7 –INSTALLATION
This machine can work according to the parameters provided by the manufacturer if correctly installed and if
the minimum requirements are observed, as follows:
- It must be used indoor and with temperatures from +5 to + 40 ° C.
- The relative humidity of the environment must not be over 95%.
- The nominal value of the voltage must be between ± 10% and the frequency must be between ± 2% of the
nominal value.
The floor must have a proper loading capacity and be flat.
Floor space, operator position and working area are indicated in the included drawing that concerns only the
bandsaw, without optional accessories.
The worktable must be levelled by using the screws and nuts ( not supplied) placed in the little feet holes.
The machine has to be fixed to the floor . To grant the return of the coolant that goes onto the bars to be cut,
we suggest you: level the work-table with about 5 mm height each 2 meters length to the unload side ( right
side).
The included electrical schemes reproduce the necessary details to arrange the connections, to be
suited for a 4 KW power request.
Earthing of all the electric parts with a dedicated GREEN/YELLOW wire, connected with a TN system
to the supply cable. A supplementary earthing point –indicated with PE –can be located on the
metallic structure of the machine.
At the origin of the power supply cables a device (such as fuses) to protect against overloading has
to be installed. On the models equipped with electronic variable-speed drive unit (ESC), in order to
connect the differential protection on the power supply line, switches with a threshold of interference
on the power dissipation of not less than 300 mA (size 0.3 A or higher is recommended) have to be
employed, having possibly time adjustment availability (0>1.5 sec).
E.M.C. - Electromagnetic noise
The user is responsible for installing and using this saw according to the manufacturer’s guidelines outlined in
this manual. This equipment complies with the protection requirements established by the Directives
2006/42/CE, 2004/108/CE, concerning Electromagnetic Compatibility (EMC). It is in compliance also with the
technical guidelines of the Norms EN 55011, EN 50082-2 and it is intended for industrial and not for
household use.
Before installing the machine the user must take into account possible electromagnetic problems of the
working area. In particular we suggest to install the equipment away from:
- signalling, control and telephone cables;
- radio-television transmitters and receivers;
The supply cable has to be as short as possible, with no twists. All doors, coverings and frame have to be
closed when the saw is running. Do not make any modifications to the machine except for adjustments and
replacements allowed/recommended by the manufacturer. Follow the maintenance schedule.
8 –TRANSPORT & LIFTING
To move and transport the saw the procedures described below have to be followed. In any case, make sure
that the lifting equipment and the means of transport have a suited loading capacity (about 700 kg).
