SERVICE MANUAL
ADDENDUM
CONTENTS
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
UNIT LAYOUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 16
Jan. 2010

Jan. 2010
1
SECTION 6.
SECTION 6. PARTS LIST
IC1 1110005230 S.IC UPC2757TB-E3 T 45.4/5.4
IC2 1110003201 S.IC TA31136FNG(EL) T 8.4/11.5
IC10 1110005230 S.IC UPC2757TB-E3 T 27.9/3.9
IC12 1130011770 S.IC CD4066BPWR B 37.8/25.1
IC14 1110006360 S.IC M62366GP D60J T 44.6/13.7
IC15 1110005230 S.IC UPC2757TB-E3 T 45.9/48
IC16 1110005230 S.IC UPC2757TB-E3 T 28.5/46.9
IC17 1110003201 S.IC TA31136FNG(EL) T 8.3/37.4
IC18 1110005180 S.IC UPC2746TB-E3 T 55.4/44.6
IC19 1110005180 S.IC UPC2746TB-E3 T 55.8/5.6
IC20 1110006360 S.IC M62366GP D60J T 45.9/41
IC21 1130011770 S.IC CD4066BPWR T 35.9/40.6
IC22 1130011760 S.IC CD4094BPWR B 47.9/25.1
Q1 1590001190 S.TRA XP6501-(TX).AB B 16.3/22.9
Q4 1590001190 S.TRA XP6501-(TX).AB B 23.6/23.4
Q5 1530003260 S.TRA 2SC5006-T1 T 13.7/7.8
Q14 1530003260 S.TRA 2SC5006-T1 B 64.4/22.3
Q24 1530003810 S.TRA 2SC5008-T1 T 64.9/45.5
Q26 1530003781 S.TRA 2SC5624VH-TL-E T 62.8/36.4
Q35 1530003260 S.TRA 2SC5006-T1 T 69.1/13.8
Q36 1530003260 S.TRA 2SC5006-T1 T 62.8/5.3
Q41 1590003231 S.TRA UNR9113G0L T 4.7/5.3
Q44 1590001660 S.TRA XP4312(TX) B 42.1/11.7
Q501 1590003231 S.TRA UNR9113G0L B 38.3/11.6
Q502 1590001810 S.TRA XP1113(TX) B 40/9.2
Q503 1590001810 S.TRA XP1113(TX) B 46.6/44.4
Q504 1590001680 S.TRA XP1110(TX) B 55.1/11
Q505 1530002880 S.TRA 2SC4226-T1 R24 B 56.5/16.5
Q506 1590003411 S.TRA UNR9110G0L B 54.9/7.5
Q507 1530003810 S.TRA 2SC5008-T1 B 69.4/31.8
Q508 1590001660 S.TRA XP4312(TX) B 69.1/36.5
Q509 1590003231 S.TRA UNR9113G0L B 57/7.5
Q510 1590001540 S.TRA UMD6N TR B 60.9/7.4
Q513 1590001650 S.TRA XP4601(TX) B 41.9/5
Q519 1590003231 S.TRA UNR9113G0L B 33.8/5.6
Q521 1530003630 S.TRA 2SC4617 TLS T 25.9/14.7
Q522 1530003630 S.TRA 2SC4617 TLS T 29.6/23.5
Q523 1530003630 S.TRA 2SC4617 TLS T 23.4/20.6
Q524 1530003630 S.TRA 2SC4617 TLS T 18.6/20.7
Q525 1590001190 S.TRA XP6501-(TX).AB T 28.9/20
Q526 1590003231 S.TRA UNR9113G0L T 16.5/20
Q527 1590003231 S.TRA UNR9113G0L T 16.5/22.3
Q528 1530003260 S.TRA 2SC5006-T1 T 2.3/21.1
Q529 1590003291 S.TRA UNR9213G0L B 30.4/24.7
Q530 1530003630 S.TRA 2SC4617 TLS T 21.7/27.6
Q531 1530003630 S.TRA 2SC4617 TLS T 16.7/27.7
Q532 1560000811 S.FET 2SK1069-4-TL-E T 29.2/28.9
Q534 1590001810 S.TRA XP1113(TX) B 39.3/14.8
Q535 1590001810 S.TRA XP1113(TX) B 42.2/17
Q540 1530003260 S.TRA 2SC5006-T1 T 13.1/14.9
Q542 1530003260 S.TRA 2SC5006-T1 T 13.5/34.7
Q543 1590003231 S.TRA UNR9113G0L T 2.9/33.3
Q544 1590001190 S.TRA XP6501-(TX).AB B 16.7/30
Q545 1590001190 S.TRA XP6501-(TX).AB B 22.6/30.2
Q546 1590001660 S.TRA XP4312(TX) B 41.2/37.2
Q547 1590003291 S.TRA UNR9213G0L B 30.5/31.3
Q548 1530003260 S.TRA 2SC5006-T1 T 61.1/22.8
Q549 1530003260 S.TRA 2SC5006-T1 B 63.2/32.5
Q550 1530003612 S.TRA FH102A-TR-E B 72.8/21.7
Q551 1590002650 S.TRA UPA805T-T1 T 68.5/23.9
Q552 1590003231 S.TRA UNR9113G0L T 73.5/9.6
Q553 1590001810 S.TRA XP1113(TX) B 41.9/40.9
Q554 1590001810 S.TRA XP1113(TX) B 46/41.5
Q555 1530003260 S.TRA 2SC5006-T1 T 14.2/40.7
Q556 1530003630 S.TRA 2SC4617 TLS T 33.7/10.7
D1 1750000711 S.VAR HVC350BTRF-E B 60.4/23
D2 1750000711 S.VAR HVC350BTRF-E B 55.9/22.9
D3 1790001621 S.DIO 1SV308(TPL3,F) T 71.2/32.4
D4 1750000711 S.VAR HVC350BTRF-E T 66.8/11.8
D5 1750000711 S.VAR HVC350BTRF-E T 61.7/11.8
D11 1790001621 S.DIO 1SV308(TPL3,F) T 73.3/37.4
D13 1790001621 S.DIO 1SV308(TPL3,F) T 72.2/35.6
D25 1790001621 S.DIO 1SV308(TPL3,F) B 54.6/21.2
D29 1790001621 S.DIO 1SV308(TPL3,F) T 59.9/12.4
D32 1790001621 S.DIO 1SV308(TPL3,F) T 58.7/44
D34 1790001621 S.DIO 1SV308(TPL3,F) T 58.4/7.3
D36 1790001621 S.DIO 1SV308(TPL3,F) T 59.4/35.4
D57 1790001241 S.DIO MA2S7280GL B 19.2/22.2
D58 1790001261 S.DIO MA2S077G0L T 26.1/8.7
D59 1790001261 S.DIO MA2S077G0L T 26.1/10
D60 1790001261 S.DIO MA2S077G0L T 16.5/8.4
D61 1790001261 S.DIO MA2S077G0L T 17.6/10.2
D64 1790001621 S.DIO 1SV308(TPL3,F) B 61.2/16.8
D65 1790001621 S.DIO 1SV308(TPL3,F) B 76.5/8.9
D66 1790001621 S.DIO 1SV308(TPL3,F) B 74.9/10.9
D67 1790001621 S.DIO 1SV308(TPL3,F) B 61.1/13.9
D68 1720000241 S.DIO 1SV172(TE85R,F) B 72.4/42.7
D69 1790001621 S.DIO 1SV308(TPL3,F) B 73.5/31.2
D70 1790001621 S.DIO 1SV308(TPL3,F) B 61.7/11.9
D72 1790001621 S.DIO 1SV308(TPL3,F) B 54.5/16.2
D73 1790001621 S.DIO 1SV308(TPL3,F) B 75.7/12.7
D74 1790001621 S.DIO 1SV308(TPL3,F) B 75.3/15.5
D75 1790001621 S.DIO 1SV308(TPL3,F) T 73.5/5.9
D76 1790001261 S.DIO MA2S077G0L B 61.7/10.5
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF UNIT]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF UNIT]
D100 1750001830 S.VAR SVC389-TL-E B 2.7/15.3
D101 1790001261 S.DIO MA2S077G0L T 71.7/6.7
D106 1750000940 S.DIO 1SS400 TE61 B 33.8/8.2
D107 1750000940 S.DIO 1SS400 TE61 B 33.8/10.8
D108 1750000940 S.DIO 1SS400 TE61 T 10.8/21.9
D109 1750000940 S.DIO 1SS400 TE61 T 11.6/20.1
D110 1750000940 S.DIO 1SS400 TE61 T 12.1/21.9
D111 1750000940 S.DIO 1SS400 TE61 T 7.3/24.7
D112 1750000940 S.DIO 1SS400 TE61 T 6.6/19.8
D113 1750000940 S.DIO 1SS400 TE61 T 6.9/21.1
D114 1790001241 S.DIO MA2S7280GL B 31.4/20.6
D115 1790001790 S.DIO RB876W TL T 24.4/30.4
D116 1790001790 S.DIO RB876W TL T 25.1/26.4
D117 1160000140 S.DIO DAP222 TL B 46.1/11.9
D119 1160000140 S.DIO DAP222 TL B 42.1/14.4
D121 1160000140 S.DIO DAP222 TL B 45.5/17.7
D130 1790001261 S.DIO MA2S077G0L T 26.2/43.2
D131 1790001261 S.DIO MA2S077G0L T 25.1/45.1
D132 1790001261 S.DIO MA2S077G0L T 17.3/43.1
D133 1790001261 S.DIO MA2S077G0L T 18.1/44.9
D134 1750000940 S.DIO 1SS400 TE61 T 13.7/44
D135 1750000940 S.DIO 1SS400 TE61 T 11.9/43.9
D136 1750000940 S.DIO 1SS400 TE61 T 6.5/44.3
D137 1750000940 S.DIO 1SS400 TE61 T 8.3/45
D138 1790001241 S.DIO MA2S7280GL B 19.1/29.2
D139 1790001241 S.DIO MA2S7280GL B 27.8/27.5
D141 1750000711 S.VAR HVC350BTRF-E T 58.4/26.6
D142 1750000711 S.VAR HVC350BTRF-E T 58.5/31
D143 1790001621 S.DIO 1SV308(TPL3,F) T 59.3/33.4
D145 1750000711 S.VAR HVC350BTRF-E B 64.6/34.5
D146 1750000711 S.VAR HVC350BTRF-E B 64/40.2
D147 1790001621 S.DIO 1SV308(TPL3,F) B 61/43.2
D148 1790001241 S.DIO MA2S7280GL B 65.3/27
D149 1790001241 S.DIO MA2S7280GL B 68.1/28.2
D150 1790001241 S.DIO MA2S7280GL T 65.6/20
D151 1790001241 S.DIO MA2S7280GL T 65.1/23
D152 1790001241 S.DIO MA2S7280GL B 61.1/29.7
D153 1790001241 S.DIO MA2S7280GL T 62.9/29.2
D154 1790001241 S.DIO MA2S7280GL T 64/41.5
D155 1790001241 S.DIO MA2S7280GL T 64/40.2
D156 1790001241 S.DIO MA2S7280GL T 60.3/40.7
D157 1790001241 S.DIO MA2S7280GL T 60.3/42
D158 1790001241 S.DIO MA2S7280GL T 62.9/27.7
D159 1790001241 S.DIO MA2S7280GL T 69.3/18.1
D160 1790001241 S.DIO MA2S7280GL T 58/9.5
D161 1790001241 S.DIO MA2S7280GL B 59.8/29.7
D162 1790001241 S.DIO MA2S7280GL B 67.8/20.2
D163 1790001241 S.DIO MA2S7280GL B 57.8/13.2
D164 1790001241 S.DIO MA2S7280GL B 59.1/13.2
D165 1790001241 S.DIO MA2S7280GL T 13.3/4.9
D166 1790001241 S.DIO MA2S7280GL B 67.8/21.5
D167 1790001241 S.DIO MA2S7280GL T 59.3/9.5
D168 1790001241 S.DIO MA2S7280GL T 71/19.4
D169 1790001241 S.DIO MA2S7280GL B 69.9/40.8
D170 1790001241 S.DIO MA2S7280GL B 69.3/45.1
D171 1750000711 S.VAR HVC350BTRF-E T 38.1/13.5
D172 1790001241 S.DIO MA2S7280GL T 13.7/31.9
D173 1750000721 S.VAR HVC375BTRF-E T 69.1/45.9
D174 1750000721 S.VAR HVC375BTRF-E T 69.1/43.3
D175 1750000721 S.VAR HVC375BTRF-E T 61.8/45.1
D176 1750000721 S.VAR HVC375BTRF-E T 61.8/47.6
D178 1750000940 S.DIO 1SS400 TE61 T 48.1/25.7
D179 1750000940 S.DIO 1SS400 TE61 T 46.7/21.7
FI1 2040001200 S.SAW EFCH266MKQP1 T 38/46.7
FI2 2020001270 CER CFWLB450KE2A-B0
(CFWM450E)
FI3 2010002280 S.MON 19S15A 19.650 MHz (FL-293) T 21.5/7.6
FI4 2040001190 S.SAW EFCH429MKQP1 T 37.8/5
FI6 2020001470 CER CFWLA450KL6A002-B0
(CFWS450K3)
FI7 2010002280 S.MON 19S15A 19.650 MHz (FL-293) T 22.3/42.3
FI8 2020001270 CER CFWLB450KE2A-B0
(CFWM450E)
X1 6050010211 S.XTA CR-593A TOP-B 19.200 MHz T 34.2/14.9
L1 6200005741 S.COI ELJRE 47NGFA B 56.8/25.2
L3 6200005681 S.COI ELJRE 15NGFA T 66.4/30.6
L4 6200005701 S.COI ELJRE 22NGFA T 66.2/28
L5 6200005681 S.COI ELJRE 15NGFA T 68.3/27.4
L9 6200005721 S.COI ELJRE 33NGFA T 70.4/5.9
L10 6200005701 S.COI ELJRE 22NGFA T 68.5/5
L11 6200005681 S.COI ELJRE 15NGFA T 70.6/37.8
L12 6200005661 S.COI ELJRE 10NGFA T 67.6/38.6
L13 6200005631 S.COI ELJRE 5N6ZFA T 67.7/34.6
L15 6200005741 S.COI ELJRE 47NGFA T 42.5/48.5
L17 6200007170 S.COI MLF1608A 3R3K-T T 12/6.7
L21 6150004841 S.COI LS-510-LF B 8.5/11.2
L28 6200006671 S.COI ELJRE 68NGFA B 61.6/21.2
L39 6200005731 S.COI ELJRE 39NGFA T 68.3/26.1
L41 6200006981 S.COI ELJRE R10GFA T 62.4/9.7
L43 6200006771 S.COI ELJRE 1N5ZFA T 64.8/35.6
L44 6200005621 S.COI ELJRE 4N7ZFA T 60.8/37.2
L56 6200005641 S.COI ELJRE 6N8ZFA T 49.7/5.2

Jan. 2010
2
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF UNIT]
L60 6200008570 S.COI LQW2BHN6N8D03L T 63.4/12.2
L61 6200008570 S.COI LQW2BHN6N8D03L T 66.9/15.6
L70 6200004720 S.COI MLF1608D R10K-T B 74.6/18
L73 6200006960 S.COI MLF1608A 2R7K-T T 25.4/5.7
L74 6200005741 S.COI ELJRE 47NGFA T 33.2/47.4
L81 6200004940 S.COI MLF1608D R27K-T B 73.1/12.6
L82 6200005140 S.COI MLF1608D R33K-T B 70.3/13.7
L83 6200004790 S.COI MLF1608D R47K-T B 64.9/19
L84 6200003630 S.COI MLF1608D R68K-T B 61.2/18.1
L85 6200006970 S.COI MLF1608A 3R9K-T B 71.4/8.9
L86 6200003630 S.COI MLF1608D R68K-T B 69.4/8.1
L87 6200003960 S.COI MLF1608A 1R0K-T B 66.2/10
L88 6200006710 S.COI MLF1608E 5R6K 5.6U B 66.3/13.8
L89 6200003640 S.COI MLF1608E 100K-T B 63.7/13.8
L90 6200002041 S.COI NLV25T-101J B 55.6/13.9
L91 6200006970 S.COI MLF1608A 3R9K-T B 73.4/8.9
L92 6200005180 S.COI MLF1608D R39K-T T 65.9/8.5
L93 6200005701 S.COI ELJRE 22NGFA T 42.7/5.2
L94 6200005721 S.COI ELJRE 33NGFA T 33.3/2.8
L95 6200005681 S.COI ELJRE 15NGFA T 32.4/5.3
L99 6200005501 S.COI NLV32T-471J T 8.3/26.9
L101 6200005641 S.COI ELJRE 6N8ZFA T 48.8/50.1
L102 6200006960 S.COI MLF1608A 2R7K-T T 24.3/39.4
L104 6200007170 S.COI MLF1608A 3R3K-T T 11.8/34.5
L105 6150004841 S.COI LS-510-LF B 8.7/37.5
L106 6200005501 S.COI NLV32T-471J T 9.3/47.8
L112 6200008570 S.COI LQW2BHN6N8D03L T 61.9/24.9
L113 6200008570 S.COI LQW2BHN6N8D03L T 59/29.3
L119 6200006671 S.COI ELJRE 68NGFA B 60.6/34.3
L120 6200005741 S.COI ELJRE 47NGFA B 65.2/36.9
L121 6200009101 S.COI ELJRE R18GFA B 70.3/25.2
L122 6200007740 S.COI LQW2BHN47NJ03L T 67.8/21.5
L123 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00) T 76.1/23.5
L124 6200010910 S.COI LQW18AN56NG00D T 76.1/19.4
L125 6200009290 S.COI LQW18AN47NG00D
(LQW1608A47NG00) T 76.3/15.5
L126 6200009070 S.COI LQW18AN18NG00D
(LQW1608A18NG00) T 72.7/27.5
L127 6200009070 S.COI LQW18AN18NG00D
(LQW1608A18NG00) T 72.7/30.9
L128 6200006981 S.COI ELJRE R10GFA B 71.6/17.6
L129 6200005611 S.COI ELJRE 3N9ZFA T 67.8/45.9
L130 6200005611 S.COI ELJRE 3N9ZFA T 67.8/43.2
L131 6200005611 S.COI ELJRE 3N9ZFA T 63.1/45
L132 6200005611 S.COI ELJRE 3N9ZFA T 63.1/47.6
L133 6200006991 S.COI ELJRE 56NGFA T 64.6/4.9
L134 6200003550 S.COI MLF1608A 4R7K-T T 31.3/8.5
R4 7030007280 S.RES ERJ2GEJ 331 X (330) T 48.4/8.3
R6 7030005710 S.RES ERJ2GEJ 121 X (120) T 62.9/3.7
R8 7030007340 S.RES ERJ2GEJ 153 X (15K) B 63.2/20.7
R9 7030005310 S.RES ERJ2GEJ 124 X (120K) B 66.1/22.3
R10 7030005240 S.RES ERJ2GEJ 473 X (47K) B 59.4/20.5
R11 7030005240 S.RES ERJ2GEJ 473 X (47K) B 57.1/20.4
R13 7030007340 S.RES ERJ2GEJ 153 X (15K) T 70.3/16.4
R14 7030005070 S.RES ERJ2GEJ 683 X (68K) T 70.8/15
R15 7030005240 S.RES ERJ2GEJ 473 X (47K) T 65.4/14.9
R16 7030005240 S.RES ERJ2GEJ 473 X (47K) T 61.9/14.8
R18 7030007340 S.RES ERJ2GEJ 153 X (15K) T 64.6/7.1
R19 7030005240 S.RES ERJ2GEJ 473 X (47K) T 64.6/37.8
R20 7030007280 S.RES ERJ2GEJ 331 X (330) T 63.3/34.3
R26 7030005240 S.RES ERJ2GEJ 473 X (47K) B 21.6/21.6
R28 7030005160 S.RES ERJ2GEJ 105 X (1M) B 25.1/20.4
R29 7030005170 S.RES ERJ2GEJ 474 X (470K) B 25.5/22.9
R30 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 14.7/24.6
R31 7030005120 S.RES ERJ2GEJ 102 X (1K) B 19.6/25.3
R34 7030005120 S.RES ERJ2GEJ 102 X (1K) T 13.3/9.9
R35 7030007340 S.RES ERJ2GEJ 153 X (15K) T 13.7/6.2
R36 7030005110 S.RES ERJ2GEJ 224 X (220K) T 15.3/6.4
R46 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 9.3/21.1
R49 7030005050 S.RES ERJ2GEJ 103 X (10K) T 9.4/20.1
R50 7030005050 S.RES ERJ2GEJ 103 X (10K) T 7.5/18.6
R54 7030005220 S.RES ERJ2GEJ 223 X (22K) T 6.6/5.2
R55 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 6.5/6.2
R56 7030005000 S.RES ERJ2GEJ 471 X (470) T 5.1/9.9
R57 7030007340 S.RES ERJ2GEJ 153 X (15K) T 5.1/13.5
R58 7030005010 S.RES ERJ2GEJ 681 X (680) T 3.7/13
R59 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 3.1/14.3
R60 7030005090 S.RES ERJ2GEJ 104 X (100K) T 5.7/15.8
R61 7030005240 S.RES ERJ2GEJ 473 X (47K) T 3.9/15.6
R62 7030009160 S.RES ERJ2GEJ 181 X (180) T 13.8/11.2
R68 7030005240 S.RES ERJ2GEJ 473 X (47K) T 10.6/4.9
R78 7030007280 S.RES ERJ2GEJ 331 X (330) B 67.3/25.1
R81 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 56.1/20.4
R88 7030007280 S.RES ERJ2GEJ 331 X (330) T 69.6/11.9
R91 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 60.9/14.8
R93 7030005710 S.RES ERJ2GEJ 121 X (120) T 66.3/47.5
R95 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 70.9/41.9
R98 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 71.8/37.6
R99 7030005120 S.RES ERJ2GEJ 102 X (1K) T 73.5/34.2
R100 7030008010 S.RES ERJ2GEJ 123 X (12K) T 64.6/42.7
R101 7030005240 S.RES ERJ2GEJ 473 X (47K) T 65.9/43.3
R102 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 59.9/44.5
R103 7030005050 S.RES ERJ2GEJ 103 X (10K) T 35.5/19.9
R105 7030005590 S.RES ERJ2GEJ 680 X (68) T 61.8/8.2
R106 7030005240 S.RES ERJ2GEJ 473 X (47K) T 64.3/9.1
R108 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 60.6/8.2
R110 7030008010 S.RES ERJ2GEJ 123 X (12K) T 63.5/39
R112 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 58.6/37.5
R116 7030005100 S.RES ERJ2GEJ 154 X (150K) B 13.7/24.6
R159 7030005120 S.RES ERJ2GEJ 102 X (1K) T 10.7/16.3
R172 7030005050 S.RES ERJ2GEJ 103 X (10K) T 7.5/17.6
R174 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 13.3/21.3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF UNIT]
R177 7030005090 S.RES ERJ2GEJ 104 X (100K) B 17.8/24.9
R179 7030005100 S.RES ERJ2GEJ 154 X (150K) B 14.4/22.8
R203 7030004980 S.RES ERJ2GEJ 101 X (100) T 26.9/11.4
R204 7030005120 S.RES ERJ2GEJ 102 X (1K) T 26.6/6.2
R205 7030005050 S.RES ERJ2GEJ 103 X (10K) T 17/5.6
R207 7030005050 S.RES ERJ2GEJ 103 X (10K) T 19.2/10.7
R208 7030005050 S.RES ERJ2GEJ 103 X (10K) T 15.3/10
R209 7030005010 S.RES ERJ2GEJ 681 X (680) T 17/6.6
R216 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 73.1/15.5
R220 7030005300 S.RES ERJ2GEJ 150 X (15) T 48.9/7
R221 7030007280 S.RES ERJ2GEJ 331 X (330) T 49.4/8.3
R222 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 68.3/17.7
R223 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 62.9/17.9
R224 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 59.5/17.8
R225 7030005120 S.RES ERJ2GEJ 102 X (1K) B 77.2/6.8
R226 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 68.9/6.9
R228 7030004980 S.RES ERJ2GEJ 101 X (100) B 58.5/18.8
R229 7030005240 S.RES ERJ2GEJ 473 X (47K) B 58.2/14.9
R230 7030005050 S.RES ERJ2GEJ 103 X (10K) B 58.4/16.2
R231 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 58.2/6.1
R232 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 72/31.8
R233 7030009270 S.RES ERJ2GEJ 821 X (820) B 71/31.8
R234 7030009270 S.RES ERJ2GEJ 821 X (820) B 71.8/33.1
R235 7030005120 S.RES ERJ2GEJ 102 X (1K) B 71.3/34.4
R236 7030005050 S.RES ERJ2GEJ 103 X (10K) B 68.2/34.1
R237 7030009140 S.RES ERJ2GEJ 272 X (2.7K) B 71.8/29.3
R238 7030005090 S.RES ERJ2GEJ 104 X (100K) B 68.5/40
R239 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 69/32
R240 7030005120 S.RES ERJ2GEJ 102 X (1K) B 66.2/12.6
R241 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 62.8/8
R243 7030005090 S.RES ERJ2GEJ 104 X (100K) B 3.2/12.6
R245 7030005220 S.RES ERJ2GEJ 223 X (22K) B 58.9/6.6
R246 7030005110 S.RES ERJ2GEJ 224 X (220K) B 2.4/10.6
R247 7030011150 S.RES ERJ2GEJ 2R7 X (2.7) B 64/5.3
R323 7030004990 S.RES ERJ2GEJ 221 X (220) T 53.8/6.9
R324 7030004980 S.RES ERJ2GEJ 101 X (100) T 52.1/5.7
R325 7030005570 S.RES ERJ2GEJ 820 X (82) T 51.6/4.4
R326 7030005570 S.RES ERJ2GEJ 820 X (82) T 51.1/5.7
R327 7030004980 S.RES ERJ2GEJ 101 X (100) B 71.4/40.5
R329 7030005090 S.RES ERJ2GEJ 104 X (100K) B 44.4/5
R330 7030007340 S.RES ERJ2GEJ 153 X (15K) B 45.7/5.7
R335 7030005090 S.RES ERJ2GEJ 104 X (100K) T 73.1/7.6
R346 7030005050 S.RES ERJ2GEJ 103 X (10K) T 12.9/24.1
R347 7030005050 S.RES ERJ2GEJ 103 X (10K) T 2.4/19.5
R352 7030005090 S.RES ERJ2GEJ 104 X (100K) T 24.3/14.6
R353 7030005240 S.RES ERJ2GEJ 473 X (47K) T 23.3/12.8
R354 7030005600 S.RES ERJ2GEJ 273 X (27K) T 23.3/14.6
R355 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 26.3/16.3
R356 7030008280 S.RES ERJ2GEJ 271 X (270) T 25.3/12.8
R357 7030005230 S.RES ERJ2GEJ 334 X (330K) T 30.7/20.1
R358 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 27.1/19.8
R359 7030005110 S.RES ERJ2GEJ 224 X (220K) T 27.6/21.9
R360 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 26.1/19
R361 7030005100 S.RES ERJ2GEJ 154 X (150K) T 25/19.6
R362 7030005100 S.RES ERJ2GEJ 154 X (150K) T 25.2/22.7
R363 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 21.2/22.7
R364 7030005720 S.RES ERJ2GEJ 563 X (56K) T 23.2/22.7
R365 7030005220 S.RES ERJ2GEJ 223 X (22K) T 21.5/20.7
R366 7030005090 S.RES ERJ2GEJ 104 X (100K) T 26.3/22.7
R367 7030005110 S.RES ERJ2GEJ 224 X (220K) T 27.3/23.3
R368 7030007340 S.RES ERJ2GEJ 153 X (15K) T 20.2/19.6
R369 7030007280 S.RES ERJ2GEJ 331 X (330) T 20/22.7
R370 7030005050 S.RES ERJ2GEJ 103 X (10K) T 14.9/20.3
R372 7030005090 S.RES ERJ2GEJ 104 X (100K) T 1.9/27.5
R373 7030008410 S.RES ERJ2GEJ 392 X (3.9K) B 26.5/22
R374 7030005050 S.RES ERJ2GEJ 103 X (10K) B 29.7/20.2
R375 7030005050 S.RES ERJ2GEJ 103 X (10K) B 26.9/23.3
R376 7030005220 S.RES ERJ2GEJ 223 X (22K) B 29.5/22.7
R377 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 33.1/22.7
R378 7030005090 S.RES ERJ2GEJ 104 X (100K) B 33.4/25.5
R379 7030007310 S.RES ERJ2GEJ 155 X (1.5M) T 22.5/30
R380 7030009140 S.RES ERJ2GEJ 272 X (2.7K) T 23.6/27.6
R381 7030007280 S.RES ERJ2GEJ 331 X (330) T 18.1/31.3
R382 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 17.2/30.3
R383 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 18/25.9
R384 7030005240 S.RES ERJ2GEJ 473 X (47K) T 15.6/29.2
R385 7030005090 S.RES ERJ2GEJ 104 X (100K) T 15.1/27.8
R386 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 19.5/30.4
R387 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 21.1/26
R388 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 20.5/30.4
R389 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 19.1/27.4
R390 7030005600 S.RES ERJ2GEJ 273 X (27K) T 26/30.4
R391 7030005050 S.RES ERJ2GEJ 103 X (10K) T 26.3/28.4
R392 7030005240 S.RES ERJ2GEJ 473 X (47K) T 27.3/28.4
R393 7030005220 S.RES ERJ2GEJ 223 X (22K) T 30.1/26.8
R394 7030005600 S.RES ERJ2GEJ 273 X (27K) T 29.8/31
R396 7030005220 S.RES ERJ2GEJ 223 X (22K) T 16/26.1
R397 7030005090 S.RES ERJ2GEJ 104 X (100K) B 42.2/20.6
R398 7030005090 S.RES ERJ2GEJ 104 X (100K) B 39.8/17.9
R414 7030008010 S.RES ERJ2GEJ 123 X (12K) T 12/13.3
R415 7030007310 S.RES ERJ2GEJ 155 X (1.5M) T 13.8/13.3
R423 7030005300 S.RES ERJ2GEJ 150 X (15) T 48.8/45.5
R425 7030005120 S.RES ERJ2GEJ 102 X (1K) T 27.2/39.9
R426 7030005010 S.RES ERJ2GEJ 681 X (680) T 17.8/41.4
R427 7030004980 S.RES ERJ2GEJ 101 X (100) T 25.4/46.3
R428 7030005050 S.RES ERJ2GEJ 103 X (10K) T 19.8/45.4
R429 7030005050 S.RES ERJ2GEJ 103 X (10K) T 15.6/36.7
R430 7030005050 S.RES ERJ2GEJ 103 X (10K) T 17.4/40.1
R431 7030005110 S.RES ERJ2GEJ 224 X (220K) T 15.6/33
R432 7030007340 S.RES ERJ2GEJ 153 X (15K) T 14.3/33.1
R433 7030005120 S.RES ERJ2GEJ 102 X (1K) T 14.6/36.7
R434 7030009160 S.RES ERJ2GEJ 181 X (180) T 12.2/38.5
R435 7030005240 S.RES ERJ2GEJ 473 X (47K) T 10.2/32.3
R436 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 4.5/33.4
R437 7030005220 S.RES ERJ2GEJ 223 X (22K) T 5/32.1

