IEI Technology LCD-KIT-F Series User manual

LCD-KIT-F
Page i
User Manual
MODEL:
LCD-KIT-F Series
12.1" ~ 19" Open Frame LCDMonitor
VGA, DVI-D, RoHS
Rev. 1.00 – 6 June, 2016

LCD-KIT-F
Page ii
Revision
Date Version Changes
6 June, 2016 1.00 Initial release

LCD-KIT-F
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

LCD-KIT-F
Page iv
ManualConventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.
HOT SURFACE
This symbol indicates a hot surface that should not be touched without
taking care.

LCD-KIT-F
Page v
Table ofContents
1 INTRODUCTION........................................................................................................... 1
1.1 LCD-KIT-F SERIES LCD MONITOR OVERVIEW............................................................ 2
1.2 FEATURES ................................................................................................................... 2
1.3 MODEL VARIATIONS..................................................................................................... 3
1.4 APPLICATIONS............................................................................................................. 4
1.5 EXTERNAL OVERVIEW .................................................................................................. 4
1.5.1 Front View.......................................................................................................... 4
1.5.2 Rear View........................................................................................................... 4
1.5.3 Connectors......................................................................................................... 5
1.6 SERIES SPECIFICATIONS............................................................................................... 6
1.7 CERTIFICATIONS.......................................................................................................... 7
2 MECHANICAL OVERVIEW......................................................................................... 8
2.1 INTRODUCTION ........................................................................................................... 9
2.2 REAR PANEL................................................................................................................ 9
2.3 CONNECTOR PANEL ..................................................................................................... 9
2.3.1 Available Connectors....................................................................................... 10
2.4 PHYSICAL DIMENSIONS.............................................................................................. 10
2.4.1 General Physical Dimensions.......................................................................... 10
2.4.2 LCD-KIT-F-12A Physical Dimensions .............................................................11
2.4.3 LCD-KIT-F-15A Physical Dimensions ............................................................ 12
2.4.4 LCD-KIT-F-17A Physical Dimensions ............................................................ 13
2.4.5 LCD-KIT-F-19A Physical Dimensions ............................................................ 14
2.5 MOUNTING HOLES.................................................................................................... 15
3 LCD SPECIFICATIONS.............................................................................................. 16
3.1 LCD SPECIFICATIONS ............................................................................................... 17
3.1.1 LCD-KIT-F12A LCD Specifications ................................................................ 17
3.1.2 LCD-KIT-F15A LCD Specifications ................................................................ 17
3.1.3 LCD-KIT-F17A LCD Specifications................................................................ 18

LCD-KIT-F
Page vi
3.1.4 LCD-KIT-F19A LCD Specifications................................................................ 19
3.2 POWER ADAPTERS..................................................................................................... 20
3.3 9~36VDC MODULE ................................................................................................. 20
4 AD BOARD ................................................................................................................... 21
4.1 AD BOARD OVERVIEW............................................................................................... 22
4.2 AV-60381 AD BOARD ............................................................................................... 22
4.2.1 AV-60381 Peripheral Interface Connectors..................................................... 22
4.2.2 Backlight Inverter Connector (INVERTER1) .................................................. 23
4.2.3 LVDS Connector (LVDS1)............................................................................... 24
4.2.4 OSD Keypad Connector (KEYPAD1) .............................................................. 24
4.2.5 Power Input Connector (PWR2)...................................................................... 25
4.2.6 RS-232 Connector for Touchscreen (RS232_1) ............................................... 25
4.2.7 USB Connector for Touchscreen (USB_TOUCH1) ......................................... 25
4.2.8 Touchscreen Connector (J1) ............................................................................ 25
4.2.9 VGA Connector (VGA2)................................................................................... 26
4.2.10 Backlight Voltage Select Jumper (JP5).......................................................... 26
4.2.11 LVDS Panel Voltage Select Jumper (JP2)...................................................... 26
4.2.12 Power Input Setting Jumper (JP4)................................................................. 27
4.2.13 Touchscreen Type Select Jumper (JP1).......................................................... 27
5 INSTALLATION........................................................................................................... 28
5.1 INSTALLATION PRECAUTIONS ..................................................................................... 29
5.2 UNPACKING............................................................................................................... 30
5.2.1 Packaging ........................................................................................................ 30
5.2.2 Unpacking Procedure ...................................................................................... 30
5.2.3 Packing List ..................................................................................................... 31
5.3 PRE-INSTALLATION PREPARATION............................................................................... 32
5.3.1 Tools................................................................................................................. 32
5.4 CONNECTORS............................................................................................................ 32
5.4.1 VGA Connector................................................................................................ 33
5.4.2 DVI-D Connector............................................................................................. 33
5.4.3 12V Power Connector...................................................................................... 34
5.4.4 9 V~36 V Terminal Block (Optional) ............................................................... 34
5.4.5 RS-232 for Touch Panel Connector ................................................................. 35

