IDEC PS5R-V Series User manual

PS5R-V
Switching Power Supplies

Ultimate Downsizing
20mm 20mm 10mm 10mm
PS5R-S
Conventional
Volume:
Approx. 50% less *3
Width:
Approx. 40% less *3
PS5R-V
PS5R-V
Slim size
Space between the switching
supplies reduced to half
downsized
downsized
Reduced installation space
•Required space between the switching
power supplies reduced to half *1
•Size is reduced to the smaller output
capacity (30W/90W/120W) *2
•Less wiring required
•Can be installed in six directions
Reduced wiring & exible installation
•Five-year warranty*1
•Operating temperature –25 to +75ºC *1
Improved reliability
Reduces installation space inside the panel
Reduced wiring & exible installation
Suitable for global and semiconductor applications
Spring-up terminals accepts
wiring of ring terminals.
No need to worry about loosing
screws .
Six mounting directions
Compliant with International
Safety Standards
Meets SEMI F47 Sag Immunity
(208V AC input)
Voltage sag ride-through capabilities for
semiconductor process equipment, metering
equipment and automatic test equipment.
(208V AC input)
Reduced wiring
(100V to 240V AC input)
*1 For details on specication or operating conditions,
see catalog or manual.
*2 Compared with conventional PS5R-S model.
*3 Compared with conventional PS5R-S output capacity
30W model.

3
Space-saving DIN-rail switching power supplies
PS5R-V Switching Power Supplies
•Spring-up terminal accepts wiring of ring terminals.
•Slim size
Width: 22.5mm (10W/15W/30W), 36mm (60W/90W),
46mm (120W), 60mm (240W)
•Can be installed in six mounting directions.
•Optional mounting bracket is available for panel mounting.
•CE marked (LVD, EMCD, RoHS)
•UL (UL508, UL1310 Class 2*1, ANSI/ISA 12.12.01)
c-UL (CSA C22.2 No. 107.1, 213, 223*1)
TÜV SÜD (EN60950-1, EN50178)
•EN61204-3 (Electromagnetic compatibility Class B)
•Meets SEMI F47 Sag Immunity (208V AC input)
•RoHS compliant
•Five-year warranty
Applicable Standards Mark File No. or Organization
UL508, UL1310*1
ANSI/ISA 12.12.01
CSA C22.2 No.107.1
CSA C22.2 No.213
CSA C22.2 No.223*1
UL/c-UL Listed
File No. E177168
File No. E467154
EN60950-1
EN50178
EN61204-3
EN50581
TÜV SÜD*2
EU Low Voltage Directive
EMC Directive
RoHS Directive
SEMI F47 — EPRI
*1: PS5R-VB/VC/VD/VE only
*2: EN60950-1, EN50178 only
PS5R-V Package Quantity: 1
Output Capacity Part No. Input Voltage Output Voltage Output Current
10W PS5R-VB05
100 to 240V AC
(Voltage range: 85 to 264V AC /
100 to 370V DC)
5V 2.0A
15W PS5R-VB12 12V 1.3A
PS5R-VB24 24V 0.65A
30W PS5R-VC12 12V 2.5A
PS5R-VC24 24V 1.3A
60W PS5R-VD24 24V 2.5A
90W PS5R-VE24 24V 3.75A
120W PS5R-VF24 24V 5.0A
240W PS5R-VG24 24V 10.0A
DIN Rail (35mm-wide)
Length Part No. Material Weight Package Quantity
1000mm BAA1000PN10 Aluminum 200g 10
BAP1000PN10 Steel 320g
End Clip
Part No. Package Quantity
BNL6PN10 10
Panel Mounting Bracket*3
Applicable Switching
Power Supply Ordering No. Remarks
PS5R-VB
PS5R-VC
PS9Z-5R1B —
PS9Z-5R2B For side mounting
PS5R-VD
PS5R-VE PS9Z-5R1C —
PS5R-VF PS9Z-5R1E —
PS5R-VG PS9Z-6R1F —
PS9Z-6R2F For side mounting
*3: Used for direct panel mounting.
*4: PS5R-VB only
*5: PS5R-VB/VC only
Part No. Development
PS5R - V  
Switching Power
Supply
Output Voltage
Code
05: 5V*4
12: 12V*5
24: 24V
Output Capacity
Code
B: 10W/15W
C: 30W
D: 60W
E: 90W
F: 120W
G: 240W
Slim Line
Use for interpreting part numbers.

