Ikegami ULE-217-HDR User manual

Please read this manual thoroughly before use, and keep it handy for future reference.
EDITION : September 2019
21.5" 3G-SDI BROADCAST MONITOR
ULE-217-HDR
USER MANUAL

2User ManualVisit the Ikegami website at https://www.ikegami.com/
Safety Instrucon
Installaon
Funcon
Trouble Shoong
Specicaon
1. Important Safety Instrucon
1. Package
2. OSD Control and Funcon
1. Monitor Switch Funcon
2. Interface
CONTENTS
3
4
6
13
11
3
4
8
5
6
.......................................................................................................................................................................................
.......................................................................................................................................................................................................
...............................................................................................................................................................
..........................................................................................................................................................................................
...................................................................................................................................................................................................
.......................................................................................................................................................
................................................................................................................................................................................................ ..
..............................................................................................................................................................
................................................................................................................................................................................................
..........................................................................................................................................................................................................

3User Manual Visit the Ikegami website at https://www.ikegami.com/
1. Read all warnings.
2. Follow all instrucons to ensure longevity of monitor.
3. Do not place the monitor near water.
4. Clean only with dry cloth.
5. Do not block any venlaon openings. Install in accordance with the manufacturer’s instrucons.
6. Do not install near any heat sources such as radiators, heat registers,stoves, or other heat generang
devices.
7. Do not override the safety purpose of the polarized or grounding-type plug.
8. A polarized plug has two blades with one wider than the other.
9. A grounding type plug has two blades and a third grounding prong.
10. The wide blade or the third prong are provided for your safety.
11. If the provided plug does not t into your outlet, consult with electrician for replacement of the outlet.
12. Protect the power cord from being walked on or pinched parcularly at plugs, convenience receptacles
and the point where it connects to the monitor.
13. Only use aachment/accessories specied by the manufacturer.
14. Use only with the cart, stand, tripod, bracket or table specied by the manufacturer or sold with the
monitor. When a cart is used, use cauon when moving the cart & monitor in combinaon to avoid
injuries.
15. Unplug the monitor during lightning storms or when unused for long periods of me.
16. Refer all servicing to qualied service personnel. Servicing is required when the monitor has been
damaged in any way.
The monitor shall not be exposed to dripping or splashing and objects containing liquids, such as vases
shall be placed near the monitor.
The monitor should have ample distance (e.g. 10cm) from the wall for sucient venlaon.
The device has been tested for conformance to safety regulaons and requirements, and has been cered for
internaonal use. However, like all electronic equipment, the device should be used with care. Please read and follow
the safety instrucons to protect yourself from possible injury and to minimize the risk of damage to the unit.
Important Safety Instruction
SAFETY INSTRUCTION

4User ManualVisit the Ikegami website at https://www.ikegami.com/
The following tools may be required depending on your installaon.
Your Ikegami monitor is shipped with all proper installaon hardware and components. If there are parts missing
and/or damaged, please stop the installaon and contact Ikegami at [phone].
Electronic Stud Finder Protecve Eye-wearPencil Level Phillips Screwdriver
Assembly Components - provided
Installation Tools
LED Monitor (Qty 1) &
Base Stand (Qty 1set)
User Manual (Qty 1) DC 15V Power Supply (Qty 1)
100-240V Power Cable (Qty 1)
INSTALLATION

5User Manual Visit the Ikegami website at https://www.ikegami.com/
CONNECT EXTERNAL EQUIPMENT
Interface Input Ports
q rw e t y u
1. 3G-SDI IN / OUT
2. USB (Only for program upgrades, do not use if non-
professionals)
3. HDMI IN
4. VGA
5. AUDIO IN
6. AUDIO OUT
7. DC 15V IN