Jan. 2010
3
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF UNIT]
R438 7030005090 S.RES ERJ2GEJ 104 X (100K) T 6.2/41.6
R439 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 2.9/40.6
R440 7030005240 S.RES ERJ2GEJ 473 X (47K) T 4.7/43
R441 7030005010 S.RES ERJ2GEJ 681 X (680) T 3.4/39.1
R442 7030007340 S.RES ERJ2GEJ 153 X (15K) T 4.9/39.6
R443 7030005000 S.RES ERJ2GEJ 471 X (470) T 4.9/36
R444 7030005120 S.RES ERJ2GEJ 102 X (1K) T 10.9/42.4
R445 7030005050 S.RES ERJ2GEJ 103 X (10K) T 15.1/42.9
R446 7030005050 S.RES ERJ2GEJ 103 X (10K) B 6.3/44.1
R447 7030004990 S.RES ERJ2GEJ 221 X (220) T 10.8/45.8
R448 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 12.9/48.7
R449 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 14.2/48.2
R450 7030005050 S.RES ERJ2GEJ 103 X (10K) T 9.5/45.2
R451 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 15/31.4
R452 7030005100 S.RES ERJ2GEJ 154 X (150K) B 14/31.4
R453 7030005100 S.RES ERJ2GEJ 154 X (150K) B 14.9/29.4
R454 7030005090 S.RES ERJ2GEJ 104 X (100K) B 18.3/31.9
R455 7030005120 S.RES ERJ2GEJ 102 X (1K) B 20.2/32
R457 7030005240 S.RES ERJ2GEJ 473 X (47K) B 20.7/27.3
R458 7030005160 S.RES ERJ2GEJ 105 X (1M) B 24/27.4
R459 7030005170 S.RES ERJ2GEJ 474 X (470K) B 24.5/29.8
R461 7030005050 S.RES ERJ2GEJ 103 X (10K) T 7/32.1
R462 7030008410 S.RES ERJ2GEJ 392 X (3.9K) B 25.3/28.4
R463 7030005050 S.RES ERJ2GEJ 103 X (10K) B 25.9/30.1
R464 7030005050 S.RES ERJ2GEJ 103 X (10K) B 29.2/29.9
R465 7030005220 S.RES ERJ2GEJ 223 X (22K) B 30/27.5
R466 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 32.8/31.6
R467 7030005090 S.RES ERJ2GEJ 104 X (100K) T 34/37.2
R469 7030005070 S.RES ERJ2GEJ 683 X (68K) T 63.2/21.1
R471 7030007340 S.RES ERJ2GEJ 153 X (15K) T 64.9/21.8
R472 7030007280 S.RES ERJ2GEJ 331 X (330) T 59.2/22.2
R473 7030005240 S.RES ERJ2GEJ 473 X (47K) T 61.4/26.7
R474 7030005240 S.RES ERJ2GEJ 473 X (47K) T 61.6/30.5
R475 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 61.6/31.5
R476 7030005310 S.RES ERJ2GEJ 124 X (120K) B 63/30.9
R478 7030007280 S.RES ERJ2GEJ 331 X (330) B 63.7/29.4
R479 7030007340 S.RES ERJ2GEJ 153 X (15K) B 61.6/31.9
R481 7030005240 S.RES ERJ2GEJ 473 X (47K) B 62.1/36.4
R482 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 62/41.5
R483 7030005240 S.RES ERJ2GEJ 473 X (47K) B 61.6/38.1
R484 7030005220 S.RES ERJ2GEJ 223 X (22K) B 71/19.4
R485 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 71/21.4
R486 7030004980 S.RES ERJ2GEJ 101 X (100) B 70.7/22.7
R487 7030004980 S.RES ERJ2GEJ 101 X (100) B 65.5/28.4
R488 7030007280 S.RES ERJ2GEJ 331 X (330) B 74.9/19.2
R489 7030005220 S.RES ERJ2GEJ 223 X (22K) T 65/27.8
R490 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 66.7/24.1
R491 7030007280 S.RES ERJ2GEJ 331 X (330) T 70.5/26.1
R492 7030007270 S.RES ERJ2GEJ 151 X (150) T 71.8/15
R493 7030007270 S.RES ERJ2GEJ 151 X (150) T 64/20
R494 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 70/7.6
R495 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 71.9/9.4
R496 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 74.7/7.1
R497 7030004990 S.RES ERJ2GEJ 221 X (220) T 54.6/46.5
R498 7030004980 S.RES ERJ2GEJ 101 X (100) T 52/48.9
R499 7030005570 S.RES ERJ2GEJ 820 X (82) T 51.1/50.2
R500 7030005570 S.RES ERJ2GEJ 820 X (82) T 50.6/48.9
R501 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 57.5/41.8
R503 7030007310 S.RES ERJ2GEJ 155 X (1.5M) T 14.1/39.1
R505 7030008010 S.RES ERJ2GEJ 123 X (12K) T 12.6/40.6
R510 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 73.4/27.1
R511 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 73.6/35.2
R512 7030008410 S.RES ERJ2GEJ 392 X (3.9K) T 35.1/9.3
R513 7030005110 S.RES ERJ2GEJ 224 X (220K) T 35.3/10.9
R514 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 31.7/11.3
R515 7030005090 S.RES ERJ2GEJ 104 X (100K) T 39/15.1
R516 7030005090 S.RES ERJ2GEJ 104 X (100K) T 39.2/10.8
R517 7030005120 S.RES ERJ2GEJ 102 X (1K) T 15.1/16.7
R518 7030005120 S.RES ERJ2GEJ 102 X (1K) T 18.9/37.5
R519 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 10.3/43.9
R520 7030004970 S.RES ERJ2GEJ 470 X (47) T 25.7/7.5
R521 7030004970 S.RES ERJ2GEJ 470 X (47) T 26.2/39.9
R522 7030005090 S.RES ERJ2GEJ 104 X (100K) T 70.3/43.6
R523 7030005090 S.RES ERJ2GEJ 104 X (100K) T 61.1/49.3
R524 7030005090 S.RES ERJ2GEJ 104 X (100K) T 60.9/43.5
R525 7030005530 S.RES ERJ2GEJ 100 X (10) B 19.1/23.9
R526 7030005530 S.RES ERJ2GEJ 100 X (10) B 20.7/23.8
R527 7030005530 S.RES ERJ2GEJ 100 X (10) B 19.7/30.7
R528 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 31.4/26.5
R529 7030005000 S.RES ERJ2GEJ 471 X (470) T 4.7/24.3
R530 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 19.1/14.7
R531 7030005090 S.RES ERJ2GEJ 104 X (100K) B 69.6/27.4
R532 7030005530 S.RES ERJ2GEJ 100 X (10) B 45.2/10.2
R533 7030005530 S.RES ERJ2GEJ 100 X (10) B 68.1/45.4
R534 7030011150 S.RES ERJ2GEJ 2R7 X (2.7) B 49.3/32.9
R536 7030003290 S.RES ERJ3GEYJ 560 V (56) T 23.5/10.3
R537 7030003290 S.RES ERJ3GEYJ 560 V (56) T 22.5/45.1
R538 7030010040 S.RES ERJ2GEJ-JPW B 67.9/4.6
R539 7030005300 S.RES ERJ2GEJ 150 X (15) B 62.7/22.3
R540 7030005300 S.RES ERJ2GEJ 150 X (15) B 62.3/34.1
R541 7030007270 S.RES ERJ2GEJ 151 X (150) T 51/33.7
R542 7030007340 S.RES ERJ2GEJ 153 X (15K) T 4.8/27
C5 4030017730 S.CER ECJ0EB1E471K T 66.4/35.8
C12 4030017420 S.CER ECJ0EC1H470J B 72.8/18
C13 4030017650 S.CER ECJ0EC1H270J B 72.8/19.4
C14 4030017460 S.CER ECJ0EB1E102K B 59.9/21.8
C15 4030017340 S.CER ECJ0EC1H010B B 58.1/22.9
C16 4030017460 S.CER ECJ0EB1E102K B 58.1/21.7
C18 4030016790 S.CER ECJ0EB1C103K T 27.6/6.3
C22 4030017590 S.CER ECJ0EC1H070C T 69.1/29.6
C23 4030017380 S.CER ECJ0EC1H050B T 69.1/28.6
C27 4030017460 S.CER ECJ0EB1E102K T 68.6/11.9
C28 4030017460 S.CER ECJ0EB1E102K T 67/13.5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF UNIT]
C30 4030017460 S.CER ECJ0EB1E102K T 65.4/16.7
C32 4030017460 S.CER ECJ0EB1E102K T 70.3/45.4
C40 4030017640 S.CER ECJ0EC1H150J T 68.5/7.5
C41 4030017380 S.CER ECJ0EC1H050B T 67.5/7.5
C42 4030017370 S.CER ECJ0EC1H3R5B T 68/6.2
C43 4030017430 S.CER ECJ0EC1H101J T 66.3/4
C44 4030016790 S.CER ECJ0EB1C103K T 62.9/8.2
C45 4030017730 S.CER ECJ0EB1E471K T 71/34.3
C46 4030017360 S.CER ECJ0EC1H030B T 69.4/34.5
C47 4030017580 S.CER ECJ0EC1H060C T 70.5/35.6
C48 4030017580 S.CER ECJ0EC1H060C T 68.9/37.1
C49 4030017360 S.CER ECJ0EC1H030B T 68.4/35.8
C50 4030017340 S.CER ECJ0EC1H010B T 67.5/33.4
C51 4030017560 S.CER ECJ0EC1H2R5B T 66.9/37.1
C52 4030017730 S.CER ECJ0EB1E471K T 62.3/34.3
C54 4030017460 S.CER ECJ0EB1E102K T 69.8/40.4
C55 4030017460 S.CER ECJ0EB1E102K T 71.9/39.4
C58 4030017460 S.CER ECJ0EB1E102K T 63.2/14.4
C59 4030017350 S.CER ECJ0EC1H020B T 65.2/13.5
C60 4030016790 S.CER ECJ0EB1C103K B 26/24.3
C61 4030017460 S.CER ECJ0EB1E102K B 25.1/21.6
C62 4550007480 S.TAN F930J106MAABMA B 16.2/20.4
C63 4030017700 S.CER ECJ0EC1H151J B 16/24.9
C64 4030017640 S.CER ECJ0EC1H150J B 13.4/22.8
C65 4030016790 S.CER ECJ0EB1C103K B 23.7/21.1
C66 4030016790 S.CER ECJ0EB1C103K B 23.5/25.3
C69 4030017460 S.CER ECJ0EB1E102K B 65.1/25.1
C70 4030017460 S.CER ECJ0EB1E102K T 48.3/3.2
C71 4030017360 S.CER ECJ0EC1H030B T 44/49.6
C73 4030017460 S.CER ECJ0EB1E102K T 14.3/9.9
C74 4030017460 S.CER ECJ0EB1E102K B 68.5/41
C75 4030017460 S.CER ECJ0EB1E102K T 12/10.5
C92 4030016790 S.CER ECJ0EB1C103K T 8.5/16.3
C93 4030017460 S.CER ECJ0EB1E102K T 12/12.3
C94 4030017460 S.CER ECJ0EB1E102K T 5.1/8.1
C95 4030017460 S.CER ECJ0EB1E102K T 4/11.7
C96 4030016790 S.CER ECJ0EB1C103K T 5.1/11.7
C97 4030016790 S.CER ECJ0EB1C103K T 4.1/14.3
C98 4030017730 S.CER ECJ0EB1E471K T 3.9/16.6
C99 4030017730 S.CER ECJ0EB1E471K T 5.7/16.8
C100 4030016930 S.CER ECJ0EB1A104K T 7/16.3
C101 4030017620 S.CER ECJ0EC1H100C T 6.5/7.2
C102 4030017460 S.CER ECJ0EB1E102K T 12.2/8.9
C103 4030016790 S.CER ECJ0EB1C103K T 8.4/7.2
C121 4030017460 S.CER ECJ0EB1E102K B 56.3/21.7
C134 4030017460 S.CER ECJ0EB1E102K T 69.4/15.4
C136 4030017590 S.CER ECJ0EC1H070C T 61.4/13.5
C138 4030017730 S.CER ECJ0EB1E471K T 65.3/47.5
C141 4030016790 S.CER ECJ0EB1C103K T 63.1/6.8
C142 4030017460 S.CER ECJ0EB1E102K T 60.9/6.9
C145 4030017460 S.CER ECJ0EB1E102K T 66.6/45.1
C147 4030017560 S.CER ECJ0EC1H2R5B T 59.6/37.1
C148 4030017730 S.CER ECJ0EB1E471K T 62.2/38.5
C150 4030017460 S.CER ECJ0EB1E102K T 57.1/15
C153 4030016930 S.CER ECJ0EB1A104K T 48.1/6
C200 4030016790 S.CER ECJ0EB1C103K B 21.9/20.6
C201 4030016930 S.CER ECJ0EB1A104K T 16/4.3
C202 4030016930 S.CER ECJ0EB1A104K T 20.5/11.2
C203 4030016930 S.CER ECJ0EB1A104K B 35.4/15.3
C206 4030017370 S.CER ECJ0EC1H3R5B T 47.8/4.5
C214 4030017460 S.CER ECJ0EB1E102K T 64.6/43.9
C218 4030017340 S.CER ECJ0EC1H010B T 67.8/29.1
C221 4030016790 S.CER ECJ0EB1C103K T 8.8/18.8
C233 4030017460 S.CER ECJ0EB1E102K B 60.9/19.3
C239 4030016790 S.CER ECJ0EB1C103K T 9.7/16.3
C241 4030011810 S.CER C1608 JB 1A 224K-T B 4.7/13.2
C242 4030011810 S.CER C1608 JB 1A 224K-T T 3/6.3
C259 4030017430 S.CER ECJ0EC1H101J T 9.2/6.2
C264 4030017460 S.CER ECJ0EB1E102K T 72.4/20.2
C402 4030017460 S.CER ECJ0EB1E102K B 42.1/26.5
C408 4030017460 S.CER ECJ0EB1E102K B 53/22.7
C410 4030017460 S.CER ECJ0EB1E102K T 68.9/16.7
C414 4030017460 S.CER ECJ0EB1E102K T 59.7/39
C416 4030017650 S.CER ECJ0EC1H270J B 73.3/16.7
C424 4030016790 S.CER ECJ0EB1C103K T 15.7/14.9
C427 4030017400 S.CER ECJ0EC1H220J T 23.7/5
C430 4030016790 S.CER ECJ0EB1C103K T 17.7/7.9
C431 4030016790 S.CER ECJ0EB1C103K T 15.3/8.2
C432 4030017460 S.CER ECJ0EB1E102K T 29.7/4.1
C433 4030017460 S.CER ECJ0EB1E102K B 44.3/12.4
C434 4030016930 S.CER ECJ0EB1A104K B 37/16.1
C435 4030017460 S.CER ECJ0EB1E102K T 25.8/2.8
C436 4030017360 S.CER ECJ0EC1H030B T 31.7/46.8
C503 4030017460 S.CER ECJ0EB1E102K B 42.4/8.1
C504 4030017460 S.CER ECJ0EB1E102K B 49.1/43.7
C505 4030017460 S.CER ECJ0EB1E102K B 48.5/45.8
C511 4030018010 S.CER ECJ0EC1H360J B 73.3/13.8
C512 4030017620 S.CER ECJ0EC1H100C B 70.8/12.5
C513 4030017430 S.CER ECJ0EC1H101J B 74.6/14.1
C514 4030017710 S.CER ECJ0EC1H181J B 72/14.2
C515 4030017690 S.CER ECJ0EC1H121J B 69.5/15.2
C516 4030017440 S.CER ECJ0EC1H221J B 67/16.8
C517 4030017430 S.CER ECJ0EC1H101J B 65.2/16.8
C518 4030017440 S.CER ECJ0EC1H221J B 63.4/16.6
C519 4030017780 S.CER ECJ0EB1E472K B 66/17.8
C520 4030018080 S.CER ECJ0EB1H182K B 64.2/17.8
C521 4030016930 S.CER ECJ0EB1A104K B 67.1/18.8
C522 4030017910 S.CER ECJ0EB1H152K B 74.2/6.7
C523 4030017910 S.CER ECJ0EB1H152K B 72.2/6.7
C524 4030016790 S.CER ECJ0EB1C103K B 70.2/6.6
C525 4030017780 S.CER ECJ0EB1E472K B 73.2/6.7
C526 4030017900 S.CER ECJ0EB1C123K B 71.2/6.7
C527 4030017420 S.CER ECJ0EC1H470J B 69.1/9.3
C528 4030017620 S.CER ECJ0EC1H100C B 66.2/11.2
C529 4030017700 S.CER ECJ0EC1H151J B 69.2/10.6

