ICT A7 Series User manual

VerticalHorizontal
A7/V7
ie
Ser s
Installation Guide
Bill Acceptor
International Currency Technologies Corp.
2003 International Currency Technologies Corporation
V. 11.0 Part Number : H4459J-R

Contents
Use of Materials Limitations
International Currency Technologies Corporation (ICT) all rights reserved.
All materials contained are the copyrighted property of ICT.
All trademarks, service marks, and trade names are proprietary to ICT.
ICT reserves the right at all times to disclose or to modify any information as
ICT deems necessary to satisfy any applicable law, regulation, legal process
or governmental request, or to edit, refuse to post or to remove any information
or materials, in whole or in part, in ICT's sole discretion.
1. Introduction ..................................................................1
1-1. Overview ...............................................................1
1-2. Features ................................................................1
2. Specifications ...............................................................1
General .........................................................................1
Electrical ......................................................................2
Mechanical ...................................................................2
3. Packing List ..................................................................2
4. Dimension ....................................................................3
5. Installation ....................................................................4
5-1. Harness Application ..............................................4
5-1-1. I/O Circuit .....................................................17
5-2. DIP Switch Setting ..............................................23
5-3. Software Download and Upgrade ......................23
6. Maintenance ..............................................................24
7. Troubleshooting .........................................................25

3. Packing List
A7 / V7 A7 / V7
1-1. Overview
1. Introduction
2. Specifications
96% or greater
Four way bill insertion acceptance.
Numerous interfaces available.
Easily Install & Maintain.
High Acceptance Rate up to 96%.
A7/V7 Series is a bill acceptor which features not only high-security
module with bill box but also outstanding recognition, acceptance
rate up to 96% or even greater.
1-2. Features
Main
Accessory
Bill Acceptor
Harnesses: see 5-1
A7/V7 Installation Guide
A7/V7 DIP Switch Setting Guide
Approx. 3 seconds to stack
Indoor
12V- Standby : 5 W
Operation: 24 W
Maximum: 36 W
Four-way acceptance
See Page.3
Approx. 100 bills ( 80~120)
200 bills (200~300)
400 bills (350~450)
800 bills (750~850)
Standard Pulse, 5V Enable, ICT Protocol,
MDB, GPT Parallel
Approx. 1.25kg
General
Mechanical
Acceptance Rate
Transaction Speed
Installation
Power Consumption
Bill Insertion
Interface
A7: 12V DC (11.4~12.6 V DC)
117V AC (105.3~128.7 V AC)
V7: 12V DC (11.4~12.6 V DC)
24V AC (21.6~26.4 V AC)
34V DC (20V~42.5 V DC)
Power Source
Operation Temperature: 0°C~55°C
Storage Temperature: -30°C~70°C
Humidity: 30%~85RH (no condensation)
Operation Environment
Outline Dimension
Bill Capacity
Weight
Electrical
Note: The incomplete bills such as extremely dirty, wet, broken or wrinkled
ones are excluded.
Bill Acceptor Bill Acceptor
1
www.ictgroup.com.tw 2www.ictgroup.com.tw