6User ManualVisit the Ikegami website at https://www.ikegami.com/
Monitor Button Function
CONTROL AND FUNCTION
q rw e t y u
1. Source
Select an input source
2. Menu
Enter the MENU, save the adjustment of sub-menu
and exit the OSD
3. Le & Right ◄ ►
Change the value on selected menu
4. Exit
Exit the MENU or go back to previous MENU selecon
5. FN
6. Power
Monitor power on / o
7. LED Indicator
Blue color: monitor on
Red color: monitor o
User denable switch. Default funcon is 'HDR'

7User Manual Visit the Ikegami website at https://www.ikegami.com/
CONTROL AND FUNCTION
Monitor Button Function
Shortcut key: FN user-denable funcon switch
1. Select "MEMU / SYSTEM / FN Conguraon" to custom FN shortcut seng. Then press ◄ ► buon to choose opons.
2. Press "MENU" to conrm opon as default, then press EXIT to exit.
Default funcon: HDR
◄ ► Switch Operaon
1. Press ◄ ► buon to acvate the Volume bar when not under the menu display.
2. Press again to adjust the value of opon directly.
3. Press 'EXIT' to exit if accidentally enter the menu.
4. Aer enter the Volume menu, press 'MENU' to select between volume, brightness, contrast, saturaon, nt and sharpness.
MENU Operaon
1. When power on, press 'MENU' on the device, the menu will display on the screen.
2. Press buon to choose sub-menu
3. Then press 'MENU' buon to conrm
4. Press 'EXIT' buon to return/exit 'MENU/SUB-MENU'.
Funcon of FN switch can also be customized: HDR, Mute, Image Flip, Display Scan and Aspect.

8User ManualVisit the Ikegami website at https://www.ikegami.com/
Brightness
Contrast
Saturaon
Setup the brightness
Setup the contrast
Setup the saturation
0 ~ 100
0 ~ 100
0 ~ 100
Tint
Sharpness
Color Temperature
Red Gain
Green Gain1)
Blue Gain1)
Red Oset1)
Green Oset1)
Blue Oset1)
Setup the tint
Setup the sharpness
Setup the color temperature
Setup the Red contrast(gain) level
Setup the Green contrast(gain) level
Setup the Blue contrast(gain) level
Setup the Red brightness(offset) level
Setup the Green brightness(offset) level
Setup the Blue brightness(offset) level
0 ~ 100
0 ~ 100
6500⁰K, 7500⁰K, 9300⁰K, User
0 ~ 255
0 ~ 255
0 ~ 255
0 ~ 511
0 ~ 511
0 ~ 511
FUNCTION VALUE
CONTROL AND FUNCTION
1) In 'User' mode, users can dene RGB Gain and Bias values for own purpose

9User Manual Visit the Ikegami website at https://www.ikegami.com/
CONTROL AND FUNCTION
Function
PC
Auto
Aspect
Phase
Fit the image size automatically
Setup the display ratio
Adjust the vertical timing of screen image
OFF, ON
16:9, 4:3
0 ~ 100
Display Scan
Clock
H-Posion
HDR
V-Posion
Display the scan mode
Adjust the number of horizontal picture element
Adjust the horizontal position of picture
Setup the HDR
Adjust the vertical position of picture
Fullscan, Overscan, Underscan
0 ~ 100
0 ~ 100
OFF, HLG, HDR10_300,
HDR10_1000, HDR10_10000
0 ~ 100
FUNCTION
FUNCTION
VALUE
VALUE
Only available in VGA mode

10 User ManualVisit the Ikegami website at https://www.ikegami.com/
CONTROL AND FUNCTION
Audio
System
Volume
Language
Mute
OSD Timer
Adjust volume on monitor
Set the language of the OSD menu
Turn on/off the audio
Set the OSD display time
0 ~ 100
English, Chinese
OFF, ON
10 , 20, 30 sec
OSD Transparency
FLIP Image
Backlight
EDID Switch
FN Conguraon
Reset
Set the OSD MENU transparency
Flip the display image
Adjust the back light
Set the EDID switch level
Set up shortcut functions
Reset the monitor settings to factory default
OFF, LOW, MIDDLE, HIGH
OFF, H, V, H/V
User, Auto
EDID 2.0, EDID 1.4
HDR, Mute, Image Flip, Display Scan, Aspect
OFF, ON
FUNCTION
FUNCTION
VALUE
VALUE