Jan. 2010
4
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF UNIT]
C530 4030017450 S.CER ECJ0EB1E271K B 68.2/10.6
C531 4030017430 S.CER ECJ0EC1H101J B 63.7/11.5
C532 4030016930 S.CER ECJ0EB1A104K B 73.9/4.8
C533 4030017910 S.CER ECJ0EB1H152K B 67.5/15.3
C534 4030017430 S.CER ECJ0EC1H101J B 66.2/15
C535 4030017750 S.CER ECJ0EB1E122K B 64.9/15.3
C536 4030016930 S.CER ECJ0EB1A104K B 54.6/5.3
C537 4030016930 S.CER ECJ0EB1A104K B 60.4/15.4
C538 4030016930 S.CER ECJ0EB1A104K B 57.1/18.6
C539 4030016930 S.CER ECJ0EB1A104K B 56.1/18.6
C540 4030016930 S.CER ECJ0EB1A104K B 71.8/30.3
C541 4030016930 S.CER ECJ0EB1A104K B 74/40.1
C542 4030016930 S.CER ECJ0EB1A104K B 73.4/37
C543 4030017460 S.CER ECJ0EB1E102K B 67.3/31.7
C544 4030017460 S.CER ECJ0EB1E102K B 67.2/34.1
C545 4030016790 S.CER ECJ0EB1C103K B 69.7/43.3
C546 4030016930 S.CER ECJ0EB1A104K B 73.4/33.4
C548 4030017460 S.CER ECJ0EB1E102K B 71.3/15.5
C558 4030017460 S.CER ECJ0EB1E102K B 67.3/36.1
C560 4030017460 S.CER ECJ0EB1E102K T 55/9.8
C561 4030017460 S.CER ECJ0EB1E102K B 54.8/19.5
C562 4030017460 S.CER ECJ0EB1E102K B 58.8/10.3
C563 4030017460 S.CER ECJ0EB1E102K B 70/30.2
C566 4030016790 S.CER ECJ0EB1C103K B 64.3/7.5
C567 4030016930 S.CER ECJ0EB1A104K B 2.2/12.6
C568 4030017420 S.CER ECJ0EC1H470J T 60/5.6
C569 4030016930 S.CER ECJ0EB1A104K B 63/6.6
C570 4030017460 S.CER ECJ0EB1E102K B 71.8/28.3
C571 4030017460 S.CER ECJ0EB1E102K B 54.6/3.5
C657 4030017700 S.CER ECJ0EC1H151J B 63.6/15
C658 4030018140 S.CER ECJ0EB1H391K B 62.3/15.3
C659 4550007480 S.TAN F930J106MAABMA B 8.2/15.7
C662 4030016930 S.CER ECJ0EB1A104K T 56.6/7.7
C663 4030016930 S.CER ECJ0EB1A104K T 53.4/4.4
C664 4030016930 S.CER ECJ0EB1A104K T 55.1/7.4
C665 4030017430 S.CER ECJ0EC1H101J T 66.3/5
C666 4030018140 S.CER ECJ0EB1H391K T 65.8/6.3
C667 4030016790 S.CER ECJ0EB1C103K B 71.8/35.7
C669 4030017460 S.CER ECJ0EB1E102K B 45.7/4.7
C673 4030017460 S.CER ECJ0EB1E102K T 70.6/9.1
C674 4030017420 S.CER ECJ0EC1H470J B 69.5/34.6
C676 4030017400 S.CER ECJ0EC1H220J T 69.3/8.9
C677 4030017350 S.CER ECJ0EC1H020B T 43.6/7
C678 4030017460 S.CER ECJ0EB1E102K T 32.1/2.9
C679 4030017460 S.CER ECJ0EB1E102K T 33/7.5
C683 4030017460 S.CER ECJ0EB1E102K T 30.8/3.3
C686 4030018140 S.CER ECJ0EB1H391K T 10.2/24.9
C687 4030018140 S.CER ECJ0EB1H391K T 5.3/28.3
C688 4030016790 S.CER ECJ0EB1C103K T 1.7/18.1
C689 4030016790 S.CER ECJ0EB1C103K T 9.8/18.8
C690 4030016790 S.CER ECJ0EB1C103K T 6.1/18.3
C691 4030016790 S.CER ECJ0EB1C103K T 11.5/24.1
C692 4030016790 S.CER ECJ0EB1C103K T 4.9/21.3
C694 4030016930 S.CER ECJ0EB1A104K T 22.3/14.7
C697 4030016790 S.CER ECJ0EB1C103K T 27.6/17
C698 4030016790 S.CER ECJ0EB1C103K T 24.3/12.8
C699 4030017440 S.CER ECJ0EC1H221J T 29.4/21.9
C700 4030016790 S.CER ECJ0EB1C103K T 26.1/20.8
C701 4030016790 S.CER ECJ0EB1C103K T 22.2/22.7
C702 4030016930 S.CER ECJ0EB1A104K T 24.2/22.7
C703 4030017480 S.CER C1608 JB 1A 474K-T T 29.2/25.2
C704 4030016790 S.CER ECJ0EB1C103K T 19/22.7
C705 4030016930 S.CER ECJ0EB1A104K T 14.9/22.8
C706 4030017460 S.CER ECJ0EB1E102K T 1.9/24.1
C707 4030017460 S.CER ECJ0EB1E102K B 28.7/20.2
C708 4030011810 S.CER C1608 JB 1A 224K-T B 28.4/24.4
C709 4030016930 S.CER ECJ0EB1A104K B 31.3/22.7
C710 4030017460 S.CER ECJ0EB1E102K B 32.5/23.7
C711 4030016930 S.CER ECJ0EB1A104K T 20.1/27.8
C712 4030016930 S.CER ECJ0EB1A104K T 21.5/30
C713 4030016930 S.CER ECJ0EB1A104K T 28.8/31
C714 4030016790 S.CER ECJ0EB1C103K T 17.9/29.2
C715 4030016790 S.CER ECJ0EB1C103K T 19.3/26
C716 4030017730 S.CER ECJ0EB1E471K T 26.7/26.4
C717 4030016930 S.CER ECJ0EB1A104K T 25.3/28.4
C718 4030016790 S.CER ECJ0EB1C103K T 27.7/26.6
C719 4030017460 S.CER ECJ0EB1E102K T 28.7/26.8
C720 4030016790 S.CER ECJ0EB1C103K T 31.1/28.3
C740 4030016790 S.CER ECJ0EB1C103K T 46.5/8.7
C741 4030016790 S.CER ECJ0EB1C103K T 11.5/14.8
C744 4030016790 S.CER ECJ0EB1C103K T 10.6/6.7
C745 4030017730 S.CER ECJ0EB1E471K T 21.8/10.7
C746 4030017370 S.CER ECJ0EC1H3R5B T 47/46.2
C747 4030017460 S.CER ECJ0EB1E102K T 48.2/48.6
C748 4030017460 S.CER ECJ0EB1E102K T 44/47.6
C749 4030017460 S.CER ECJ0EB1E102K T 26.4/48.6
C750 4030017460 S.CER ECJ0EB1E102K T 30.3/46.6
C752 4030017400 S.CER ECJ0EC1H220J T 22.1/39.5
C753 4030017400 S.CER ECJ0EC1H220J T 18.5/42.7
C754 4030017460 S.CER ECJ0EB1E102K T 26.7/46.3
C755 4030017730 S.CER ECJ0EB1E471K T 20.8/45.4
C756 4030016930 S.CER ECJ0EB1A104K T 21/46.7
C757 4030016930 S.CER ECJ0EB1A104K T 18.7/39.6
C758 4030016790 S.CER ECJ0EB1C103K T 15.1/34.8
C759 4030017460 S.CER ECJ0EB1E102K T 12.6/36.7
C760 4030017460 S.CER ECJ0EB1E102K T 13.6/36.7
C761 4030017460 S.CER ECJ0EB1E102K T 11.6/36.7
C762 4030017430 S.CER ECJ0EC1H101J T 8.9/32.1
C764 4030017460 S.CER ECJ0EB1E102K T 3.9/36
C765 4030017620 S.CER ECJ0EC1H100C T 6.6/33.1
C766 4030016790 S.CER ECJ0EB1C103K T 8.6/33.1
C767 4030011810 S.CER C1608 JB 1A 224K-T B 2.9/32.6
C768 4030017730 S.CER ECJ0EB1E471K T 5.7/42.9
C769 4030017730 S.CER ECJ0EB1E471K T 6.7/42.9
C770 4030016790 S.CER ECJ0EB1C103K T 3.9/40.6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF UNIT]
C771 4030016790 S.CER ECJ0EB1C103K T 4.9/37.8
C772 4030017460 S.CER ECJ0EB1E102K T 3.9/37.8
C773 4030016930 S.CER ECJ0EB1A104K T 7.7/42.2
C774 4030016790 S.CER ECJ0EB1C103K T 9.9/42.5
C775 4550007480 S.TAN F930J106MAABMA B 8.6/42.1
C776 4030011810 S.CER C1608 JB 1A 224K-T B 4.8/39.5
C777 4030016790 S.CER ECJ0EB1C103K T 15.4/45.1
C778 4030016790 S.CER ECJ0EB1C103K T 4.2/45.5
C779 4030016790 S.CER ECJ0EB1C103K B 8.9/44.1
C780 4030016930 S.CER ECJ0EB1A104K B 39.3/40
C781 4030017440 S.CER ECJ0EC1H221J T 11.9/48.5
C782 4030017440 S.CER ECJ0EC1H221J T 6.8/48.5
C783 4030016930 S.CER ECJ0EB1A104K T 15.5/48.4
C784 4030016790 S.CER ECJ0EB1C103K T 8.7/42.7
C785 4030017640 S.CER ECJ0EC1H150J B 10.4/33.4
C786 4030017700 S.CER ECJ0EC1H151J B 16.4/31.9
C788 4030016790 S.CER ECJ0EB1C103K B 22/27.8
C789 4030017460 S.CER ECJ0EB1E102K B 24/28.4
C790 4030016790 S.CER ECJ0EB1C103K B 25.3/31.1
C791 4550007480 S.TAN F930J106MAABMA B 17.2/27.5
C792 4030016790 S.CER ECJ0EB1C103K B 20.7/28.3
C793 4030016790 S.CER ECJ0EB1C103K B 22.5/32
C794 4030017460 S.CER ECJ0EB1E102K B 26.3/28.8
C795 4030016930 S.CER ECJ0EB1A104K B 31.9/27.5
C796 4030011810 S.CER C1608 JB 1A 224K-T B 28.8/31.7
C797 4030017460 S.CER ECJ0EB1E102K T 34/35.8
C807 4030017460 S.CER ECJ0EB1E102K T 64.2/24.6
C808 4030017460 S.CER ECJ0EB1E102K T 62.6/32.6
C809 4030017460 S.CER ECJ0EB1E102K T 59.2/23.2
C811 4030017460 S.CER ECJ0EB1E102K T 62.7/22.6
C812 4030017460 S.CER ECJ0EB1E102K T 59.7/25.2
C814 4030017350 S.CER ECJ0EC1H020B T 60.1/27.5
C815 4030017460 S.CER ECJ0EB1E102K T 63.2/26.5
C816 4030017460 S.CER ECJ0EB1E102K T 61.1/29.2
C817 4030017590 S.CER ECJ0EC1H070C T 60.2/31.1
C827 4030017460 S.CER ECJ0EB1E102K B 65.2/31.8
C828 4030017460 S.CER ECJ0EB1E102K B 65.2/33
C832 4030017460 S.CER ECJ0EB1E102K B 62.9/35.4
C833 4030017340 S.CER ECJ0EC1H010B B 63.5/36.7
C834 4030017460 S.CER ECJ0EB1E102K B 64/38.1
C835 4030017460 S.CER ECJ0EB1E102K B 63.1/41.6
C836 4030017460 S.CER ECJ0EB1E102K B 60.3/37.6
C837 4030017430 S.CER ECJ0EC1H101J B 67.8/22.7
C838 4030017430 S.CER ECJ0EC1H101J B 63.7/28.4
C839 4030017460 S.CER ECJ0EB1E102K B 74.9/21.2
C840 4030017460 S.CER ECJ0EB1E102K B 74.9/22.6
C841 4030017390 S.CER ECJ0EC1H180J B 73.2/25.1
C842 4030017460 S.CER ECJ0EB1E102K B 74.9/20.2
C843 4030017600 S.CER ECJ0EC1H080C B 70.6/26.4
C844 4030017460 S.CER ECJ0EB1E102K T 70.6/24.1
C845 4030017600 S.CER ECJ0EC1H080C T 70.6/22.1
C846 4030017460 S.CER ECJ0EB1E102K T 70.6/23.1
C847 4030017460 S.CER ECJ0EB1E102K T 70.6/25.1
C848 4030017360 S.CER ECJ0EC1H030B T 68.1/20
C849 4030017430 S.CER ECJ0EC1H101J T 71.3/13.6
C850 4030017430 S.CER ECJ0EC1H101J T 61.8/20.6
C851 4030017650 S.CER ECJ0EC1H270J T 75.6/21.1
C852 4030017650 S.CER ECJ0EC1H270J T 75.6/17.7
C853 4030017640 S.CER ECJ0EC1H150J T 75.6/13.1
C854 4030017610 S.CER ECJ0EC1H090C T 73.7/25.8
C855 4030017420 S.CER ECJ0EC1H470J T 72.2/28.7
C856 4030017590 S.CER ECJ0EC1H070C T 73.5/29.2
C857 4030017430 S.CER ECJ0EC1H101J T 72.2/29.7
C858 4030017630 S.CER ECJ0EC1H120J T 73.5/32.4
C859 4030017460 S.CER ECJ0EB1E102K T 76.5/9.6
C860 4030017460 S.CER ECJ0EB1E102K T 74.7/8.1
C861 4030017460 S.CER ECJ0EB1E102K T 75.1/9.4
C862 4030017460 S.CER ECJ0EB1E102K B 48.1/41.6
C863 4030017460 S.CER ECJ0EB1E102K B 47.9/39.8
C864 4030016930 S.CER ECJ0EB1A104K T 57.2/45.4
C865 4030017460 S.CER ECJ0EB1E102K T 53/48.9
C866 4030017460 S.CER ECJ0EB1E102K T 57.5/43.6
C867 4030016790 S.CER ECJ0EB1C103K T 46.1/34.5
C868 4030017460 S.CER ECJ0EB1E102K T 56.5/41.5
C869 4030016790 S.CER ECJ0EB1C103K T 13/42.4
C870 4030016790 S.CER ECJ0EB1C103K T 15.8/38.4
C871 4030016790 S.CER ECJ0EB1C103K T 11.6/40.6
C872 4030016930 S.CER ECJ0EB1A104K B 73.5/28.9
C873 4030017440 S.CER ECJ0EC1H221J T 38/15.7
C874 4030017390 S.CER ECJ0EC1H180J T 35.7/17.5
C875 4030017510 S.CER ECJ0EC1H680J T 33.7/12.3
C876 4030017500 S.CER ECJ0EC1H560J T 31.7/12.3
C877 4030016790 S.CER ECJ0EB1C103K T 34.5/8.3
C878 4030016790 S.CER ECJ0EB1C103K T 36.8/11.5
C879 4030017620 S.CER ECJ0EC1H100C T 31.7/10.3
C880 4030017460 S.CER ECJ0EB1E102K B 4/35.4
C881 4030017460 S.CER ECJ0EB1E102K B 45.2/36.2
C882 4030017460 S.CER ECJ0EB1E102K T 11.5/32.7
C884 4030017460 S.CER ECJ0EB1E102K B 24/5.6
C885 4030017460 S.CER ECJ0EB1E102K T 26.8/36.7
C886 4030017460 S.CER ECJ0EB1E102K T 62.9/49.3
C887 4030017460 S.CER ECJ0EB1E102K T 59.6/45.8
C888 4030017460 S.CER ECJ0EB1E102K T 69/31
C889 4030016930 S.CER ECJ0EB1A104K T 16.7/25
C890 4030016930 S.CER ECJ0EB1A104K T 31.4/24.7
C891 4030016790 S.CER ECJ0EB1C103K B 76.2/6.7
C893 4030016790 S.CER ECJ0EB1C103K T 3.9/20.7
C894 4030016790 S.CER ECJ0EB1C103K T 20.9/14.7
C895 4030017730 S.CER ECJ0EB1E471K T 68.5/41.5
C896 4030016790 S.CER ECJ0EB1C103K T 4.3/3.7
C897 4030017460 S.CER ECJ0EB1E102K B 68.6/26.4
C898 4030017460 S.CER ECJ0EB1E102K B 67.5/29.9
C899 4030017460 S.CER ECJ0EB1E102K B 60.6/31.9
C900 4030017460 S.CER ECJ0EB1E102K B 63.2/25.1
C901 4030017460 S.CER ECJ0EB1E102K T 66.1/25.5

Jan. 2010
5
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[RF UNIT]
C902 4030017420 S.CER ECJ0EC1H470J T 53.6/42.8
C903 4030017420 S.CER ECJ0EC1H470J T 53.6/41.3
C904 4030017420 S.CER ECJ0EC1H470J T 53.6/39.8
C905 4030017420 S.CER ECJ0EC1H470J T 53.5/38.3
C906 4030017420 S.CER ECJ0EC1H470J T 51.8/22.3
C907 4030017420 S.CER ECJ0EC1H470J T 53.6/14.4
C908 4030017420 S.CER ECJ0EC1H470J T 53.6/12.9
C909 4550007460 S.TAN F930G107MBABMA B 47.5/7.9
C910 4550007460 S.TAN F930G107MBABMA B 66.3/48.2
C911 4550007460 S.TAN F930G107MBABMA B 45.6/31.3
C912 4030016930 S.CER ECJ0EB1A104K B 45.9/1.9
C913 4030017460 S.CER ECJ0EB1E102K T 49.5/19.1
C914 4030017460 S.CER ECJ0EB1E102K T 50/17
C916 4030017460 S.CER ECJ0EB1E102K T 31.1/18.1
C917 4030017460 S.CER ECJ0EB1E102K T 28/8.9
C918 4030017460 S.CER ECJ0EB1E102K B 58.1/43.2
C919 4030017460 S.CER ECJ0EB1E102K B 57.1/45
C920 4030017460 S.CER ECJ0EB1E102K T 31.4/36.7
C921 4030017460 S.CER ECJ0EB1E102K B 61.2/46.9
C922 4030017700 S.CER ECJ0EC1H151J T 5.8/27
J1 6510022160 S.CON AXN440C040P T 40.3/27.5
W1 7030012290 JUM RDS2T0R0
W2 7030012290 JUM RDS2T0R0
EP2 3310003010 ANT KY-058-006-2 <KAI>
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[1STAVCO UNIT]
IC2 1110005180 S.IC UPC2746TB-E3 B 20.3/10.9
IC3 1130011660 S.IC MB15T61ULPVA-G-ER B 10.3/13.1
Q1 1530003260 S.TRA 2SC5006-T1 T 16.2/4.3
Q2 1530003260 S.TRA 2SC5006-T1 T 12.4/9.2
Q3 1530003260 S.TRA 2SC5006-T1 T 12.9/15
Q6 1560000531 S.FET 2SK880-GR(TE85R,F) B 11.6/5.4
Q7 1530003001 S.TRA 2SC4117-BL(TE85R,F) B 8.6/3.2
Q8 1530003582 S.TRA 2SC5231A-8-TL-E B 15.5/8.8
Q9 1530003582 S.TRA 2SC5231A-8-TL-E B 22.1/16.2
Q11 1590001810 S.TRA XP1113(TX) B 20.7/6.7
Q12 1590001810 S.TRA XP1113(TX) B 20.7/4.1
Q13 1530003592 S.TRA 2SC5277A-2-TL-E B 3.9/13.1
D1 1720000401 S.VAR 1SV245(TPH3,F) T 5.5/2.2
D2 1720000401 S.VAR 1SV245(TPH3,F) T 6.9/5.1
D3 1750001051 S.VAR HVC417CTRU-E T 4.6/8.1
D4 1750001051 S.VAR HVC417CTRU-E T 4.4/13.1
D7 1790001621 S.DIO 1SV308(TPL3,F) T 21.2/8.4
D8 1790001621 S.DIO 1SV308(TPL3,F) T 20.3/10.6
D9 1790001621 S.DIO 1SV308(TPL3,F) T 21.2/12.7
L1 6200009351 S.COI ELJRE R22GFA T 4.7/4.3
L2 6200009351 S.COI ELJRE R22GFA T 8.3/3.1
L3 6200010030 S.COI C2012C-15NG-A T 10.6/4
L4 6200003960 S.COI MLF1608A 1R0K-T T 12.4/4.4
L5 6200009351 S.COI ELJRE R22GFA T 4.1/10.7
L6 6200009980 S.COI C2012C-18NG-A T 7.4/9.3
L7 6200003960 S.COI MLF1608A 1R0K-T T 15.7/10.6
L8 6200009351 S.COI ELJRE R22GFA T 4.1/16.4
L9 6200009280 S.COI LQW18AN27NG00D
(LQW1608A27NG00) T 7.3/14.4
L10 6200003960 S.COI MLF1608A 1R0K-T T 16.2/16.2
R1 7030004970 S.RES ERJ2GEJ 470 X (47) T 13.6/4.2
R2 7030004990 S.RES ERJ2GEJ 221 X (220) T 17.4/1.8
R3 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 14.6/4.2
R4 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 15.2/2.2
R5 7030004990 S.RES ERJ2GEJ 221 X (220) T 20.1/4.9
R6 7030004970 S.RES ERJ2GEJ 470 X (47) T 17.6/9.8
R7 7030004990 S.RES ERJ2GEJ 221 X (220) T 15/8.1
R8 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 12.4/7.6
R9 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 9.7/8
R10 7030004990 S.RES ERJ2GEJ 221 X (220) T 17.5/8.4
R11 7030004970 S.RES ERJ2GEJ 470 X (47) T 18.3/16
R12 7030004990 S.RES ERJ2GEJ 221 X (220) T 15.5/13.6
R13 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 12.9/13.2
R14 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 10.3/13.5
R15 7030007280 S.RES ERJ2GEJ 331 X (330) T 18.2/14.6
R23 7030005120 S.RES ERJ2GEJ 102 X (1K) B 13.7/13.7
R24 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 11.2/8.3
R25 7030004990 S.RES ERJ2GEJ 221 X (220) B 13.3/4.5
R26 7030006020 S.RES RR0510P-682-D (6.8K) B 9.4/5.7
R27 7030006030 S.RES RR0510P-822-D (8.2K) B 10.5/3.2
R28 7030007340 S.RES ERJ2GEJ 153 X (15K) B 3.7/5
R29 7030005090 S.RES ERJ2GEJ 104 X (100K) B 12.8/8.3
R30 7030004990 S.RES ERJ2GEJ 221 X (220) B 15.2/7.2
R31 7030005080 S.RES ERJ2GEJ 823 X (82K) B 18.1/11.4
R32 7030007270 S.RES ERJ2GEJ 151 X (150) B 13.9/7.4
R33 7030007260 S.RES ERJ2GEJ 330 X (33) B 16.9/13.3
R34 7030004990 S.RES ERJ2GEJ 221 X (220) B 19/8.3
R35 7030009140 S.RES ERJ2GEJ 272 X (2.7K) B 3.7/6.9
R36 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 20.6/2.6
R37 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 18.6/10
R38 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 19.5/16.1
R40 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 21.7/8.8
R41 7030005300 S.RES ERJ2GEJ 150 X (15) B 17.9/13.3
R42 7030004970 S.RES ERJ2GEJ 470 X (47) B 17.4/14.6
R43 7030005080 S.RES ERJ2GEJ 823 X (82K) B 20.5/15.1
R44 7030004990 S.RES ERJ2GEJ 221 X (220) B 22.2/14.6
R45 7030005120 S.RES ERJ2GEJ 102 X (1K) B 20.7/13.8
R46 7030005120 S.RES ERJ2GEJ 102 X (1K) B 1/15.5
R47 7030005120 S.RES ERJ2GEJ 102 X (1K) B 5.1/15
R48 7030005120 S.RES ERJ2GEJ 102 X (1K) B 6.4/15.3
R49 7030008300 S.RES ERJ2GEJ 184 X (180K) B 3.6/16.2
R50 7030005090 S.RES ERJ2GEJ 104 X (100K) B 3.2/11.1
R51 7030005090 S.RES ERJ2GEJ 104 X (100K) B 3.7/9.4
R52 7030005090 S.RES ERJ2GEJ 104 X (100K) B 5.2/9.8
R53 7030005570 S.RES ERJ2GEJ 820 X (82) B 13.6/15
R54 7030004970 S.RES ERJ2GEJ 470 X (47) T 4.1/15.2
R55 7030005120 S.RES ERJ2GEJ 102 X (1K) [EUR] B 6/13.5
7030005120 S.RES ERJ2GEJ 102 X (1K) [UK]
7030005120 S.RES ERJ2GEJ 102 X (1K) [USA]
7030005120 S.RES ERJ2GEJ 102 X (1K) [FRA]
7030010040 S.RES ERJ2GEJ-JPW [SEA]
7030010040 S.RES ERJ2GEJ-JPW [EXP-01]
7030010040 S.RES ERJ2GEJ-JPW [EXP-02]
7030005120 S.RES ERJ2GEJ 102 X (1K) [CAN]
7030010040 S.RES ERJ2GEJ-JPW [CHN]
R56 7030005120 S.RES ERJ2GEJ 102 X (1K) [EUR] B 6.3/12.6
7030005120 S.RES ERJ2GEJ 102 X (1K) [UK]
7030005120 S.RES ERJ2GEJ 102 X (1K) [USA]
7030005120 S.RES ERJ2GEJ 102 X (1K) [FRA]
7030010040 S.RES ERJ2GEJ-JPW [SEA]
7030010040 S.RES ERJ2GEJ-JPW [EXP-01]
7030010040 S.RES ERJ2GEJ-JPW [EXP-02]
7030005120 S.RES ERJ2GEJ 102 X (1K) [CAN]
7030010040 S.RES ERJ2GEJ-JPW [CHN]