tHorizontal
tVertical
4. Dimension
Unit : :mm [inch]
A7 / V7 A7 / V7
Bill Acceptor Bill Acceptor
94.0[3.70]
83.0[3.27]
116.0[4.57]8.0[0.31] 115.0[4.53]
50.8[2.00]
239.0[9.41]
132.0[5.20]
13.0[0.51]
48.6[1.31]
107.0[4.21]
115.0[4.53] 200bills
97.0[3.82] 100bills
200 pcs.
100 pcs.
130.0[5.12] 400bills
400 pcs.
190.0[7.48] 800bills
800 pcs.
51.0[2.008]
95.0[3.740]
69.5[2.736]
4.0[0.157]
134.0[5.276]
7.5[0.295]
126.5[4.980]
78.5 [3.091]
78.5 [3.091]
6-R2.65[R0.104]
232.0[9.134]
19.5[0.768]
10.0[0.394]
400 pcs.
800 pcs.
200 pcs.
100 pcs.
9.0[0.354] 23.5[0.925]
59.0[2.323] 52.0[2.047]
179.5[7.067] 200 bills 161.5[6.358] 100 bills 194.5[7.657] 400 bills
254.5[10.020] 800 bills
5. Installation
5-1. Harness Application
Standard
Pulse
Standard
Pulse
MDB
5V Enable
ICT Protocol
(RS232)
ICT Protocol
(RS232)
A7
V7
117V AC
117V AC
117V AC
12V DC
12V DC
12V DC
24V AC
34V DC
12V DC
24V AC
Interface
Model Used
Voltage Usage
Power & *Data Comm.
Extension Wire
Power & *Data Comm.
Extension Wire
Power & *Data Comm.
**Power Ext.
*Data Comm.
Power
**Power Ext.
*Data Comm.
Power & *Data Comm.
Extension Wire
Power & *Data Comm.
Extension Wire
Power & *Data Comm.
Power
Extension Wire
*Data Comm.
Power & *Data Comm.
Extension Wire
Power
GPT Parallel
*Data Comm. : Data Communication.
**Power Ext. : Power Extension Wire
***5RBG-AA203L1-xx : Plug-in Box & Cables, “xx” varies from version to version.
Table 1
Figure.1
Figure.2
3
www.ictgroup.com.tw 4www.ictgroup.com.tw
WEL-RM008
WEL-RV706
WEL-RM007
WEL-RM012
WEL-RM012
WEL-RM008
CU-R961-1
WEL-RV706
WEL-RM017
WEL-RV701
CU-R961-1
WEL-RV701
WEL-RV706
WEL-RM018
CU-R961-1
WEL-RV703
WEL-RV702
WEL-RM007
WEL-RM006
CU-R961-1
Harness Page
5
6
7
8
9
7
11
5
6
11
12
8
14
13
15
11
7
11
16
10
6
***
5RBG-AA203L1-xx

WEL-RM008
2464 22 AWG 8C CABLE
AC 117V
WEL-RM008
(Standard Pulse, ICT Protocol <RS232> / 117V AC)
PIN 1- YELLOW.....................NEUTRAL INHIBIT
PIN 2- RED...........................NEUTRALE NABLE
PIN 3- BROWN..............................HOT ENABLE
PIN 4- BLACK.....................117VAC HOT(Power)
PIN 5- GREEN................................Earth-Ground
PIN 6- WHITE...........117VAC NEUTRAL(Power)
PIN 7- BLUE.....................CREDIT_RELAY(N.O.)
PIN 8- PURPLE.........CREDIT_RELAY(Common)
PIN 9- Reserved
PIN 1- PURPLE......CREDIT_RELAY(Common)
PIN 3- RED..........................NEUTRALENABLE
PIN 4- WHITE..........117VACNEUTRAL(Power)
PIN 5- YELLOW....................NEUTRALINHIBIT
PIN 16- BLUE..................CREDIT_RELAY(N.O.)
PIN 18- BROWN.............................HOTENABLE
PIN 20- BLACK...................117VACHOT(Power)
PIN 21- GREEN........................EARTHGROUND
1 2 3 4 5 6 7 8 9
AMP 172340-1
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
BLK-15*2(KEY)
* *
A7 / V7 A7 / V7
Bill Acceptor Bill Acceptor
5
www.ictgroup.com.tw 6www.ictgroup.com.tw
WEL-RM012
PIN 1- YELLOW...............NEUTRAL INHIBIT+
PIN 2- RED.......................NEUTRAL INHIBIT-
PIN 3- ORANGE........................HOT ENABLE
PIN 4- BLACK...............117VAC HOT (Power)
PIN 5- GREEN..........................Earth - Ground
PIN 6- BLACK......117VAC NEUTRAL (Power)
PIN 7- BLUE...............CREDIT_RELAY (N.O.)
PIN 8- PURPLE...CREDIT_RELAY (Common)
PIN 9- Reserved
PURPLE.......CREDIT_RELAY (Common)
BLUE...................CREDIT_RELAY (N.O.)
GREEN.............................Earth - Ground
ORANGE...........................HOT ENABLE
RED..........................NEUTRAL INHIBIT-
YELLOW..................NEUARAL INHIBIT+
( Standard Pulse, ICT Protocol <RS232> / 117V AC )
2464 22 AWG 6C CABLE
1 2 3 4 5 6 7 8 9
AMP 172340-1
AC 117V
WEL-RM012
AC
202 202 202 202 202 202
Figure.3 Figure.4

