IFM VSE153 Application guide

Device manual
Diagnostic electronics
with Modbus TCP interface
for vibration sensors
VSE153
80270599/00 03/2019
UK

2
Contents
1 Preliminary note � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
1�1 Symbols used� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
2 Safety instructions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4
3 Documentation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
4 Functions and features � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
5 Sensor functions� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 5
5�1 Firmware � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 6
5�2 Functional overview � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 7
6 Installation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
6�1 Sources of interference � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
6�2 Cable routing in control cabinets � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9
6�3 Installation instructions � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9
7 Electrical connection� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9
7�1 Wiring � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
7�2 Connection of the sensors � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
7�3 Ethernet connection � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �11
8 Modbus TCP� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �11
8�1 Characteristics Modbus TCP � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �11
8�2 Modbus TCP data model � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 12
8�3 Register � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
8�3�1 Modbus TCP device identification register� � � � � � � � � � � � � � � � � � � � 15
8�4 Modbus TCP register mapping input (FC4) � � � � � � � � � � � � � � � � � � � � � � � 15
8�5 Modbus TCP input function code � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 15
8�6 Modbus TCP register mapping output (FC3, FC6 and FC16) � � � � � � � � � 15
8�7 Modbus TCP output function code � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16
8�8 Modbus TCP exception response � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16
9 Factory setting � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16
9�1 General factory setting � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 16
9�2 Factory setting VSE153 - Modbus TCP � � � � � � � � � � � � � � � � � � � � � � � � � � 16
10 Parameter setting � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 17
11 Operating and display elements � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 17
11�1 Sensor operating states � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 18
11�2 Operating states for the status LEDs on the industrial Ethernet ports 1
and 2 � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 18
11�3 Operating states of the network (NET) and mode (MOD) status LED � � 18
12 Maintenance, disposal � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 19

UK
3

4
1 Preliminary note
Technical data, approvals, accessories and further information at
www�ifm�com�
1.1 Symbols used
Symbols
►Instruction
> Reaction, result
[…] Designation of keys, buttons or indications
→Cross-reference
Important note
Non-compliance may result in malfunction or interference�
Information
Supplementary note
2 Safety instructions
●Read this document before setting up the product and keep it during the entire
service life�
●The product must be suitable for the corresponding applications and
environmental conditions without any restrictions�
● Only use the product for its intended purpose (→ Functions and features).
●If the operating instructions or the technical data are not adhered to, personal
injury and/or damage to property may occur�
●The manufacturer assumes no liability or warranty for any consequences
caused by tampering with the product or incorrect use by the operator�
●Installation, electrical connection, set-up, operation and maintenance of the
product must be carried out by qualified personnel authorised by the machine
operator�
●Protect units and cables against damage�
●The design of the device corresponds to protection class III (EN61010) except
for the terminal blocks� Protection against accidental contact (safety from finger
contact to IP 20) for qualified personnel is only ensured if the terminals have
been completely inserted� Therefore the unit must always be mounted in a
control cabinet of at least IP 54 which can only be opened using a tool�

UK
5
●For DC units the external 24 V DC supply must be generated and supplied
according to the requirements for safe extra-low voltage (SELV) since this
voltage is provided near the operating elements and at the terminals for the
supply of sensors without further protection measures�
3 Documentation
This documentation relates to the hardware and firmware status at the time of
editing this manual� The features of the devices are continuously developed further
and improved�
4 Functions and features
The devices have been designed for use in applications described in this manual
and the device-specific data sheets�
Adhere to the data indicated in the data sheets and in the manual� If the handling
specifications and safety instructions for configuration, installation and operation
indicated in the documentation are adhered to, the devices normally do not lead to
a danger for persons and objects�
5 Sensor functions
The diagnostic electronics has
– 2 analogue inputs
– 4 dynamic inputs
– 1 analogue or digital output
– 1 digital output
– 1 TCP/IP parameter setting interface
– 2 Modbus TCP ports
An analogue current signal (0/4…20 mA) or a pulse signal (HTL) can be
connected to the analogue inputs�
The analogue inputs can be used
– as trigger for measurements (e�g� rotational speed for vibration diagnostics)
– as trigger of a counter
– for process monitoring
VSA, VSP or standard IEPE acceleration sensors can be connected to the
dynamic inputs�

6
The dynamic inputs can be used for
– vibration monitoring
– vibration diagnostics
– analysis of other dynamic signals
Alternatively, the dynamic inputs can also be used like an analogue input with an
analogue current signal (4���20 mA)�
The hardware outputs can be configured as 2 x binary (NO/NC) or as 1 x analogue
(0/4…20 mA) and 1 x binary (NO/NC)�
The outputs can be used for
– time-critical alarms (e�g� machine protection, response time up to 1 ms)
– alarm output
– analogue value output of values measured by the diagnostic electronics
The parameter setting interface (TCP/IP) is used for the communication between
the diagnostic electronics and a PC (e�g� VES004 parameter setting software)�
The parameter setting interface can be used for
– parameter setting of the device
– online data monitoring
– reading the history memory
– firmware update
The Modbus TCP ports are used for the communication between the diagnostic
electronics and a Modbus TCP client/master (e�g� PLC)�
The Modbus TCP interface can be used for
– transferring the current measured values, limits and alarm states of the
diagnostic electronics to the PLC
– reading the counter readings of the diagnostic electronics
– writing rotational speeds and other values from the PLC to the diagnostic
electronics
– writing teach values from the PLC to the diagnostic electronics
The device is not approved for safety-related tasks in the field of operator
protection�
5.1 Firmware
►Recommendation: Install the firmware to use all device functions�
The firmware can only be updated via the VES004 PC software� Only the firmware
of the entire device can be updated�

UK
7
Firmware and operating software → download area www.ifm.com
A description of all firmware parameters and their meaning → VES004 PC
software manual�
5.2 Functional overview
With the device
– vibration monitoring (total vibration to ISO)
– condition monitoring (condition-based monitoring on the basis of vibration
characteristics)
– machine protection/process monitoring (monitoring vibration characteristics
in real time with a very fast response time up to 1 ms)
can be implemented�
Monitoring of
– up to 24 objects (indicators for different machine parts, vibration
characteristics or process values)
– dynamic values within the time range (e�g� v-RMS to ISO)
– dynamic values within the frequency range FFT or HFFT (e�g� imbalance or
rolling element bearing)
– process values (analogue signals) for current value above or below the limit
The device has an internal history memory (600,000 values) with real-time clock
and flexible memory interval per object� The memory is a ring memory (FIFO)�
Up to 32 counters can be configured to measure the duration of exceeding the
limit and/or operating times�
The signals at the inputs are permanently picked up and continuously monitored
according to the set parameters�
With objects within the frequency range (imbalance, rolling element bearing ���) the
multiplex mode is used for monitoring�
With objects within the time range (v-RMS, a-RMS and a-Peak) all 4 dynamic
inputs are monitored simultaneously and without interruption�
The two outputs OU1/2 can be used for alarms� The respective object states per
sensor are also indicated via the 4 sensor LEDs�
The system LED displays the operating status of the device�
Parameter setting of the monitoring tasks and alarming is effected by the VES004
software� The software allows to display and record the current measured values,
spectra and time signals (online data)�
Via the Ethernet interface of the device, networking is possible to visualise data
(measured values, alarm states, ���) in other systems (e�g� SCADA, MES, ����)�

8
Data (e�g� measured values, alarm states, limits, rotational speeds, timer readings,
���) is exchanged between the diagnostic electronics and the Modbus TCP client/
master (e�g� PLC)�
6 Installation
►Mount the unit in a control cabinet with a protection rating of at least IP 54 to
ensure protection against accidental contact with dangerous contact voltages
and against atmospheric influence�
The control cabinet should be installed in accordance with local and national rules
and regulations�
►Mount the unit vertically on a DIN rail�
►Leave enough distance to neighbouring heat sources and between the unit and
the top or bottom of the control cabinet to enable air circulation and to avoid
excessive heating�
►Prevent the penetration of conductive or other dirt during installation and wiring�
When preparing for cable installation, the local conditions and the corresponding
mounting regulations are very important� Cables can be installed, for example, in
cable ducts or on cable bridges�
Data corruption and loss
A minimum distance between the cabling and possible sources of
interference (e�g�, machines, welding equipment, power lines) is defined
in the applicable regulations and standards� During system planning and
installation, these regulations and standards must be taken into account
and observed�
Protect the bus cables from sources of electric/magnetic interference and
mechanical strain�
Observe the following guidelines regarding "electromagnetic compatibility"
(EMC) to keep mechanical risks and interference to a minimum�
6.1 Sources of interference
Signal cables and power supply lines should not be installed in parallel�
►If necessary, metal isolating segments should be placed between the power
supply lines and signal cables�
►During installation, all connector locking mechanisms (screws, coupling nuts)
must be firmly tightened in order to ensure the best possible contact between
shielding and ground� Before initial startup, the ground or shielding connection
of cables must be checked for low-resistance continuity�

UK
9
6.2 Cable routing in control cabinets
►Install network/bus cables in separate cable ducts or separate cable bundles�
►Where possible, do not install network/bus cables parallel to power supply
lines�
►Install network/bus cables at least 10 cm away from power lines�
6.3 Installation instructions
Electrostatic discharge
The device contains components that can be damaged or destroyed by
electrostatic discharge�
►When handling the device, observe the necessary safety precautions against
electrostatic discharge (ESD) according to EN 61340-5-1 and IEC 61340-5-1�
►In order to eliminate electrostatic charges, the device may only be operated on
a grounded DIN rail�
7 Electrical connection
The national and international regulations for the installation of electrical
equipment must be adhered to� Avoid contact with dangerous contact voltages�
► Disconnect power.
► Connect device, connection via COMBICON connectors (pre-mounted).
► To prevent negative effects on the functions caused by noise voltages, lay
sensor cables and load cables separately� Maximum length of the sensor cable:
250 m�
►Use a screened sensor cable�
The outputs are short-circuit proof and can be configured as either normally closed
or normally open�
In addition an analogue signal can be provided on output [OU 1] (0/4���20 mA) (e�g�
acceleration values)�

10
7.1 Wiring
18
17
20
19
14
13
16
15
22
21
24
23
6
5
8
7
2
1
4
3
10
9
12
11
Supply L- (GND)
OU 1: switch/analog
OU 2: switch
IN 1 (0/4...20 mA / pulse)
GND 1
IN 2 (0/4...20 mA / pulse)
GND 2
1
2
3
4
4
3
2
1
1
2
3
4
1
2
3
4
Supply L+ (24 V DC ±20 %)
Sensor 1
Sensor 2
Sensor 3
Sensor 4
Wiring of 1���4 (S1���S4) according to the use of the sensors
Sensor VSA IEPE/VSP 0���20 mA
S1 S2 S3 S4
09 16 20 24 BN: L+ (+ 9 V) not connected
(n�c�)
not connected
(n�c�)
10 15 19 23 WH: signal IEPE + signal
11 14 18 22 BU: GND IEPE - GND
12 13 17 21 BK: test not connected
(n�c�)
not connected
(n�c�)
Terminal 1 supply L+
When using an IEPE input 24 V DC + 20% (Integrated Electronics Piezo
Electric)
The ground GND of the DC supply is directly connected to the ground GND
of the sensor supply� Therefore the SELV criteria have to be met for the DC
supply�
►Protect the supply voltage externally (max� 2 A)�
7.2 Connection of the sensors
Adhere to the SELV criteria (safety extra-low voltage, circuit electrically isolated
from other circuits, ungrounded) when the sensors are connected so that no
dangerous contact voltages are applied to the sensor or transferred to the device�

UK
11
If the DC circuit is to be grounded (e�g� due to national regulations), the PELV
criteria must be adhered to (protective extra-low voltage, circuit electrically isolated
from other circuits)�
Sensor and diagnostic electronics supply are not electrically isolated�
7.3 Ethernet connection
The RJ45 config socket is used for the connection to the Ethernet�
Ethernet cables can be supplied as accessories, e�g�:
cross-over cable, 2 m, article no� EC2080
cross-over cable, 5 m, article no� E30112
8 Modbus TCP
8.1 Characteristics Modbus TCP
Request Parameters
Register access only acyclical r/w
Register addressing based on 1
Transmission rate 100 Mbits/s, 10 Mbits/s
Protocols and minutes Modbus TCP/IP
Data format big-endian
Modbus TCP/IP
Max� input and output process image 1024 bytes (512 registers)
Configuration via PC with configuration tool: VES004
Max� number of socket connections 8x Modbus TCP
Register filing of the input data analogue input register 16 bits (r)
Register filing of the output data analogue holding register 16 bits (r/w)
Supported function codes FC3, FC4, FC6, FC16
Write max� byte length for registers 1���123 registers
Read max� byte length for registers 1���125 registers