4
PS5R-V Switching Power Supplies
Specifications
Part No.
(10W/15W)
PS5R-VB05
PS5R-VB12
PS5R-VB24
(30W)
PS5R-VC12
PS5R-VC24
(60W)
PS5R-VD24 (90W) PS5R-VE24 (120W) PS5R-VF24 (240W) PS5R-VG24
Input
Rated Input Voltage
(Single-phase two-wire)*1
100 to 240V AC
(Voltage range: 85 to 264V AC/100 to 370V DC) (Load ≤ 80% at 100-105V DC)
Frequency 50/60 Hz
Input
Current
(Typ.)
100V AC
5V: 0.25A
12V, 24V: 0.35A 0.7A 1.3A 1.1A 1.4A 2.7A
230V AC
5V: 0.14A
12V, 24V: 0.19A 0.3A 0.8A 0.6A 0.7A 1.2A
Inrush
Current
(Typ.)
100V AC 18A (Ta = 25°C, cold start) 14A max.
(Ta = 25°C, cold start)
230V AC 45A (Ta = 25°C, cold start) 30A max.
(Ta = 25°C, cold start)
Leakage
Current
120V AC 0.5 mA max.
230V AC 1.0 mA max.
Efciency
(Typ.)
(at rated
output)*2
100V AC 5V: 77%, 12V: 82%, 24V: 84% 12V: 83%, 24V: 85% 86% 88% 89%
230V AC 5V: 73%, 12V: 80%, 24V: 81% 12V: 85%, 24V: 87% 86% 89% 90%
Power
Factor (Typ.)
100V AC — — — 0.99
230V AC — — — 0.86 0.92 0.96
Output
Rated Voltage/Current 5V/2.0A*3, 12V/1.3A,
24V/0.65A 12V/2.5A, 24V/1.3A 24V/2.5A 24V/3.75A 24V/5A 24V/10A
Adjustable Voltage
Range ±10% ±5% ±10%
Output
Holding Time
(Typ.)
(at rated output)
100V AC
5V: 53ms, 12V: 34ms,
24V: 36ms 12V: 13ms, 24V: 15ms 13ms 20ms 30ms 30ms
230V AC
5V: 330ms
12V: 215ms
24V: 230ms
12V: 110ms
24V: 110ms 105ms 30ms 33ms 40ms
Start Time (at rated
input and output) 500 ms max. 600 ms max. 800 ms max. 700 ms max. 800 ms max.
Rise Time (at rated
input and output) 5V, 12V: 200ms max. 24V: 250ms max. 200ms max.
Regulation
Input Fluctuation 0.4% max.
Load Fluctuation 5V: 2.5% max.
12V, 24V: 1.0% max. 1.0% max.
Temperature
Change
0.05%/C max. (–10 to +65C )
12V: 0.05%/C max. (–10 to +50C)
24V: 0.05%/C max. (–10 to +55C)
0.05%/C max. (–10 to +55C ) 0.05%/C max. (–25 to +55C )
Ripple
(including noise)
5V: 8% p-p max. (–25 to –10C)
12V: 6% p-p max. (–25 to –10C)
24V: 4% p-p max. (–25 to –10C)
12V: 6% p-p max. (–25 to –10C)
24V: 4% p-p max. (–25 to –10C)
4% p-p max. (–25 to –10C) 4% p-p max. (–25 to –10C)
5V: 5% p-p max. (–10 to +0C)
12V: 2.5% p-p max. (–10 to +0C)
24V: 1.5% p-p max. (–10 to +0C)
12V: 2.5% p-p max. (–10 to +0C)
24V: 1.5% p-p max. (–10 to +0C)
1.5% p-p max. (–10 to +0C) 1.5% p-p max. (–10 to +0C)
5V:2.5% p-p max. (0 to +65C)
12V:1.5% p-p max. (0 to +65C)
24V:1% p-p max. (0 to +65C)
12V: 1.5% p-p max. (0 to +50C)
24V: 1% p-p max. (0 to +55C)
1% p-p max. (0 to +55C) 1% p-p max. (0 to +55C)
Supple-
mentary
Functions
Overcurrent
Protection 105% min. (auto reset) 101% min. (auto reset) 105% min. (auto reset)
