IEI Technology PUZZLE-9030 Series User manual

PUZZLE-9030
Page 1
User Manual
MODEL:
PUZZLE-9030
1U Network Appliance with AMD® EPYC™ Milan 7543 Processors,
Up to 4TB DDR4, M.2 NVMe, U.2 NVMe, Gen-Z 4C+ Interfaces,
Redundant 1300W PSU, Rack Mount, and RoHS Compliant
Rev. 1.00 –September 18, 2023

PUZZLE-9030
Page 2
Revision
Date
Version
Changes
September 18, 2023
1.00
Initial release

PUZZLE-9030
Page 3
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

PUZZLE-9030
Page 4
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.

PUZZLE-9030
Page 5
Table of Contents
1 INTRODUCTION........................................................................................................ 10
1.1 OVERVIEW.................................................................................................................11
1.2 FEATURES................................................................................................................. 12
1.3 FRONT PANEL........................................................................................................... 12
1.4 REAR PANEL ............................................................................................................ 13
1.5 TECHNICAL SPECIFICATIONS .................................................................................... 14
1.6 DIMENSIONS............................................................................................................. 16
2 UNPACKING ............................................................................................................... 17
2.1 ANTI-STATIC PRECAUTIONS...................................................................................... 18
2.2 UNPACKING PRECAUTIONS....................................................................................... 18
2.3 PACKING LIST .......................................................................................................... 19
2.4 OPTIONAL ITEMS ...................................................................................................... 19
3 INSTALLATION ......................................................................................................... 21
3.1 INSTALLATION PRECAUTIONS ................................................................................... 22
3.2 TOP COVER REMOVAL.............................................................................................. 23
3.3 DIMM INSTALLATION .............................................................................................. 24
3.4 HDD/SSD INSTALLATION ........................................................................................ 25
3.4.1 3.5" SATA HDD/SSD........................................................................................ 25
3.4.2 2.5" U.2 SSD .................................................................................................... 27
3.5 PCIE EXPANSION CARD INSTALLATION .................................................................... 29
3.6 IEI NETWORKING MODULE INSTALLATION .............................................................. 31
3.7 M.2 MODULE INSTALLATION.................................................................................... 33
3.8 LAN CONNECTION................................................................................................... 34
3.9 CONSOLE CONNECTION............................................................................................ 35
3.9.1 Enable Console Port When Booting ................................................................ 35
3.10 POWER-ON PROCEDURE......................................................................................... 38
3.11 AVAILABLE DRIVERS.............................................................................................. 39
3.11.1 Driver Download............................................................................................ 40
3.12 MAINTENANCE....................................................................................................... 41

PUZZLE-9030
Page 6
3.12.1 Power Supply Unit Replacement ................................................................... 42
3.12.2 Fan Module Replacement .............................................................................. 43
3.12.3 Jumper Settings.............................................................................................. 44
3.12.3.1 Clear CMOS............................................................................................ 44
4 INTERFACE CONNECTORS ................................................................................... 45
4.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 46
4.2 INTERNAL PERIPHERAL CONNECTORS ...................................................................... 46
4.2.1 BMC Debug Connector (DB1)......................................................................... 47
4.2.2 BMC Programming Connectors (J_BMC1) .................................................... 48
4.2.3 CPLD Programming Connector (J_CPLD1) .................................................. 48
4.2.4 Debug Port Connector (DBG_PORT1)........................................................... 48
4.2.5 EC Debug Connector (EC_DBG1).................................................................. 49
4.2.6 Fan Board Power Connector (FAN_PWR1).................................................... 49
4.2.7 Fan Board Connector (FAN1).......................................................................... 50
4.2.8 I/O Board Connectors (IO1, IO2).................................................................... 50
4.2.9 Power Button Connector (PWR_BTN1) .......................................................... 52
4.2.10 Power Input Connector (PSU1, PSU2) ......................................................... 52
4.2.11 Reset Button Connector (RST_BTN1)............................................................ 53
4.2.12 SATA Power Connector (SATA_PWR1, SATA_PWR2) .................................. 53
4.2.13 SPI Flash Connector (J_SPI1)....................................................................... 54
4.2.14 SPI Flash Connector - EC (J_EC1)............................................................... 54
4.2.15 TPM Connector (TPM1)................................................................................ 55
4.2.16 USB 2.0 Connector (JUSB1).......................................................................... 55
4.2.17 Networking Module Gen-Z 4C+ Slots (PCIE3, PCIE4, PCIE5, PCIE6) ...... 56
4.2.18 PCIe Riser Card Slot (PCIE1)....................................................................... 58
A REGULATORY COMPLIANCE .............................................................................. 63
B SAFETY PRECAUTIONS ......................................................................................... 68
B.1 SAFETY PRECAUTIONS............................................................................................. 69
B.1.1 General Safety Precautions ............................................................................. 69
B.1.2 Anti-static Precautions .................................................................................... 70
B.1.3 Product Disposal ............................................................................................. 71
B.2 MAINTENANCE AND CLEANING PRECAUTIONS ........................................................ 72
B.2.1 Maintenance and Cleaning.............................................................................. 72