LCD-KIT-F
Page vii
5.4.6 USB for Touch Panel Connector...................................................................... 36
5.5 MOUNTING THE LCD-KIT-F SERIES LCD MONITOR.................................................. 36
5.5.1 Panel Mounting................................................................................................ 36
6 ON-SCREEN-DISPLAY (OSD) CONTROLS ............................................................. 41
6.1 OSD KEYPAD ............................................................................................................ 42
6.2 OSD MENU STRUCTURE............................................................................................ 43
6.3 USING THE OSD........................................................................................................ 44
6.3.1 Image Menu ..................................................................................................... 44
6.3.1.1 Color Setting............................................................................................. 45
6.3.2 Display Menu................................................................................................... 46
6.3.3 System Menu .................................................................................................... 47
6.3.3.1 Input.......................................................................................................... 48
6.3.3.2 OSD Settings............................................................................................. 49
7 SOFTWARE DRIVER.................................................................................................. 50
7.1 INTRODUCTION ......................................................................................................... 51
7.2 RS-232 OR USB TOUCH SCREEN ............................................................................... 51
7.3 TOUCH PANEL DRIVER INSTALLATION......................................................................... 52
7.4 CHANGE THE TOUCH SCREEN INTERFACE................................................................... 55
7.5 CALIBRATING THE TOUCH SCREEN ............................................................................. 55
A REGULATORY COMPLIANCE.................................................................................. 58
B SAFETY PRECAUTIONS........................................................................................... 62
B.1 SAFETY PRECAUTIONS............................................................................................... 63
B.1.1 General Safety Precautions............................................................................. 63
B.1.2 Anti-static Precautions .................................................................................... 64
B.1.3 Product Disposal............................................................................................. 65
B.2 MAINTENANCE AND CLEANING PRECAUTIONS............................................................ 66
B.2.1 Maintenance and Cleaning.............................................................................. 66
B.2.2 Cleaning Tools................................................................................................. 66
C SMARTOSD.................................................................................................................. 68
C.1 IEI SMARTOSD QUICK INSTALLATION GUIDE ............................................................ 69
C.2 PRE-INSTALLATION NOTICE ....................................................................................... 69
C.3 SMARTOSD INSTALLATION......................................................................................... 69

LCD-KIT-F
Page viii
C.4 SOFTWARE ILLUSTRATION.......................................................................................... 72
C.4.1 Manage Page................................................................................................... 75
C.4.2 EDID Page...................................................................................................... 76
C.4.3 Image Page...................................................................................................... 77
C.4.4 Display Page (for analog signal).................................................................... 78
C.4.5 Color Page ...................................................................................................... 79
C.4.6 PIP Page.......................................................................................................... 80
C.4.7 System Page..................................................................................................... 81
C.4.8 About Page...................................................................................................... 82
C.5 SMARTOSD FAQ ...................................................................................................... 83
C.5.1 Windows 2000 Installation Failure ................................................................. 83
C.5.2 Vista Installation Failure................................................................................. 83
C.5.3 Model Failure.................................................................................................. 84
C.5.4 DDC Port Failure ........................................................................................... 85
D HAZARDOUS MATERIALS DISCLOSURE ............................................................ 86