Operation
Indicator LED (green)
Dielectric Strength Between input and output terminals: 3,000V AC, 1 minute Between input and ground terminals: 2,000V AC, 1 minute
Between output and ground terminal: 500V AC, 1 minute
Insulation Resistance Between input and output terminals: 100M min. (500V DC megger), Between input and ground terminal: 100M min. (500V DC megger)
Operating Temperature*4
–25 to +75°C (no freezing)
–25 to +70°C (no freezing) –25 to +65°C (no freezing)
Operating Humidity 20 to 90% RH (no condensation)
Storage Temperature –25 to +75°C (no freezing)
Storage Humidity 20 to 90% RH (no condensation)
Vibration Resistance 10 to 55 Hz, amplitude 0.375mm, 2 hours each in 3 axes
(when used with part no. BNL6 mounting clips)
10 to 55 Hz, amplitude 0.33mm, 2 hours each in 3 axes
(when used with part no. BNL6 mounting clips)
10 to 55 Hz, amplitude 0.375mm, 2 hours each in 3
axes (when used with part no. BNL8 mounting clips)
10 to 55 Hz, amplitude
0.21mm, 2 hours each in 3
axes (when used with part
no. BNL6 mounting clips)
10 to 55 Hz, amplitude
0.375mm, 2 hours each in 3
axes (when used with part
no. BNL8 mounting clips)
10 to 55 Hz, amplitude
0.375mm, 2 hours each
in 3 axes
(when used with part no.
BNL6 mounting clips)
Shock Resistance 300 m/s2, 3 times each in 6 directions
EMC EMI EN61204-3 (Class B)
EMS EN61204-3 (industrial)
Safety Standards UL508 (Listing), UL1310 Class 2, ANSI/ISA-12.12.01, CSA C22.2 No. 107.1, 213, 223
EN60950-1, EN50178 UL508 (Listing), ANSI/ISA-12.12.01 CSA C22.2 No. 107.1, 213, EN60950-1, EN50178
Other Standard SEMI F47 (at 208V AC input only)
Degree of Protection IP20 (EN60529)
Dimensions (mm) 90H × 22.5W × 95D 95H × 36W × 108D 115H × 46W × 121D 125H × 60W × 125D
Weight (approx.) 140g 150g 260g 310g 470g 960g
Terminal Screw M3.5
At normal temperature and humidity unless otherwise specied.
*1: DC input voltage is not subject to safety standards. When using on DC input, connect a fuse to the input terminal for DC input protection.
*2: Under stable state. *3: PS5R-VB05 (5V DC/2.0A) is 10W (Up to 3.0A at Ta = 0 to 40°C. Not subject to safety standards at 2.0A and over.)
*4: See the output derating curves on page 5.
Reference Value
Expected Life*58 years minimum (at the rated input, 50% load, operating temperature +40°C, standard mounting direction)
*5: Calculation of the expected life is based on the actual life of the aluminum electrolytic capacitor. The expected life depends on operating conditions.