PUZZLE-9030
Page 7
B.2.2 Cleaning Tools................................................................................................. 72
C ERROR BEEP CODE ................................................................................................ 73
C.1 PEI BEEP CODES ..................................................................................................... 74
C.2 DXE BEEP CODES ................................................................................................... 74
D HAZARDOUS MATERIALS DISCLOSURE ......................................................... 75
D.1 ROHS II DIRECTIVE (2015/863/EU) ....................................................................... 76
D.2 CHINA ROHS........................................................................................................... 77

PUZZLE-9030
Page 8
List of Figures
Figure 1-1: PUZZLE-9030 Series.................................................................................................11
Figure 1-2: PUZZLE-9030 Front Panel........................................................................................12
Figure 1-3: PUZZLE-9030 Rear Panel .........................................................................................13
Figure 1-4: Physical Dimensions (millimeters)..........................................................................16
Figure 3-1: Top Cover Removal ..................................................................................................23
Figure 3-2: DIMM Slot Locations.................................................................................................24
Figure 3-3: HDD Bracket Retention Screws...............................................................................25
Figure 3-4: Secure HDD to the Bracket ......................................................................................26
Figure 3-5: HDD Installation ........................................................................................................26
Figure 3-6: 3.5" HDD Bracket Retention Screws.......................................................................27
Figure 3-7: 2.5" SSD Bracket Retention Screws .......................................................................27
Figure 3-8: Secure SSD to the Bracket.......................................................................................28
Figure 3-9: SSD Installation.........................................................................................................28
Figure 3-10: Riser Card Module Retention Screws...................................................................29
Figure 3-11: Blank Bracket Screw...............................................................................................29
Figure 3-12: PCIe Expansion Card Installation..........................................................................30
Figure 3-13: Riser Card Module Installation..............................................................................30
Figure 3-14: Networking Module Slot Cover Removal..............................................................31
Figure 3-15: Inserting Networking Module.................................................................................32
Figure 3-16: Securing Networking Module ................................................................................32
Figure 3-17: RJ-45 Ethernet Connector......................................................................................34
Figure 3-18: Power-on..................................................................................................................38
Figure 3-19: IEI Resource Download Center..............................................................................39
Figure 3-20: Clear CMOS Button Location.................................................................................44