WEL-RM007
PIN 1- PURPLE.......CREDIT_RELAY (Common)
PIN 2- RED..................................12VDC (Power)
PIN 3- WHITE........................................ENABLE-
PIN 5- YELLOW....................................INHIBIT+
PIN 10- BROWN...............................GND (Power)
PIN 16- BLUE...................CREDIT_RELAY (N.O.)
PIN 18- BLACK......................................ENABLE+
PIN 20- GREEN.......................................INHIBIT-
( Standard Pulse, ICT Protocol <RS232> / 12V DC )
2464 22 AWG 8C CABLE
WEL-RM007
DC +12V
1 2 3 4 5 6 7 8 9
AMP 172340-1
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
BLK-15*2(KEY)
* *
PIN 1- YELLOW.......................................INHIBIT+
PIN 2- GREEN..........................................INHIBIT-
PIN 3- Reserved
PIN 4- Reserved
PIN 5- RED...................................12V DC (Power)
PIN 5 Dotted- BLACK..................12V DC (Power)
PIN 6- Reserved
PIN 7- BLUE......................CREDIT_RELAY (N.O.)
PIN 8- PURPLE..........CREDIT_RELAY (Common)
PIN 9- BROWN..................................GND (Power)
PIN 9 Dotted- WHITE.......................GND (Power)
( Standard Pulse, ICT Protocol <RS232> / 12V DC)
CU-R961-1
2464 22 AWG 6C CABLE
DC 12V
#CU-R961-1
202 202 202 202
1 2 3 4 5 6 7 8 9
AMP 172332-1
202 202
PIN 1- YELLOW...........................INHIBIT+
PIN 2- GREEN..............................INHIBIT-
PIN 5- RED...............+12VDC(POWER-IN)
PIN 7- BLUE...............CREDIT-RELAY-NO
PIN 8- PURPLE.......CREDIT-RELAY-COM
PIN 9- ORANGE.............GND(POWER-IN)
K
+AMP
.551 inch or 14mm
.165inch or 4.2mm
1 2 3 4 5 6 7 8 9
AMP 172332-1 BACK VIEW
A7 / V7 A7 / V7
Bill Acceptor Bill Acceptor
7
www.ictgroup.com.tw 8www.ictgroup.com.tw
Figure.5 Figure.6

WEL-RM017
2464 22AWG 8C CABLE
HORN-30
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
PIN 2- RED....................................................I-ENABLE-L
PIN 4- BLACK.............................................115VAC-HOT
PIN 5- GREEN.....................................EARTH-GROUND
PIN 6- WHITE & YELLOW.................115VAC-NEUTRAL
PIN 7- BLUE.....................................CREDIT-RELAY-NO
PIN 8- PURPLE & BROWN...........CREDIT-RELAY-COM
A6&A7 AC110V 5V INHIBIT
#WEL-RM017
* *
+AMP
.551 inch
or 14mm
.165inch or 4.2mm
123 456 789
AMP 172340-1
BACK VIEW
1 2 3 4 5 6 7 8 9
AMP 172340-1
PIN 1- PURPLE.........................CREDIT-RELAY-COM
PIN 4- WHITE............115VAC-NEUTRAL(POWER IN)
PIN 5- YELLOW..............................NEUTRAL-INHIBIT
PIN 10- BROWN......................................................GND
PIN 16- BLUE.................................CREDIT-RELAY-NO
PIN 20- BLACK.....................115VAC-HOT(POWER IN)
PIN 21- GREEN..................................EARTH-GROUND
PIN 27.& 28. & 29- RED..............................I-ENABLE-L
PIN 13. & 14. & 15. & 25- BLACK...............I-ENABLE-H
(5V Enable / 117V AC)
A7 / V7 A7 / V7
Bill Acceptor Bill Acceptor
9
www.ictgroup.com.tw 10 www.ictgroup.com.tw
2464 22 AWG 6C CABLE
(KST) (SHBM1-4)
WEL-RM018
AC
A6&A7 AC110V 5V INHIBIT
#WEL-RM018
1 2 3 4 5 6 7 8 9
AMP 172332-1
K
+AMP
.551 inch or 14mm
.165inch or 4.2mm
123 456 789
AMP 172332-1 BACK VIEW
202 202 202 202
PIN 2- RED.............................................I-ENABLE-L
PIN 4- BLACK..................115VAC-HOT(POWER-IN)
PIN 5- GREEN..............................EARTH-GROUND
PIN 6- BLACK........115VAC-NEUTRAL(POWER-IN)
PIN 7- BLUE..............................CREDIT-RELAY-NO
PIN 8- PURPLE......................CREDIT-RELAY-COM
(5V Enable / 117V AC)
Figure.7 Figure.8

