 1x PCIe(4x) [Connector C]
4x PCI masters (ITE IT8892E PCIe to PCI bridge, 14mm x 14mm LQFP128)
[Connector D]
Watchdog
Timer
Yes (256 segments, 0, 1, 2…255 sec/min)
iSMART ver.
3.0
1. EuP / ErP(thru Super I/O)
2. Auto-scheduler
3. Power fail detector
4. Low temperature Guardian
5. IFUB ( Intelligent Firmware Update from BIOS & NVRAM data)
Others
- RAID function(0, 1, 5, 10)
- iAMT 9.0
- LAN wake up
- TPM 1.2 (Infineon SLB9655) supported
Environment
Operation Temperature : 0~60 degree C
Storage Temperature : -20~80 degree C
Relative humidity : 0~90%, non-condensing
System Voltage
+5V, +3.3V, +12V, -12V & 5VSB
Operation
System
Windows 7, Windows 8
Certification
CE /FCC/LVD
RoHS
Yes
Board Size
338mm x 122mm
[

INSTALLATIONS
8 IB980 User’s Manual
Board Dimensions

INSTALLATIONS
IB980 User’s Manual 9

INSTALLATIONS
10 IB980 User’s Manual
Installations
This section provides information on how to use the jumpers and
connectors on the IB980 in order to set up a workable system. The topics
covered are:
Installing the CPU................................................................................10
Installing the Memory..........................................................................12
Setting the Jumpers..............................................................................13
Connectors on IB980 ...........................................................................19

INSTALLATIONS
IB980 User’s Manual 11
Installing the CPU
The IB980 board supports an LGA1150 Socket (shown below) for Intel
Sandy Bridge processors.
To install the CPU, unlock first the socket bypressing the lever sideways,
then lift it up to a 90-degree. Then, position the CPU above the socket
such that the CPU corner aligns with the gold triangle matching the
socket corner with a small triangle. Carefully insert the CPU into the
socket and push down the lever to secure the CPU. Then, install the heat
sink and fan.
NOTE:
Ensure that the CPU heat sink and the CPU top surface are in
total contact to avoid CPU overheating problem that would
cause your system to hang or be unstable.

INSTALLATIONS
12 IB980 User’s Manual
Installing the Memory
The IB980 board supports four DDR3 memory socket for a maximum
total memory of 16GB in DDR3 DIMM memory type.
Installing and Removing Memory Modules
To install the DDR3 modules, locate the memory slot on the board and
perform the following steps:
1. Hold the DDR3 module so that the key of the DDR3 module aligned
with that on the memory slot.
2. Gently push the DDR3 module in an upright position until the clips of
the slot close to hold the DDR3 module in place when the DDR3
module touches the bottom of the slot.
3. To remove the DDR3 module, press the clips with both hands.
DDR3 Module
Lock
Lock
Lock
Lock

INSTALLATIONS
IB980 User’s Manual 13
Setting the Jumpers
Jumpers are used on IB980 to select various settings and features
according to your needs and applications. Contact your supplier if you
have doubts about the best configuration for your needs. The following
lists the connectors on IB980 and their respective functions.
Jumper Locations on IB980................................................................. 14
JBAT1: Clear CMOS Contents............................................................ 16
JP1: COM1 RS232 RI/+5V/+12V Power Setting................................ 16
JP5: Power Test (Factory use only, Default OPEN)............................ 16
JP7: Flash Descriptor Security Override (Factory use only)................ 17
JP11 LVDS Panel Power Selection ..................................................... 17
JP14: BL_ADJ_LEVEL Setting.......................................................... 18
JP13: BL Voltage TYPE Setting ......................................................... 18

INSTALLATIONS
14 IB980 User’s Manual
Jumper Locations on IB980

INSTALLATIONS
IB980 User’s Manual 15
Jumpers on IB980.............................................................................Page
JBAT1: Clear CMOS Contents............................................................ 16
JP1: COM1 RS232 RI/+5V/+12V Power Setting................................ 16
JP7: Flash Descriptor Security Override (Factory use only)................ 17
JP11 LVDS Panel Power Selection ..................................................... 17
JP14: BL_ADJ_LEVEL Setting.......................................................... 18
JP13: BL Voltage TYPE Setting ......................................................... 18

INSTALLATIONS
16 IB980 User’s Manual
JBAT1: Clear CMOS Contents
JBAT1
Setting
Function
Pin 1-2
Short/Closed
Normal
Pin 2-3
Short/Closed
Clear CMOS
JP1: COM1 RS232 RI/+5V/+12V Power Setting
JP1
Setting
Function
Pin 1-3
Short/Closed
+12V
Pin 3-4
Short/Closed
RI
Pin 5-3
Short/Closed
+5V
13
5 1
6 2

INSTALLATIONS
IB980 User’s Manual 17
JP7: Flash Descriptor Security Override (Factory use only)
JP7
Flash Descriptor
Security Override
Open
Disabled
(Default)
Close
Enabled
JP11: LVDS Panel Power Selection
JP11
Setting
Panel Voltage
Pin 1-2
Short/Closed
3.3V (default)
Pin 2-3
Short/Closed
5V
12

INSTALLATIONS
18 IB980 User’s Manual
JP14: BL_ADJ_LEVEL Setting
JP14
Function
Open
3.3V(default)
Close
5V
JP13: BL Voltage TYPE Setting
JP13
Setting
Function
Pin 1-2
Short/Closed
DC MODE
Pin 2-3
Short/Closed
PWM MODE

INSTALLATIONS
IB980 User’s Manual 19
Connectors on IB980
Connector Locations on IB980............................................................ 20
J1: COM1 and COM2 Serial Ports...................................................... 21
J2: COM3 and COM4 Serial Ports...................................................... 21
CN3, CN4, CN5, CN6: SATA3 Connectors........................................ 21
CN7: DB-15 VGA Connector.............................................................. 22
J4: USB3.0/2.0 Connector................................................................... 22
J15,J16: USB2.0 Connector................................................................. 22
CN8: Gigabit LAN (Intel I211AT) Connector .................................... 23
CN9: Gigabit LAN (Intel I217LM) Connector.................................... 23
J17: LCD Backlight Connector............................................................ 23
CN11,CN12: USB3.0 Connector......................................................... 23
J3: Front Panel Function Connector .................................................... 24
CN1, CN2: DDR3 DIMM Socket........................................................ 24
J6: External Audio Connector (DF11 Connector) ............................... 25
J7: ATX 12V Power Connector........................................................... 25
J12: Digital I/O 4 In/4 Out................................................................... 26
J9: PS/2 Keyboard and Mouse Connectors (DF11 Connector) ........... 26
J10: SPI Flash Connector (Factory use only)....................................... 26
J5: Parallel Port ................................................................................... 27
J8: MCU Flash Connector (factory use only) ...................................... 27
J13: DVI-D Port (DF11 Connector) .................................................... 27
CN10: Mini PCIE Connector (Support M-SATA with CN5).............. 28
CPU_FAN1: CPU Fan Power Connector............................................ 29
SYS_FAN1: System Fan1 Power Connector....................................... 29
J18,J19: LVDS Connectors ................................................................. 30

INSTALLATIONS
20 IB980 User’s Manual
Connector Locations on IB980
