PulM Series
PulM-1G4T-I211
Networking Module Quick Installation Guide
Torx Screws x 2 Torx Wrench x 1
PulM-1G4T-I211
Package Contents
LAN Port
Link
LED
Speed
LED
PulM-1G4T-I211 Block Diagram
LAN LED Status
LED State Description
Link (Left) Yellow Active
Speed (Right) Orange 1 Gbps date rate
Green 100 Mbps data rate
A32 A19
B
A32 A19
A
Slot A
PCIe Conguration
x4
x8
x4
Slot B
PCIe Conguration
x4
x2 x2 x2 x2
x4
A19 A32 PCIe Cong. Slot
0 0 4x2 B
0 1 2x4 A & B
1 0 1x8 A
PCH
CPU
Hardware Installation
Install the PulM-1G4T-I211 networking module into the slot of the
PUZZLE series. The Slot A supports 8 lanes from CPU (1 PCIe x8 or
2 PCIe x4); the Slot B supports 8 lanes from PCH (2 PCIe x4 or 4 PCIe
x2). When the PulM-1G4T-I211 is installed into the Slot A, only two
LAN ports (port 1 & port 3) are active.
Four PCIe x2 or
Two PCIe x4
One PCIe x8 or
Two PCIe x4
DMI GEN3 x4
Slot A Slot B
Ethernet 1G
Ethernet 1G
Ethernet 1G
Ethernet 1G
Intel®
I211
Intel®
I211
Intel®
I211
PCIe 2.0
A19
A32
4 PCIe 2.0 x2
A19
0
A32PCIe CONF. MODE
0Four x2
Intel®
I211 RJ-45
RJ-45
RJ-45
RJ-45

Networking Module Installation
Use the Torx wrench to remove the two Torx screws. Remove the slot cover. Save the slot cover screws.
Slide an IEI networking module into the slot until the module
is seated in the slot correctly and securely.
1
Step 2 Step
3
Step
Install the previously-removed Torx screws to secure the module
to the chassis.
4
Step