LCD-KIT-F
Page ix
List of Figures
Figure 1 1: LCD-KIT-F Series.........................................................................................................2
Figure 1-2: Typical LCD-KIT-F Front View ...................................................................................4
Figure 1-3: Typical LCD-KIT-F Rear View.....................................................................................5
Figure 1-4: Typical LCD-KIT Connectors .....................................................................................6
Figure 2-1: Rear Panel....................................................................................................................9
Figure 2-2: LCD-KIT-F-12A Physical Dimensions (millimeters)...............................................11
Figure 2-3: LCD-KIT-F-15A Physical Dimensions (millimeters)...............................................12
Figure 2-4: LCD-KIT-F-17A Physical Dimensions (millimeters)...............................................13
Figure 2-5: LCD-KIT-F-19A Physical Dimensions (millimeters)...............................................14
Figure 4-1: AV-60381 AD Board Layout Diagram......................................................................22
Figure 5-1: VGA Connector .........................................................................................................33
Figure 5-2: DVI-D Connector .......................................................................................................34
Figure 5-3: 12V Power Connector...............................................................................................34
Figure 5-4: 3-pin Terminal Block.................................................................................................35
Figure 5-5: RS-232 Touch Panel Connector ..............................................................................35
Figure 5-6: USB Touch Panel Connector...................................................................................36
Figure 5-7: Mounting Clamps Holder..........................................................................................37
Figure 5-8: Mounting Clamps......................................................................................................37
Figure 5-9: Secure the Mounting Clamps Holders....................................................................38
Figure 5-10: Panel Mounting Clamp Position............................................................................38
Figure 5-11: Mounting Clamps Holder Dimensions..................................................................39
Figure 5-12: Ultra Set Plate Dimensions ....................................................................................39
Figure 5-13: Bolt Dimensions......................................................................................................39
Figure 5-14: Steering Button Dimensions..................................................................................40
Figure 6-1: OSD Keypad ..............................................................................................................42
Figure 6-2: Image Menu ...............................................................................................................44
Figure 6-3: Color Settings............................................................................................................45
Figure 6-4: Display Menu.............................................................................................................46
Figure 6-5: System Menu.............................................................................................................47
Figure 6-6: Input Options.............................................................................................................48

LCD-KIT-F
Page x
Figure 6-7: OSD Settings Menu...................................................................................................49
Figure 7-1: Setup Icon..................................................................................................................52
Figure 7-2: Welcome Screen .......................................................................................................53
Figure 7-3: License Agreement...................................................................................................53
Figure 7-4: Initiate Install .............................................................................................................54
Figure 7-5: Installation Starts......................................................................................................54
Figure 7-6: Finish Installation......................................................................................................55
Figure 7-7: PenMount Monitor Icon ............................................................................................56
Figure 7-8: PenMount Monitor Popup Menu..............................................................................56
Figure 7-9: Configuration Screen................................................................................................56
Figure 7-10: Calibration Initiation Screen ..................................................................................57
Figure 7-11: Calibration Screen ..................................................................................................57

LCD-KIT-F
Page xi
List of Tables
Table 1-1: LCD-KIT-F Series Model Variations ............................................................................3
Table 2-1: General Physical Dimensions ...................................................................................10
Table 2-2: Mounting Holes...........................................................................................................15
Table 3-1: LCD-KIT-F12A LCD Specifications ...........................................................................17
Table 3-2: LCD-KIT-F15A LCD Specifications ...........................................................................18
Table 3-3: LCD-KIT-F17A LCD Specifications ...........................................................................19
Table 3-4: LCD-KIT-F19A LCD Specifications ...........................................................................19
Table 3-5: Power Adapter Specifications...................................................................................20
Table 3-6: 9~36V DC Module Specifications..............................................................................20
Table 4-1: AV-60381 Peripheral Interface Connectors..............................................................23
Table 4-2: Backlight Inverter Connector (INVERTER1) Pinouts..............................................24
Table 4-3: LVDS Connector (LVDS1) Pinouts............................................................................24
Table 4-4: OSD Keypad Connector (KEYPAD1) Pinouts..........................................................24
Table 4-5: Power Input Connector (PWR2) Pinouts..................................................................25
Table 4-6: RS-232 Connector for Touchscreen (RS232_1) Pinouts ........................................25
Table 4-7: USB Connector for Touchscreen (USB_TOUCH1) Pinouts....................................25
Table 4-8: Touchscreen Connector (J1) Pinouts.......................................................................26
Table 4-9: VGA Connector (VGA2) Pinouts ...............................................................................26
Table 4-10: Backlight Voltage Select Jumper (JP5) Pinouts....................................................26
Table 4-11: LVDS Panel Voltage Select Jumper (JP2) Pinouts................................................26
Table 4-12: Power Input Setting Jumper (JP4) Pinouts............................................................27
Table 4-13: Touchscreen Type Select Jumper (JP1) Pinouts..................................................27
Table 5-1: Rear Panel Connectors..............................................................................................33
Table 5-2: VGA Connector Pinouts.............................................................................................33
Table 5-3: DVI-D Connector Pinouts...........................................................................................34
Table 5-4: RS-232 Touch Panel Connector Pinouts..................................................................35
Table 5-5: USB Touch Panel Connector Pinouts ......................................................................36
Table 6-1: OSD Control Buttons..................................................................................................42
Table 6-2: OSD Menu Structure...................................................................................................43
Table C-1: SmartOSD Menu Structure........................................................................................74