Jan. 2010
6
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[1STAVCO UNIT]
R57 7030005120 S.RES ERJ2GEJ 102 X (1K) [EUR] B 6.7/11.7
7030005120 S.RES ERJ2GEJ 102 X (1K) [UK]
7030005120 S.RES ERJ2GEJ 102 X (1K) [USA]
7030005120 S.RES ERJ2GEJ 102 X (1K) [FRA]
7030010040 S.RES ERJ2GEJ-JPW [SEA]
7030010040 S.RES ERJ2GEJ-JPW [EXP-01]
7030010040 S.RES ERJ2GEJ-JPW [EXP-02]
7030005120 S.RES ERJ2GEJ 102 X (1K) [CAN]
7030010040 S.RES ERJ2GEJ-JPW [CHN]
C1 4030017460 S.CER ECJ0EB1E102K T 3.4/2.9
C2 4030017460 S.CER ECJ0EB1E102K T 9/4.6
C3 4030017360 S.CER ECJ0EC1H030B T 17.8/3.6
C4 4030017570 S.CER ECJ0EC1H040B T 19.3/1.7
C5 4030017460 S.CER ECJ0EB1E102K T 16.4/2.2
C6 4030016930 S.CER ECJ0EB1A104K T 13/2.3
C7 4030017530 S.CER ECJ0EC1H0R5B T 19.1/3
C8 4030016930 S.CER ECJ0EB1A104K T 18.8/4.3
C9 4030017460 S.CER ECJ0EB1E102K T 4.1/9.5
C10 4030017460 S.CER ECJ0EB1E102K T 5.8/10.2
C11 4030017350 S.CER ECJ0EC1H020B T 14/8.1
C12 4030017460 S.CER ECJ0EB1E102K T 10.8/8.1
C13 4030016930 S.CER ECJ0EB1A104K T 10/9.7
C14 4030017530 S.CER ECJ0EC1H0R5B T 15.3/9.4
C15 4030016930 S.CER ECJ0EB1A104K T 16/8.1
C16 4030017360 S.CER ECJ0EC1H030B T 14/10.1
C17 4030017460 S.CER ECJ0EB1E102K T 3.9/14.2
C18 4030017460 S.CER ECJ0EB1E102K T 6.1/15.8
C19 4030017600 S.CER ECJ0EC1H080C T 14.5/15.5
C20 4030017570 S.CER ECJ0EC1H040B T 14.5/13.6
C21 4030017460 S.CER ECJ0EB1E102K T 11.3/13.5
C22 4030016930 S.CER ECJ0EB1A104K T 10.3/14.9
C23 4030017530 S.CER ECJ0EC1H0R5B T 16.1/15
C24 4030016930 S.CER ECJ0EB1A104K T 16.6/13.6
C31 4030016790 S.CER ECJ0EB1C103K B 2/15.5
C35 4030017770 S.CER ECJ0EB1E332K B 10.2/8.4
C37 4550003220 S.TAN TEESVA 1E 105M8R B 13.5/2.9
C38 4550000930 S.TAN TEESVA 1D 684M8R B 5.6/6.8
C39 4550000930 S.TAN TEESVA 1D 684M8R B 7.7/6.8
C40 4030016790 S.CER ECJ0EB1C103K T 3.3/4.8
C41 4030017460 S.CER ECJ0EB1E102K B 12.4/9.7
C42 4030017460 S.CER ECJ0EB1E102K B 14/9.2
C43 4030017350 S.CER ECJ0EC1H020B B 17/11.4
C44 4030017460 S.CER ECJ0EB1E102K B 17.3/10.1
C46 4030017460 S.CER ECJ0EB1E102K B 18.7/9.3
C47 4030017460 S.CER ECJ0EB1E102K B 19.4/12.7
C48 4340000290 S.MYL ECHU 1C 103JX5 B 4.8/3
C49 4030017620 S.CER ECJ0EC1H100C B 20.7/8.8
C50 4030017380 S.CER ECJ0EC1H050B B 17.4/15.6
C52 4030017460 S.CER ECJ0EB1E102K B 23.6/14.8
C53 4030017460 S.CER ECJ0EB1E102K B 21.2/12.7
C54 4030017460 S.CER ECJ0EB1E102K T 20.4/3.9
C55 4030017460 S.CER ECJ0EB1E102K T 19.4/8.3
C56 4030017460 S.CER ECJ0EB1E102K T 18.1/13.4
C58 4030016930 S.CER ECJ0EB1A104K B 16.5/2.3
C59 4030016790 S.CER ECJ0EB1C103K B 4/14.9
C60 4030016790 S.CER ECJ0EB1C103K B 6.4/14.4
C61 4030016930 S.CER ECJ0EB1A104K B 14/12.5
C62 4030016930 S.CER ECJ0EB1A104K B 7.6/10.3
C63 4030017460 S.CER ECJ0EB1E102K B 9.8/10
C64 4550007600 S.TAN F920J106MPABMA B 15.4/14.7
C65 4550007600 S.TAN F920J106MPABMA B 17.9/3.2
C66 4550007600 S.TAN F920J106MPABMA B 16.6/5.5
C67 4030017460 S.CER ECJ0EB1E102K [EUR] B 14/10.9
4030017460 S.CER ECJ0EB1E102K [UK]
4030017460 S.CER ECJ0EB1E102K [USA]
4030017460 S.CER ECJ0EB1E102K [FRA]
4030017460 S.CER ECJ0EB1E102K [CAN]
J1 6910015521 CON IMSA-9230B-1-07Z064-PT1
J2 6910015511 CON IMSA-9230B-1-08Z064-PT1
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[1STBVCO UNIT]
IC2 1110005180 S.IC UPC2746TB-E3 B 20.6/12.4
IC3 1130011660 S.IC MB15T61ULPVA-G-ER B 10/13.3
Q1 1530003260 S.TRA 2SC5006-T1 T 16.4/4.3
Q2 1530003260 S.TRA 2SC5006-T1 T 13.2/8.5
Q3 1530003260 S.TRA 2SC5006-T1 T 13.9/12.4
Q4 1530003260 S.TRA 2SC5006-T1 T 9.5/15.3
Q5 1530003260 S.TRA 2SC5006-T1 T 13.4/16.8
Q6 1560000531 S.FET 2SK880-GR(TE85R,F) B 11.8/4.9
Q7 1530003001 S.TRA 2SC4117-BL(TE85R,F) B 8.1/2.5
Q8 1530003582 S.TRA 2SC5231A-8-TL-E B 16.2/10
Q9 1530003582 S.TRA 2SC5231A-8-TL-E B 21.5/16.6
Q10 1590001810 S.TRA XP1113(TX) B 20.9/4
Q11 1590001810 S.TRA XP1113(TX) B 20.6/6.6
Q12 1530003592 S.TRA 2SC5277A-2-TL-E B 3.6/15.7
D1 1720000401 S.VAR 1SV245(TPH3,F) T 5.2/2.7
D2 1720000401 S.VAR 1SV245(TPH3,F) T 7/4.5
D3 1750001051 S.VAR HVC417CTRU-E T 4.9/6.8
D4 1750001051 S.VAR HVC417CTRU-E T 4.6/11.7
D5 1750001051 S.VAR HVC417CTRU-E T 4.1/17
D7 1790001621 S.DIO 1SV308(TPL3,F) T 21.5/6.6
D8 1790001621 S.DIO 1SV308(TPL3,F) T 20.9/9.1
D9 1790001621 S.DIO 1SV308(TPL3,F) T 21.5/11.3
D10 1790001621 S.DIO 1SV308(TPL3,F) T 21.4/14.2
L1 6200009351 S.COI ELJRE R22GFA T 3.9/4.6
L2 6200009351 S.COI ELJRE R22GFA T 8.2/2.5
L3 6200010020 S.COI C2012C-12NG-A T 10.7/3.9
L4 6200003960 S.COI MLF1608A 1R0K-T T 12.5/4
L5 6200009351 S.COI ELJRE R22GFA T 4.5/9.1
L6 6200010020 S.COI C2012C-12NG-A T 7.9/7.9
L7 6200003960 S.COI MLF1608A 1R0K-T T 16.5/9.3
L8 6200009351 S.COI ELJRE R22GFA T 4.3/13.5
L9 6200009280 S.COI LQW18AN27NG00D
(LQW1608A27NG00) T 7.7/12.9
L10 6200003960 S.COI MLF1608A 1R0K-T T 17.4/13.3
L11 6200004940 S.COI MLF1608D R27K-T T 1.9/16
L12 6200010210 S.COI C2012C-22NG-A T 6.3/15.9
L13 6200005741 S.COI ELJRE 47NGFA T 14/15.1
L14 6200005741 S.COI ELJRE 47NGFA T 17.6/15
R1 7030004970 S.RES ERJ2GEJ 470 X (47) T 13.7/4.4
R2 7030004990 S.RES ERJ2GEJ 221 X (220) T 17.7/2.4
R3 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 14.8/4.4
R4 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 15.7/2.2
R5 7030009160 S.RES ERJ2GEJ 181 X (180) [EUR] T 20.1/5.7
7030009160 S.RES ERJ2GEJ 181 X (180) [UK]
7030009160 S.RES ERJ2GEJ 181 X (180) [USA]
7030009160 S.RES ERJ2GEJ 181 X (180) [FRA]
7030007250 S.RES ERJ2GEJ 220 X (22) [SEA]
7030007250 S.RES ERJ2GEJ 220 X (22) [EXP-01]
7030007250 S.RES ERJ2GEJ 220 X (22) [EXP-02]
7030009160 S.RES ERJ2GEJ 181 X (180) [CAN]
7030007250 S.RES ERJ2GEJ 220 X (22) [CHN]
R6 7030004970 S.RES ERJ2GEJ 470 X (47) T 18.2/8.7
R7 7030004990 S.RES ERJ2GEJ 221 X (220) T 14.4/6.5
R8 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 13.1/6.6
R9 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 10.1/6.7
R10 7030004990 S.RES ERJ2GEJ 221 X (220) [EUR] T 17.7/7.4
7030004990 S.RES ERJ2GEJ 221 X (220) [UK]
7030004990 S.RES ERJ2GEJ 221 X (220) [USA]
7030004990 S.RES ERJ2GEJ 221 X (220) [FRA]
7030007250 S.RES ERJ2GEJ 220 X (22) [SEA]
7030007250 S.RES ERJ2GEJ 220 X (22) [EXP-01]
7030007250 S.RES ERJ2GEJ 220 X (22) [EXP-02]
7030004990 S.RES ERJ2GEJ 221 X (220) [CAN]
7030007250 S.RES ERJ2GEJ 220 X (22) [CHN]
R11 7030004970 S.RES ERJ2GEJ 470 X (47) T 18.7/11.6
R12 7030004990 S.RES ERJ2GEJ 221 X (220) T 16.4/10.8
R13 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 13.9/10.8
R14 7030005210 S.RES ERJ2GEJ 822 X (8.2K) T 12.5/11.1
R15 7030005000 S.RES ERJ2GEJ 471 X (470) T 20.1/11.2
R16 7030005290 S.RES ERJ2GEJ 682 X (6.8K) T 9.2/16.9
R17 7030005710 S.RES ERJ2GEJ 121 X (120) T 11.6/15.1
R18 7030005290 S.RES ERJ2GEJ 682 X (6.8K) T 11.8/16.6
R19 7030007280 S.RES ERJ2GEJ 331 X (330) T 15.7/16.8
R23 7030005120 S.RES ERJ2GEJ 102 X (1K) B 13.8/12.5
R24 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 11.2/7.4
R25 7030004990 S.RES ERJ2GEJ 221 X (220) B 13.8/4.2
R26 7030006020 S.RES RR0510P-682-D (6.8K) B 10/4.9
R27 7030006030 S.RES RR0510P-822-D (8.2K) B 10/2.8
R28 7030007340 S.RES ERJ2GEJ 153 X (15K) B 3.7/4.7
R29 7030005090 S.RES ERJ2GEJ 104 X (100K) B 16.8/7.4
R30 7030004990 S.RES ERJ2GEJ 221 X (220) B 16.9/8.4
R31 7030005080 S.RES ERJ2GEJ 823 X (82K) B 17.3/12.2
R32 7030007270 S.RES ERJ2GEJ 151 X (150) B 18.3/8.8
R33 7030007260 S.RES ERJ2GEJ 330 X (33) B 16.2/14.1
R34 7030004990 S.RES ERJ2GEJ 221 X (220) B 19.6/8.8
R35 7030009140 S.RES ERJ2GEJ 272 X (2.7K) B 3.5/7
R36 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 20.6/2.6
R37 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 19.2/8.9
R38 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 20/12.2
R39 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 19.1/16.8
R40 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 21.3/9.5
R41 7030005300 S.RES ERJ2GEJ 150 X (15) B 17.3/14
R42 7030004970 S.RES ERJ2GEJ 470 X (47) B 16.3/15.6
R43 7030005080 S.RES ERJ2GEJ 823 X (82K) B 18.9/15.5
R44 7030004990 S.RES ERJ2GEJ 221 X (220) B 22.8/15.3
R45 7030005120 S.RES ERJ2GEJ 102 X (1K) B 21.4/14.7
R46 7030005120 S.RES ERJ2GEJ 102 X (1K) B 1.5/15.6

Jan. 2010
7
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[1STBVCO UNIT]
R47 7030005120 S.RES ERJ2GEJ 102 X (1K) B 6.4/16.7
R48 7030005120 S.RES ERJ2GEJ 102 X (1K) B 5.8/15.1
R49 7030008300 S.RES ERJ2GEJ 184 X (180K) B 5.1/16.7
R50 7030005090 S.RES ERJ2GEJ 104 X (100K) B 3.3/13.3
R51 7030005090 S.RES ERJ2GEJ 104 X (100K) B 4.3/13.4
R52 7030005090 S.RES ERJ2GEJ 104 X (100K) B 4.3/11
R53 7030005570 S.RES ERJ2GEJ 820 X (82) B 12.2/16.3
R54 7030004970 S.RES ERJ2GEJ 470 X (47) T 3.3/12.1
R55 7030005120 S.RES ERJ2GEJ 102 X (1K) [EUR] B 5.9/13.8
7030005120 S.RES ERJ2GEJ 102 X (1K) [UK]
7030005120 S.RES ERJ2GEJ 102 X (1K) [USA]
7030005120 S.RES ERJ2GEJ 102 X (1K) [FRA]
7030010040 S.RES ERJ2GEJ-JPW [SEA]
7030010040 S.RES ERJ2GEJ-JPW [EXP-01]
7030010040 S.RES ERJ2GEJ-JPW [EXP-02]
7030005120 S.RES ERJ2GEJ 102 X (1K) [CAN]
7030010040 S.RES ERJ2GEJ-JPW [CHN]
R56 7030005120 S.RES ERJ2GEJ 102 X (1K) [EUR] B 5.9/12.8
7030005120 S.RES ERJ2GEJ 102 X (1K) [UK]
7030005120 S.RES ERJ2GEJ 102 X (1K) [USA]
7030005120 S.RES ERJ2GEJ 102 X (1K) [FRA]
7030010040 S.RES ERJ2GEJ-JPW [SEA]
7030010040 S.RES ERJ2GEJ-JPW [EXP-01]
7030010040 S.RES ERJ2GEJ-JPW [EXP-02]
7030005120 S.RES ERJ2GEJ 102 X (1K) [CAN]
7030010040 S.RES ERJ2GEJ-JPW [CHN]
R57 7030005120 S.RES ERJ2GEJ 102 X (1K) [EUR] B 5.9/11.8
7030005120 S.RES ERJ2GEJ 102 X (1K) [UK]
7030005120 S.RES ERJ2GEJ 102 X (1K) [USA]
7030005120 S.RES ERJ2GEJ 102 X (1K) [FRA]
7030010040 S.RES ERJ2GEJ-JPW [SEA]
7030010040 S.RES ERJ2GEJ-JPW [EXP-01]
7030010040 S.RES ERJ2GEJ-JPW [EXP-02]
7030005120 S.RES ERJ2GEJ 102 X (1K) [CAN]
7030010040 S.RES ERJ2GEJ-JPW [CHN]
C1 4030017460 S.CER ECJ0EB1E102K T 3.1/2.2
C2 4030017460 S.CER ECJ0EB1E102K T 9.1/4.1
C3 4030017350 S.CER ECJ0EC1H020B T 18/4.2
C4 4030017350 S.CER ECJ0EC1H020B T 19/2.2
C5 4030017460 S.CER ECJ0EB1E102K T 16.7/2.2
C6 4030016930 S.CER ECJ0EB1A104K T 14.1/2.5
C7 4030017530 S.CER ECJ0EC1H0R5B T 19.3/3.2
C8 4030016930 S.CER ECJ0EB1A104K T 19/4.5
C9 4030017460 S.CER ECJ0EB1E102K T 4.2/8
C10 4030017460 S.CER ECJ0EB1E102K T 6.3/8.6
C11 4030017350 S.CER ECJ0EC1H020B T 15.4/6.5
C12 4030017460 S.CER ECJ0EB1E102K T 11.1/6.7
C13 4030016930 S.CER ECJ0EB1A104K T 10.4/8.4
C14 4030017530 S.CER ECJ0EC1H0R5B T 16.1/8.1
C15 4030016930 S.CER ECJ0EB1A104K T 16.4/6.8
C16 4030017570 S.CER ECJ0EC1H040B T 14.8/8.4
C17 4030017460 S.CER ECJ0EB1E102K T 3.3/10.2
C18 4030017460 S.CER ECJ0EB1E102K T 5.7/12.1
C19 4030017600 S.CER ECJ0EC1H080C T 15.5/12.7
C20 4030017570 S.CER ECJ0EC1H040B T 15.3/10.9
C21 4030017460 S.CER ECJ0EB1E102K T 11.5/11.7
C22 4030016930 S.CER ECJ0EB1A104K T 10/11.8
C23 4030017530 S.CER ECJ0EC1H0R5B T 17/12.1
C24 4030016930 S.CER ECJ0EB1A104K T 17.4/10.8
C25 4030017460 S.CER ECJ0EB1E102K T 3.1/15.6
C26 4030017460 S.CER ECJ0EB1E102K T 4.4/15.5
C27 4030017540 S.CER ECJ0EC1HR75B T 9.2/17.9
C28 4030017540 S.CER ECJ0EC1HR75B T 7.9/17
C29 4030017460 S.CER ECJ0EB1E102K T 10.8/16.6
C30 4030017460 S.CER ECJ0EB1E102K T 15.8/14.8
C31 4030017460 S.CER ECJ0EB1E102K B 1.7/16.9
C35 4030017770 S.CER ECJ0EB1E332K B 10.2/7.4
C37 4550003220 S.TAN TEESVA 1E 105M8R B 12.9/2.4
C38 4550000930 S.TAN TEESVA 1D 684M8R B 5.6/6
C39 4550000930 S.TAN TEESVA 1D 684M8R B 8.1/6.8
C40 4030016790 S.CER ECJ0EB1C103K B 3.6/5.9
C41 4030017460 S.CER ECJ0EB1E102K B 13.2/8.6
C42 4030017460 S.CER ECJ0EB1E102K B 15.5/8
C43 4030017350 S.CER ECJ0EC1H020B B 16.2/12.3
C44 4030017460 S.CER ECJ0EB1E102K B 18.3/11.6
C45 4030017530 S.CER ECJ0EC1H0R5B T 17.2/17.3
C46 4030017460 S.CER ECJ0EB1E102K B 19.9/10.1
C47 4030017460 S.CER ECJ0EB1E102K B 18.4/13.5
C48 4340000290 S.MYL ECHU 1C 103JX5 B 4.9/2.5
C49 4030017620 S.CER ECJ0EC1H100C B 21.4/10.6
C50 4030017380 S.CER ECJ0EC1H050B B 16.3/16.8
C52 4030017460 S.CER ECJ0EB1E102K B 23.8/15.4
C53 4030017460 S.CER ECJ0EB1E102K B 19.9/15.5
C54 4030017460 S.CER ECJ0EB1E102K T 20.3/4.7
C55 4030017460 S.CER ECJ0EB1E102K T 19.4/7.1
C56 4030017460 S.CER ECJ0EB1E102K T 19.5/10.2
C57 4030017460 S.CER ECJ0EB1E102K T 17.4/16.2
C58 4030016930 S.CER ECJ0EB1A104K B 20.6/1.6
C59 4030016790 S.CER ECJ0EB1C103K B 3.6/17.2
C60 4030016790 S.CER ECJ0EB1C103K B 6.9/15.3
C61 4030016930 S.CER ECJ0EB1A104K B 13/10.6
C62 4030016930 S.CER ECJ0EB1A104K B 5/9.5
C63 4030017460 S.CER ECJ0EB1E102K B 7.7/10.1
C64 4550007600 S.TAN F920J106MPABMA B 13.9/15
C65 4550007600 S.TAN F920J106MPABMA B 18.7/2.4
C66 4550007600 S.TAN F920J106MPABMA B 16.9/2.4
C67 4550007600 S.TAN F920J106MPABMA B 16.3/4.7
C68 4030017460 S.CER ECJ0EB1E102K [EUR] B 11.8/9.7
4030017460 S.CER ECJ0EB1E102K [UK]
4030017460 S.CER ECJ0EB1E102K [USA]
4030017460 S.CER ECJ0EB1E102K [FRA]
4030017460 S.CER ECJ0EB1E102K [CAN]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[1STBVCO UNIT]
J1 6910015521 CON IMSA-9230B-1-07Z064-PT1
J2 6910015511 CON IMSA-9230B-1-08Z064-PT1

Jan. 2010
8
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[2NDCVCO UNIT]
IC1 1130011671 S.IC MB15E03SLPFV1-G-ER-6E1 B 5.6/11.4
Q1 1530003612 S.TRA FH102A-TR-E T 6.1/11.8
Q3 1530003592 S.TRA 2SC5277A-2-TL-E T 3.5/8.9
Q4 1530003630 S.TRA 2SC4617 TLS T 2.3/13.6
D1 1750000741 S.VAR 1SV314(TPH3,F) T 9.3/9.2
L1 6200009070 S.COI LQW18AN18NG00D
(LQW1608A18NG00) T 7.2/8.1
L2 6200005721 S.COI ELJRE 33NGFA T 4/13.4
L3 6200005701 S.COI ELJRE 22NGFA T 7.4/14.6
L4 6200009351 S.COI ELJRE R22GFA T 5.4/6.3
R1 7030004970 S.RES ERJ2GEJ 470 X (47) T 6.6/5.5
R2 7030005050 S.RES ERJ2GEJ 103 X (10K) T 5.5/10
R3 7030005120 S.RES ERJ2GEJ 102 X (1K) T 9.5/10.3
R4 7030005120 S.RES ERJ2GEJ 102 X (1K) T 8.8/13.2
R9 7030005580 S.RES ERJ2GEJ 560 X (56) B 5.9/14.7
R10 7030004980 S.RES ERJ2GEJ 101 X (100) B 7.3/15.5
R11 7030005120 S.RES ERJ2GEJ 102 X (1K) B 8.9/6.4
R12 7030005120 S.RES ERJ2GEJ 102 X (1K) B 6.9/6.4
R13 7030005120 S.RES ERJ2GEJ 102 X (1K) B 7.9/6.4
R14 7030005530 S.RES ERJ2GEJ 100 X (10) B 5.1/7.8
R15 7030009270 S.RES ERJ2GEJ 821 X (820) B 5.6/6.5
R16 7030005120 S.RES ERJ2GEJ 102 X (1K) T 2.4/5.3
R17 7030008300 S.RES ERJ2GEJ 184 X (180K) T 2.4/6.3
R18 7030005120 S.RES ERJ2GEJ 102 X (1K) T 1.2/7.8
R19 7030005120 S.RES ERJ2GEJ 102 X (1K) T 0.69/9.6
R21 7030005120 S.RES ERJ2GEJ 102 X (1K) T 1.1/12.3
R22 7030007280 S.RES ERJ2GEJ 331 X (330) B 5.7/5.3
C1 4550006910 S.TAN TEESVP 1C 334M8R T 8.7/5.7
C2 4030017390 S.CER ECJ0EC1H180J T 9.1/8
C3 4030017640 S.CER ECJ0EC1H150J T 5.4/8.7
C4 4030017620 S.CER ECJ0EC1H100C T 7.7/10.2
C5 4030017630 S.CER ECJ0EC1H120J T 8.6/11.2
C6 4030017460 S.CER ECJ0EB1E102K T 8.6/12.2
C7 4030017570 S.CER ECJ0EC1H040B T 5.2/13.9
C8 4030017340 S.CER ECJ0EC1H010B T 6.2/15
C9 4030017380 S.CER ECJ0EC1H050B T 8.9/14.2
C10 4030017380 S.CER ECJ0EC1H050B T 8.9/15.2
C16 4030017730 S.CER ECJ0EB1E471K B 3.4/5.3
C17 4030017380 S.CER ECJ0EC1H050B B 4.1/14.7
C18 4030017420 S.CER ECJ0EC1H470J B 8.4/8.1
C19 4030017420 S.CER ECJ0EC1H470J B 8.7/14.9
C20 4030017420 S.CER ECJ0EC1H470J B 9.9/13.5
C21 4550007630 S.TAN F920J475MPABMA B 3/7.2
C22 4030016790 S.CER ECJ0EB1C103K T 3.7/5.8
C23 4030016790 S.CER ECJ0EB1C103K T 3/7.3
C24 4030016790 S.CER ECJ0EB1C103K T 1.9/9.5
C25 4030017460 S.CER ECJ0EB1E102K B 1.3/13.8
C26 4030016930 S.CER ECJ0EB1A104K B 1.3/10
C27 4030017460 S.CER ECJ0EB1E102K B 9.9/10.3
C30 4030017460 S.CER ECJ0EB1E102K T 4.7/15.2
C31 4030017460 S.CER ECJ0EB1E102K T 2.5/15.2
C32 4550007600 S.TAN F920J106MPABMA T 3.1/11.3
C33 4030017350 S.CER ECJ0EC1H020B T 9.1/7.1
J1 6910010841 CON IMSA-9230B-1-05Z057-PT1
J2 6910014431 CON IMSA-9230B-1-06Z057-PT1
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[2NDDVCO UNIT]
IC1 1130011671 S.IC MB15E03SLPFV1-G-ER-6E1 B 5.6/11.4
Q1 1530003612 S.TRA FH102A-TR-E T 6.1/11.8
Q3 1530003592 S.TRA 2SC5277A-2-TL-E T 3.5/8.9
Q4 1530003630 S.TRA 2SC4617 TLS T 2.2/13.6
D1 1750000711 S.VAR HVC350BTRF-E T 9.4/9
L1 6200010850 S.COI LQW18AN22NG00D
(LQW1608A22NG00) T 7.2/8.1
L2 6200005741 S.COI ELJRE 47NGFA T 4/13.4
L3 6200005701 S.COI ELJRE 22NGFA T 7.4/14.6
L4 6200009351 S.COI ELJRE R22GFA T 5.4/6.3
R1 7030004970 S.RES ERJ2GEJ 470 X (47) T 6.6/5.5
R2 7030005240 S.RES ERJ2GEJ 473 X (47K) T 5.5/10
R3 7030007280 S.RES ERJ2GEJ 331 X (330) T 9.5/10.2
R4 7030005120 S.RES ERJ2GEJ 102 X (1K) T 8.8/13.2
R9 7030004990 S.RES ERJ2GEJ 221 X (220) B 5.9/14.7
R10 7030004980 S.RES ERJ2GEJ 101 X (100) B 7.3/15.5
R11 7030005120 S.RES ERJ2GEJ 102 X (1K) B 8.9/6.4
R12 7030005120 S.RES ERJ2GEJ 102 X (1K) B 6.9/6.5
R13 7030005120 S.RES ERJ2GEJ 102 X (1K) B 7.9/6.4
R14 7030005530 S.RES ERJ2GEJ 100 X (10) B 5.1/7.8
R15 7030009270 S.RES ERJ2GEJ 821 X (820) B 5.6/6.5
R16 7030005120 S.RES ERJ2GEJ 102 X (1K) T 2.4/5.3
R17 7030008300 S.RES ERJ2GEJ 184 X (180K) T 2.4/6.3
R18 7030005120 S.RES ERJ2GEJ 102 X (1K) T 1.2/7.8
R19 7030005120 S.RES ERJ2GEJ 102 X (1K) T 0.69/9.6
R21 7030005120 S.RES ERJ2GEJ 102 X (1K) T 1.1/11.9
R22 7030007280 S.RES ERJ2GEJ 331 X (330) B 5.6/5.3
C1 4550006910 S.TAN TEESVP 1C 334M8R T 8.7/5.7
C2 4030017500 S.CER ECJ0EC1H560J T 9.1/7.6
C3 4030017400 S.CER ECJ0EC1H220J T 5.4/8.7
C4 4030017630 S.CER ECJ0EC1H120J T 7.7/10.2
C5 4030017650 S.CER ECJ0EC1H270J T 8.6/11.2
C6 4030017460 S.CER ECJ0EB1E102K T 8.6/12.2
C7 4030017620 S.CER ECJ0EC1H100C T 5.2/13.9
C8 4030017570 S.CER ECJ0EC1H040B T 6.2/15
C9 4030017600 S.CER ECJ0EC1H080C T 8.9/14.2
C10 4030017600 S.CER ECJ0EC1H080C T 8.9/15.2
C16 4030017730 S.CER ECJ0EB1E471K B 3.4/5.3
C17 4030017380 S.CER ECJ0EC1H050B B 4.1/14.7
C18 4030017420 S.CER ECJ0EC1H470J B 8.4/8.1
C19 4030017420 S.CER ECJ0EC1H470J B 8.7/14.9
C20 4030017420 S.CER ECJ0EC1H470J B 9.9/13.5
C21 4550007630 S.TAN F920J475MPABMA B 3/7.2
C22 4030016790 S.CER ECJ0EB1C103K T 3.7/5.8
C23 4030016790 S.CER ECJ0EB1C103K T 3/7.3
C24 4030016790 S.CER ECJ0EB1C103K T 1.9/9.5
C25 4030017460 S.CER ECJ0EB1E102K B 1.3/13.8
C26 4030016930 S.CER ECJ0EB1A104K B 1.3/10
C27 4030017460 S.CER ECJ0EB1E102K B 9.9/10.3
C30 4030017460 S.CER ECJ0EB1E102K T 4.7/15.2
C31 4030017460 S.CER ECJ0EB1E102K T 2.6/15.2
C32 4550007600 S.TAN F920J106MPABMA T 3.1/11.2
J1 6910010841 CON IMSA-9230B-1-05Z057-PT1
J2 6910014431 CON IMSA-9230B-1-06Z057-PT1