WEL-RV706
26 AWG 6C PHONE CABLE
(ICT Protocol <RS232> / 12V DC, 117V AC <A7> )
D-SUB(F)
12345
6789
D-SUB 9F TOP VIEW
RJ-45
1
2
34
56
7
8
RJ-45 VIEW
PIN 1- Reserved
PIN 2- RXD
PIN 3- TXD
PIN 4- Reserved
PIN 5- GND
PIN 6- Reserved
PIN 7- Reserved
PIN 8- Reserved
PIN 9- Reserved
PIN 1- BLUE................GND
PIN 2- YELLOW.........TX22
PIN 3- GREEN...........RX22
PIN 5- Reserved
PIN 6- Reserved
PIN 6- RED..................VCC
PIN 7- BLACK.............RX11
PIN 8- WHITE..............TX11
WEL-RV706
ICT PROTOCOL
A7 / V7 A7 / V7
Bill Acceptor Bill Acceptor
11
www.ictgroup.com.tw 12 www.ictgroup.com.tw
WEL-RV701
* *
DC 12V
#WEL-RV701
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
BLK-15*2
1 2 3 4 5 6 7 8 9
AMP 172340-1
+AMP
.551 inch
or 14mm
.165inch or 4.2mm
123 456 789
AMP 172340-1 BACK VIEW
P 1- Y ELLOW .....................................INHIBIT+
P 2- G REEN .........................................INHIBIT
P 3- Reserved
P 4- Reserved
P 5- R ED .............................. 12V DC (POWER)
P 6- Reserved
P 7- B LUE.................... CREDIT_RELAY (N.O.)
P 8- P URPLE ........ CREDIT_RELAY (Common)
P 9-O RANGE ........................... GND (POWER)
IN
IN
IN
IN
IN
IN
IN
IN
IN
P 1- PURPLE........CREDIT_RELAY (Common)
P 2- BLUE...................CREDIT_RELAY ( N.O.)
P 3- RED...............................12VDC (POWER)
P 4- YELLOW......................................INHIBIT+
P 18- GREEN..........................................INHIBIT
P 20- ORANGE...........................GND (POWER)
IN IN IN IN IN IN
( Standard Pulse, ICT Protocol <RS232> / 12V DC)
Figure.9 Figure.10

WEL-RV702
AC 24V
#WEL-RV702
202 202 202 202 202 202
.551 inch
or 14mm
K
+AMP
.165inch or 4.2mm
1 2 3 4 5 6 7 8 9
AMP 172332-1 BACK VIEW
1 2 3 4 5 6 7 8 9
AMP 172332-1
P 1- Reserved
P 2- INHIBIT+.....................................................YELLOW
P 3- Reserved
P 4- CREDIT_RELAY (N.O.)....................................BLUE
P 5- CREDIT_RELAY (Common).........PURPLE&GREEN
P 5- INHIBIT.........................................PURPLE&GREEN
P 6- Reserved
P 7- 24V AC (RET).............................................ORANGE
P 8- 24V AC (HOT)....................................................RED
P 9- Reserved
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
YELLOW....................................INHIBIT+
BLUE...................CREDIT_RELAY (N.O.)
PURPLE.......CREDIT_RELAY (Common)
GREEN.........CREDIT_RELAY (Common)
ORANGE............................24V AC (RET)
RED...................................24V AC (HOT)
( Standard Pulse / 24V AC )
P 1- Reserved
P 2- INHIBIT+.............................................YELLOW
P 3- Reserved
P 4- CREDIT_RELAY (N.O.)...........................BLUE
P 5- CREDIT_RELAY (Common)
..............PURPLE&GREEN
P 5- INHIBIT-
P 6- Reserved
P 7- 24V AC (RET)....................................ORANGE
P 8- 24V AC (HOT)...........................................RED
P 9- Reserved
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
WEL-RV703
2464 22 AWG 6C CABLE
* *
AC 24V
#WEL-RV703
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
BLK-15*2
+AMP
.551 inch
or 14mm
.165inch or 4.2mm
123 456 789
AMP 172340-1 BACK VIEW
1 2 3 4 5 6 7 8 9
AMP 172340-1
P 1- CREDIT_RELAY (Common).........PURPLE
P 2- CREDIT_RELAY (N.O.).....................BLUE
P 4- INHIBIT+......................................YELLOW
P 16- 24V AC (RET)..............................ORANGE
P 18- INHIBIT...........................................GREEN
P 23- 24V AC (HOT).....................................RED
IN
IN
IN
IN
IN
IN
( Standard Pulse / 24V AC )
A7 / V7 A7 / V7
Bill Acceptor Bill Acceptor
13
www.ictgroup.com.tw 14 www.ictgroup.com.tw
Figure.11 Figure.12