11User Manual Visit the Ikegami website at https://www.ikegami.com/
SPECIFICATION
Display
Dimension &
Weight
Audio
3G-SDI In / Out
HDMI In
RGB In
USB
Audio In / Out
Interface
General
Panel Type
Response Time
Aspect Ratio
Speaker
Operating Temperature
Weight
Dimensions (W x H x D)
Electrical Ratings
Power Consumption
Accessories
Max. Resolution
Case Type
Pixel Pitch
Brightness
Contrast Ratio
Color Depth
Viewing Angle
Black Metal
500 cd/m²
R/L : 89°/ 89° U/D : 89°/ 89°
16 : 9
2 x 2W
1000 : 1(Typ.)
32 - 122°F / 0 - 50°C
16.7 Million Colors
1 / 1 (BNC, 1 input / loop-through out)
1
1
1
1 / 1
Model No. ULE-217-HDR
21.5'' LED Backlit Monitor
0.24795 (H) x 0.24795 (V) mm
1920 (H) x 1080 (V) @60Hz
< 20 ms
20.32 x 12.99 x 1.72” (516.0 x 330.0 x 43.6 mm )
≤ 30 W
Monitor x1, Power Adapter x1, Base Stand x1, Manual x1
DC15V (AC100 ~ 240V[50/60Hz])
5.6 kg )12.3lbs (

12 User ManualVisit the Ikegami website at https://www.ikegami.com/
SMPTE 425M - A&B (YCbCr 4:2:2)
SMPTE 274M (YCbCr 4:2:2)
SMPTE 296M (YCbCr 4:2:2)
SMPTE 125M (YCbCr 4:2:2)
HDMI
VGA
Input
Signal
Format
SDI
1080p ( 60/59.94/50 )
1080i (60/59.94/50), 1080p (30/29.97/25/24/23.98),
1080Psf (30/29.97/25/24/23.98),
720P(60/59.94/50/30/29.97/25/24/23.98)
525i (NTSC 59.94)
625i (PAL 50)
525i/625i/480p/576p
720p (60/59.94/50/30/29.97/25/24/23.98)
1080i (60/59.94/50)
1080p (60/59.94/50/30/29.97/25/24/23.98)
3840x2160p (60/59.94/50/30/29.97/25/24/23.98)
4096x2160p (60/50/29.97/25/24/23.98)
VGA, SGA, XGA, SXGA, WXGA, WUXGA
SPECIFICATION
Special Features
EDIT Switch
HDR / SDR
RGB Gain
RGB Bias
Support
-128 to +128
-128 to +128
Model No. ULE-217-HDR
EDID 2.0 / EDID 1.4

13User Manual Visit the Ikegami website at https://www.ikegami.com/
TROUBLESHOOTING GUIDE
At start
We recommend that you test with dierent input sources when you have trouble with
the current input source. If symptom persists, follow the instrucons below. Aer
following the instrucons below, please contact Ikegami at [phone].
- Check the following before calling for service.
- If the same problems connue aer checking, contact the reseller you purchased the monitor from.
Note: due to constant eort to improve products and product features, specicaons may change without noce.
Only black-and-white
display
Power on but no pictures
Wrong or abnormal colors
When on the picture
shows size error
Other problems
Check whether the color saturaon is properly setup.
Check whether the cables of Video, HDMI, RGB and SDI are correctly connected. Please use the
standard power adapter coming with the product package. Improper power input may cause
the device.
Check whether the cables are correctly and properly connected. Broken or loose pins of the
cables may cause a bad connecon.
Press “MENU → Function → Underscan” to zoom in/out pictures automatically when receiving
HDMI signals
Please press menu switch and choose “MENU→SYSTEM→ Reset →ON”
