Idemia MTop Slim V3 User manual

Document version: V1.4
MTop Slim (V3) - Installation guide
Product version
Module version
Mobile version

2/13
CONTENTS
INTRODUCTION.................................................................................................................................................................3
RECOMMENDATIONS.......................................................................................................................................................3
General precautions......................................................................................................................................................3
Cleaning precautions....................................................................................................................................................3
Warning..........................................................................................................................................................................3
SAFETY INSTRUCTIONS ..................................................................................................................................................4
Europe information.......................................................................................................................................................4
Caution...........................................................................................................................................................................4
USA information............................................................................................................................................................4
GENERAL DESCRIPTION .................................................................................................................................................5
Product version:............................................................................................................................................................5
Module Version: ............................................................................................................................................................6
Mobile version...............................................................................................................................................................6
RECOMMENDED DEVICE INSTALLATION (ONLY FOR PRODUCT VERSION) ............................................................7
Example of integration for ergonomic acquisitions...................................................................................................7
Example of an integration with product surface protection......................................................................................9
TECHNICAL CHARACTERISTICS ..................................................................................................................................10
Product version...........................................................................................................................................................10
Module version............................................................................................................................................................10
Mobile version.............................................................................................................................................................11
Operating conditions..................................................................................................................................................12
Software Environments..............................................................................................................................................12
SUPPORT.........................................................................................................................................................................13
For basic needs: self-service mode...........................................................................................................................13
For technical issues: Customer Care Center............................................................................................................13
For security features queries.....................................................................................................................................13

3/13
INTRODUCTION
We thank you for choosing a fingerprint acquisition terminal from IDEMIA.
The MTop Slim provides an effective solution for the fingerprint acquisition of 4 fingers
simultaneously, of two thumbs and of rolled fingers.
Among a range of alternative biometric technologies, the use of fingerprints has significant
advantages: each fingerprint constitutes an unalterable physical signature which develops
before birth and preserves until death.
The MTop Slim stands out as a fast, precise, easy-to-use and ideal system for the fingerprint
acquisition applications.
The MTop Slim has the following characteristics:
High quality TFT sensor (500 PPI IQS Appendix F certified),
Compact size for easy installation and fast integration,
Intuitive and easy-to-use Interface,
Open architecture, with dedicated applications implemented via the MLS SDK and
MBop SDK.
USB device (USB2 , compatible USB3)
To ensure the most effective use of your MTop Slim, we recommend that you read this
Installation Guide thoroughly.
RECOMMENDATIONS
General precautions
Do not put sharp hard object (such as but not limited to screw-driver, pen, USB
connector,..) on the acquisition area. MTop Slim sensor is robust as a TFT screen can be, so
sharp objects could damage the sensor.
Do not attempt to repair the MTop Slim yourself. The manufacturer cannot be held responsible
for any damage/accident that may result from attempts to repair components. Any work carried
out by unauthorized staff will invalidate your warranty.
Do not expose the MTop Slim to extreme temperatures.
Due to electrostatic discharge, and depending on the environment, synthetic carpet should be
avoided in areas where the MTop Slim has been installed.
Cleaning precautions
MTop Slim is designed with anti-Smudge coating, for easier clean purpose. Clean periodically latent
trace with a dry wipe dedicated to optic or TFT screen part; no hard water (acidic/alkaline/ type of
detergent solvent). If necessary use ethyl alcohol.
Warning
The manufacturer cannot be held responsible if the above recommendations are not followed or if the
MTop Slim is incorrectly used.

4/13
SAFETY INSTRUCTIONS
This product is planned for being installed according to the EN IEC 62368-1:2020 + A11: 2020. The power
supply is carried out by the standard USB link of the PC with a nominal voltage of 5V DC (as shown on the
product label: 5V ).
Europe information
Hereby declares that the MTop Slim has been tested and found compliant with the following
standards as required by the EMC Directive:
2014/30/EU
Directive of the European parliament and of the council of 26
February 2014 on the harmonisation of the laws of the Member
States relating to electromagnetic compatibility
2011/65/EU
2015/863/EU
Directive of the European Parliament and of the Council of 8 June
2011 on the restriction of the use of certain hazardous substances in
electrical and electronic equipment
Caution This product is a Class A device. In a residential environment, this device may cause
interference. In this case, the user is encouraged to try to correct the interference with
appropriated measures.
USA information
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.