12
8.2 Modbus TCP data model
Input (PLC)
Source Type Size Use
Analogue inputs (DC)
<input name> Real 4 bytes Value of the signal connected
to the analogue input (IN1, IN2)
External inputs
<input name> Real 4 bytes Value of the external input (External_xx)
Objects
Time domain
<object name>
Value Real 4 bytes Object value in SI unit (m/s², m/s)
State Byte 1 byte (Alarm) state of the object
0: OK
1: warning alarm
2: damage alarm
3: inactive
4: error (description: see Error)
Error Word 2 bytes Error code for object state
Hex0000: no error
Hex0001: internal error
Hex0002: calculation error
Hex0004: speed out of range
Hex0008: speed unstable
Hex0010: invalid base line
Hex0020: invalid reference value (1)
Hex0040: invalid reference value (2)
Hex0100: deactivated by signal weighting
Hex0200: reference value out of range
Hex1000: warning alarm
Hex2000: damage alarm
Hex8000: object inactive (by variant)
Rotational
speed
Real 4 bytes Trigger - rotational speed
Reference
value
Real 4 bytes Trigger - reference value
Warning
alarm
Real 4 bytes Limits - warning alarm (relative)
Damage
alarm
Real 4 bytes Limits - damage alarm (relative)
Base line Real 4 bytes Limits - base line in SI unit
(m/s², m/s)
Frequency domain
<object name>
Value Real 4 bytes Object value in SI unit (m/s², m/s, m)

UK
13
State Byte 1 byte (Alarm) state of the object
0: OK
1: warning alarm
2: damage alarm
3: inactive
4: error (description: see Error)
Error Word 2 bytes Error code for object state
Hex0000: no error
Hex0001: internal error
Hex0002: calculation error
Hex0004: speed out of range
Hex0008: speed unstable
Hex0010: invalid base line
Hex0020: invalid reference value (1)
Hex0040: invalid reference value (2)
Hex0100: deactivated by signal weighting
Hex0200: reference value out of range
Hex1000: warning alarm
Hex2000: damage alarm
Hex8000: object inactive (by variant)
Rotational
speed
Real 4 bytes Trigger - rotational speed
Reference
value
Real 4 bytes Trigger - reference value
Warning
alarm
Real 4 bytes Limits - warning alarm (relative)
Damage
alarm
Real 4 bytes Limits - damage alarm (relative)
Base line Real 4 bytes Limits - base line in SI unit (m/s², m/s, m)
Upper/lower limit monitor
<object name>
Value Real 4 bytes Object value in SI unit (m/s², m/s, m)
State Byte 1 byte (Alarm) state of the object
0: OK
1: warning alarm
2: damage alarm
3: inactive
4: error (description: see Error)
Error Word 2 bytes Error code for object state
Hex0000: no error
Hex0001: internal error
Hex0002: calculation error
Hex0004: speed out of range
Hex0008: speed unstable
Hex0010: invalid base line
Hex0020: invalid reference value (1)
Hex0040: invalid reference value (2)
Hex0100: deactivated by signal weighting
Hex0200: reference value out of range
Hex1000: warning alarm
Hex2000: damage alarm
Hex8000: object inactive (by variant)

14
Rotational
speed
Real 4 bytes Trigger - rotational speed
Reference
value
Real 4 bytes Trigger - reference value
Warning
alarm
Real 4 bytes Limits - warning alarm (relative)
Damage
alarm
Real 4 bytes Limits - damage alarm (relative)
Counter
<counter name> DINT 4 bytes Counter value (in seconds)
Alarms
<alarm name> Byte 1 byte Alarm state (0, 1)
General
Variant Byte 1 byte Current variant (0���31)
System mode Byte 1 byte System mode:
0 : self-test
1: supervise (normal monitoring)
2: set-up (parameter setting)
3: measure (spectrum, raw data)
4: start-up (system booting)
Self-test result Byte 1 byte Binary bit pattern
0: sensors OK
1: sensor 1 self-test failed
2: sensor 2 self-test failed
4: sensor 3 self-test failed
8: sensor 4 self-test failed
Current queue level Byte 1 byte Current level of the fieldbus
communication
Queue overflow counter DINT 4 bytes Overflow counter of the fieldbus
communication
Checksum error counter DINT 4 bytes Checksum error counter of the fieldbus
communication
Output (PLC)
External inputs
<input name> Real 4 bytes Set value of the external input (Exter-
nal_xx)
Objects
<object name>
Base line Real 4 bytes Limits - set base line in SI unit (m/s², m/s,
m) to adapt the limits
General
Variant Byte 1 byte Set current variant (0���31)
Do self-test Byte 1 byte Do self-test (≠ 0)