Jan. 2010
9
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[DOWNCONV UNIT]
IC2 1110005120 S.IC UPC2749TB-E3 T 8.4/5.2
IC3 1110005230 S.IC UPC2757TB-E3 T 11/5.5
IC4 1130011671 S.IC MB15E03SLPFV1-G-ER-6E1 B 7.9/9.7
Q1 1530003260 S.TRA 2SC5006-T1 T 7.5/16.9
Q2 1530003260 S.TRA 2SC5006-T1 B 4.8/15.3
Q3 1590003381 S.TRA UNR9111G0L B 5.8/18.5
Q4 1530003781 S.TRA 2SC5624VH-TL-E T 1.5/9.2
Q5 1590001810 S.TRA XP1113(TX) B 8.2/18.2
Q6 1530003592 S.TRA 2SC5277A-2-TL-E B 3.8/6.4
D1 1790001621 S.DIO 1SV308(TPL3,F) T 1.4/3.9
D2 1790001621 S.DIO 1SV308(TPL3,F) B 10.8/3.4
D3 1720000401 S.VAR 1SV245(TPH3,F) T 11.3/16.5
D5 1790001621 S.DIO 1SV308(TPL3,F) T 3.9/9
D6 1790001621 S.DIO 1SV308(TPL3,F) T 3.2/10.9
D7 1790001621 S.DIO 1SV308(TPL3,F) T 10.8/9.4
D8 1790001621 S.DIO 1SV308(TPL3,F) T 10.8/10.7
L1 6200005651 S.COI ELJRE 8N2ZFA T 6.2/4.9
L2 6200005651 S.COI ELJRE 8N2ZFA T 3.4/6.2
L3 6200004480 S.COI MLF1608D R82K-T T 6.9/18.7
L4 6200010020 S.COI C2012C-12NG-A T 9.9/18.5
L6 6200009351 S.COI ELJRE R22GFA T 11.7/14.9
L7 6200006771 S.COI ELJRE 1N5ZFA T 4.6/10.9
L8 6200005641 S.COI ELJRE 6N8ZFA T 3.2/13.4
L9 6200005611 S.COI ELJRE 3N9ZFA T 4.6/7.6
L10 6200005581 S.COI ELJRE 2N2ZFA T 8.4/7.8
L11 6200005641 S.COI ELJRE 6N8ZFA B 10.8/4.7
R1 7030009160 S.RES ERJ2GEJ 181 X (180) [EUR] T 6.5/3
7030009160 S.RES ERJ2GEJ 181 X (180) [UK]
7030004980 S.RES ERJ2GEJ 101 X (100) [USA]
7030009160 S.RES ERJ2GEJ 181 X (180) [FRA]
7030004980 S.RES ERJ2GEJ 101 X (100) [SEA]
7030004980 S.RES ERJ2GEJ 101 X (100) [EXP-01]
7030004980 S.RES ERJ2GEJ 101 X (100) [EXP-02]
7030004980 S.RES ERJ2GEJ 101 X (100) [CAN]
7030004980 S.RES ERJ2GEJ 101 X (100) [CHN]
R2 7030005000 S.RES ERJ2GEJ 471 X (470) T 11.4/3.5
R3 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 13/3.2
R4 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 2.8/3
R5 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 2.8/4
R6 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 9.9/6
R7 7030005790 S.RES RR0510P-331-D (330) T 8.1/14.8
R8 7030005820 S.RES RR0510P-103-D (10K) T 5.8/15
R9 7030006010 S.RES RR0510P-472-D (4.7K) T 5.6/17.1
R10 7030004970 S.RES ERJ2GEJ 470 X (47) T 4.7/18.5
R11 7030005300 S.RES ERJ2GEJ 150 X (15) T 0.69/15.6
R12 7030005530 S.RES ERJ2GEJ 100 X (10) T 1.8/17.1
R13 7030005300 S.RES ERJ2GEJ 150 X (15) T 1.2/18.4
R14 7030005720 S.RES ERJ2GEJ 563 X (56K) B 3.7/18.1
R15 7030004990 S.RES ERJ2GEJ 221 X (220) B 3.2/15.8
R16 7030007270 S.RES ERJ2GEJ 151 X (150) B 2.2/16.6
R17 7030005120 S.RES ERJ2GEJ 102 X (1K) B 4.5/13.7
R18 7030007280 S.RES ERJ2GEJ 331 X (330) B 9.5/13.5
R19 7030009270 S.RES ERJ2GEJ 821 X (820) B 9.8/15.3
R20 7030005530 S.RES ERJ2GEJ 100 X (10) B 8.5/13.5
R21 7030005600 S.RES ERJ2GEJ 273 X (27K) T 1.8/11.5
R22 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 8.7/11
R23 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 11.5/8.3
R25 7030005120 S.RES ERJ2GEJ 102 X (1K) T 6.6/12.5
R26 7030005120 S.RES ERJ2GEJ 102 X (1K) T 4.8/13.6
R27 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 9.8/12.3
R28 7030005530 S.RES ERJ2GEJ 100 X (10) T 8.1/12
R29 7030005120 S.RES ERJ2GEJ 102 X (1K) B 3.6/3.2
R30 7030008300 S.RES ERJ2GEJ 184 X (180K) B 3.1/4.5
R31 7030005120 S.RES ERJ2GEJ 102 X (1K) B 5.7/4.6
R32 7030005120 S.RES ERJ2GEJ 102 X (1K) B 5.6/3.3
R33 7030003440 S.RES ERJ3GEYJ 102 V (1K) T 13.5/16.4
C1 4030017620 S.CER ECJ0EC1H100C T 10.1/3.3
C2 4030017600 S.CER ECJ0EC1H080C T 6.4/6.6
C3 4030017580 S.CER ECJ0EC1H060C T 5.1/6.1
C4 4030017600 S.CER ECJ0EC1H080C T 3.6/5
C5 4030017730 S.CER ECJ0EB1E471K T 8.3/3.3
C6 4030017730 S.CER ECJ0EB1E471K T 11.7/7.3
C7 4030017340 S.CER ECJ0EC1H010B T 13.1/4.5
C8 4030017350 S.CER ECJ0EC1H020B T 9.1/16.6
C9 4030017350 S.CER ECJ0EC1H020B T 9.1/14.8
C10 4030017340 S.CER ECJ0EC1H010B T 3.6/17.1
C11 4030017460 S.CER ECJ0EB1E102K T 6.8/14.9
C12 4550007600 S.TAN F920J106MPABMA T 2.8/15.7
C13 4030017400 S.CER ECJ0EC1H220J T 12/18.2
C14 4030016930 S.CER ECJ0EB1A104K B 6.1/16.8
C15 4030017730 S.CER ECJ0EB1E471K B 3.4/19.1
C16 4030017730 S.CER ECJ0EB1E471K B 3.7/17.1
C17 4030017730 S.CER ECJ0EB1E471K B 3.2/14
C18 4030017730 S.CER ECJ0EB1E471K B 3.7/12.7
C19 4030017730 S.CER ECJ0EB1E471K T 3.5/18.5
C21 4030017730 S.CER ECJ0EB1E471K B 12.9/13.3
C22 4550006910 S.TAN TEESVP 1C 334M8R T 12.1/13.3
C23 4550007070 S.TAN TEESVP 1A 475M8R B 11.2/14.3
C26 4030016930 S.CER ECJ0EB1A104K B 2.6/9.3
C27 4030017620 S.CER ECJ0EC1H100C T 1/13.1
C28 4030017340 S.CER ECJ0EC1H010B T 6.1/9.8
C29 4030017340 S.CER ECJ0EC1H010B T 7.4/9.5
C30 4030017350 S.CER ECJ0EC1H020B T 8.7/10
C31 4030017630 S.CER ECJ0EC1H120J T 6.1/8.8
C32 4030017400 S.CER ECJ0EC1H220J T 8.7/9
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[DOWNCONV UNIT]
C34 4030017730 S.CER ECJ0EB1E471K T 5.7/11.1
C35 4030017730 S.CER ECJ0EB1E471K T 2/13.5
C36 4030017350 S.CER ECJ0EC1H020B T 4.8/12.6
C37 4030017730 S.CER ECJ0EB1E471K T 8.5/13.1
C38 4030017730 S.CER ECJ0EB1E471K T 11.2/11.9
C39 4030017340 S.CER ECJ0EC1H010B T 10.2/7.6
C40 4030017570 S.CER ECJ0EC1H040B T 10/14.9
C41 4030017640 S.CER ECJ0EC1H150J T 1.6/6.1
C42 4030017630 S.CER ECJ0EC1H120J T 5.1/3.5
C43 4030017730 S.CER ECJ0EB1E471K T 4.1/3.5
C44 4030017730 S.CER ECJ0EB1E471K B 11.2/6.2
C45 4030017360 S.CER ECJ0EC1H030B B 12.5/5.2
C46 4030017360 S.CER ECJ0EC1H030B B 9.1/3.6
C47 4030016790 S.CER ECJ0EB1C103K B 2.1/4
C48 4030016790 S.CER ECJ0EB1C103K B 5.9/6
C49 4030016790 S.CER ECJ0EB1C103K B 4.1/4.5
C50 4030017730 S.CER ECJ0EB1E471K B 2.4/11.6
C51 4030017730 S.CER ECJ0EB1E471K B 12.1/7.8
C52 4030017730 S.CER ECJ0EB1E471K B 2.6/8.3
C53 4030016790 S.CER ECJ0EB1C103K B 7.4/3.3
C54 4030017420 S.CER ECJ0EC1H470J B 6.1/13
C55 4030017420 S.CER ECJ0EC1H470J B 7.5/15.5
C56 4030017420 S.CER ECJ0EC1H470J T 12.7/3.2
C58 4030016930 S.CER ECJ0EB1A104K T 4.8/15
J1 6910015511 CON IMSA-9230B-1-08Z064-PT1
J2 6910015531 CON IMSA-9230B-1-06Z064-PT1

Jan. 2010
10
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[LOGIC UNIT]
IC1 1130014370 S.IC CAT24C256XI-T2 B 72.5/21.5
IC2 1130011980 S.IC BD5228G-TR B 72.6/3.1
IC3 1140012100 S.IC M30620MCP-129GP
(RX-2699B J/E) [EUR] B 54.1/20
1140012100 S.IC M30620MCP-129GP
(RX-2699B J/E) [UK]
1140012110 S.IC M30620MCP-130GP
(RX-2699C USA) [USA]
1140012100 S.IC M30620MCP-129GP
(RX-2699B J/E) [FRA]
1140012100 S.IC M30620MCP-129GP
(RX-2699B J/E) [SEA]
1140012100 S.IC M30620MCP-129GP
(RX-2699B J/E) [EXP-01]
1140012100 S.IC M30620MCP-129GP
(RX-2699B J/E) [EXP-02]
1140012100 S.IC M30620MCP-129GP
(RX-2699B J/E) [CAN]
1140012100 S.IC M30620MCP-129GP
(RX-2699B J/E) [CHN]
IC4 1130007111 S.IC TC7W04FU(TE12L,F) B 99.5/10.8
IC5 1190000711 S.IC TA31056FG(EL) B 111.6/18.4
IC6 1130004831 S.IC TC7SU04F(TE85R,F) B 96.3/40.6
IC7 1130011860 S.IC SM6451BT-G-E2 B 80.4/3
IC8 1180002371 S.REG R1111N321B-TR-F B 39/29.3
IC9 1180002371 S.REG R1111N321B-TR-F B 42.6/44.5
IC11 1130007111 S.IC TC7W04FU(TE12L,F) B 14.3/3.1
IC12 1110006380 S.IC LM2904PWR B 73.9/46.6
IC13 1110006380 S.IC LM2904PWR B 73.9/34.6
IC14 1130006551 S.IC TC7S08FU(TE85R,F) B 72.8/10.2
IC15 1130006551 S.IC TC7S08FU(TE85R,F) B 72.8/12.7
Q1 1530003630 S.TRA 2SC4617 TLS T 19.9/10.4
Q3 1510000771 S.TRA 2SA1586-GR(TE85L,F) B 97.5/7
Q4 1530003630 S.TRA 2SC4617 TLS T 24.9/10.4
Q5 1530003630 S.TRA 2SC4617 TLS B 112.9/48.9
Q6 1530002691 S.TRA 2SC4116-GR(TE85R,F) B 99.6/4.5
Q7 1590001170 S.TRA XP1501-(TX).AB B 118.9/23.8
Q8 1510000671 S.TRA 2SA1588-GR(TE85R, F) B 111/13.1
Q9 1520000460 S.TRA 2SB1132 T100 R B 117.9/19.3
Q10 1510000581 S.TRA 2SA1362-GR(TE85R,F) B 84.8/42.4
Q11 1590003231 S.TRA UNR9113G0L B 93.6/38.1
Q12 1530003630 S.TRA 2SC4617 TLS B 100.3/16.5
Q13 1590001190 S.TRA XP6501-(TX).AB B 35.5/44.7
Q14 1510000671 S.TRA 2SA1588-GR(TE85R, F) B 35.4/41.9
Q15 1510000581 S.TRA 2SA1362-GR(TE85R,F) B 88.8/42.4
Q16 1530003630 S.TRA 2SC4617 TLS B 105.7/15.5
Q17 1510000671 S.TRA 2SA1588-GR(TE85R, F) B 38.7/47.4
Q19 1590001391 S.FET 2SJ144-Y(TE85R,F) B 85.3/9.5
Q20 1590003251 S.TRA UNR9115G0L B 70.9/43.7
Q21 1590003251 S.TRA UNR9115G0L B 70.9/31.6
Q22 1530003630 S.TRA 2SC4617 TLS B 89.1/10.8
Q23 1530003630 S.TRA 2SC4617 TLS B 80.9/14
Q24 1590001190 S.TRA XP6501-(TX).AB B 85.7/34.1
Q25 1590001190 S.TRA XP6501-(TX).AB B 85.6/20.5
Q26 1590001391 S.FET 2SJ144-Y(TE85R,F) B 88.5/14.7
Q27 1590001391 S.FET 2SJ144-Y(TE85R,F) B 88.6/28.3
Q28 1530003630 S.TRA 2SC4617 TLS B 29/5.2
Q29 1590003291 S.TRA UNR9213G0L B 39/12.8
Q30 1520000651 S.TRA 2SB1201S-TL-E T 3.8/38.5
Q31 1590002950 S.FET HAT1023R-EL T 23.4/38.7
Q32 1530003630 S.TRA 2SC4617 TLS T 1.6/30.4
Q33 1520000460 S.TRA 2SB1132 T100 R T 9.8/39.2
Q34 1590003391 S.TRA UNR9215G0L T 3.8/27.7
Q35 1590003291 S.TRA UNR9213G0L T 9/49.2
Q36 1530003630 S.TRA 2SC4617 TLS T 32/10.5
Q37 1510000671 S.TRA 2SA1588-GR(TE85R, F) B 39.5/42.1
Q38 1590001650 S.TRA XP4601(TX) B 100.2/36
D2 1790001241 S.DIO MA2S7280GL [FRA] B 22.3/37.3
1790001241 S.DIO MA2S7280GL [SEA]
1790001241 S.DIO MA2S7280GL [EXP-01]
1790001241 S.DIO MA2S7280GL [EXP-02]
1790001241 S.DIO MA2S7280GL [CAN]
1790001241 S.DIO MA2S7280GL [CHN]
D3 1750000940 S.DIO 1SS400 TE61 T 33.8/30
D5 1790001241 S.DIO MA2S7280GL [USA] B 22.3/35.6
1790001241 S.DIO MA2S7280GL [FRA]
D6 1750000940 S.DIO 1SS400 TE61 T 33.8/28.4
D8 1790001241 S.DIO MA2S7280GL [UK] B 22.3/34
1790001241 S.DIO MA2S7280GL [USA]
D9 1750000940 S.DIO 1SS400 TE61 T 33.8/26.8
D10 1750000940 S.DIO 1SS400 TE61 [FRA] only B 25.8/32.4
D11 1790001241 S.DIO MA2S7280GL [EUR] B 22.3/32.4
1790001241 S.DIO MA2S7280GL [FRA]
D12 1750000940 S.DIO 1SS400 TE61 T 33.8/25.2
D13 1750000940 S.DIO 1SS400 TE61 B 97.5/4.4
D14 1750000771 S.VAR HVC376BTRF-E B 68.2/4.2
D18 1750001830 S.VAR SVC389-TL-E B 95.1/45.4
D20 1750000940 S.DIO 1SS400 TE61 B 82.5/30.9
D21 1750000940 S.DIO 1SS400 TE61 B 83.4/17.3
D22 1790001561 S.DIO 1SS372(TE85R,F) B 18.4/3
D23 1790001561 S.DIO 1SS372(TE85R,F) B 21/3
D24 1790001561 S.DIO 1SS372(TE85R,F) B 23.6/3
D25 1790001561 S.DIO 1SS372(TE85R,F) B 26.2/3
D26 1750000940 S.DIO 1SS400 TE61 T 27.2/42.9
D27 1750000940 S.DIO 1SS400 TE61 T 16.1/42.4
D28 1790001251 S.DIO MA2S1110GL T 3.5/30.3
D29 1790000671 S.DIO SB07-03C-TB-E T 9/44.2
D30 1750000940 S.DIO 1SS400 TE61 T 23.9/44.3
D31 1750000940 S.DIO 1SS400 TE61 T 16.1/41
D32 1790001251 S.DIO MA2S1110GL B 39.6/10.1
D33 1730002511 S.ZEN MAZ8027GHL B 35.5/6.6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[LOGIC UNIT]
D34 1790000671 S.DIO SB07-03C-TB-E T 28.9/37
D35 1790001241 S.DIO MA2S7280GL T 28.6/40.6
D36 1790000861 S.DIO MA3S1330GL T 7.3/32.4
D37 1750001830 S.VAR SVC389-TL-E B 95.1/48.8
X1 6050011310 S.XTA CR-717 SX-1302 9.8304 MHz B 62.6/6.5
X2 6060000820 S.CER CSBFB453KJ58-R1 B 105.8/44.5
L1 6200003640 S.COI MLF1608E 100K-T B 16.5/5.9
R1 7410001110 S.ARR EXB28V332JX B 57.6/31.9
R2 7410001220 S.ARR EXB28V103JX B 61.8/42.4
R3 7410001220 S.ARR EXB28V103JX B 68.4/27.2
R4 7030005050 S.RES ERJ2GEJ 103 X (10K) B 72.1/5.3
R5 7410001220 S.ARR EXB28V103JX B 61.2/32.8
R6 7410001220 S.ARR EXB28V103JX B 73.9/25.6
R7 7030005050 S.RES ERJ2GEJ 103 X (10K) B 66.6/13.6
R8 7030005240 S.RES ERJ2GEJ 473 X (47K) B 50.3/3.8
R9 7030005240 S.RES ERJ2GEJ 473 X (47K) B 66.4/23.6
R10 7030005050 S.RES ERJ2GEJ 103 X (10K) B 65.7/22.9
R11 7030005120 S.RES ERJ2GEJ 102 X (1K) B 66.5/21.1
R12 7030005120 S.RES ERJ2GEJ 102 X (1K) T 18.3/10.3
R13 7030005310 S.RES ERJ2GEJ 124 X (120K) B 94.4/6
R14 7030005570 S.RES ERJ2GEJ 820 X (82) T 19.3/8.2
R15 7030005090 S.RES ERJ2GEJ 104 X (100K) B 96.3/9.4
R17 7410001220 S.ARR EXB28V103JX B 49.5/31.4
R18 7410001220 S.ARR EXB28V103JX B 66.2/16.6
R19 7030005570 S.RES ERJ2GEJ 820 X (82) T 21.3/8.2
R20 7030005090 S.RES ERJ2GEJ 104 X (100K) B 97.3/9.4
R21 7410001110 S.ARR EXB28V332JX B 47.7/29.6
R22 7030010040 S.RES ERJ2GEJ-JPW B 64.8/15.5
R23 7030005570 S.RES ERJ2GEJ 820 X (82) T 18.3/8.2
R24 7030005120 S.RES ERJ2GEJ 102 X (1K) B 64/14.7
R25 7410001110 S.ARR EXB28V332JX B 43.8/27.7
R26 7030005120 S.RES ERJ2GEJ 102 X (1K) B 63.3/14
R27 7030005530 S.RES ERJ2GEJ 100 X (10) B 57.4/8.1
R28 7030005160 S.RES ERJ2GEJ 105 X (1M) B 63.5/2.9
R29 7030005570 S.RES ERJ2GEJ 820 X (82) T 20.3/8.2
R30 7030005120 S.RES ERJ2GEJ 102 X (1K) B 46.4/28.4
R31 7030005240 S.RES ERJ2GEJ 473 X (47K) B 61.8/13.2
R32 7030005120 S.RES ERJ2GEJ 102 X (1K) T 23.3/10.3
R33 7030005090 S.RES ERJ2GEJ 104 X (100K) B 111.8/46.4
R34 7030005050 S.RES ERJ2GEJ 103 X (10K) B 99.5/6.8
R35 7410001130 S.ARR EXB28V102JX B 41.6/25.5
R36 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 61/11.7
R38 7030005570 S.RES ERJ2GEJ 820 X (82) T 23.3/8.2
R39 7030005050 S.RES ERJ2GEJ 103 X (10K) B 95.4/7
R40 7030005050 S.RES ERJ2GEJ 103 X (10K) B 95.9/5.2
R41 7030008010 S.RES ERJ2GEJ 123 X (12K) B 100.5/6.8
R42 7410001130 S.ARR EXB28V102JX B 40.6/23
R43 7030007340 S.RES ERJ2GEJ 153 X (15K) B 28.2/32.7
R45 7030005530 S.RES ERJ2GEJ 100 X (10) B 28.2/31.7
R47 7030007320 S.RES ERJ2GEJ 225 X (2.2M) B 68/5.8
R49 7030005570 S.RES ERJ2GEJ 820 X (82) T 24.3/8.2
R51 7410001130 S.ARR EXB28V102JX B 38.9/20
R52 7030005090 S.RES ERJ2GEJ 104 X (100K) B 69/5.8
R53 7030005570 S.RES ERJ2GEJ 820 X (82) T 22.3/8.2
R54 7030005050 S.RES ERJ2GEJ 103 X (10K) B 116.7/26.2
R55 7030005570 S.RES ERJ2GEJ 820 X (82) T 26.3/8.2
R56 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 116.7/24
R57 7030010040 S.RES ERJ2GEJ-JPW B 100.9/1.7
R58 7030005100 S.RES ERJ2GEJ 154 X (150K) B 27.7/36.6
R59 7030005100 S.RES ERJ2GEJ 154 X (150K) B 28.7/36.6
R60 7030005100 S.RES ERJ2GEJ 154 X (150K) B 35.9/24.4
R61 7030005100 S.RES ERJ2GEJ 154 X (150K) B 36.9/24.4
R62 7030005090 S.RES ERJ2GEJ 104 X (100K) B 70/5.8
R63 7410001220 S.ARR EXB28V103JX B 40.6/17.5
R64 7030005000 S.RES ERJ2GEJ 471 X (470) B 117.8/26.2
R66 7030005120 S.RES ERJ2GEJ 102 X (1K) B 45/14
R67 7030005120 S.RES ERJ2GEJ 102 X (1K) B 45/13
R68 7030005120 S.RES ERJ2GEJ 102 X (1K) B 45/12
R69 7030005050 S.RES ERJ2GEJ 103 X (10K) B 45/11
R70 7030010040 S.RES ERJ2GEJ-JPW B 49.3/4.6
R71 7030010040 S.RES ERJ2GEJ-JPW B 48.6/5.4
R72 7030010040 S.RES ERJ2GEJ-JPW B 47.8/6.1
R73 7030010040 S.RES ERJ2GEJ-JPW B 46.5/6.2
R74 7030005240 S.RES ERJ2GEJ 473 X (47K) B 42/12
R76 7030005240 S.RES ERJ2GEJ 473 X (47K) B 42/13
R77 7410001130 S.ARR EXB28V102JX B 42/15
R82 7030005240 S.RES ERJ2GEJ 473 X (47K) B 45.5/6.2
R83 7030005240 S.RES ERJ2GEJ 473 X (47K) B 38.5/15.8
R84 7030005050 S.RES ERJ2GEJ 103 X (10K) B 101.3/18.2
R85 7030004980 S.RES ERJ2GEJ 101 X (100) B 93.9/40.1
R86 7030005090 S.RES ERJ2GEJ 104 X (100K) B 36.5/39.6
R87 7030007350 S.RES ERJ2GEJ 393 X (39K) B 35/40.1
R88 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 34.8/47.3
R89 7030005170 S.RES ERJ2GEJ 474 X (470K) B 84.4/44.6
R90 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 85.9/45.1
R91 7030009290 S.RES ERJ2GEJ 562 X (5.6K) B 99.3/18.2
R93 7030005160 S.RES ERJ2GEJ 105 X (1M) B 97.3/44.9
R94 7030005240 S.RES ERJ2GEJ 473 X (47K) B 37.9/45.6
R95 7030005050 S.RES ERJ2GEJ 103 X (10K) B 106.7/17.2
R96 7030005160 S.RES ERJ2GEJ 105 X (1M) B 99.8/43.9
R97 7030005160 S.RES ERJ2GEJ 105 X (1M) B 97.3/48.2
R98 7030005060 S.RES ERJ2GEJ 333 X (33K) B 37.4/44.1
R99 7030005170 S.RES ERJ2GEJ 474 X (470K) B 88.4/44.6
R100 7030010040 S.RES ERJ2GEJ-JPW B 89.9/45.1
R101 7030009290 S.RES ERJ2GEJ 562 X (5.6K) B 104.7/17.2
R103 7030005060 S.RES ERJ2GEJ 333 X (33K) B 99.8/45.4
R104 7030005170 S.RES ERJ2GEJ 474 X (470K) B 40.8/47.6
R105 7030005290 S.RES ERJ2GEJ 682 X (6.8K) B 40.3/49.1
R106 7030010040 S.RES ERJ2GEJ-JPW B 82.6/7

