IGS Golden Master User manual

1
Table of Contents
1. Hardware....................................................................................3
Hardware Connection .......................................................................................3
Connecting Touch Panel ................................................................................... 4
Connection Diagram .........................................................................................5
DIP Switch Settings........................................................................................... 6
36 & 10 PIN Button Layout................................................................................7
Solving Ticket SSR Error...................................................................................7
Reset.................................................................................................................8
2. Bookkeeping & Adjustment....................................................11
Access Flow Chart .......................................................................................... 11
System Settings ..............................................................................................12
Chance Settings..............................................................................................14
Touch Screen Calibration................................................................................14
3. Introduction .............................................................................15
Common Features ..........................................................................................15
Lobby...............................................................................................................15
4. (Game 1) Golden Buffalo ........................................................16
Game Rule......................................................................................................16
Feature Game.................................................................................................17
Bonus Game...................................................................................................19
Free Game......................................................................................................20
Jackpot............................................................................................................21
Line Chart........................................................................................................22
5. (Game 2) Fire 7’s......................................................................23
Game Rule......................................................................................................23
All Up Feature ................................................................................................. 24
Devil Symbol ...................................................................................................25
Wild Feature....................................................................................................26
Grand Wheel Bonus........................................................................................27
Jackpot............................................................................................................28
Line Chart........................................................................................................29

2
6. (Game 3) Golden Fortune .......................................................30
Game Rule......................................................................................................30
Respin Feature................................................................................................31
Wild Feature....................................................................................................32
Choose A Game..............................................................................................33
Free Game......................................................................................................34
Step By Step....................................................................................................36
Jackpot............................................................................................................38
Line Chart........................................................................................................39

3
1.Hardware
Hardware Connection
36-Pin Connector
Audio Jack
SD Card Slot
10-Pin Connector
COM 1. RS-232
Connects to printer/ticket dispenser.
* Use Belkin #F2L044 (serial printer cable/null modem) for printer.
COM 2. RS-232
Connects to Micro Touch
compatible touch screen
+5V
+5V Power output
HDMI port
Connects to screen
COM 3. RS-232
Connects to Bill Acceptor

4
Connecting Touch Panel
Refer to the diagram below to connect the touch screen.
Golden Master supports only touch screen interface. Please make sure that the
touch screen is well-connected before operating
The resolution of this game is Full HD. Please confirm that a monitor supports
Full HD resolution.
The interface of a monitor can only use HDMI connector.

5
Connection Diagram
36 Pins (6 Buttons)
10 Pins (6 Buttons)
PARTS SIDE
SOLDER SIDE
PARTS SIDE
SOLDER SIDE
1
GND
1
GND
SPEAKER_R
2
GND
2
GND
SPEAKER_L
3
GND
+5V
3
+5V
4
+5V
4
+5V
5
+12V
5
+12V
6
HOP-VCC
6
TICKET OUT
7
TICKET SSR
7
TICKET SWITCH
8
START / ALL STOP
9
8
SMALL
10
START / ALL STOP
GND
9
GND
PLAY
11
GND
10
GND
TAKE
12
DOUBLE
13
14
15
BIG
16
17
COIN A
18
KEY IN
19
COIN C
RECORD
20
TEST
21
KEY OUT/PRINTER OUT
22
COIN A METER
23
KEY IN METER
24
25
COIN C METER
26
OUT METER
27
28
LAMP: START/ALL STOP
29
LAMP: SMALL
30
LAMP:PLAY
31
LAMP: COUNT
LAMP: TAKE
32
LAMP: DOUBLE
33
LAMP: BIG
34
35
GND
36
GND

6
DIP Switch Settings
DIP SWITCH 2
1
2
3
4
5
6
7
8
BILL ACCEPTOR
MODE
PLUSE
OFF
RS232
ON

7
36 & 10 PIN Button Layout
2 Buttons
COLLECT
START
ALL STOP
TAKE
Solving Ticket SSR Error
After powering on the machine, if the ticket dispenser keeps working and can’t be
stopped, it could be that the Ticket SSR’s jump setting is incorrect.
How to solve:
1. Locate the Ticket SSR jump (JP5) on the PC board. Then identify current
TICKET SSR is at HIGH ACTIVE or LOW ACTIVE.
2. Change to use the alternative JP5 setting.
JP5
Low Active
3 2 1
Short pins 1-2
High Active (Default)
3 2 1
Short pins 2-3

8
Reset
1. Power off the machine and then power on.
2. Press and hold the【TEST】button until the game enters the CHECKING
SYSTEM page.
3. Enter the「TEST」page.
4. Press the【PLAY】button to enter the「TEST 2」PAGE (PAGE 2).

9
5. Press the【STOP3】button to enter the「RESET」page.
6. Press the【PLAY】button to RESET the game to default value.

