icklebubba ROTATOR I-SIZE User manual

THE
ROTATOR I-SIZE
360 spin isofix car seat
INSTRUCTIONS FOR USE
ECE R129 40 TO 150cm

Item: ROTATOR I-SIZE (40-150CM)
Thank you for purchasing this Rotator i-Size car seat. If you are not completely
satisfied with the car seat or you would like to change any accessory or obtain any
help about the car seat, please contact our customer services department.
Please Note: Only suitable for use in vehicles fitted with a 3 point retractable safety
belt or lsofix attachments.
Read the instructions carefully before use and keep for future reference.
CONTENTS
• Warnings 03
• Car Seat Features and Components 05
• Installation in the vehicle 06
• Cleaning and Maintenance 18
• Warranty and Product Guarantee 19
IMPORTANT!
IMPORTANT! Read the instructions carefully before use and keep for future
reference. Install and use the child safety seat as described in the instruction
manual. Failure to do this could result in serious injury or death. Keep the
instructions together with the child restraint for future reference. Used as i-Size
category ECRS: This is an i-Size Enhanced Child Restraint System. It is approved
according to UN Regulation No.129, for use in, i-Size compatible vehicle seating
positions as indicated by vehicle manufacturers in the vehicle users’ manual. If in
doubt, consult either the Enhanced Child Restraint System manufacturer or the
retailer. 2. Used as i-Size booster cushion category ECRS: This is an i-Size booster
seat Enhanced Child Restraint System. It is approved according to UN Regulation
No. 129, for use primarily in "i-Size seating positions" as indicated by vehicle
manufacturers in the vehicle user’s manual. If in doubt, consult either the Enhanced
Child Restraint System manufacturer or the retailer.
IMPORTANT! Because of potential medical issues inherent to low birth weight
and premature infants, always have a trained professional doctor or hospital staff
member assess the suitability of the child restraint prior to leaving the hospital or
using the child restraint. It is recommended that the car seat inserts be used until
the child’s height exceeds 76cm.
WARNINGS!
1. Used as i-Size category ECRS: This is an i-Size Enhanced Child
Restraint System. It is approved according to UN Regulation
No.129, for use in, i-Size compatible vehicle seating positions as
indicated by vehicle manufacturers in the vehicle users’ manual.
If in doubt, consult either the Enhanced Child Restraint System
manufacturer or the retailer.
2. Used as i-Size booster cushion category ECRS: This is an i-Size
booster seat Enhanced Child Restraint System. It is approved
according to UN Regulation No. 129, for use primarily in "i-Size
seating positions" as indicated by vehicle manufacturers in the
vehicle user’s manual. If in doubt, consult either the Enhanced Child
Restraint System manufacturer or the retailer.
3. IMPORTANT - DO NOT USE FORWARD FACING BEFORE THE
CHILD'S AGE EXCEEDS 15 MONTHS (Refer to instruction).
4. Do not use the ECRS in seating positions where there is an active
frontal airbag installed.
icklebubba.comicklebubba.com 32

icklebubba.comicklebubba.com4 5
5. The rigid items and plastic parts of an ECRS shall be located
and installed so that they are not liable to become trapped by a
movable seat or in a door of the vehicle during everyday use of the
vehicle.
6. Any straps holding the restraint to the vehicle should be tight, any
straps or impact shields restraining the child should be adjusted to
the child's body, and straps should not be twisted.
7. It is important to ensure that any lap strap is worn low down.
8. The ECRS should be replaced when it has been subject to violent
stresses in an accident.
9. It is dangerous to make any alterations or additions to the device
without the approval of the Type Approval Authority, and it is also
dangerous of not following closely the installation instructions
provided by the child restraint manufacturer.
10. Be sure that children are not left in their ECRS unattended.
11. Be sure that any luggage or other objects liable to cause injuries in
the event of a collision shall be properly secured.
12. Be sure that the Enhanced Child Restraint System shall not be
used without the cover.
13. Be sure that the ECRS cover should not be replaced with
any other than the one recommended by the manufacturer,
because the cover constitutes an integral part of the restraint
performance.
14. Be referred to the vehicle manufacturer's handbook for the use of
an “i-Size ECRS”.
15. The child restraint may not fit in all approved vehicles when used
in stature range above 135 cm.
16. The child restraint may not fit in all approved vehicles when used
in one of all angles of inclination positions.
A
D
K
C
E
F
G
J
B
I
H
L
QPO
M
N
Car Seat Features
A. Headrest height adjuster
B. Headrest
C. Shoulder belt guide (100-150 cm)
D. Shoulder belt pad
E. Harness straps
F. Harness buckle
G. Recline lever
H. Harness adjustment button
I. Harness adjustment strap
J. Rotation handle
K. Lap belt guide
L. Small baby insert cushion
M. Top Tether system
N. Top tether hook
O. ISOFIX connector
P. ISOFIX system unlock button 1
Q. ISOFIX system unlock button 2