Jan. 2010
11
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[LOGIC UNIT]
R107 7030005160 S.RES ERJ2GEJ 105 X (1M) B 79.2/9.5
R108 7030005170 S.RES ERJ2GEJ 474 X (470K) B 79.2/10.5
R110 7030005080 S.RES ERJ2GEJ 823 X (82K) B 81.8/10
R111 7030010040 S.RES ERJ2GEJ-JPW B 40/32.3
R112 7030005310 S.RES ERJ2GEJ 124 X (120K) B 70.9/48.2
R113 7030005310 S.RES ERJ2GEJ 124 X (120K) B 70.9/36
R114 7030007320 S.RES ERJ2GEJ 225 X (2.2M) B 83.1/10.5
R115 7030008010 S.RES ERJ2GEJ 123 X (12K) B 71.4/49.7
R116 7030008010 S.RES ERJ2GEJ 123 X (12K) B 71.4/37.5
R117 7030005160 S.RES ERJ2GEJ 105 X (1M) B 86/7.2
R118 7030005530 S.RES ERJ2GEJ 100 X (10) B 90.6/8.6
R119 7030008010 S.RES ERJ2GEJ 123 X (12K) B 89.1/9.1
R120 7030009270 S.RES ERJ2GEJ 821 X (820) B 90.2/12.5
R121 7030005530 S.RES ERJ2GEJ 100 X (10) B 80.6/19
R122 7030005050 S.RES ERJ2GEJ 103 X (10K) B 80.6/17
R123 7030009270 S.RES ERJ2GEJ 821 X (820) B 83/13.5
R124 7030005170 S.RES ERJ2GEJ 474 X (470K) B 87.6/11
R125 7030005170 S.RES ERJ2GEJ 474 X (470K) B 81.1/15.5
R126 7030005170 S.RES ERJ2GEJ 474 X (470K) B 75.5/40.7
R127 7030005170 S.RES ERJ2GEJ 474 X (470K) B 75.6/28.6
R128 7030008300 S.RES ERJ2GEJ 184 X (180K) B 82.2/29.1
R129 7030008300 S.RES ERJ2GEJ 184 X (180K) B 82.2/17
R130 7030008300 S.RES ERJ2GEJ 184 X (180K) B 73.4/40.7
R131 7030009150 S.RES ERJ2GEJ 824 X (820K) B 74.5/40.7
R132 7030008300 S.RES ERJ2GEJ 184 X (180K) B 73.4/28.6
R133 7030009150 S.RES ERJ2GEJ 824 X (820K) B 74.5/28.6
R134 7030005080 S.RES ERJ2GEJ 823 X (82K) B 85.7/29.6
R135 7030005090 S.RES ERJ2GEJ 104 X (100K) B 85.2/28.1
R136 7030005080 S.RES ERJ2GEJ 823 X (82K) B 85.6/16
R137 7030005090 S.RES ERJ2GEJ 104 X (100K) B 85.1/14.5
R139 7030005080 S.RES ERJ2GEJ 823 X (82K) B 76.9/48.2
R140 7030005080 S.RES ERJ2GEJ 823 X (82K) B 76.9/36
R141 7030007340 S.RES ERJ2GEJ 153 X (15K) B 83.1/33.1
R142 7030007340 S.RES ERJ2GEJ 153 X (15K) B 83.1/19.5
R143 7030005170 S.RES ERJ2GEJ 474 X (470K) B 76.9/47.2
R144 7030005170 S.RES ERJ2GEJ 474 X (470K) B 76.9/35
R145 7030005090 S.RES ERJ2GEJ 104 X (100K) B 83.1/34.1
R146 7030005090 S.RES ERJ2GEJ 104 X (100K) B 83.1/20.5
R147 7030007320 S.RES ERJ2GEJ 225 X (2.2M) B 86.6/15
R148 7030005100 S.RES ERJ2GEJ 154 X (150K) B 76.9/46.2
R149 7030007350 S.RES ERJ2GEJ 393 X (39K) B 76.9/45.2
R150 7030005100 S.RES ERJ2GEJ 154 X (150K) B 76.9/34
R151 7030007350 S.RES ERJ2GEJ 393 X (39K) B 76.9/33
R152 7030008300 S.RES ERJ2GEJ 184 X (180K) B 87.7/32.6
R153 7030008300 S.RES ERJ2GEJ 184 X (180K) B 85.2/31.1
R154 7030007320 S.RES ERJ2GEJ 225 X (2.2M) B 86.7/28.6
R155 7030008300 S.RES ERJ2GEJ 184 X (180K) B 87.6/19
R156 7030008300 S.RES ERJ2GEJ 184 X (180K) B 86.1/18.5
R157 7030005080 S.RES ERJ2GEJ 823 X (82K) B 78.4/48.7
R158 7030007320 S.RES ERJ2GEJ 225 X (2.2M) B 85.2/36.1
R159 7030005170 S.RES ERJ2GEJ 474 X (470K) B 83.1/35.1
R160 7030007320 S.RES ERJ2GEJ 225 X (2.2M) B 85.1/22.5
R161 7030005170 S.RES ERJ2GEJ 474 X (470K) B 83.1/21.5
R162 7030005080 S.RES ERJ2GEJ 823 X (82K) B 78.4/36.5
R163 7030005160 S.RES ERJ2GEJ 105 X (1M) B 88.2/30.1
R164 7030005160 S.RES ERJ2GEJ 105 X (1M) B 89.1/16.5
R165 7030007350 S.RES ERJ2GEJ 393 X (39K) B 78.4/44.7
R166 7030007350 S.RES ERJ2GEJ 393 X (39K) B 78.4/32.5
R167 7030005050 S.RES ERJ2GEJ 103 X (10K) B 28.8/6.7
R168 7030005090 S.RES ERJ2GEJ 104 X (100K) B 79.4/40.7
R169 7030005090 S.RES ERJ2GEJ 104 X (100K) B 79.4/28.6
R170 7030007320 S.RES ERJ2GEJ 225 X (2.2M) B 87.2/38.1
R172 7030007320 S.RES ERJ2GEJ 225 X (2.2M) B 87.1/23.5
R174 7030005090 S.RES ERJ2GEJ 104 X (100K) B 79.4/44.7
R175 7030005090 S.RES ERJ2GEJ 104 X (100K) B 79.4/32.5
R176 7030006610 S.RES ERJ2GEJ 394 X (390K) B 87.2/36.1
R177 7030008300 S.RES ERJ2GEJ 184 X (180K) B 88.7/33.6
R178 7030006610 S.RES ERJ2GEJ 394 X (390K) B 87.1/22.5
R179 7030008300 S.RES ERJ2GEJ 184 X (180K) B 88.6/20
R180 7030005240 S.RES ERJ2GEJ 473 X (47K) B 38.5/14.8
R181 7030005590 S.RES ERJ2GEJ 680 X (68) T 3.8/32.6
R182 7030007570 S.RES ERJ2GEJ 122 X (1.2K) T 4.9/30.6
R183 7030005120 S.RES ERJ2GEJ 102 X (1K) T 25.1/42.6
R184 7030005570 S.RES ERJ2GEJ 820 X (82) T 1.6/32.6
R185 7030003210 S.RES ERJ3GEYJ 120 V (12) T 9.2/35.1
R186 7030003210 S.RES ERJ3GEYJ 120 V (12) T 7.8/35.1
R187 7030005120 S.RES ERJ2GEJ 102 X (1K) T 1.1/28.2
R188 7030007270 S.RES ERJ2GEJ 151 X (150) T 2.1/28.2
R189 7030005120 S.RES ERJ2GEJ 102 X (1K) T 9/46.9
R190 7510001470 S.THE NTCG20 4AG 473JT B 62/46.5
R191 7030005090 S.RES ERJ2GEJ 104 X (100K) B 60.5/45.1
R192 7030008300 S.RES ERJ2GEJ 184 X (180K) T 28.4/42.6
R193 7030005090 S.RES ERJ2GEJ 104 X (100K) T 26.1/44.6
R194 7030005871 S.RES ERA3YKD 104V (100K) T 14.7/36.6
R195 7030008051 S.RES ERA3YKD 184V (180K) T 15.5/38.7
R196 7030000120 S.RES MCR10EZHJ 6.8 (6R8) T 12.7/34.7
R197 7030000120 S.RES MCR10EZHJ 6.8 (6R8) T 10.8/34.7
R198 7030005090 S.RES ERJ2GEJ 104 X (100K) T 30/8.8
R199 7030004990 S.RES ERJ2GEJ 221 X (220) T 32.5/8.2
R200 7030005210 S.RES ERJ2GEJ 822 X (8.2K) B 39.1/40.1
R201 7030005170 S.RES ERJ2GEJ 474 X (470K) B 37.4/42.1
R202 7030005570 S.RES ERJ2GEJ 820 X (82) T 25.3/8.2
R203 7030005570 S.RES ERJ2GEJ 820 X (82) B 110.3/50.4
R204 7030005570 S.RES ERJ2GEJ 820 X (82) B 99.3/49.5
R205 7030005570 S.RES ERJ2GEJ 820 X (82) B 119.9/47.2
R206 7030005570 S.RES ERJ2GEJ 820 X (82) B 117.3/47.2
R207 7030005090 S.RES ERJ2GEJ 104 X (100K) B 98.2/36
R208 7030005090 S.RES ERJ2GEJ 104 X (100K) B 99.3/33.7
R209 7030005090 S.RES ERJ2GEJ 104 X (100K) B 70.8/13.5
R210 7030005090 S.RES ERJ2GEJ 104 X (100K) B 42.4/40.5
R211 7030005000 S.RES ERJ2GEJ 471 X (470) B 80.7/6.4
R212 7030005000 S.RES ERJ2GEJ 471 X (470) B 80.7/7.4
R213 7030010040 S.RES ERJ2GEJ-JPW B 69.8/13.5
R214 7030010040 S.RES ERJ2GEJ-JPW B 80.7/8.4
R215 7030010040 S.RES ERJ2GEJ-JPW B 69/7.6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[LOGIC UNIT]
R216 7030010040 S.RES ERJ2GEJ-JPW B 70/7.6
R217 7030005090 S.RES ERJ2GEJ 104 X (100K) B 58.3/36.2
C1 4030016930 S.CER ECJ0EB1A104K B 68.3/24.6
C2 4030017460 S.CER ECJ0EB1E102K B 65/24.7
C3 4030017460 S.CER ECJ0EB1E102K B 65.3/25.7
C4 4030017460 S.CER ECJ0EB1E102K B 65.5/26.7
C5 4030017460 S.CER ECJ0EB1E102K B 63.8/30.1
C6 4030017460 S.CER ECJ0EB1E102K B 63.4/29.1
C7 4030016790 S.CER ECJ0EB1C103K B 72.1/0.69
C8 4030017460 S.CER ECJ0EB1E102K B 63/28.1
C9 4030017460 S.CER ECJ0EB1E102K B 62/27.1
C10 4030017460 S.CER ECJ0EB1E102K B 61/28.1
C11 4030017460 S.CER ECJ0EB1E102K B 61.4/29.1
C12 4030017460 S.CER ECJ0EB1E102K B 61.8/30.1
C13 4030016930 S.CER ECJ0EB1A104K B 66.8/25.2
C14 4030017460 S.CER ECJ0EB1E102K B 62.2/31.1
C16 4030017460 S.CER ECJ0EB1E102K B 60.1/9.9
C18 4030017420 S.CER ECJ0EC1H470J T 125.6/29.7
C19 4030017420 S.CER ECJ0EC1H470J T 125.6/12.6
C20 4030017420 S.CER ECJ0EC1H470J T 125.6/22.4
C21 4030017420 S.CER ECJ0EC1H470J T 125.6/5.3
C22 4030017640 S.CER ECJ0EC1H150J B 62.8/1.5
C23 4030016930 S.CER ECJ0EB1A104K B 44.6/25.6
C24 4030017460 S.CER ECJ0EB1E102K B 62.5/12.4
C26 4030017460 S.CER ECJ0EB1E102K B 111.8/47.4
C27 4030016790 S.CER ECJ0EB1C103K B 65.1/4.5
C28 4030017730 S.CER ECJ0EB1E471K B 69/1.2
C29 4030016930 S.CER ECJ0EB1A104K T 32.5/14.8
C30 4030018870 S.CER ECJ0EF0J105Z B 69.4/9
C31 4550007610 S.TAN F931E474MAABMA B 115.2/25.1
C33 4030017460 S.CER ECJ0EB1E102K T 121.7/10.8
C34 4550006550 S.TAN TEESVD 0G 227M12R B 120.3/14.4
C35 4030018870 S.CER ECJ0EF0J105Z B 69.4/10
C36 4030017680 S.CER ECJ0EC1H820J T 115/14.4
C37 4030017420 S.CER ECJ0EC1H470J B 100.9/2.7
C38 4550007300 S.TAN F931A335MAABMA B 121.1/26.1
C39 4030016930 S.CER ECJ0EB1A104K B 113.5/13.1
C40 4510009000 S.ELE EEE1AA330WR B 123.1/20.1
C41 4030016930 S.CER ECJ0EB1A104K B 121.7/24.6
C42 4030017430 S.CER ECJ0EC1H101J B 113.6/23.5
C43 4550007230 S.TAN F930J475MAABMA B 112.1/25.1
C44 4550007230 S.TAN F930J475MAABMA B 109.9/25.1
C45 4030016930 S.CER ECJ0EB1A104K B 35/39.1
C46 4030017490 S.CER C1608 JB 1A 105K-T B 97.6/16.5
C47 4030016930 S.CER ECJ0EB1A104K B 103.4/18.2
C48 4030017460 S.CER ECJ0EB1E102K B 84.4/39.6
C49 4030016930 S.CER ECJ0EB1A104K B 96.5/16.5
C50 4030016930 S.CER ECJ0EB1A104K B 92.9/40.1
C51 4030017460 S.CER ECJ0EB1E102K B 34.8/49.3
C52 4030017460 S.CER ECJ0EB1E102K B 84.9/46.1
C53 4030016790 S.CER ECJ0EB1C103K B 93.4/41.6
C54 4030016930 S.CER ECJ0EB1A104K B 96.7/37.6
C55 4030017460 S.CER ECJ0EB1E102K B 83.9/46.1
C56 4030016790 S.CER ECJ0EB1C103K B 97.8/43.4
C57 4030017490 S.CER C1608 JB 1A 105K-T B 103/15.5
C58 4030016930 S.CER ECJ0EB1A104K B 108.2/17.7
C59 4030017460 S.CER ECJ0EB1E102K B 89.3/40.2
C60 4030016930 S.CER ECJ0EB1A104K B 101.9/15.5
C61 4030017460 S.CER ECJ0EB1E102K B 37.5/39.6
C62 4550007230 S.TAN F930J475MAABMA B 36.3/48.9
C63 4030017460 S.CER ECJ0EB1E102K B 88.9/46.1
C64 4030017460 S.CER ECJ0EB1E102K B 87.9/46.1
C65 4030016790 S.CER ECJ0EB1C103K B 98.3/44.9
C66 4030017490 S.CER C1608 JB 1A 105K-T B 108.3/34.2
C67 4030017490 S.CER C1608 JB 1A 105K-T B 108.3/35.6
C68 4030017460 S.CER ECJ0EB1E102K B 37.9/49.6
C69 4030017460 S.CER ECJ0EB1E102K B 38.9/49.6
C70 4550007520 S.TAN F931A106MAABMA B 75.4/3.9
C71 4030017490 S.CER C1608 JB 1A 105K-T B 108.3/37
C72 4030017490 S.CER C1608 JB 1A 105K-T B 108.3/38.4
C73 4030016790 S.CER ECJ0EB1C103K B 99.6/38.6
C74 4030017730 S.CER ECJ0EB1E471K B 99.6/39.6
C75 4030017490 S.CER C1608 JB 1A 105K-T B 105/34.2
C76 4030017490 S.CER C1608 JB 1A 105K-T B 105/35.6
C77 4030017460 S.CER ECJ0EB1E102K B 43.9/47.3
C78 4030017490 S.CER C1608 JB 1A 105K-T B 105/37
C79 4030017490 S.CER C1608 JB 1A 105K-T B 105/38.4
C80 4550007520 S.TAN F931A106MAABMA B 85.4/3.7
C81 4030017490 S.CER C1608 JB 1A 105K-T B 105/39.8
C82 4550007320 S.TAN F930J226MAABMA B 36.4/26.4
C83 4550007320 S.TAN F930J226MAABMA B 42.3/48.9
C84 4030017780 S.CER ECJ0EB1E472K B 83.1/8.5
C85 4030016930 S.CER ECJ0EB1A104K B 83.1/9.5
C86 4030016930 S.CER ECJ0EB1A104K B 84.1/7.5
C87 4030017460 S.CER ECJ0EB1E102K B 70.4/40.7
C88 4030017460 S.CER ECJ0EB1E102K B 70.4/28.6
C89 4030017460 S.CER ECJ0EB1E102K B 42.1/42.1
C90 4550007260 S.TAN F931C475MAABMA B 47.6/44.5
C91 4030017460 S.CER ECJ0EB1E102K B 71.4/40.7
C92 4030017760 S.CER ECJ0EB1H222K B 70.4/46.7
C93 4030017460 S.CER ECJ0EB1E102K B 71.4/28.6
C94 4030017760 S.CER ECJ0EB1H222K B 70.4/34.5
C95 4030016930 S.CER ECJ0EB1A104K B 89.6/7.6
C96 4030016930 S.CER ECJ0EB1A104K B 84.1/11.5
C97 4030016930 S.CER ECJ0EB1A104K B 81.1/21.5
C98 4550007260 S.TAN F931C475MAABMA B 45.4/44.5
C99 4030016970 S.CER ECJ0EB1C223K B 71.4/46.7
C100 4030016970 S.CER ECJ0EB1C223K B 71.4/34.5
C101 4030016930 S.CER ECJ0EB1A104K B 88.6/7.6
C102 4030016930 S.CER ECJ0EB1A104K B 81.1/20.5
C103 4030016930 S.CER ECJ0EB1A104K B 87.6/8.6
C104 4030016930 S.CER ECJ0EB1A104K B 79.8/12
C105 4550007260 S.TAN F931C475MAABMA B 35.8/32.8

Jan. 2010
12
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[LOGIC UNIT]
C106 4510008040 S.ELE EEFCD 0K 330R B 39.3/36.2
C107 4550007510 S.TAN F931C106MBABMA B 28/41.4
C108 4030016930 S.CER ECJ0EB1A104K B 76.5/40.7
C109 4030016930 S.CER ECJ0EB1A104K B 76.6/28.6
C110 4030016930 S.CER ECJ0EB1A104K B 86.7/26.5
C111 4030016930 S.CER ECJ0EB1A104K B 86.1/13.5
C112 4030016930 S.CER ECJ0EB1A104K B 83.7/28.6
C113 4030016930 S.CER ECJ0EB1A104K B 83.4/15
C114 4030017460 S.CER ECJ0EB1E102K B 52.3/33
C115 4030016930 S.CER ECJ0EB1A104K B 90.7/11
C116 4030016930 S.CER ECJ0EB1A104K B 82.1/18.5
C117 4030017490 S.CER C1608 JB 1A 105K-T B 84.9/38.3
C118 4030017490 S.CER C1608 JB 1A 105K-T B 84.7/24.8
C119 4030016930 S.CER ECJ0EB1A104K B 83.6/31.6
C120 4030016930 S.CER ECJ0EB1A104K B 85.1/17.5
C122 4030016930 S.CER ECJ0EB1A104K B 84.7/29.5
C123 4030016930 S.CER ECJ0EB1A104K B 85.7/26.5
C124 4030016930 S.CER ECJ0EB1A104K B 84.6/16
C125 4030016930 S.CER ECJ0EB1A104K B 85.2/12.5
C126 4030017490 S.CER C1608 JB 1A 105K-T B 17.1/.9
C127 4030017730 S.CER ECJ0EB1E471K B 73.3/51.1
C128 4030017730 S.CER ECJ0EB1E471K B 73.3/39
C131 4030017490 S.CER C1608 JB 1A 105K-T B 18.4/5.2
C132 4030017490 S.CER C1608 JB 1A 105K-T B 19.7/.9
C133 4030017740 S.CER ECJ0EB1E821K B 85.2/32.1
C134 4030017740 S.CER ECJ0EB1E821K B 86.6/17
C135 4030017490 S.CER C1608 JB 1A 105K-T B 21/5.2
C136 4030017450 S.CER ECJ0EB1E271K B 87.7/34.6
C137 4030017450 S.CER ECJ0EB1E271K B 87.6/21
C138 4030017490 S.CER C1608 JB 1A 105K-T B 22.3/.9
C139 4030017460 S.CER ECJ0EB1E102K B 72.4/40.7
C140 4030017430 S.CER ECJ0EC1H101J B 73.9/42.2
C141 4030017460 S.CER ECJ0EB1E102K B 72.4/28.6
C142 4030017430 S.CER ECJ0EC1H101J B 73.9/30.1
C143 4030017490 S.CER C1608 JB 1A 105K-T B 23.6/5.2
C144 4030017490 S.CER C1608 JB 1A 105K-T B 24.9/.9
C145 4030016780 S.CER ECJ0EB1C153K B 77.4/49.7
C146 4030016780 S.CER ECJ0EB1C153K B 77.4/37.4
C147 4030018100 S.CER ECJ0EB1H681K B 83.6/36.6
C148 4030018100 S.CER ECJ0EB1H681K B 83.6/23
C149 4030017490 S.CER C1608 JB 1A 105K-T B 26.2/5.2
C150 4030017460 S.CER ECJ0EB1E102K B 77.4/43.7
C151 4030017460 S.CER ECJ0EB1E102K B 77.4/31.5
C152 4030008680 S.CER C2012 JF 1C 105Z-T B 28.3/2
C153 4030016930 S.CER ECJ0EB1A104K B 78.4/46.7
C154 4030016930 S.CER ECJ0EB1A104K B 78.4/34.5
C155 4030017730 S.CER ECJ0EB1E471K B 85.2/37.1
C156 4030016930 S.CER ECJ0EB1A104K B 86.7/30.6
C157 4030017730 S.CER ECJ0EB1E471K B 85.1/23.5
C158 4030016930 S.CER ECJ0EB1A104K B 87.6/17
C159 4550007260 S.TAN F931C475MAABMA B 31.6/2.9
C160 4030017720 S.CER ECJ0EB1H331K B 77.9/40.2
C161 4030017720 S.CER ECJ0EB1H331K B 77.9/28.1
C162 4030011600 S.CER C1608 JB 1E 104K-T B 29.9/2.4
C163 4030017720 S.CER ECJ0EB1H331K B 77.9/41.2
C164 4030017720 S.CER ECJ0EB1H331K B 77.9/29.1
C165 4030017760 S.CER ECJ0EB1H222K B 87.2/37.1
C166 4030018080 S.CER ECJ0EB1H182K B 89.2/32.1
C167 4030017760 S.CER ECJ0EB1H222K B 87.1/24.5
C168 4030018080 S.CER ECJ0EB1H182K B 89.1/18.5
C169 4030016790 S.CER ECJ0EB1C103K B 89.2/36.1
C170 4030016930 S.CER ECJ0EB1A104K B 89.7/34.6
C171 4030016790 S.CER ECJ0EB1C103K B 89.1/22.5
C172 4030016930 S.CER ECJ0EB1A104K B 89.6/21
C173 4030017460 S.CER ECJ0EB1E102K T 16.6/37.2
C174 4030016930 S.CER ECJ0EB1A104K B 60.5/44.1
C175 4030016930 S.CER ECJ0EB1A104K T 25.1/44.6
C176 4030016930 S.CER ECJ0EB1A104K T 16.1/39.8
C177 4030017460 S.CER ECJ0EB1E102K T 26.1/42.6
C178 4030017460 S.CER ECJ0EB1E102K T 29.4/42.6
C179 4030017460 S.CER ECJ0EB1E102K B 99.9/27
C180 4030017460 S.CER ECJ0EB1E102K T 5.5/27.7
C181 4030017460 S.CER ECJ0EB1E102K B 99.9/28
C182 4030017460 S.CER ECJ0EB1E102K T 20.8/42.6
C183 4030017780 S.CER ECJ0EB1E472K T 105/8.8
C184 4030017490 S.CER C1608 JB 1A 105K-T B 108.3/39.8
C185 4030017460 S.CER ECJ0EB1E102K T 30/9.8
C186 4030017460 S.CER ECJ0EB1E102K B 39.8/43.9
C187 4030017460 S.CER ECJ0EB1E102K B 40.6/39.6
C188 4030017460 S.CER ECJ0EB1E102K B 109.8/31.3
C189 4030017460 S.CER ECJ0EB1E102K B 75.2/0.69
C190 4030016930 S.CER ECJ0EB1A104K B 80.7/10
C191 4030016930 S.CER ECJ0EB1A104K B 16.5/8.2
C192 4030016930 S.CER ECJ0EB1A104K B 89.7/30.6
C193 4030016930 S.CER ECJ0EB1A104K B 90.6/6.5
C194 4030017490 S.CER C1608 JB 1A 105K-T B 14.4/6.2
C196 4030016930 S.CER ECJ0EB1A104K T 101.3/7.7
J3 6450002250 CON HSJ1456-010320
J5 6510022150 S.CON AXN340C130P B 93.7/27.5
J6 6450002131 CON 04-730A3-02BKA
J8 6510021901 S.CON BM02B-ASRS-TF(LF)(SN) T 26.4/2.7
J9 6510024221 S.CON 23FLZ-RSM2-TB(LF)(SN) B 113.8/36.8
DS1 5040002930 S.LED SML-512MW T86 T 81.3/38.4
DS2 5040002930 S.LED SML-512MW T86 T 45.6/25.9
DS3 5040002930 S.LED SML-512MW T86 T 45.6/38.4
DS4 5040002930 S.LED SML-512MW T86 T 81.3/25.9
DS5 5040002930 S.LED SML-512MW T86 T 63.2/25.9
DS6 5040002930 S.LED SML-512MW T86 T 63.2/38.4
DS7 5040002930 S.LED SML-512MW T86 T 81.3/13.4
DS8 5040002930 S.LED SML-512MW T86 T 63.2/13.4
DS9 5040002930 S.LED SML-512MW T86 T 45.6/13.4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[LOGIC UNIT]
DS11 5040002990 S.LED SML-512UWT86 T 32.8/6.6
DS12 5030002691 LCD M3-0243TIY-1
S24 2250000200 ENC TP90N00E20-16F-1517
S25 2250000200 ENC TP90N00E20-16F-1517
EP1 6910012350 S.BEA MMZ1608Y 102BT T 125.4/28.5
EP2 6910012350 S.BEA MMZ1608Y 102BT T 125.4/23.5
EP3 6910012350 S.BEA MMZ1608Y 102BT T 125.4/11.4
EP4 6910012350 S.BEA MMZ1608Y 102BT T 125.4/6.4
EP6 6910014680 S.BEA MMZ1608Y 121BT B 112.4/2.8
EP7 6910013310 S.BEA MMZ1608D121B T 114.5/12.5
EP8 6910014680 S.BEA MMZ1608Y 121BT B 112.3/11.2
EP9 6910014690 S.BEA MPZ1608S221A-T T 102.6/8.8
EP10 6910014690 S.BEA MPZ1608S221A-T T 105.5/6.9
EP12 6910018350 E.O SD1081 RX2699
EP13 6910016220 S.BEA MZA2010D121C B 47.3/10.7