LCD-KIT-F
Page 1
Chapter
1
1Introduction

LCD-KIT-F
Page 2
1.1 LCD-KIT-F Series LCD Monitor Overview
Figure 1 1: LCD-KIT-F Series
The LCD-KIT-F series LCD monitor is the latest member of IEI’s line of sophisticated
LCD designs, and it has been improved to be RoHS compliant. It is designed to fit
industrial automation, or any other applications that require minimum installation space
and flexible configuration. Flexible analog or digital interfaces are provided for ease of
connection with a management computer. If remote/non-attentive control is preferred,
RS-232 or USB interfaces can be used with customized adapter cables.
1.2 Features
The LCD-KIT-F series have the following standard features:
12.1"~19"open frame architecture for embedded integration
Over 350cd/m² high brightness and 50000hrs MTFB long lifetime panel
Analog VGA or digital DVI interfaces support most of general systems
Various touch panel solution : Resistive / Resistive touch windows / PCAP
multi-touch
Optional 9-36V DC module
-20°C~60°C extended operating temperature
Support software OSD for remote control applications

LCD-KIT-F
Page 3
1.3 Model Variations
The LCD-KIT-F series offer the following model variations.
Model Number Description
LCD-KIT-F12A-R10 12.1" 600 cd/m² XGA open frame monitor, VGA and DVI-D input, R10
LCD-KIT-F15A-R10 15" 450 cd/m² XGA open frame monitor, VGA and DVI-D input, R10
LCD-KIT-F17A-R10 17" 350 cd/m² SXGA open frame monitor, VGA and DVI-D input, R10
LCD-KIT-F19A-R10 19" 350 cd/m² SXGA open frame monitor, VGA and DVI-D input, R10
LCD-KIT-F12A/R-R10 12.1" 600 cd/m² XGA open frame monitor, VGA and DVI-
D input, Resistive
touch screen RS-232/USB interface,R10
LCD-KIT-F15A/R-R10 15" 450 cd/m² XGA open frame monitor, VGA and DVI-D input, Resistive
touch screen RS-232/USB interface,R10
LCD-KIT-F17A/R-R10 17" 350 cd/m² SXGA open frame monitor, VGA and DVI-
D input, Resistive
touch screen RS-232/USB interface,R10
LCD-KIT-F19A/R-R10 19" 350 cd/m² SXGA open frame monitor, VGA and DVI-
D input, Resistive
touch screen RS-232/USB interface,R10
LCD-KIT-F12A/TW-R10 12.1" 600 cd/m² XGA open frame monitor, VGA and DVI-
D input, Resistive
touch window RS-232/USB interface,R10
LCD-KIT-F15A/TW-R10 15" 450 cd/m² XGA open frame monitor, VGA and DVI-D input, Resistive
touch window RS-232/USB interface,R10
LCD-KIT-F17A/TW-R10 17" 350 cd/m² SXGA open frame monitor, VGA and DVI-
D input, Resistive
touch window RS-232/USB interface,R10
LCD-KIT-F19A/TW-R10 19" 350 cd/m² SXGA open frame monitor, VGA and DVI-
D input, Resistive
touch window RS-232/USB interface,R10
LCD-KIT-F12A/PC-R10 12.1" 600 cd/m² XGA open frame monitor, VGA and DVI-
D input, Projected
capacitive touch window USB interface,R10
LCD-KIT-F15A/PC-R10 15" 450 cd/m² XGA open frame monitor, VGA and DVI-D input, Projected
capacitive touch window USB interface,R10
LCD-KIT-F17A/PC-R10 17" 350 cd/m² SXGA open frame monitor, VGA and DVI-
D input, Projected
capacitive touch window USB interface,R10
LCD-KIT-F19A/PC-R10 19" 350 cd/m² SXGA open frame monitor, VGA and DVI-
D input, Projected
capacitive touch window USB interface,R10
Table 1-1: LCD-KIT-F Series Model Variations

