IKEA LACKERBIT User manual

$8
LÄCKERBIT

ENGLISH 4

4
ENGLISH
Contents
Safety information 4
Product description 7
Care and cleaning 8
What to do if... 9
Technical data 9
Environment concerns 10
IKEA GUARANTEE 11
Safety information
For your safety and correct operation of the appliance, read this
manual carefully before installation and use. Always keep these
instructions with the appliance even if you move or sell it. Users must
fully know the operation and safety features of the appliance.
The wire connection has to be done by specialized technician.
Recommendations and suggestions
• This appliance is intended to be used in household and similar
applications such as:
• Farm houses.
• By clients in serviced apartments, holiday apartments and other
residential type environments.
• The manufacturer will not be held liable for any damages resulting
from incorrect or improper installation.
• The minimum safety distance between the cooker top and the
extractor hood is: for electrical hob 500mm and for gas hob
650mm.
• If the instructions for installation for the gas hob specify a greater
distance, this must be respected.
• Check that the mains voltage corresponds to that indicated on the
rating plate fixed to the inside of the hood.
• For Class I appliances, check that the domestic power supply
guarantees adequate earthing.
• If the extractor is used in conjunction with non-electrical appliances
(e.g. gas burning appliances), a sufficient degree of aeration must
be guaranteed in the room in order to prevent the backflow of
exhaust gas. When the cooker hood is used in conjunction with
appliances supplied with energy other than electric, the negative
pressure in the room must not exceed 0,04 mbar to prevent fumes
being drawn back into the room by the cooker hood.

5
ENGLISH
• WARNING: Failure to install the screws or fixing device in
accordance with these instructions may result in electrical hazards.
• If the supply cord is damaged, it must be replaced from the
manufacturer or its service agent.
• Connect the plug to a socket complying with current regulations,
located in an accessible place.
• With regards to the technical and safety measures to be adopted
for fume discharging it is importat to closely follow the regulations
provided by the local authorities.
• WARNING: Before installing the Hood, remove the protective films
(white and transparent).
• Use only screws and small parts in support of the hood.
Warning: Failure to install the screws or fixing device in
accordance with these instructions may result in electrical hazards.
• Connect the hood to the power net by using a bipolar switch
having a contact gap of at least 3 mm.
• Do not flambè under the range hood; risk of fire.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Children should be supervised to ensure that they do not play with
the appliance.
Accessible parts may become hot when used with cooking
appliances.
• Clean and/or replace the Filters after the specified time period
(Fire hazard).

6
ENGLISH
Use
• Switch off or unplug the appliance from
the mains supply before carrying out any
maintenance work.
• The extractor hood has been designed
exclusively for domestic use to eliminate
kitchen smells.
• Never use the hood for purposes other
than for which it has been designed.
• Never leave high naked flames under the
hood when it is in operation.
• Adjust the flame intensity to direct it onto
the bottom of the pan only, making sure
that it does not engulf the sides.
• Deep fat fryers must be continuously
monitored during use: overheated oil can
burst into flames.
Care and cleaning
• Activated charcoal filter these filters
are not washable and cannot be
regenerated, and must be replaced
approximately every 4 months of
operation, or more frequently with heavy
usage.
• Grease filters the filters must be cleaned
every 2 months of operation, or more
frequently for particularly heavy usage,
and can be washed in a dishwasher.
• Clean the hood using a damp cloth and
a neutral liquid detergent.

7
ENGLISH
Product description
Perimeter panel
Hood body
Lighting
Grease filter
Control panel








Lights
To turn the lights ON, press the dial
and release it so that it pops out
of its housing.
To turn the lights OFF, push the dial
back inwards, returning it to the
OFF position
Motor
Press the dial and release it so
that it pops out of its housing, then
turn the dial counterclockwise to
select one of the available suction
speeds.
Control Panel

8
ENGLISH
Care and cleaning
Switch off or unplug the appliance from
the mains supply before carrying out any main-
tenance work.
IMPORTANT Clean the hood using a damp
cloth and a neutral liquid detergent.
Charcoal Filter
These filters are not washable and cannot be
regenerated, and must be replaced approxi-
mately every 4 months of operation, or more
frequently with heavy usage.
Grease Filters
Clean or replace the filters continuously accord-
ing to below time intervals, to maintain good
performance of the hood and to prevent a po-
tential fire hazard, caused by excessive grease
build-up.
The grease filters must be cleaned every 2
months of operation, or more frequently for
particularly heavy usage, and can be washed in
a dishwasher.
Opening Perimeter Panel
Open the Panel by pulling it. Clean the outside
with a damp cloth and neutral detergent. Clean
the inside using a damp cloth and neutral deter-
gent; do not use wet cloths or sponges, or jets of
water; do not use abrasive substances.

9
ENGLISH
Replacing the lamps
Remove the snap-on lamp cover by levering it
from under the metal ring, supporting it with one
hand. Remove the halogen lamp from the lamp
holder by pulling gently. Replace the lamp with
a new one of the same type, making sure that
you insert the two pins properly into the housings
on the lamp holder. Replace the snap-on lamp
cover. 20 W - 12V halogen light. Connection
type: G4, Length 30mm.
[
Lamp Power (W) Socket Voltage (V) Dimension (mm) ILCOS Code
20 G4 12 33 x 9 HSG/C/UB-20-12-G4

10
ENGLISH
What to do if...
PROBLEM POSSIBLE CAUSE SOLUTION
Appliance not stable The appliance is not correctly installed Follow the Installation instruction enclosed to
the appliance.
Appliance is not in horizontal position The appliance is not correctly installed Follow the Installation instruction enclosed to
the appliance.
Performance in terms of oil capture
arent satisfying Oil and grease on metal lters Follow the cleaning frequency of lters as described in the user manual
Appliance doesn't work The appliance is not correctly connected
Verify that the main cable is connected to
the motor group or the plug is connected
to the socket
The lamp is not working The lamp is not correctly xed Verify that the lamp is screwed properly to
the lampholder
The lamp is not working The lamp is faulty Replace the lamp bulb
If there is a fault, first try to find a solution to the
problem yourself. If you cannot find a solution
to the problem yourself, contact an authorized
service center.
If you operated the appliance wrongly, or
the installation was not carried out according
to the Assembly instructions, the visit from the
After Sales Service technician may not take
place free of charge, even during the warranty
period.
Technical data
Product Type Island hood / Wall mounted hood
Dimensions
Width
Height
Depth
600 mm
400 mm
420 mm
Lamp 2 x 20W
Total Connection Rating 180 W
Type of lamp and socket Halogen 12V 20W G4 / Length 30mm
Airow Max - Exhaust -
Noice Max - Exhaust -
Airow Max - Recirculation 320 m3/h
Noice Max - Recirculation 76 dB(A)
Installation Min. Height - Gas Hob 650 mm
Installation Min. Height - Electric Hob 500 mm
Weight 17,7 Kg