5/13
GENERAL DESCRIPTION
Product version:
Acquisition Status indicators
Orange means harder
pression on related finger is
requested
Acquisition surface
Roll acquisition surface
Acquisition type indicators
2 mounting holes for M3 screw
USB trapdoor, to be able to
change USB cable if necessary.
Tightening torque of associated
screws (*4): 0.2 Nm

6/13
Module Version:
Mobile version
The USB cable of the mobile version has a USB-C connector
Micro USB2 connector
Roll acquisition surface
Roll acquisition surface

7/13
RECOMMENDED DEVICE INSTALLATION (ONLY FOR PRODUCT
VERSION)
Example of integration for ergonomic acquisitions
To optimize the ergonomic of Thumb acquisition, it is advised to set up the product a bit over the table (and
fixed on the table, thanks to the 2 mounting holes defined just before), as shown below or using a riser (part
number 293775646)
Example of integration for ergonomic acquisitions
Drawing to drill the table:

8/13
Use two M3 screws to maintain the product to the table. Choose a screw length = table
thickness + 3 to 5.5mm. Fix them gently without exceeding max force of 0.9 Nm, and with M3
washers (1,1 mm thickness +/-0,1 mm) between the terminal and the support

9/13
Example of an integration with product surface protection
Figure 1: example of integration into a kiosk
Product
Transparent
protective element

10/13
TECHNICAL CHARACTERISTICS
Product version
Device Configuration
MTOP Slim R: Slap and roll Finger Print scanner, at 500 ppi IQS Appendix F certified, with VERIF
license
Part Number
The MTOP Slim R is identified by a part number 293764669 –“MTOP Slim R V3 (x1)”
Man Machine Interface
Two-colored LEDs & Buzzer
Acquisition area 3’’x3.2’’
USB2 device (integrated cable with USB-A connector, can be change if needed)
Size and weight
Volume (L*W*H) = 14,5 x 13 x 2,6 cm3 (5.7 x 5.1 x 1”)
Weight ~ 0.4 Kg
Power consumption
Operating (acquisition) ~ 1.25 W
Idle (backlight switched off) ~ 0.6 W
Suspend (USB link closed) ~12.5 mW
Module version
Device Configuration
MTOP Slim module: Slap and roll Finger Print scanner, at 500 ppi IQS Appendix F certified, with
VERIF license
Part Number
The MTOP Slim module is identified by a part number 293775881 - “MTOP Slim Module V3 package
(x54)”
Man Machine Interface
Acquisition area 3’’x3.2’’
Micro USB 2 connector, for data and power supply
Size and weight
Volume (L*W*H) = 10,4 x 9,9 x 1,3 cm3 (4.1 x 3.9 x 0.5”)
Weight ~ 0.2 Kg
Power consumption
Operating (acquisition) ~ 1.1 W
Idle (backlight switched off) ~0.6 W
Suspend (USB link closed) ~12.5 mW

11/13
Mobile version
Device Configuration
MTOP Slim mobile: Slap and roll Finger Print scanner, at 500 ppi IQS Appendix F certified, with
VERIF license
Part Number
The MTOP Slim module is identified by a part number 293790445- “MTOP Slim Mobile PR
(emballé)”
Man Machine Interface
Acquisition area 3’’x3.2’’
USB2 device (integrated cable with USB-C connector, can be change if needed)
Size and weight
Volume (L*W*H) = 12.8 x 11.7x 2.7 cm3 (5.0 x 4.6 x 1.06”)
Weight ~ 0,32g
Power consumption
Operating (acquisition) ~ 1.1 W
Idle (backlight switched off) ~0.6 W
Suspend (USB link closed) ~12.5 mW

12/13
Operating conditions
Operating
Temperature: -10°C to +50°C.
Relative Humidity:10%<RH<80%.
Storage
-40°C to +70°C.
RH < 90%.
Light
We recommend the MTop Slim installation within controlled lighting
conditions (300-1500 Lux). Avoid direct exposure of sensor to sunlight or
intensive UV lights. Both may degrade the performances of the sensor on a
long time period (even when device not powered).
Ground connection
Make sure that the ground connection of your computer is correctly done
(connected to earth), otherwise terminal might be sensible to electric noise
Software Environments
Android 10, 11 and 12
Microsoft Windows 10 (32 and 64 bits). Windows 11 (Mid-2023)
Ubuntu (from 14 to 20.04 LTS) (64 bits)
Nominal PC HW configuration is I5 Core with 4 GB RAM
It is highly recommended to have at least 2 USB controllers:
-1 for MTop Slim
-1 for other devices behind a USB Hub

13/13
SUPPORT
For basic needs: self-service mode
Biometric Devices Portal : https://biometricdevices.idemia.com/
Technical guides, datasheets, bulletins, firmwares…
For technical issues: Customer Care Center
USA & Canada
Email : support.bioterminals.us@idemia.com
Phone : +1 888 940 7477
LATAM (Latin America)
Email : support.bioterminals.us@idemia.com
Phone: +1 714 575 2973
EMEA (Europe, Middle East & Africa)
Email : support.bioterminals@idemia.com
Phone: +33 1 30 20 30 40
APAC (Asia & Pacific)
Phone : +91 8929 159 665
India
Phone: +91 1800 120 203 020
For security features queries
Copyright ©2023 IDEMIA
www.idemia.com