Jan. 2010
13
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
[REC UNIT]
IC1 1130011980 S.IC BD5228G-TR T 12.2/15.2
IC2 1140012090 S.IC M30622M6P-131GP
(RX-2699A ALL) B 14.9/26.2
IC3 1130011681 S.IC FT245BL T 27.4/16.7
IC4 1130012250 S.IC SN74AHC1G02DCKR B 9.3/37.3
IC5 1130012260 S.IC SN74AHC1G32DCKR B 7.5/35.5
IC6 1130011971 S.IC K9F5608U0D-PCB0 <TOMO> B 24.2/12.2
IC7 1190001951 S.IC ML2302TBZ03A T 19.7/28.2
IC8 1130011801 S.IC SN74AHC1G66HDBV3 T 24.5/38.3
IC9 1130011801 S.IC SN74AHC1G66HDBV3 T 24.5/41.8
IC10 1180002371 S.REG R1111N321B-TR-F T 17.8/15.3
Q1 1590003301 S.TRA UNR921NG0L B 38.3/9.5
Q2 1590003511 S.TRA UNR9119G0L B 35.9/9.7
X1 6050010940 S.XTA CR-672 SMD-49 6.000 MHz
<KDS> T 7.4/13.9
X2 6050011240 S.XTA CR-708 DSX631S 16.384 MHz T 7.5/24.9
R1 7030005050 S.RES ERJ2GEJ 103 X (10K) T 11.2/19.5
R6 7030009530 S.RES ERJ2GEJ 270 X (27) T 35.4/12
R7 7030009530 S.RES ERJ2GEJ 270 X (27) T 35.9/13.5
R8 7030005240 S.RES ERJ2GEJ 473 X (47K) T 4.3/30
R9 7030005050 S.RES ERJ2GEJ 103 X (10K) T 12.7/18.7
R10 7030005240 S.RES ERJ2GEJ 473 X (47K) B 6.5/19.5
R11 7030005000 S.RES ERJ2GEJ 471 X (470) T 22/11.8
R12 7030007280 S.RES ERJ2GEJ 331 X (330) B 9.3/15.8
R13 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 34.6/13.4
R15 7030005240 S.RES ERJ2GEJ 473 X (47K) T 4.3/32
R16 7030005170 S.RES ERJ2GEJ 474 X (470K) T 28.3/33.6
R17 7030005100 S.RES ERJ2GEJ 154 X (150K) T 27.9/35.4
R18 7030005230 S.RES ERJ2GEJ 334 X (330K) T 46.1/46.6
R19 7030005240 S.RES ERJ2GEJ 473 X (47K) T 4.3/31
R20 7030004980 S.RES ERJ2GEJ 101 X (100) B 39.3/7.5
R21 7030005090 S.RES ERJ2GEJ 104 X (100K) T 8/31.4
R22 7030005090 S.RES ERJ2GEJ 104 X (100K) T 9.5/30.9
C1 4030016790 S.CER ECJ0EB1C103K T 32/10.5
C2 4550006050 S.TAN TEESVA 0J 106M8R T 15/14.8
C3 4030016790 S.CER ECJ0EB1C103K T 11.7/17.7
C4 4030016790 S.CER ECJ0EB1C103K T 17.3/17.7
C5 4030016790 S.CER ECJ0EB1C103K T 12.7/12.9
C6 4030017660 S.CER ECJ0EC1H330J B 7.9/16.6
C7 4030017660 S.CER ECJ0EC1H330J B 7.9/18
C8 4030017330 S.CER ECJ0EF1C104Z T 23.4/10.3
C9 4030017040 S.CER ECJ0EB1A333K T 35.9/15.7
C10 4030017330 S.CER ECJ0EF1C104Z B 10.7/15.1
C11 4030016790 S.CER ECJ0EB1C103K B 21.9/34.6
C12 4030016790 S.CER ECJ0EB1C103K B 6.4/18
C13 4030016790 S.CER ECJ0EB1C103K B 6/34.4
C14 4030016790 S.CER ECJ0EB1C103K B 13.9/4.1
C15 4030016790 S.CER ECJ0EB1C103K B 33.2/21.6
C16 4030016790 S.CER ECJ0EB1C103K T 28.9/31.4
C17 4030017390 S.CER ECJ0EC1H180J T 27.5/32.8
C18 4030016790 S.CER ECJ0EB1C103K T 21.6/40.8
C19 4030016790 S.CER ECJ0EB1C103K T 26/34.9
C20 4030017400 S.CER ECJ0EC1H220J T 10.3/22.7
C21 4030017400 S.CER ECJ0EC1H220J T 10.3/24.7
C22 4030016790 S.CER ECJ0EB1C103K T 19.7/38.7
C23 4030017490 S.CER C1608 JB 1A 105K-T T 14.4/35.5
C24 4030017490 S.CER C1608 JB 1A 105K-T T 16.4/37.5
C25 4030016790 S.CER ECJ0EB1C103K T 27.4/38.3
C26 4030016790 S.CER ECJ0EB1C103K T 27.4/41.8
C27 4550007460 S.TAN F930G107MBABMA B 35.3/5.6
C28 4030016790 S.CER ECJ0EB1C103K B 39.9/9.8
J2 6510024171 S.CON CSS5005-0401FSZ T 35.6/3.9
J6 6910006591 CON IMSA-9230B-1-04Z030-PT1
J7 6910006521 CON IMSA-9230B-1-06Z030-PT1
S1 2230001070 S.SWI JPM1990-2711R T 69.5/48.6
S2 2230001070 S.SWI JPM1990-2711R T 52.6/48.6
S3 2230001070 S.SWI JPM1990-2711R T 39.6/48.6
EP1 6910012350 S.BEA MMZ1608Y 102BT T 34/11.2
EP3 6910012350 S.BEA MMZ1608Y 102BT T 38.6/10.8
EP4 6910012350 S.BEA MMZ1608Y 102BT T 40.3/10.4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount

Jan. 2010
14
SECTION 9.
SECTION 9. BOARD LAYOUTS
The combination of top side and bottom side of this
• LOGIC UNIT
(TOP VIEW)
AFOUT
GND
1
2
J8
SP
W18
W19
+
–
J6
[DC]
[SP/CI-V]
J3
C18
C19
C20
C21
C29
C33
C36
C173
C175
C176
C177 C178
C180
C182
C183
C185
C196
D3
D6
D9
D12
D26
D27
D28
D29
D30
D31
D34
D35
D36
DS1
3SD2SD
DS4
6SD5SD
DS7 DS8 DS9
DS11
EP1
EP2
EP3
EP4
EP7
EP9
EP10
EP12
J8
Q1 Q4
Q30
Q31
Q32
Q33
Q34
Q35
Q36
R12
R14 R19 R23 R29
R32R38
R49 R53 R55
R181
R182
R183
R184
R185 R186
R187 R188
R189
R192
R193
R194
R195
R196 R197
R198
R199
R202
B6077D
H0H5H10H15H20H25H30H35H40H45H50H55H60H65H70H75H80H85H90H95H100H105H110H115H120H125H130
V0 V5 V10 V15 V20 V25 V30 V35 V40 V45 V50

Jan. 2010
15
The combination of top side and bottom side of this
• LOGIC UNIT
(BOTTOM VIEW)
J9
LCD
J5
140
20 21
LD2
+3S
GND
B_VCO2
B_VCO3
B_VCO4
PLLCK
PLLDATA
STR2
HFC
B1C
B2C
B3C
D
CLK
LD1
EAR
A_VCO1
A_VCO2
GND
B_DET
B_R3V
GND
B_NOISE
B_RSSI
+3V
GND
PLLBSTB
PLLDSTB
VP
GND
PLLESTB
PLLCSTB
PLLASTB
RFO
A_DET
A_R3V
GND
A_NOISE
A_RSSI
to RF UNIT J1
[L-DIAL]
[R-DIAL]
[DC]
[SP/CI-V]
Li-ion Battery
+
–
CP2
CP4
CP1
CP3
C1 C2
C3
C4
C5
C6
C7
C8
C9
C10
C11
C12
C13
C14
C16
C22
C23
C24
C26
C27
C28
C30
C31
C34
C35
C37
C38
C39
C40
C41
C42
C43 C44
C45
C46
C47
C48
C49
C50
C51
C52
C53
C54
C55
C56
C57
C58
C59
C60
C61
C62
C63 C64
C65
C66
C67
C68 C69
C70
C71
C72
C73
C74
C75
C76
C77
C78
C79
C80
C81
C82
C83
C84
C85
C86
C87 C88
C89
C90
C91
C92
C93
C94
C95
C96
C97
C98
C99 C100
C101
C102
C103
C104
C105
C106
C107
C108 C109
C110
C111
C112 C113
C114
C115
C116
C117
C118
C119
C120
C122
C123
C124
C125
C126
C127
C128
C131
C132
C133
C134
C135
C136 C137
C138
C139
C140
C141
C142
C143
C144
C145 C146
C147 C148
C149
C150 C151
C152
C153 C154
C155
C156
C157
C158
C159
C160
C161
C162
C163
C164
C165
C166
C167
C168
C169
C170
C171
C172
C174
C179
C181
C184
C186
C187
C188
C189
C190
C191
C192
C193
C194
D2
D5
D8
D7
D10 D11
D13
D14
D18
D20
D21
D22D23D24D25
D32
D33
D37
EP6
EP8 EP13
IC1
IC2
IC3
IC4
IC5
IC6
IC7
IC8
IC9
IC11
IC12
IC13
IC14IC15
J3
J5
J6
J9
L1
Q3
Q5
Q6
Q7
Q8
Q9
Q10
Q11
Q12
Q13
Q14
Q15
Q16
Q17
Q19
Q20
Q21
Q22
Q23
Q24 Q25
Q26
Q27
Q28
Q29
Q37
Q38
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R11
R13
R15
R17
R18
R20
R21
R22
R24
R25
R26
R27
R28
R30
R31
R33
R34
R35
R36
R39
R40
R41
R42
R43
R45
R47
R51
R52
R54 R56
R57
R58 R59
R60 R61
R62
R63
R64
R66
R67
R68
R69
R70
R71
R72
R73
R74
R76
R77
R82
R83
R84
R85
R86
R87
R88
R89
R90
R91
R93
R94
R95
R96
R97
R98
R99
R100
R101
R103
R104
R105
R106
R107
R108
R110
R111
R112
R113
R114
R115 R116
R117
R118
R119
R120
R121 R122
R123
R124
R125
R126 R127
R128
R129
R130 R131
R132 R133
R134
R135
R136
R137
R139
R140
R141
R142
R143
R144
R145
R146
R147
R148
R149
R150
R151
R152
R153
R154
R155
R156
R157
R158
R159
R160
R161
R162
R163
R164
R165 R166
R167
961R861R
R170
R172
R174 R175
R176
R177
R178
R179
R180
R190
R191
R200
R201
R203
R204
R205 R206
R207
R208
R209
R210
R211
R212
R213
R214
R215 R216
R217
S24S25
X1
X2
H0 H5 H10 H15 H20 H25 H30 H35 H40 H45 H50 H55 H60 H65 H70 H75 H80 H85 H90 H95 H100 H105 H110 H115 H120 H125 H130
V0V5V10V15V20V25V30V35V40V45V50

Jan. 2010
16
SECTION 11
.
VOLTAGE DIAGRAM
*: Refer to the PARTS LIST for the value and name of component.
RF UNIT (1/2)
3.0V
433 MHz
0V
ATT-ON
2.9V
5 MHz
2.0V
145 MHz
2.6V
145 MHz
51 MHz
2.9V
2.9V
145 MHz
2.6V
433 MHz
2.9V
433 MHz
3.0V
145 MHz
2.9V
470 MHz
2.9V
1295 MHz
1.9V
433 MHz
1
2
3
4
5
6
7
8
B_R3V
IFO16
AGC
ATT
IFO10
A_R3V
A-AGC
ANTSW
B_TRAC
A_ATTC
AGC
AGC
AGC
CGACGACGA
AGC
AGC
AGC
AGC
AGC
R220
15
C214
0.001
R108
2.2k
C16
0.001
C435
0.001
C566
0.01
R88
330
C408
0.001
R226
2.2k
C121
0.001
L61
6.8nH
R6
120
L13
5.6nH
C43
100p
R95
2.2k
Q508
XP4312
123
456
L91
3.9µH
D101
MA2S077G0
C544
0.001
L41
0.1µH
C662
0.1
R98
2.2k
R106
47k
C148
470p
C563
0.001
C539
0.1
R101
47k
R112
2.2k
C537
0.1
C206
3.5p
R216
2.2k
R78
330
R238
100k
L44
4.7nH
C561
0.001
C521
0.1
C27
0.001
R239
2.2k
C13
27p
R231
4.7k
R13 15k
R228
100
C543
0.001
R100
12k
R102
2.2k
C14
0.001
C32
0.001
R230
10k
C665
100p
R105
68
L81
0.27µH
C15
1p
C44
0.01
C50
1p
C49
3p
R11
47k
C40
15p
C524
0.01
R16
47k
C134
0.001
C55
0.001
R110 12k
R10
47k
C12
47p
L39
39nH
L11
15nH
C545
0.01
R236
10k
C41
5p
L56
6.8nH
C47
6p
C218
1p
R221
330
R222
2.2k
C42
3.5p
C538
0.1
C432
0.001
C663
0.1
C560
0.001
C136
7p
C568
47p
C69
0.001
R229
47k
C147
2.5p
L82
0.33µH
C546
0.1
C529
150p
C70
0.001
C410
0.001
R223
2.2k
C569
0.1
L9
33nH
C22
7p
C570
0.001
R99
1k
R224
3.3k
C558
0.001
R91
2.2k
C23
5p
C28
0.001
C59
2p
C674
47p
R237
2.7k
C48
6p R4
330
C416
27p
L60
6.8nH
C141
0.01
L5
15nH
L83
0.47µH
C516
220p
C30
0.001
C150
0.001
C667
0.01
L92
0.39µH
C536
0.1
C523
0.0015
L85
3.9µH
C233
0.001
C562
0.001
C571
0.001
C414
0.001
L4
22nH
C58
0.001
C548
0.001
C142
0.001
R8
15k
L10
22nH
R240
1k
R18
15k
R93
120
C52
470p
R19
47k
C540
0.1
C5
470p
L12
10nH
R15
47k
L70
0.10µH
C138
470p
R81
2.2k
C153
0.1
C54
0.001
R245
22k
C532
0.1
C677
2p
L93
22nH
L94
33nH C678
0.001
L95
15nH
FI4 EFCH429MKQP1
I
C679
0.001
C683
0.001
Q509
UNR9113G0
IC15
µPC2757TB
1RFI
2GND
3LO 4
PS
5
VCC
6
IFO IC16
µPC2757TB
1RFI
2GND
3LO 4
PS
5
VCC
6
IFO
L74
47nH
C747
0.001
C750
0.001
C746
3.5p
C748
0.001
R423
15
C436
3p
C749
0.001
L15
47nH
C71
3p
L101
6.8nH
L112
6.8nH
R471
15k
C807
0.001
C808
0.001
C809
0.001
C811
0.001
R472
330
C812
0.001
R473
47k
C814
2p
C815
0.001
C816
0.001
L113
6.8nH
R474
47k
C817
7p
R475
2.2k
D143
1DV308
C827
0.001
C828
0.001
R478
330
R479
15k
C832
0.001
R481
47k
C833
1p
C834
0.001
C835
0.001
C836
0.001
R482
2.2k
D147
1SV308 F
R483
47k
C837
100p
C838
100p
Q550
FH102A-E
1
2
3
4
5
6
R485
4.7k
C839
0.001
C840
0.001
R488
330
C842
0.001
C843
8p
C841
18p
Q551
UPA805T
1
2
3
4
5
6
R490
4.7k
L122
47nH
C844
0.001
C845
8p
C846
0.001
C847
0.001
R491
330
R492
150
R493
150
C849
100p
C850
100p
R484
22k
R489
22k
C851
27p
C852
27p
C853
15p
C854
9p
C855
47p
C856
7p
C857
100p
C858
12p
C859
0.001
Q552
UNR9113G0
R495 4.7k
R496
4.7k
C860
0.001 C861
0.001
R494
4.7k
D152 MA2S7280G
D153 MA2S7280G
D154 MA2S7280G
D155
MA2S7280G
IC18
µPC2746TB
1IN
2GND
3GND 4
OUT 5
GND 6
VCC
C864
0.1
C865
0.001
R500
82
C866
0.001
IC19
µPC2746TB
1IN
2GND
3GND 4
OUT 5
GND 6
VCC
C664
0.1
R501
4.7k
D156
MA2S7280G
D157 MA2S7280G
D158 MA2S7280G
D159 MA2S7280G
D160 MA2S7280G D161 MA2S7280G
D162 MA2S7280G
D163
MA2S7280G
D164
MA2S7280G
D166 MA2S7280G
D167 MA2S7280G
D168 MA2S7280G
C868
0.001
R335
100k
C673
0.001
C676
22p
D169
MA2S7280G
D170
MA2S7280G
C872
0.1
CP3
ANTENNA
0.1500 – 3304.9999 MHz
IC1
µPC2757TB
1RFI
2GND
3LO 4
PS
5
VCC
6
IFO
FI1 EFCH266MKQP1
I
IC10
µPC2757TB
1RFI
2GND
3LO 4
PS
5
VCC
6
IFO
Q510
UMD6
1
2
34
5
6
D1
HVC350B-E
D2
HVC350B-E
D4
HVC350B-E
D5
HVC350B-E
D141
HVC350B-E
D142
HVC350B-E
D145
HVC350B-E
D146
HVC350B-E
D3
1SV308 F
D11
1SV308 F
D13
1SV308 F
D25
1SV308 F
D29
1SV308 F
D32
1SV308 F
D34 1SV308 F
D36
1SV308 F
D72
1SV308 F
D73
1SV308 F
D74
1SV308 F
D75
1SV308 F
D76
MA2S077G0
C666
390p
D148
MA2S7280G
D149
MA2S7280G
D150
MA2S7280G
D151
MA2S7280G
L121
0.18µH
L28
68nH L1
47nH
L119
68nH
L120
47nH
L128
0.1µH
R234
820
R233
820
R232
3.3k
D173
HVC375B-E
D174
HVC375B-E
L129
3.9nH
L130
3.9nH
C145
0.001
L131
3.9nH L132
3.9nH
C886
0.001
C887 0.001
D175
HVC375B-E
D176
HVC375B-E
R522
100k
R523
100k R524
100k
Q24
2SC5008
C45
470p
C51
2.5p
C848
3p
C888
0.001
R469
68k
Q548
2SC5006
R14
68k
Q35
2SC5006
Q36
2SC5006
L3
15nH
L133
56nH
L90
100µH
C513
100p
C511
36p C514
180p
C512
10p C515
120p
C519
0.0047
C517
100p C518
220p
C520
0.0018
L84
0.68µH
D65
1SV308 F
L86
0.68µH
L87
1µH
C527
47p C528
10p
C530
270p
C531
100p
C533
0.0015
C534
100p C535
0.0012
C657
150p C658
390p
L88
5.6µH
L89
10µH
D66
1SV308 F
D64
1SV308 F
D70
1SV308 F
D67
1SV308 F
C891
0.01
C522
0.0015
C525
0.0047 C526
0.012
L126
18nH
L127
18nH
L123
47nH
Q507
2SC5008
Q14
2SC5006
Q549
2SC5006
L124
56nH
L125
47nH
R327
100
R235
1k
R225 1k
D69
1SV308 F
R9
120k
R476
120k
C895
470p
Q505
2SC4226
C897
0.001
C898
0.001
C899
0.001
C900
0.001
C901
0.001
R323 220
R497 220
R324
100
R325
82
R326
82
R498
100
R499
82
R531
100k
R486
100
R487
100
Q26
2SC5624-E
R20
330
C46
3p
R533
10
C910
100
R241
2.2k
D178
1SS400
CP18
R539
15
R540
15
C921
0.001
L43
1.5nH
Q504
XP1110
1
2
34
5
Q506
UNR9110G0
C541
0.1
C542
0.1
D68
1SV172
B1C
HFC
B2C
ANTSW
ANTSWANTSW
A_TRAC
A_TRAC
A_TRAC
A_TRACA_TRACA_TRACA_TRAC
A_R3V
B_TRAC B_TRAC
B_TRAC
A_R3V
A_R3V
V3R_AV3R_A
B_G3VB_G3VB_G3V
B_UHF3VB_UHF3V
B_TRAC
A_UHF3V
A_UHF3VA_UHF3V
A_TRAC
B_ATTC
B_ATTC
B_ATTC
B_ATTC
B_ATTC
B_ATTC
A_R3V
B_R3V
B_R3V
B_R3V B_R3V
300M3V
A_ATTC
A_ATTCA_ATTCA_ATTC A_ATTC
A_ATTC
A_ATTC A_ATTC
A_ATTC
ANTSW
B_R3V
B_800M3VB_800M3V
B_800M3V
B_800M3V
CART_BCART_BB_TRAC
A_VHF3V
ATT
B3C
B_VHF3V
B_R3V
B_RXV
EAREAREAR
EAR
C_VCO OUT
A_VCO OUT
B BAND RF IN
B_VCO OUT B_VCO OUT
C919
0.001
D_VCO OUT
D_VCO OUT
A-BAND VHF
B-BAND VHF
A-BAND UHF
B BAND UHF
B BAND 800M
30 – 300 MHz
B_BAND 1G
UHF PRE-AMP
VHF PRE-AMP
ANTSW
ANTSW
ANTSW
EAR
ANTSW
B BAND RF AMP
A BAND RF AMP
HF H
HF L
MF
O
C567
0.1
R243
100k
CP5
CP6
CP7
D100
SVC389
CP8
R247
2.7
C912
0.1
R538
JPW
R246
220k
W1 W2
RDS2T0R0
RDS2T0R0
EP2
BAR ANTENNA
0.4950 – 1.6200 MHz
1
B
2
W
3
R
4
G
blue
white
red
green
C505 0.001
C504 0.001
C503 0.001
Q501
UNR9113G0
C862 0.001
C863 0.001
Q502
XP1113 1
2
3
4
5
Q503
XP1113 1
2
3
4
5
Q554
XP1113
1
2
3
4
5
A_UHF3V
A_VHF3V
B_G3V
B_800M3V
A_UHFC
B_GC
B_800MC
B_VHFC
B_UHFC
A
B_VHF3V
B_VHF3V
B_UHF3V
B_UHF3VB_UHF3V
300M3V
A_VHFC
A_300MC
A_R3V
B_R3V
O
R329
100k
Q513
XP4601
123
45 6
R330
15k
C669
0.001
A_TRAC
VP
VP
B
Explanatory notes
VOLTAGE LINE
RX LINE
IF_OUT
J10
R510
2.2k
C923
10p
C924
10p
C923* – C925*
C925
10p
CSOCSO
RFIN
GND
PLLESTB
PLLDATA
PLLCK
PLLESTB
PLLDATA
PLLCK
J11
1
12
23
34
45
56
6
DOWN_CONV
2GLO
1GLO
+3V
to DOWNCONV
BOARD J1
to DOWNCONV
BOARD J2
R534
2.7
C911
100
+3S
DOWN
CONV
BOARD
R511
2.2k
RFIN