PUZZLE-9030
Page 9
List of Tables
Table 1-1: Technical Specifications............................................................................................15
Table 3-1: LAN Pinouts ................................................................................................................34
Table 3-2: RJ-45 Ethernet Connector LEDs...............................................................................34
Table 3-3: RJ-45 Serial Port Pinouts...........................................................................................35
Table 1-6: Clear BIOS Jumper Settings......................................................................................44
Table 4-1: Peripheral Interface Connectors...............................................................................47
Table 4-2: BMC Debug Connector (DB1) Pinouts .....................................................................47
Table 4-3: BMC Programming Connector (J_BMC1) Pinouts..................................................48
Table 4-4: CPLD Programming Connector (J_CPLD1) Pinouts...............................................48
Table 4-5: Debug Port Connector (DBG_PORT1) Pinouts........................................................49
Table 4-6: EC Debug Connector (EC_DBG1) Pinouts...............................................................49
Table 4-7: Fan Board Power Connector (FAN_PWR1) Pinouts ...............................................49
Table 4-8: Fan Board Connector (FAN1) Pinouts......................................................................50
Table 4-9: I/O Board Connectors (IO1) Pinouts.........................................................................51
Table 4-10: I/O Board Connectors (IO2) Pinouts.......................................................................52
Table 4-11: Power Button Connector (PWR_BTN1) Pinouts....................................................52
Table 4-12: Power Input Connector (PSU1, PSU2) Pinouts......................................................53
Table 4-13: Reset Button Connector (RST_BTN1) Pinouts......................................................53
Table 4-14: SATA Power Connector Pinouts.............................................................................53
Table 4-15: SPI Flash Connector (J_SPI1) Pinouts...................................................................54
Table 4-16: SPI Flash Connector - EC (J_EC1) Pinouts............................................................54
Table 4-17: TPM Connector (TPM1) Pinouts..............................................................................55
Table 4-18: USB 2.0 Connector (JUSB1) Pinouts......................................................................55
Table 4-19: Networking Module Gen-Z 4C+ Slot Pinouts.........................................................58
Table 4-20: PCIe Riser Card Slot (PCIE1) Pinouts.....................................................................62

PUZZLE-9030
Page 10
Chapter
1
1Introduction

PUZZLE-9030
Page 11
1.1 Overview
Figure 1-1: PUZZLE-9030 Series
The PUZZLE-9030 is a 1U network appliance series powered by two AMD® EPYC™
Milan 7543 processors, which is made for cybersecurity vendors that require faster CPU
performance to accelerate SD-WAN architecture, and secure access service edge (SASE)
solutions. It is also capable of supporting4TB system memory.
The PUZZLE-9030 supports four IEI network modules through Gen-Z 4C+ interfaces to
improve HPC, cloud and enterprise workload performance. In addition, it is equipped with
two PCIe Gen4 x16 slots for upgrading with expansion cards, such as NIC cards or
accelerator cards. Multiple storage interfaces for fast and stable data transmission are
offered, including two M.2 M key 2280 slots, two SATA 6Gb/s connectors for 3.5" HDD or
two U.2 connectors for 2.5" U.2 NVMe SSD.
WARNING:
This equipment is not suitable for use in locations where children are
likely to be present.

PUZZLE-9030
Page 12
1.2 Features
The PUZZLE-9030 features are listed below:
Powered by two AMD® EPYC™ Milan 7543 processors
Support 16 DDR4 3200 MHz ECC & register RDIMM/LRDIMM (system max.
4 TB)
Support multiple storage options, including M.2 NVMe SSD, U.2 NVMe SSD
and 2.5" SATA 6Gb/s SSD
Equipped four Gen-Z 4C+ connectors, supporting IEI PulM-100G2SF-CX6
network interface cards
Upgradable with future expansion cards by two PCIe Gen4 slots
One RJ-45 console port
Dual 1300W redundant power supply, 80+ platinum
Six hot-swappable fan modules
1U chassis for rack mounting
CE, FCC and RoHS compliant
1.3 Front Panel
The overview of the front panel is shown in Figure 1-2691H691H.
Figure 1-2: PUZZLE-9030 Front Panel

PUZZLE-9030
Page 13
1.4 Rear Panel
An overview of the PUZZLE-9030’s rear panel is shown in 691H691Figure 1-3Hbelow. The rear
panel also contains several LED indicators:
PSU LED
Fan module LED
Status LED (green)
Power LED (green)
Alert LED (red)
Figure 1-3: PUZZLE-9030 Rear Panel

PUZZLE-9030
Page 14
1.5 Technical Specifications
The PUZZLE-9030 technical specifications are listed in Table 1-1.
System
Form Factor
1U
CPU (SoC)
2 x AMD® EPYC™ Milan 7543
Chipset
Integrated in CPU
Memory
Technology: ECC & Register DDR4 3200 MHz memory, up to
256GB per DIMM
Capacity: RDIMM/LRDIMM, up to 4TB
Socket: 16 x 288-pin DIMM (8 DIMM/CPU), eight channels
IPMI
1 x AST2620 (RTL8211E)
Networking
Ethernet port: 1 x GbE RJ-45 via Intel® I211
Network module slot: 4 x Optional PulM-100G2SF-CX6 (Gen-Z
4C+, PCIe Gen4 x16, dual QSFP28, 1/10/25/40/50/100 Gb/s)
Storage
2 x M.2 M key 2280 (PCIe Gen4 x4)
2 x U.2 (PCIe Gen4 x4) or 2 x SATA 6Gb/s - (colay design)
Expansion
2 x PCIe Gen4 x16 slot (FHHL)
I/O and Indicators
Console
1 x RJ-45
USB
2 x USB 3.2 Gen 1 (5 Gb/s) port (external)
Indicator
Power LED (green)
Status LED (green)
Alert LED (red)
Fan module LED (green)
PSU LED (green)
Button
1 x Reset button
TPM
1 x TPM 2.0 (2x10 pin header)
Power
Power Input
AC power inlet on PSU AC 100V ~ 240V @47~63Hz

PUZZLE-9030
Page 15
Type/Watt
YM-2132EAR
90 ~ 132VAC @900W
100 ~ 132VAC @1000W
110 ~ 132VAC @1100W
180 ~ 264VAC @1300W
Processor Cooling
2 x CPU heatsink
System Cooling
6 x Individual hot-swappable cooling fans
Environmental and Mechanical
Mounting
1U rack mount
Operating Temperature
0C~40C (32F~104F)
Storage Temperature
-10°C~50°C (14°F~122°F)
Operating Humidity
5%~90%, non-condensing
Safety
RoHS, CE, FCC, UL
Weight
14.80 kg
Physical Dimensions
438 mm x 670 mm x 44.2 mm (W x D x H)
Operating System
Linux (CentOS, Red Hat, Ubuntu, etc.)
Table 1-1: Technical Specifications

PUZZLE-9030
Page 16
1.6 Dimensions
The physical dimensions are shown below:
Figure 1-4: Physical Dimensions (millimeters)

PUZZLE-9030
Page 17
Chapter
2
2Unpacking

PUZZLE-9030
Page 18
2.1 Anti-static Precautions
WARNING:
Failure to take ESD precautions during installation may result in
permanent damage to the PUZZLE-9030 and severe injury to the user.
Electrostatic discharge (ESD) can cause serious damage to electronic components,
including the PUZZLE-9030. Dry climates are especially susceptible to ESD. It is therefore
critical that whenever the PUZZLE-9030 or any other electrical component is handled, the
following anti-static precautions are strictly adhered to.
Wear an anti-static wristband: Wearing a simple anti-static wristband can
help to prevent ESD from damaging the board.
Self-grounding: Before handling the board, touch any grounded conducting
material. During the time the board is handled, frequently touch any
conducting materials that are connected to the ground.
Use an anti-static pad: When configuring the PUZZLE-9030, place it on an
anti-static pad. This reduces the possibility of ESD damaging the
PUZZLE-9030.
2.2 Unpacking Precautions
When the PUZZLE-9030 is unpacked, please do the following:
Follow the anti-static precautions outlined in Section 2.1.
Make sure the packing box is facing upwards so the PUZZLE-9030 does not
fall out of the box.
Make sure all the components shown in Section 2.3 are present.

PUZZLE-9030
Page 19
2.3 Packing List
NOTE:
If some of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the PUZZLE-9030 from or contact an IEI sales
representative directly. To contact an IEI sales representative, please
send an email to [email protected].
The PUZZLE-9030 is shipped with the following components:
Quantity
Item
1
PUZZLE-9030
2
Power cord
1
USB to console cable
2.4 Optional Items
The following table lists the optional items that can be purchased separately.
Optional Item
Sliding rails
(P/N: 45009-0019C0-00-RS)

PUZZLE-9030
Page 20
Optional Item
USB to console cable
(P/N: 32013-004000-100-RS)
RS-232 to console cable
(P/N: 32005-005100-100-RS)