icklebubba.com icklebubba.com 7
General seat use
1. How to use the harness buckle.
Insert the two clips on the belts into the buckle until you hear a 'click'.
2. Adjust the length of the harness.
The straps should be level with the child’s shoulders.
Installation positions inside the car
6
In seats with:
ISOFIX anchorages and Top Tether anchor points and 3-point belt (car's seat belt).
Warning:
Only suitable for seats with a 3 point safety belt.
Shoulder belt (A) and lap belt (B).
A.Shoulder belt
B. Lap belt

icklebubba.com icklebubba.com 98
3. How to rotate the seat.
Pull the recline lever located at the base of the seat, and fully recline the seat (position 5).
Press the rotation handle while turning the seat to face rearward or forward.
5. Hide the 5-point harness and buckle.
Remove small baby insert cushion (L).Hide the harness straps (E) in the backrest,and the
buckle (F) in the base of the seat preparing it for 100-150 cm in height.
4. How to adjust the recline positions.
Pull the lever and move the seat to select one of the recline positions available for your child’s
group/weight. (G)
55
55
55
R

icklebubba.com icklebubba.com 1110
Installation
6. Rearward-facing installation.
(ISOFIX+Top Tether+harness system).
40-105cm
ECRS will turn to gear R for rear facing used.
55
1
OK
OK
OK
OK
OK
OK
40-75cm 76-105cm

icklebubba.com icklebubba.com 1312
Installation
7. Forward-facing installation.
(ISOFIX+Top Tether+harness system).
76-105cm
Remark: the child restraint may not fit in all approved vehicles when used in gear 1 and 2.
40-75cm 76-105cm
55
OK
OK
OK
OK
OK
OK

icklebubba.com icklebubba.com 1514
Installation
8. Forward-facing installation.
(ISOFIX+3-point safety belt)
100-150cm
55
100-150cm

icklebubba.com icklebubba.com 1716
Installation
8. Forward-facing installation.
(3-point safety belt).
100-150cm
55
100-150cm

icklebubba.com icklebubba.com 1918
Cleaning and Maintenance
1. Clean straps and plastic parts with a neutral detergent and warm water.
2. Make sure soap does not enter the buckle or other metal parts.
3. Do not use chemical products or bleach on any part of the seat.
4. The reducer cushion can be washed, just like the cover,but first remove the foam
pieces inside before washing.The inside foam pieces should never be washed for
any reason.
Washing instructions:
• The cover is removable and can be washed at 30°Air dry.
• For dry cleaning use any solvent except trichloroethylene.
• Machine wash on cold cycle.
• Do not use a drier.
• Do not bleach.
• Do not iron.
Warranty Information:
Please ensure you have registered your product online and keep your proof
of purchase for any future claim. We will not be able to investigate any claims
without this. If you register your product with us online within 28 days of
receiving your product, we will extend all parts/items with standard 2 year*
warranty to 4 years* from the date of purchase, at no extra cost.
Our warranty covers you against manufacturing defects, you are not covered
against the below:
- Normal wear and tear.
- Incorrect use, cleaning or storage.
- Damage caused by not following your Ickle Bubba product user guide.
- Modifying or altering your product with non-approved parts, or by an
unauthorised agent.
- Accidental damage (including airline damage) or damage caused by non-
domestic use.
- Damage caused by use of accessories not recommended by Ickle Bubba, or
advised against in your user guide.
If you have any problems with your Ickle Bubba product caused by a
manufacturing defect when under warranty, we offer a 4-step speedy aftercare
service within 5 working days. We advise customers to check the contents of their
product within 14 days of delivery. Please contact us within 7 days if you discover
a fault with your product.
We are more than happy to fulfil our warranty commitments. Ickle Bubba
have the right to offer a repair, provide a replacement self-fit part/spare, or
a full replacement product. If your product design, colour or fabric has been
discontinued we may be required to offer an alternative equivalent product. If
a returned item is found to have a fault not related to a manufacturing defect,
Ickle Bubba reserve the right to charge for any repairs carried out or spares/
replacements provided.
The warranty applies in the country of purchase only. The warranty applies to
the original purchaser and is non-transferrable. It does not cover second hand
purchases.
*Standard and extended warranty is only applicable on certain parts/items,
please check the warranty overview table for further details.
Your consumer statutory rights are not affected by the warranty.
Pram/pushchair/stroller chassis & pram/seat frames 2 years*
Car seats 2 years*
Wheels and brake bars 1 year
All fabric parts, handle coverings, bumper bars and accessories 6 months
*4 year extended warranty applies to these parts/items only.
Register your product
To register your product and activate your extended warranty, please visit our
website:
UK - https://icklebubba.com/pages/warranty
Replacing Damaged Components
If your seat trim becomes damaged, only replace it with one provided by Ickle
Bubba as it is dangerous to use an uncertified replacement. If you need a
replacement cover, contact our customer care team.
It is not safe to buy or sell secondhand restraints. Please dispose of your child
restraint safely once it has been involved in an accident or is damaged. Although
it may look undamaged, after an accident, a child restraint can have hidden stress
and strain that could make it ineffective if another accident was to occur.