UK
15
Set time DINT 4 bytes Set time, always UTC, format:
- VSE150: U32: 0x00ssmmhh
- VSE151: U32: 0x00hhmmss
- VSE152: U32: 0x00hhmmss
- VSE153: U32: 0x00hhmmss
Set counter ID Byte 1 byte Set ID (1���32) of the counter
Set counter value DINT 4 bytes Set value of the counter selected with the
ID (in seconds)
8.3 Register
8.3.1 Modbus TCP device identication register
Address Access Length
(word)
Request Parameter
39000 R 30 vendor name "ifm electronic"
39030 R 20 product name "VSE153"
39050 R 2 production status of
the unit
"AA"
39052 R 10 firmware version "V1�0�0"
39062 R 2 serial Number defined in the product process
39064 R 20 short description
device
diagnostic electronics VSE153
8.4 Modbus TCP register mapping input (FC4)
Register no. IEC61131 address Access Memory area
30001…30512 %IW0…%IW511 r input area
8.5 Modbus TCP input function code
function code Parameter
Code 4 (dec) read input register
8.6 Modbus TCP register mapping output (FC3, FC6 and FC16)
Register no. IEC61131 address Access Memory area
40001…40512 %QW0…%QW511 r/w output area

16
8.7 Modbus TCP output function code
Function code Description
Code 3 (dec) read holding register
Code 6 (dec) write single holding register
Code 16 (dec) write multiple holding register
8.8 Modbus TCP exception response
The following exception codes are supported by VSE153
Function code Name
Code 01 Illegal function
Code 02 Illegal data address
Code 03 Illegal data value
Code 04 Server device failure
9 Factory setting
9.1 General factory setting
Request Parameter
Parameter set none
Host name no name assigned
IP address 192�168�0�1
TCP/IP port 3321
Subnet mask 255�255�255�0
Default gateway 192�168�0�244
MAC address defined in the production process
9.2 Factory setting VSE153 - Modbus TCP
There is read and write access to the device settings� The following default values
are set by the factory:
Request Parameter
IP address 192�168�0�100
Subnet mask 255�255�255�0
Gateway 192�168�0�244
Port 502

UK
17
10 Parameter setting
The device parameters are set exclusively via the VES004 PC software� All
parameters of the configured application are bundled in a parameter set and
transferred to the device�
For a detailed description of all parameters and possible configurations we refer
you to the VES004 software manual�
11 Operating and display elements
For quick identification of error states, the device has two diagnostic LEDs on the
device front�
13
LED 1
LED 2
LED 3
LED 4
LED 5
LED 7
LED 6
2
1: Config: TCP/IP, IP address 192�168�0�1 (factory setting), parameter setting and data interface (e�g�
VES004)
2: IE 1: Modbus TCP
3: IE 2: Modbus TCP

18
11.1 Sensor operating states
LED 1 for sensor 1... LED 4 for sensor 4
Green on sensor connected and configured
Green flashing sensor is configured;
type VSA: sensor is not connected or faulty
type IEPE: sensor is not connected
Yellow on warning alarm
Red on main alarm
Green/yellow flashing alternately teach process active
Yellow/red flashing alternately no parameter set loaded
11.2 Operating states for the status LEDs on the industrial Ethernet ports
1 and 2
VSE153 has two industrial Ethernet ports (RJ45 sockets) with one integrated link
and activity LED each�
Designation Colour Status Description
Link green on connected at ports 1/2
green off not connected at ports 1/2
Activity yellow flashing data transfer at ports 1/2
yellow OFF no data
transfer at
ports 1/2
device functions reliably
(normal operation)
11.3 Operating states of the network (NET) and mode (MOD) status LED
Designation Description Colour Status Description
NET (LED 6) Network status n�a� off device is switched off
(no supply voltage)
or no IP address
green flashing
(approx� 2
Hz)
no connection has been
established,
an IP address was assigned
green on device connected to the network
red on error on the fieldbus

UK
19
Designation Description Colour Status Description
MOD (LED 7) Modbus TCP/IP
status
n�a� off device is switched off
(no voltage supply)
green on device functions reliably
(normal operation)
red on device error
orange flashing firmware image is loaded to the
RAM
orange on firmware image is written to the
flash
green flashing 2 s
(approx� 2
Hz)
firmware image has been written
correctly to the flash
orange flashing 2 s
(approx� 2
Hz)
parameter set was successful
transferred
12 Maintenance, disposal
The unit is maintenance-free�
►Dispose of the device including the battery in accordance with the national
environmental regulations�
