IEI Technology NANO-LX User manual

NANO-LX EPIC SBC
Page I
User Manual
NANO-LX EPIC SBC User Manual
MODEL:
NANO-LX
EPIC AMD® Geode LX 800 SBC with VGA/LVDS/TFT
Single GbE, SATA RAID, USB 2.0 and Audio
Rev. 1.23 – August 22, 2017

NANO-LX EPIC SBC
Page II
Revision
Date Version Changes
August 22, 2017 1.22 Updated the following sections:
Section 2.3: Data Flow
Section 4.2.23: Serial Communications Connector
Section 5.6.3: UART Port A RS-422/485 Select Jumper
August 17, 2017 1.22 Clarified Section 4.2.23: Serial Communications
Connector
July 6, 2010 1.21 Modified CN13 connector diagram
April 9, 2009 1.20 Changed SATA controller to VIA VT6421A
Added SATA power connector (CN38)
Updated BIOS section.
May 2007 1.10 - Added notice for LCD panel voltage select jumper (JP7).
- Added dimension drawings.
- Changed the document format.
April 2007 1.01 - Updated AMD VGA driver installation (Section 6.2)
August 2006 1.00 Initial release

NANO-LX EPIC SBC
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

NANO-LX EPIC SBC
Page IV
Packing List
NOTE:
If any of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the NANO-LX motherboard from or contact an
IEI sales representative directly. To contact an IEI sales representative,
please send an email to [email protected].
The items listed below should all be included in the NANO-LX motherboard package.
NANO-LX single board computer
IDE flat cable 44p/44p
RS-232 cables
Audio cable
Power cable
Keyboard/Mouse Y cable
SATA cables
SATA power cables
Mini jumper Pack
Quick Installation Guide
Utility CD
Images of the above items are shown in Chapter 3.

NANO-LX EPIC SBC
Page V
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 NANO-LX CPU BOARD OVERVIEW.......................................................................... 2
1.1.1 NANO-LX CPU Board Applications.................................................................. 2
1.1.2 NANO-LX CPU Board Benefits......................................................................... 2
1.1.3 NANO-LX CPU Board Features........................................................................ 3
1.2 NANO-LX SBC OVERVIEW ...................................................................................... 4
1.2.1 NANO-LX CPU Board Connectors.................................................................... 5
1.2.2 Technical Specifications..................................................................................... 6
1.3 COMPATIBLE OPERATING SYSTEMS AND MEMORY MODULES .................................... 7
1.3.1 Operating System............................................................................................... 8
1.3.2 Memory Module................................................................................................. 8
2 DETAILED SPECIFICATIONS.................................................................................. 9
2.1 OVERVIEW................................................................................................................ 10
2.2 DIMENSIONS............................................................................................................. 10
2.2.1 Board Dimensions............................................................................................ 10
2.2.2 External Interface Panel Dimensions...............................................................11
2.3 DATA FLOW ...............................................................................................................11
2.4 CPU SUPPORT .......................................................................................................... 12
2.4.1 AMD®Geode™ LX800 500MHz Overview..................................................... 12
2.4.2 AMD®Geode™ LX800 Memory Support........................................................ 13
2.4.3 AMD®Geode™ LX800 500MHz Display Support.......................................... 13
2.4.4 AMD®Geode™ LX800 500MHz Graphics Processor.................................... 13
2.4.5 AMD®Geode™ LX800 500MHz Power Management.................................... 15
2.5 SYSTEM CHIPSET...................................................................................................... 15
2.5.1 GeodeLink™ Interface Unit............................................................................. 15
2.5.2 AMD®Geode™ CS5536 ATA-6 Controller..................................................... 16
2.5.3 AMD®Geode™ CS5536 Audio Codec 97 (AC’97) Controller ....................... 16
2.5.4 AMD®Geode™ CS5536 Flash Interface ........................................................ 18
2.5.5 AMD®Geode™ CS5536 USB Controller........................................................ 18
2.5.6 AMD®Geode™ CS5536 Serial Communications........................................... 18
2.5.7 AMD®Geode™ CS5536 Real Time Clock....................................................... 19

NANO-LX EPIC SBC
Page VI
2.5.8 BIOS................................................................................................................. 19
2.6 GEODELINK™PCI BRIDGE ..................................................................................... 19
2.6.1 Overview.......................................................................................................... 19
2.6.2 10/100M Ethernet ............................................................................................ 20
2.6.3 PCI to ISA Bridge ............................................................................................ 21
2.7 ENVIRONMENTAL AND POWER SPECIFICATIONS ....................................................... 21
2.7.1 System Monitoring ........................................................................................... 21
2.7.2 Operating Temperature and Temperature Control........................................... 22
2.7.3 Power Consumption......................................................................................... 22
3 UNPACKING............................................................................................................... 23
3.1 ANTI-STATIC PRECAUTIONS ...................................................................................... 24
3.2 UNPACKING .............................................................................................................. 24
3.2.1 Unpacking Precautions.................................................................................... 24
3.3 UNPACKING CHECKLIST ........................................................................................... 25
3.3.1 Package Contents............................................................................................. 25
3.4 OPTIONAL ITEMS ...................................................................................................... 27
4 CONNECTORS AND JUMPERS.............................................................................. 28
4.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 29
4.1.1 NANO-LX SBC Layout..................................................................................... 29
4.1.2 Peripheral Interface Connectors ..................................................................... 30
4.1.3 Rear Panel Connectors.................................................................................... 32
4.1.4 Onboard Jumpers............................................................................................. 32
4.2 INTERNAL PERIPHERAL CONNECTORS ...................................................................... 33
4.2.1 ATX Connector................................................................................................. 33
4.2.2 ATX Power Button............................................................................................ 34
4.2.3 Audio CD-In Connector................................................................................... 34
4.2.4 Audio Connector .............................................................................................. 35
4.2.5 Battery Connector............................................................................................ 36
4.2.6 CompactFlash® Connector............................................................................. 37
4.2.7 Digital Input Output Connector....................................................................... 40
4.2.8 Fan Connector................................................................................................. 40
4.2.9 FDD Connector ............................................................................................... 41
4.2.10 IDE Interface Connector................................................................................ 43
4.2.11 Inverter Connector......................................................................................... 44

NANO-LX EPIC SBC
Page VII
4.2.12 Infrared Connector ........................................................................................ 45
4.2.13 Keyboard/Mouse Connector.......................................................................... 46
4.2.14 LED Power Connector................................................................................... 47
4.2.15 LVDS LCD Panel Connector......................................................................... 48
4.2.16 Parallel Port Connector ................................................................................ 49
4.2.17 PC/104-Plus Connector................................................................................. 50
4.2.18 Power Connector........................................................................................... 53
4.2.19 Power Input Connector.................................................................................. 54
4.2.20 Reset Button Connector ................................................................................. 55
4.2.21 SATA Drive Ports........................................................................................... 56
4.2.22 SATA Power Connector.................................................................................. 57
4.2.23 Serial Communications Connector................................................................ 58
4.2.24 TFT TTL LCD Connector............................................................................... 59
4.3 EXTERNAL (REAR PANEL)CONNECTORS.................................................................. 61
4.3.1 RS-232 Serial Connector (COM1)................................................................... 62
4.3.2 VGA Connector................................................................................................ 63
4.3.3 Ethernet Connector.......................................................................................... 63
4.3.4 USB Combo Connectors.................................................................................. 64
4.3.5 Keyboard/Mouse Connector............................................................................ 65
5 INSTALLATION AND CONFIGURATION ............................................................ 66
5.1 ANTI-STATIC PRECAUTIONS ...................................................................................... 67
5.2 INSTALLATION CONSIDERATIONS.............................................................................. 68
5.2.1 Installation Notices.......................................................................................... 68
5.2.2 Installation Checklist....................................................................................... 69
5.3 UNPACKING .............................................................................................................. 70
5.3.1 Unpacking Precautions.................................................................................... 70
5.3.2 Unpacking Checklist........................................................................................ 70
5.4 SO-DIMM INSTALLATION ....................................................................................... 71
5.5 CF CARD INSTALLATION .......................................................................................... 72
5.6 JUMPER SETTINGS .................................................................................................... 73
5.6.1 LCD Panel Shift Clock Jumper........................................................................ 74
5.6.2 COM1/2 Port RI and Voltage Selection Jumper (Optional)............................ 75
5.6.3 UART Port A RS-422/485 Select Jumper......................................................... 75
5.6.4 AT/ATX Power Mode Select Jumper................................................................ 76
5.6.5 PC/104-Plus VIO Voltage Select Jumper......................................................... 77

NANO-LX EPIC SBC
Page VIII
5.6.6 PC/104-Plus SERIRQ Select Jumper............................................................... 77
5.6.7 LCD Panel (LVDS/TTL) Voltage select Jumper............................................... 78
5.7 CHASSIS INSTALLATION............................................................................................ 78
5.7.1 Airflow.............................................................................................................. 78
5.7.2 Motherboard Installation................................................................................. 79
5.8 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 79
5.8.1 Peripheral Device Cables................................................................................ 79
5.8.2 ATA Flat Cable Connection ............................................................................. 80
5.8.3 AT Power Connection...................................................................................... 81
5.8.4 Audio Kit Installation....................................................................................... 82
5.8.5 Parallel Port Cable.......................................................................................... 83
5.8.6 Single RS-232 Cable........................................................................................ 84
5.8.7 SATA Drive Connection ................................................................................... 85
5.9 EXTERNAL PERIPHERAL INTERFACE CONNECTION ................................................... 87
5.9.1 LAN Connection (Single Connector)............................................................... 88
5.9.2 PS/2 Keyboard/Mouse Connection.................................................................. 88
5.9.3 Serial Device Connection ................................................................................ 90
5.9.4 USB Connection (Dual Connector)................................................................. 90
5.9.5 VGA Monitor Connection ................................................................................ 91
6 AWARD BIOS SETUP................................................................................................. 93
6.1 INTRODUCTION......................................................................................................... 94
6.1.1 Starting Setup................................................................................................... 94
6.1.2 Using Setup...................................................................................................... 94
6.1.3 Getting Help..................................................................................................... 95
6.1.4 Unable to Reboot After Configuration Changes.............................................. 95
6.1.5 Main BIOS Menu ............................................................................................. 95
6.2 STANDARD CMOS FEATURES .................................................................................. 98
6.2.1 IDE Primary Master/Slave ............................................................................ 100
6.3 ADVANCED BIOS FEATURES .................................................................................. 103
6.4 ADVANCED CHIPSET FEATURES .............................................................................. 109
6.4.1 Flat Panel Configuration................................................................................112
6.5 INTEGRATED PERIPHERALS......................................................................................114
6.6 POWER MANAGEMENT SETUP ................................................................................ 120
6.7 PNP/PCI CONFIGURATIONS .................................................................................... 121
6.8 PC HEALTH STATUS ............................................................................................... 126

NANO-LX EPIC SBC
Page IX
7 SOFTWARE DRIVERS............................................................................................ 128
7.1 AVAILABLE SOFTWARE DRIVERS ............................................................................ 129
7.2 AMD®VGA INSTALLATION ................................................................................... 131
7.3 AUDIO DRIVER INSTALLATION ............................................................................... 140
7.4 LAN DRIVER ......................................................................................................... 147
7.5 SATA/RAID DRIVER ............................................................................................. 151
7.6 ISA DRIVER ........................................................................................................... 155
A REGULATORY COMPLIANCE............................................................................ 161
B PRODUCT DISPOSAL............................................................................................ 163
C BIOS CONFIGURATION OPTIONS..................................................................... 165
C.1 BIOS CONFIGURATION OPTIONS ........................................................................... 166
D WATCHDOG TIMER .............................................................................................. 169
E ADDRESS MAPPING .............................................................................................. 172
E.1 I/O ADDRESS MAP ................................................................................................. 173
E.2 IRQ ADDRESS MAP ............................................................................................... 175
E.3 MEMORY ADDRESS MAP........................................................................................ 175
F CONNECTINGAN ATX POWER SUPPLY.......................................................... 176
F.1.1 Using ATX Power Switch............................................................................... 177
F.1.2 Using AT Power Supply ................................................................................. 179
G HAZARDOUS MATERIALS DISCLOSURE....................................................... 180

NANO-LX EPIC SBC
Page X
List of Figures
Figure 1-1: NANO-LX EPIC SBC....................................................................................................2
Figure 1-2: NANO-LX CPU Board Overview (Front Side) ...........................................................4
Figure 1-3: NANO-LX CPU Board Overview (Solder Side) .........................................................4
Figure 2-1: NANO-LX Dimensions (mm) ....................................................................................10
Figure 2-2: External Interface Panel Dimensions (mm)............................................................11
Figure 2-3: Data Flow Block Diagram.........................................................................................12
Figure 4-1: Connector and Jumper Locations (Front Side) .....................................................29
Figure 4-2: Connector and Jumper Locations (Solder Side) ...................................................30
Figure 4-3: CN3 Connector Location..........................................................................................33
Figure 4-4: CN5 Connector Location..........................................................................................34
Figure 4-5: CN8 Connector Location..........................................................................................35
Figure 4-6: CN9 Connector Location..........................................................................................36
Figure 4-7: BT1 Connector Location ..........................................................................................37
Figure 4-8: CN35 Connector Location........................................................................................39
Figure 4-9: CN18 Connector Location........................................................................................40
Figure 4-10 CN4 Connector Location.........................................................................................41
Figure 4-11: CN34 Connector Location......................................................................................42
Figure 4-12: CN13 Connector Location......................................................................................44
Figure 4-13: CN26 Connector Location......................................................................................45
Figure 4-14: CN32 Connector Location......................................................................................46
Figure 4-15: CN30 Connector Location......................................................................................47
Figure 4-16: CN12 Connector Location......................................................................................48
Figure 4-17: CN23 Connector Location......................................................................................49
Figure 4-18: CN20 Connector Location......................................................................................50
Figure 4-19: CN7 Connector Location........................................................................................53
Figure 4-20: CN2 Connector Location........................................................................................54
Figure 4-21: CN25 Connector Location......................................................................................55
Figure 4-22: CN6 Connector Location........................................................................................56
Figure 4-23: CN10, CN11 Connector Locations.........................................................................57
Figure 4-24: CN38 Connector Location......................................................................................58
Figure 4-25 CN14, CN15, CN16, CN17, CN19 Connector Locations........................................59

NANO-LX EPIC SBC
Page XI
Figure 4-26 CN22 Connector Locations.....................................................................................61
Figure 4-27: NANO-LX CPU Board Rear Panel..........................................................................62
Figure 4-28: COM1 Pinout Locations..........................................................................................62
Figure 4-29: CN24 Connector......................................................................................................63
Figure 4-30: CN27 Connector......................................................................................................64
Figure 4-31: CN31 Pinout locations............................................................................................65
Figure 5-1: SO-DIMM Installation................................................................................................71
Figure 5-2: CF Card Installation..................................................................................................72
Figure 5-3: Jumper Locations.....................................................................................................73
Figure 5-4: Jumper Locations.....................................................................................................74
Figure 5-5: IDE Cable Connection...............................................................................................80
Figure 5-6: Power Cable to Motherboard Connection..............................................................81
Figure 5-7: Connect Power Cable to Power Supply..................................................................82
Figure 5-8: Audio Kit Cable Connection.....................................................................................83
Figure 5-9: LPT Cable Connection..............................................................................................84
Figure 5-10: Connect the LPT Device.........................................................................................84
Figure 5-11: Single RS-232 Cable Installation ...........................................................................85
Figure 5-12: SATA Drive Cable Connection...............................................................................86
Figure 5-13: SATA Power Drive Connection..............................................................................87
Figure 5-14: LAN Connection......................................................................................................88
Figure 5-15: PS/2 Connector .......................................................................................................89
Figure 5-16: Serial Device Connector.........................................................................................90
Figure 5-17: USB Connector........................................................................................................91
Figure 5-18: VGA Connector .......................................................................................................92
Figure 7-1: AMD® LX/GX CD Main Menu................................................................................. 130
Figure 7-2: AMD® LX/GX CD Driver Menu .............................................................................. 130
Figure 7-3: Access Windows Control Panel ........................................................................... 131
Figure 7-4: Double Click the System Icon............................................................................... 132
Figure 7-5: Click the Device Manager Tab .............................................................................. 132
Figure 7-6: Device Manager List .............................................................................................. 133
Figure 7-7: Video Controller Properties Window ................................................................... 134
Figure 7-8: Hardware Update Wizard....................................................................................... 135
Figure 7-9: Install Options Window ......................................................................................... 135
Figure 7-10: Search Options Window...................................................................................... 136
Figure 7-11: Folder Selection Window .................................................................................... 136
Figure 7-12: Search Options Window...................................................................................... 137

NANO-LX EPIC SBC
Page XII
Figure 7-13: Hardware Update Wizard Search Window......................................................... 138
Figure 7-14: Windows Logo Testing Window......................................................................... 138
Figure 7-15: Driver Installation Window.................................................................................. 139
Figure 7-16: Driver Installation Complete Window ................................................................ 139
Figure 7-17: Device Manager Window..................................................................................... 140
Figure 7-18: Access Windows Control Panel ......................................................................... 141
Figure 7-19: Double Click the System Icon............................................................................. 142
Figure 7-20: Double Click the Device Manager Tab............................................................... 142
Figure 7-21: Device Manager List ............................................................................................ 143
Figure 7-22: Search for Suitable Driver................................................................................... 144
Figure 7-23: Locate Driver Files............................................................................................... 145
Figure 7-24: Location Browsing Window................................................................................ 146
Figure 7-25: Locate the Setup Program Icon.......................................................................... 147
Figure 7-26: Preparing Setup Screen ...................................................................................... 147
Figure 7-27: Install Wizard Welcome Screen.......................................................................... 148
Figure 7-28: Installing Screen ..................................................................................................149
Figure 7-29: Restart the Computer .......................................................................................... 150
Figure 7-30: Preparing Setup Screen ...................................................................................... 151
Figure 7-31: Install Wizard Welcome Screen.......................................................................... 152
Figure 7-32: Components to Install ......................................................................................... 152
Figure 7-33: Confirm the Installing Component List.............................................................. 153
Figure 7-34: Installing Screen ..................................................................................................153
Figure 7-35: InstallShield Wizard Complete Screen............................................................... 154
Figure 7-36: Access Windows Control Panel ......................................................................... 155
Figure 7-37: Double Click the System Icon............................................................................. 156
Figure 7-38: Double Click the Device Manager Tab............................................................... 156
Figure 7-39: Device Manager List ............................................................................................ 157
Figure 7-40: Search for Suitable Driver................................................................................... 158
Figure 7-41: Locate Driver Files............................................................................................... 159
Figure 7-42: Location Browsing Window................................................................................ 160

NANO-LX EPIC SBC
Page XIII
List of Tables
Table 1-1: Technical Specifications..............................................................................................7
Table 1-2: Compatible Memory Modules......................................................................................8
Table 2-1: Geode LX Graphics Features ....................................................................................15
Table 2-2: Supported HDD Specifications..................................................................................16
Table 2-3: Power Consumption...................................................................................................22
Table 3-1: Package List Contents...............................................................................................26
Table 3-2: Package List Contents...............................................................................................27
Table 4-1: Peripheral Interface Connectors...............................................................................31
Table 4-2: Rear Panel Connectors..............................................................................................32
Table 4-3: Onboard Jumpers.......................................................................................................32
Table 4-4: CN3 Connector Pinouts .............................................................................................33
Table 4-5: CN5 Connector Pinouts .............................................................................................34
Table 4-6: CN8 Connector Pinouts .............................................................................................35
Table 4-7: CN9 Connector Pinouts .............................................................................................36
Table 4-8: BT1 Connector Pinouts..............................................................................................37
Table 4-9: CN35 Connector Pinouts ...........................................................................................38
Table 4-10: CN18 Connector Pinouts .........................................................................................40
Table 4-11 CN4 Connector Pinouts.............................................................................................41
Table 4-12 CN4 Connector Pinouts.............................................................................................42
Table 4-13: CN13 Connector Pinouts .........................................................................................43
Table 4-14: CN26 Connector Pinouts .........................................................................................45
Table 4-15: CN32 Connector Pinouts .........................................................................................46
Table 4-16: CN30 Connector Pinouts .........................................................................................46
Table 4-17: CN12 Connector Pinouts .........................................................................................47
Table 4-18: CN23 Connector Pinouts .........................................................................................48
Table 4-19: CN20 Connector Pinouts .........................................................................................50
Table 4-20: CN7 (PC/104) Connector Pinouts............................................................................52
Table 4-21: CN7 (PCI-104) Connector Pinouts...........................................................................53
Table 4-22: CN2 Connector Pinouts ...........................................................................................53
Table 4-23: CN25 Connector Pinouts .........................................................................................54
Table 4-24: CN6 Connector Pinouts ...........................................................................................55
Table 4-25: CN10, CN11 Connector Pinouts..............................................................................56

NANO-LX EPIC SBC
Page XIV
Table 4-26: CN38 Connector Pinouts .........................................................................................58
Table 4-27: CN14, CN15, CN16, CN17 Connector Pinouts........................................................59
Table 4-28: CN19 Connector Pinouts .........................................................................................59
Table 4-29: CN22 Connector Pinouts .........................................................................................60
Table 4-30: COM1 Pinouts ...........................................................................................................62
Table 4-31: CN24 Connector Pinouts .........................................................................................63
Table 4-32: CN27 Connector Pinouts .........................................................................................64
Table 4-33: CN27 Connector LEDs .............................................................................................64
Table 4-34: CN28, CN29 Connector Pinouts..............................................................................65
Table 4-35: CN31 Pinouts ............................................................................................................65
Table 5-1: Jumpers.......................................................................................................................73
Table 5-2: JP1 Jumper Settings..................................................................................................75
Table 5-3: JP2 Jumper Settings..................................................................................................75
Table 5-4: JP3 Jumper Settings..................................................................................................76
Table 5-5: JP4 Jumper Settings..................................................................................................76
Table 5-6: JP5 Jumper Settings..................................................................................................77
Table 5-7: JP6 Jumper Settings..................................................................................................77
Table 5-8: JP7 Jumper Settings..................................................................................................78
Table 5-9: IEI Provided Cables....................................................................................................79
Table 6-1: BIOS Navigation Keys................................................................................................95

NANO-LX EPIC SBC
Page XV
List of BIOS Menus
BIOS Menu 1: AwardBIOS CMOS Setup Utility .........................................................................96
BIOS Menu 2: Standard CMOS Features....................................................................................98
BIOS Menu 3: IDE Primary Master ........................................................................................... 100
BIOS Menu 4: Advanced BIOS Features................................................................................. 103
BIOS Menu 5: Advanced Chipset Features............................................................................. 109
BIOS Menu 6: Flat Panel Configuration................................................................................... 112
BIOS Menu 7: Integrated Peripherals...................................................................................... 114
BIOS Menu 8: Power Management Setup ............................................................................... 120
BIOS Menu 9: PnP/PCI Configurations.................................................................................... 121
BIOS Menu 10: IRQ Resources ................................................................................................ 123
BIOS Menu 11: Memory Resources......................................................................................... 124
BIOS Menu 12: PC Health Status............................................................................................. 126

NANO-LX EPIC SBC
Page 1
Chapter
1
1 Introduction

NANO-LX EPIC SBC
Page 2
1.1 NANO-LX CPU Board Overview
Figure 1-1: NANO-LX EPIC SBC
The EPIC form factor NANO-LX AMD® Geode™ LX800 is a highly-integrated embedded
computer specifically optimized for multi-media applications requiring minimum installation
space. The NANO-LX is particularly suitable for low power and fan-less applications. The
NANO-LX supports a full range of functionality for an AT/ATX-compatible industrial
computer in a space-saving 3.5” profile. The NANO-LX is equipped with an on board
low-power consumption and high performance AMD® Geode™ LX800 processor. It also
contains a DDR SO-DIMM socket that supports up to 1GB memory in size.
1.1.1 NANO-LX CPU Board Applications
The NANO-LX SBC has been designed for use in industrial applications where board
expansion is critical and operational reliability is essential.
1.1.2 NANO-LX CPU Board Benefits
Some of the NANO-LX SBC benefits include,
operating reliably in harsh industrial environments with ambient temperatures
as high as 60°C
rebooting automatically if the BIOS watchdog timer detects that the system is
no longer operating

NANO-LX EPIC SBC
Page 3
1.1.3 NANO-LX CPU Board Features
Some of the NANO-LX SBC features are listed below:
Complies with RoHS
Supports AMD® GeodeLX800 500 MHz CPU
Supports up to 1GB of 400/333 MHz single channel DDR memory
Comes with one high performance gigabit Ethernet (GbE) controller
Supports two SATAchannels with transfer rates up to 150 MB/s and RAID 0, 1
support
Supports four USB 2.0 connectors

NANO-LX EPIC SBC
Page 4
1.2 NANO-LX SBC Overview
Figure 1-2: NANO-LX CPU Board Overview (Front Side)
Figure 1-3: NANO-LX CPU Board Overview (Solder Side)