10
7. Press the【PLAY】button again to confirm RESET or press ANY button to
EXIT.
8. After RESET is completed, it displays SYSTEM RESET COMPLETED on
the screen.
9. Power off the machine and then power on to complete the Reset procedure.

11
2.Bookkeeping & Adjustment
Access Flow Chart
[STOP3]
SHORT-TERM
[STOP2]
LAST HAND
Enter
Password
[RECORD]
Default password:
Press [START] 8 times
[STOP4]
SYSTEM
CURRENT
DATA
LAST
DATA
[STOP2]
GAME 1
[STOP2]
MAIN GAME
[STOP3]
ADJUSTMENT
[STOP4]
INTERFACE
[STOP2]
SYSTEM
[STOP3]
CHANCE
[STOP4]
TIME
[STOP1]
VOLUME
[STOP2]
PRINTER
[STOP3]
TOUCH
[STOP4]
BILLACCEPTOR
[STOP3]
GAME 2
[STOP4]
GAME 3
[STOP2]
TOTAL
[STOP3]
GAME1
[STOP4]
GAME2
[STOP1]
GAME3
[STOP2]
TOUCH CALIBRATE
[STOP3]
TOUCH REVERSE

12
System Settings
ITEMS
SETTING SELECTION
DEFAULT
MAX. PLAY(TOTAL)
200, 250, 300, 400, 500
500
MIN. PLAY(TOTAL)
25, 50, 100, 150, 200
25
MIN. PLAY FOR
JACKPOT
25, 50, 100, 150, 200
100
JACKPOT MIN
50000,80000,120000, 160000, 200000,
240000, 300000
120000
JACKPOT MAX
80000,120000,160000,200000, 240000,
300000, 500000
500000
COIN RATE
1,4,5,10,15,20,25,50,75,100,200,375,500,1000
100
KEY IN RATE
100
KEY OUT RATE
100
TICKET RATE
500
INTERFACE
DISPENSER , PRINTER ,ATTENDANT
PRINTER
PRINTER COMMAND
PYRAMID_PHX POG(CBM1)
CITIZEN_IDP3551(CBM1)
CUSTOM_TG558(ESC/POS2)
CUSTOM_TG1260II(ESC/POS2)
ITHACA_EPIC950
OTHER(CBM1)
OTHER(ESC/POS)
OTHER(ESC/POS2)
OTHER(STAR)
PYRAMID_PHX
POG(CBM1)
SYSTEM LIMIT
NO, YES
NO
PASSWORD
NO, YES
NO
SCORE BOX
NO, YES
NO
PLAY SCORE
NO, YES
YES
HAND COUNT
NO, YES
NO
DISPLAY
DOLLAR, CREDIT
DOLLAR
PENNY FEATURE
NO, YES
NO
TIME OUT
NO, 15, 20, 30, 60
NO
PRIZE VIEWER
NO, YES
NO

13
ACTION REQUIRED
NO, YES
NO
COLLECT
CONFIRMATION
NO, YES
NO

14
Chance Settings
ITEMS
SETTING SELECTION
DEFAULT
MAIN GAME LEVEL
W,HARD, MIDDLE, EASY
MIDDLE
Touch Screen Calibration
1. If a touch screen is connected,
press [RECORD]>
[SYSTEM]>[INTERFACE]>
[TOUCH] and follow the on-screen
prompts to enter the calibration
screen.
2. Touch center of the cross on the
screen for 3 seconds.
3. Follow the cross when it moves till
the calibration is completed.

15
3.Introduction
Common Features
Single Line.
Free Game/ Bonus Game /Feature.
Configurable Jackpot.
Touch screen / Auto play support.
Lobby
Golden Master is a 3 in 1 Nudge multigame.
Game Menu
Credit
Payout Button

16
4.(Game 1) Golden Buffalo
Game Rule
Press + or - to adjust your play.
Press START to start a new game.
Press RAISE or LOWER to move one symbol UP or DOWN. Only one move
is allowed.
Match the Winning Combination on the pay line and win the prize
accordingly.
A game ends if players move wrong symbol.
can substitute for all symbols except , ,
, , .

17
Feature Game
There’s a chance for every reel to reveal its own unique buffalo coin
(First reel , second reel , third reel ).
When moving the coin symbol to the payline, will trigger the Feature Game.
The reel with the coin appeard on it will grow into 1x6 and will award 3
Respin times.
Only appear symbols during Feature Game.
The coin symbols will be locked on the reel once appear and Respin times
will be reset to 3 times.

18
If during Feature Game, a reel reveals a coin that isn’t belong to the current
reel, the coin will move to the correspondent reel and the reel will grow into
1x6.
The Feature Game ends when all reels are filled with coins or the Respin
times reach to 0.