WEL-RM006
HORN-30
PIN 1- BLUE..............................................34VDC
PIN 2- YELLOW.................34VDC Power Return
PIN 3- N/C
PIN 4- ORANGE...........................Master Receive
PIN 5- RED..................................Master Transmit
PIN 6- GREEN............Communications Common
PIN 6- ORANGE...........................Master Receive
PIN 14- RED..................................Master Transmit
PIN 16- YELLOW..................34VDC Power Return
PIN 23- 3BLUE...............................................4VDC
PIN 28- GREEN.............Communications Common
123
456
.163inch or 4.14 mm
MOLEX 5557-6R BACK VIEW
1 2 3
54 6
.163or4.14
MOLEX 5559-06P BACK VIEW
* *
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
DC 34V MDB
#WEL-M006
1 2 3 4 5 6
MOLEX 5559-06P
1 2 3 4 5 6
MOLEX 5557-6R
( MDB / 34V DC )
1 2 3 4 5 6 7 8 9
15 14 12 13 11 10
MOLEX 15P 0.248/6.3(F)
1 2 3 4 5 6 7 8 9
15 14 12 13 11 10
MOLEX 15P 0.248/6.3(M)
2464 24AWG 6C CABLE 2464 24AWG 4C CABLE
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
BLK-15*2(2.54mm/KEY)
* *
PIN 1- BLUE............CH1
PIN 2- YELLOW......CH2
PIN 3- WHITE.........CH3
GREEN
BLUE YELLOW WHITE ORANGE
BLACK WHITE BLUE
PURPLE
PIN 1- BROWN............24VAC-Neutral
PIN 2- BLUE................... 24VAC_HOT
PIN 9- BLUE................... 24VAC_HOT
15 12 9 14 11 8
13 10 7
6 3 5 2 4 1
MOLEX
1991-15
MOLEX 15P 0.248/6.3(M)BACK
#WEL-RLD15
Parallel GPT
1 2 3 4 5 6 7
MOLEX 51004-7P
5RBG-AA203L1-0x
(Parallel<GPT> / 24VAC)
PIN 1- BROWN.............24VAC-Neutral
PIN 2- BLUE.................... 24VAC_HOT
PIN 9- BLUE.....................24VAC_HOT
15129 14118 13107
63 52 41
MOLEX
1991-15
MOLEX 15P 0.248/6.3(F)BACK
PIN 3- WHITE..........................+12V
PIN 4- RED........................INHIBIT+
PIN 6- PURPLE...............MDB_RXD
PIN 10&18- BLACK...................GND
PIN 14- BLUE...................MDB_TXD
PIN 16- BROWN.......24VAC-Neutral
PIN 23- BLUE............... 24VAC_HOT
Plug-in Box
MOLEX 51004-7P
BLK-15*2(2.54mm/KEY)
PIN 4- ORANGE.....CH4
PIN 5- RED.......INHIBIT
PIN 7- GREEN.......GND
A7 / V7 A7 / V7
Bill Acceptor Bill Acceptor
15
www.ictgroup.com.tw 16 www.ictgroup.com.tw
Figure.13
Figure.14

5-1-1. I/O Circuit
ICT-Protocol Interface.
RXD
RXD TXD
+5VDC
Hi"TR ON
Lo"TR OFF
+5VDC
1K
RXDTXD
TXD
+5VDC
A7 / V7 A7 / V7
Bill Acceptor Bill Acceptor
17
www.ictgroup.com.tw 18 www.ictgroup.com.tw
Pulse Interface. Figure.15 Figure.16
Credit O/P
Credit_Relay_NO
Inhibit+
BA Status DIP SW Setting Control Signal
Inhibit
Active
Inhibit
Active
Low Low
Low High
High High
High Low
Inhibit
Enable
Inhibit I/P
Hi"TR ON
Lo"TR OFF
Inhibit-
+5VDC~+12VDC
+5VDC
+5VDC +5VDC~+12VDC
Customer Side
Customer Side
Customer Side
Customer Side
Bill Acceptor
Bill Acceptor
Bill Acceptor
Bill Acceptor
4K7
1K
TR
Credit_Relay_COM