5
PS5R-V Switching Power Supplies
Block Diagrams
PS5R-VB
V.ADJ
L
N
INPUT
+
V
−
V
Switching
Control
Detection
Fuse
Rectifying Rectifying Line lter
Overcurrent Detection
PS5R-VC / PS5R-VD
V.ADJ
L
N
INPUT
+
V
−
V
Switching
Control
Detection
Fuse
Rectifying
Rectifying
Line lter
Overcurrent Detection
PS5R-VE24
L
N
INPUT
V.ADJ
+V
−V
Switching
Control
Detection
Fuse
Rectifying
Active Filter
Ripple Filter
Rectifying
Line lter
Overcurrent Detection
PS5R-VF24
L
N
INPUT
V.ADJ
+
V
−
V
Switching
Control
Detection
Fuse
Rectifying
Rectifying
Active Filter
Ripple Filter
Line lter
Overcurrent Detection
PS5R-VG24
L
N
INPUT
V.ADJ
+V
−V
Switching
Control
Detection
Fuse
Rectifying
Active Filter
Ripple Filter
Rectifying
Line lter
Overcurrent Detection

6
PS5R-V Switching Power Supplies
Mounting A
(Vertical, standard)
Mounting B
(Upright)
Mounting C
(Left side up)
Mounting D
(Right side up)
Mounting E
(Upside down)
Mounting F
(Downward)
Up
Mounting Style
Mounting A
Mounting B, C, D, E, F
Mounting E
Mounting E
Mounting E
Mounting B
-30 -20 -10 0 10 20 30 40 50 60 70 80
0
10
20
30
40
50
60
70
80
90
100
-30 -20 -10 0 10 20 30 40 50 60 70 80
0
10
20
30
40
50
60
70
80
90
100
Input Voltage:
85-100V AC
Input Voltage:
85-100V AC
Mounting F
Mounting A Mounting A, B
MountingC
Mounting B, C, D, E, F
Mounting
B, C, D, F
Mounting
B, C, F
Mounting D, E, F
Input Voltage:
85-100V AC
Input Voltage:
85-100V AC
-30 -20 -10 0 10 20 30 40 50 60 70 80
0
10
20
30
40
50
60
70
80
90
100
-30 -20 -10 0 10 20 30 40 50 60 70 80
0
10
20
30
40
50
60
70
80
90
100
Mounting B, C, D
Mounting A
Mounting A
Mounting A
Output Current (%)
Operating Temperature (˚C) Operating Temperature (˚C) Operating Temperature (˚C)
Operating Temperature (˚C)
Operating Temperature (˚C)
Operating Temperature (˚C)
Output Current (%)Output Current (%) Output Current (%)
Output Current (%)Output Current (%)
Mounting F
Mounting C, E
-30 -20 -10 0 10 20 30 40 50 60 70 80
0
10
20
30
40
50
60
70
80
90
100
Mounting
B, D
Mounting A
Operating Temperature (˚C)
Output Current (%)
-30 -20 -10 0 10 20 30 40 50 60 70 80
0
10
20
30
40
50
60
70
80
90
100
-30 -20 -10 0 10 20 30 40 50 60 70 80
0
10
20
30
40
50
60
70
80
90
100
Operating Temperature Approved by Safety Standards
Part No.
UL508, CSA C22.2 No.107.1, ANSI/ISA12.12.01, EN60950-1, EN50178
Mounting
A
Mounting
B
Mounting
C
Mounting
D
Mounting
E
Mounting
F
PS5R-VB05,
-VB12, -VB24 65 60 60 60 60 60
PS5R-VC12 50 45 45 45 45 45
PS5R-VC24 55 55 50 45 45 45
PS5R-VD24 55 40 40 40 45 35
PS5R-VE24 50 40 40 40 45 40
PS5R-VF24 55 40 45 40 45 35
PS5R-VG24 50 35 30 30 45 30
PS5R-VC12
PS5R-VE24
PS5R-VD24
85 100 264
100
(ACV)
(DCV) 140 370
0
10
20
30
40
50
60
70
80
90
100
Input Voltage (V)
Output Current (%)
PS5R-VG24
Output Current vs. Input Voltage
(derating curves)
PS5R-VG24
PS5R-VF24
PS5R-VC24PS5R-VB05, -VB12, -VB24
Characteristics
Operating Temperature vs. Output Current (Derating Curves)
Conditions: Natural air cooling (Operating temperature is the temperature around the switching power supply.)

7
PS5R-V Switching Power Supplies
Parts Description
PS5R-VB/VC
PS5R-VB/VC/VD/VF
PS5R-VD/VE/VF
PS5R-VE24
PS5R-VG
PS5R-VG24
Marking Name Description
L, N AC Input Terminal Voltage range: 85 to 264V AC/100 to 370V DC
Ground Terminal Be sure to connect this terminal to a proper ground.
+V, –V DC Output Terminals +V: Positive output terminal
–V: Negative output terminal
VR.ADJ Output Voltage Adjustment
Turning clockwise increases the output voltage.
Turning counterclockwise decreases the output
voltage.
DC ON Operation Indicator (green) Lights when the output voltage is on.
Overcurrent Protection Characteristics
-30
0 100
0
100
0
0
100
95
0
0
100
95
100 100
105 and over
105 and over
101 and over Output Current (%)Output Current (%)Output Current (%)
Output Voltage (%) Output Voltage (%) Output Voltage (%)
Intermittent Operation
Intermittent Operation Intermittent Operation

8
PS5R-V Switching Power Supplies
Dimensions
35.3 44.9
106.5
60
9.5 9.5 9.5 9.5
9.5 9.5
9.3
5.5
1254.5
125
3.8
115 98 8.5
46
23
11.5 11.5
4.5 44.935.3
3.8
121
36
95 79 8
20
10 10 108
3.8
4.5 24.935.3
3.8
95
4.4 35.3 27.3
61.6
12.2 8.2
90
9.5
22.5
5-M3.5
Screw Terminal
5-M3.5
Screw Terminal
5-M3.5
Screw Terminal
5-M3.5
Screw Terminal
PS5R-VD/VE
PS5R-VF
PS5R-VG
PS5R-VB/VC
All dimensions in mm.
Tolerance: ±1mm

9
PS5R-V Switching Power Supplies
Dimensions
Mounting hole layout
when installing on
a panel directly
Mounting hole layout
when installing on
a panel directly
Mounting hole layout
when installing on
a panel directly
Mounting hole layout
when installing on
a panel directly
Mounting hole layout
when installing on
a panel directly
Mounting hole
layout for side
mounting
Side View
Side View
Front View
Front View
Front View Side View
Front View Side View
Front View Side View
Side View Back View Mounting Screws
(4 M3×6 countersunk screws)
13.616.4
96.7
5.5
28.8
10.0
10.0
12
112
102
26
105
10.2
9.9
109.8
12
24.7
112 120
102.0
110
44
62.9
26
38
105 115
36
48
125 135
36
125
10.2
9.9
122.8
135
145
28
39
28
135
28
10.5 10.5
145
10
130.6
56
138.6
56
148.6
138.6
56
70
62.3 29.5
11.8
31
11.8
2-M4 or ø2-4.5 holes
2-M4 or ø2-4.5 holes
2-M4 or ø2-4.5 holes
2-M4 or ø2-4.5 holes
4-M4 or ø4-4.5 holes
4-M4 or ø4-4.5 holes
Panel Mounting Bracket
PS9Z-5R1B
PS9Z-5R1C
PS9Z-5R1E
PS9Z-6R1F
PS9Z-6R2F Side-mount
PS9Z-5R2B Side-mount
When installed on switching power supply
All dimensions in mm.
Tolerance: ±1mm