LCD-KIT-F
Page 4
1.4 Applications
IEI’s series of LCD monitors are designed for system manufacturers, integrators, or
value-added resellers that want to provide all the performance, quality and reliability of an
LCD display solution at a cost effective price. IEI’s LCD kits offer additional components
such as cables, an inverter and power supply with controller interfaces that include VGA
and DVI.
1.5 External Overview
The following sections describe the physical layout of the LCD-KIT-F series LCD monitors.
1.5.1 Front View
The front of the LCD-KIT-F series LCD monitor is a flat panel TFT LCD screen attached to
a metal chassis. 362HFigure 1-2 shows a typical LCD-KIT-F front view.
Figure 1-2: Typical LCD-KIT-F Front View
1.5.2 Rear View
The rear of the LCD-KIT-F series LCD monitor is a metal chassis. An on screen display
(OSD) control button panel, if present, is located vertically on the left side of the chassis
with the following control buttons:
LCD On/Off

LCD-KIT-F
Page 5
Auto
Left
Right
Menu
The OSD panel also has one power LED.
363HFigure 1-3 shows a typical LCD-KIT-F rear panel.
Figure 1-3: Typical LCD-KIT-F Rear View
1.5.3 Connectors
Each LCD-KIT series LCD monitor has a number of interface connectors on the I/O panel
of the chassis (when viewing the rear panel). 364HFigure 1-4 shows a typical LCD-KIT-F
connector panel. Each model may include or exclude additional connectors. Refer to
Section 365H2.3 for listings of LCD-KIT-Fs and their connectors. All connectors are fully
described in Section 366H5.4.

LCD-KIT-F
Page 6
Figure 1-4: Typical LCD-KIT Connectors
1.6 Series Specifications
The table below shows the LCD-KIT-F Series specifications.
Model LCD-KIT-F12A LCD-KIT-F15A LCD-KIT-F17A LCD-KIT-F19A
LCD Size 12.1" 15” 17” 19"
Resolution 1024 x 768 1024 x 768 1280 x 1024 1280 x 1024
Brightness (cd/m2) 600 450 350 350
Contrast Ratio 700:1 800:1 800:1 1000:1
Display Color 16.2M 16.2M 16.7M 16.7M
Pixel Pitch (mm) 0.24 0.297 0.264 0.294
Viewing Angle (H/V) 160°/140° 160°/150° 170°/160° 170°/160°
AD Board AV-60381
Input Interface Analog VGA, DVI-D, RS-232/USB(Optional for Touch)
Touchscreen &
controller
Resistive type 5-wire single touch / Penmount 6000 or Projected capacitive 2-point touch /
EETI EXC7200 (Assembly by adhesive tape)
OSD function 5 Key OSD
Smart-OSD Yes
Dimensions
(W x H x D mm) 323.8 x 263.8 x 40.3 380.1 x 304.6 x 43.2 410 x 343 x 49.4 449 x 374 x 49.45

LCD-KIT-F
Page 7
Model LCD-KIT-F12A LCD-KIT-F15A LCD-KIT-F17A LCD-KIT-F19A
Operating Temperature -20°C~60°C
Storage
Temperature -20°C~70°C
Humidity 10% to 95% (non-condensing)
Input Voltage 12VDC, 9~36V(Optional, with LCD-KIT-F-936160-R10)
Construction Material sheet metal rear cover SPCC
Mounting Panel Mount, Rear Mount, VESA 100
1.7 Certifications
All LCD-KIT-F series LCD monitor models comply with the following international
standards:
RoHS
For a more detailed description of these standards, please refer to Appendix D.

LCD-KIT-F
Page 8
Chapter
2
2MechanicalOverview

LCD-KIT-F
Page 9
2.1 Introduction
This chapter describes the general mechanical overview of the LCD-KIT-F series LCD
monitors including rear panel variations, available interfaces and overall dimensions.
2.2 Rear Panel
The following models of the LCD-KIT-F series LCD monitor have an OSD control panel
located vertically along the left side of the rear panel:
LCD-KIT-F12A
LCD-KIT-F15A
LCD-KIT-F17A
LCD-KIT-F19A
370HFigure 2-1 shows the location of the rear panel OSD controls.
Figure 2-1: Rear Panel
2.3 Connector Panel
All external peripheral interface connectors are located on the rear panel of the LCD-KIT-F
series LCD monitor. The following sections describe the rear panel variants and their
associated connectors.
