DB-16R 16-channel Relay Output Board - QuickStart (Apr/2017)
ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
1
DB-16R
16-channel Relay Output Board
Quick Start Guide
Product Website:
https://www.icpdas-usa.com/db_16r.html
1. Introduction
The DB-16R, 16-channel Relay Output Board, consists of 16 form c relays
for efficient switch of load by programmed control. It is connector and
functionally compatible with 785 series board but with industrial type
terminal block. TheDB-16R can be connected to DIO-64,A-626, A82x DAS
board and PCI-series multi-function board or any other compatible DAS
board. The relay are energized by apply 5 volt signal to the appropriate
relay channel on the 20-pinflat cable connector. 16 enunciator LEDs, one
for each relay, light when their associated relay is activated. To avoid
overloading your PC’s power supply, this board provides a screw terminal
for external power supply.
2. Features
16-channel relay output board
•16 Form C Relays
•Accept 20-pin connector to control 16 form c relays, for
use with A-82X, A-62X, DIO-64, PCI-1800, PCI-1200, PCI-
1002 series digital output port or any compatible digital
output port.
•LED status indicator
•Screw terminals for field wiring.

DB-16R 16-channel Relay Output Board - QuickStart (Apr/2017)
ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
2
3. Layout
4. Jumper Settings

DB-16R 16-channel Relay Output Board - QuickStart (Apr/2017)
ICP DAS USA, Inc. | www.icpdas-usa.com | 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
3
5. Pin Assignment