5V Enable Interface
+5VDC~+12VDC +5VDC~+12VDC
+5VDC~+12VDC
+5VDC~+12VDC
+5VDC~+12VDC
+5VDC
+5VDC
+5VDC
1K 1K
TR
TR
TR
1K
1K
1K
2_CREDIT
1_ENABLE
1_ENABLE_H
2_ENABLE_H
5_ENABLE_H
2_ENABLE_L
5_ENABLE_L
1_ENABLE_L
HiZTR ON
HiZTR ON
HiZTR ON
LoZTR OFF
LoZTR OFF
LoZTR OFF
2_ENABLE
5_ENABLE
2
5
5_CREDIT
A7 / V7 A7 / V7
Bill Acceptor Bill Acceptor
19
www.ictgroup.com.tw 20 www.ictgroup.com.tw
Customer Side
Customer Side
Bill Acceptor
Bill Acceptor
Figure.17 Figure.18

+5VDC
+5VDC
+5VDC~+12VDC
+5VDC~+12VDC
1K
1
1
8
8
3
3
6
6
2
2
7
7
4
4
5
5
1K
MDB_MASTER_RXD
MDB_MASTER_TXD
TXD
RXD
HiZTR ON
LoZTR OFF
MDB Interface GPT Parallel Interface
GPT System
Serial to Parallel
Converter
5V
VEND1~4
INHIBIT
12V
TXD
RXD
Customer Side Customer Side
Customer Side
Bill Acceptor Bill Acceptor
Bill Acceptor
Figure.19 Figure.20
A7 / V7 A7 / V7
Bill Acceptor Bill Acceptor
21
www.ictgroup.com.tw 22 www.ictgroup.com.tw

To download and upgrade the software to A7/V7 Series, the
programmer (FP-001) is needed. Please contact ICT to purchase
FP-001 and refer to FP-001 user guide for software download and
upgrade information.
There are two serial DIP switches which are located on the side of
A7/V7 Series (as figure 21). According to different currencies which
are used by users, DIP switch settings could be varied to fit users’
need. Besides, there’s also a serial DIP switches on CPU board
inside of A7/V7 Series for interface settings.(as figure 21)
Please refer to “A7/V7 Series DIP Switch Setting” Guide in the
package for more detail.
A7/V7 FP-001 PC
Power must be applied to BA AFTER connecting.
1234
ON DIP
FirmwarePower
WEL-RM009 WEL-R087
COM1 or COM2PH
5 4 3 2 1
9 8 7 6
To make sure the bill acceptor always works smoothly, please clean the
internal parts regularly.
Buttons
Sensors
Sensors
5-2. DIP Switch Setting
5-3. Software Download and Upgrade
Figure.21 Figure.22
Figure.23
Figure.24
Figure.25
6. Maintenance
To clean the internal parts:
1. Press the buttons on the sides of bill path unit and pull the unit out
(as figure 24).
2. Use a soft, dry cloth or towel to clean the bill path and sensors
(as figure 25).
A7 / V7 A7 / V7
Bill Acceptor Bill Acceptor
23
www.ictgroup.com.tw 24 www.ictgroup.com.tw
Mild, non-abrasive, soap water.
Organic solvent , Alcohol, Volatility liquid
OK
DO NOT USE

2
3
Bezel LED
7. Troubleshooting
LED
Flashes
1
3
3+2
3+5
(Optional)
2
5
6
7
4
Status Corrective Actions
Bill jammed.
Recognition sensor error.
Hook sensor error.
Disable
Anti-string sensor error or
a stringing attempt has
detected.
Bill box has been removed.
Stacker error or stacker full.
Motor error.
Remove the bill box by sliding the top
button and the bill path unit (as figure 27),
and then remove the jammed bill.
Inspect for foreign objects on sensor
or bill path and clean.
Inspect for foreign objects on security
hook and clean.
Magnetic Head error. Inspect for foreign objects on Magnetic
Head and clean.
Inspect for right DIP switch setting.
Inspect for foreign objects on sensor
or bill path and clean.
Replace the bill box.
Empty the bill box.
Inspect for foreign objects on bill path
and clean.
If the error can not be solved after corrective actions or happen again,
please contact ICT for technical support.
Bill Box
1
Slide Button
A7 / V7
Bill Acceptor
25
www.ictgroup.com.tw
Figure.26 Figure.27
Ji-Hong Building, No 24, Alley 38, Lane 91, Nei-hu Rd., Sec. 1, Taipei, Taiwan, R.O.C.
Tel: [phone] ‧ Fax: [phone]
[e-mail] (For Sales) ‧ [e-mail] (For Customer Service)
Website: www.ictgroup.com.tw
Taiwan
International Currency Technologies Corporation
Table 2