Jan. 2010
17
*: Refer to the PARTS LIST for the value and name of component.
RF UNIT (2/2)
2.9V
WFM
433 MHz
1.5V
3.0V
433 MHz
2.9V
NB-ON
1.0V
NB-ON
2.9V
CW
1.8V
1.6V
3.0V
C713
0.1
2.9V
WFM
2.6V
CW
3.0V
145 MHz
2.9V
CW
+3V
J1
1STAVCO
BOARD
2NDCVCO
BOARD
2NDDVCO
BOARD
1STBVCO
BOARD
LOGIC
UNIT
IFO16
B_R3V
AGC
ATT
IFO10
A_R3V
A-AGC
ANTSW
B_TRAC
A_ATTC
R208
10k
C264
0.001
R57
15k
C102
0.001
C427
22p
C63
150p
C65
0.01
R34
1k
C96
0.01
C203
0.1
C100
0.1
R29
470k
R159
1k
R59
1.5k
C221
0.01
R56
470 R31
1k
R68
47k
C95
0.001
L17
3.3µH
C18
0.01
C200
0.01
C103
0.01
R103
10k
R61
47k
C92
0.01
C62
10
R60
100k
C74
0.001
C434
0.1
R116
150k
C94
0.001
C97
0.01
R49
10k
C433
0.001
R28
1M
C242
0.22
C75
0.001
Q1 XP6501
1
2
3
456
R58
680
C101
10p
C259
100p
C430
0.01
Q4
XP6501
123
56
1
23
45 6
L73
2.7µH
R205
10k
C64
15p
C201
0.1
C239
0.01
R54
22k
C241
0.22
R207
10k
C73
0.001
R50
10k
C61
0.001
R26
47k
C659
10
C66
0.01
C60
0.01
C202
0.1
R177
100k
R35
15k
C431
0.001
C93
0.001
D106
1SS400
D107
1SS400
L99
470µH
R46
4.7k
D108
1SS400
D109
1SS400
D110
1SS400
D111
1SS400
D112
1SS400
D113
1SS400
C688
0.01
Q519
UNR9113G0
C689
0.01
C690
0.01
C691
0.01
C692
0.01
Q521
2SC4617
Q522
2SC4617
Q523
2SC4617 Q524
2SC4617
C694
0.1
R352
100k
R353
47k
R354
27k
R355
1.5k
R356
270
C697
0.01
R357
330k
C698
0.01
R358
1.5k
C700
0.01
R361
150k
R362
150k R363
4.7k
C701
0.01
R365
22k
R366
100k
R367
220k C702
0.1
C703
0.47
R369
330
Q526
UNR9113G0
C705
0.1
R347
10k
R346
10k
R172
10k
R370
10k
Q527
UNR9113G0
R372
100k
C706
0.001
R374
10k
R375
10k
R376
22k
C708
0.22 Q529
UNR9213G0
C709
0.1
R377
4.7k
R378
100k
Q530
2SC4617
Q531
2SC4617
C711
0.1
C712
0.1
C714
0.01
C715
0.01 C716
470p
R390
27k
R391
10k
C718
0.01
R392
47k
C719
0.001
Q532
2SK1069-4-TL-E
R396
22k
R397
100k
R398
100k
D121 DAP222
D119
DAP222
D117
DAP222
C740
0.01
C744
0.01
FI3 FL-293
19.650 MHz
1
3
C758
0.001
R432
15k
L104
3.3µH
C759
0.001
R433
1k
C760
0.001
C761
0.001
IC17
TA31136FNG
1
OSCIN
2
OSCOUT 3
MIXOUT 4
VCC 5
IFIN 6
DEC 7
FILOUT 8
FILIN
9AFOUT
10 QUAD
11 IFOUT
12 RSSI
13 N-DET
14 N-REC
15 GND
16 MIXIN
R435
47k
C764
0.001
R437
22k
L105
LS-510-LF
C765
10p
C766
0.01
R438
100k
C768
470p C769
470p
R439
1.5k
R440
47k
C770
0.01
R441
680
R442
15k
C771
0.01
C772
0.001
R443
470
C773
0.1
R444
1k
C774
0.01
C775
10
C776
0.22
D134
1SS400
D135
1SS400
R445
10k
C777
0.01
FI8
CFWM450E
IO
C778
0.01
R446
10k
D136
1SS400
D137
1SS400
C779
0.01
C780
0.1
R447
220
R448
2.2k C781
220p C782
220p R449
2.2k
L106
470µH C783
0.1
C784
0.01
R450
10k
C785
15p
R452
150k
Q544
XP6501
123
456
Q545
XP6501
123
456
C786
150p R454
100k
R455
1k C788
0.01
R457
47k
R458
1M
R459
470k
C789
0.001
C791
10
C792
0.01
R461
10k
C762
100p
Q546
XP4312
1
2
3
456
C793
0.01
R463
10k
R464
10k
R465
22k
C795
0.1
R466
4.7k
C796
0.22
Q547
UNR9213G0
R467
100k
C752
22p
R430
10k
C754
0.001
C756
0.1
R429
10k
R428
10k
D131
MA2S077G0
C753
22p
L102
2.7µH
D133
MA2S077G0
FI7 FL-293
19.650 MHz
1
34 D132
MA2S077G0
D130
MA2S077G0
C757
0.1
D115
RB876W
D116
RB876W
C867
0.01
D165
MA2S7280G
C741
0.01
C869
0.01
C870
0.01
C871
0.01
CP1
CP2
FI2
CFWM450E
I
Q44
XP4312
X1 CR-593A
19.200 MHz
Q556
2SC4617
C877
0.01
R513
220k
R514
2.2k
D171
HVC350B-E
R515
100k
C878
0.01
R516
100k
C879
10p
C424
0.01
R517
1k
R518
1k
D58
MA2S077G0
D59
MA2S077G0
D60
MA2S077G0
D61
MA2S077G0
IC2
TA31136FNG
1
OSCIN 2
OSCOUT 3
MIXOUT 4
VCC 5
IFIN 6
DEC 7
FILOUT 8
FILIN
9AFOUT
10 QUAD
11 IFOUT
12 RSSI
13 N-DET
14 N-REC
15 GND
16 MIXIN
Q534
XP1113
1
2
34
5
Q535
XP1113
1
2
3
4
5
Q553
XP1113
1
2
34
5
C98
470p C99
470p
D172
MA2S7280G
C880
0.001
C767
0.22
D138
MA2S7280G
D57
MA2S7280G
R519
4.7k
C881
0.001
L21
LS-510-LF
Q525
XP6501
1
2
3
456
C882
0.001
C884
0.001
C885
0.001
C873
220p
C874
18p
R203
100
R204
1k
R209
680
R36
220k
R427
100
R425
1k R426
680
R431
220k
R525
10 R526
10
R527
10
C889
0.1
R373
3.9k
C707
0.001
C710
0.001
D114
MA2S7280G
R30
3.3k
R179
150k
R394
27k
R393
22k
C717
0.1
C720
0.01
C890
0.1
R462
3.9k
C794
0.001
C797
0.001
D139
MA2S7280G
R451
3.3k
R453
150k
C790
0.01
Q5
2SC5006
Q542
2SC5006
FI6
CFWS450K3
I
R359 220k
R360
2.2k
C704
0.01
Q528
2SC5006
C893
0.01
R529
470
R530
4.7k
C894
0.01
CP11
CP12
IC22
CD4094BPWR
1STR
2D
3CLK
4Q1
5Q2
6Q3
7Q4
8GND 9
QS
10
Q’S
11
Q8
12
Q7
13
Q6
14
Q5
15
OE
16
V+
IC12
CD4066BPWR
1I/O1
2O/I1
3O/I2
4I/O2
5CONT2
6CONT3
7VSS 8
I/O3
9
O/I3
10
O/I4
11
I/O4
12
CONT4
13
CONT1
14
VDD
IC21
CD4066BPWR
1I/O1
2O/I1
3O/I2
4I/O2
5CONT2
6CONT3
7VSS 8
I/O3
9
O/I3
10
O/I4
11
I/O4
12
CONT4
13
CONT1
14
VDD
C896
0.01
IC14
M62366GP
1VSS
2AO3
3AO4
4AO5
5AO6
6AO7
7AO8
8AO9
9AO10
10 VDD 11
VCC
12
AO11
13
AO12
14
DO
15
LD
16
CLK
17
DI
18
AO1
19
AO2
20
GND
IC20 M62366GP
1VSS
2AO3
3AO4
4AO5
5AO6
6AO7
7AO8
8AO9
9AO10
10 VDD 11
VCC
12
AO11
13
AO12
14
DO
15
LD
16
CLK
17
DI
18
AO1
19
AO2
20
GND
R520
47
R521
47
R62
180
R434
180
R379
1.5M R380
2.7k
R381
330 R382
1.5k
R383
1.5k
R384
47k
R385
100k
R386
2.2k
R387
2.2k
R388
2.2k
R389
2.2k
R415
1.5M R414
12k
Q540
2SC5006
R503
1.5M
R505
12k
Q555
2SC5006
R55
2.2k
R436
2.2k
Q543
UNR9113G0
Q41
UNR9113G0
R528
2.2k
R536
56 C745
470p
R537
56
C755
470p
L134
4.7µH
R512
3.9k
C875
68p
C876
56p
C699
220p
R364
56k
R368
15k
C686
390p C687
390p
R542
15k
R174
4.7k
C922
150p
SSBC
SSBC
A_WFMC
A_ANLC
A_RSSI
A_R3V
A_DETSSB
A_DETSSB
A_DETAM
A_DETAM
A_DETFM
SSB3V
SSB3VSSB3VSSB3V
SSB3V SSB3V
SSB3V SSB3V
SSB3V
SSB3V
SSB3V
A_DET
A_R3V
A_R3V
A_WFMC
A_R3V
A_AMC
A_AMC
A_WFMC
A_WFMC
A_NFMC
A_NFMC
A_AMC
A_AMC
SSBC
BFO
A_AMC
SSBC
CLK
D
LD1
NBC
A_R3V
B_RSSI
B_NOISE
B_RSSI
B_RSSI
B_NOISE
B_NOISE
B_R3V
B_R3V
B_R3V
B_R3VB_R3V
B_R3V
B_R3VB_R3V
B_R3V
B_R3V
B_R3V
B_R3V
B_WFMC
B_AM FM
CLK
LD2
B_AMC
B_AM FM
A_ANLC
B_ATTC
B_WFMC
A_TRAC
A_NFMC
A_300MC
A_VHFC
A_UHFC
A_ATTC
B_UHFC
B_GC B_800MC B_VHFC
B_TRAC
ATT
ATTATTATT
B_ANLC
B_DET
B_R3V
V3R_AV3R_A
A_NOISE
B_WFMC
B_WFMC
+3S
STR2
D
D
D
D
CLK
DOWN_CONV
2GLO 1GLO
ANTSWANTSW
BPS
NBC
A_VCO3
B_AMC
B_ANLC
A_WFMC
APS
B_VCO1
A_R3V
A_R3VA_R3V A_R3V
A_R3VA_R3V
A_R3V
A_R3V
A_R3V
A_R3V
A_R3V A_R3V
A_R3V
3rd_Lo
DET_OUT
AGC
AGCAGC
AGC
CGACGA
ANL_CONT
AM_DET
WFM_CONT
AM/NFM CONT AM/NFM CONT
AM/NFM_CONT
WFM CONT
WFM_CONT
AM MODE
WFM_CONT
WFM_CONTWFM_CONT
19.200 MHz
+3S
+3S
+3S +3S
+3S
+3S
+3S
FSET
OSC
C402
0.001
HJ2
GND
GND
1
2
3
4
5
6
7
8
HJ3
11
22
33
44
55
66
7
7
HJ8
11
22
33
44
55
66
HJ4
11
22
33
44
55
66
HJ5
11
22
33
44
55
HJ9
11
22
33
44
55
to LOGIC unit J5
C906
47p
C907
47p
C908
47p
R532
10
C909
100
D179 1SS400
C913
0.001
C914
0.001
C916
0.001
C917
0.001
B_R3V
PLLDSTB
PLLDATA
PLLCK
PLLCK PLLCK
PLLDSTB
A_R3V A_R3V
PLLCSTB
PLLDATA
+3V
OSC
GND
PLLCK
+3V
OSC
GND
BTSALLPBTSALLP
GND
ATADLLPATADLLP
BPS
GND
GND
APS APS
GND
GND
A_VCO2
A_VCO3
A_R3V
A_VCO1
OSC OSC
+3V
+3V +3V
A_VCO2
A_VCO3
A_VCO1
+3V
+3V
APS
PVPV
B_RXV B_RXV
C_VCO OUT C_VCO OUT
TUOOCV_ATUOOCV_A
B_VCO OUT
B_VCO OUT
HJ6
to 1STBVCO BOARD
J2
to 2NDDVCO BOARD
J2
to 2NDDVCO BOARD
J1
to 1STBVCO BOARD
J1
to 1STAVCO BOARD
J2
to 2NDCVCO BOARD
J2
to 2NDCVCO BOARD
J1
to 1STAVCO BOARD
J1
1
2
3
4
5
6
7
8
C902
47p
C903
47p
C904
47p
C905
47p
C918
0.001
R541
150
B_VCO1
B_VCO1
B_VCO2
B_VCO3
B_VCO4
B_VCO2
B_VCO3
B_VCO4
+3V
+3V
+3V
D_VCO OUT
D_VCO OUT
A_VCO2
A_RSSI
A_VCO1
BFO
PLLCSTB
PLLESTB
PLLBSTB
VP
PLLASTB
A_R3V
B_R3V
B_R3V
+3V
B_R3V
+3V
B_R3V
B_NOISE
B_NOISE
B_RSSI
B_RSSI
A_DET
B_DET
D
D
A_NOISE
+3S
+3S
+3S
EAR
LD1
LD1
CLK
CLK
B3C
B2C
B1C
HFC
A_VCO2
A_RSSI
A_VCO1
BFO
PLLESTB
A_DET
B_DET
A_NOISE
EAR
B3C
B2C
B1C
HFC
STR2
STR2
PLLDATA
PLLCK
B_VCO4
B_VCO2
B_VCO3
LD2
LD2
21
1
22
2
23
3
24
4
25
5
26
6
27
7
28
8
29
9
30
10
31 11
32
12
33
13
34
14
35
15
36
16
37
17
38
18
39
40
19
20
HJ7
11
22
33
44
55
66
7
7
C920
0.001
VP
GND
VP
PLLCK
PLLBSTB PLLBSTB
PLLDATA
CSOCSO
BPS BPS
B_GC
B_800MC
B_VHFC
A
B_UHFC
O
O
4
2
2
OSC
OSC
OSC
CSOCSO
A_DETFM
B
Explanatory notes
VOLTAGE LINE
RX LINE

Jan. 2010
18
*: Refer to the PARTS LIST for the value and name of component.
C177
0.001
D36
MA133
C88
0.001
R26 1k
C152
1
Q26
2SJ144 Y F
R31 47k
Q31
HAT1023R
5D
6D
7D
8D1
S2
S3
S4
G
C106
33
Q8
2SA1588 GR F IC5
TA31056FG
1
IN 2
VREF 3
NF 4
COMP
5GND
6OUT
7TB
8VCC
C1
0.1
Q25
XP6501
1
2
34
5 6
C114
0.001
R56
4.7k
C178
0.001
IC9
R1111N321B F
1
VDD 2
GND 3
CE
4NC
5VOUT
Q33
2SB1132
C113
0.1
C62
4.7
C37
47p
C40
33
C68
0.001
C124
0.1
C111
0.1
R142
15k
C97
0.1
R94
47k
C39
0.1
C183
0.0047
C69
0.001
IC11
TC7W04FU F
1
2
3
45
6
7
8
EP8
C45
0.1
C42
100p
R4 10k
D29
SB07-03C E
EP6
AFOUT
AFOUT
AFOUT
AFOUT
AFOUT
AFOUT
AFOUT
AFOUT
GND
C120
0.1
C33
0.001
C93
0.001
C173
0.001
R8
47k
R7
10k
C172
0.1
C61
0.001
C116
0.1
C7
0.01
D35
MA2S7280G
C44
4.7
Q14
2SA1588 GR F
C109
0.1
C141
0.001
R129
180k
Q7
XP1501
123
5
C34
220
Q17
2SA1588 GR F
R98
33k
C158
0.1
EP10
C43
4.7
R121
10
C89
0.001
C104
0.1
R127
470k
Q13
XP6501
1
2
34
5
6
R64
470
EP9
C182
0.001
C51
0.001
C16
0.001
C125
0.1
C102
0.1
IC8
R1111N321B F
1
VDD 2
GND 3
CE
4NC
5VOUT
R164
1M
C31
0.47
R74
47k
R137
100k
R136
82k
D22
1SS372 F
R54
10k
C24
0.001
Q9
2SB1132
R150 150k
R151
39k
R166
39k
C151
0.001
C154
0.1
C142
100p
C100
0.022
C94
0.0022
R168
100k
C160
330p
C131
1C135
1
C143
1
C149
1
C126
1
C132
1
C138
1
C144
1
C162
0.1
Q28
2SC4617
C118
1
D21
1SS400
R147
2.2M
Q23
2SC4617
R11
1k
R24 1k
C91
0.001
R126
470k
R148 150k
R149 39k
R165
39k
C99
0.022
C92
0.0022 C108
0.1
C139
0.001
C140
100p C150
0.001
C153
0.1
C87
0.001
C170
0.1
C156
0.1
R163
1M
Q24
XP6501
1
2
34
5 6
R141
15k
C119
0.1
C117
1
C115
0.1
R118
10
C101
0.1
C112
0.1
C103
0.1
Q22
2SC4617
R128
180k
D20
1SS400
R134
82k
C122
0.1
C123
0.1
C110
0.1
Q27
2SJ144 Y F
R154
2.2M
C84
0.0047
C95
0.1
C86
0.1
Q19
2SJ144 Y F
R114
2.2M
R117
1M
C96
0.1
R169
100k
C161
330p
Q30
2SB1201 S-TL-E
R185
12
R186
12
Q35
UNR9213G0
R189
1k
D28
MA2S1110G
C176
0.1
R157
82k
R139
82k
R162
82k
R140
82k
R143
470k
R144
470k
R115
12k
R116
12k
R113
120k
R112
120k
C127
470p
C128
470p
C145
0.015
C146
0.015
R131
820k
R133
820k
R70_JPW
R57 JPW
R71_JPW
S3
S2
S18
S9 S14 S20
S4 S10
S8
S15
S13
S21
S1
S7
S19
CP3
CP4
J6
IC3*
1P94/DA1/TB4IN 2P93/DA0/TB3IN 3P92/TB2IN/SOUT3
4P91/TB1IN/SIN3 5P90/TB0IN/CLK3 6BYTE 7CNVSS 8P87/XCIN
9P86/XCOUT
10 RESET 11 XOUT 12 VSS 13 XIN
14 VCC
15 P85/NMI 16 P84/INT2 17 P83/INT1 18 P82/INT0
19 P81/TA4IN/U
20 P80/TA4OUT/U 21 P77/TA3IN 22 P76/TA3OUT 23 P75/TA2IN/W
24 P74/TA2OUT/W
25
P73/CTS2/RTS2
26
P72/clk2/TA1OUT
27
P71/RXD2/SCL
28
P70/TXD2/SDA
29
P67/TXD1
30
P66/RXD1
31
P65/CLK1
32
P64/CTS1/RTS1
33
P63/TXD0
34
P62/RXD0
35
P61/CLK0
36
P60/CTS0/RTS0
37
P57/RDY/CLKOUT
38
P56/ALE
39
P55/HOLD
40
P54/HLDA
41
P53/BCLK
42
P52/RD
43
P51/WRH/BHE
44
P50/WRL/WR
45
P47/CS3
46
P46/CS2
47
P45/CS1
48
P44/CS0
49
P43/A19
50
P42/A18
51
P41/A17
52
P40/A16
53
P37/A15
54
P36/A14
55
P35/A13
56
P34/A12
57
P33/A11
58
P32/A10
59
P31/A9
60
VCC
61
P30/A8(/-/D7)
62
VSS
63
P27/A7(/D7/D6)
64
P26/A6(/D6/D5)
65
P25/A5(/D/D4)
66
P24/A4(/D4/D3)
67
P23/A3(/D3/D2)
68
P22/A2(/D2/D1)
69
P21/A1(/D1/D0)
70
P20/A0(/D0/-)
71
P17/D15/INT5
72
P16/D14/INT4
73
P15/D13/INT3
74
P14/D12
75
P13/D11
76 P12/D10
77 P11/D9
78 P10/D8
79 P07/D7
80 P06/D6
81 P05/D5
82 P04/D4
83 P03/D3
84 P02/D2
85 P01/D1
86 P00/D0
87 P107/AN7/KI3
88 P106/AN6/KI2
89 P105/AN5/KI1
90 P104/AN4/KI0
91 P103/AN3
92 P102/AN2
93 P101/AN1
94 AVSS
95 P100/AN0
96 VREF
97 AVCC
98
P97/ADTRG/SIN4
99
P96/ANEX1/SOUT4
100
P95/ANEX0/CLK4
S5 S11 S16 S22
S6 S12 S17 S23
D12
1SS400
D9
1SS400
D6
1SS400
D3
1SS400
R10
10k
R9
47k
IC1
CAT24C256XI
1A0
2A1
3NC
4VSS 5
SDA
6
SCL
7
WP
8
VCC
C2 0.001 C3 0.001 C4 0.001
C5 0.001
C6 0.001 C8 0.001
C9 0.001
C10 0.001 C11 0.001 C12 0.001 C14 0.001
R35 1k
R42 1k
R51 1k
R61 150k R60 150k
R59 150k
R58 150k
C13
0.1
C23
0.1
D23
1SS372 F
D24
1SS372 F
D25
1SS372 F
R22 JPW
R77 1k
R72_JPW
R73_JPW
EP7
C36
82p
R66 1k
R68 1k
R19
82
DS2
Q1
2SC4617
DS3
R23
82
DS4
R14
82
DS1
R29
82 R49
82
R53
82
R55
82
Q4
2SC4617
DS5
DS1–DS9_SML-512UW
DS6 DS7
R38
82
DS8
C26
0.001
Q5
2SC4617
R33
100k
R192
180k
R193
100k
C175
0.1
R36 4.7k
D33
MA8027GH
Q29
UNR9213G0
D32
MA2S1110G
R180
47k
C180
0.001
R191
100k
C174
0.1
R190
47k
C54
0.1
R96
1M
R85
100
C73
0.01
C53
0.01
C74
470p
C50
0.1
Q11
UNR9113G0
SVC389 SVC389
C49
0.1
R84
10k
R91
5.6k
C47
0.1
Q12
2SC4617
C46
1
R101
5.6k
C58
0.1
C60
0.1
Q16
2SC4617
C57
1
R95
10k
IC7
SM6451B
1RSTN
2ADRS1
3ADRS2
4DVDD
5LOUT
6LIN
7AVDD
8VRL 9
VRR
10
AVSS
11
RIN
12
ROUT
13
DVSS
14
MLEN
15
MCK
16
MDT
C55
0.001
R90
4.7k
C52
0.001
C48
0.001
R100
ERJ2GE-JPW
C64
0.001
C63
0.001
C59
0.001
C85
0.1
X1
CR-717
R27
10 R28
1M
C22
15p
C27
0.01
R82
47k
R76
47k
R67 1k
R83
47k
R43 15k
IC4
TC7W04FU F
1
2
3
45
6
7
8
R40
10k
R34
10k
R41
12k
R15
100k D13
1SS400
Q3
2SA1586 GR F
Q6
2SC4116 GR F
R20
100k
R39
10k
D31
1SS400
D30
1SS400
D26
1SS400
D27
1SS400
C41
0.1
IC2
BD5228G
1OUT
2VDD
3VSS 4
NC
5
CD
J3
J8
1
2
3
C171
0.01
R178
390k
C167
0.0022
R172
2.2M
C157
470p
C148
680p
R161
470k
R160
2.2M
R156
180k
R146
100k
C134
820p
C137
270p
R155
180k
R125
470k
C168
0.0018
R175
100k
C164
330p
C169
0.01
R176
390k
C165
0.0022
R170
2.2M
C155
470p
C147
680p
R159
470k
R158
2.2M
R153
180k
R145
100k
C133
820p
C136
270p
R152
180k
R124
470k
C166
0.0018
R174
100k
C163
330p
R135
100k
S26
CP5
CP6
CP1
CP2
Q36_2SC4617
R198
100k
C185
0.001
Q37
2SA1588 GR F
C186
0.001
C187
0.001
C188
0.001
DS9
R202
82
R32
1k
R12
1k
C38
3.3
C70
10
C80
10
C82
22
C83
22 C159
4.7
1
2
3
4
5
6
7
8
9
C107
10
C105
4.7
C98
4.7
C90
4.7
C29
0.1
R203
82 R204
82 R205
82
R206
82
R30
1k
R89
470k
R99
470k
R201
470k
R200
8.2k
R104
470k
R105
6.8k
R86
100k
R88
2.2k C77
0.001
IC6
TC7SU04F F
11
22
334
5
C189
0.001
DS11
SML-512UW
R199
220
R111
JPW
C190
0.1
Q10
2SA1362 GR F Q15
2SA1362 GR F
Q38
XP4601
123
45
6
R207
100k
R208
100k
R122
10k
R103
33k
R179
180k
R177
180k
R87
39k
IC14
TC7S08FU F
1
2
34
5
IC15
TC7S08FU F
1
2
34
5
R209
100k
C191
0.1
R2_10k
R3_10k
R5_10k
R6_10k
R17 10k
R18 10k
R63
10k
X2
CSBFB453K
EP12_CV1081
Q32
2SC4617
R183
1k
IC12
LM2904PWR
1
2
3
45
6
7
8
IC13
LM2904PWR
1
2
3
45
6
7
8
R182
1.2k
R187
1k
R188
150
R210
100k
R106
JPW
R213
JPW
R214
JPW D34
SB07-03C E
R216
JPW
R215
JPW
Q20
UNR9115G0
C30
1C35
1
R1
3.3k
R21 3.3k
R25 3.3k
R123
820
R120
820
R107
1M R108
470k
D14
HVC376B-E
C28
470p
R52
100k
R62
100k
L1
10µH C194
1
R167
10k
R110
82k
R119
12k
R69 10k
R211
470
R212
470
R217
100k
R194
100k
R195
180k
R181
68
R184
82
R196
6.8
R197
6.8
Q34 UNR9215G0
R93
1M
R97
1M
C56
0.01 C65
0.01
R130
180k
R132
180k
EP13
MZA2010D121C
Q21
UNR9115G0
R45
10
D8*
D5*
D2* D11*
C196
0.1
R47_2.2M
MP5
A_VSCAF
CHGS
A_VCO2
LD2
B_VCO2
B_RSSI
B_VCO3
B_VCO4
ECK
ESIO
PLLDSTB
PLLCK
PLLESTB PLLCSTB PLLASTB
KR1
KR4
KR5
KR0 KR1
KR2
KR3
KS0 KS1
KS2
KS3
KS3
KS2
KS1
KS0
KR5
KR3
KR2
KR0
A_RTONE
B_VSCAF
B_RTONE
B_CTONE
A_CTONE
BUSY SCLK
A_NOISE
B_NOISE
B_AF_THURUB_AF_THURU
A_RTONE
B_CTONE
TEMP
BATTIN
HVIN
HVDET
TEMP
B_AMUTEB_AMUTE
CNVSS
BEEPBEEP
BEEP
BFO_SHIFT
BUSY
SCLK
RXD
TXD
RESET
CNVSS
BUSY
SCLK
RXD
TXD
RESET
CNVSS
HVDET
BFOC
BFO
CKO
CKO
+3SC
CK
DATA
CK
AFON
A_CTONE
D
CLK
D
CLK
RESET
RESET
A_TCON
B_TCON
B_RTONE
EAR
A_AINA_AIN
A_AIN
B_AINB_AIN
AOUTAOUT
B_R3C
A_R3C
VRSTB
+3SC
LIGHT
B3C
I1
I0 I1
BTSRVBTSRV
B_TCON
KR4
VOL_UP_DOWN
CK
DATA
DATA
DATA
DATA
POWER
CIV_IN CIV_OUT
CPU3V
CPU3V
CPU3V
CPU3V
CPU3V
CPU3VCPU3V
CPU3V
CPU3V CPU3V
HVIN
BATTIN
CPU3V
CPU3V
CPU3V
CHGC
CIV_IN
A_RSSI
REC
C81 1
C79 1
C78 1
C76 1
C75 1
C184 1
C71 1
C67 1
C66 1
C72 1
J9
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 25
24
LCD_CS
LCD_RESET
LCD_RS
CK
DATA
PCON
LIGHT
LIGHT
LIGHT
A_VCO1
PLLBSTB
SQL
A_AF_THURU
B_AMUTE
AFON
CIV_OUT
CIV_IN
SUB_3C
RXD
RXD
TXD
TXD
B_DCK
A_DUD
A_DCK
B_DUD
A_VCO1
REC
CHGS
CHGC
LD1
B2C
B1C
HFC
PLLDATA
STR2
PCON
B_AF_THURU
A_R3C
A_TCON
LCD_CS
BFOC
B_R3C
LCD_RESET
LCD_RS
A_VCO2
A_AF_THURU
A_AF_THURU
A_VSCAF
A_RSSI
B_VSCAF
CPU3V CPU3V
CPU3V
A_R3V
+3S
+3S
VPVP
BFO_SHIFT
DATAC
KCKC
DATA
D
CLK
DATAC
CLS1
POWER
CLS0
+3V
+3V
+3V
+3V +3V
VCC
VCC
A_DET
A_R3V
A_R3VA_R3V
B_DET
B_R3V
B_DET
A_DET
B_DET
A_DET
B_TCON
B_RTONE
A_R3V
A_TCON
A_RTONE
B_R3V
BFO
PLLCSTB
PLLESTB
PLLBSTB
VP
PLLASTB
A_R3V
B_R3V
B_NOISE
B_RSSI
+3V
A_DET
B_DET
D
A_NOISE
+3S
EAR
LD1
CLK
B3C
B2C
B1C
HFC
STR2
PLLDATA
PLLCK
B_VCO4
B_VCO2
B_VCO3
LD2
A_VCO2
A_RSSI
CK
DATA
CK
DATA
CK
DATA
CK
DATA
A_VCO1
BFO
PLLCSTB
PLLESTB
PLLBSTB
VP
PLLASTB
A_R3V
B_R3V
B_NOISE
B_RSSI
+3V
A_DET
B_DET
D
A_NOISE
+3S
EAR
LD1
CLK
B3C
B2C
B1C
HFC
STR2
PLLDATA
PLLCK
B_VCO4
B_VCO2
B_VCO3
LD2
C179
0.001
C181
0.001
C192
0.1
B_CTONE
A_CTONE
DW MAIN
1
4
7
<< >> PLAY REC
SCOPE
BAND VFO MODE MR
B3 B2 B1 B0
POWER
EP3
EP4
S25
1
COM
2
A3
B
S24
1
COM
2
A3
B
EP1
EP2
C18
47p
C20
47p
C19
47p
C21
47p
B_DCK
B_DUD
A_DCK
A_DUD
A DIAL
B DIAL
R13
120k (HJ9)
1
2
3
4
5
6
(HJ8)
1
2
3
4
C193
0.1
TXD
A_AIN
B_AIN
AOUT
SQL
SUB_3C
RXD
VOL_UP_DOWN
TXD (CPU_TX)
A_AIN
B_AIN
GND
AOUT
SQL
SUB_3C
+3V
RXD (CPU_RX)
VOL_UP_DOWN to REC
unit
J7
to REC
unit
J6
EXT SP
EXT DC
INT SP
B GND
Li+
Li–
S
REC
J5
21
1
22
2
23
3
24
4
25
5
26
6
27
7
28
8
29
9
30
10
31 11
32
12
33
13
34
14
35
15
36
16
37
17
38
18
39
40
19
20
to RF unit J1
to_LCD
DS12
M3-0243TIY
4
Explanatory notes
VOLTAGE LINE
RX LINE
RECORDING LINE
PLAYBACK LINE
23
56 0
89 .
4
LOGIC UNIT
B_R3V
B_R3V
+3S
+3S
+3S
+3S
+3V
+3V+3V
+3V
+3V +3V +3V
+3V
+3V
B_R3V
Approx. 12V
3.2V
3.6V
3.1V
3.3V_SQL_OPEN
3.1V
3.0V
3.0V
3.0V
3.2V
3.7V
TSQL/DTCS/VSC ON
2.9V
3.0V
3.0V
2.9V
TSQL/DTCS/VSC ON
3.6V
3.2V
3.1V
2.8V
CW/BFO_ON
PLLDSTBPLLDSTB
3.1V
D18
D37

SERVICE MANUAL
ADDENDUM
CONTENTS
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
BOARD LAYOUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 22
Aug. 2009
[VERSION LIST]
Model Version Battery
pack
AC adapter
IC-R20
[EUR]
BP-206
BC-149D
[UK] –
[USA] BC-153SA
[FRA] BC-149D
[SEA] – –
[EXP-01]
BP-206
BC-149A
[EXP-02] BC-149D
[CAN] BC-153SA
[CHN] BC-153SC