10
PS5R-V Switching Power Supplies
Mounting on DIN Rails
1. Use a 35mm-wide DIN rail.
2. Fasten the DIN rail to a mounting plate using screws.
3. Place the PS5R-V on the DIN rail as shown with input termi-
nal side up (), and press the PS5R-V towards the DIN rail
(). Make sure that the PS5R-V is installed rmly.
4. Use BNL6 mounting clips for fastening the PS5R-V on the
DIN rail. Use of BNL8 mounting clips is recommended when
excessive vibration or shock is anticipated. Do not use the
PS5R-V when it is subject to vibration constantly.
Removal
•Insert a at screwdriver into the slot in the clamp, and pull out
the clamp until it clicks (). The lock mechanism is released
and the PS5R-V can be removed (). When mounting the
PS5R-V again, push in the latch rst.
Notes for installation
•Do not close the top and bottom openings of the PS5R-V to
allow for heat radiation by convection.
•Maintain a minimum of 10 mm clearance around the PS5R-V,
except for the top and bottom openings.
•When mounting multiple PS5R-V switching power supplies
side by side, maintain a minimum of 10 mm clearance. Ob-
serve the derating curves in consideration of the ambient
temperature.
10mm minimum
•When the derating voltage may exceed the recommended
value, provide forced air-cooling.
•Make sure to wire the ground terminal correctly.
•For wiring, use wires of heat resistance of 60C or higher
(PS5R-VB: 80C or higher). Use copper wire of the following
sizes, according to the rated current.
Terminal Wire Size (allowable current) Wire Type
Input AWG18 to 14 Copper
Solid/Stranded
Output AWG18 to 14
(AWG18: 7A, AWG16: 10A, AWG14: 15A)
Cross-sectional area
AWG18: 0.82mm2, AWG16: 1.31mm2, AWG14: 2.0mm2
Note: Wires of the above size must be used to comply with
UL508, CSA C22.2 No. 107.1.
Applicable crimp terminal (reference)
7.0 max.
4.1 max. 5.6 min. (PS5R-VG: 6.3 min)
ø3.6 min.
•Recommended tightening torque of the input and output ter-
minals is 1.0 to 1.3 N·m (0.8 N·m for UL).
Safety Precautions
Operating Instructions
Mount the PS5R-V in an enclosure. Do not use the PS5R-V
alone as an Electric Facilities for General Use.
Use the PS5R-V for electric facilities for business use only.
•Do not use switching power supplies with electric equipment
whose malfunction or inadvertent operation may damage the hu-
man body or life directly.
•Make sure that the input voltage and output current do not ex-
ceed the ratings. If the input voltage and output current exceed
the ratings, electric shock, re, or malfunction may occur.
•Do not touch the terminals of the switching power supply while
input voltage is applied, otherwise electric shock may occur.
•Provide the nal product with protection against malfunction or
damage that may be caused by malfunction of the switching
power supply.
•Operating temperatures should not exceed the ratings. Be sure to
note the derating characteristics. If the operating temperature ex-
ceeds the ratings, electric shock, re, or malfunction may occur.
•Blown fuses indicate that the internal circuits are damaged. Con-
tact IDEC for repair. Do not just replace the fuse and reoperate,
otherwise electric shock, re, or malfunction may occur.
•Do not use the switching power supplies to charge rechargeable
batteries.
•Do not overload or short-circuit the switching power supply for
a long period of time, otherwise the internal elements may be
damaged.
•Do not disassemble, repair, or modify the power supplies, other-
wise the high voltage internal part may cause electric shock, re,
or malfunction.
•The fuse inside the PS5R-V switching power supply is for AC
input. Use a DC fuse for DC input.
Mounting Removal
Clamp

11
PS5R-V Switching Power Supplies
Installing the Panel Mounting Bracket






Latch
Latch
LOCK
LOCK
Panel Mounting Bracket (PS9Z-5R1)
Panel Mounting Bracket (PS9Z-5R2B)
Power
Supply
Power
Supply
Tab
Tab
Slot


<Installing PS9Z-5R1Panel Mounting Bracket>
<Installing PS9Z-5R2B Panel Mounting Bracket>
LOCK
UNLOCK
LOCK
UNLOCK
Push in the latch to LOCK
position.
Install the tab on the panel
mounting bracket into the
slot on the power supply.
Install the brackets as
shown on the left.
Ensure that the panel
mounting bracket is locked
by the latch.
Pull out the latch to
UNLOCK position.
Insert the tab on the panel
mounting bracket into the
slot on the power supply.
Push in the latch to LOCK
position.
Ensure that the panel
mounting bracket is locked
by the latch.
Installing PS9Z-6R2F Side-mount Panel
Mounting Bracket
Install the bracket on the switching power supply using four
M3 × 6 countersunk screws supplied with the bracket.
Adjustment of Output Voltage
The output voltage can be adjusted within ±10% of the rated
output voltage (PS5R-VE: ±5%) by using the VR.ADJ control
on the front. Turning the VR.ADJ clockwise increases the out-
put voltage. Turning the VR.ADJ counterclockwise decreases
the output voltage.
Overcurrent Protection
The output voltage drops automatically when an overcurrent
ows due to an overload or short circuit. Normal voltage is
automatically restored when the load returns to normal condi-
tions.
Insulation/Dielectric Test
When performing an insulation/dielectric test, short-circuit the
input (between L and N) and output (between +V and –V). Do
not apply or interrupt the voltage quickly, otherwise surge volt-
ages may be generated and the PS5R-V may be damaged.
Notes for Operation
•Output interruption may indicate blown fuses. Contact IDEC.
•The PS5R-V switching power supply contains an internal fuse
for AC input. When using with DC input, install an external
fuse for DC input. To avoid blown fuses, select a fuse in con-
sideration of the rated current of the internal fuse.
Rated Current of Internal Fuses
Part No. Internal Fuse
Rated Current
PS5R-VB/VC 2A
PS5R-VD/VE/VF 4A
PS5R-VG 6.3A
•Avoid overload and short-circuit for a long period of time,
otherwise the internal elements may be damaged.
•DC input operation is not subject to safety standards.
Rust and Scratches on Metal parts
Hot-dip galvanized steel and bonderized steel are used for the
PS5R-V. Rust on the edge and scratches on the surfaces may
be developed depending on the storage condition, but the
performance of the PS5R-V is not affected.
Noise
Small acoustic noise inside the PS5R-V may be heard de-
pending on the input voltage and load, but the performance of
the PS5R-V is not affected.
Operating Instructions

12
PS5R-V Switching Power Supplies
Series Operation
The following series operation is allowed. In (b) series opera-
tion, connect Schottky barrier diodes. Choose (a) series opera-
tion when using the PS5R-V as positive and negative output
power supply. Insert a Shottky barrier diode for loads such
as operational amplier where outputs of two power supplies
may be connected in series (Load 3). Select a Schottky diode
in consideration of the rated current.
L
N
L
N
+V
–V
L
N
+V
–V
Load
(a)
L
N
L
N
+V
–V
L
N
+V
–V
Load 3
(b)
Load 1
Load 2
Parallel Operation
Parallel operation is not possible to increase the output capac-
ity, because the internal elements and load may be damaged.
Backup Operation
Backup operation is a connection method of two switch-
ing power supplies in parallel for emergency. Normally one
switching power supply has a sufcient output. If one switch-
ing power supply fails, another one operates to continue the
output. Make sure that the sum of power consumption by load
and diode is not greater than the rated wattage (rated voltage
× rated current) of one switching power supply.
＋
−
IN
A
C OUT
＋
−
IN OUT
Load
D
D
Select a diode in consideration of:
Diode's current must be more than double the PS5R-V's
output current. Take heat dissipation into consideration.
Operating Instructions
Warranty
Warranty
IDEC warrantees the PS5R-V switching power supplies for a
period of ve years from the date of shipment.
Scope
IDEC agrees to repair or replace the PS5R-V switching power
supply if the product has been operated under the following
conditions. The maximum value of output capacity is within the
range shown in “Operating Temperature vs. Output Current"
on page 5.
1. Average operating temperature (ambient temperature of
switching power supply) is 40°C maximum.
2. The load is 80% maximum.
3. Input voltage is the rated input voltage.
4. Standard mounting style
IDEC shall not be liable for other damages including conse-
quential, contingent or incidental damages. Warranty does not
apply if the PS5R-V switching power supply was subject to:
1. Inappropriate handling, or operation beyond the specica-
tions.
2. Modication or repair by other than IDEC.
3. Failure caused by other than the PS5R-V switching power
supply.
4. Failure caused by natural disasters.
www.idec.com
USA IDEC Corporation Tel: [phone] [email protected]
Germany
IDEC Electrotechnik GmbH Tel: [phone] - 0 [email protected]
Singapore IDEC Izumi Asia Pte. Ltd. Tel: [phone]
[email protected]
Thailand IDEC Asia (Thailand) Co., Ltd Tel: [phone] [email protected]
Australia IDEC Australia Pty. Ltd. Tel:
[phone] [email protected]
Taiwan IDEC Taiwan Corporation Tel: [phone] ser[email protected]
Hong Kong IDEC Izumi (H.K.) Co., Ltd. Tel: [phone]
[email protected]
China/Shanghai IDEC (Shanghai) Corporation Tel: + 86-21-6135-1515 [email protected]
China/Shenzhen IDEC (Shenzhen) Corporation Tel: [phone] [email protected]
China/Beijing IDEC (Beijing) Corporation Tel: [phone] [email protected]
Japan IDEC Corporation Tel:
[phone] [email protected]
Specications and other descriptions in this brochure are subject to change without notice.
2017 IDEC Corporation, All Rights Reserved.
EP1591-5 MARCH 2017
Head Office
6-64, Nishi-Miyahara-2-Chome, Yodogawa-ku, Osaka 532-0004, Japan
